Vishay 40L40CW, 40L45CW Data Sheet

Vishay High Power Products

Schottky Rectifier, 2 x 20 A

40L40CW/40L45CW

Base

common

cathode

2

FEATURES

• 150 °C TJ operation

• Center tap TO-247 package

• High purity, high temperature epoxy encapsulation for
enhanced mechanical strength and moisture resistance

• Very low forward voltage drop

• High frequency operation

• Guard ring for enhanced ruggedness and long term
reliability

• Designed and qualified for industrial level

TO-2 47 AC

13

Anode

1

Common

cathode

Anode

2

2

DESCRIPTION

PRODUCT SUMMARY

I

F(AV)

V

R

2 x 20 A

40/45 V

The 40L..CW center tap Schottky rectifier has been
optimized for very low forward voltage drop with moderate
leakage. The proprietary barrier technology allows for
reliable operation up to 150 °C junction temperature. Typical
applications are in parallel switching power supplies.

MAJOR RATINGS AND CHARACTERISTICS

SYMBOL CHARACTERISTICS VALUES UNITS

I

F(AV)

V

RRM

I

FSM

V

F

T

J

Rectangular waveform 40 A

40/45 V

tp = 5 µs sine 1240 A

20 Apk, TJ = 125 °C (per leg, typical) 0.42 V

- 55 to 150 °C

VOLTAGE RATINGS

PARAMETER SYMBOL 40L40CW 40L45CW UNITS

Maximum DC reverse voltage V

Maximum working peak reverse voltage V

R

RWM

40 45 V

ABSOLUTE MAXIMUM RATINGS

PARAMETER SYMBOL TEST CONDITIONS VALUES UNITS

Maximum average
forward current
See fig. 5

Maximum peak one cycle non-repetitive
surge current per leg
See fig. 7

Non-repetitive avalanche energy per leg E

Repetitive avalanche current per leg I

Document Number: 93344 For technical questions, contact: [e-mail]
Revision: 21-Aug-08 1

per leg

per device 40

I

F(AV)

I

FSM

AR

50 % duty cycle at TC = 122 °C, rectangular waveform

5 µs sine or 3 µs rect. pulse

10 ms sine or 6 ms rect. pulse 350

TJ = 25 °C, IAS = 3 A, L = 4.4 mH 20 mJ

AS

Current decaying linearly to zero in 1 µs
Frequency limited by T

maximum VA = 1.5 x VR typical

J

Following any rated load
condition and with rated
V

applied

RRM

20

1240

A

3A

www.vishay.com

40L40CW/40L45CW

Vishay High Power Products

Schottky Rectifier, 2 x 20 A

ELECTRICAL SPECIFICATIONS

PARAMETER SYMBOL TEST CONDITIONS TYP. MAX. UNITS

20 A

Maximum forward voltage drop per leg
See fig. 1

V

FM

40 A 0.61 0.69

(1)

20 A

40 A 0.60 0.70

Reverse leakage current per leg
See fig. 2

I

RM

Threshold voltage V

Forward slope resistance r

Maximum junction capacitance per leg C

Typical series inductance per leg L

F(TO)

TJ = 25 °C

(1)

T

= 100 °C 20 80

J

TJ =TJ maximum

t

VR = 5 VDC (test signal range 100 kHz to 1 MHz) 25 °C - 1500 pF

T

Measured lead to lead 5 mm from package body 7.5 - nH

S

Maximum voltage rate of change dV/dt Rated V

T

= 25 °C

J

= 125 °C

T

J

V

= Rated V

R

R

R

0.48 0.53

0.42 0.49

-1.5

0.27 V

8.72 mΩ

10 000 V/µs

Note

(1)

Pulse width < 300 µs, duty cycle < 2 %

THERMAL - MECHANICAL SPECIFICATIONS

PARAMETER SYMBOL TEST CONDITIONS VALUES UNITS

Maximum junction and storage
temperature range

Maximum thermal resistance,
junction to case per leg

Maximum thermal resistance,
junction to case per package

Typical thermal resistance,
case to heatsink

Approximate weight

Mounting torque

minimum

maximum 12 (10)

Marking device Case style TO-247AC (JEDEC)

, T

T

J

Stg

DC operation
See fig. 4

R

thJC

DC operation 0.8

R

thCS

Mounting surface, smooth and greased 0.24

- 55 to 150 °C

1.6

°C/W

6g

0.21 oz.

Non-lubricated threads

6 (5)

kgf ⋅ cm

(lbf ⋅ in)

40L40CW

40L45CW

V

mA

www.vishay.com For technical questions, contact: [e-mail]

Document Number: 93344

2 Revision: 21-Aug-08

40L40CW/40L45CW

Schottky Rectifier, 2 x 20 A

1000

100

TJ = 150 °C
T

= 125 °C

J

= 25 °C

T

10

1

- Instantaneous Forward Current (A)

F

I

0

0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6 1.8

V

- Forward Voltage Drop (V)

FM

Fig. 1 - Maximum Forward Voltage Drop Characteristics

J

(Per Leg)

10 000

Vishay High Power Products

1000

100

- Reverse Current (mA)

R

0.01

I

0.001

TJ = 150 °C

TJ = 125 °C

TJ = 100 °C

10

TJ = 75 °C

1

TJ = 50 °C

0.1

0

TJ = 25 °C

1051520

V

- Reverse Voltage (V)

R

Fig. 2 - Typical Values of Reverse Current vs.

Reverse Voltage (Per Leg)

25 30 35

40

45

1000

- Junction Capacitance (pF)

T

C

100

0

10 20 40 5030

TJ = 25 °C

VR - Reverse Voltage (V)

Fig. 3 - Typical Junction Capacitance vs. Reverse Voltage (Per Leg)

10

1

0.1

- Thermal Impedance (°C/W)

thJC

Z

0.01

0.00001 0.0001 0.001 0.01 0.1 1

Single pulse

(thermal resistance)

D = 0.75
D = 0.50
D = 0.33
D = 0.25
D = 0.20

t1 - Rectangular Pulse Duration (s)

Fig. 4 - Maximum Thermal Impedance Z

Characteristics (Per Leg)

thJC

P

DM

Notes:

1. Duty factor D = t

2. Peak TJ = PDM x Z

t

1

t

2

1/t2

+ T

thJC

C

10 100

Document Number: 93344 For technical questions, contact: [e-mail]

www.vishay.com

Revision: 21-Aug-08 3

40L40CW/40L45CW

Vishay High Power Products

150

140

130

120

110

Allowable Case Temperature (°C)

100

Square wave (D = 0.50)
80 % rated V

See note (1)

0

I

F(AV)

applied

R

1051520

- Average Forward Current (A)

Fig. 5 - Maximum Allowable Case Temperature vs.

Average Forward Current (Per Leg)

10 000

Schottky Rectifier, 2 x 20 A

DC

Average Power Loss (W)

25 30

At any rated load conditon
and with rated V
following surge

RRM

applied

18

D = 0.20

16

D = 0.25
D = 0.33

14

D = 0.50
D = 0.75

12

10

8

6

4

2

0

0

I

F(AV)

1051520

- Average Forward Current (A)

DC

Fig. 6 - Forward Power Loss Characteristics

(Per Leg)

RMS limit

3025

1000

- Non-Repetitive Surge Current (A)

100

FSM

I

10

tp - Square Wave Pulse Duration (µs)

Fig. 7 - Maximum Non-Repetitive Surge Current (Per Leg)

D.U.T.

Current
monitor

IRFP460

= 25 Ω

R

g

Fig. 8 - Unclamped Inductive Test Circuit

100 1000

L

High-speed

switch

Freewheel

diode

40HFL40S02

10 000

V

+

= 25 V

d

Note

(1)

Formula used: TC = TJ - (Pd + Pd
Pd = Forward power loss = I
Pd

= Inverse power loss = VR1 x IR (1 - D); IR at VR1 = 80 % rated V

REV

F(AV)

) x R

REV

x VFM at (I

thJC

;

F(AV)

/D) (see fig. 6);

R

www.vishay.com For technical questions, contact: [e-mail]

Document Number: 93344

4 Revision: 21-Aug-08

40L40CW/40L45CW

Schottky Rectifier, 2 x 20 A

ORDERING INFORMATION TABLE

Device code

40 L 45 C W -

1 - Current rating (40 = 40 A)

2 - Schottky “L” series

3 - Voltage code

4 - Circuit configuration:

5 - Package:

6 - None = Standard production

Tube standard pack quantity: 25 pieces

C = Common cathode

W = TO-247

PbF = Lead (Pb)-free

51324

Vishay High Power Products

6

40 = 40 V
45 = 45 V

LINKS TO RELATED DOCUMENTS

Dimensions http://www.vishay.com/doc?95223

Part marking information http://www.vishay.com/doc?95226

Document Number: 93344 For technical questions, contact: [e-mail]
Revision: 21-Aug-08 5

www.vishay.com

Assembly
lot code

xxxxxxx

V P119X

A

Part Marking Information

Vishay High Power Products

TO-247

Example: This is a xxxxxxx with

Part number

C

Product version (optional):

P = Lead (Pb)-free
None = Standard

Date code:
Year 1 = 2001
Week 19
Line X

assembly lot code AC,
assembled on WW 19, 2001
in the assembly line ”X”

Document Number: 95226 For technical questions concerning discrete products, contact: [e-mail]
Revision: 28-Nov-08 For technical questions concerning module products, contact: [e-mail]

www.vishay.com

1

DIMENSIONS in millimeters and inches

Outline Dimensions

Vishay High Power Products

TO-247

(2) R/2

2 x R

(2)

(5) L1

0.10 AC

Planting

B

D

C

2 x b2

3 x b

MM

(c)

Section C - C, D - D, E - E

E

1

2

b4

(b1, b3, b5)

(b, b2, b4)

(3)

E/2

3

(4)

2 x e

S

D

L

Base metal

c1

See view B

A

A2

A

D

A

C

A1

DDE E

View B

A

(6)

Ø P

MM

Ø K BD

D2

Thermal pad

Lead assignments

HEXFET

1. - Gate

2. - Drain

3. - Source

4. - Drain

C

C

IGBTs, CoPAK

1. - Gate

2. - Collector

3. - Emitter

4. - Collector

4

(4)
E1

MM

0.01 BD

View A - A

(Datum B)

FP1

D1 (4)

Diodes

1. - Anode/open

2. - Cathode

3. - Anode

SYMBOL

MILLIMETERS INCHES

MIN. MAX. MIN. MAX. MIN. MAX. MIN. MAX.

NOTES SYMBOL

MILLIMETERS INCHES

NOTES

A 4.65 5.31 0.183 0.209 D2 0.51 1.30 0.020 0.051
A1 2.21 2.59 0.087 0.102 E 15.29 15.87 0.602 0.625 3
A2 1.50 2.49 0.059 0.098 E1 13.72 - 0.540 -

b 0.99 1.40 0.039 0.055 e 5.46 BSC 0.215 BSC
b1 0.99 1.35 0.039 0.053 FK 2.54 0.010
b2 1.65 2.39 0.065 0.094 L 14.20 16.10 0.559 0.634
b3 1.65 2.37 0.065 0.094 L1 3.71 4.29 0.146 0.169
b4 2.59 3.43 0.102 0.135 N 7.62 BSC 3
b5 2.59 3.38 0.102 0.133 FP 3.56 3.66 0.14 0.144

c 0.38 0.86 0.015 0.034 FP1 - 6.98 - 0.275
c1 0.38 0.76 0.015 0.030 Q 5.31 5.69 0.209 0.224

D 19.71 20.70 0.776 0.815 3 R 0.452 5.49 0.178 0.216
D1 13.08 - 0.515 - 4 S 5.51 BSC 0.217 BSC

Notes

(1)

Dimensioning and tolerancing per ASME Y14.5M-1994

(2)

Contour of slot optional

(3)

Dimension D and E do not include mold flash. Mold flash shall not exceed 0.127 mm (0.005") per side. These dimensions are measured at
the outermost extremes of the plastic body

(4)

Thermal pad contour optional with dimensions D1 and E1

(5)

Lead finish uncontrolled in L1

(6)

Ø P to have a maximum draft angle of 1.5 to the top of the part with a maximum hole diameter of 3.91 mm (0.154")

(7)

Outline conforms to JEDEC outline TO-247 with exception of dimension c

Document Number: 95223 For technical questions concerning discrete products, contact: [e-mail]

www.vishay.com

Revision: 11-Mar-08 For technical questions concerning module products, contact: [e-mail]

1

Legal Disclaimer Notice

Vishay

Disclaimer

All product specifications and data are subject to change without notice.

Vishay Intertechnology, Inc., its affiliates, agents, and employees, and all persons acting on its or their behalf
(collectively, “Vishay”), disclaim any and all liability for any errors, inaccuracies or incompleteness contained herein
or in any other disclosure relating to any product.

Vishay disclaims any and all liability arising out of the use or application of any product described herein or of any
information provided herein to the maximum extent permitted by law. The product specifications do not expand or
otherwise modify Vishay’s terms and conditions of purchase, including but not limited to the warranty expressed
therein, which apply to these products.

No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted by this
document or by any conduct of Vishay.

The products shown herein are not designed for use in medical, life-saving, or life-sustaining applications unless
otherwise expressly indicated. Customers using or selling Vishay products not expressly indicated for use in such
applications do so entirely at their own risk and agree to fully indemnify Vishay for any damages arising or resulting
from such use or sale. Please contact authorized Vishay personnel to obtain written terms and conditions regarding
products designed for such applications.

Product names and markings noted herein may be trademarks of their respective owners.

Document Number: 91000 www.vishay.com
Revision: 18-Jul-08 1
