Vishay 409CNQ...PbF Series Data Sheet

TO-2 44

PRODUCT SUMMARY

I

F(AV)

V

R

Vishay High Power Products

Schottky Rectifier, 400 A

FEATURES

• 175 °C TJ operation

Lug

terminal

anode 1

Base common

400 A

135/150 V

cathode

Lug
terminal
anode 2

• Center tap module

• Low forward voltage drop

• High frequency operation

• Guard ring for enhanced ruggedness and long term
reliability

• Lead (Pb)-free

• Designed and qualified for industrial level

DESCRIPTION

The 409CNQ... center tap Schottky rectifier module series
has been optimized for low reverse leakage at high
temperature. The proprietary barrier technology allows for
reliable operation up to 175 °C junction temperature. Typical
applications are in high current switching power supplies,
plating power supplies, UPS systems, converters,
freewheeling diodes, welding, and reverse battery
protection.

409CNQ...PbF Series

MAJOR RATINGS AND CHARACTERISTICS

SYMBOL CHARACTERISTICS VALUES UNITS

I

F(AV)

V

RRM

I

FSM

V

F

T

J

Rectangular waveform 400 A

Range 135/150 V

tp = 5 µs sine 20 000 A

200 Apk, TJ = 125 °C (per leg) 0.75 V

Range - 55 to 175 °C

VOLTAGE RATINGS

PARAMETER SYMBOL 409CNQ135PbF 409CNQ150PbF UNITS

Maximum DC reverse voltage V

Maximum working peak reverse voltage V

R

RWM

135 150 V

ABSOLUTE MAXIMUM RATINGS

PARAMETER SYMBOL TEST CONDITIONS VALUES UNITS

Maximum average forward
current
See fig. 5

Maximum peak one cycle non-repetitive
surge current per leg
See fig. 7

Non-repetitive avalanche energy per leg E

Repetitive avalanche current per leg I

per leg

per device 400

I

F(AV)

I

FSM

AR

50 % duty cycle at TC = 129 °C, rectangular waveform

5 µs sine or 3 µs rect. pulse

10 ms sine or 6 ms rect. pulse 2300

TJ = 25 °C, IAS = 5.5 A, L = 1 mH 15 mJ

AS

Current decaying linearly to zero in 1 µs
Frequency limited by T

maximum VA = 1.5 x VR typical

J

Following any rated load
condition and with rated
V

applied

RRM

200

A

20 000

1A

Document Number: 94207 For technical questions, contact: [e-mail]
Revision: 29-Apr-08 1

www.vishay.com

409CNQ...PbF Series

Vishay High Power Products

Schottky Rectifier, 400 A

ELECTRICAL SPECIFICATIONS

PARAMETER SYMBOL TEST CONDITIONS VALUES UNITS

200 A

Maximum forward voltage drop per leg
See fig. 1

V

FM

400 A 1.46

(1)

200 A

400 A 0.89

Maximum reverse leakage current per leg
See fig. 2

I

RM

Maximum junction capacitance per leg C

Typical series inductance per leg L

TJ = 25 °C

(1)

T

= 125 °C 85

J

VR = 5 VDC (test signal range 100 kHz to 1 MHz) 25 °C 6000 pF

T

From top of terminal hole to mounting plane 5.0 nH

S

Maximum voltage rate of change dV/dt Rated V

T

= 25 °C

J

= 125 °C

T

J

V

= Rated V

R

R

R

1.13

0.75

6

10 000 V/µs

Note

(1)

Pulse width < 300 µs, duty cycle < 2 %

THERMAL - MECHANICAL SPECIFICATIONS

PARAMETER SYMBOL MIN. TYP. MAX. UNITS

Maximum junction and storage temperature range T

Thermal resistance, junction to case per leg

Thermal resistance, case to heatsink R

Weight

Mounting torque 35.4 (4) 53.1 (6)

Mounting torque center hole 30 (3.4) 40 (4.6)

Terminal torque 30 (3.4) - 44.2 (5)

Vertical pull - - 80

2" lever pull - - 35

, T

J

Stg

R

thJC

thCS

- 55 - 175 °C

- - 0.19

°C/WThermal resistance, junction to case per module - - 0.095

-0.10-

-68- g

-2.4-oz.

lbf ⋅ in

(N ⋅ m)

lbf ⋅ in

V

mA

www.vishay.com For technical questions, contact: [e-mail]

Document Number: 94207

2 Revision: 29-Apr-08

409CNQ...PbF Series

1000

100

- Instantaneous Forward Current (A)

F

I

10

1

TJ = 175 °C

TJ = 125 °C

TJ = 25 °C

1.0

V

- Forward Voltage Drop (V)

FM

1.5 2.0 2.500.5

Schottky Rectifier, 400 A

- Reverse Current (mA)

R

I

Vishay High Power Products

1000

100

0.1

0.01

0.001

TJ = 175 °C

TJ = 150 °C

10

1

0

TJ = 125 °C

TJ = 100 °C

TJ = 75 °C

TJ = 50 °C

TJ = 25 °C

6030 90 120

V

- Reverse Voltage (V)

R

Fig. 1 - Maximum Forward Voltage Drop Characteristics Fig. 2 - Typical Values of Reverse Current vs.

Reverse Voltage

10 000

150

1000

- Junction Capacitance (pF)

T

C

100

TJ = 25 °C

60 90 120030

V

- Reverse Voltage (V)

R

Fig. 3 - Typical Junction Capacitance vs.

Reverse Voltage

1

0.1

D = 0.75

0.01

- Thermal Impedance (°C/W)

thJC

Z

0.001

0.00001 0.0001 0.001 0.01 0.1 1

Single pulse

(thermal resistance)

D = 0.50

D = 0.33

D = 0.25

D = 0.20

t1 - Rectangular Pulse Duration (s)

Fig. 4 - Maximum Thermal Impedance Z

Characteristics

thJC

10

Document Number: 94207 For technical questions, contact: [e-mail]

www.vishay.com

Revision: 29-Apr-08 3
