Vishay 401CNQ...PbF Series Data Sheet

TO-2 44

PRODUCT SUMMARY

I

F(AV)

V

R

Vishay High Power Products

Schottky Rectifier, 400 A

FEATURES

Lug
terminal
anode 1

Base common

cathode

400 A

40/45 V

Lug
terminal
anode 2

• 175 °C TJ operation

• Center tap module

• Low forward voltage drop

• High frequency operation

• Guard ring for enhanced ruggedness and long term
reliability

• Lead (Pb)-free

• Designed and qualified for industrial level

DESCRIPTION

The 401CNQ... center tap Schottky rectifier module series
has been optimized for low reverse leakage at high
temperature. The proprietary barrier technology allows for
reliable operation up to 175 °C junction temperature. Typical
applications are in high current switching power supplies,
converters, freewheeling diodes, welding and reverse
battery protection.

401CNQ...PbF Series

MAJOR RATINGS AND CHARACTERISTICS

SYMBOL CHARACTERISTICS VALUES UNITS

I

F(AV)

V

RRM

I

FSM

V

F

T

J

Rectangular waveform 400 A

Range 40/45 V

tp = 5 µs sine 25 000 A

200 Apk, TJ = 125 °C (per leg) 0.56 V

Range - 55 to 175 °C

VOLTAGE RATINGS

PARAMETER SYMBOL 401CNQ040PbF 401CNQ045PbF UNITS

Maximum DC reverse voltage V

Maximum working peak reverse voltage V

R

RWM

40 45 V

ABSOLUTE MAXIMUM RATINGS

PARAMETER SYMBOL TEST CONDITIONS VALUES UNITS

Maximum average forward
current
See fig. 5

Maximum peak one cycle non-repetitive
surge current per leg
See fig. 7

Non-repetitive avalanche energy per leg E

Repetitive avalanche current per leg I

per leg

per device 400

I

F(AV)

I

FSM

AR

50 % duty cycle at TC = 147 °C, rectangular waveform

5 µs sine or 3 µs rect. pulse

10 ms sine or 6 ms rect. pulse 3450

TJ = 25 °C, IAS = 24 A, L = 1 mH 270 mJ

AS

Current decaying linearly to zero in 1 µs
Frequency limited by T

maximum VA = 1.5 x VR typical

J

Following any rated load
condition and with rated
V

applied

RRM

200

A

25 000

40 A

Document Number: 94205 For technical questions, contact: [e-mail]
Revision: 29-Apr-08 1

www.vishay.com

401CNQ...PbF Series

Vishay High Power Products

Schottky Rectifier, 400 A

ELECTRICAL SPECIFICATIONS

PARAMETER SYMBOL TEST CONDITIONS VALUES UNITS

200 A

Maximum forward voltage drop per leg
See fig. 1

V

FM

400 A 0.78

(1)

200 A

400 A 0.69

Maximum reverse leakage current per leg
See fig. 2

I

RM

Maximum junction capacitance per leg C

Typical series inductance per leg L

TJ = 25 °C

(1)

T

= 125 °C 180

J

VR = 5 VDC (test signal range 100 kHz to 1 MHz) 25 °C 10 300 pF

T

From top of terminal hole to mounting plane 5.0 nH

S

Maximum voltage rate of change dV/dt Rated V

T

= 25 °C

J

= TJ maximum

T

J

V

= Rated V

R

R

R

0.67

0.56

20

10 000 V/µs

Note

(1)

Pulse width < 300 µs, duty cycle < 2 %

THERMAL - MECHANICAL SPECIFICATIONS

PARAMETER SYMBOL MIN. TYP. MAX. UNITS

Maximum junction and storage temperature range T

Thermal resistance, junction to case per leg

Thermal resistance, case to heatsink R

Weight

Mounting torque 35.4 (4) 53.1 (6)

Mounting torque center hole 30 (3.4) 40 (4.6)

Terminal torque 30 (3.4) - 44.2 (5)

Vertical pull - - 80

2" lever pull - - 35

, T

J

Stg

R

thJC

thCS

- 55 - 175 °C

- - 0.19

°C/WThermal resistance, junction to case per module - - 0.095

-0.10-

-68- g

-2.4-oz.

lbf ⋅ in

(N ⋅ m)

lbf ⋅ in

V

mA

www.vishay.com For technical questions, contact: [e-mail]

Document Number: 94205

2 Revision: 29-Apr-08

401CNQ...PbF Series

1000

TJ = 175 °C

100

10

TJ = 25 °C

- Instantaneous Forward Current (A)

1

F

I

V

FM

0.4 0.6 0.8 1.000.2

- Forward Voltage Drop (V)

Schottky Rectifier, 400 A

TJ = 125 °C

- Reverse Current (mA)

R

I

Vishay High Power Products

10 000

1000

0.001

100

10

0.1

0.01

1

0

TJ = 175 °C

TJ = 150 °C

TJ = 125 °C

TJ = 100 °C

TJ = 75 °C

TJ = 50 °C

TJ = 25 °C

V

2010 30 40 50

- Reverse Voltage (V)

R

Fig. 1 - Maximum Forward Voltage Drop Characteristics Fig. 2 - Typical Values of Reverse Current vs.

Reverse Voltage

10 000

TJ = 25 °C

- Junction Capacitance (pF)

T

C

1000

0

2010 30 40 50 60

VR - Reverse Voltage (V)

Fig. 3 - Typical Junction Capacitance vs. Reverse Voltage

1

0.1

D = 0.75

0.01

- Thermal Impedance (°C/W)

thJC

Z

0.001

0.00001 0.0001 0.001 0.01 0.1 1

Single pulse

(thermal resistance)

D = 0.50
D = 0.33
D = 0.25
D = 0.20

Notes:

1. Duty factor D = t

2. Peak TJ = PDM x Z

t1 - Rectangular Pulse Duration (s)

Fig. 4 - Maximum Thermal Impedance Z

Characteristics (Per Leg)

thJC

P

DM

t

1

t

2

1/t2

+ T

thJC

C

10

Document Number: 94205 For technical questions, contact: [e-mail]

www.vishay.com

Revision: 29-Apr-08 3

401CNQ...PbF Series

Vishay High Power Products

180

160

140

120

Square wave (D = 0.50)
80 % rated V

100

80

0

I

See note (1)

F(AV)

Allowable Case Temperature (°C)

applied

r

10050 150 200

- Average Forward Current (A)

Fig. 5 - Maximum Allowable Case Temperature vs.

Average Forward Current

DC

100 000

Schottky Rectifier, 400 A

Average Power Loss (W)

250 300

At any rated load condition
and with rated V
following surge

RRM

applied

175

150

125

D = 0.20
D = 0.25

100

D = 0.33
D = 0.50

75

D = 0.75

50

25

0

0

I

F(AV)

10050 150 200 250 300

- Average Forward Current (A)

DC

Fig. 6 - Forward Power Loss Characteristics

RMS limit

10 000

- Non-Repetitive Surge Current (A)

1000

FSM

I

10

tp - Square Wave Pulse Duration (µs)

Fig. 7 - Maximum Non-Repetitive Surge Current

D.U.T.

Current
monitor

IRFP460

= 25 Ω

R

g

Fig. 8 - Unclamped Inductive Test Circuit

100 1000

L

High-speed

switch

Freewheel

diode

40HFL40S02

10 000

V

+

= 25 V

d

Note

(1)

Formula used: TC = TJ - (Pd + Pd
Pd = Forward power loss = I
Pd

= Inverse power loss = VR1 x IR (1 - D); IR at VR1 = 80 % rated V

REV

F(AV)

) x R

REV

x VFM at (I

;

thJC

/D) (see fig. 6);

F(AV)

R

www.vishay.com For technical questions, contact: [e-mail]

Document Number: 94205

4 Revision: 29-Apr-08

401CNQ...PbF Series

ORDERING INFORMATION TABLE

Device code

40 1 C N Q 045 PbF

- Average current rating (x 10)

1

- Product silicon identification

2

- C = Circuit configuration

3

- N = Not isolated

4

- Q = Schottky rectifier diode

5

6

- Voltage ratings

7 - Lead (Pb)-free

Schottky Rectifier, 400 A

51324

Vishay High Power Products

67

040 = 40 V
045 = 45 V

LINKS TO RELATED DOCUMENTS

Dimensions http://www.vishay.com/doc?95021

Document Number: 94205 For technical questions, contact: [e-mail]
Revision: 29-Apr-08 5

www.vishay.com

DIMENSIONS in millimeters (inches)

3

2

3

1

Ø 5.2 (Ø 0.20)

9.6 (0.37) MIN.

93 (3.66) MAX.

¼" - 20 UNC

80 (3.15)

13 (0.51)

35 (1.37) REF.

7 (0.27)
6 (0.23)

17.5 (0.69)

16.5 (0.65)

21 (0.82)
20 (0.78)

Ø 7.2 (Ø 0.28)

(2 places)

12.6 (0.5)

Outline Dimensions

Vishay Semiconductors

TO-244

Document Number: 95021 For technical questions, contact: [e-mail]
Revision: 25-Jun-07 1

www.vishay.com
