ViewSonic VA902, VA902B - 19"" LCD Monitor, VA902b User Manual

ViewSonic

®

VA902/VA902b

LCD Display

ViewSonic VA902/VA902b

Contents

TCO Information.......................................................................................... i

Compliance Information.............................................................................. 1

Important Safety Instructions...................................................................... 2

Copyright Information................................................................................. 3

Product Registration................................................................................... 3

Getting Started

Package Contents ...................................................................................... 4

Precautions ................................................................................................4

Quick Installation ........................................................................................ 5

Wall Mounting (Optional) ............................................................................ 6

Using the LCD Display

Setting the Timing Mode............................................................................. 7

OSD and Power Lock Settings................................................................... 7

Adjusting the Screen Image ....................................................................... 8

Main Menu Controls ................................................................................. 10

Other Information

Specifications ........................................................................................... 13

Troubleshooting........................................................................................ 14

Customer Support .................................................................................... 15

Cleaning the LCD Display ........................................................................ 16

Limited Warranty ...................................................................................... 17

ViewSonic VA902/VA902b i

TCO Information

Congratulations!

You have just purchased a TCO’99 approved and labelled product!
Your choice has provided you with a product developed for
professional use. Your purchase has also contributed to reducing the
burden on the environment and also to the further development of
environmentally adapted electronics products.

Why do we have environmentally labelled computers?

In many countries, environmental labelling has become an established method for encouraging
the adaptation of goods and services to the environment. With the growing manufacture and
usage of electronic equipment throughout the world, there is a recognized concern for the
materials and substances used by electronic products with regards to their eventual recycling
and disposal. By proper selection of these materials and substances, the impact on the
environment can be minimized.

There are also other characteristics of a computer, such as energy consumption levels, that are
important from the viewpoints of both the work (internal) and natural (external) environments.
Electronic equipment in offices is often left running continuously, resulting in unnecessary
consumption of large amounts of energy and additional power generation. From the standpoint
of carbon dioxide emissions alone, it is vital to save energy.

What does labelling involve?

The product meets the requirements for the TCO’99 scheme which provides for international
and environmental labelling of personal computers and/or displays. The labelling scheme was
developed as a joint effort by the TCO (The Swedish Confederation of Professional
Employees), Svenska Naturskyddsforeningen (The Swedish Society for Nature Conservation)
and Statens Energimyndighet (The Swedish National Energy Administration).

Approval requirements cover a wide range of issues: ecology, ergonomics, emission of
electrical and magnetical fields, energy consumption and electrical safety.

Ecological criteria impose restrictions on the presence and use of heavy metals, brominated
and chlorinated flame retardants, and other substances. The product must be prepared for
recycling and the manufacturing site(s) shall be certified according to ISO14001 or EMAS
registered.

Energy requirements include a demand that the system unit and/or display, after a certain
period of inactivity, shall reduce its power consumption to a lower level in one or more stages.
The length of time to reactivate the system unit shall be reasonable for the user.

Labelled products must meet strict environmental demands, for example, in respect of the
reduction of electrical and magnetical fields as well as work load and visual ergonomics.

ViewSonic VA902/VA902b ii

Below you will find a brief summary of the ecological requirements met by this product. The
complete ecological criteria document can be found at TCO Development’s website
http://www.tcodevelopment.com or may be ordered from:

TCO Development

SE-114 94 STOCKHOLM, Sweden
Fax: [phone]
E-mail: [e-mail]
Information regarding TCO’99 approved and labelled products may also be obtained at
http://www.tcodevelopment.com

Ecological requirements

Flame retardants

Flame retardants may be present in printed wiring board laminates, cables, and housings. Their
purpose is to prevent, or at least to delay the spread of fire. Up to 30% by weight of the plastic
in a computer casing can consist of flame retardant substances. Many flame retardants contain
bromine or chlorine, and these flame retardants are chemically related to PCBs
(polychlorinated biphenyls). Both the flame retardants containing bromine or chlorine and the
PCBs are suspected of giving rise to health effects, including reproductive damage in fish­eating birds and mammals, due to the bio-accumulative* processes when not disposed of in
accordance with strict standards for disposal.

TCO’99 requires that plastic components weighing more than 25 grams shall not contain flame
retardants with organically bound bromine or chlorine. Flame retardants are allowed in the
printed wiring board laminates due to the lack of commercially available alternatives.

Cadmium**

Cadmium is present in rechargeable batteries and in the colour-generating layers of certain
computer displays. TCO’99 requires that batteries, the colour-generating layers of display
screens, and the electrical or electronics components shall not contain any cadmium.

Mercury**

Mercury is sometimes found in batteries, relays and switches. TCO’99 requires that batteries
shall not contain any mercury. It also demands that mercury is not present in any of the
electrical or electronics components associated with the labelled unit. There is however one
exception. Mercury is, for the time being, permitted in the back light system of flat panel
monitors as there today is no commercially available alternative. TCO aims on removing this
exception when a mercury free alternative is available.

Lead**

Lead can be found in picture tubes, display screens, solders and capacitors. TCO’99 permits
the use of lead due to the lack of commercially available alternatives, but in future
requirements TCO Development aims at restricting the use of lead.

* Bio-accumulative is defined as substances which accumulate in living organisms.
**Lead, Cadmium and Mercury are heavy metals which are bio-accumulative.

ViewSonic VA902/VA902b 1

Compliance Information

For U.S.A.

This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy, and if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.

• Consult the dealer or an experienced radio/TV technician for help.

FCC Warning

To assure continued FCC compliance, the user must use grounded power supply cord and the
cables which are included with the equipment or specified. Also, any unauthorized changes or
modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate this device.

For Canada

This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

For European Countries

CE Conformity

The device complies with the requirements of the EEC directive 89/336/EEC as
amended by 92/31/EEC and 93/68/EEC Art.5 with regard to “Electromagnetic
compatibility,” and 73/23/EEC as amended by 93/68/EEC Art.13 with regard to
“Safety.”

User Information for all Countries

Notice: Use the cables which are included with the unit or specified.

ViewSonic VA902/VA902b 2

Important Safety Instructions

1. Read these instructions completely before using the equipment.

2. Keep these instructions in a safe place.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this equipment near water.

6. Clean with a soft, dry cloth. If further cleaning is required, see “Cleaning the Display” in

this guide for further instructions.

7. Do not block any ventilation openings. Install the equipment in accordance with the
manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other
devices (including amplifiers) that produce heat.

9. Do not attempt to circumvent the safety provisions of the polarized or grounding-type
plug. A polarized plug has two blades with one wider than the other. A grounding type
plug has two blades and a third grounding prong. The wide blade and the third prong are
provided for your safety. If the plug does not fit into your outlet, consult an electrician for
replacement of the outlet.

10. Protect the power cord from being tread upon or pinched, particularly at the plug, and the
point where if emerges from the equipment. Be sure that the power outlet is located near
the equipment so that it is easily accessible.

11. Only use attachments/accessories specified by the manufacturer.

12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or

sold with the equipment. When a cart is used, use caution when moving the cart/
equipment combination to avoid injury from tipping over.

13. Unplug this equipment when it will be unused for long periods of time.

14. Refer all servicing to qualified service personnel. Service is required when the unit has

been damaged in any way, such as: if the power-supply cord or plug is damaged, if liquid
is spilled onto or objects fall into the unit, if the unit is exposed to rain or moisture, or if
the unit does not operate normally or has been dropped.

15. The apparatus shall only be used between 5° tilted forward and 20° tilted backward as
normal operation position. If the tilt angle exceeds 20°, it shall be used for wall mounting
or packaging only.

ViewSonic VA902/VA902b 3

Copyright Information

Copyright © ViewSonic® Corporation, 2005. All rights reserved.
Macintosh and Power Macintosh are registered trademarks of Apple Computer, Inc.
Microsoft, Windows, Windows NT, and the Windows logo are registered trademarks of

Microsoft Corporation in the United States and other countries.
ViewSonic, the three birds logo, OnView, ViewMatch, and ViewMeter are registered
trademarks of ViewSonic Corporation.
VESA is a registered trademark of the Video Electronics Standards Association. DPMS and
DDC are trademarks of VESA.
ENERGY STAR® is a registered trademark of the U.S. Environmental Protection Agency (EPA).
As an ENERGY STAR® partner, ViewSonic Corporation has determined that this product meets
the ENERGY STAR® guidelines for energy efficiency.
Disclaimer: ViewSonic Corporation shall not be liable for technical or editorial errors or
omissions contained herein; nor for incidental or consequential damages resulting from
furnishing this material, or the performance or use of this product.
In the interest of continuing product improvement, ViewSonic Corporation reserves the right

to change product specifications without notice. Information in this document may change
without notice.
No part of this document may be copied, reproduced, or transmitted by any means, for any
purpose without prior written permission from ViewSonic Corporation.

Product Registration

To meet your future needs, and to receive any additional product information as it becomes
available, please register your product on the Internet at: www.viewsonic.com. The ViewSonic
Wizard CD-ROM also provides an opportunity for you to print the registration form, which
you may mail or fax to ViewSonic.

Product disposal at end of product life

THE LAMP IN THIS PRODUCT CONTAINS MERCURY. Please dispose of in accordance
with local, state or federal laws.
ViewSonic is concerned about the preservation of our environment. Please dispose of this
product properly at the end of its useful life. For TCO'03 recycling information, please refer to
our website:

1. USA: www.viewsonic.com/pdf/recyclePlus.pdf

2. Europe: www.viewsoniceurope.com

3. Taiwan: recycle.epa.gov.tw

For Your Records

Product Name:

Model Number:

Document Number:

Serial Number:

Purchase Date:

VA902/b

ViewSonic 19” LCD Display

VS10715

VA902/b-2_UG_ENG Rev. 1A 09-26-05

______________________________

______________________________

ViewSonic VA902/VA902b 4

Getting Started

Congratulations on your purchase of a ViewSonic® LCD display.

Important! Save the original box and all packing material for future shipping needs.

NOTE: The word “Windows” in this user guide refers to the following Microsoft operating
systems: Windows ‘95, Windows NT, Windows ‘98, Windows 2000, Windows Me
(Millennium), and Windows XP.

Package Contents

Your LCD display package includes:

• LCD display

• Power cord

• Video cable

• ViewSonic Wizard CD-ROM

• Quick Start Guide

NOTE: The CD includes the User Guide PDF files and INF/ICM display optimization files.
The INF file ensures compatibility with Windows operating systems, and the ICM file (Image
Color Matching) ensures accurate on-screen colors. ViewSonic recommends that you install
both the INF and ICM files.

Precautions

• Sit at least 18” from the LCD display.

• Avoid touching the screen. Skin oils are
difficult to remove.

• Never remove the rear cover. This LCD
display contains high-voltage parts. You
may be seriously injured if you touch
them.

• Avoid exposing the LCD display to direct
sunlight or another heat source. Orient the
LCD display away from direct sunlight to
reduce glare.

• Always handle the LCD display with care
when moving it.

• Place the LCD display in a well ventilated
area. Do not place anything on the LCD
display that prevents heat dissipation.

• Ensure the area around the LCD display is
clean and free of moisture.

• Do not place heavy objects on the LCD
display, video cable, or power cord.

• If smoke, an abnormal noise, or a strange
odor is present, immediately switch the
LCD display off and call your dealer or
ViewSonic. It is dangerous to continue
using the LCD display.

• Do not rub or apply pressure to the LCD
panel, as it may permanently damage the
screen.

ViewSonic VA902/VA902b 5

Quick Installation

1. Connect power cord (and AC/DC
adapter if required)

2. Connect video cable

• Make sure both the LCD display and
computer are turned OFF

• Connect the video cable from the LCD
display to the computer

Macintosh users: Models older than G3
require a Macintosh adapter. Attach the
adapter to the computer and plug the video

cable into the adapter.

To order a ViewSonic® Macintosh adapter,
contact ViewSonic Customer Support.

3. Turn ON LCD display and computer

Turn ON the LCD display, then turn ON
the computer. This sequence (LCD display
before computer) is important.

NOTE: Windows users may receive a
message asking them to install the INF
file. This is on the CD.

4. Insert the ViewSonic Wizard CD into
the computer’s CD drive.

Follow the on-screen instructions. If your
computer does not have a CD-ROM drive,
see “Customer Support” on page 15.

• Wait for the CD-ROM to auto-start.

NOTE: If the CD-ROM does not auto­start: double-click on the CD-ROM icon in
the Windows Explorer, then double-click
on viewsonic.exe.

• Follow the on-screen instructions.

5. Windows users: Set the timing mode
(resolution and refresh rate)

Example: 1280 x 1024 @ 60 Hz.

For instructions on changing the resolution
and refresh rate, see the graphics card’s
user guide.

Installation is complete. Enjoy your new
ViewSonic LCD display.

To be best prepared for any future
customer service needs: print this user
guide and write the serial number in “For
Your Records” on page 3. (See back of
LCD display.)

You can register your product online at the
ViewSonic website for your region. See
the Customer Support table in this guide.

The ViewSonic Wizard CD-ROM also
provides an opportunity for you to print
the registration form which you may mail
or fax to ViewSonic.

AC IN

AC Outlet

(Wall Socket)

Computer Power Cord

D-SUB

ViewSonic VA902/VA902b 6

Wall Mounting (Optional)

To obtain a wall-mounting kit, contact ViewSonic® or your local dealer. Refer to the
instructions that come with the base mounting kit. To convert your LCD display from a desk­mounted to a wall-mounted display, do the following:

1. Verify that the Power button is turned
Off, then disconnect the power cord.

2. Push the LCD display back and down
flat against the base as shown.

3. Lay the LCD display face down on a
towel or blanket. Notice the four
screw holes on the back cover.

4. Attach the mounting bracket from the
VESA compatible wall mounting kit
(100 mm x 100 mm distance).

5. Attach the LCD display to the wall,
following the instructions in the wall­mounting kit.

Four
screw
holes

Mounted
on the wall

ViewSonic VA902/VA902b 7

Using the LCD Display

Setting the Timing Mode

Setting the timing mode is important for maximizing the quality of the screen image and
minimizing eye strain. The timing mode consists of the resolution (example 1280 x 1024) and
refresh rate (or vertical frequency; example 60 Hz). After setting the timing mode, use the
OSD (On-screen Display) controls to adjust the screen image.

For the best picture quality set your LCD display timing mode to:

VESA 1280 x 1024 @ 60Hz.

To set the Timing Mode:

1. Set the resolution: Right-click on the Windows desktop > Properties > Settings > set the
resolution.

2. Set the refresh rate: See your graphic card's user guide for instructions.

WA R NI N G : Do not set the graphics card in your computer to exceed the maximum refresh

rate of 75Hz; doing so may result in permanent damage to your LCD display.

OSD and Power Lock Settings

• OSD Lock: Press and hold [1] and the up arrow S for 10 seconds. If any buttons are

pressed the message OSD Locked will display for 5 seconds.

• OSD Unlock: Press and hold [1] and the up arrow S again for 10 seconds.

• Power Button Lock: Press and hold [1] and the down arrow T for 10 seconds. If the

power button is pressed the message Power Button Locked will display for 5 seconds. With
or without this setting, after a power failure, your LCD display’s power will automatically
turn ON when power is restored.

• Power Button Unlock: Press and hold [1] and the down arrow T again for 10 seconds.

ViewSonic VA902/VA902b 8

Adjusting the Screen Image

Use the buttons on the front control panel to display and adjust the OSD controls which display
on the screen. The OSD controls are explained at the top of the next page and are defined in
“Main Menu Controls” on page 10.

Main Menu

with OSD controls

Front Control Panel

shown below in detail

Scrolls through
menu options and
adjusts the
displayed control.

Also a shortcut to
display the
Contrast
adjustment control
screen.

Displays the control screen

for the highlighted control.

Also toggles between two

controls on some screens.

Also a shortcut to Auto

Image Adjust.

Power light
Green = ON
Orange = Power Saving

Standby Power
On/Off

Displays the

Main Menu or

exits the

control screen

and saves

adjustments.

ViewSonic VA902/VA902b 9

Do the following to adjust the display setting:

1. To display the Main Menu, press button [1].

NOTE: All OSD menus and adjustment screens disappear automatically after about 15

seconds. This is adjustable through the OSD timeout setting in the setup menu.

2. To select a control to adjust, pressSorTto scroll up or down in the Main Menu.

3. After the desired control is selected, press button [2]. A control screen like the one shown

below appears.

4. To adjust the setting, press the upSor downTbuttons.

5. To save the adjustments and exit the menu, press button [1] twice.

The following tips may help you optimize your display:

• Adjust the computer's graphics card so that it outputs a 1280 x 1024 @ 60Hz video signal to
the LCD display. (Look for instructions on “changing the refresh rate” in the graphics card's
user guide.)

• If necessary, make small adjustments using H. POSITION and V. POSITION until the
screen image is completely visible. (The black border around the edge of the screen should
barely touch the illuminated “active area” of the LCD display.)

The line at the bottom of the screen shows
the current functions of buttons 1 and 2:
Exit or select the Brightness control.

ViewSonic VA902/VA902b 10

Main Menu Controls

Adjust the menu items shown below by using the upSand downTbuttons.

Control Explanation

Auto Image Adjust automatically sizes, centers, and fine tunes the video signal
to eliminate waviness and distortion. Press the [2] button to execute Auto Image
Adjust.

NOTE: Auto Image Adjust works with most common video cards. If this
function does not work on your LCD display, then lower the video refresh rate
to 60 Hz and set the resolution to its pre-set value.

Contrast adjusts the difference between the image background (black level)
and the foreground (white level).

Brightness adjusts background black level of the screen image.

Color Adjust provides several color adjustment modes, including preset color

temperatures and a User Color mode which allows independent adjustment of
red (R), green (G), and blue (B). The factory setting for this product is 6500K
(6500 Kelvin).

sRGB - This is quickly becoming the industry standard for color management,
with support being included in many of the latest applications. Enabling this
setting allows the LCD display to more accurately display colors the way they
were originally intended. Enabling the sRGB setting will cause the Contrast and
Brightness adjustments to be disabled.

9300K - Adds blue to the screen image for cooler white (used in most office
settings with fluorescent lighting).

6500K - Adds red to the screen image for warmer white and richer red.

5400K - Adds green to the screen image for a darker color.

ViewSonic VA902/VA902b 11

Control Explanation

User Color - Individual adjustments for red (R), green (G), and blue (B).

1. To select color (R, G or B) press button [2].

2. To adjust selected color, pressSorT.

3. When all color adjustments are complete, press button [1] twice.

Information displays the timing mode (video signal input) coming from the

graphics card in the computer, the LCD model number, the serial number, and
the ViewSonic® website URL. See your graphics card’s user guide for
instructions on changing the resolution and refresh rate (vertical frequency).
NOTE: VESA 1280 x 1024 @ 60Hz (recommended) means that the resolution
is 1280 x 1024 and the refresh rate is 60 Hertz.

Manual Image Adjust

H./V. Position (Horizontal/Vertical Position) moves the screen image left or

right and up or down. Press button [2] to toggle between Horizontal and
Vertical. The Horizontal setting moves the screen image to the left or to the
right. The Vertical setting moves the screen image up and down.

H. Size (Horizontal Size) adjusts the width of the screen image.

Fine Tune sharpens the focus by aligning text and/or graphics with pixel

boundaries.

NOTE: Try the Auto Adjust function before using the Fine Tune control.

Sharpness adjusts the clarity and focus of the screen image.

ViewSonic VA902/VA902b 12

Control Explanation

Setup Menu displays the menu shown below:

Language Select allows the user to choose the language used in the menus and

control screens.

Resolution Notice advises the optimal resolution to use.

OSD Position allows the user to move the OSD menus and control screens.

OSD Timeout sets the length of time the OSD screen is displayed. For example,

with a “15 second” setting, if a control is not pushed within 15 seconds, the
display screen disappears.

OSD Background allows the user to turn the OSD background On or Off.

Memory Recall returns the adjustments back to factory settings if the display is

operating in a factory Preset Timing Mode listed in the Specifications of this
manual.

ViewSonic VA902/VA902b 13

Other Information

Specifications

1

Macintosh computers older than G3 require a ViewSonic® Macintosh adapter. To order an adapter, contact

ViewSonic.

LCD Typ e

Color Filter
Glass Surface

19” (full 19" viewable diagonal area),
TFT (Thin Film Transistor), Active Matrix SXGA LCD,

0.294 mm pixel pitch
RGB vertical stripe
Anti-Glare

Panel tilt +20°, -5°

Input Signal Video

Sync

RGB analog (0.7/1.0 Vp-p, 75 ohms)
Separate Sync
f

h

:30-82 kHz, fv:50-85 Hz

Compatibility PC

Macintosh

1

Up to 1280 x 1024 Non-interlaced
Power Macintosh up to 1152 x 870

Resolution Recommended

and supported

1280 x 1024 @ 60, 75 Hz
1152 x 870 @ 75 Hz
1024 x 768 @ 60, 70, 75 Hz
832 x 624 @ 75 Hz
800 x 600 @ 56, 60, 72, 75 Hz
720 x 400 @ 70 Hz
640 x 480 @ 60, 67, 72, 75 Hz

Power Voltage 100-240 VAC, 50/60 Hz (auto switch)

Display area Full Scan 376.3 mm (H) x 301.1 mm (V)

14.8" (H) x 11.9" (V)

Operating
conditions

Temperature
Humidity
Altitude

32° F to + 104° F (0° C to + 40° C)
10% to 90% (non-condensing)
To 10,000 feet

Storage
conditions

Temperature
Humidity
Altitude

-4° F to + 140° F (-20° C to + 60° C)
5% to 90% (non-condensing)
To 40,000 feet

Dimensions Physical 414 mm (W) x 407 mm (H) x 219 mm (D)

16.3" (W) x 16" (H) x 8.6" (D)

Weight Net 12.6 lb (5.7 kg)

Regulations BSMI, PSB, C-Tick,

CE, GS, Ergo, Gost-R/Hygienic, SASO, TCO'99,

UL/cUL, FCC-B, ICES-B, NOM, TUV-S, E

NERGY STAR

®

, ENERGY

Power saving
modes

On
Off

Normal (green LED)
<1W (orange LED)

Preset Timing Mode (pre-adjusted to VESA

®

1280 x 1024 @ 60 Hz)

Warning: Do not set the graphics card in your computer to exceed these refresh rates; doing so may result in
permanent damage to the LCD display.

ViewSonic VA902/VA902b 14

Troubleshooting

No power

• Make sure power button (or switch) is ON.

• Make sure A/C power cord is securely connected to the LCD display.

• Plug another electrical device (like a radio) into the power outlet to verify that the outlet is
supplying proper voltage.

Power is ON but no screen image

• Make sure the video cable supplied with the LCD display is tightly secured to the video
output port on the back of the computer. If the other end of the video cable is not attached
permanently to the LCD display, tightly secure it to the LCD display.

• Adjust brightness and contrast.

• If you are using an Macintosh older than G3, you need a Macintosh adapter.

Wrong or abnormal colors

• If any colors (red, green, or blue) are missing, check the video cable to make sure it is
securely connected. Loose or broken pins in the cable connector could cause an improper
connection.

• Connect the LCD display to another computer.

• If you have an older graphics card, contact ViewSonic® for a non-DDC adapter.

Control buttons do not work

• Press only one button at a time.

ViewSonic VA902/VA902b 15

Customer Support

For technical support or product service, see the table below or contact your reseller.

NOTE: You will need the product serial number.

Country/Region Website

T = Telephone
F = FAX

Email

United States www.viewsonic.com/support

T= [phone]
F= [phone]

[e-mail]

Canada www.viewsonic.com/support T= [phone] [e-mail]

United Kingdom www.viewsoniceurope.com/uk T= 0207 949 0307

Europe, Middle East,
Baltic countries, and
North Africa

www.viewsoniceurope.com (Contact your reseller)

Australia and New
Zealand

www.viewsonic.com.au/support/

AUS= 1800 880 818
NZ= 0800 008 822

[e-mail]

Singapore, Southeast
Asia, and India

www.viewsonic.com.sg/support/

T= (65) 6273 4018
F= (65) 6273 1566

[e-mail]

South Africa and other
countries

www.viewsonic.com

T= [phone]
F= [phone]

[e-mail]

Hong Kong www.hk.viewsonic.com/support/ T= [phone] [e-mail]

Macau www.hk.viewsonic.com/support/ T= [phone] [e-mail]

Korean www.viewsonic.com T= 080 333 2131 [e-mail]

ViewSonic VA902/VA902b 16

Cleaning the LCD Display

• MAKE SURE THE LCD DISPLAY IS TURNED OFF.

• NEVER SPRAY OR POUR ANY LIQUID DIRECTLY ONTO THE SCREEN OR CASE.

To clean the screen:

1. Wipe the screen with a clean, soft, lint-free cloth. This removes dust and other particles.

2. If the screen still not clean, apply a small amount of non-ammonia, non-alcohol based glass

cleaner onto a clean, soft, lint-free cloth, and wipe the screen.

To clean the case:

1. Use a soft, dry cloth.

2. If the case still not clean, apply a small amount of a non-ammonia, non-alcohol based, mild

non-abrasive detergent onto a clean, soft, lint-free cloth, then wipe the surface.

Disclaimer

• ViewSonic® does not recommend the use of any ammonia or alcohol-based cleaners on the
LCD display screen or case. Some chemical cleaners have been reported to damage the
screen and/or case of the LCD display.

• ViewSonic will not be liable for damage resulting from use of any ammonia or alcohol-

based cleaners.

ViewSonic VA902/VA902b 17

Limited Warranty

VIEWSONIC® LCD DISPLAY

What the warranty covers:

ViewSonic warrants its products to be free from defects in material and workmanship during the warranty period.
If a product proves to be defective in material or workmanship during the warranty period, ViewSonic will, at its
sole option, repair or replace the product with a like product. Replacement product or parts may include
remanufactured or refurbished parts or components.

How long the warranty is effective:

ViewSonic LCD displays are warranted for three (3) years for all parts including the light source and three (3)
years for all labor from the date of the first consumer purchase.

Who the warranty protects:

This warranty is valid only for the first consumer purchaser.

What the warranty does not cover:

1. Any product on which the serial number has been defaced, modified or removed.

2. Damage, deterioration or malfunction resulting from:
a. Accident, misuse, neglect, fire, water, lightning, or other acts of nature, unauthorized product

modification, or failure to follow instructions supplied with the product.
b. Repair or attempted repair by anyone not authorized by ViewSonic.
c. Any damage of the product due to shipment.
d. Removal or installation of the product.
e. Causes external to the product, such as electrical power fluctuations or failure.
f. Use of supplies or parts not meeting ViewSonic’s specifications.
g. Normal wear and tear.
h. Any other cause which does not relate to a product defect.

3. Any product exhibiting a condition commonly known as "image burn-in" which results when a static image is
displayed on the product for an extended period of time.

4. Removal, installation, and set-up service charges.

How to get service:

1. For information about receiving service under warranty, contact ViewSonic Customer Support. You will need

to provide your product's serial number.

2. To obtain service under warranty, you will be required to provide (a) the original dated sales slip, (b) your

name, (c) your address, (d) a description of the problem, and (e) the serial number of the product.

3. Take or ship the product freight prepaid in the original container to an authorized ViewSonic service center or

ViewSonic.

4. For additional information or the name of the nearest ViewSonic service center, contact ViewSonic.

Limitation of implied warranties:

There are no warranties, express or implied, which extend beyond the description contained herein including the
implied warranty of merchantability and fitness for a particular purpose.

Exclusion of damages:

ViewSonic's liability is limited to the cost of repair or replacement of the product. ViewSonic shall not be liable
for:

1. Damage to other property caused by any defects in the product, damages based upon inconvenience, loss of

use of the product, loss of time, loss of profits, loss of business opportunity, loss of goodwill, interference with
business relationships, or other commercial loss, even if advised of the possibility of such damages.

2. Any other damages, whether incidental, consequential or otherwise.

3. Any claim against the customer by any other party.

Effect of state law:

This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
Some states do not allow limitations on implied warranties and/or do not allow the exclusion of incidental or
consequential damages, so the above limitations and exclusions may not apply to you.

Sales outside the U.S.A. and Canada:

For warranty information and service on ViewSonic products sold outside of the U.S.A. and Canada, contact
ViewSonic or your local ViewSonic dealer.

Warranty_VSLCD 1 of 1

4.3: ViewSonic LCD Warranty Rev. 1c Release Date: 03-31-05
