ViewSonic SCZ55BKUS0 User Manual

SC-Z55 Zero Client

User Guide

Model No. VS15168

Compliance Information

FCC Statement

This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help. Warning: You are cautioned that changes or modications not expressly approved by the

party responsible for compliance could void your authority to operate the equipment.

For Canada

• This Class B digital apparatus complies with Canadian CAN ICES-3 (B).

• Cet appareil numérique de la classe B est conforme à la norme NMB-3 (B) du Canada.

Following information is only for EU-member states:

The mark is in compliance with the Waste Electrical and Electronic Equipment Directive 2002/96/EC (WEEE).

The mark indicates the requirement NOT to dispose the equipment including any spent or discarded batteries or accumulators as unsorted municipal waste, but use the return and collection systems available. If the batteries, accumulators and button cells included with this equipment, display the chemical symbol Hg, Cd, or Pb, then it means that the battery has a heavy metal content of more than 0.0005% Mercury or more than, 0.002% Cadmium, or more than 0.004% Lead.

Important Safety Instructions

1. Read these instructions completely before using the equipment.

2. Keep these instructions in a safe place.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this equipment near water. Warning: To reduce the risk of re or electric

shock, do not expose this apparatus to rain or moisture.

6. Do not block any ventilation openings. Install the equipment in accordance with the manufacturer’s instructions.

7. Do not install near any heat sources such as radiators, heat registers, stoves, or other

devices (including ampliers) that produce heat.

8. Do not attempt to circumvent the safety provisions of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding

type plug has two blades and a third grounding prong. The wide blade and the third

prong are provided for your safety. If the plug does not t into your outlet, consult an

electrician for replacement of the outlet.

9. Protect the power cord from being tread upon or pinched, particularly at the plug, and the point where if emerges from the equipment. Be sure that the power outlet is located near the equipment so that it is easily accessible.

10. Only use attachments/accessories specied by the manufacturer.

11. Use only with the cart, stand, tripod, bracket, or table specied by the manufacturer, or sold with the equipment. When a cart is used, use caution

when moving the cart/equipment combination to avoid injury from tipping over.

12. Unplug this equipment when it will be unused for long periods of time.

13. Refer all servicing to qualied service personnel. Service is required when the unit has been damaged in any way, such as: if the power-supply cord or plug is damaged, if liquid is spilled onto or objects fall into the unit, if the unit is exposed to rain or

moisture, or if the unit does not operate normally or has been dropped.

14. Do not remove equipment covers and access any of the components inside the

equipment. Any access inside the equipment without an authorized or certied

technician may cause serious injuries and damage. For any problem, contact your dealer for assistance.

15. Don’t use a keyboard and mouse that in total require more than 200 mA of rated current during operation.

16. Use only power supplies listed in the user instructions.

Declaration of RoHS Compliance

This product has been designed and manufactured in compliance with Directive 2002/95/ EC of the European Parliament and the Council on restriction of the use of certain

hazardous substances in electrical and electronic equipment (RoHS Directive) and is

deemed to comply with the maximum concentration values issued by the European Technical Adaptation Committee (TAC) as shown below:

Substance

Proposed Maximum

Concentration

Actual Concentration

Lead (Pb) 0.1% < 0.1%

Mercury (Hg) 0.1% < 0.1%

Cadmium (Cd) 0.01% < 0.01%

Hexavalent Chromium (Cr6+) 0.1% < 0.1%

Polybrominated biphenyls (PBB) 0.1% < 0.1%

Polybrominated diphenyl ethers

(PBDE)

0.1% < 0.1%

Certain components of products as stated above are exempted under the Annex of the

RoHS Directives as noted below:

Examples of exempted components are:

1. Mercury in compact uorescent lamps not exceeding 5 mg per lamp and in other lamps

not specically mentioned in the Annex of RoHS Directive.

2. Lead in glass of cathode ray tubes, electronic components, uorescent tubes, and

electronic ceramic parts (e.g. piezoelectronic devices).

3. Lead in high temperature type solders (i.e. lead-based alloys containing 85% by weight

or more lead).

4. Lead as an allotting element in steel containing up to 0.35% lead by weight, aluminium

containing up to 0.4% lead by weight and as a cooper alloy containing up to 4% lead by weight.

iii

ViewSonic, the three birds logo, OnView, ViewMatch, ViewMeter, and MultiClient are either registered trademarks or trademarks of ViewSonic Corporation.

Microsoft companies.

Other product names mentioned herein are used for identication purposes only and may

be trademarks and/or registered trademarks of their respective companies.

Disclaimer: ViewSonic Corporation shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from furnishing this material, or the performance or use of this product.

, Windows®, and MultiPoint™ are trademarks of the Microsoft group of

ENERGY STAR® is a registered trademark of the U.S. Environmental Protection Agency (EPA). As an ENERGY STAR® partner, ViewSonic Corporation has determined that this product meets the ENERGY STAR® guidelines for energy

efciency.

In the interest of continuing product improvement, ViewSonic Corporation reserves the

right to change product specications without notice. Information in this document may

change without notice.

No part of this document may be copied, reproduced, or transmitted by any means, for any purpose without prior written permission from ViewSonic Corporation.

NOTE

• Display Sleep Mode. Within 5 minutes of user inactivity, the display will enter

the Display Sleep mode with a blank screen and reduced power consumption by the factory default settings. The display returns to the Display Normal mode upon sensing a request from a user such as moving the mouse or pressing a key.

• To adjust settings for the Display Sleep mode, click Options > Conguration > OSD to adjust the settings.

• System Sleep Mode. ViewSonic SC-Z55 doesn’t support the System/Client Sleep mode.

NOTE

• The default power management settings have been selected for compliance with ENERGY STAR that are recommended by the ENERGY STAR program for optimal energy savings.

Product Registration

To meet your future needs, and to receive any additional product information as it becomes available, please register your product on the Internet at: www.viewsonic.com.

For Your Records

Product Name:

Model Number: Document Number: Serial Number: Purchase Date:

SC-Z55 ViewSonic Zero Client VS15168 SC-Z55_UG_ENG Rev. 1A 01-02-13

_______________________________ _______________________________

Product disposal at end of product life

ViewSonic respects the environment and is committed to working and living green. Thank you for being part of Smarter, Greener Computing. Please visit ViewSonic website to learn more.

USA & Canada: http://www.viewsonic.com/company/green/recycle-program/

Europe: http://www.viewsoniceurope.com/uk/support/recycling-information/

Taiwan: http://recycle.epa.gov.tw/recycle/index2.aspx

About This User’s Manual

This installation guide provides basic information on how to set up SC-Z55 zero clients.

Manual Structure and Subjects

Chapter Subject

1 Provides an overview of ViewSonic SC-Z55 zero clients.

2 Provides detailed instructions on how to set up ViewSonic SC-Z55 zero clients.

Specications Provides detailed information on key components of ViewSonic SC-Z55 zero clients.

Notes, Tips, and Warnings

Throughout this manual, the notes and warnings in the following formats are used to provide important information, and prevent injuries to you, damage to your devices, or loss of data on your system.

NOTE

• Anoteprovidesimportantinformationforaspecicsituation.

WARNING

• A warning provides crucial information that must be followed to prevent injuries to you, damage to your devices, or loss of data on your system.

Table of Contents

Compliance Information i

Important Safety Instructions ii

Declaration of RoHS Compliance iii

Product Registration v

About This User’s Manual vi

Manual Structure and Subjects vi Notes, Tips, and Warnings vi

1 Overview 1

1.1 Introduction 2

1.2 Features 2

1.3 Package Contents 3

1.4 Exterior Views 3

1.5 Panel Components 4

1.6 LED Indicators 6

2 Setting Up Your SC-Z55 7

2.1 Positioning Your SC-Z55 8

2.2 Assembling the AC Adapter 11

2.3 Getting Connected 12

Specications 13

Other Information 14

Customer Support 14

Limited Warranty 15
