ViewSonic DPV5 User Manual

ViewSonic

DVP5

Pocket Camcorder

Projector

IMPORTANT: Please read this User Guide to obtain

important information on installing and using your

product in a safe manner, as well as registering your

product for future service. Warranty information

contained in this User Guide will describe your limited

coverage from ViewSonic Corporation, which is also

found on our web site at http://www.viewsonic.com in

English, or in specic languages using the Regional

selection box in the upper right corner of our website.

“Antes de operar su equipo lea cuidadosamente las

instrucciones en este manual”

- User Guide

®

- Guide de l’utilisateur

- Bedienungsanleitung

- Guía del usuario

- Guida dell’utente

- Guia do usuário

- Kullanιcι kιlavuzu

- Gebruikshandleiding

- 使用手冊 (繁體)

- 使用手册 (简体)

- 사용자 안내서

- ユーザーガイド

-

ﻢﺪﺨﺘﺴﻤﻠﺍ ﻞﻴﻠﺪ

Model No. : VS13783

Compliance Information

FCC Statement

This device complies with part 15 of FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy, and if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.

• Consult the dealer or an experienced radio/TV technician for help.

Warning: You are cautioned that changes or modications not expressly approved by the party
responsible for compliance could void your authority to operate the equipment.

For Canada

• This Class B digital apparatus complies with Canadian ICES-003.

• Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

CE Conformity for European Countries

The device complies with the EMC Directive 2004/108/EC and Low Voltage Directive
2006/95/EC.

Following information is only for EU-member states:

The mark is in compliance with the Waste Electrical and Electronic Equipment Directive
2002/96/EC (WEEE).
The mark indicates the requirement NOT to dispose the equipment including any spent
or discarded batteries or accumulators as unsorted municipal waste, but use the return
and collection systems available.
If the batteries, accumulators and button cells included with this equipment, display the
chemical symbol Hg, Cd, or Pb, then it means that the battery has a heavy metal content
of more than 0.0005% Mercury or more than, 0.002% Cadmium, or more than 0.004%
Lead.

ViewSonic i DVP5

Important Safety Instructions

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this unit near water.

6. Clean with a soft, dry cloth.

7. Do not block any ventilation openings. Install the unit in accordance with the manufacturer’s

instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other devices

(including ampliers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug

has two blades with one wider than the other. A grounding type plug has two blades and a
third grounding prong. The wide blade and the third prong are provided for your safety. If the
provided plug does not t into your outlet, consult an electrician for replacement of the obsolete
outlet.

rotect the power cord from being walked on or pinched particularly at plugs. Convenience

10. P

receptacles and the point where they exit from the unit. Be sure that the power outlet is located
near the unit so that it is easily accessible.

11. Only use attachments/accessories specied by the manufacturer.

12. Use only with the cart, stand, tripod, bracket, or table specied by the manufacturer,

or sold with the unit. When a cart is used, use caution when moving the cart/unit
combination to avoid injury from tipping over.

13. Unplug this unit when unused for long periods of time.

14. Refer all servicing to qualied service personnel. Servicing is required when the unit has been

damaged in any way, such as: if the power-supply cord or plug is damaged, if liquid is spilled
onto or objects fall into the unit, if the unit is exposed to rain or moisture, or if the unit does not
operate normally or has been dropped.

ViewSonic ii DVP5

Declaration of RoHS Compliance

This product has been designed and manufactured in compliance with Directive 2002/95/EC of the
European Parliament and the Council on restriction of the use of certain hazardous substances in
electrical and electronic equipment (RoHS Directive) and is deemed to comply with the maximum
concentration values issued by the European Technical Adaptation Committee (TAC) as shown
below:

Substance

Lead (Pb) 0.1% < 0.1%

Mercury (Hg) 0.1% < 0.1%

Cadmium (Cd) 0.01% < 0.01%

Hexavalent Chromium (Cr6+) 0.1% < 0.1%

Po ly br om in at ed bi phen yls
(PBB)

Polybrominated diphenyl ethers
(PBDE)

Certain components of products as stated above are exempted under the Annex of the RoHS
Directives as noted below:

Examples of exempted components are:

1. Mercury in compact uorescent lamps not exceeding 5 mg per lamp and in other lamps not

specically mentioned in the Annex of RoHS Directive.

2. Lead in glass of cathode ray tubes, electronic components, uorescent tubes, and electronic

ceramic parts (e.g. piezoelectronic devices).

3. Lead in high temperature type solders (i.e. lead-based alloys containing 85% by weight or more

lead).

4. Lead as an allotting element in steel containing up to 0.35% lead by weight, aluminium

containing up to 0.4% lead by weight and as a cooper alloy containing up to 4% lead by weight.

Proposed Maximum

Concentration

0.1% < 0.1%

0.1% < 0.1%

Actual Concentration

ViewSonic iii DVP5

Copyright Information

Copyright © ViewSonic® Corporation, 2010. All rights reserved.
ViewSonic, the three birds logo, OnView, ViewMatch, and ViewMeter are registered trademarks of

ViewSonic Corporation.
Disclaimer: ViewSonic Corporation shall not be liable for technical or editorial errors or omissions

contained herein; nor for incidental or consequential damages resulting from furnishing this
material, or the performance or use of this product.

In the interest of continuing product improvement, ViewSonic Corporation reserves the right to
change product specications without notice. Information in this document may change without
notice.

No part of this document may be copied, reproduced, or transmitted by any means, for any purpose
without prior written permission from ViewSonic Corporation.

Product Registration

To meet your future needs, and to receive any additional product information as it becomes
available, please register your product on the Internet at: www.viewsonic.com. The ViewSonic®
Wizard CD-ROM also provides an opportunity for you to print the registration form, which you may
mail or fax to ViewSonic.

For Your Records

Product Name:

Model Number:
Document Number:
Serial Number:
Purchase Date:

Product disposal at end of product life

The lamp in this product contains mercury which can be dangerous to you and the environment.
Please use care and dispose of in accordance with local, state or federal laws.

ViewSonic respects the environment and is committed to working and living green. Thank you for
being part of Smarter, Greener Computing. Please visit ViewSonic website to learn more.

USA & Canada: http://www.viewsonic.com/company/green/recycle-program/
Europe: http://www.viewsoniceurope.com/uk/support/recycling-information/
Taiwan: http://recycle.epa.gov.tw/recycle/index2.aspx

DVP5
ViewSonic Pocket Camcorder Projector
VS13783
DVP5_UG_ENG Rev. 1B 11-04-10
_______________________________
_______________________________

ViewSonic iv DVP5

Table of Contents

Getting Started .............................................................................1

Product overview ...................................................................................................1

Package Content ...................................................................................................2

Remote Controller..................................................................................................2

Reading LED indicators .........................................................................................3

Charging the battery ..............................................................................................3

Inserting a memory card (optional) ........................................................................4

Turning on/off your projector ..................................................................................4

Setting language ....................................................................................................4

Button Operation....................................................................................................5

Reading LCD indicators .........................................................................................5

Basic Operations .........................................................................6

Recording a video clip ...........................................................................................6

Taking a still picture ...............................................................................................6

Projecting les .......................................................................................................7

Playing les in other devices ...............................................................................11

Advanced Operations ...............................................................13

Menu Setting items ..............................................................................................13

File management with a PC.................................................................................14

Flicker Setting Table ............................................................................................16

Battery Life Indicator ............................................................................................16

AV-IN recording (optional)
USB Projection (optional)

Specications ............................................................................23

Troubleshooting ........................................................................25

................................................................................17

................................................................................18

ViewSonic DVP5

Getting Started

Product overview

Projection button

Shutter button Record button

Up button (Zoom in)

Menu button

Left button

(Folder)

Power/Charging LED

DC In/USB connector

AV input / Headphone output

Down button

(Zoom out)

HDMI out

Return Button

Right button (LED light)

OK button

Mic

Tripod socket

LED Light

Micro SD card slot

IR receiver

Power Switch

Speaker

Projection
Lens

Focus switch

Camcorder
Lens

ViewSonic 1 DVP5

Package Content

Projector Quick Guide CD AC power adapter

USB cable AV cable (RCA

female to mini jack)

AV cable (mini jack

to mini jack)

Remote Controller

Remote Controller

Up button

Projection on/off

Record button

Left button

Menu button

Down button

ViewSonic 2 DVP5

Shutter button

OK/Play/Pause button

Right button

Return button

Volume control buttons

Reading LED indicators

The Power LED is lighting orange when projector is charged.
The Power LED is lighting green when connected with AC power adapter in standby

mode or the battery is fully charged.

Charging the battery

1

Connect one end of the supplied AC adapter to the USB

port of the projector and the other end to a wall outlet.
OR
Connect one end of the supplied USB cable to the USB

port of the projector and the other end to a powered PC.

Make sure the projector is powered off.

2

The charging LED turns orange and the charging starts.

3

When interrupted the LED went off.

Charging status Charging time

Powered OFF, charged by AC adapter around 4 hours

Powered OFF, charged by USB around 7 hours

Powered ON and connecting with AC adapter no charging

Powered ON and connecting with USB no charging

ViewSonic 3 DVP5

Inserting a memory card (optional)

1

Open the Micro SD card cover.

2

Gently push the card as indicated (golden-ngers facing

upwards) until the card reaches the end of the slot.

3

When the card is inserted successfully, the icon (

appear on screen. To remove the card, push the card to

release it and then pull it out gently.

4

Put the cover back.

) will

Turning on/off your projector

Slide the Power switch to “ON” position to turn on the projector.
To turn off the projector, slide the Power switch to “OFF” position.

Setting language

1

Power on the projector.

2

Press the MENU button to enter the Setting screen.

3

Use the Up/Down button to select the Language item, and then Press the OK

button to conrm.

4

Use the Up/Down button to select a language.

5

When done, press the OK button to conrm the setting.

ViewSonic 4 DVP5

Button Operation

How to Action

Bring up the menu Press the MENU button.

Move the highlight bar Press the Up/Down/Left/Right button.

Enter sub-menu/Conrm an item Press the OK button.

Exit menu/Go back to upper menu Press the Return button (when in sub-menu).

Reading LCD indicators

00:03:12

Video resolution Internal memory/SD card inserted

1

Picture resolution Battery life

LED light Zoom ratio indicator

Recording time

ViewSonic 5 DVP5

Basic Operations

Recording a video clip

1

Use the Up/Down buttons to zoom in or zoom out.

2

Press the Record (

3

Press the Record (

4

While recording, press the OK/Quick Playback (

recording, and press the ( ) button again to resume recording.

Video recording will be stopped after 25 minutes due to power saving setting. If you want

to continue recording, press the “Record” button again.

For better image quality, you may add extra light when the lighting is insufcient during

recording video clips. Please press the Right button to turn on the LED light.

Option Icon Description

On

) button to start recording.

) button again to stop recording.

) button to pause

Enable LED light.

Off

Disable LED light.

Taking a still picture

1

Use the Up/Down buttons to zoom in or zoom out.

2

Press the Shutter (

For better image quality, you may add extra light when the lighting is insufcient during

taking pictures. Please press the Right button to turn on the LED light.

Option Icon Description

On

Off

ViewSonic 6 DVP5

) button to take a picture.

Enable LED light.

Disable LED light.

Projecting les

1

Press the OK/Quick Playback (

2

Use the Up/Down buttons to select target folder.

3

When selecting one le, press the OK button to play it.

4

Press the Projection button (

mode; is lighting white in standby mode.)

• There are two ways to view the les.

OK/Quick Playback button Left button

) button or the Left button.

) to project. ( is lighting blue in working

Video

DCIM


0001/0001

100MEDIA

100MEDIA

100MEDIA


0001/0001

0005/0012

DCIM

100MEDIA

100MEDIA

CLIP0007.MP4


CLIP0008.MP4




0001/0001

0005/0012

00:00:07

1MB

00:05:12

611KB

809KB

486KB

ViewSonic 7 DVP5

During Playback

• Playing Video

1

Press Left/Right button to move to previous/next le.

Long press Left/Right button to fast forward and fast rewind.

2

Use Up/Down button to control volume.

3

Press the OK button to pause the video (OK again for continue). The following

status information will pop up.

Icon Item Description

Fast
Rewind

Pause

Press Left button: scroll the les up.
Long press Left button: fast rewind.

This is a button to pause a Video le during playback.

Play

Fast
Forward

This is a button to play a selected Video le.

Press Right button: scroll the les down.
Long press Right button: fast forward.

• Playing Photo

1

Use the Up/Down button to select target folder or a photo displayed in preview

mode.

2

After a photo is selected, press the OK button to display full size of this photo.

3

Use the Left/Right button to display previous or next photo.

Item Description

Zoom in/out Push the Up/Down button.

Lock/Release zoom ratio When the zoom ratio is greater than 1.0x, press the OK button.

Browse the enlarged

When the zoom ratio is locked, use the Joystick to browse the picture.

ViewSonic 8 DVP5

• Menu items in Playback mode

When playback video or photo les, press Menu ( ) button to set up the following features.

Pressing menu button to bring up and close the menu screen.

Item Description

Delete Delete the les.

Repeat

Slide show speed Set the Slide show speed at 3, 5, or 8 seconds.

Repeat playing les in the folder. There are four options: Off, Single, All,
and Random.

Icon

When giving a presentation using PowerPoint/PDF documents, please save the PPT/

PDF le into .jpeg format.

Enable/Disable OSD icons to display on the screen.

Adjust the Focus

Adjust the Focus by using the Focus switch to get a sharper

and clear picture.

ViewSonic 9 DVP5

Adjusting the Projected Image

Projection Distance

(A)

(cm) (inch) (cm) (inch) (cm) (inch) (cm) (inch)

19.0 7.5 12.2 4.8 9.1 3.6 15.2 6.0

38.1 15 24.4 9.6 18.3 7.2 30.5 12.0

63.5 25 40.6 16.0 30.5 12.0 50.8 20.0

101.3 39.9 65.0 25.6 48.8 19.2 81.3 32.0

133.0 52.4 85.3 33.6 64.0 25.2 106.7 42.0

158.5 62.4 101.6 40.0 76.2 30.3 127.0 50.0

190.2 74.9 121.9 48.0 91.4 36.0 152.4 60.0

206.6 81.1 132.1 52.0 99.1 39.0 165.1 65.4

Screen size - Width

(B)

Screen Size - Height

(C)

Screen Diagonal

(D)

ViewSonic 10 DVP5

Playing les in other devices

Connecting the projector with your media players

Before connecting your media player to projector, you need to have media player dedicated com­posite AV-out cable and projector AV cable ready.

Projector AV cable

(red)

(white)

AV OUT

1

Connect Composite AV-out cable to media player.

2

Connect both AV cables (yellow to yellow, white to white and red to red).

White might be black on some Media players or cables.

Please make sure that your media player is enabled with AV-out function.

<AV cable>

(yellow)

Connecting the projector to your mobile media devices

1

Connect the other end of the projector cable to the AV jack of Projector.

2

Now you can project photos and videos from your mobile devices. You also can

control the volume from control panel (Up/Down button).

Composite AV-out
cable

(red)

(white)

(yellow)

Video/Music Player

DVD Player/
SAT-Receiver

Portable Media
Player

Game console

Mobile Phone

Digital camcorder/

<AV cable> (optional)

camera

Portable Media Player

ViewSonic 11 DVP5

Connecting the projector with HDTV (optional)

TV

HDMI OutHDMI In

HDMI cable (Optional)

1

Turn on your HDTV.

2

Connect the HDMI-in connector (the bigger end) of the HDMI cable to the HDTV.

3

Turn on the camcorder.

4

Connect the other end of the HDMI cable to your camcorder.

5

Switch the HDTV to “HDMI input” mode.

ViewSonic 12 DVP5

Advanced Operations

Menu Setting items

Item Option Description

QVGA Set the video resolution to QVGA (320x240 pixels).

Video

Resolution


Resolution

Select Card

Beep

Icon

Clock -

Language

Keypad

Sensitivity

Display Auto Off

Frequency

Format

Default

VGA Set the video resolution to VGA (640x480 pixels).

DVD Set the video resolution to DVD (720x480 pixels).

HD(720P) Set the video resolution to HD 720P (1280x720 pixels).

3M Set the picture resolution to 3 mega pixels.

5M Set the picture resolution to 5 mega pixels.

8M Set the picture resolution to 8 mega pixels.

Internal

memory/ Micro

SD card

On/Off

-2 ~ +2 Set the sensitivity of the touch-pad.

On/Off Enable/Disable the LCD monitor display for power-saving purpose.

Select the storage devices between internal memory and Micro SD card.

Off

Disable beep sound.

On

Enable beep sound.

Enable/Disable OSD icons to display on the screen.

Set date and time.

-

Let you select the language used for OSD.

50Hz

60Hz

Set frequency to 50Hz.

Set frequency to 60Hz.

No

Cancel action.

Format the storage medium. Note that all les stored in the medium

Yes

will be gone.

No

Cancel action.

Restore factory defaults. Note that your current settings will be

Yes

overridden.

ViewSonic 13 DVP5

File management with a PC

For select model only. Please refer to the package printing for detailed

specication.

Follow the procedures below to manage les in either built-in memory or memory
card by using a PC or Notebook.

1

Make sure the projector is powered off.

2

Connect one end of the bundled USB cable to the USB port of the projector and

the other end to a powered PC.

3

Please switch on the projector and wait until the picture below appears on the

projection screen. Press OK to enter Disk mode.

Disk

USB Projection

4

Two removable disks will appear in “My Computer”.

Disk Name Description

Removable Disk for storing your recordings.

DV Projector

PC can only recognize one storage medium each time (If the projector with SD Card

inside, the computer will detect the SD Card. If you want to detect the internal memory,

you have to remove the SD Card.)
Do not switch the storage medium during operation.
When connecting the projector to PC USB port without turning on the projector, the PC

starts charging the battery inside the projector. To read the les in the memory, press

the Power button.

for storing AMC, E-manual and USB Driver

ViewSonic 14 DVP5

How to download YouTube video for projection

During installing ArcSoft Media Converter (AMC), you are recommended to install ArcSoft
Video Downloader as well. It will bring you more convenience to download the videos from the
Internet and convert them as mp4 format to be played back in your projector. Then you can
share them with your family and friends.

• How to use ArcSoft Video Downloader

1

Complete the ArcSoft Video Downloader installation.

2

Run Internet Explorer 6 or above.

3

Launch your favorite webpage and then move your cursor to the video clip.

4

Click the “download” button on the top left corner of the window.

5

This video le will be downloaded into AMC automatically. Please specify the le destination

and press Start to make le conversion.

6

The converted video will be as into the assigned directory as mp4 format.

ViewSonic 15 DVP5

Frequency Setting Table

Region England Germany France Italy Spain

Setting 50Hz 50Hz 50Hz 50Hz 50Hz 50Hz 50Hz

Region Portugal America Taiwan China Japan Korea Thailand

Setting 50Hz 60Hz 60Hz 50Hz 50/60Hz 60Hz 50Hz

Netherlands

Battery Life Indicator

Icon Description

Full battery life

Moderate battery life

Low battery life

Empty battery life

Note 1: To avoid sudden outage of power supply, you are recommended to plug AC power

adapter rst then take off the battery when the icon indicates low battery life.

Note 2: When “Battery Low” message appeared on the screen, the projector will be

powered off automatically.

Russia

ViewSonic 16 DVP5

For select model only. Please refer to the package printing for detailed

specication.

AV-IN recording (optional)

This projector is able to record through the AV input.

1

To record press “

will appear ashing in upper-left corner of screen.

2

To stop recording press “

video le will be saved as mp4 video le in \DCIM\100MEDIA\.

Resolution 640x480 Pixels (up to 30fps)

Aspect Ratio 4:3

File Format MP4 (H.264)

Audio Compression Technology AAC (48k bps)

Maximum recording capacity per video 1.7GB

When memory is full, the screen will show “Memory Full”.

” when video is playing through the projector. A “REC” icon

” again, the “REC” icon will disappear. The recorded

ViewSonic 17 DVP5

For select model only. Please refer to the package printing for detailed

specication.

USB Projection (optional)

System requirements

- Pentium 4 / Athlon / Core 2 Duo 2.6 GHz or higher processor.

- 1GB RAM or higher (Higher memory recommended for optimal performance)

- Available USB 2.0 port

- Windows XP SP2 / Windows Vista / Windows 7

- Recommended Resolution for video projection: 800*600

ViewSonic 18 DVP5

Installing Driver

1

Make sure the projector is powered off.

2

Connect one end of the bundled USB cable to the USB port of the projector and

the other end to a powered PC.

3

Please switch on the projector and wait until the picture below appears on the

projection screen. Press OK to enter Disk mode.

Disk

USB Projection

4

Two removable disks will appear in “My Computer”. Please double-click the disk

named DV Projector -> USB driver folder -> Setup.exe program.

5

Click Next to continue.

ViewSonic 19 DVP5

6

Click Install to begin the installation.

7

Installing driver.

(The actual screen may vary depending on the operating system you use.)

8

Click Finish.

ViewSonic 20 DVP5

9

Please unplug the USB cable for a second to exit Disk mode. Then restart your

computer then plug the USB cable again.

10

Please switch on the projector and wait until the picture below appears on the

projection screen. Select “USB Projection” and press OK.

Disk

USB Projection

11

You will nd a small projector icon ( ) on the function bar of your PC.

Note 1: Right-click the projector icon and click

Screenshot to freeze the current projecting

screen. Just PC display is in working mode.

Note 2: Right-click the projector icon and click Start to

resume the real-time projecting.

ViewSonic 21 DVP5

Verication device driver installation

The following procedure allows you to verify the device driver installation.

1

Please right click “My Computer” -> ”Properties” -> ”Hardware” -> ”Device
Manager”. (For Windows XP user)

Please right click “Start” -> “My Computer” -> ”Device Manager”. (For
Windows Vista and Windows 7 users)

2

Then double click ”Imaging devices”. You will nd “Pico Projector” on
“Imaging devices”.

ViewSonic 22 DVP5

Specications

Item Description

Light Source RGB LED

LCD Display 2.4” (6 cm) LCD

Brightness 15 Lumens (AC Mode); 12 Lumens (Battery Mode)

Aspect Ratio 4:3

Resolution 640 x 480 (VGA) Pixels

Projection Image Size 15 cm ~ 165.1 cm (6” ~ 65” Diagonal)

Projection Distance 19 cm ~ 206 cm

Contrast Ratio 200:1

Zoom & Focus Manual

Projection Source External from 3-in-1 AV jack, build-in memory or memory card

Play Back Format

Sensor Resolution 5M

Video Clip HD 720p, DVD, VGA, QVGA

Image Resolution 8M, 5M, 3M

Lens Focus Fixed

Output HDMI, Audio

Audio Speaker Mono

Built-in Memory 32MB (13.4MB for storage)

Memory Slot MicroSD up to 32GB

Power Supply

Battery Life Up to 120 minutes

Power consumption

Operation temperature 0°C ~ 35°C

Bundled Software Arcsoft Media Converter

Photo: JPEG
Video: MPEG-4( ASF), H.264(MP4), M-JPEG(AVI)
Audio: MP3

AC power adapter (5V/2A) or embedded rechargeable battery
2100mAH

Working mode: 5 W
Standby mode (Projector light off): 3.5W

ViewSonic 23 DVP5

Item Description

Dimension (LxWxH) 125 x 62 x 24 mm

Package Content

Optional Accessory

AV cable (RCA female to mini jack), USB cable, AC power adapter,
Quick Guide, Remote controller, AV cable (mini jack to mini jack,
CD (User Manual))

iPod cable, AV cable (RCA male to mini jack), HDMI Cable, Pouch,
Projection screen, Tripod

Note: Specications are subject to change without notication.

Supported le types for conversion (Input le formats)

- Windows AVI les (*.AVI)

- Advanced Systems Format (*.ASF)

- Video CD (*.DAT)

- Quick Time les (*.MOV)

- MP4 les (*.MP4; *.M4V)

- MPEG (*.MPG; *.MPEG; *.MPE)

- RealMedia Video (*.RMVB)

- Windows Media Video (*.WMV)

- Microsoft PowerPoint (*.ppt, *.pps)

Supported le types for export to projector

- MPEG4 MP4 (H.264)

ViewSonic 24 DVP5

Troubleshooting

If your projector does not seem to be functioning properly, check the items below before you
contact an authorized service center.

Symptom Check Point

The projector can not be
turned on.

The projected image is
too dark.

The projected image is dim.

The image is not played.

No image is projected when
an AV device is connected.

No image is projected when
a computer is connected.

The surface temperature of
projector ascended.

• Ensure the battery is fully charged or the AC power adapter
is in use.

• Use the projector in a darker environment.

• Increase the brightness by using the AC power adapter.

• Project the image on a at, white surface.

• Decrease the size of projected image.

• Adjust the focus. Please refer to “Adjusting the Focus”
section.

• Check if the lens is dirty.

• Replace with an image of higher resolution.

• Ensure the image format is compatible.

• Replace with another le or memory card.

• Convert the le with the attached AMC software.

• Ensure the connected device is equipped with AV-out
function.

• Check if the AV Cable is connected, and the projector is
switched to AV-in function.

• Check if the AV Cable is plugged correctly.

• Check if the USB Cable is plugged correctly.

• Make sure the PC has been switched to projector display.

• Ensure the display resolution of PC screen is 640x480 or
800x600.

As the high-luminance LED equipped in the projector will generate
heat in long-time use, the projector case will help to dissipate heat
so that its surface temperature will ascend. This will not affect
the performance of projector. Please operate the projector in a
ventilated environment indoor as far as possible.

ViewSonic 25 DVP5

Customer Support

For technical support or product service, see the table below or contact your reseller.

Note : You will need the product serial number.

Country/Region Website

Australia/New
Zealand

Canada www.viewsonic.com

Europe www.viewsoniceurope.com www.viewsoniceurope.com/uk/support/call-desk/
Hong Kong www.hk.viewsonic.com T= 852 3102 2900 [e-mail]
India www.in.viewsonic.com T= 1800 11 9999 [e-mail]

Ireland (Eire) www.viewsoniceurope.com/uk/

Korea www.kr.viewsonic.com T= 080 333 2131 [e-mail]
Latin America

(Argentina)
Latin America (Chile) www.viewsonic.com/la/ T= 1230-020-7975 [e-mail]
Latin America

(Columbia)
Latin America

(Mexico)
Renta y Datos, 29 SUR 721, COL. LA PAZ, 72160 PUEBLA, PUE. Tel: [phone] CON 10 LINEAS

Electroser, Av Reforma No. 403Gx39 y 41, 97000 Mérida, Yucatán. Tel: [phone]
Other places please refer to http://www.viewsonic.com/la/soporte/index.htm#Mexico

Latin America (Peru) www.viewsonic.com/la/ T= 0800-54565 [e-mail]
Macau www.hk.viewsonic.com T= 853 2870 0303 [e-mail]
Middle East ap.viewsonic.com/me/ Contact your reseller [e-mail]

Puerto Rico & Virgin
Islands

Singapore/Malaysia/
Thailand

South Africa ap.viewsonic.com/za/ Contact your reseller [e-mail]

United Kingdom www.viewsoniceurope.com/uk/

United States www.viewsonic.com

www.viewsonic.com.au

www.viewsonic.com/la/ T= 0800-4441185 [e-mail]

www.viewsonic.com/la/ T= 01800-9-157235 [e-mail]

www.viewsonic.com/la/ T= 001-8882328722 [e-mail]

www.viewsonic.com

www.ap.viewsonic.com T= 65 6461 6044 [e-mail]

T = Telephone
F = FAX

AUS= 1800 880 818
NZ= 0800 008 822

T (Toll-Free)= 1-866-463-4775
T (Toll)= 1-424-233-2533
F= 1-909-468-3757

www.viewsoniceurope.com/
uk/support/call-desk/

T= 1-800-688-6688 (English)
T= 1-866-379-1304 (Spanish)
F= 1-909-468-3757

www.viewsoniceurope.com/
uk/support/call-desk/

T (Toll-Free)= 1-800-688-6688
T (Toll)= 1-424-233-2530
F= 1-909-468-3757

Email

[e-mail]

[e-mail]

service_ie@
viewsoniceurope.com

[e-mail]
[e-mail]

service_gb@
viewsoniceurope.com

[e-mail]

ViewSonic 26 DVP5

Limited Warranty

ViewSonic® Pocket Camcorder Projector

What the warranty covers:

ViewSonic warrants its products to be free from defects in material and workmanship, under normal
use, during the warranty period. If a product proves to be defective in material or workmanship
during the warranty period, ViewSonic will, at its sole option, repair or replace the product with a
like product. Replacement product or parts may include remanufactured or refurbished parts or
components.

How long the warranty is effective:

ViewSonic Pocket Camcorder Projector are warranted for 1 year for labor from the date of the rst
customer purchase.

Who the warranty protects:

This warranty is valid only for the rst consumer purchaser.

What the warranty does not cover:

1. Any product on which the serial number has been defaced, modied or removed.

2. Damage, deterioration or malfunction resulting from:
a. Accident, misuse, neglect, re, water, lightning, or other acts of nature, unauthorized

b. Any damage of the product due to shipment.
c. Removal or installation of the product.
d. Causes external to the product, such as electrical power uctuations or failure.
e. Use of supplies or parts not meeting ViewSonic’s specications.
f. Normal wear and tear.
g. Any other cause which does not relate to a product defect.

3. Any product exhibiting a condition commonly known as “image burn-in” which results when a

4. Removal, installation, one way transportation, insurance, and set-up service charges.

How to get service:

1. For information about receiving service under warranty, contact ViewSonic Customer Support

2. To obtain warranted service, you will be required to provide (a) the original dated sales slip,

3. Take or ship the product freight prepaid in the original container to an authorized ViewSonic

4. For additional information or the name of the nearest ViewSonic service center, contact

product modication, or failure to follow instructions supplied with the product.

static image is displayed on the product for an extended period of time.

(please refer to Customer Support page). You will need to provide your product’s serial
number.

(b) your name, (c) your address, (d) a description of the problem, and (e) the serial number of
the product.

service center or ViewSonic.

ViewSonic.

ViewSonic 27 DVP5

Limitation of implied warranties:

There are no warranties, express or implied, which extend beyond the description contained herein
including the implied warranty of merchantability and tness for a particular purpose.

Exclusion of damages:

ViewSonic’s liability is limited to the cost of repair or replacement of the product. ViewSonic shall
not be liable for:

1. Damage to other property caused by any defects in the product, damages based upon
inconvenience, loss of use of the product, loss of time, loss of prots, loss of business
opportunity, loss of goodwill, interference with business relationships, or other commercial
loss, even if advised of the possibility of such damages.

2. Any other damages, whether incidental, consequential or otherwise.

3. Any claim against the customer by any other party.

4. Repair or attempted repair by anyone not authorized by ViewSonic.

4.3: ViewSonic Pocket Camcorder Projector Warranty DVP_LW01 Rev. 1A 08-05-08

ViewSonic 28 DVP5

Mexico Limited Warranty

ViewSonic® Pocket Camcorder Projector

What the warranty covers:

ViewSonic warrants its products to be free from defects in material and workmanship, under normal use, during the
warranty period. If a product proves to be defective in material or workmanship during the warranty period, ViewSonic
will, at its sole option, repair or replace the product with a like product. Replacement product or parts may include
remanufactured or refurbished parts or components.

How long the warranty is effective:

ViewSonic Pocket Camcorder Projector are warranted for 1 year for labor from the date of the rst customer purchase.

Who the warranty protects:

This warranty is valid only for the rst consumer purchaser.

What the warranty does not cover:

1. Any product on which the serial number has been defaced, modied or removed.

2. Damage, deterioration or malfunction resulting from:

a. Accident, misuse, neglect, re, water, lightning, or other acts of nature, unauthorized product

b. Any damage of the product due to shipment.
c. Removal or installation of the product.
d. Causes external to the product, such as electrical power uctuations or failure.
e. Use of supplies or parts not meeting ViewSonic’s specications.
f. Normal wear and tear.
g. Any other cause which does not relate to a product defect.

3. Any product exhibiting a condition commonly known as “image burn-in” which results when a static image is

4. Removal, installation, one way transportation, insurance, and set-up service charges.

How to get service:

For information about receiving service under warranty, contact ViewSonic Customer Support (Please refer to the
attached Customer Support page). You will need to provide your product’s serial number, so please record the product
information in the space provided below on your purchase for your future use. Please retain your receipt of proof of
purchase to support your warranty claim.
For Your Records
Product Name: ________________________ Model Number: __________________________
Document Number: ____________________ Serial Number: __________________________
Purchase Date: ________________________ Extended Warranty Purchase? __________(Y/N)
If so, what date does warranty expire? ________

1. To obtain warranty service, you will be required to provide (a) the original dated sales slip, (b) your name, (c)

2. Take or ship the product in the original container packaging to an authorized ViewSonic service center.

3. Round trip transportation costs for in-warranty products will be paid by ViewSonic.

Limitation of implied warranties:

There are no warranties, express or implied, which extend beyond the description contained herein including the
implied warranty of merchantability and tness for a particular purpose.

Exclusion of damages:

ViewSonic’s liability is limited to the cost of repair or replacement of the product. ViewSonic shall not be liable for:

1. Damage to other property caused by any defects in the product, damages based upon inconvenience, loss of

2. Any other damages, whether incidental, consequential or otherwise.

3. Any claim against the customer by any other party.

4. Repair or attempted repair by anyone not authorized by ViewSonic.

modication, or failure to follow instructions supplied with the product.

displayed on the product for an extended period of time.

your address, (d) a description of the problem, and (e) the serial number of the product.

use of the product, loss of time, loss of prots, loss of business opportunity, loss of goodwill, interference with
business relationships, or other commercial loss, even if advised of the possibility of such damages.

ViewSonic 29 DVP5

Contact Information for Sales & Authorized Service (Centro Autorizado de Servicio) within Mexico:

Name, address, of manufacturer and importers:

México, Av. de la Palma #8 Piso 2 Despacho 203, Corporativo Interpalmas,
Col. San Fernando Huixquilucan, Estado de México
Tel: [phone] http://www.viewsonic.com/la/soporte/index.htm

NÚMERO GRATIS DE ASISTENCIA TÉCNICA PARA TODO MÉXICO: 001.866.823.2004

Hermosillo:

Distribuciones y Servicios Computacionales SA de CV.
Calle Juarez 284 local 2
Col. Bugambilias C.P: 83140
Tel: [phone]
E-Mail: [e-mail]

Puebla, Pue. (Matriz):

RENTA Y DATOS, S.A. DE C.V. Domicilio:
29 SUR 721 COL. LA PAZ
72160 PUEBLA, PUE.
Tel: [phone] CON 10 LINEAS
E-Mail: [e-mail]

Chihuahua

Soluciones Globales en Computación
C. Magisterio # 3321 Col. Magisterial
Chihuahua, Chih.
Tel: [phone]
E-Mail: [e-mail]

Distrito Federal:

QPLUS, S.A. de C.V.
Av. Coyoacán 931
Col. Del Valle 03100, México, D.F.
Tel: [phone]
E-Mail : [e-mail]

Guerrero Acapulco

GS Computación (Grupo Sesicomp)
Progreso #6-A, Colo Centro
39300 Acapulco, Guerrero
Tel: [phone]

MERIDA:

ELECTROSER
Av Reforma No. 403Gx39 y 41
Mérida, Yucatán, México CP97000
Tel: [phone]
E-Mail: [e-mail]

Tijuana:

STD
Av Ferrocarril Sonora #3780 L-C
Col 20 de Noviembre
Tijuana, Mexico

4.3: ViewSonic Mexico Limited Warranty PRJ_LW03 Rev. 1A 06-25-07

Villahermosa:

Compumantenimietnos Garantizados, S.A. de C.V.
AV. GREGORIO MENDEZ #1504
COL, FLORIDA C.P. 86040
Tel: [phone]
E-Mail: [e-mail]

Veracruz, Ver.:

CONEXION Y DESARROLLO, S.A DE C.V. Av. Americas
# 419
ENTRE PINZÓN Y ALVARADO
Fracc. Reforma C.P. 91919
Tel: [phone]
E-Mail: [e-mail]

Cuernavaca

Compusupport de Cuernavaca SA de CV
Francisco Leyva # 178 Col. Miguel Hidalgo
C.P. 62040, Cuernavaca Morelos
Tel: [phone]
E-Mail: [e-mail]

Guadalajara, Jal.:

SERVICRECE, S.A. de C.V.
Av. Niños Héroes # 2281
Col. Arcos Sur, Sector Juárez
44170, Guadalajara, Jalisco
Tel: [phone]
E-Mail: [e-mail]

Monterrey:

Global Product Services
Mar Caribe # 1987, Esquina con Golfo Pérsico
Fracc. Bernardo Reyes, CP 64280
Monterrey N.L. México
Tel: [phone]
E-Mail: [e-mail]

Oaxaca, Oax.:

CENTRO DE DISTRIBUCION Y
SERVICIO, S.A. de C.V.
Murguía # 708 P.A., Col. Centro, 68000, Oaxaca
Tel: [phone]
Fax: [phone]
E-Mail. [e-mail]

FOR USA SUPPORT:

ViewSonic Corporation
381 Brea Canyon Road, Walnut, CA. 91789 USA
Tel: [phone] (English); 866-323-8056 (Spanish);
Fax: [phone]
E-Mail: http://www.viewsonic.com

ViewSonic 30 DVP5
