Venturer STS91 User Manual

Important Safety Instructions

The lightning flash with an arrowhead symbol, within the equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to cause an electric shock.

WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USERSERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

WARNING: CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

INVISIBLE LASER RADIATION WHEN OPEN AND INTERLOCKS DEFEATED.

TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

CAUTION

AVOID EXPOSURE TO BEAM

яюэььыъыюэьщшычшцхфяу эччэшщюыыюэьщшыхщыяюэььщыъ чшцхфяуц ыюэьщшыхщыяюэьщыъ чшцхфуцыюэьщшыяюэььщыъ

The exclamation point within the equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in this owner manual.

This product contains a low power laser device.

The symbol for Class II (Double lnsulation)

On Placement

• Do not use the unit in places which are extremely hot, cold, dusty, or humid.

• Place the unit on a flat and even surface.

• Do not restrict the air flow of the unit by placing it in a place with poor air flow, by covering it with a cloth, or by placing it on carpeting.

On Safety

• When connecting or disconnecting the AC cord, grip the plug and not the cord itself. Pulling the cord may damage it and create a hazard.

• When you are not going to use the unit for a long period of time, disconnect the AC power cord.

On Condensation

• When left in a heated room where it is warm and damp, water droplets or condensation may form inside the unit. When there is condensation inside the unit, the unit may not function normally. Let the unit stand for 1 to 2 hours before turning the power on, or gradually heat the room up and dry the unit before use.

WARNING:

• Should any trouble occur, disconnect the AC power cord and refer servicing to a qualified technician.

• Do not place anything directly on the top of the unit. Damage to the unit can result.

Notes on Copyright

It is forbidden by law to copy, broadcast, show, broadcast on cable, play in public, rent copyrighted material without permission.

Apparatus Claims of U.S. Patent Nos. 4,631,603; 4,577,216; 4,819,098 and 4,907,093 licensed for limited viewing uses only.

DVD video discs are copy protected, and any recordings made from these discs will be distorted. This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only, unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.

E - 1

IMPORTANT SAFETY INSTRUCTIONS

1. Read Instructions - All the safety and operating instructions should be read before the appliance is

operated.

2. Retain Instructions - The safety and operating instructions should be retained for future reference.

3. Heed Warnings - All warnings on the appliance and in the operating instructions should be adhered to.

4. Follow Instructions - All operating and use instructions should be followed.

5. Water and Moisture - The appliance should not be used near water - for example, near a bathtub,

washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool, and the like.

6. Carts and Stands - The appliance should be used only with a cart or stand that is

recommended by the manufacturer.

6A. An appliance and cart combination should be moved with care. Quick stops, excessive

force, and uneven surfaces may cause the appliance and cart combination to overturn.

7. Wall or Ceiling Mounting - The appliance should be mounted to a wall or ceiling only as

recommended by the manufacturer.

8. Ventilation - The appliance should be situated so that its location or position does not interfere with

its proper ventilation. For example, the appliance should not be situated on a bed, sofa, rug, or similar surface that may block the ventilation openings; or, placed in a built-in installation, such as a book case or cabinet, that may impede the flow of air through the ventilation openings.

9. Heat - The appliance should be situated away from heat sources such as radiators, heat registers,

stoves, or other appliances (including amplifiers) that produce heat.

10. Power Sources - The appliance should be connected to a power supply only of the type described in

the operating instructions or as marked on the appliance.

11. Grounding or Polarization - Precautions should be taken so that the grounding or polarization means

of an appliance are not defeated.

12. Power-Cord Protection - Power-supply cords

should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the appliance.

13. Cleaning - The appliance should be cleaned only

as recommended by the manufacturer.

14. Power Lines - An outdoor antenna should be

located away from power lines.

15. Outdoor Antenna Grounding - If an outside

antenna is connected to the receiver, be sure the antenna system is grounded so as to provide some protection against voltage surges and built up static charges. Section 810 of the National Electrical Code, ANSI/NFPA No. 70, provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode. See Figure 1.

16. Nonuse Periods - The power cord of the appliance should be unplugged from the outlet when left

unused for a long period of time.

17. Object and Liquid Entry - Care should be taken so that objects do not fall, and liquids are not spilled,

into the enclosure through openings.

18. Damage Requiring Service - The appliance should be serviced by qualified service personnel when:

A. The power-supply cord or the plug has been damaged; or B. Objects have fallen, or liquid has been spilled, into the appliance; or C. The appliance has been exposed to rain; or D. The appliance does not appear to operate normally or exhibits a marked change in performance; or E. The appliance has been dropped, or the enclosure damaged.

19. Servicing - The user should not attempt to service the appliance beyond that described in the operating

instructions. All other servicing should be referred to qualified service personnel.

E - 2

Table of Contents

Important Safety Instruction ..................... 1-2

Disc Formats ................................................ 4

Before You Start ........................................... 5

Using the remote control .......................................... 5

Parts and Functions .................................. 6-8

Remote Control ...................................................... 6-7

Front and Top Panel ................................................... 8

Display ......................................................... 9

Front Panel Display .................................................... 9

Display Information ................................................... 9

Setup ..................................................... 10-14

For better reception ................................................ 10

Connecting your TV ........................................... 10-11

Connecting a VCR .................................................... 12

Connecting another source .................................. 12

Connecting the speakers & subwoofer ................ 13

Positioning the speakers and subwoofer ............. 13

Mounting rear surround speakers .......................... 14

Turning on the Unit and TV .................................... 14

Power cord connection ........................................... 14

Adjusting the Sound ............................. 15-16

Playing a Disc ....................................... 17-19

Playing Disc ............................................................. 17

Pausing playback (still mode) ............................... 17

Stopping playback ................................................. 17

To skip to a different track ...................................... 17

Fast Foward/Fast Reverse ..................................... 18

Slow-motion play ................................................... 18

Skip (Forward/Reverse) .......................................... 18

Zooming into an image ......................................... 18

Angle selection ....................................................... 19

Audio selection ....................................................... 19

Subtitle selection .................................................... 19

Special Functions ................................. 20-22

Display function (DVD) .......................................... 20

Locating a specific title ......................................... 21

Locating a specific title/chapter/track .................. 21

Locating a specific time ......................................... 22

Angle setting ........................................................... 22

Audio setting .......................................................... 22

Subtitle setting ....................................................... 22

CD / DVD programmable memory ............... 23

DVD programmable memory ................................. 23

Title/Chapter programmed playback ............. 23

CD programmable memory ................................... 23

Track programmed playback .......................... 23

Repeat Playback ........................................ 24

Repeating a title/chapter (DVD) ............................ 24

Repeating a single track/whole disc (CD) ........... 24

Repeating a specific section (DVD) ...................... 24

Playing MP3 and Picture File Disc......... 25-26

Playing a MP3 file disc ............................................ 25

Playing a Picture file disc ....................................... 26

Playing a MP3/Picture file disc ............................... 26

Customizing the Function Settings ........ 27-34

LANGUAGE setting .................................................. 27

VIDEO setting ...................................................... 27-29

TV Shape .............................................................. 27

Video Output ....................................................... 28

Brightness ............................................................ 29

Edges .................................................................... 29

AUDIO setting ..................................................... 30-32

Digital Out ........................................................... 30

L/R speaker .......................................................... 30

Subwoofer ............................................................ 31

Surround Delay ................................................. 31

Center Delay ....................................................... 32

Pink noise ........................................................... 32

RATING setting ................................................... 33-34

Password/Parental lock .................................... 33

Factory Set .......................................................... 34

Radio Operation ......................................... 35

Language Code List for Disc Language ....... 36

Maintenance ................................................ 37

Cleaning Disc .......................................................... 37

Cleaning the Unit ................................................... 37

Important Note ....................................................... 37

Trouble Shooting Guide ........................ 37-38

E - 3

Disc Formats

The unit can playback discs bearing any of the following marks:

DVDs [8cm (3") / 12cm (5”) disc]

Audio CDs [8cm (3") 12cm (5”) disc]

Region Management Information

Region Management Information: This unit is designed and manufactured to respond to the Region Management Information that is encoded on DVD discs. If the Region number printed on the DVD disc does not correspond to the Region number of this unit, this unit cannot play that disc.

Compatible

The region number of this unit is 1.

Disc Function or Operation that is Not Available

When the symbol appears on the TV screen, it indicates that the function or operation attempted is not available at that time. This occurs because the DVD disc manufacturer determines the specific functions. Certain functions may not be available on some discs. Be sure to read the documentation provided with the disc.

Icons Used on DVDs

Sample lcons

Notes:

• This unit supports 2-channel (L/R) audio and 5.1ch (Multi-channel) MPEG Audio 1/2 (only when the DIGITAL AUDIO OUT coaxial jack is used for connection). It does not support 7.1 channel MPEG Audio Version 2.0.

• When playing back a CD-G (Graphics) or CD EXTRA disc, the audio portion will be played, but the graphic images will not be shown.

Title, Chapter and Tracks

• DVDs are divided into “titles” and “chapters”. If the disc has more than one movie on it, each movie would be a separate “title”. “Chapters” are sections of titles.

1. English

2. French

1. English

2. French

Language selections for audio Language selections for subtitles

Screen aspect ratio

Multiple camera angles Region code indicator

  

• Audio CDs are divided into “tracks”. A “track” is usually one song on an Audio CD.

ÿýþ úùüû ÿýþú ùü ÿýþú ùü яэюъщ ь ÿý þúù ü

Note :

• Numbers identify each title, chapter, and track on a disc. Most discs have these numbers recorded on them, but some do not.

Notes on Unauthorized Discs

You may not be able to play back some DVD discs on this unit if they were purchased from outside your geographic area or made for business purposes.

E - 4

Before Y ou Start

Using the Remote Control

• Point the Remote Control at the REMOTE SENSOR located on the Unit.

• When there is a strong ambient light source, the performance of the infrared REMOTE SENSOR may be degraded, causing unreliable operation.

• The recommended effective distance for remote operation is about 16 feet (5 meters).

To install Batteries

1.Open the battery door.

Battery Replacement

When batteries become weak, the operating distance of the Remote Control is greatly reduced and you will need to replace the batteries.

2. Insert two "AAA" or IECR03 [1.5V] size batteries.

Notes:

• If the Remote Control is not going to be used for a long time, remove the batteries to avoid damage caused by battery leakage corrosion.

• Do not mix old and new batteries. Do not mix ALKALINE, standard (CARBON-ZINC) or rechargeable (NICKEL-CADMIUM) batteries.

E - 5

Remote Control

üþ÷ü



3 4

þü

÷ù

6 7

ÿþ

8 9

10 11

÷üø÷ÿ

12 13 14

ýü ÿúþþ ÷û úýüû

16 17

ûÿýù

ÿþ÷

ÿ÷ ø 

  ÿýüøúÿ

яю эьыъщшчь

þüü üþ

÷÷øþ ÷û

ýû÷

ý ÿ   ýù

яюэяь

ÿ÷üû

ýú ûÿ

ýþ

Parts and Functions

1) FUNCTION button

Display the FUNCTION screen where you can check or change various setting.

ü

4) DISPLAY button

5) RETURN button

6) MEMORY button

÷

8) SETUP button

÷þ÷

10) ENTER button

11) SLOW

12)

13) P. SCAN / CVBS button

14)

15) Number (0 - 9) and (+10) buttons

16) ANGLE button

17) SUBTITLE button

PREV button

Move reverse through titles, chapters or tracks on a disc. Tune to the presetted stations.

/ TUNING buttons : Fast reverse playback. : Fast forward playback. TUNING : Scan all available radio stations.

Change disc status information displayed on the TV.

Return to the normal operation after using the SETUP menu.

Enter the number of a selected chapter or track. Enter the number of a selected station.

STOP button

Stop playback.

Open and close the unit's SETUP menu screen.

/ CURSOR buttons

Use to highlight selections on a menu screen and make adjust certain settings.

Confirm selections on a menu screen.

button

Perform slow forward playback of DVDs.

OPEN / CLOSE button

Use to open or close the disc tray.

Changing YUV output to Progressive Scan Video mode or back to CVBS mode.

PRO LOGIC II button

In AV_IN mode, switches to Dolby Pro Logic mode for VHS tapes encoded with Dolby Pro Logic.

Use when creating programs, and entering a parental level password. To select numbers over 9, press +10 button and then the second no. for example, to enter 18, press +10 and then 8.

Switch the camera angle of the video presentation when scenes with multiple camera angles are recorded on a DVD.

Select one of the subtitle languages programmed on a DVD.

яяяяя

E - 6

(Continued on next page)(Continued on next page)

(Continued on next page)

(Continued on next page)(Continued on next page)

Remote Control

üþ÷ü



þü

÷ù

ÿþ

÷üø÷ÿ

ýü ÿúþþ  ÷û úýüû

þüü üþ

ûÿýù

ÿþ÷

яюэяь

ÿ÷ ø

ÿýüøúÿ

яюэьыъщшчь

÷÷øþ  ÷ û 

ýû÷

ý ÿ   ýù

ü

ÿ÷üû

ýú ûÿ

ýþ

÷

÷þ÷

Parts and Functions

18) STANDBY / ON [ I / ] button

Turns the Unit on and puts it in standby mode.

button

18 19

20 21

22 23

24 25

26 27

30 31

19) NEXT

Move forward through titles, chapters or tracks on a disc. Tune to the presetted stations.

20) AUDIO button

Select one of the audio soundtracks programmed on a DVD or selects the audio output mode on a AUDIO CD.

21) ZOOM button

Zoom into an image.

TV MODE button

In stop mode, select whether to output the video signal. TV shows "AUTO" which means output signal depends on DVD disc (either NTSC or PAL). TV shows "PAL" or "NTSC" which means output signal fixed to PAL or NTSC.

PAUSE button

22)

Pause playback, frame advance.

23) PLAY button

Start playback.

24) MENU button

Open and close DVD's menu.

/ CURSOR buttons

25)

Use to highlight selections on a menu screen and adjust certain settings.

26) 5.1 / 2.1 CH button

Switch speaker output to 5.1 channel mode. (All speakers + subwoofer)

Switch speaker outputs to 2.1 channel. (Front left/right speakers + subwoofer)

27) SOUND button

Selects sound balance and tone controls for adjustment with the cursor buttons.

28) VOL + / - buttons

Adjust the volume.

29) GOTO button

Skip directly to a specific location on a DVD disc.

30) BAND / REPEAT-DISC button

Switch between AM(MW) or FM. Repeat chapter or title of a DVD. Repeat single track or whole CD.

31) FM MODE / REPEAT A - B button

Set FM MODE to FM STEREO for FM stereo sound or to FM MONO for mono sound.

Perform point-to-point repeat playback on a DVD or CD.

E - 7

(Continued on next page)(Continued on next page)

(Continued on next page)

(Continued on next page)(Continued on next page)

Front and Top Panel

Parts and Functions

910

1) Disc tray

Open or close tray by pushing OPEN/CLOSE button. Place a disc on the disc tray, label side up.

2) STANDBY indicator

When the Unit is turned on by pressing the STANDBY/ON button. If you press the ON button on the remote control, the Unit will turn off and go into standby mode. The light will continue to illuminate.

3) Display window

Display system information.

OPEN/CLOSE button

Use to open and close the disc tray.

Note:

Screen saver - If no button is pressed within 2 minutes, the function will active. If you want to return the normal screen, press any button.

STANDBY/

PLAY button

Press to start or resume playback

STOP button

Stop playing a disc.

7) FUNCTION button

Select the source.

8) VOLUME controls

Change the loudness of the sound from the speakers connected to the Unit.

9) STANDBY/ON button

Turn the power on or off.

10 ) Remote sensor

Receive the remote control unit signals.

Rear Panel

17 1816151311 12

SPEAKER IMP. 6 ohm

RIGHT

FRONT REAR

SUBWOOFER CE NTER

FM ANT.

LEFT

Ω

300

FRONTREAR

IMP. 6 ohmIMP. 6 ohm

11) Right FRONT speaker terminals

12) SUBWOOFER terminals

13) Left REAR speaker terminals

14) FM ANTENNA jack

15) DIGITAL AUDIO OUT jack

16) COMPONENT VIDEO jacks (Y, PB/CB, PR/CR)

17) VIDEO OUT jack

18) Left/Right AUDIO IN jacks

21 24 25 26

19) Right REAR speaker terminals

20) CENTER speaker terminals

21) Left FRONT speaker terminals

22) AM(MW) LOOP ANTENNA terminal

23) S-VIDEO OUT jack

24) Left/Right AUDIO OUT jacks

25) VIDEO IN (VCR) jack

26) Power cord

E - 8

Front Panel Display

DOLBY PRO LOGIC II indicator

When Dolby Pro Logic sound is selected in AV_IN mode, the light will illuminate.

Display

REPEAT 1 playback indicator

Displayed during repeat of CD/DVD playback.

DOLBY DIGIT AL indicator

Displays while Dolby Digital sound processing is being performed or when the loaded disc contains Dolby Digital sound.

ANGLE indicator

Appears when multiple camera angles are recorded in the section of the DVD that is currently playing.

OPERA TION indicator

Indicates the operation status of the disc and Unit.

REPEAT A-B playback indicator

Displayed during repeat of specific section of DVD playback.

MEMORY indicator

Displayed during programmed playback.

Display Information

The DVD displays the information shown below on the TV screen and on the Unit's DVD display depending on the operation status.

Display Examples

If no disc is loaded when the Main Unit is switched on.

Tray open

TV Screen

No Disc

Unit Display

Remarks

" appears when the tray is closed and:

1)There is no disc in the tray.

2) The disc type is not playable in this Unit.

3) The disc is not loaded correctly (upside-down, etc.)

Tray closed Loading Stopped

Playing Paused

Fast forward Fast reverse Slow

Repeat A - B

Stop

Play

Pause

x 2

1/2

Rep A- Rep A-B

A-B

The display changes to show other indicators. (total time, etc.)

Freezes the image on the screen or pauses audio playback. The display changes to show other indicators.

(total time, etc.)

Does not function for Audio CDs. Repeat a specific section.

The operation is not permitted by the DVD Unit or the disc.

Region (Local) Number Error Indicator

If the region (local) number of the disc that you attempt to play differs from the region number of the Unit. "Invalid Region" appears on the TV screen. (The disc cannot be played).

E - 9

Setup

For better reception

Connect FM antenna (supplied) to the FM ANTENNA jacks.

AM(MW)

Connect the loop antenna (supplied) to the AM(MW) LOOP ANTENNA terminals.

SPEAKER IMP. 6 ohm

RIGHT

FRONT REAR

SUBWOOFER CENTER

FM ANT.

Ω

300

LEFT

FRONTREAR

IMP. 6 ohmIMP. 6 ohm

яюэьыъъэющшъчш

A.Connecting your TV

The unit can be connected to your TV in several different ways, depending on the design of your TV.

RCA Audio/Video cable

Use the Audio/Video cable (supplied). Connect the VIDEO OUT and left/right AUDIO OUT jacks on the unit to the VIDEO IN and left/right AUDIO IN jacks on your TV.

SPEAKER IMP. 6 ohm

RIGHT

FRONT REAR

SUBWOOFER CE NTER

FM ANT.

Ω

300

LEFT

FRONTREAR

IMP. 6 ohmIMP. 6 ohm

яюэьыъъэющшъчш

(red) (white) (yellow)

Audio/Video cable (supplied)

Note:

If you want the sound come from the speakers of the Main Unit, you need not to connect the left/right AUDIO OUT jacks from the Main Unit to your TV.

S-Video cable

Use an S-Video cable (not supplied) and the Audio cable (not supplied).

1. Use an S-Video cable to connect the S-VIDEO (DVD) jack on your unit to the S-VIDEO IN jack on your TV.

2. Next, use the Audio cable to connect the left/right AUDIO OUT jacks on the unit to the left/right AUDIO IN jack on your

TV.

RIGHT

FRONT REAR

SUBWOOFER

SPEAKER IMP. 6 ohm

FM ANT.

Ω

300

LEFT

FRONTREAR

CENTER IMP. 6 ohmIMP. 6 ohm

Audio cable (not supplied)

яюэьыъъэющшъчш

(red)

(white)

S-Video cable (not supplied)

E - 10

(continued to next page)(continued to next page)

(continued to next page)

(continued to next page)(continued to next page)

Setup

Component video outputs (DVD)

Some TVs or monitors are equipped with component video inputs. Using the Audio cable (not supplied), connect the left/right AUDIO OUT jacks on your Unit to the left/right AUDIO IN

jacks on your TV and the Component video cable (not supplied), connect the Green plug Y VIDEO OUT jack on your Unit to Y VIDEO IN jack on your TV, the Blue plug PB/CB VIDEO OUT jack on your Unit to PB/CB VIDEO IN jack on your TV and the Red plug PR/CR VIDEO OUT jack on your Unit to PR/CR VIDEO IN jack on your TV to view the higher quality picture playback.

Progressive outputs (DVD)

Some TVs or monitors are equipped with component video inputs that are capable of reproducing a progressively scanned video signal.

Using the Audio cable (not supplied), connect the left/right AUDIO OUT jacks on your Unit to the left/right AUDIO IN jacks on your TV and the Component video cable (not supplied), connect the Green plug Y VIDEO OUT jack on your Unit to Y VIDEO IN jack on your TV, the Blue plug PB/CB VIDEO OUT jack on your Unit to PB/CB VIDEO IN jack on your TV and the Red plug PR/CR VIDEO OUT jack on your Unit to PR/CR VIDEO IN jack on your TV to enjoy highest quality picture with less flicker.

Press the SETUP button and select Video Output to YUV. Connect the component video cable to TV, press the P. SCAN button on the remote control when DVD is stopped. "P. SCAN" display. You can select the output signal for better picture quality.

Attention:

• When progressive output is activated, there is no video signal output from S-video and RCA (CVBS) video jacks.

• Make sure your TV supports progressive scan component video signal, press the P. SCAN button repeatedly until "CVBS" is displayed to go back to CVBS video signal.

SPEAKER IMP. 6 ohm

RIGHT

FRONT REAR

SUBWOOFER CE NTER

FM ANT.

300

LEFT

Ω

FRONTREAR

IMP. 6 ohmIMP. 6 ohm

яюэьыъъэющшъчш

VIDEO

OUT

PB/CB

VIDEO

OUT

Component video cable (not supplied)

PR/CR

VIDEO OUT

Audio cable

(not supplied )

(white)

(red)

To VIDEO IN

PB/CB

To VIDEO IN

PR/CR

Coaxial Antenna Jack

Some TVs do not have an RCA or S-Video jack, they only have a coaxial antenna jack. In order to connect this Unit to these TVs, you must purchase an RF modulator (availabel in teh Audio/Video department of most electronics retailers or at http://www.18002526123.com) and follow the instructions included with it.

Notes :

• Connect the Unit to your TV directly. If you connect the Unit through a VCR, the playback picture will be distorted because DVD discs are copy protected.

• When you connect the Unit to other equipment, be sure to turn off the power and unplug all of the equipment from the wall outlet before making any connection.

• Refer to the instruction manual of the connected equipment as well.

E - 11

(continued to next page)(continued to next page)

(continued to next page)

(continued to next page)(continued to next page)

Setup

B. Connecting a VCR

1. Using the supplied Audio/Video cable, connect the yellow plug from VIDEO OUT jack on your Unit to VIDEO IN jack on your TV , connect the left and right AUDIO OUT jacks on your Unit to A UDIO IN jacks on your TV . If you w ant the sound come from the speakers of t he Main Unit, you need not to connect these left and right Audio cable from the Main Unit to your TV .

2. Using the Video cable (not supplied), connect the VIDEO IN (VCR) jack on your Unit to VIDEO OUT jac k on your VCR.

3. Using the Audio cable (not supplied), connect the left/right AUDIO IN jacks on your Unit to the A UDIO OUT jacks on your VCR.

Watching a Videotape

1. Turn on the Unit, use the FUNCTION button on the remote control or the front panel to select "AV_IN".

2. T urn on your TV and follo w the instructions included with it to select VIDEO function which corresponds to the VIDEO IN jack that is connected with the Main Unit.

3. Tu rn on the VCR and follow the instructions included with it to play the videotape.

Notes:

• If you have a mono VCR, the volume level from the speakers will be low . T o a void this, connect the left/right audio out from the Unit to the left/right audio inputs on your TV using the supplied A/V cable.

• S-video and Component Video jacks (Y, P

B, PR) is only for D VD .

FRONT REAR

RIGHT

SUBWOOFER

SPEAKER IMP. 6 ohm

FM ANT.

300

Ω

LEFT

FRONTREAR

CENTER

IMP. 6 ohmIMP. 6 ohm

яюэьыъъэющшъчш

Audio cable

(not supplied)

(white)

(red)

Audio/Video cable

(supplied)

(yellow)

Video cable (not supplied)

(white) (red) (yellow)

C.Connecting another source

Analogue connection

Using the Audio cable (not supplied), connect the left/right A UDIO OUT jack on your Unit to the A UDIO IN jack.

Digital connection

Using the Coaxial Digital Audio cable (not supplied), connect the DIGITAL AUDIO OUT on your Unit to the DIGITAL AUDIO IN jack on your another equipment.

Listening to another audio equipment

1.T urn on the Unit.

2.Turn on your audio equipment and follow the instructions included with it to select the AUDIO IN or DIGIT AL IN function.

Notes:

• When you connect the Unit to other equipment, be sure to turn off the power and unplug all of the equipment from the wall outlet before making any connection.

• If the external equipment is a television and this audio system is closed to it, you may experience interference if the tuner function is selected while the television is working.

• If you have a stereo VCR, make sure you set it in stereo mode .

• Due to copyright protection, DVD movies cannot be copied. If you cop y a DVD mo vie onto a videotape, the resulting copy will be unclear, with poor sound quality. This is NOT caused b y a defective D VD system.

• Refer tot he instruction manual of the connected equipment as well.

RIGHT

FRONT REAR

SUBWOOFER

SPEAKER IMP. 6 ohm

FM ANT.

300

Ω

LEFT

FRONTREAR

CENTER

IMP. 6 ohmIMP. 6 ohm

Audio cable

(not supplied )

Coaxial digi tal audio cable

(not supplied )

(red)

(white)

яюэьыъъэющшъчш

яюэьыъыщшчцъч

щшщцчщючщ

ö÷ûüù

Audio equipment with digital

audio input jack

ANALOGUE

CONNECTION

DIGITAL

CONNECTIO N

E - 12

(continued to next page)(continued to next page)

(continued to next page)

(continued to next page)(continued to next page)

Setup

D. Connecting the speakers & subwoofer

The speaker cords have been color-coded to simplify connection. Just plug the POSITIVE (+) and NEGATIVE (-) ends of each speaker wire into the corresponding jacks on the rear of the Unit, matching the color tube on the end of the speaker wire to the color-coded connector.

FRONT (RIGH T) REAR (RIGHT) REAR (LEFT) FRONT (LEFT )

E. Positioning the speakers and subwoofer

FRONT SPEAKERS

Place on both sides of theTV,equal distances apart.

SUBWOOFER

Canbeplacedanywhere.

CENTER

Place on the top of or below the TV.

REAR SPEAKERS

Place right beside or slightly behind your listening position, and a little higher than your ears.

CENTERSUBWOOFER

E - 13

(continued to next page)(continued to next page)

(continued to next page)

(continued to next page)(continued to next page)

Setup

Mounting rear surround speakers

1) Mark the correct mounting position on the wall.

2) Insert a fixing screw(s) at the marked position on the wall.

3) Align the slot hole(s) of the speaker over the screw and pull the speaker downward until it is firmly hooked.

Need More Help?

DO NOT RETURN THIS TO THE STORE

Please call Customer Service at 1-800-252-6123

or visit online help at http://www.18002526123.com

Turning on the Unit and TV

1)Press the STANDBY/ON button to turn the Unit ON, or

2)Press the the Unit while the Unit is in standby mode.

3)Turn on the TV by pressing its POWER button.

4)Select the channel on your TV corresponding to the VIDEO IN jack that the Unit is connected to. See TV User guide for more information.

• If you have connected the Unit successfully, the DVD logo (start-up picture) will appear on your TV screen.

Notes :

• Whenever no disc or disc stop for 60 minutes, the system will be turned to POWER standby mode automatically.

• The LED of Standby will be turned on while the unit is at standby mode.

ST ANDBY/ON button on the remote control or the FUNCTION button or the PLAY b utton to turn on

Power cord connection

• Make sure that all the components and speakers are connected correctly.

• To prevent electrical shock, match wide blade of plug to wide slot, fully insert.

• Be sure the AC power cord is disconnected and all functions are off before making connections.

• When you are not going to use the Unit for a long period of time, disconnect the power cord.

E - 14

Adjusting the Sound

To adjust the surround sound balance while Dolby Digital and Pro Logic II decoding is in effect

Use the remote control to make the following changes to speaker balance:

Front speaker (left)

• Press the SOUND button repeatedly to display will show on the display of the Unit.

Front speaker (right)

• Press the SOUND button repeatedly to display will show on the display of the Unit.

Center speaker

• Press the SOUND button repeatedly to display will show on the display of the Unit.

Rear speaker (left)

• Press the SOUND button repeatedly to display will show on the display of the Unit.

Rear speaker (right)

• Press the SOUND button repeatedly to display will show on the display of the Unit.

Subwoofer

• Press the SOUND button repeatedly to display will show on the display of the Unit.

Note :

• If you do not press any button within a few seconds, the display will return to normal.

, then press the or CURSOR button to adjust the sound level. It

, then press the or CURSOR button toadjust the sound level. It

, then press the or CURSOR button to adjust the sound level. It

To adjust the sound quality

Press the SOUND button repeatedly to select an equalization mode (BASS and TREBLE). Press the or CURSOR button to adjust the sound level.

BASS : the low range of sounds TREBLE : the high range of sounds

Bass and treble control the sound from the front left and right speakers.

Dolby Digital

Dolby Digital is a sound system developed by Dolby Laboratories Inc. that gives movie theatre ambience to audio output when the Unit is connected to a Dolby Digital 5.1 channel processor or amplifier. This Unit automatically recognizes DVDs that have been recorded with Dolby Digital. Not all Dolby Digital sources are recorded with 6 channels. Some sources marked Dolby Digital may be recorded in Dolby Surround, a 2 channel system. Look for this logo on your DVD Unit.

Dolby Pro Logic II creates five full-bandwidth output channels from two-channel sources. This is done using an advanced, high-purity matrix surround decoder that extracts the spatial properties of the original recording without adding any new sounds or tonal colorations.

Movie Mode (MOVIE)

The Movie mode in Pro Logic II is very similar to that of the original Pro Logic decoder. The main difference is that it has stereo surround channels and no surround filter, unlike Pro Logic which has a mono surround channel and a 7 kHz surround filter. Movie mode is the standard required for all A/V systems. When an autosound unit has a video screen, it is also considered an A/V system. It can be called simply "Pro Logic II".

Music Mode (MUSIC)

The Music mode offers users some flexibility to control the end results to their own taste. Music mode should not be used with THX audio processing mode. Music mode is recommended as the standard mode for autosound music systems (without video), and is optional for A/V systems. It is recommended that Music mode be identified as the "Music" version of Pro Logic II, to distinguish it from the Movie mode.

E - 15

(continued to next page)(continued to next page)

(continued to next page)

(continued to next page)(continued to next page)

Adjusting the Sound

PCM

DVD /

(SMALL/

Pro Logic Emulation Mode (PL II and EMU)

The Pro Logic emulation mode offers users the same robust surround processing as original Pro Logic, in case the source content is not of optimum quality, or if there is a desire to hear the program more "as it used to be". When this mode is used, it is called Pro Logic, as before. There is no "Pro Logic I" mode. The Pro Logic emulation mode is optional. Dolby does not require PLII products to use the original Pro Logic decoding algorithm. However, if the DSP contains the original Pro Logic code, and if the product maker would like to use it, this is quite acceptable and even encouraged. A product must not offer both original Pro Logic and the Pro Logic emulation mode.

Matrix Mode (MATRX)

The Matrix mode is the same as the Music mode except that the directional enhancement logic is turned off. It may be used to enhance mono signals by making them seem "larger". The Matrix mode may also find use in auto systems, where the fluctuations from poor FM stereo reception can otherwise cause disturbing surround signals from a logic decoder. The ultimate "cure" for poor FM stereo reception may be simply to force the audio to mono.

Manufactured under license from Dolby Laboratories. 'Dolby' , 'Pro Logic' and the double-D symbol are trademarks of Dolby Laboratories.

To select the listening channel

1.When the disc is stopped, you can press the 5.1/2.1 CH button on the remote control to select different speakers output status shown on below table.

2.At AV IN function mode, you also can press the PRO LOGIC II button repeatedly on the remote control to select

PRO LOGIC II (indicator on the front panel of display will illuminate).

3.You can active or off subwoofer output by setup menu.

Notes:

• The wording "2.1 CH" will be corresponded to the audio/sound output from Front Left and Front Right speakers plus the Subwoofer.

• 5.1/2.1 CH button is no response to JPG CD-ROM or JPG/MP3 CD-ROM. Please select 5.1/2.1 CH output before putting such CD-ROM.

• Dolby Digital 5.1 CH will not be activated on Pro Logic II.

The following table shows which speakers are working in the various modes.

L/R

SPEAKER

LARGE)

SMALL ON 5.1 5.1 5.1 5.1 5.1 or 2.1 LARGE ON 5.1 5.1 5.1 5.1 5.1 or 2

--- OFF 5 5 5 5 5 or 2 SMALL ON 2.1 2.1 2.1 2.1 2.1 LARGE ON 2 2 2 2 2

--- OFF 2 2 2 2 2

--- ON 5.1 5.1 5.1 5.1 5.1

--- OFF 5 5 5 5 5 SMALL ON 2.1 2.1 2.1 2.1 2.1 LARGE ON 2 2 2 2 2

--- OFF 2 2 2 2 2

SMALL ON 5.1 5.1 5.1 5.1 5.1 LARGE ON 5.1 5.1 5.1 5.1 2.1

--- OFF 5 5 5 5 5

MP 3

DVD

---

5.1 / 2.1 CH

Button

5.1 CH

2.1 CH

5.1 CH --- --- 5.1 5.1 5.1 5.1 5.1

2.1 CH --- ON 2.1 2.1 2.1 2.1 2.1

--- --- OFF 2 2 2 2 2

5.1 CH

2.1 CH

FUNCTION DISCS

DVD MODE

TUNER --- --- --- --- 2.1 2.1 2.1 2.1 2.1

AV_IN ---

SUB-

WOOFER

ON/OFF

EMU MATRIX MUSIC MOVIE

5.1- Represents FRONT LEFT/RIGHT, REAR LEFT/RIGHT, CENTER speakers and SUBWOOFER

2.1- Represents FRONT LEFT/RIGHT speakers and SUBWOOFER 5 - Represents FRONT LEFT/RIGHT, REAR LEFT/RIGHT and CENTER speakers 2 - Represents FRONT LEFT/RIGHT speakers

Dolby Pro Logic II Selection

PASS

Dolby Pro

Logic II not

applied on

Tuner, MP3

and PCM

DVD.

DVD CD

Basic playback

Playing a Disc

This owner’ s manual explains the basic instructions of this DVD Unit. Some DVD discs are produced in a manner that allows specific or limited operation during playback. As such, the D VD Unit may not respond to all operating commands. This is not a defect in the D VD Unit. Refer to the instruction notes of discs.

“ ” may appear on the TV screen during operation. A “ ” means that the desired operation is not permitted by the DVD Unit or the disc.

Playing a Disc

1.Press the STANDBY/ON b utton on the front panel or press the STANDBY/ON b utton on the remote control to turn on the Unit while the Unit is in standby mode, press the FUNCTION button to select DVD mode.

See CUSTOMIZING THE FUNCTION SETTINGS before proceeding to step 2.

2.Press the

3.Place the disc on the disc tray with the label side up.

4.Press the

It takes a short while for your Unit to load the disc. After loading, for some discs, the Unit will automatically start playback of the disc.

5.Press the PLAY button.

Notes:

• Use the may damage the Unit.

• Let the disc tray open completely before removing the disc. Press the tray after you remove the disc.

OPEN/CLOSE button. The disc tray opens.

OPEN/CLOSE button. The disc tray closes.

OPEN/CLOSE button on the front panel to open or close the disc tray. Do not push the disc tray or you

OPEN/CLOSE button to close the disc

Pausing playback (still mode)

Press the II PAUSE button. To resume normal playback, press the PLAY button.

Stopping playback

Press the STOP button at the location where you want to interrupt playback. To resume playback at the position where the disc was stopped, press the If you press the the disc to the beginning.

STOP button twice, the Unit’s memory will be cleared and pressing the PLAY button will reset

PLAY button.

T o skip to a different trac k

• Press the PREV button on the remote once to skip to the start of the previous track.

• Press the

• For audio CD disc, use the number buttons (remote control only) to jump straight to that track number.

NEXT button on the remote to skip to the next track.

E - 17

(continued on next page)(continued on next page)

(continued on next page)

(continued on next page)(continued on next page)

Playing a Disc

Fast Forward/Fast Reverse

1.Press the TUNING or TUNING button when a disc is pla ying.

• The disc begins fast scan at x2 speed.

• Four speeds are available. Each time TUNING

button is pressed, the speed of fast scan changes in the following sequence:

2.Press the

Slow-motion play

1.Press the SLOW button in the play mode.

• Two speeds are available. Each time SLOW button is pressed, the speed of slow-motion playback changes

in the following sequence:

2. Press the

PLAY button when you reach the desired point to resume playback at normal speed.

DVD

PLAY button to return to the normal playback speed.

SKIP (Forward / Reverse)

While you are playing a disc, press the NEXT button of the remote to move to the beginning of the next chapter or track. Press the PREV button of the remote to move to the previous chapter or track and automatically start playing it.

DVD CD

or TUNING

x 1/2 x 1/4

DV D C D

The speed of fast scan

x 2

Zooming into an image

While a disc is playing, press the ZOOM/TV MODE button.

• While an image is zoomed, you can use

• To return to the normal view, press the ZOOM/TV MODE button until the “ return to normal.

, , and button to shift the view and display the part you want.

“ symbol shows. The screen will

off

• When you reach the edge of the image, the display will not shift anymore in that direction.

(continued on next page)(continued on next page)

(continued on next page)

E - 18

(continued on next page)(continued on next page)

DVD

Playing a Disc

Angle selection

Some DVDs contain scenes which have been shot from a number of different angles. For these discs, the same scene can be viewed from each of these different angles.

1.While you are playing a D VD with different angles recorded, press the ANGLE button to view the number of the current angle.

2.Press the ANGLE button repeatedly to change the scene to the next angle in those recorded.

• About two seconds later, pla yback continues from the ne w

angle you selected.

• If no button is pressed within 10 seconds, playback

continues without changing the current angle.

Sequence of angle shots

(Example)

Notes:

• This function can only be used for discs on which scenes shot from multiple angles have been recorded.

1/1

• If only one angle is recorded, “

” is displayed.

2/3

Number changes to show the number of the current angle. (The maximum number of possible angles is 9)

Audio selection

On some discs, the sound is recorded in two or more formats. Follow the directions below to select the type of playback.

1.While a disc is playing, press the AUDIO button to show the current audio format number.

2.Press the AUDIO button repeatedly to select the desired audio format.

Notes :

• If only one audio format is recorded, the number does not change.

• About two seconds later, playback continues in the new audio format.

Recorded audio format number changes sequentially. (The maximum number of possibl e audio formats is 8)

Subtitle selection

1.While a DVD is playing, press the SUBTITLE button to

display the current language setting, as shown in the example below.

2. Press the SUBTITLE button repeatedly to select the desired subtitle language.

Notes :

• If only one language is recorded, the language does not change.

• About two seconds later, playback continues with the new subtitle you selected.

• The number of languages recorded differs depending on the disc.

• If no button is pressed within a few seconds, playback continues without changing the current subtitle.

• This function can only be used for discs on which subtitles have been recorded in multiple languages.

• On some DVDs, subtitles are activated from the main menu of the DVD. Press the MENU button to activate the main menu.

2/3 Spa

Recorded language changes sequentially.

E - 19

DVD

Basic playback

Special Functions

DISPLAY function

Using DISPLA Y, you can check and change the current settings of the follo wing items: ANGLE, A UDIO and SUBTITLE.

• While the disc is playing, press the DISPLAY button to display the screen shown below.

Elapsed time: Elapsed time from the beginning of the chapter which is currently playing. Remaining time: Remaining time of the title which is currently playing.

Elapsed Time Remaining Time

• Press the DISPLAY button twice to display the screen shown as below.

• Press the ANGLE, AUDIO and SUBTITLE button to change the selected item.

Chapter

Title

DVD 00:09:29 01:25: 27 Title 1/10 Chapter 3/15 Angle 1/3

Audio setting

Subtitle setting

Audio Subtitle BitRate 7.1 Mbps

2/3 Spa

Title skip

• The number of the title currently playing and total titles of disc.

• Press the GOTO button to set your desired title, then press the ENTER button to confirm.

Chapter skip

• The number of the chapter currently playing and total chapters of the currently played title.

• Press the GOTO button to set your desired chapter, then press the ENTER button to confirm.

Time skip

• Elapsed time from the beginning of the currently playing chapter and the remaining time from the beginning of the currently playing title.

• Press the GOTO button to set your desired point to start playback, then press the ENTER button to confirm.

Angle setting

• The current angle is displayed. When a disc with only one angle is played back, “

• Press the ANGLE button to select the desired angle.

Audio setting

• The type of audio currently selected is displayed.

• Press the AUDIO button to select your desired type of audio.

Subtitle setting

• The subtitle number and language currently selected is displayed. When a disc with only one subtitle is played

1/1 Eng

back, “

• Press the SUBTITLE button to select your desired language.

” is displayed.

Time

Angle setting

” is displayed.

Angle 1/1

GOTO function

This function allows you to skip directly to any part of the disc while a disc is playing.

Note :

• After settings, press the DISPLAY button again to return to the normal screen.

E - 20

(continued on next page)(continued on next page)

(continued on next page)

(continued on next page)(continued on next page)

Basic playback

Special Functions

Locating a specific title

If a DVD disc contains title numbers, you can locate a specific title by directly selecting a title number.

1.In stop mode, press the GOTO button.

2.Press , or button to highlight a specific field and press the corresponding number button(s) for the title you want.

3.Press the ENTER button to confirm. The Unit will start playback about 3 seconds later.

Locating a specific title / chapter / track

If you know the title / chapter / track n umber you want to pla y, you can locate a specifc title / chapter / track by directly selecting a title / chapter / track number.

1.Press the GOTO button to search your desired title / chapter / track.

2.Press , or button to highlight a title / chapter / track and press the corresponding number button(s) for the chapter you want.

3.Press the ENTER button to confirm. The Unit will start playback about 3 seconds later.

DVD

DVD CD

DVD

E - 21

(continued on next page)(continued on next page)

(continued on next page)

(continued on next page)(continued on next page)

Basic playback

Special Functions

Locating a specific time

You can move to a specific location by entering its corresponding time (hours, minutes, seconds).

1.Press the GOTO button.

2.Press or button to highlight time.

DVD CD

3. Press the corresponding number buttons for the setting point you want.

• The first two numbers you entered represent hours.

• The second two numbers you entered represent minutes.

• The third two numbers you entered represent seconds.

4.Press the ENTER button to confirm. The Unit will start playback about 3 seconds later.

Notes :

• Some discs may not respond to this process.

• Some scenes may not be located as precisely as you specified.

• This method for accessing specific locations is available only within the current title of the DVD disc.

• You can move through the menu by pressing the

DVD CD

and buttons.

Angle setting

1.Press the DISPLAY button twice. The FUNCTION menu is displayed on the screen and you can see how many angles are recorded on the disc.

2.Press the ANGLE button repeatedly to select your desired angle.

3.The Unit will change to your desired angle about 3 seconds later.

Audio setting

1.Press the DISPLAY button twice. The FUNCTION menu is displayed on the screen and you can see how many audio formats are recorded on the disc.

2.Press the AUDIO button repeatedly to select your desired type of audio.

3.The Unit will change to your desired type audio about 3 seconds later.

Subtitle setting

1.Press the DISPLAY button twice. The FUNCTION menu is displayed on the screen and you can see how many subtitle formats are recorded on the disc.

2. Press the SUBTITLE button repeatedly to select your desired language.

3. The Unit will change to your desired language about 3 seconds later.

DVD

DV D

BitRate 7.1 Mbps

E - 22

Advanced playback

CD / DVD programmable memory

Programmable memory

The two types of programmed playback provided by this Unit are title programmed playback and chapter programmed playback.

DVD

Title / Chapter programmed playback

1.Press the MEMORY button while the disc is stopped.

2.Enter the title numbers in in

- -

3.Use

4.Repeat steps 2 to 3.

5.Press the

Notes :

• If you press the

, , or button to move to the other field.

PLAY button to star t the programmed playback.

STOP button twice at programmed playback mode, the programmed playback function will be

cancelled.

. Use or button to move the highlight to chapter and enter the chapter numbers

- -

Title

Chapter

Programmable memory

Track programmed playback

1.Press the MEMORY button while the disc is stopped.

2.Enter the track numbers in

3.Use

4.Repeat steps 2 to 3.

5.Press the

Notes :

• When the unit is playing at program memory mode, the “MEMORY” will display on display window.

, , or button to other field.

PLAY button to star t the programmed playback.

- - -

Track

E - 23

Advanced playback

You can play a specific title or chapter repeatedly. (Title repeat, chapter repeat, A-B repeat)

Repeat Playback

Repeating a title

You can play the same title repeatedly.

1.While the disc is playing, press the REPEA T DISC button until the “ indicator displays on the screen. The current title is played repeatedly.

DVD

Repeat Title

Repeating a chapter

You can play the same chapter repeatedly.

2.While the disc is playing, press the REPEAT DISC button until the “

Repeat Chapter

repeatedly .

” indicator displays on the screen. The current chapter is play ed

To resume normal playback

3. While the disc is playing, press the REPEAT DISC button until the “ indicator displays on the screen.

You can play a single track and whole disc repeatedly.

Repeating a single track

You can play the same track repeatedly.

1.While the disc is playing, press the REPEAT DISC button until the “

Repeat Single

repeatedly.

” indicator displays on the screen. The current track is played

Off

”

Repeating a whole disc

2.While the disc is playing, press the REPEA T DISC button until the “ indicator displays on the screen. The whole disc is played repeatedly.

Repeat All

”

To resume normal playback

3. Press the REPEAT DISC button until the “ screen.

Repeating a specific section

You can play a specific section repeatedly.

1. While the disc is playing, press the REPEAT A-B button at the beginning of the section (

2. Press the REPEAT A-B button again at the end of the section ( displayed.

3. The Unit will immediately begin replaying your selection.

) is displayed you want to play repeatedly.

Rep A -

Off

” indicator displays on the

DV D

Rep A - B

) is

To resume normal playback

4.While the disc is playing, press the REPEA T A-B button until the “ displays on the screen.

Notes :

• A-B repeat can only be used within the same title. If the start and end of the section to be repeated are in different titles,

A-B repeat is cancelled.

• The A-B repeat function does not operate in scenes where different camera angles are recorded.

E - 24

Off

” indicator

Playing MP3 and Picture File Disc

This Unit will play MP3 and Picture files recorded on CD-R disc.

Playing a MP3 file disc

1. Press the OPEN/CLOSE button, the disc tray opens.

2. Insert a MP3 file disc on the disc tray with the label side up.

Press the OPEN/CLOSE button, the disc tray closes.

4. The Unit will take a short while to load the disc and automatically

begin playback.

To pause playback

•

Press the PAUSE button. To resume playback again, press the PLAY button.

To stop playback

•

Press the STOP button.

To skip to the next or previous file

•

Press the NEXT button on the remote control briefly while playing, to skip ahead to the beginning of the next file. Each time you press the button consecutively, the beginning of the next file is located and played back.

•

Press the PREV button on the remote control briefly while playing, to skip back to the beginning of the previous file. Each time you press the button consecutively,the beginning of the previous files is located and played back.

• You also can press the GOTO button, set the track number you want and then press the ENTER button.

Note:

• You can not play in Fast reverse or Fast forward during MP3 playback.

On-screen display

Turn on your TV to view the on-screen display of MP3 files.

• Press the

press ENTER button and this selected file is located and played back.

Notes:

The ability of this Unit to read MP3 discs is dependent on the following:

•

The Bit Rate must be within 64 - 256 kbps.

•

The total number of files on the disc should not exceed 254.

•

The maximum number of directories should not exceed 32.

•

The maximum depth level of directories should not exceed 4.

•

File names should be named using 12 or fewer letters and/or numbers, and must incorporate the “MP3” file extension. EXAMPLE: ********.MP3 where each * is a letter or number.

•

Use only letters and / or numbers in file names. If you use special characters, the file and/or folder names may not be displayed correctly on the on-screen display.

•

When recording on CD-R discs, use 74-minute (650MB) discs.

•

The CD-R discs should be “finalized” in computer by “single session format”.

•

See your CD/MP3 creation software for details.

, , or CURSOR button on the remote control to select the file you want to listen to, then

E - 25

(continued to next page)(continued to next page)

(continued to next page)

(continued to next page)(continued to next page)

Playing MP3 and Picture File Disc

Playing a Picture file disc

1. Press the OPEN/CLOSE button, the disc tray opens.

2. Insert a Picture CD on the disc tray with the label side up.

3. Press the OPEN/CLOSE button, the disc tray closes.

4. The unit will take a short while to load the disc.

5. Press the

PLAY button. The next picture will automatically display after 6 seconds.

Full-Screen

Review

PREV NEXT

Notes:

• If you press the MENU button on the remote control in full-screen review, the Unit will display a menu of 9

thumbnail images.

• Use the cursor to highlight the

button to review other images. If you want to review one image in full-screen, you can use the CURSOR

, or button to highlight the image and then press the ENTER button to confirm. The image you

selected will show on TV in Full-Screen and automatically display one by one again in about 6 seconds intervals.

• You can press the PAUSE button to interrupt playback, and press the

• You also can use GOTO function or use the numbered buttons to enter the number to quickly select any

image.

• You can press the ZOOM button to enlarge the picture in 3 levels.

• Press the ANGLE button on the remote control to rotate the picture orientation by 90°.

NEXT or PREV in thumbnail screen and then press the ENTER

PLAY button to resume playback.

Thumbnail Review

Playing a MP3/Picture file disc

1. Press the OPEN/CLOSE button, the disc tray opens.

2. Insert a MP3 files/Picture CD on the disc tray with the label side up.

Press the OPEN/CLOSE button, the disc tray closes.

4. The unit will take a short while to load the disc.

5. Use

Note:

• The SETUP button does not work during MP3 or Picture Disc playback

, , or button to select MP3 or Picture CD, then press the

ENTER button.

or stop.

E - 26

Customizing the Function Settings

LANGUA GE setting

1. Press the FUNCTION button until DVD appears on the display.

2.Press the STOP button so that no disc is playing.

3.Press the SETUP button.

4.Use

5. Use or button to English, then press the ENTER button. The screen will change to English Wordings

6.To exit the FUNCTION SETUP MENU and return to the normal screen, press the RETURN button.

or button to select the Language, then press the ENTER button.

immediately.

VIDEO setting

TV Shape

1.Press the SETUP button.

2.Use

3.Use or button to select TV Shape, then press the ENTER button.

4.Use

5.To exit the FUNCTION SETUP MENU and retur n to the nor mal screen, press the RETURN button.

or button to select Video, then press the ENTER button.

or button to shift and select the TV type, then press the ENTER button.

E - 27

(continued on next page)(continued on next page)

(continued on next page)

(continued on next page)(continued on next page)

Customizing the Function Settings

Cut off when a wide-screen video image is played.

4:3 Pan Scan

• When wide-screen video material is played, this mode clips the right and left sides of the image so that it can be viewed on a conventional TV screen.

• Some wide-screen DVDs that do not permit Pan Scan mode playback are automatically played in letterbox mode (black bands top and bottom).

4:3 Letter Box

• When wide-screen video material is played in this mode on a conventional TV screen, black bands appear at the top and bottom of the screen.

16:9 Wide-screen

• This is the correct mode for playing wide-screen videos on a wide-screen TV.

• You must also set the screen mode on your wide-screen TV to "FULL".

The actual appearance of the image depends on the screen mode setting of your wide-screen TV.

Notes :

• The displayable picture siz e is preset on the D VD disc. Theref ore the playbac k picture of some DVD discs may not conform to the picture size you select.

• When you play DVD discs recorded in the 4:3 picture size only, the playback picture always appears in the 4:3 picture size regardless of the TV shape setting.

• If you select 16:9 wide-screen mode and you own a 4:3 TV set, the DVD playback picture will be horizontally distorted during playback. Images will appear to be horizontally compressed. Always be sure that your TV shape conforms to the actual TV in use.

Video Output

1.Press the SETUP button.

2.Use or button to select Video, then press the ENTER button.

3.Use

4.Use

5.To exit the FUNCTION SETUP MENU and retur n to the nor mal screen, press the RETURN button.

CVBS : Corresponding to your TV which has a video or S-video input. YUV : Corresponding to your TV which has a YUV input.

Attention :

Always set Video Output in CVBS, otherwise, the picture on the TV may be distorted. If this occurs, and you cannot see the screen, press the P. SCAN button twice until the "CVBS" display.

or button to select Video Output, then press the ENTER button. or button to shift and select the signal, then press the ENTER button.

E - 28

(continued on next page)(continued on next page)

(continued on next page)

(continued on next page)(continued on next page)

Customizing the Function Settings

Brightness

1.Press the SETUP button.

2.Use

3.Use

4.Use or button to shift and select the Off/On, then press the ENTER button.

5.If you want to exit the SETUP MENU and return to the normal screen, press the RETURN button.

On : Picture will be brighter to clarify details. Off : Picture will have deepened colors.

or button to select Video, then press the ENTER button. or button to select Brightness, and then press the ENTER button.

Note:

• Actual effect on pictures will vary depending on the TV.

Edges

1.Press the SETUP button.

2.Use

3.Use

4.Use or button to shift and select the Sharpen / Soften / Off, then press the ENTER button.

5.If you want to exit the SETUP MENU and return to the normal screen, press the RETURN button.

Sharpen : Fine detail will be easier to see. Soften : Soft-focus effect. Off : Picture will be returned to normal.

or button to select Video, then press the ENTER button. or button to select Edges, and then press the ENTER button.

E - 29

(continued on next page)(continued on next page)

(continued on next page)

(continued on next page)(continued on next page)

Customizing the Function Settings

AUDIO setting

Digital Out

1.Press the SETUP button.

2.Use

3.Use or button to select Digital Out, and then press the ENTER button repeatedly to select Digital Out type.

4.To exit the FUNCTION SETUP MENU and retur n to the nor mal screen, press the RETURN button.

Raw : Does not have a Dolby Digital Decode. PCM : Do have a Dolby Digital Decode.

or button to select Audio, press the ENTER button.

L/R Speaker

1.Press the SETUP button.

2.Use

3.Use

4.Use or button to select the desired setting, and then press the ENTER button.

5.To exit the FUNCTION SETUP MENU and retur n to the nor mal screen, press the RETURN button.

L/R Speaker Small : Small size of Speaker. Large : Large size of Speaker (speaker diameter normally larger than 4 inch or 10 cm)

Note :

• You can adjust the channel balance on your Unit. Please see "ADJUSTING THE SOUND".

or button to select the Audio, press the ENTER button. or button to L/R Speaker, and then press the ENTER button.

E - 30

(continued on next page)(continued on next page)

(continued on next page)

(continued on next page)(continued on next page)

Customizing the Function Settings

Subwoofer

1.Press the SETUP button.

2.Use

3.Use or button to Subwoofer, and then press the ENTER button.

4.Use

5.To exit the FUNCTION SETUP MENU and retur n to the nor mal screen, press the RETURN button.

Subwoofer "On" should be selected if your subwoofer is connected.

If "Off" is selected, no sound will be emitted by subwoofer.

or button to select the Audio, press the ENTER button.

or button to select the desired setting, and then press the ENTER button.

Note :

• You can adjust the channel balance on your Unit. Please see "ADJUSTING THE SOUND".

Surround Delay

1.Press the SETUP button.

2.Use

3.Use or button to Surround Delay, then repeatedly press the ENTER button to select the desired Surround

4.To exit the FUNCTION SETUP MENU and retur n to the nor mal screen, press the RETURN button.

Notes:

• The first number represents the Dolby Digital and the second number represents the Pro Logic.

• The delay adjustment depends on the location of your surround speakers and the front speakers. If the location

or button to select the Audio, press the ENTER button.

Delay type. 0/15ms, 5/20ms, 10/25ms or 15/30ms appears.

of the surround speakers is closer than the front speakers, the delay adjustment can compensate the distance difference.

E - 31

(continued on next page)(continued on next page)

(continued on next page)

(continued on next page)(continued on next page)

Customizing the Function Settings

Center Delay

1.Press the SETUP button.

2.Use

3.Use or button to Center delay, then repeatedly press the ENTER button to select the desired Center Delay

4.To exit the FUNCTION SETUP MENU and retur n to the nor mal screen, press the RETURN button.

Note:

• This delay adjustment depends on the location of your center speak er . If the distance between the center speaker

or button to select the Audio, press the ENTER button.

type. 0ms, 1ms, 2ms, 3ms, 4ms or 5ms appears.

and the listener is less than the distance between the front right and left speaker and the listener, this delay adjustment is balanced.

Pink noise

1.Press the SETUP button.

2.Use

3.Use

4.Use or button to select the desired setting, and then press the ENTER button.

5.To exit the FUNCTION SETUP MENU and retur n to the nor mal screen, press the RETURN button.

Pink noise Off : Pink noise test mode should always be switched off, unless you are testing your speakers. Left : Pink noise comes out from front left speaker for testing. Center : Pink noise comes out from center speaker for testing. Right : Pink noise comes out from front right speaker for testing. Left sur : Pink noise comes out from rear surround left speaker for testing. Right sur : Pink noise comes out from rear surround right speaker for testing. Subwoofer : Pink noise comes out from subwoofer for testing.

or button to select the Audio, press the ENTER button. or button to Pink noise, and then press the ENTER button.

Note :

• When using the pink noise generator to test your speakers, you can press the SOUND button on the remote control to adjust the channel balance. Please "Adjusting the Sound".

E - 32

(continued on next page)(continued on next page)

(continued on next page)

(continued on next page)(continued on next page)

Customizing the Function Settings

RA TING setting

Password/Parental lock

DVD discs equipped with the password function are rated according to their content. The contents allowed by a parental lock level and the way a DVD disc can be controlled may vary from disc to disc.

For example, if the disc allowed, you could edit out violent scenes unsuitable for children and replace them with more suitable scenes, or you could lock out playback of the disc altogether.

1.Press the SETUP button.

2.Use or button to select Rating, press the ENTER button.

3.Use or button to select Parental lock and then press the ENTER button repeatedly to set the parental lock level.

4.Use

or button to shift and select Password, enter your 4-digit security code and then press the ENTER

button.

You cannot play DVD discs rated higher than the level you selected unless you cancel the parental lock function.

The parental lock level is equivalent to the following ratings.

Level 1 : Kid Safe Level 5 : PG_R Level 2 : G Level 6 : R Level 3 : PG Level 7 : NC_17 Level 4 : PG_13 Level 8 : Adult

5.To exit the FUNCTION SETUP MENU and retur n to the nor mal screen, press the RETURN button.

Indicates Parental lock is NOT active.

The Parental lock is active.

If you forget the password, you can erase your current password by pressing number button 8 on the remote four times, then press the ENTER button to confirm the setting.

P ASSW ORD : 8 8 8 8

E - 33

(continued on next page)(continued on next page)

(continued on next page)

(continued on next page)(continued on next page)

Customizing the Function Settings

Factory Set

If you want to return the initial language setting to the factory default, do the following:

1.Press the SETUP button.

2.Use

3.Use

4.Use or button to shift and select Yes, then press the ENTER button.

5.To exit the FUNCTION SETUP MENU and retur n to the nor mal screen, press the RETURN button.

Note:

When you reset the Unit to the factory default, the Unit will take 3-5 seconds to reset.

or button to select the Rating, then press the ENTER button. or button to shift and select the Factory Set, then press the ENTER button.

E - 34

Radio Operation

T uning into a station manually

1. Press the FUNCTION button until the frequency band appears on the display.

2. Press the BAND button on the remote remote or STOP button on the front panel to select the desired band.

3.Press the

FM Stereo

• Press the FM MODE button on the remote until " [ ST ] " appears on the display.

Weak FM stations

• Press the FM MODE button on the remote until the " " word appears on the display. Background noise will be reduced but the signal reproduced will be mono. To restore stereo reception, press the FM MODE button on the remote to select STEREO.

Note:

• The left / right front speakers and subwoofer are activated only.

TUNING button to tune in the desired station.

T o sear c h for a station automaticall y

• Hold down the TUNING b uttons on the remote f or 1 to 2 seconds, and a station is searched for automatically. After tuning in a station, the search stops.

• The search may not stop at a station with a very weak signal.

Presetting stations

You can tune into a stored station directly by entering the preset number.

20 stations on FM band can be preset. 20 stations on AM(MW) band can be preset.

1.Press the FUNCTION button until the frequency band appears on the display.

2. Press the BAND button on the remote to select the desired band.

3.Use the

4.Press the MEMORY button on the remote.

5.Press the NEXT or PREV button to select the preset number and press the MEMORY button on the remote to store the station.

6.Repeat steps 2-5 to store other stations.

TUNING button to find your desired station.

T uning into a preset station

1.Press the FUNCTION button on the front panel until the frequency band appears on the display.

2. Press the BAND button on the remote to select the desired band.

• Press the PLAY button and NEXT or PREV button to select the presetted station or use the numbered buttons to enter the number to select the presetted station.

Example: To select preset number 15, press the +10 and 5 buttons.

To select preset number 10, press the +10 and 0 buttons.

E - 35

Language Code List for Disc Language

Code

AA AB AF AM AR AS AY AZ BA BE BG BH BI BN

BO BR CA CO CS CY DA DE DZ EL EN EO ES ET EU FA FI FJ FO FR

LanguageName

Afar Abkhazian Afrikaans Ameharic Arabic Assamese Aymara Azerbaijani Bashkir Byerlorussian Bulgarian Bihari Bislama Bengali Bangla Tibetan Breton Catalan Corsican Czech Welsh Danish German Bhutani Greek English Esperanto Spanish Estonian Basque Persian Finnish Fiji Faroese French

Code

FY GA GB GL GN GU HA HI HR HU HY IA IE IK IN IS IT IW JA JI JW KA KK KL KM KN KO KS KU KY LA LN LO LT LV

LanguageName

Frisian Irish Scots Gaelic Galician Guarani Gujarati Hausa Hindi Croatian Hungarian Armenian Interlingua Interlingue Inupiak Indonesian Icelandic Italian Hebrew Japanese Yiddish Javanese Georgian Kazakh Greenlandic Cambodian Kannada Korean Kashmiri Kurdish Kirghiz Latin Lingala Laothian Lithuanian Latvian, Lettish

Code

MG MI MK ML MN MO MR MS MT MY NA NE NL NO OC OM OR PA PL PS PT QU RM

RN RO RU RW SA SD SG SH

SI SK

LanguageName

Malagasy Maori Macedonian Malayalam Mongolian Moldavian Marathi Malay Maltese Burmese Nauru Nepali Dutch Norwegian Occitan (Afan) Oromo Oriya Panjabi Polish Pashto, Pushto Portuguese Quechua RhaetoRomance Kirundi Romanian Russian Kinyarwanda Sanskrit Sindhi Sangho SerboCroatian Singhalese Slovak

Code

SL SM SN SO SQ SR SS ST SU SV SW TA TE TG TH TI TK TL TN TO TR TS TT TW UK UR UZ VI VO WO XH YO ZH ZU

LanguageName

Slovenian Samoan Shona Somali Albanian Serbian Siswat Sesotho Sundanese Swedish Swahili Tamil Telugu Tajik Thai Tigrinya Turkmen Tagalog Setswana Tonga Turish Tsonga Tatar Twi Ukrainian Urdu Uzbek Vietnamese Volapük Wolof Xhosa Yoruba Chinese Zulu

Maintenance

456

Cleaning Disc

A defective or soiled disc inserted into the Unit can cause sound to drop out during playback. Handle the disc by holding its inner and outer edges.

• Do NOT touch the surface of the unlabeled side of the disc.

• Do NOT stick paper or tape on the surface.

• Do NOT expose the disc to direct sunlight or excessive heat.

• Clean the disc before playback. Wipe the disc from the centre outwards with a cleaning cloth.

• NEVER use solvents such as benzine or alcohol to clean the disc.

• Do NOT use irregular shape discs (example : heart shaped, octagonal, etc.). They may cause malfunctions.

Cleaning the Unit

• Be sure to turn the Unit off and disconnect the AC power cord before maintaining the Unit.

• Wipe the Unit with a dry soft cloth. If the surfaces are extremely dirty, wipe clean with a cloth which has been dipped in a weak soap-and-water solution

and wrung out thoroughly, then wipe with a dry cloth.

• Never use alcohol, benzine, thinner, cleaning fluid or other chemicals. And do NOT use compressed air to remove dust.

Important Note

Before transporting the Unit, remove disc from the CD tray.

Trouble Shooting Guide

SYMPTOM CAUSE (AND REMEDY)

No power.

No picture.

The picture is not clear.

• Check that the AC power cord is connected.

• The region number of the disc doesn't match the region number of this Unit.

1 2 3

• The TV is not set to receive DVD signal output.

• The video cable is not connected.

• The TV is not turned on.

• Clean the disc.

• If video from your system has to go through your VCR to get to your TV, the copy-protection applied to some DVD programs could affect picture quality. If you still experience problems after checking your connections, please try connecting your Unit directly to your TV through the S-Video-input, if your TV is equipped with this input.

• The disc is scratched.

• The DVD unit may be set to progressive scan, moreover, TV does not support Progressive Scan component video signal. Press the P. SCAN button repeatedly until the "CVBS" display.

Trouble Shooting Guide

SYMPTOM CAUSE (AND REMEDY)

• The location and orientation of the antenna are incorrect. If you use an indoor antenna, change to an outdoor antenna.

• The TV antenna wire is too close to the Unit. Separate the antenna wire of the TV set from the Unit.

No sound or only a very low-level sound is heard.

Severe hum or noise is heard.

The remote does not function.

• Check that the speakers and equipment are connected securely.

• Make sure that you've selected the corrected equipment on the system.

• The system is in pause mode or in Slow-motion Play mode. Press the PLAY button to return to normal play mode.

• Fast forward or fast reverse is performed. Press the PLAY button to return to normal play mode.

• Check the speaker settings.

• Make sure that AUDIO output and AV IN input connections correct.

• Adjust the speakers volume.

• The DTS DVD disc cannot be decoded to have speaker output.

• This Unit is too hot, shut off half 30 minutes for cool down.

• You can use the Pink Noise setting to test that the speaker output is present (Please see Customizing the Function Settings)

• Check that the speakers and equipment are connected securely.

• Check that the connecting cords are away from a transformer or motor, and at least 10 feet (3 meters) away from a TV set or fluorescent light.

• Move your TV away from the audio equipment.

• The plugs and jacks are dirty. Wipe them with a cloth slightly moistened with alcohol.

• Clean the disc.

• Vibrations from the speakers are affecting the Unit.

• Remove any obstacles between the remote and the Unit.

• Use the remote near the Unit.

• Point the remote at the remote sensor on the Unit.

• Replace all the batteries in the remote with new ones.

The disc does not play.

The DVD door cannot open.

• There is no disc inside ("No Disc" appears on the TV screen).

• Insert the disc correctly with the playback side facing down on the disc tray.

• Clean the disc.

• A non-NTSC or PAL disc has been inserted. The Unit and disc region number are incompatible. Press the ZOOM/TV MODE button on the remote to output the video signal.

• Condensation may have formed inside the Unit due to a sudden change in temperature. Wait about an hour for it to clear and try again.

• Reset the Unit, press the STANDBY/ON button to turn off the Unit, wait for a few

seconds, then restart the Unit.

Venturer STS91 User Manual
