Venturer CMP6937 Operating Instructions Manual
MICRO MP3 / CD MUSIC SYSTEM
with SUBWOOFER
OPERATING INSTRUCTIONS
Printed in China 811-693791-011
TO PLAY MP3 (for remote only)
This set can read MP3.
1. Press the FUNCTION button to CD.
2. To open CD door. Place a MP3 disc in the center with the label face front. The
total albums and the total tracks appear on the display.
3. Press the PLAY/PAUSE
button to start play.
4. Press the STOP button to stop playback.
5. In stop mode, press PLAY/PAUSE
button to start playback.
TO SEARCH AN ALBUM
Basically this system supports the album search mode to search an album at highspeed.
1. Press the PRESET + / ALBUM + or PRESET – / ALBUM – button to search a desired
album in play /stop mode.
2. After selected a desired album, the first track of this album will be shown on the
display within two seconds.
3. Press the SKIP/SEARCH / button to search a desired track and then press
the PLAY/PAUSE
button to play the track.
4. During searching the album, the album number is shown on the display.
USING THE REMOTE CONTROL CORRECTLY
• Point the Remote Control at the REMOTE SENSOR located on the unit.
• When there is a strong ambient light source, the performance of the infrared
REMOTE SENSOR may be degraded, causing unreliable operation.
• The recommended effective distance for remote operation is about 6 meters (19
feet).
SEARCH A FILE (SONGS) BY FILE NAME
1. Press the MP3 MODE button once the " " will blink, the file name and the
number's tracks appear on the display.
2. Press the SKIP/SEARCH / buttons one by one to find the file name, the
file name will display sequence as "A,B ........... Z, 0 .......... 9".
3. Press the SKIP/SEARCH / buttons about 2 seconds, the capital letters or
the figure will blinks. If the first letter of the file name in this disc haven't the
capital letters or the figure, it will not blink.
4. Press the SKIP/SEARCH / buttons one by one to search file.
5. Press the PLAY/PAUSE
button to play select file.
SEARCH A FILE (SONGS) BY ALBUM
1. Press the MP3 MODE button twice times, the " " will light and ALBUM appear
on the display.
2. Press the SKIP/SEARCH / buttons one by one, to select album.
3. Press the SKIP/SEARCH / buttons about 2 seconds until "ALBUM" disappear.
4. Press the SKIP/SEARCH
/ buttons one by one to search file.
5. Press the PLAY/PAUSE
button to play select file.
1. FM MONO / STEREO / MP3 MODE /
CD ESP ON/OFF button
2. STANDBY/ ON button
3. FUNCTION (CD/AUX/TUNER) button
4. PRESET+ / ALBUM+ button
5.
STOP / BAND button
6.
TUNING / SKIP / SEARCH button
7. MEMORY
button
8. PRESET– / ALBUM– button
9. SLEEP button
10. REPEAT button
11.
PLAY / PAUSE button
12.
TUNING / SKIP / SEARCH button
13. X-BASS button
14. RANDOM button
15. TIMER button
16. VOLUME +\– controls
TO REPEAT THE WHOLE DISC
Press the REPEAT button a second
time to repeat all tracks, the repeat
all indicator will light.
REPEAT PLAY (for remote only)
This function will allow a single tracks or all the tracks on the disc to be played
repeatedly.
TO REPEAT THE SAME TRACK
Press the REPEAT button once during
playback, the repeat one indicator
will light.
TO CANCEL REPEAT PLAY
Press the REPEAT button until "REPEAT" indicator is switched off.
RANDOM PLAY (for remote only)
All the tracks on the disc can be played in random order.
Press the RANDOM button.
RANDOM appears in the display and the disc will play automatically.
TO CANCEL RANDOM PLAY
Press the STOP
or RANDOM button so that "RANDOM" in the display goes
out.
TO REPEAT PLAY THE ALBUM (in MP3 Mode) (for remote only)
Press the REPEAT button three times to repeat the album, the repeat album
indicator will light.
TO CANCEL REPEAT PLAY
Press the REPEAT button until "REPEAT & ALBUM" indicator is switched off.
This product contains a low power laser device.
WARNING: TO REDUCE THE RISK
OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO
USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
The lightning flash and
arrowhead within the
triangle is a warning
sign alerting you of
"dangerous voltage"
inside the product.
The exclamation point
within the triangle is a
warning sign alerting
you of important instructions accompanying the product.
CAUTION
INVISIBLE LASER RADIATION WHEN
OPEN AND INTERLOCKS DEFEATED.
AVOID EXPOSURE TO BEAM
CLASS 1 LASER
PRODUCT
APPAREIL Á LASER
DE CLASSE 1
CAUTION : Use of any controls, adjustments, or procedures other than those speci-
fied herein may result in hazardous radiation exposure.
WARNING : TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR MOISTURE.
CLASS 1 LASER PRODUCT
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Should any trouble occur, disconnect the AC power cord and refer
servicing to qualified personnel.
SAFETY PRECAUTIONS
Follow the advice below for safe and appropriate operations
ON PLACEMENT
• Do not use the unit in places which are extremely hot, cold, dusty or
humid.
• Place the unit on a flat and even surface.
• Do not restrict the air flow of the unit by placing it in a place with poor air
flow, by covering it with a cloth, or by placing it on a carpet.
ON SAFETY
• When connecting and disconnecting the AC cord, grip the plug and not the
cord itself. Pulling the cord may damage it and create hazard.
• When you are not going to use the unit for a long period of time, disconnect
the AC power cord.
ON AC VOLTAGE
• Before use, check that the rated voltage of your unit matches your local
voltage.
FCC INFORMATION
This device complies with part 15 of FCC Rules. Operations are subject to the
following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference
that may cause undesirable operations.
ON CONDENSATION
• When left in a heated room where it is warm and damp, water droplets or
condensation may form inside the CD player.
• When there is condensation inside the unit, it may not function normally.
• Let it stand for 1 to 2 hours before turning the power on, or gradually heat
the room up and dry the unit before use.
VENTILATION WARNING
• The normal ventilation of the product shall not be impeded for intended
use.
RATING PLATE LOCATION
The rating plate location is on the bottom of product.
GENERAL
Power consum
ption:
25W
Power source: AC ~120V 60 H
z (USA and Canada)
AC ~220V 50 Hz (China)
AC ~230V 50 Hz (Europe)
AC ~240V 50 Hz (Australia)
AC ~110-120V/220-240V 50/60Hz (Others)
SPECIFICATION
Specifications may be subject to change without notice.
TROUBLE SHOOTING TIPS
RADIO
Disc skips
System does not turn on
Problem
Solutions
Disc in place but unit
won't play
CD/MP3
• Make sure AC power plug is secure in the
outlet, and outlet has power.
• Make sure FUNCTION switch is set to CD.
• Make sure disc label is facing up.
• Make sure disc is clean.
• Pause mode is activated.
• Disc may be damaged or dirty; check disc.
• Make sure the unit is on a secure spot.
Vibration or jarring can cause the disc to
skip.
Poor FM reception
Poor MW reception
• Make sure FM antenna wire is unwound.
• Electrical interference in your home can
cause poor reception. Move the unit away
from sources of interference (especially those
with motors and transformers).
• Set the AM/MW loop antenna to a direction
for the better reception.
1
2
3
4
5
6
7
10
11
12
13
14
15
16
8
9
TO CHANGE REMOTE BATTERY
1. Open the battery
door.
2. Insert one CR2025 (3V)
size battery.
BATTERY REPLACEMENT
When battery become weak, the operating distance of the Remote Control is
greatly reduced and you will need to replace the battery.
NOTE:
If the Remote Control is not to be used for a long time, remove the battery to avoid
damage caused by battery leakage corrosion.
WARNING:
Do not dispose of batteries in fire, batteries may explode or leak.
ATTENTION
Take out the PVC sheet
before operating
the Remote
Control.
REMOTE CONTROL
CARE & MAINTENANCE
CLEANING CD
If the CD skips or will not play, the disc may
need cleaning. Before playing, wipe the disc
from the centre out with a cleaning cloth. After
playing, store the disc in its case.
CLEANING THE UNIT
Do not use volatile chemicals on this unit. Clean by lightly wiping with
a soft cloth.
IMPORTANT NOTICE:
• Should the CD door be opened before the reading of the CD is
completed, a jamming noise may occur. This can be resolved by
closing the CD door and then setting the FUNCTION switch
temporarily to AUX.
• If an abnormal display indication or an operating problem occurs,
disconnect the AC power cord. Wait at least 5 seconds, then reconnect
the AC power cord.
• Before transporting the unit, remove the disc from the CD tray.
PROGRAMMING TRACKS - in the MP3 stop mode (Up to a maximum of 64
tracks)
1. Press the MEM button, the ALBUM blinks on the display.
2. Press the SKIP/SEARCH / buttons to select the desired albums.
3. Press the MEM
button, the FILE (SONGS) blinks on the display.
4. Press the SKIP/SEARCH / buttons to select the desired files (songs).
5. Press the MEM
button again.
6. Repeat alone step 2 and 5 procedure to program additional tracks. Press PLAY/
PAUSE
button to start playback of the programmed tracks and memory
indicator will appear on display.
To check the program
While in the stop mode, press the MEM
button. The album , file (songs) and
program numbers will appear on the display.
Press the MEM button again to view the other programmed selections.
These displays do not appear during programmed play.
To play the programmed tracks
Press the PLAY/PAUSE
button.
To stop programmed play
Press the STOP button, if you want to recover programmed play. You can first
press MEM button and then press PLAY button again.
To clear the memory content
Press the STOP
button and then open the CD door or press MEM button and
then press the STOP button in stop mode.
AM/MW
Connect the loop aerial (provided) to
the "AM (MW) ANT." snap terminal.
Set the MW/AM loop antenna to a
direction for the better reception.
TO SEARCH FOR A STATION
AUTOMATICALLY
Press the TUNING / SKIP / button
for 1 to 2 seconds, and a station is
searched for automatically. After tuning
in a station, the search stops.
The search may not stop at a station with
a very weak signal.
1.Press the FUNCTION button to
TUNER.
FOR BETTER RECEPTION
FM
2.Press the
STOP/BAND button to
select the desired band.
3.Press the TUNING / SKIP /
buttons to select a station.
TO RECEIVE THE FM BROADCAST
IN STEREO
When receiving FM broadcasts in stereo,
The word " (
(
STEREO)) " illuminate.
1.Set to the desired band and
station.
PRESETTING STATION (for remote only)
Your favourite Radio Stations can be tuned in to by selecting their preset numbers.
It is possible to store up to 10 preset stations for FM band and 10 preset stations for
AM/MW band in the order of your choice.
TUNING INTO A PRESET STATION
Manual memory presetting
This feature allows you to manually preset stations to any desired channel.
2.Press the MEM button until the
MEMORY indicator is shown and
" 01 " will blink on the display.
3.Press the PRESET+/ALBUM+ button
to select a channel number for the
preset station on the remote control.
4.Press the MEM
button to memorize
the station.
5.Repeat steps 1 to 4 for the next
preset.
Press the PRESET+/ALBUM+ or PRESET–/ALBUM– button to select a preset
number.
NOTE:
If a button is not pressed within 10 seconds the preset mode will be cancelled
automatically.
TUNING INTO A STATION MANUALLY
1. PHONES jack
2.
STANDBY indicator
3. Remote sensor
4. PLAY / PAUSE button
5. VOLUME UP
button
6. SKIP
/ TUNING DOWN
button
7. VOLUME DOWN
button
8. SKIP
/ TUNING UP
button
9. LCD display
10.
STANDBY / ON button
11. STOP
/ BAND button
12. SLEEP / TIMER button
13. MEMORY
button
14. FUNCTION (CD/AUX/
TUNER) button
15. CD door
16. AC cord
17. Speaker terminal
18. Subwoofer terminal
19. AM (MW) loop terminal
20. AUX IN jack
21. FM antenna wire
Note : 16 to 21 are under the
rear cabinet cover.
Fully unwind the wire antenna. Then
extend the wire antenna and place it
in the position that sounds best.
NOTE:DO NOT CONNECT TO AN
OUTSIDE ANTENNA.
CONNECTIONS
1. SPEAKER CONNECTION
Remove the rear cover and connect the right speaker to
the R terminals, and the left speaker to the L terminals.
Connect the wires with the red lines (or printed white
lines) to the red (+) terminals and the plain-black wires
to the black (–) terminals.
NOTE : Connecting speakers other than the speakers
supplied with the unit may damage the unit.
2. SUBWOOFER CONNECTION
Remove the rear cover and connect speaker wires from
the Subwoofer to the output of subwoofer.
NOTE : Ensure in each case that the red wire (or printed
white lines) is connected to red (+) terminal of the speaker output and the
black wire is connected to the black (–) terminal of the speaker output. Also
ensure that the connect orientation for left and right main speaker is observed.
3. CONNECTION WITH OTHER OPTIONAL EQUIPMENT
To listen to or record audio signals from external units through this unit.
Connect the signal cord between the unit's AUX jack and the output jack of
the external equipment.
LISTENING TO THE CONNECTED EQUIPMENT
• Press the FUNCTION button to AUX. • Play the external source.
4. MW/AM LOOP ANTENNA CONNECTION
Do not connect to an outside antenna. Connect the supplied MW/AM loop
antenna to receive better MW/AM broadcast signal.
5. FM ANTENNA WIRE
Do not connect to an outside antenna.
6. POWER CORD CONNECTION
Before use, check that the rated voltage of your unit matches your local
voltage. Make sure speakers are connected correctly before plugging the AC
power cord into an AC outlet.
Caution: • Be sure the AC power cord is disconnected and all functions are
off before making connections.
• To prevent electrical shock, match wide blade of plug to wide slot,
fully insert. (For N. America)
PROGRAMMING TRACKS - in the CD stop mode (Up to a maximum of 64
tracks)
2.Open the CD door. Hold the disc by
its sides and carefully make it fit
onto the central support of
compartment with the label side
facing towards you until you hear a
“click”. The total number and times
of tracks will show on the display.
TO INTERRUPT PLAYBACK
Press the PLAY/PAUSE
button.
The track time will blink.
To resume playback, press the PLAY/
PAUSE
button again.
TO STOP PLAYBACK
Press the STOP
button.
1.Press the FUNCTION button to CD.
3.To start playing, press the PLAY/
PAUSE
button.
To move backward at high speed
Keep the SKIP
button pressed
during play and release at the desired
point.
To move forward at high speed
Keep the SKIP
button pressed
during play and release at the desired
point.
Locating a particular point in a track
Keep it pressed
To find a previous track
Press the SKIP
button once to
return to the beginning of the current
track.
Press the SKIP
button repeatedly
to skip tracks backward one by one.
To skip tracks
Press the SKIP
button repeatedly
to skip track(s) forward one by one.
Searching for the beginning of a track
Press it once
NOTE :
The CD player may skip if the loud speakers are situated close to the player and if
high volume or x-bass levels are used.
LISTENING TO THE RADIO
CLOCK SETTING
TIMER OPERATION
1.In standby mode, press and hold
the MEMORY
button for about
3 seconds until time format blinks
on display.
3.Press the MEMORY
button, the
Hour blinks.
4.Press the TUNING / SKIP
/
buttons to set correct hour.
2.Press the TUNING / SKIP
/
buttons to set 12 Hour or 24 Hour
time format.
5.Press the MEMORY button, the
Minute blinks.
6.Press the TUNING / SKIP
/
buttons to set correct minute, and then
press the MEMORY
button to start
the clock.
1.Press the MEM
button.
2.Press the SKIP
/ buttons to
select the desired tracks.
3.Press the MEM button again.
4.Repeat alone step 2 and 3 procedure
to program additional tracks. Press
PLAY/PAUSE
button to start
playback of the programmed tracks
and memory indicator will appear
on display.
To check the program
While in the stop mode, press the MEM
button. The disc, track and program
numbers will appear on the display.
Press the MEM
button again to view
the other programmed selections.
These displays do not appear during pro-
grammed play.
To play the programmed tracks
Press the PLAY/PAUSE button.
To stop programmed play
Press the STOP button, if you want
to recover programmed play. You can
first press MEM
button and then
press PLAY
button again.
To clear the memory content
Press the STOP button and then open
the CD door or press MEM
button
and then press the STOP button in
stop mode.
1. Press and hold SLEEP/TIMER button
for about 3 seconds until the "
" and
"on" indicators will on the display
and the hour will blinks on the display.
2. Press the TUNING / SKIP
/
buttons to set hour.
3. Press the SLEEP/TIMER button, the
minute will blink.
4. Press the TUNING / SKIP
/
buttons to set minutes. Press the
SLEEP/TIMER button, the "off"
indicator will on the display and the
hour will blink on the display.
5. Press the TUNING / SKIP
/
buttons to set hour.
6. Press the SLEEP/TIMER button, the
minute will blink.
7. Press the TUNING / SKIP /
buttons to set minutes.
8. Press the SLEEP/TIMER button, the
"TUNER" will blink on the display.
9. Press the TUNING / SKIP
/
buttons to set CD or TUNER.
10.Press the SLEEP/TIMER button, the
"VOL" will blink on the display.
11.Press the TUNING / SKIP
/
buttons to set volume.
12.Press the SLEEP/TIMER button to
"confirm" and turn on time, turn off
time, CD or TUNER, VOL will
sequence automatically on display.
Finally the "
" indicator and clock
time will on the display.
SLEEP SETTING
When the sleep timer is used, the power is automatically turned off after the specified
time passes.
NOTE :
Press SLEEP/TIMER button to set the sleep timer after 5 seconds. The sleep setting
is automatically turned on.
1.Press the SLEEP/TIMER button while
the power is on. "SLEEP 90" lights in
the display.
Note:SLEEP can be adjusted in
TUNER, CD and AUX modes.
2.Press the SLEEP/TIMER button one by
one to select the length of remaining
time until the unit turns off.
It changes the indicator in the
following way:
The sleep timer is set and the word
"SLEEP" is shown on the display.
To cancel the sleep timer, press the
SLEEP/TIMER button until "SLEEP" go
out in the display.
PARTS IDENTIFIC ATION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
17
18
19
20
21
16
TO ADJUST THE VOLUME
Press the VOLUME UP / DOWN button to obtain the
desired volume level.
FOR PRIVATE LISTENING
Connect headphones (Ø3.5 mm stereo mini-plug) to the
PHONES
jack. When headphones are connected,
speakers automatically disconnected.
TO SELECT X-BASS (FOR REMOTE ONLY)
X-BASS is designed specifically to boost the low frequency
sound to obtain a more powerful bass.
ADJUSTING THE SOUND
TURNING ON THE UNIT
TO TURN ON THE UNIT
Press the STANDBY/ON button, the indicator will turn off. Select the desired
function and the corresponding function indicator will light up.
TO TURN OFF THE UNIT
Press the STANDBY/ON button to STANDBY, the indicator will light up and
only clock display will light up.
CD PLAYBACK
TIMER PLAY AND TURN OFF THE UNIT AUTOMATICALLY
The power can be turn on or turn off automatically at a preset time. So that you can
listen CD and RADIO function only.
Make sure the clock is correct before TIMER OPERATION. Make sure the time which
use to turn on or turn off is correct, please refer to CLOCK setting procedure.
NOTE : 1. To check the TIMER, press the TIMER button twice (for remote only).
2. To cancel the TIMER function, press the TIMER button once (for remote
only) and "
" will go out in the display.
x
x
x
x
x
x
x
x
xxx
xxxxx
L
R
RIGHT
SPEAKER
BOX
SUBWOOFER
SPEAKER
BOX
LEFT
SPEAKER
BOX
To AC outlet
For external source
2
3
6
5
1
4
Loading...
