Venturer ASR150 User Manual

SURROUND SOUND HOME THEATER SYSTEM

Instruction Manual

Model ASR150

Please read the instruction manual carefully before using your unit.

For support visit : www.1800customersupport.com

GENERAL

TABLE OF CONTENTS



PRECAUTIONS ............................................

2

IMPORTANT SAFETY INSTRUCTIONS .......

3

FUNCTION CONTROL ...............................

4

Front Panel ...................................................

4

Back Panel ....................................................

4

Remote Control ............................................

5

Using the remote control correctly ...............

5

To change remote battery .............................

5

Battery replacement .....................................

5

CONNECTIONS ..........................................

6

Power connection ........................................

6

Connecting the speakers & subwoofer .........

6

Mounting the rear surround speakers ...........

6

Positioning the speakers & subwoofer .........

7

Connection with TV .....................................

8

Connection with TV Game ..........................

8

Connection with DVD player ........................

8

Connection with VCR ..................................

8

Connection with other equipment ...............

8

Set up diagram .............................................

9

SOUND ADJUSTMENT .............................

10

To adjust the master volume ......................

10

To adjust the volume of individual speaker ....



....................................................................

10

To change the preset equalizer ...................

10

To change the speaker channel ..................

10

TROUBLE SHOOTING GUIDE ..................

11

OPERATING VOLTAGE ..............................

11

INTRODUCTION

Thank you for purchasing this Surround Sound HomeTheaterSystem.Pleasereadthisinstruction manual for best results.

SUPPLIED ACCESSORIES

Remote control with battery ........................

x1

Satellite speaker ............................................

x5

Audio cable .................................................

x1

Instruction manual ......................................

x1

1

PRECAUTIONS



CAUTION

The lightning flash with an arrowhead symbol,

the user to the presence of uninsulated "danger-



within the equilateral triangle, is intended to alert

RISK OF ELECTRIC SHOCK

ous voltage" within the product's enclosure that

DO NOT OPEN

may be of sufficient magnitude to cause an elec-



tric shock.

WARNING: TO REDUCE THE RISK OF ELECTRIC

The exclamation point within the equilateral tri-

SHOCK, DO NOT REMOVE COVER (OR BACK).

angle is intended to alert the user to the pres-

NO USER-SERVICEABLE PARTS INSIDE. REFER

ence of important operating and maintenance

(servicing) instructions in this owner manual.

SERVICING TO QUALIFIED SERVICE PERSONNEL.



WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT. (FOR USA AND CANADA ONLY)

The symbol for Class II (Double lnsulation)

FCC Information

This device complies with Part 15 of FCC Rules.

Operation is subject to the following two conditions:

(1)This device may not cause harmful interference, and

(2)This device must accept any interference received, including interference that may cause undesirable operation.

Notes on Placement

Do not use the unit in places which are extremely hot, cold, dusty, or humid.

Place the unit on a flat and even surface.

In a cabinet, allow about 2.5cm (1 inch) of free space around the unit for adequate ventilation.

Do not restrict the air flow of the unit by placing it in a place with poor air flow, by covering it with a cloth, or by placing it on carpet.

Notes on Safety

When connecting or disconnecting the AC cord, grip the plug and not the cord itself. Pulling the cord may damage it and create a hazard.

Unplug the unit during lightning storms or when unused for a long period of time.

Check that the rated voltage of your unit matches your local voltage before use.

No naked flame sources, such as lighted candles, should be placed on the apparatus.

Be sure to use it near the wall outlet. If a malfunction occurs, disconnect the plug from the wall outlet at once.

When the AC power supply cord is connected, the power indicator on the AC Adaptor will remain on although the unit is turned off. Disconnect the AC power supply cord from the AC outlet when not in use.

Note on Condensation

When left in a heated room where is warm and damp, water droplets or condensation may form inside the unit. When there is condensation inside, the unit may not function normally. Let the unit stand for 1 to 2 hours before turning the power on, or gradually heat the room up and dry the unit before use.

Notes on Maintenance

Do not use volatile chemicals on this unit. Clean by lightly wiping with a soft cloth.

Do not place a heavy object on or step on the unit. The object may fall, causing serious personal injury and serious damage to the unit.

Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the unit.

WARNING:

Should any trouble occur, disconnect the AC power cord and refer servicing to a qualified technician.

Do not place anything directly on top of the unit, it may cause damage.

2

IMPORTANT SAFETY INSTRUCTIONS

1.Read Instructions - All the safety and operating instructions should be read before the appliance is operated.

2.Retain Instructions - The safety and operating instructions should be retained for future reference.

3.Heed Warnings - All warnings on the appliance and in the operating instructions should be adhered to.

4.Follow Instructions - All operating and use instructions should be followed.

5.Water and Moisture - The appliance should not be used near water - for example, near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool, and the like.

6.Carts and Stands - The appliance should be used only with a cart or stand that is recommended by the manufacturer.

6A. An appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the appliance and cart combination to overturn.

7.Wall or Ceiling Mounting - The appliance should be mounted to a wall or ceiling only as recommended by the manufacturer.

8. Ventilation - The appliance should be situated so that its location or position does not interfere with its proper ventilation. For example, the appliance should not be situated on a bed, sofa, rug, or similar surface that may block the ventilation openings; or, placed in a built-in

installation, such as a book case or cabinet, that may impede the flow of air through the ventilation openings.

9.Heat - The appliance should be situated away from heat sources such as radiators, heat registers, stoves, or other appliances (including amplifiers) that produce heat.

10.Power Sources - The appliance should be connected to a power supply only of the type described in the operating instructions or as marked on the appliance.

11.Grounding or Polarization - Precautions should be taken so that the grounding or polarization means of an appliance are not defeated.

12.Power-Cord Protection - Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the appliance.

13.Cleaning - The appliance should be cleaned only as recommended by the manufacturer.

14.Power Lines - An outdoor antenna should be located away from power lines.

15. Outdoor Antenna Grounding - If an outside antenna is connected to the receiver, be sure the antenna system is grounded so as to provide some protection against voltage surges and built up static charges. Section 810 of the National Electrical Code, ANSI/NFPA No. 70, provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode. See Figure 1.

16. Non-use Periods - The power cord of the appliance should be unplugged from the outlet when left unused for a long period of time.

17.Object and Liquid Entry - Care should be taken so that

objects do not fall, and liquids are not spilled, into the enclosure through openings.

18.Damage Requiring Service - The appliance should be serviced by qualified service personnel when:

A.The power-supply cord or the plug has been damaged; or

B.Objects have fallen, or liquid has been spilled, into the appliance; or

C.The appliance has been exposed to rain; or

D.The appliance does not appear to operate normally or exhibits a marked change in performance; or

E.The appliance has been dropped, or the enclosure damaged.

19.Servicing - The user should not attempt to service the appliance beyond that described in the operating instructions. All other servicing should be referred to qualified service personnel.

3
