Refer to the illustrations on page 2 of this manual.
Front panel
1 input volume control: turn clockwise to increase the volume of the corresponding source.
2 CHIME switch: press to turn on the chime. The chime function can only be activated if a switch is
connected between the Priority terminals [15]. The audio signals from AUX IN are then muted.
3 SIREN switch: press to turn on siren
4 ECHO control: adjust the output signal echo
5 AUX/CD volume control: turn clockwise to increase the volume of the corresponding source.
6 MASTER control: control main power
7 POWER switch: turn the device on or off.
8 PL LED: turns on when power is switched on [7]
9 Signal LED: gain setting – turn up the channel gain [1] of the corresponding channel until the
signal LED starts flashing.
10 PEAK LED: turns on when a clipping condition occurs.
11 AM/FM + MEDIA PLAYER (only on model PAA02)
See table below for description.
Rear panel
12 AC SELECT: select the applicable input voltage (115V/230V).
13 AC IN: Power cord connection with fuse. Only replace the fuse with a fuse of the same rating.
14 DC 12V/3A: battery terminals. Connect an external 12Vdc battery (not incl.) to keep the amplifier
working during a power outage.
15 PRIORITY: connect a switch (not incl.) between these terminals; when pushing this switch, audio
signals from AUX IN are muted.
16 Speaker binding post terminals. As with all speaker wiring, care must be taken to ensure no wires
can present short-circuit to the amplifier. Speaker wires carry h ig h voltages. Therefore, care should
be taken to ensure no bare wires can be touched as this may result in an electric shock.
Refer to illustrations A through I on pages 3 and 4 for possible speaker connection sche mes.
17 FM antenna (PAA02 only): connect an FM antenna for FM signal reception
18 AM antenna (PAA02 only): connect an AM antenna fro AM signal reception
19 INPUT JACK (AUX/MIC 2/MIC 1): use these jacks for unbalanced input signals
20 AUX input: connect a device with a high-level output signal, e.g. AM/FM tuner, CD player... to the
“left” (white) and “right” (red) RCA input connectors. Control the volume with the AUX/CD volume
control [5]. Refer to illustration J on page 4.
21 CD/AUX switch: for low input signals, set to AUX, for high signals e.g. from CD p layer, set to CD.
a AM/FM select AM / FM
b MP3 select MP3
c MEMORY press memory followed by a preset key (M1 – M5); the LCD indicates the
d USB/SD (M1) select USB or SD card input
e REP (M2) select repeat mode: repeat one, repeat all, random
EQ (M3) select equalizer mode: classic, pop, rock, jazz, flat
g USB CONNECTOR connect USB device (not incl.)
h LCD display working status and information
i SD/MMC CARD SLOT insert SD/MMC card (not incl.)
k VOL- decrease volume
l
m
n VOL+ increase volume
o
(M4)
/ (M5)
frequency
radio mode: move backwards on the frequency band
other modes: return to the start of the program
press to play/pause
radio mode: move forward on the frequency band
other modes: skip to the end of the program
switch power on or off or stop playback
6. Troubleshooting
• The amplifier stops working.
Turn the volume knobs of both channels to zero, switch off the amplifier and disconnect from the
mains. Check the front panel, the fuse and all input and output connections. Replace the fuse with a
fuse of the same type and ratings.
• No sound when power LED is switched off.
The power supply is not connected or the amplifier has a blown fuse. Check the power connections
and switches, or replace the fuse located below the power input.
• No sound when power LED is switched on.
No or low input, or faulty speakers. Check if the input is connected and if the LED shows the
presence of a signal. Gently increase the volume level and check the speakers and speaker
connections.
• Hum or buzz.
Power supply noise is picked up in the signal path or earth problem. Only use good quality, shielded
signal cables and ensure they are kept away from the power cables and other AC-powered
equipment. Use a mains tester to ensure the mains outlet has a good earth.
• Distorted sound.
There is an excessive signal level or damaged signal cables. Check the LED to ensure the input level
to the amp is at the correct level. Only use good quality, shielded signal cab les and protect them
from damage.
• Sound cuts out.
The signal cables are damaged or the connectors are not properly inserted. Check all cables and
connections.
7. Maintenance
• Regularly wipe the amplifier with a moist, lint-free cloth. Do not use alcohol or solvents.
• Ensure that liquids are not spilled into the enclosure through the v entilation openings.
• Contact your HQPower™ dealer if your amplifier needs servicing.
distortion <1%
outputs 4ohm, 8 ohm, 70V or 100V
DC power 12V / 3A
AC power 230V / 115V (selector)
dimensions 240 x 190 x 75mm
weight 3.30kg (PAA01), 3.50kg (PAA02)
Use this device with original accessories only. Velleman nv cannot be held responsible in the
event of damage or injury resulted from (incorrect) use of this device.
For more info concerning this product and the latest version of this manual, please visit our
website www.hqpower.eu.
The information in this manual is subject to change without prior notice.
No part of this manual or may be copied, reproduced, translated or reduced to any electronic medium or
otherwise without the prior written consent of the copyright holder.
