VDO TPMS Go User Manual

VDO TPMS Go
User manual
24/2018 – EN
REVISION OF THE VDO TPMS GO MANUAL
Due to continuing improvements, the information contained in this user manual, the features and design of this device are subject to be changed without prior notice.
Edition/
Revision
First edition
Date
(week/year)
24/2018 Firmware version HV1-13-11
Chapters updated
UM-UV1-13-11 Table of contents
TABLE OF CONTENTS
User guide 2
VDO TPMS GO TOOL .................................................................................................... 2
1. SPECIFICATIONS .......................................................................................................................... 2
2. IMPORTANT SAFETY INSTRUCTIONS ......................................................................................... 3
3. CAUTION ....................................................................................................................................... 4
4. FUNCTION KEYS ........................................................................................................................... 5
5. POWER ON .................................................................................................................................... 6
6. OPERATING INSTRUCTIONS........................................................................................................ 7
VDO TPMS GO USE ....................................................................................................... 8
1. CHECK SENSOR ........................................................................................................................... 8
2. PROGRAM BLANK SENSOR ...................................................................................................... 11
3. PART LOOKUP ............................................................................................................................ 17
SETTINGS ..................................................................................................................... 19
1. SETTINGS MENU ......................................................................................................................... 19
ABOUT .......................................................................................................................... 23
1. THE ABOUT MENU ...................................................................................................................... 23
LANGUAGE .................................................................................................................. 24
1. LANGUAGE MENU ...................................................................................................................... 24
RECENT SENSOR DATA ............................................................................................. 25
1. RECENT SENSOR DATA ............................................................................................................. 25
MISCELLANEOUS........................................................................................................ 26
1. CHARGE ...................................................................................................................................... 26
2. TROUBLESHOOTING .................................................................................................................. 27
3. TOOL UPDATE ............................................................................................................................ 27
4. LIMITED HARDWARE WARRANTY ............................................................................................ 29
5. SAFETY BATTERY AND CHARGE INFORMATION .................................................................... 29
6. CE STATEMENTS ........................................................................................................................ 31
7. FCC STATEMENTS...................................................................................................................... 31
8. RCM STATEMENTS ..................................................................................................................... 31
9. RECYCLING ................................................................................................................................. 31
Index 32
Page 1/32
UM-HV1-13-11 VDO TPMS GO user guide
User guide
VDO TPMS GO TOOL
1. SPECIFICATIONS
Battery Type: Rechargeable Li-Po (Lithium-Polymer). Battery Life: Approximately 400 activations per full charge. Dimensions (Max. L,W,D): 16.5 cm x 9.5 cm x 3.8 cm (6.5" x 3.7" x 1.5") Housing Material: High Impact ABS. Response Frequency:
Low Battery Indication: LCD bar graph display. Weight: 0,35 Kg (0,7 lbs.) Temperature: Operating: -4° F to 131° F (-20° C to +55° C).
Operating Altitude: Up to 2 000 m (6 560 ft). Device accessories: USB cable
Main frequencies: 315 MHz and 433.92 MHz. (supporting most specific frequencies).
Storage: -40°F to 140° F (-40° C to +60° C).
Power supply USB stick with WebTPM PC software, driver program
and user manual
Page 2/32
UM-HV1-13-11 VDO TPMS GO user guide
2. IMPORTANT SAFETY INSTRUCTIONS Do not discard. Retain for future reference.
This device complies with:
- CE standards
- FCC rules
- RCM standards
- ROHS standards Operation is subject to the following two conditions: (1) This device will not cause harmful interference, and (2) This device will accept any interference received, including interference that may
cause undesired or improper operation.
WARNING: This product emits electromagnetic and electronically generated waves that may interfere with the safe operation of pacemakers.
Individuals that have pacemakers should never use this product.
WARNING:
Do not use on live electrical circuits. Must read instructions before use. Wear safety goggles. (User and bystanders). Risk of entanglement.
Read the Warranty, Safety and Recycling information at the end of this user guide.
Page 3/32
UM-HV1-13-11 VDO TPMS GO user guide
3. CAUTION
READ THESE INSTRUCTIONS BEFORE USE
Your Tire Pressure Monitoring (TPM) tool has been designed to be durable, safe, and reliable when properly used.
All VDO TPMS TOOLS are intended to be used only by qualified and trained automotive technicians or in a light industrial repair shop environment. Please read all instructions below before using. Always follow these safety instructions. If you have any questions pertaining to the safe or reliability use of this tool, please call your local dealer.
1. Read All Instructions
All warnings on the tool and in this manual should be adhered to. All operating instructions should be followed.
2. Retain Instructions
The safety and operating instructions should be retained for future reference.
3. Heed Warnings
User and bystanders must wear safety goggles and must read instructions before use. Do not use on live electrical circuits, risk of entanglement.
4. Cleaning
Clean with a soft dry cloth, or if necessary, a soft damp cloth. Do not use any harsh chemical solvents such as acetone, thinner, brake cleaner, alcohol, etc as this may damage the plastic surface.
5. Water & Moisture
Do not use this tool where contact or immersion in water is a possibility. Never spill liquid of any kind onto the tool.
6. Storage
Do not use or store the tool in an area where it is exposed to direct sunlight or excessive moisture.
7. Use
To reduce the risk of fire, do not operate the tool in the vicinity of open containers or flammable liquids. Do not use if the potential for explosive gas or vapors exists. Keep the tool away from heat generating sources. Do not operate the tool with the battery cover removed.
Page 4/32
UM-HV1-13-11 VDO TPMS GO user guide
4. FUNCTION KEYS
Power ON /OFF switch Test or trigger sensor.
Next, continue or confirm. Cancel, previous step.
Navigate to select "up”. Navigate to select “down”.
Navigate to select “left”. Navigate to select “right”.
Antenna
Result lights
Trigger light
Battery charge
indicator and
low bat. light
Keyboard
Page 5/32
UM-HV1-13-11 VDO TPMS GO user guide
5. POWER ON
Press key to turn on the TPMS TOOL
Ø Displays the VDO Logo as Fig. 1.
Fig. 1
VDO TPMS Go
Ø The software version as Fig. 2.
Ø At first start or after a factory reset, the work
zone is asked as Fig. 3.
Ø Then reverts to the MAIN MENU as Fig. 4.
Version HV1-13-11
ZONE:EUROPE
Fig. 2
ZONE
> AMERICA EUROPE COREA
Fig. 3
MAIN MENU
CHECK SENSOR
Fig. 4
Page 6/32
UM-HV1-13-11 VDO TPMS GO user guide
6. OPERATING INSTRUCTIONS
6.1. TPMSTOOL OVERVIEW
Read and diagnose sensors.
Service Procedure Read Sensor Test
Before servicing the tires/wheels, using your TPMS TOOL, trigger each of the vehicle's sensors to
MAIN MENU
make sure they are working properly. This will eliminate the liability associated with
replacing previously damaged or defective sensors.
CHECK SENSOR
This procedure will not change the vehicle settings because the vehicle has yet to be put into learn/retraining mode. This procedure allows you to quickly identify damaged or defective sensors, because some vehicles do not report a damaged or defective sensor condition on the instrument cluster for up to 20 minutes.
Note: If the sensors do not trigger, please refer to the Troubleshooting section of this Guide.
Perform tire/wheel service. Begin by triggering the driver's left front (LF) wheel sensor. The same procedure should be followed on all wheel sensors, in a
clockwise rotation.
1 Start LF
RF 2
We recommend you trigger each wheel sensor, one final time, to make sure they are working correctly prior to releasing the vehicle to the customer.
4 End LR
RR 3
Page 7/32
Fig. 5
UM-HV1-13-11 VDO TPMS GO user guide
VDO TPMS GO USE
IMPORTANT:
Vehicle specific information in this manual is used as an example and may not represent specific instructions each make and model may require. When performing various functions with the tool, it is important to refer to the on-screen prompts and/or repair manual information.
1. CHECK SENSOR
MAIN MENU
CHECK SENSOR
1.1. SELECT CAR MANUFACTURER
VEHICLE SELECTION
SUBARU SUZUKI TESLA > TOYOTA
VEHICLE SELECTION
SUBARU SUZUKI TESLA > TOYOTA
TOYOTA
ProAce Combi > RAV4 III RAV4 IV Solara II
1.2. SELECT CAR MODEL
TOYOTA
ProAce Combi > RAV4 III RAV4 IV Solara II
Page 8/32
RAV4 III
> 2005-2013
UM-HV1-13-11 VDO TPMS GO user guide
▲◄►
▲◄►
1.3. SELECT YEAR
RAV4 III
> 2005-2013
1.4. SELECT WHEEL NUMBER
This option does not appear for all vehicles.
RAV4 III
> 4 WHEELS 5 WHEELS
RAV4 III
> 4 WHEELS 5 WHEELS
RAV4 III
SELECT TIRE
C:
: START
The tool is ready to trigger the
sensors.
1.5. TEST SENSOR
RAV4 III
SELECT TIRE
C:
: START
Use keypad for tire selection.
RAV4 III
TRIGGER PROCESSING
C:
: START
Page 9/32
UM-HV1-13-11 VDO TPMS GO user guide
1.6. TEST RESULTS
RAV4 III
TRIGGER PROCESSING
C:
: START
1: PASS: press to go to next tire.
2/5: FAIL.
1: PASS
2: FAIL
3: FAIL
RAV4 III
F383834 25°C
2.50 bar BAT:OK 433 MHz
C:
RAV4 III
NO SENSOR DETECTED
C:
RAV4 III
DUPLICATE SENSOR
C:
RAV4 III
: START
: START
: START
4: FAIL
5: FAIL
REDUCE TIRE PRESSURE
C:
RAV4 III
COM. ERROR
C:
: START
: START
Page 10/32
UM-HV1-13-11 VDO TPMS GO user guide
2. PROGRAM BLANK SENSOR
This feature allows to recover a sensor ID in order to enter it in the spare blank sensor. If the "old" sensor can be read, use the "COPY ORIGINAL SENSOR" function to recover the ID. If it can't be read, use the "CREATE NEW SENSOR" menu to create a randomized ID.
MAIN MENU
PROG. SENSOR
VEHICLE SELECTION
SUBARU SUZUKI TESLA > TOYOTA
2.1. PROGRAM BY SENSOR OR VEHICLE
This option offers to program a sensor, either by sensor brand or by vehicle.
2.1.1. Sensor selection mode
PROGRAM SENSOR
> SENSOR SELECTION VEHICLE SELECTION
ALCAR by Schrader ALLIGATOR Sens.it > EU-Pro HUF Intellisens
PROGRAM SENSOR
PROGRAM SENSOR
ALCAR by Schrader ALLIGATOR Sens.it > EU-Pro HUF Intellisens
2.1.1. Vehicle selection mode
PROGRAM SENSOR
SENSOR SELECTION > VEHICLE SELECTION
VEHICLE SELECTION
SUBARU SUZUKI TESLA > TOYOTA
VEHICLE SELECTION
SUBARU SUZUKI TESLA > TOYOTA
Page 11/32
UM-HV1-13-11 VDO TPMS GO user guide
NEXT
2.1. SELECT CAR MANUFACTURER
VEHICLE SELECTION
SUBARU SUZUKI TESLA > TOYOTA
2.2. SELECT VEHICLE MODEL
TOYOTA
ProAce Combi > RAV4 III RAV4 IV Solara II
TOYOTA
ProAce Combi > RAV4 III RAV4 IV Solara II
RAV4 III
> 2005-2013
2.3. SELECT YEAR
RAV4 III
> 2005-2013
2.4. SELECT BLANK SENSOR MODEL
PROGRAM SENSOR
ALCAR by Schrader ALLIGATOR Sens.it > EU-Pro HUF Intellisens
PROGRAM SENSOR
ALCAR by Schrader ALLIGATOR Sens.it > EU-Pro HUF Intellisens
The list of compatible sensors depend
on the vehicle selected
TOYOTA
Use EU-Pro1 or EU-Pro Hybrid
(C) STOP (OK)
The device displays the compatible
references of the selected brand
to continue.
Page 12/32
UM-HV1-13-11 VDO TPMS GO user guide
NEXT
2.5. SELECT THE OPTION
TOYOTA
Use EU-Pro1 or EU-Pro Hybrid
(C) STOP (OK)
2.6. "COPY ORIGINAL SENSOR"
EU-Pro Hybrid
> COPY ID CREATE SENSOR
EU-Pro Hybrid
> COPY ID CREATE SENSOR
RAV4 III
COPY ID
C:
: START
C:
RAV4 III
COPY ID
: START
RAV4 III
TRIGGER PROCESSING
C:
: START
Page 13/32
UM-HV1-13-11 VDO TPMS GO user guide
"
Sensor
reprogramming
"
section
.
2.6.1. Test results
RAV4 III
RAV4 III
TRIGGER PROCESSING
C:
: START
1: PASS
F383834 25°C
2.50 bar BAT:OK 433 MHz
C:
: START
1: PASS: See
RAV4 III
2: FAIL: press to test again.
3: FAIL: reduce the tire pressure and
press to test again.
4: FAIL: press to test again.
2: FAIL
3: FAIL
4: FAIL
NO SENSOR DETECTED
C:
RAV4 III
REDUCE TIRE PRESSURE
C:
RAV4 III
COM. ERROR
C:
: START
: START
: START
Page 14/32
UM-HV1-13-11 VDO TPMS GO user guide
2.7. PROGRAMMING SENSOR
RAV4 III
F383834 25°C
2.50 bar BAT:OK 433 MHz
C:
: START
Hold the new programmable sensor
near the device antenna.
2.7.1. Results
RAV4 III
PROGRAM SENSOR
433 MHz
C:
: START
RAV4 III
PROGRAM SENSOR
433 MHz
C:
RAV4 III
: START
UPLOADING…
C:
RAV4 III
: START
VERIFYING
433 MHz
C:
RAV4 III
: START
F383834 25°C
2.50 bar BAT:OK 433 MHz
C:
: START
Page 15/32
UM-HV1-13-11 VDO TPMS GO user guide
2.8. "CREATE NEW SENSOR"
EZ-sensor
COPY ID > CREATE SENSOR
2.8.1. Results
RAV4 III
CREATE SENSOR
433 MHz
C:
: START
Note: in this operation the ID is a
random number.
RAV4 III
CREATE SENSOR
433 MHz
C:
: START
Hold the new programmable sensor
near the device antenna.
RAV4 III
UPLOADING…
C:
RAV4 III
VERIFYING
433 MHz
: START
C:
RAV4 III
: START
EE995DD 25°C
2.50 bar BAT:OK 433 MHz
C:
: START
.
Page 16/32
UM-HV1-13-11 VDO TPMS GO user guide
3. PART LOOKUP
This is a spare parts data base for all sensors available for each car.
MAIN MENU
PART # LOOKUP
3.1. SELECT CAR MANUFACTURER
VEHICLE SELECTION
SUBARU SUZUKI TESLA > TOYOTA
VEHICLE SELECTION
SUBARU SUZUKI TESLA > TOYOTA
TOYOTA
ProAce Combi > RAV4 III RAV4 IV Solara II
3.2. SELECT VEHICLE MODEL
TOYOTA
ProAce Combi > RAV4 III RAV4 IV Solara II
RAV4 III
> 2005-2013
Page 17/32
UM-HV1-13-11 VDO TPMS GO user guide
3.1. SELECT YEAR
RAV4 III
> 2005-2013
3.1. SELECT PART NUMBER
PART# LOOKUP
> OE OE Sensor ref OE SERVICE KIT OE SERVICE VALVE
PART# LOOKUP
> OE OE Sensor ref OE SERVICE KIT OE SERVICE VALVE
OE
42607-20010
TOYOTA
RAV4 III
2005-2013
Page 18/32
UM-HV1-13-11 VDO TPMS GO user guide
AUTO OFF : 60min
SETTINGS
1. SETTINGS MENU
MAIN MENU
SETTINGS
> ZONE : EUROPE
UNITS : PSI/°F FORMAT : AUTO BUZZER ON : YES CONTRAST : 80 %
Complete listing.
SETTINGS
> UNITS : PSI/°F FORMAT : AUTO
Scroll up and down to select function or settings.
Enter menu or validate settings by using OK.
BUZZER ON : YES CONTRAST: 80 %
Key functional descriptions: ZONE: to select the area of work, AMERICA, EUROPE, KOREA or JAPAN. UNITS: change the air pressure and temperature display (kPa, Bar or PSI with F° or C°). FORMAT: change the format of sensor ID display. BUZZER: turn buzzer to ON or OFF (YES or NO). CONTRAST: adjust LCD backlight brightness level (0% to 100%). AUTO OFF: time to turn off the device automatically after not being operated.
Page 19/32
UM-HV1-13-11 VDO TPMS GO user guide
1.1. CHANGE ZONE SETTINGS
SETTINGS
> ZONE : EUROPE UNITS : PSI/°F FORMAT : AUTO
> AMERICA EUROPE KOREA
ZONE
BUZZER ON : YES
DATABASE
PLEASE WAIT...
Scroll up or down to select the zone.
Press to enter. At first start or after a factory reset, the zone option appears on the screen. To apply a factory reset to the device, please use the WebTPM software. Connect the TPMS Go device to the PC, open WebTPM and then click on the "Factory
reset" button in the header menu.
1.2. CHANGE UNITS SETTINGS
SETTINGS
ZONE : EUROPE > UNITS : PSI/°F FORMAT : AUTO BUZZER ON : YES
Scroll up and down to select function
or settings.
Enter settings parameter.
Complete listing.
> PSI/°F PSI/°C kPa/°C kPa/°F bar/°F bar/°C
Scroll up or down to select the desired change.
Press to confirm the change
and return to settings.
Press to return settings
Page 20/32
without change.
UM-HV1-13-11 VDO TPMS GO user guide
1.3. CHANGE FORMAT SETTINGS
SETTINGS
ZONE : EUROPE UNITS : PSI/°F > FORMAT : AUTO
> AUTO DECIMAL HEXADECIMAL
Complete listing.
BUZZER ON : YES
Scroll up or down to select the desired
Scroll up and down to select function
change.
or settings.
Press to confirm the change
and return to settings.
Enter settings parameter.
Press to return settings
without change.
AUTO: display sensor ID format in the way sensor is transmitting. DECIMAL: force to display sensor ID in decimal (0 to 9). HEXADECIMAL: force to display sensor ID in hexadecimal (0 to F).
1.4. CHANGE BUZZER ON SETTINGS
When buzzer on is set to YES, a beep is triggered when the sensor ID is detected.
SETTINGS
ZONE : EUROPE UNITS : PSI/°F FORMAT : AUTO > BUZZER ON : YES
UNITS : PSI/°F FORMAT : AUTO BUZZER ON : NO <
Change by YES or NO.
SETTINGS
CONTRAST: 80 %
Scroll up and down to select function
or settings.
Scroll up or down to select the desired change.
Press to confirm the change
Enter settings parameter.
and return to settings.
Page 21/32
Press to return to settings
without change.
UM-HV1-13-11 VDO TPMS GO user guide
1.5. CHANGE CONTRAST SETTINGS
SETTINGS
> CONTRAST: 80 % A U T O OFF: 6 0 m i n
Scroll up and down to select function
or settings.
Enter settings parameter.
Change from 0% (clear) to 100% (dark).
SETTINGS
CONTRAST: 85 % < A U T O OFF: 6 0 m i n
Scroll up or down to select the desired change.
Press to confirm the change
and return to settings.
Press to return to settings
1.6. CHANGE AUTO OFF SETTINGS
SETTINGS
CONTRAST: 80 % > A U T O O F F: 60 mi n
Scroll up and down to select function
or settings.
Enter settings parameter.
without change.
Change from 60 min (maximum) to
DISABLED (never).
SETTINGS
CONTRAST: 80 % > A U T O O F F: DIS A B L E D
Scroll up or down to select the desired change.
Press to confirm the change
and return to settings.
Press to return settings
without change.
Page 22/32
UM-HV1-13-11 VDO TPMS GO user guide
ABOUT
1. THE ABOUT MENU
Displays the current software version and information about the device.
MAIN MENU
LANGUAGE
ABOUT
S/N: K360-10853 Version: HV1-13-11 Database: MYE1-62 Receiver 1:OK 2:--
Page 23/32
UM-HV1-13-11 VDO TPMS GO user guide
LANGUAGE
1. LANGUAGE MENU
MAIN MENU
LANGUAGE
English / German / Spanish / Czech / French / Italian / Slovenian / Swedish / Danish / Hungarian / Slovak / Dutch / Romanian / Polish / Norwegian / Finnish / Portuguese / Turkish / Croatian / Greek / Russian / Hebrew / Chinese / Korean.
LANGUAGE
> ENGLISH ESPANOL SUOMI FRANCAIS
Scroll up and down to select language.
Press to select language.
Page 24/32
UM-HV1-13-11 VDO TPMS GO user guide
RECENT SENSOR DATA
1. RECENT SENSOR DATA When a new vehicle is triggered the result is automatically stored in the RECENT
SENSOR DATA menu. You may recall the result and continue to trigger the entire vehicle.
The data is automatically replaced if a new vehicle is triggered. The data remains in the memory even after the device has been turned off.
MAIN MENU
RECENT SENSOR DATA
RAV4 III
F383834 25°C
2.50 bar BAT:OK 433 MHz
C:
: START
Page 25/32
UM-HV1-13-11 VDO TPMS GO user guide
MISCELLANEOUS
1. CHARGE Low Battery Indication
Your TPMS TOOL incorporates a low battery detection circuit. Battery life is an average of 400 sensor tests per battery full charge (approximately 80-100 cars).
A full charge takes about 6 hours. When battery is low, the battery screen is
flashing with the message "LOW". The power button my also be pressed and held
for a second to display battery status.
Battery Charging
BATTERY LEVEL
BATTERY LEVEL
LOW
USB Power
supply connector
When the battery is low, the “status bar” appears every 10 seconds. The display turns off when the battery loses power.
Plug the USB cable between the tool and the charger adapter, and then plug the charger adapter to an appropriate outlet. The red LED "CHARGE" light will turn on.
It’s not recommended to use the tool with low battery status as the transmission and emission may not be reliable.
Once charged, the bar graph is full and the LED "CHARGE" turns to green light.
Battery replacement
The tool must be returned to the factory for battery replacement.
Opening the tool or tampering with the seal placed on the tool will void the warranty.
BATTERY LEVEL
Fig. 6
Page 26/32
UM-HV1-13-11 VDO TPMS GO user guide
2. TROUBLESHOOTING
If the TPMS TOOL is unable to trigger one or more of the sensors, please use the following troubleshooting guide:
1) The vehicle does not have a sensor even though a metal valve stem is present. Be aware of Schrader rubber style snap-in stems used on TPMS systems.
2) The sensor, module or ECU itself may be damaged or defective.
3) The sensor may be the type that periodically triggers on its own and is not designed to
respond to a triggering frequency.
4) Your TPMS TOOL may require a software upgrade.
5) Check “Auto Off” time settings for screen display.
6) Your TPMS TOOL is damaged or defective.
3. TOOL UPDATE Updating your TPMS TOOL
As new cars and sensors becomes available, it will be necessary to upgrade your tool. Please follow the steps below:
IMPORTANT: Temporarily turn off all of the anti-virus and spam blocking software on your computer. This is necessary to ensure a successful upgrade.
Page 27/32
USB connector
for Internet
update.
Fig. 7
UM-HV1-13-11 VDO TPMS GO user guide
3.1. INSTALL WEBTPM PC SUITE
1) Connect the TPMS tool to the USB port and power the tool ON.
2) Insert the USB key supplied with your tool into any available USB port and click on the WebTPM icon to start the program installation.
3) A screen will appear that says “Welcome to the Install Shield Wizard for WebTPM. Click “Next >
4) A window will appear to choose destination location, click “Next >
5) Follow instructions until the window with the “Finish” button appears.
6) Click “Finish” when the WebTPM installation is complete.
Note: To order annual update software part number, please see your dealer for availability and pricing.
3.2. UPDATING WITH WEBTPM
Before updating, ensure that the battery is fully charged.
1) Connect the USB cable between the TPMS TOOL and the PC and turn the device on.
2) Start WebTPM software.
3) A screen will appear indicating “Update Device”.
4) Press “Yes” to update to the latest software version. Update will take several minutes
to complete and the status bar will indicate the percentage of update completed.
Warning!
Do not disconnect the TPMS TOOL from the PC or turn the computer off during the update process. This may result in serious damage to the tool.
www.vdo.com
Page 28/32
UM-HV1-13-11 VDO TPMS GO user guide
4. LIMITED HARDWARE WARRANTY
VDO Limited Hardware Warranty
VDO warrants to the original purchaser that your VDO hardware product shall be free from defects
in material and workmanship for the length of time, identified on your product package and/or contained in your user documentation, from the date of purchase. Except where prohibited by applicable law, this warranty is nontransferable and is limited to the original purchaser. This warranty gives you specific legal rights, and you may also have other rights that vary under local laws.
Remedies
VDO’s entire liability and your exclusive remedy for
any breach of warranty shall be to repair or replace the hardware. VDO may, at its option, use new or refurbished or used parts in good working condition to repair or replace any hardware product. Any replacement hardware product will be warranted for the remainder of the original warranty period or thirty (30) days, whichever is longer or for any additional period of time that may be applicable in your jurisdiction.
This warranty does not cover problems or damage resulting from (1) accident, abuse, misapplication, or any unauthorized repair, modification or disassembly; (2) improper operation or maintenance, usage not in accordance with product instructions or connection to improper voltage supply; or (3) use of consumables, such as replacement batteries, not supplied by VDO except where such restriction is prohibited by applicable law.
How to Obtain Warranty Support
Before submitting a warranty claim, we recommend you visit the support section at www.vdo.com for technical assistance. Valid warranty claims are generally processed through the point of purchase during the first thirty (30) days after purchase; however, this period of time may vary depending on where you purchased your product – please check with VDO or the retailer where you purchased your product for details. Warranty claims that cannot be processed through the point of purchase and any other product related questions should be addressed directly to VDO. The addresses and customer service contact information for VDO can be found in the documentation accompanying your product and on the web at www.vdo.com.
Limitation of Liability
VDO SHALL NOT BE LIABLE FOR ANY SPECIAL, INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES WHATSOEVER, INCLUDING BUT NOT LIMITED TO LOSS OF PROFITS, REVENUE OR DATA (WHETHER DIRECT OR INDIRECT) OR COMMERCIAL
LOSS FOR BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON YOUR PRODUCT EVEN IF VDO HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Some jurisdictions do not allow the exclusion or limitation of special, indirect, incidental or consequential damages, so the above limitation or exclusion may not apply to you.
Duration of Implied Warranties
EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ANY IMPLIED WARRANTY OR CONDITION OF MERCHANTABILITY OR FITNESS ON THIS HARDWARE PRODUCT IS LIMITED IN DURATION TO THE DURATION OF THE APPLICABLE LIMITED WARRANTY PERIOD FOR YOUR PRODUCT. Some jurisdictions do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you.
National Statutory Rights
Consumers have legal rights under applicable national legislation governing the sale of consumer goods. Such rights are not affected by the warranties in this Limited Warranty.
No Other Warranties
No VDO dealer, agent, or employee is authorized to make any modification, extension, or addition to this warranty.
Warranty Periods
The warranty period for the VDO TPMS Go device is two years.
5. SAFETY BATTERY AND CHARGE INFORMATION
You must read and understand these safety instructions and warnings before using or charging your Li-Po batteries.
Operating environment
Remember to follow any special current regulations in any area, and always switch off your device when its use is prohibited or when it may cause interference or danger.
Use the device only in its normal operating positions.
Your device and its enhancements may contain small parts. Keep them out of the reach of small children.
About Charging
Use only the charger supplied with your device. Use of another type of charger will result in malfunction and/or danger.
Page 29/32
UM-HV1-13-11 VDO TPMS GO user guide
When the red LED turns off, the charge is complete.
About the Charger
Do not use the charger in a high moisture environment. Never touch the charger when your hands or feet are wet.
Allow ventilation around the charger when using it. Do not cover the charger with paper or other objects that will reduce cooling. Do not use the charger while it is inside a carrying case.
Connect the charger to a proper power source. The voltage requirements are found on the product case and/or packaging.
Do not use the charger if the wires become damaged. Do not attempt to service the unit. There are no serviceable parts inside. Replace the unit if it is damaged or exposed to excess moisture.
This charger is not a toy and should not be used by children or infirm persons without proper training or supervision.
Do not use it as a power source. Unplug it before attempting to service or clean it.
About the Battery
CAUTION: This unit contains an internal Li-Po battery. The battery can burst or explode, releasing hazardous chemicals. To reduce the risk of fire or burns, do not disassemble, crush, pierce or dispose of the battery or the instrument in fire or water, do not short circuit or short the contacts with a metal object.
Use a specified charger approved by the manufacturer and supplied with the device.
The tool must be returned to the factory for battery replacement.
Opening the tool or tampering with the seal placed on the tool, if broken will void the warranty.
Safety for Li-Po battery use
NEVER leave the battery unattended during the
charging process. The device must imperatively be placed on a non-flammable surface during charging (ceramic platter or metal box).
Charge the Li-Po battery ONLY with the charger provided.
If the battery begins to overheat more than 60°C (140° F), IMMEDIATELY STOP the charge. The battery should NEVER exceed 60°C (140° F) during the charging process.
If you see smoke or liquid coming out of the battery, stop the charge immediately. Disconnect the charger and place the tool in an isolated area for at least 15 minutes. DO NOT USE THE BATTERY AGAIN, but return the device to your seller.
Keep a fire extinguisher for electrical fires handy while charging the battery. In the unlikely event that the Li-Po battery ignites, DO NOT use water to extinguish the fire, take some sand or a fire extinguisher as described above.
This must neutralize the battery elements so that they are unusable. The neutralization process must be performed with very strict security fit. It is recommended that you return the tool to us, so that we can collect the out of use battery and give this to a specialized recycler.
Do not dispose of Li-Po batteries in the dustbin.
The Li-Po battery is not suitable for children under 14 years. Do not let a Li-Po battery reach of children.
To prevent leakage or other hazards, do not store batteries above 60°C (140°F). Never leave the battery inside a car (for example) where the temperature could be very high or in a place where temperatures could exceed 60°C (140°F). Store the battery in a dry place to avoid contact with liquid, whatever the type. Store the battery only on a nonflammable surface, heat resistant, non conductive and away from all flammable materials or sources. Always store the battery out of reach of children.
A Li-Po battery should be stored with a minimum charge of 30%. If you store completely discharged, it will quickly become unusable.
If you don't follow these safety precautions, you may cause serious personal injury and damage to property; you may even cause a fire!
The company disclaims any responsibility for damage sustained in case of non compliance with these safety instructions.
Using a Li-Po battery has a high risk of fires and can cause serious damage to property and persons, the user agrees to accept the risk and responsibility.
As the company cannot control the proper use of the battery by each customer (charge, discharge, storage etc.); it cannot be held responsible for damage to persons and property.
NEVER charge the battery immediately after use and while still hot. Leave it cool down to ambient temperature.
Page 30/32
UM-HV1-13-11 VDO TPMS GO user guide
6. CE STATEMENTS
DECLARATION OF CONFORMITY
The manufacturer of the VDO TPMS Go device declares that this device complies with the requirements of:
- ETSI EN 300 330 V2.1.1 (2017-02)
- ETSI EN 301 489-1/-3 V2.1.1 (2017-03)
- EN 61010-1:2010 (2014/35/EU)
- EN 62479:2010
- EN 61326-1:2013 (2014/30/EU)
7. FCC STATEMENTS
DECLARATION OF CONFORMITY
8. RCM STATEMENTS
DECLARATION OF CONFORMITY
The manufacturer of the VDO TPMS Go device declares that this device complies with the requirements of:
- CISPR 32:2015 / COR1:2016 Class B
- AS/NZS CISPR 32:2015 Class B
The manufacturer of the VDO TPMS Go declares that this device complies with the requirements of:
- PART 15B 2005
- PART 15C 47 CFR FCC PART 15.209
9. RECYCLING
Do not dispose the rechargeable Li-Po battery or the tool and/or its
accessories in the dustbin.
These components must be collected and recycled.
Page 31/32
The crossed-out wheeled dustbin means that the product must be taken to separate collection at the product end-of life. This applies to your tool but also to any enhancements marked with this symbol. Do not dispose of these products as unsorted municipal waste. For further information, please contact VDO.
UM-HV1-13-11 VDO TPMS GO user guide
Index
A
About .................................................. 23
Auto off ............................................... 22
B
Battery ................................................ 30
Buzzer ................................................ 21
C
Caution ........................................... 4, 30
CE Conformity .................................... 31
Charge ................................................ 26
Charger............................................... 30
Charging ....................................... 26, 30
Check Sensor ....................................... 8
Contrast .............................................. 22
Copy original sensor ........................... 13
Create new sensor ............................. 16
D
Device update ..................................... 28
E
Environment ....................................... 29
F
FCC Conformity .................................. 31
Format ................................................ 21
Function keys ....................................... 5
L
Language ............................................ 24
Low battery ......................................... 26
M
Main Menu ............................................ 8
O
Operating instructions ........................... 7
Overview ............................................... 7
Part lookup ......................................... 17
Power supply ...................................... 30
Program blank sensor ......................... 11
Programming sensor .......................... 15
RCM Conformity ................................. 31
Recent sensor data............................. 25
Recycling ............................................ 31
Safety instructions ................................ 3
Safety precautions .............................. 29
Security ............................................... 30
Settings ............................................... 19
Software installation ............................ 28
Software update.................................. 28
Specifications........................................ 2
Tire selection ........................................ 9
Tool update ......................................... 27
Troubleshooting .................................. 27
Units ................................................... 20
Use ....................................................... 8
Use Instructions .................................... 4
Warning ................................................ 3
Warranty.............................................. 29
WebTPM PC suite .............................. 28
Zone ................................................... 20
P
R
S
T
U
W
Z
Page 32/32
This document is the exclusive property of VDO.
It may not be communicated, reproduced or used without prior consent.
Loading...
