Installation and User Guide
VADDIO™ POWERVIEW™ HD PTZ CAMERAS
PowerVIEW HD-22 High Definition PTZ Camera
Model Number 999-6960-000 (North America)
Model Number 999-6960-001 (International)
PowerVIEW HD-30 High Definition PTZ Camera
Model Number 999-6970-000 (North America)
Model Number 999-6970-001 (International)
© 2013 Vaddio - All Rights Reserved. PowerVIEW HD-22 & HD-30 Cameras - Document Number 342-0626 Rev A
(22X Optical Zoom)
(30X Optical Zoom)
PowerVIEW HD-22 and HD-30
TABLE OF CONTENTS
Overview .................................................................................................................................................................... 3
Unpacking: ................................................................................................................................................................. 4
Front View with Feature Call-outs .......................................................................................................................... 5
Image: PowerVIEW HD-22/30 HD PTZ Camera ............................................................................................... 5
Rear Panel Connections with Feature Call-outs .................................................................................................... 6
Image: PowerVIEW HD-20 or HD-30 HD PTZ Camera .................................................................................... 6
First Time Set-up with the PowerVIEW HD-22 or HD-30: ......................................................................................... 7
Image: PowerVIEW HD-22/30 Rear Panel Connections .................................................................................. 7
Drawing: Dip Switch and Resolution Label on the Bottom of the HD-22/30 ...................................................... 7
Image: Basic Connectivity Example of the HD-22 & HD-30 ............................................................................. 8
Installation Basics: ................................................................................................................................................. 8
Compliance and CE Declaration of Conformity - PowerVIEW HD-22 and HD30 ..................................................... 9
Warranty Information ............................................................................................................................................... 10
General Specifications: ............................................................................................................................................ 11
Appendix 1: YPbPr Video Pin-Out for the HD-22/30 Camera ............................................................................... 11
EZCamera Power & HD Video RJ-45 Connector Pin-outs .................................................................................. 12
Drawing: PowerVIEW HD-22/30 Dimensions ................................................................................................. 12
Communication Specification .................................................................................................................................. 13
HD-22/30 Command List (1/2) ......................................................................................................................... 13
HD-22/30 Command List (2/2) ......................................................................................................................... 14
HD-22/30 Inquiry List (1/1) ............................................................................................................................... 15
PowerVIEW HD-22 and HD-30 HD PTZ Cameras Document Number 342-0626 Rev A Page 2 of 16
PowerVIEW HD-22 and HD-30
prop
p
O
VERVIEW
:
The impressive Vaddio PowerVIEW HD-22 and HD-30 high
definition PTZ cameras are available with 22X and 30X power zoom
optics. This new camera the latest Maicovicon 1MOS, 1/2.8-Type,
progressive scan image sensors, which allow for better light
sensitivity, increased noise reduction and lower power consumption
than either CCD or CMOS image sensors. This advanced MOS
image sensor provides for delicate gradation, realistic textures and
vivid colors that are comparable to 3-chip camera performance.
Both the HD-22 and the HD-30 provide matchless low-light
capabilities with a minimum illumination rating of an amazing 0.4 lux
(color) and 0.3 lux (B/W). With a 2.2 megapixel MOS sensor, the
cameras deliver native 1080p/60 high definition video resolution and
superior color reproduction for use in any professional A/V
presentation, videoconferencing, House of Worship, education, live
event and industrial applications.
Image: PowerVIEW HD-22 or HD-30 PTZ Camera
The HD-22 has a powerful 22X multi-element glass zoom lens (f=4.3mm to 94.6mm) and works exceptionally in
large rooms. However, the premium optics also provides a super-wide horizontal field of view of 65.2º, which
works very well in small room video applications. The HD-30, as the name would suggest, has a robust 30X
optical power zoom lens that enables the capture of brilliant and detailed video images even in the largest rooms.
The cameras output multi-format HD video in both analog component (YPbPr), HDMI and differential formats in
HD resolutions of 1080p/59.94, 1080p/50 1080p/29.97 1080p/25, 1080i/59.94, 1080i/50, 720p/59.94, 720p/50 and
SD resolutions of 480p/59.97 and 576p/50.
Both PowerVIEW cameras will be offered in WallVIEW™ packages with Quick-Connect™ Interfaces using HSDS
for distribution of video, power and control over Cat-5 cable. The packages will include the Quick-Connect
Universal CCU, Quick-Connect SR, Quick-Connect DVI/HDMI SR, Quick-Connect USB and USB Mini. The
PowerVIEW HD-22 and the HD-30 cameras represent an exceptional value and are remarkable performers for
even the most demanding HD video applications.
Intended Use:
Before operating the device, please read the entire manual thoroughly. The system was designed, built and
tested for use indoors with the power supply provided. The use of a power supply other than the one provided or
outdoor operation has not been tested and could damage the device and/or create a potentially unsafe operating
condition.
Important Safeguards:
Read and understand all instructions before using. Do not operate any device if it has been dropped or
damaged. In this case, a Vaddio technician must examine the product before operating. To reduce the risk of
electric shock, do not immerse in water or other liquids and avoid extremely humid conditions.
Use only the power supply provided with the system. Use of any unauthorized
power supply will void any and all warranties.
Please do not use “pass-thru” type RJ-45 connectors. These pass-thru type connectors do not
work well for professional installations and can be the cause of intermittent connections which
can result in the RS-232 control line failing and locking up, and/or compromising the HSDS (high
speed differential) signals. For best results please use standard RJ-45 connectors and test all
cables for
er pin-outsprior to use and connection to Vaddio
roduct.
Save These Instructions:
The information contained in this manual will help you install and operate your product. If these instructions are
misplaced, Vaddio keeps copies of Specifications, Installation and User Guides and most pertinent product
drawings for the Vaddio product line on the Vaddio website. These documents can be downloaded from
www.vaddio.com free of charge.
PowerVIEW HD-22 and HD-30 HD PTZ Cameras Document Number 342-0626 Rev A Page 3 of 16
PowerVIEW HD-22 and HD-30
U
NPACKING
:
Carefully remove the product and all of the included parts from the packaging.
Identify the following parts for each camera:
PowerVIEW HD-22 HD PTZ Camera (North America):
Part Number: 999-6960-000
One (1) PowerVIEW HD-22 HD PTZ Camera (998-6960-000)
One (1) Vaddio IR Remote Commander
One (1) EZCamera™ Control Adapter (RJ-45 to DB-9)
One (1) 12 VDC, 3.0 Amp Power Supply with Power Cord for North America
Documentation
PowerVIEW HD-22 HD PTZ Camera (International):
Part Number: 999-6960-001
One (1) PowerVIEW HD-22 HD PTZ Camera (998-6960-000)
One (1) Vaddio IR Remote Commander
One (1) EZCamera™ Control Adapter (RJ-45 to DB-9)
One (1) 12 VDC, 3.0 Amp Power Supply
One (1) Euro Power Cable
One (1) UK Power Cable
Documentation
PowerVIEW HD-30 HD PTZ Camera (North America):
Part Number 999-6970-000
One (1) PowerVIEW HD-30HD PTZ Camera (998-6970-000)
One (1) Vaddio IR Remote Commander
One (1) EZCamera™ Control Adapter (RJ-45 to DB-9)
One (1) 12 VDC, 3.0 Amp Power Supply with Power Cord for North America
Documentation
PowerVIEW HD-30 HD PTZ Camera (International):
Part Number 999-6970-001
One (1) PowerVIEW HD-22 HD PTZ Camera (998-6960-000)
One (1) Vaddio IR Remote Commander
One (1) EZCamera™ Control Adapter (RJ-45 to DB-9)
One (1) 12 VDC, 3.0 Amp Power Supply
One (1) Euro Power Cable
One (1) UK Power Cable
Documentation
PowerVIEW HD-22 and HD-30 HD PTZ Cameras Document Number 342-0626 Rev A Page 4 of 16
PowerVIEW HD-22 and HD-30
Front View with Feature Call-outs
Image: PowerVIEW HD-22/30 HD PTZ Camera
①
②
④
③
1) Camera and Zoom Lens:
The 22X (HD-22) or 30X (HD-30) optical zoom lens is built around a (1/2.8 Type) high-speed MOS image sensor
with a total of 2.2 megapixels for precise HD video image acquisition.
2) Red Tally Light:
A red tally light is illuminated when the camera receives a command from an external control system.
3) IR Sensors:
IR sensors are built into the front of the PowerVIEW HD-22/30 to receive IR signals from the IR remote control
supplied with the camera.
4) Blue Power Light:
A Vaddio blue power light is illuminated when the camera is turned on.
PowerVIEW HD-22 and HD-30 HD PTZ Cameras Document Number 342-0626 Rev A Page 5 of 16
PowerVIEW HD-22 and HD-30
Rear Panel Connections with Feature Call-outs
Image: PowerVIEW HD-22 or HD-30 HD PTZ Camera
⑤
⑨
⑥
⑩
⑦
⑪
⑧
5) RS-232 IN & IR Out:
The RS-232 accepts modified VISCA protocol for camera control, as well as transmits IR signaling received by
the IR receivers, which can be transmitted to third party devices.
6) Dip Switch Settings:
Settings for IR remote, baud rate and image flip can be configured on these switches. See the Switch Settings
page for additional information.
7) HD Video Select:
A rotary switch allows the user to choose the component HD output video resolution and format. See the Switch
Settings page for additional information.
HD Resolution Note: When changing the resolution of the camera, the camera should be power-
cycled after the change.
8) 12 VDC Input:
Power input for the standard, PowerVIEW HD-22 and HD-30 camera power supply.
9) HDMI Output:
The HDMI output feeds out HD digital video only (no copy protect or device communication is included). The
HDMI output is optimized for HD video signals (seems logical).
10) YPbPr Output:
Component HD video (YPbPr) is output through the DE-15 connector. YPbPr and HDMI signals are
simultaneous. Limited SD resolutions are supported.
11) EZ Power/Video Port:
This RJ-45 connector is only used with the Quick-Connect SR Interface, Quick-Connect DVI-D/HDMI SR
Interface and the Quick-Connect USB Interface to supply power and return HSDS (differential) video from the
camera.
12) Slot for Optional Cards:
Optional slot cards can be plugged into the PowerVIEW HD-22 HD camera (the HD-SDI and the EZIM CCU Slot
Cards are available).
⑫
PowerVIEW HD-22 and HD-30 HD PTZ Cameras Document Number 342-0626 Rev A Page 6 of 16
PowerVIEW HD-22 and HD-30
F
IRST TIME SET-UP WITH THE POWER
VIEW HD-22
OR
HD-30:
The PowerVIEW HD-22 and HD-30 were designed to be very easy to use and operate. There is documentation
at the back of this manual for pin-outs of the connectors on the PowerVIEW HD-22 camera.
Step 1: Using the HD VIDEO SELECT rotary switch and CAMERA SETTINGS dip switches on the back of the
camera, set up the camera’s output resolution and functional preferences. There is a label on the bottom of the
camera that identifies the choices.
Important Dip Switch Note: Setting all dip switches down and power cycling the camera will load the factory default camera settings. For
the first time set-up, loading the defaults may be a good idea
.
Image: PowerVIEW HD-22/30 Rear Panel Connections
HD Video Select Switch
Camera Settings 10-Pos Dip Switch
HD-22 Rear Panel
Drawing: Dip Switch and Resolution Label on the Bottom of the HD-22/30
IR 1
1 & 2 UP
DIP SWITCH SETTINGS
IR
9600
bps
OFF
5
OUT
OFF
OFF
HDMI
6
COLOR
YCbCr
FLIP
OFF
OFF
9
10
OFF
IR 2ONIR 3
ON
12
21
ON
38400
bps
3
3
4
4
56
5
sRGB
ON
68109
8
7
7
910
VIDEO RESOLUTION SELECT
720p/59.94
0
1080i/59.94
1
1080p/59.94
2
3
720p/50
4
1080i/50
5
1080p/50
6
480p/59.94 1080p/25
7
8
9
A
B
C
D
E
F
576p/50
1080p/29.97
Set the desired and available HD output resolution for the camera with the Rotary Switch.
Set the IR frequency of the camera if it is to respond to the IR remote control.
If using the IR forwarding feature, set the IR OUT switch to ON (SW3).
Set the Baud Rate dip switch (SW4) to 9600bps for most applications. Default for Vaddio EZCamera
Cabling Systems is 9600bps.
To set the HDMI or DVI color space, use dip switch 7 (SW7).
If inverting the camera, turn the IMAGE FLIP ON (SW8).
Dip Switch Settings:
IR 1 & 2: The IR remote has the capability of operating up to three different PTZ cameras from one remote.
Use the selector buttons at the top of the IR remote to select the frequency.
IR Out 3: The IR output is sent out on the RS-232 RJ-45 jack on the back of the camera. Turning on the IR
output will allow IR signals to be transmitted over the Cat-5 cable to the head end. When using RS-232
control or Vaddio CCU controllers (also via RS-232), turn the IR OUT to OFF (up).
Baud Rate 4: The options for baud rate are either 9600 bps or 38,400 bps.
HDMI Color or sRGB Color space 7: Default is YCbCr. Use sRGB color space with older DVI-D 1.0
monitors only. The YCbCr color space is best for HDMI digital video.
Image Flip 8: To invert the HD-20, turn the IMAGE FLIP ON (switch down).
Switches 9 and 10: Leave up - or in the OFF position.
PowerVIEW HD-22 and HD-30 HD PTZ Cameras Document Number 342-0626 Rev A Page 7 of 16
PowerVIEW HD-22 and HD-30
Othe
Image: Basic Connectivity Example of the HD-22 & HD-30
Camera Connected to ProductionVIEW™ Precision Camera Controller, Codec and Monitors
Rear of
ClearVIEW
HD-22/30
12VDC, 3.0A
PowerRite
Power Supply
(Local)
RS-232
HDMI
YPbPr
r YPbPr FEED
ProductionVIEW Precision Camera Controller
HD Monitor (Simulated Video Feeds)
Installation Basics:
Locate the camera mounting location paying close attention to camera viewing angles, lighting conditions,
possible line of site obstructions, and checking for in-wall obstructions where the camera is to be mounted. Pick
a mounting location that will optimize the performance of the camera.
RS-232 Cabling:
For RS-232, use a standard Cat-5 cable (568B termination for RJ-45 connectors) from the RS-232 port on the
back of a Vaddio ProductionVIEW camera controller or switcher. If the camera will be connected to a third-party
control system (such as AMX or Crestron), a DB-9 to RJ-45 adapter is supplied with the camera for RS-232.
.
PowerVIEW HD-22 and HD-30 HD PTZ Cameras Document Number 342-0626 Rev A Page 8 of 16
PowerVIEW HD-22 and HD-30
C
OMPLIANCE AND CE DECLARATION OF CONFORMITY - POWER
Compliance testing was performed to the following regulations:
FCC Part 15 (15.107, 15.109), Subpart B Class A
ICES-003, Issue 4: 2004 Class A
EN 55022 A: 2006 + A1: 2007 Class A
KN24 2008 (CISPR 24: 1997 + A1: 2000 + A2: 2002) Class A
KN22 2008 (CISPR 22: 2006) Class A
EMC Directive 2004/108/EC Class A
EN 55024: A2: 2003
Class A
VIEW HD-22
AND
HD30
FCC Part 15 Compliance
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part
15, Subpart B, of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may
cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be required to correct the interference at his/her own
expense.
Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) This
device must accept any interference including interference that may cause undesired operation of the device.
Changes or modifications not expressly approved by Vaddio can affect emission compliance and could void the
user’s authority to operate this equipment.
ICES-003 Compliance
This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus set out
in the Radio Interference Regulations of the Canadian Department of Communications.
Le présent appareil numérique n’emet pas de bruits radioélectriques dépassant les limites applicables aux
appareils numeriques de la classe A préscrites dans le Règlement sur le brouillage radioélectrique édicte par le
ministère des Communications du Canada.
European Compliance
This product has been evaluated for Electromagnetic Compatibility under the EMC Directive for Emissions and
Immunity and meets the requirements for a Class A digital device. In a domestic environment this product may
cause radio interference in which case the user may be required to take adequate measures.
Standard(s) To Which Conformity Is Declared:
EMC Directive 2004/108/EC
EN 55022 A: 2006 + A1: 2007(CISPR 22:2005/A1:2005)
EN 55024: 1998 + Amendments A1: 2001 + A2: 2003
EN 61000-4-2: 1995 + Amendments A1: 1998 + A2: 2001 Electrostatic Discharge
EN 61000-4-3: 2006 + A1: 2008 Radiated Immunity
EN 61000-4-4: 2004 + Corrigendum 2006 Electrical Fast Transients
EN 61000-4-5: 2006 Surge Immunity
EN 61000-4-6: 2009 Conducted Immunity
EN 61000-4-8: 2010 Power Frequency Magnetic Field
EN 61000-4-11: 2004 Voltage Dips, Interrupts and Fluctuations
KN24 2008 (CISPR 24: 1997 + A1: 2000 + A2: 2002)
EN 61000-4-2 Electrostatic Discharge
EN 61000-4-3 Radiated Immunity
EN 61000-4-4 Electrical Fast Transients
EN 61000-4-5 Surge Immunity
EN 61000-4-6 Conducted Immunity
EN 61000-4-8 Power Frequency Magnetic Field
EN 61000-4-11 Voltage Dips, Interrupts and Fluctuations
IEC 60950-1:2005 (2nd Edition); Am 1:2009
EN 60950-1:2006+A11:2009+A1:2010+A12:2011
Safety
Safety
Radiated and Conducted Emissions
Immunity
IT Immunity Characteristics
PowerVIEW HD-22 and HD-30 HD PTZ Cameras Document Number 342-0626 Rev A Page 9 of 16
PowerVIEW HD-22 and HD-30
WARRANTY INFORMATION
(See Vaddio Warranty, Service and Return Policies posted on vaddio.com for complete details):
Hardware* Warranty: Two (2) year limited warranty on all parts and labor for Vaddio manufactured products. Vaddio
warrants its manufactured products against defects in materials and workmanship for a period of two years from the day of
purchase, to the original purchaser, if Vaddio receives notice of such defects during the warranty. Vaddi o, at its option, will
repair or replace products that prove to be defective. Vaddio man ufactures its hard ware products from parts an d components
that are new or equivalent to new in accordance with industry standard practices.
Exclusions: The above warranty shall not apply to defects resulting from improper or inadequate maintenance by the
customer, customers applied software or interfacing, unauthorized modifications or misuse, mishandling, operati on outside the
normal environmental specifications for the product, use of the incorrect power supply, modified power supply or improper site
operation and maintenance. OEM products and products manufactured by other companies are excluded a nd ar e co vered b y
the manufacturer’s warranty.
Vaddio Customer Service: Vaddio will test, repair, or replace the product or products without charge if the unit is under
warranty. If the product is out of warranty, Vaddio will test then repair the product or products. T he cost of parts and labor
charge will be estimated by a technician and confirmed by the customer prior to repair. All compon ents must be returned for
testing as a complete unit. Vaddio will not accept responsibility for shipment after it has left the premises.
Vaddio Technical Support: Vaddio technicians will determine and discuss with the customer the criteria for repair costs
and/or replacement. Vaddio Technical Support can be contacted through one of the following resources: e-mail support at
support@vaddio.com or online at vaddio.com.
Return Material Authorization (RMA) Number: Before returning a product for repair or replacement request an RMA from
Vaddio’s technical support. Provide the technician with a return phone number, e-mail address, shipping address, product
serial numbers and original purchase order number. Describe the reason for repairs or returns as well as the date of
purchase. See the General RMA Terms and Procedures section for more information. RMA’s are valid for 30 days and will be
issued to Vaddio dealers only. End users must return products through Vaddio dealers. Include the assigned RMA number in
all correspondence with Vaddio. Write the assigned RMA numb er clearly on the shippi ng label of the box when returning the
product. All products returned for credit are subject to a restocking charge without exception.
Voided Warranty: The warranty does not apply if the original s erial number has been removed or if the product has been
disassembled or damaged through misuse, accident, modifications, use of incorrect po wer supply, use of a modified power
supply or unauthorized repair.
Shipping and Handling: Vaddio will not pay for inbound shipping transportation or insurance charges or accept any
responsibility for laws and ordinances from inbound transit. Vaddio will pay for outbound shipping, transportation, and
insurance charges for all items under warranty but will not assume responsibility for loss and/or damage by the outbound
freight carrier. If the return shipment appears damaged, retain the original boxes and packing material for inspection by the
carrier. Contact your carrier immediately.
Products not under Warranty: Payment arrangements are required before outbound shipment for all out of warranty
products.
*Vaddio manufactures its hardware products from parts and components that are new or equivalent to new in accordance with industry standard practices.
Other General Information:
Care and Cleaning
Do not attempt to take this product apart at any time. There are no user-serviceable components inside.
Do not spill liquids in the product
Keep this device away from food and liquid
For smears or smudges on the product, wipe with a clean, soft cloth
Use a lens cleaner on the lens - not a hanky
Do not use any abrasive chemicals.
Operating and Storage Conditions:
Do not store or operate the device under the following conditions:
Temperatures above 40°C (104°F) or temperatures below 0°C (32°F)
High humi dit y, condensing or wet environments
In inclement weather
In swimming pools or bird’s nest
Dry environments with an excess of static discharge
In orbit (vacuum problem)
Under severe vibration
PowerVIEW HD-22 and HD-30 HD PTZ Cameras Document Number 342-0626 Rev A Page 10 of 16
PowerVIEW HD-22 and HD-30
G
ENERAL SPECIFICATIONS
Camera PowerVIEW HD-22 PTZ PowerVIEW HD-30 PTZ
Part Numbers 999-6960-000 (North America)
Zoom 22X Optical Zoom 30X Optical Zoom
Field of View Horizontal: 65.2º Wide End to 3.1º Tele
Lens Focal Length f=4.3 mm to 94.6 mm / F1.6 - F4.7 f=4.3mm to 129.0 mm / F1.6- F4.7
Image Sensor 1/2.8-Type MOS, 2.2 Megapixel, Progressive Scan
Minimum Illumination Color: 0.4 lux (F1.6, 1/30 sec, 50 IRE, Gain: High),
Video Resolutions HD: 1080p/59.94, 1080p/50, 1080p/29.97/25, 1080i/59.94, 1080i/50, 720p/59.94, 720p/50
Video Output
Formats
Signal to Noise Ratio > 50 dB (AGC: Off)
Compatible
Quick-Connects
Pan Range Pan: +170 degrees to -170 degrees
Preset Positions 16 (internal), 6 recalled via Vaddio IR Remote Commander
Image Control Red & Blue Gain, Detail, Chroma, Gamma, Pedestal, Iris, and Gain
Tally Light Available through RS-232 Control
HD Video Select 16-Position Rotary Switch: Used to set HD Video Resolution Output
Camera Settings 10-Position Dip Switch: Settings for IR Select, Baud Rate 9600, Image Flip, Unpublished Functions
Accessory Slot Cards EZIM HD-SDI Slot Card PN# 998-6900-007,
Dimensions/Weight 7.81” (198.37mm) H x 6.67” (169.42mm) W x 7.057” (179.25. mm) D / 5.6 lbs. (2.630835643 kg.)
Moon in Front Page Header: Miranda - Moon of the planet Uranus.
:
999-6970-000 (North America)
999-6960-001 (Int’l)
(16:9 Aspect Ratio)
B/W: 0.04 lux (F1.6, 1/30 sec, 50 IRE, Gain: High)
SD: 480p/59.97 and 576p/50
HDMI (YCbCr for HDMI and sRGB for DVI), Analog Component (YPbPr)
HSDS (Power, Differential HD Video & R$S-232 Control)
Quick-Connect SR, Quick-Connect DVI/HDMI SR, Quick-Connect Universal CCU and QuickConnect USB (varying voltages), USB Mini
Tilt: +90 degrees to -30 degrees
(Controls available through RS-232 control and Quick-Connect CCU and Slot Card)
EZIM CCU Slot Card PN# 999-6900-006 - For Use with Quick-Connect CCU Only
999-6970-001 (Int’l)
Horizontal: 65º Wide End to 2.2º Tele
(16:9 Aspect Ratio)
A
PPENDIX 1: YPBPR VIDEO PIN-OUT FOR THE
Pin YPbPr
1 Pr
2 Y
3 Pb
4 5 6 Pr GND
7 Y GND
8 Pb GND
9 10 GND
11 12 13 14 15 -
HD-22/30 C
AMERA
PowerVIEW HD-22 and HD-30 HD PTZ Cameras Document Number 342-0626 Rev A Page 11 of 16
PowerVIEW HD-22 and HD-30
EZCamera Power & HD Video RJ-45 Connector Pin-outs
Important Note: The EZ Power and HD Video RJ-45 Connector is for use with the Quick-Connect SR,
Quick-Connect DVI/HDMI SR and Quick-Connect USB Interfaces ONLY (568B Wiring Standard).
The video signals are differential (HSDS™) and can only be received by the interfaces above.
Pin YPbPr
1 Power+
2 Power-
3 Y+
4 PB+
5 PB -
6 Y -
7 PR+
8 PR-
EZ POWER
HD VIDEO
12345678
Drawing: PowerVIEW HD-22/30 Dimensions
Optional Accessories:
Wall Mount
Bracket
535-2020-230
15-pin to Male BNC Output Cables
440-5600-001 (3 ft.)
440-5600-002 (6 ft.)
440-5600-003 (7 inch.)
PowerVIEW HD-22 and HD-30 HD PTZ Cameras Document Number 342-0626 Rev A Page 12 of 16
PowerVIEW HD-22 and HD-30
COMMUNICATION SPECIFICATION
Communication Speed: 9600 bps (default)
Start bit: 1
Stop bit: 1
Data bits: 8
Parity: None
No Flow control
12345678
Pin # RJ-45 RS-232 and IR Out Pins
1) Unused
2) Unused
3) Unused
4) IR Output (Diff Signal to Quick-Connect SR)
5) IR Ground (Diff Signal to Quick-Connect SR)
6) GND (GND of IR Short Range - Pin 3)
7) RXD (from TXD of control source)
8) TXD (to RXD of control source)
NOTE: The Vaddio PowerVIEW HD-22 and 30Control Protocol is similar, but not identical to, the Sony®
VISCA™ command set in order to be compatible with several popular control devices. Not all VISCA commands
are supported and there are many HD-22/30 specific commands in the following Command and Inquiry Lists.
HD-22/30 Command List (1/2)
Command Set Command Command Packet Comments
Address Set Broadcast 88 30 01 FF Address Set (Daisy chain)
IF_Clear Broadcast 88 01 00 01 FF IF Clear
Command Cancel 8x 2p FF p:socket number(1,2)
CAM_Power On
CAM_Zoom Stop
CAM_Focus Stop
CAM_WB Auto
CAM_RGain Reset
CAM_BGain Reset
CAM_AE Full Auto
CAM_Iris Reset
CAM_Gain Reset
CAM_Backlight On
CAM_Aperture Reset
Off(Standby)
Tele(Standard)
Wide(Standard)
Tele(Variable)
Wide(Variable)
Direct
Far(Standard)
Near(Standard)
Far(Variable)
Near(Variable)
AutoFocus
ManualFocus
Auto/Manual
Direct
Indoor
Outdoor
One Push WB
Manual
Fluorescent
One Push Trigger
Up
Down
Direct
Up
Down
Direct
Manual
Up
Down
Direct
Up
Down
Direct
Off
Up
Down
Direct
8x 01 04 00 02 FF
8x 01 04 00 03 FF
8x 01 04 07 00 FF
8x 01 04 07 02 FF
8x 01 04 07 03 FF
8x 01 04 07 2p FF
8x 01 04 07 3p FF
8x 01 04 47 00 0p 0q 0r FF
8x 01 04 08 00 FF
8x 01 04 08 02 FF
8x 01 04 08 03 FF
8x 01 04 08 2p FF
8x 01 04 08 3p FF
8x 01 04 38 02 FF
8x 01 04 38 03 FF
8x 01 04 38 10 FF
8x 01 04 48 0p 0q 0r 0s FF
8x 01 04 35 00 FF
8x 01 04 35 01 FF
8x 01 04 35 02 FF
8x 01 04 35 03 FF
8x 01 04 35 05 FF
8x 01 04 35 06 FF
8x 01 04 10 05 FF
8x 01 04 03 00 FF
8x 01 04 03 02 FF
8x 01 04 03 03 FF
8x 01 04 43 00 00 0p 0q FF
8x 01 04 04 00 FF
8x 01 04 04 02 FF
8x 01 04 04 03 FF
8x 01 04 44 00 00 0p 0q FF
8x 01 04 39 00 FF
8x 01 04 39 03 FF
8x 01 04 0B 00 FF
8x 01 04 0B 02 FF
8x 01 04 0B 03 FF
8x 01 04 4B 00 00 0p 0q FF
8x 01 04 0C 00 FF
8x 01 04 0C 02 FF
8x 01 04 0C 03 FF
8x 01 04 4C 00 00 0p 0q FF
8x 01 04 33 02 FF
8x 01 04 33 03 FF
8x 01 04 02 00 FF
8x 01 04 02 02 FF
8x 01 04 02 03 FF
8x 01 04 42 00 00 0p 0q FF
Power On/Off
p:(1-Slow to 4-Fast)
p:(1-Slow to 4-Fast)
pqr: Zoom Position*
p:(1-Slow to 4-Fast)
p:(1-Slow to 4-Fast)
pqrs: Focus position(0-0x438)*
Normal Auto (Auto Tracing WB)
Indoor Mode (Color Temp 3200K)
Outdoor Mode (Color Temp 5600K)
One Push White Balance Mode
Manual White Balance
Fluorescent(Color Temp 4200K)
One Push WB Trigger
pq:00-ff
pq:00-ff
Auto Exposure Mode
Manual Control Mode
pq(0x00-0xFF)
pq(0x00-0xFF)
pq(0x00-0x3F)
*Zoom and Focus Data:
CAM_Zoom: Range (0x000–0xA23/0xA73), HD22: 0xA23(22x Zoom), HD30: 0xA73(30x Zoom)
CAM_Focus: Ran ge (0x000-0x438) dependent on Zoom Position
PowerVIEW HD-22 and HD-30 HD PTZ Cameras Document Number 342-0626 Rev A Page 13 of 16
PowerVIEW HD-22 and HD-30
HD-22/30 Command List (2/2)
Command Set Command Command Packet Comments
CAM_Memory Reset
Set
Recall
CAM_IDWrite 8x 01 04 22 0p 0q 0r 0s FF pqrs:0x0000 – 0xFFFF
CAM_LR_Reverse On
Off
CAM_Freeze On
Off
CAM_PictureEffect Color
B&W
Pan-tiltDrive Up
Down
Left
Right
UpLeft
UpRight
DownLeft
DownRight
Stop
Absolute Position
Home
Reset
Tally On
Off
Preset Pan Speed Pan/Tilt/Zoom Speed 8x 01 7E 01 0B WW SS ZZ FF WW: Pan Speed (0x01-0x18)
Motor Config Hard Motor Stops
Soft Motor Stops
BLK.Enhance Pedestal 8x 01 7E 53 00 00 0p 0q FF Pq: Pedestal(0x00-0xFF)
GMA.Enhance Gamma 8x 01 7E 54 00 00 0p 0q FF pq: Gamma (0x00-0x03)
CRM.Enhance Chroma 8x 01 7E 55 00 00 0p 0q FF pq: Chroma (0x00-0xFF)
KNE.Enhance Knee No Support No Support
DIS.Enhance Digital Image
Stabilizer
DNR.Enhance Digital Noise
Reduction
AGC.Enhance AGC Mode 8x 01 7E 59 00 FF
CAM_Shutter No Support No Support No Support
CAM_ICR ICR Off
ICR On
8x 01 04 3F 00 0p FF
8x 01 04 3F 01 0p FF
8x 01 04 3F 02 0p FF
8x 01 04 61 02 FF
8x 01 04 61 03 FF
8x 01 04 62 02 FF
8x 01 04 62 03 FF
8x 01 04 63 00 FF
8x 01 04 63 04 FF
8x 01 06 01 VV WW 03 01 FF
8x 01 06 01 VV WW 03 02 FF
8x 01 06 01 VV WW 01 03 FF
8x 01 06 01 VV WW 02 03 FF
8x 01 06 01 VV WW 01 01 FF
8x 01 06 01 VV WW 02 01 FF
8x 01 06 01 VV WW 01 02 FF
8x 01 06 01 VV WW 02 02 FF
8x 01 06 01 VV WW 03 03 FF
8x 01 06 02 VV WW
0Y 0Y 0Y 0Y 0Z 0Z 0Z 0Z FF
8x 01 06 04 FF
8x 01 06 05 FF
8x 01 7E 01 0A 00 02 FF
8x 01 7E 01 0A 00 03 FF
8x 01 7E 01 70 00 00 FF
8x 01 7E 01 70 00 01 FF
8x 01 7E 57 02 FF
8x 01 7E 57 03 FF
8x 01 7E 58 02 FF
8x 01 7E 58 03 FF
8x 01 7E 59 01 FF
8x 01 7E 59 02 FF
8x 01 7E 59 03 FF
8x 01 7E 59 04 FF
8x 01 7E 59 05 FF
8x 01 7E 59 06 FF
8x 01 7E 59 07 FF
8x 01 7E 59 00 0p FF
8x 01 04 01 02 FF
8x 01 04 01 03 FF
p:Memory No(=0-0xF)
Mirror (Horizontal) on
Mirror (Horizontal) off
Still image on
VV: Pan Speed (0x01-0x18)
WW: Tilt Speed(0x01-0x14)
YYYY: Pan Position**
ZZZZ: Tilt Position**
SS:Tilt Speed(0x01-0x14)
ZZ:Zoom Speed(0-7);
On
Off
On
Off
Off Manual AGC Gain (0dB)
Low
Medium
High
Low1
Low2
Med1
High1
Off p: Manual AGC Gain(1-0x0e)***
ICR Off Color
ICR On Black and White
**Additional Information:
Pan Range: 8044 – 7FBC (-32,700 to +32,700)
Tilt Range: E891 – 4C2B (-5,999 to +19,499)
Actual Pan/Tilt ranges defined in Inquiry list
PowerVIEW HD-22 and HD-30 HD PTZ Cameras Document Number 342-0626 Rev A Page 14 of 16
PowerVIEW HD-22 and HD-30
HD-22/30 Inquiry List (1/1)
Inquiry Command Command Response Packet Comments
CAM_PowerInq 8x 09 04 00 FF y0 50 02 FF
CAM_ICRModeInq 8x 09 04 01 FF y0 50 02 FF
CAM_BacklightModeInq 8x 09 04 33 FF y0 50 02 FF
CAM_WBModeInq 81 09 04 35 FF y0 50 00 FF
CAM_AEModeInq 8x 09 04 39 FF y0 50 00 FF
CAM_LR_Reverse 8x 09 04 61 FF y0 50 02 FF
CAM_Freeze 8x 09 04 62 FF y0 50 02 FF
CAM_PictureEffect 8x 01 04 63 FF y0 50 00 FF
CAM_MemoryInq 8x 09 04 3F FF y0 50 0p FF p:Preset 0-0xf
CAM_IDInq 8x 09 04 22 FF y0 50 0p 0q 0r 0s FF pqrs:0x0000 – 0xFFFF
CAM_ApertureInq 8x 09 04 42 FF y0 50 00 00 0p 0q FF Pq:x00-0x3F
CAM_RGain 8x 09 04 43 FF y0 50 00 00 0p 0q FF pq:000-0ff
CAM_BGain 8x 09 04 44 FF y0 50 00 00 0p 0q FF pq:000-0ff
CAM_ZoomPosInq 8x 09 04 47 FF y0 50 0p 0q 0r 0s FF pqr: 0-0x6B3
CAM_FocusPosInq 8x 09 04 48 FF y0 50 0p 0q 0r 0s FF pqrs: Focus Position
CAM_FocusModeInq 8x 09 04 38 FF y0 50 02 FF
CAM_Gain 8x 09 04 4C FF y0 50 00 00 0p 0q FF pq(0x00-0x24)
CAM_IRReceiveInq 8x 09 06 08 FF y0 50 02 FF
Pan-TiltMaxSpeedInq 8x 09 06 11 FF y0 50 pp qq FF pp:Pan 0x01-0x18
Pan-tiltPositionInq 8x 09 06 12 FF FF y0 50 0p 0p 0p 0p 0q 0q 0q 0q FF pppp: Pan 0x8044-0x7FB2
CAM_ShutterPosInq No support No support Shutter Position
TallyInq 8x 09 7E 01 0A FF y0 50 02 FF
PresetSpeedInq 8x 09 7E 01 0B FF y0 50 pp qq rr FF pp:Pan 0x01-0x18
Motor Config 8x 09 7E 01 70 FF y0 50 00 FF
BLK.Enhance 8x 09 7E 53 FF y0 50 00 00 0p 0q FF pq: Pedestal(0x00-0xFF)
GMA.Enhance 8x 09 7E 54 FF y0 50 00 00 00 0p FF p: Gamma (0x00-0x03)
CRM.Enhance 8x 09 7E 55 FF y0 50 00 00 0p 0q FF p: Chroma (0x00-0xFF)
KNE.Enhance No support No Support Knee
DIS.Enhance 8x 09 7E 57 FF y0 50 02 FF
DNR.Enhance 8x 09 7E 58 FF y0 50 02 FF
AGC.Enhance 8x 09 7E 59 FF
8x 09 7E 59 00 FF
y0 50 03 FF
y0 50 03 FF
y0 50 03 FF
y0 50 01 FF
y0 50 02 FF
y0 50 03 FF
y0 50 05 FF
y0 50 06 FF
y0 50 03 FF
y0 50 03 FF
y0 50 03 FF
y0 50 04 FF
y0 50 03 FF
y0 50 03 FF
y0 50 03 FF
y0 50 01 FF
y0 50 03 FF
y0 50 03 FF
y0 50 00 FF
y0 50 01 FF
y0 50 02 FF
y0 50 03 FF
y0 50 04 FF
y0 50 05 FF
y0 50 06 FF
y0 50 07 FF
y0 50 0p FF
On
Off(Standby)
On - ICR filter Out
Off – ICR filter In
On
Off
Auto
Indoor
Outdoor
One Push WB
Manual
Fluorescent
Auto Exposure Mode
Manual Control Mode
On
Off
On
Off
Off
B&W
Auto
Manual
On
Off
qq:Tilt 0x01-0x14
qqqq: Tilt 0xE890-0x4C2C
On
Off
qq:Tilt 0x01-0x14
rr:Zoom 0x00-0x07
Hard Motor Stops
Soft Motor Stops
On
Off
On
Off
Off Manual AGC Gain(0dB)
Low
Medium
High
Low1
Low2
Med1
High1
Off p: Manual AGC Gain(0-0x0e)***
***Manual AGC Gain: 0:0dB, 1:3dB, 2:6dB, 3:9dB, 4:12dB, 5:15dB, 6:18dB, 7:21dB, 8:24dB, 9:27dB, 10:30dB, 11:33dB,
12:36dB, 13:39dB & 14:42dB
PowerVIEW HD-22 and HD-30 HD PTZ Cameras Document Number 342-0626 Rev A Page 15 of 16
PowerVIEW HD-22 and HD-30
©2013 Vaddio - All Rights Reserved. Reproduction in whole or in part without written permission is prohibited. Specifications and pricing are subject to
change without notice or obligation. Vaddio, PowerVIEW, ProductionVIEW, WallVIEW, EZCamera, Quick-Connect and HSDS are trademarks of Vaddio. All
other trademarks are property of their respective owners. Document Number 342-0626 Rev A
PowerVIEW HD-22 and HD-30 HD PTZ Cameras Document Number 342-0626 Rev A Page 16 of 16
Toll Free: 800-572-2011 ▪ Phone: 763-971-4400 ▪ FAX: 763-971-4464
www.vaddio.com
Loading...
