ClearVIEW HD-19

INSTALLATION AND USER GUIDE

AADDDDIIO

™

AALLL

VVIIEEW

™

HHDD--119

DDVVII//HHDDM

MII

With Quick-Connect™ DVI/HDMI - SR with HSDS™ and the CONCEAL Wall Mounting System for the Vaddio™ HD-19 Robotic Pan/Tilt/Zoom Camera

Quick-Connect DVI/HDMI SR Interface

PN: 998-1105-018

Arctic White Version Part Number 999-6946-000AW (North America) Part Number 999-6946-001AW (International)

Black Version Part Number 999-6946-000 (North America) Part Number 999-6946-001 (International)

WallVIEW HD-19 DVI/HDMI

Inside Front Cover - Blank

WallVIEW HD-19 DVI/HDMI Manual 342-0267 Rev. C Page 2 of 24

WallVIEW HD-19 DVI/HDMI

Overview:

The WallVIEW HD-19 HD PTZ camera and Quick-Connect DVI/HDMI EZCamera™ Cat-5e cabling system using HSDS™, is a system that allows for easy installation and integration of a camera system capable of simultaneous HD analog YPbPr and composite (CVBS). The HD-19 camera is built around a 1/3-type high-speed Exmor CMOS image sensor with a total of 1.3 Megapixels and a 19X optical zoom lens, making it the ideal choice for a wide range of high definition video applications including, 720p, 1080i or 1080p.

Because the camera module is built around a new, high speed CMOS image sensor with an increased pixel aperture size, high frame rate, high signal to noise while using the column-parallel A/D conversion method, the resolution, saturation and the sensitivity of the sensor is increased. The HD-19 achieves improved picture quality even in low light environments requiring a minimum

WallVIEW HD-19 PTZ Camera and CONCEAL Wall Mounting System

illumination rated at an astonishing 0.7 LUX (F1.6 - 50IRE). The WallVIEW HD-19 is available in Black and in Arctic White and is equipped with a slip-clutch mechanism for

smooth pan/tilt operation and control. The HD-19 outputs HD video (YPbPr at 1080p/60/59.94/50/30/25, 1080i/59.94/50, 720p/59.94/50, 480i/30fps and 576i/25fps) and SD video (CVBS at 480i/NTSC or 576i/PAL) simultaneously.

The HD-19 is paired with the Quick-Connect DVI/HDMI SR Interface, which provides power to the camera and returns HSDS video from the camera up to 100’ (30.5m) over a single Cat-5e cable. The Quick-Connect DVI/HDMI features extended control functions including Daisy Chain Control Emulation (DCCE™), which allows single control port codecs to control multiple HD-19 cameras, and IR forwarding in modulated and non-modulated formats for extending the reach of the IR remotes included with today’s most popular videoconferencing systems. The WallVIEW HD-19 is an exceptional camera for a wide range of HD video applications such as houses of worship, corporate boardrooms, live events and distance-learning.

Intended Use:

Before operating the device, please read the entire manual thoroughly. The system was designed, built and tested for use indoors, and with the provided power supply and cabling. The use of a power supply other than the one provided or outdoor operation has not been tested and could damage the device and/or create a potentially unsafe operating condition.

Important Safeguards:

Read and understand all instructions before using. Do not operate any device if it has been dropped or damaged. In this case, a Vaddio technician must examine the product before operating. To reduce the risk of electric shock, do not immerse in water or other liquids and avoid extremely humid conditions.

Use only the power supply provided with the system. Use of any unauthorized power supply will void any and all warranties.

Please do not use “pass-thru” type RJ-45 connectors. These pass-thru type connectors do not work well for professional installations and can be the cause of intermitten t connections which can result in the RS-232 control line failing and locking up, and/or com promising the HSDS™ signals. For best results please use standard RJ-45 connectors and test all cables for proper

in-outs prior to use and connection to Vaddio product.

Save These Instructions:

The information contained in this manual will help you install and operate your product. If these instructions are misplaced, Vaddio keeps copies of Specifications, Installation and User Guides and most pertinent product drawings for the Vaddio product line on the Vaddio website. These documents can be downloaded from

www.vaddio.com free of charge.

WallVIEW HD-19 DVI/HDMI Manual 342-0267 Rev. C Page 3 of 24

WallVIEW HD-19 DVI/HDMI

UNPACKING:

Carefully remove the device and all of the parts from the packaging. Unpack and identify the following parts for 999-6946-000:

 One (1) ClearVIEW HD-19 HD PTZ Camera  One (1) Vaddio IR Remote Commander  One (1) Quick-Connect DVI/HDMI SR Interface One (1) Laird Technologies 28A2432-0A2 Clamp-on Ferrite Cylinder (Wrap IR forwarding

LED wires twice before screwing stripped wire ends to 3 conductor Molex Euro Jack)

 Two (2) Laird Technologies 28A0640-0A2 Clamp-on Ferrite (Clamp around 0.8" diameter DVI Cable at the Quick-Connect DVI end)  One (1) Laird Technologies HFA163090-0A2 Clamp-on Ferrite (Clamp around 0.8" diameter shielded DVI Cable at the Monitor end)  One (1) Vaddio PowerRite™ 24 VDC, 2.0 Amp Power Supply  One (1) 998-1001-232 EZCamera Control Adapter (for control systems)  One (1) 998-1002-232 EZCamera Control Adapter (for TANDBERG VC systems) One (1) 3-pos Phoenix type connector  One (1) CONCEAL Wall Mounting System and Mounting Hardware  One (1) AC Cord Set for North America  Documentation

(Note: The 999-6946-001 Int’l Version includes the Euro and UK power cables)

ClearVIEW HD-19 PTZ Camera, Front View with Feature Call-outs:

①

②

④

③

1) Camera and Zoom Lens:

The 19X optical zoom lens is built around a 1/3-type high-speed CMOS image sensor with a total of 1.3 Megapixels for precise HD video image acquisition.

2) Red Tally Light:

A red tally light is illuminated when the camera receives a VISCA command from an external control system.

3) IR Sensors:

IR sensors are built into the front of the ClearVIEW HD-19 to receive IR signals from the IR remote control supplied with the camera as well as other 3

party remotes for the IR forwarding feature.

4) Blue Power Light:

A Vaddio blue power light is illuminated when the camera is turned on.

Compatible Vaddio Switchers and Joystick Controllers:

ProductionVIEW™ HD MV

(999-5625-000)

AutoPresenter

(999-5675-000)

Precision Camera Controller

WallVIEW HD-19 DVI/HDMI Manual 342-0267 Rev. C Page 4 of 24

WallVIEW HD-19 DVI/HDMI

ClearVIEW HD-19 PTZ Camera, Rear View with Feature Call-outs:

5) RS-232 IN & IR Out:

The RS-232 accepts modified VISCA protocol for camera control, as well as transmits IR signaling received by the IR receivers, which can be transmitted to third party devices.

6) Dip Switch Settings:

Settings for IR remote, baud rate, SD output format, and image flip can be configured on these switches. See page 5 for additional information on switch settings.

7) HD Video Select:

A rotary switch allows the user to choose the component HD output video resolution and format. See page 6 for additional information on switch settings.

8) 12 VDC Input:

Power input for the standard, ClearVIEW HD-19 camera power supply.

9) YPbPr Output:

Component HD video is fed through the DB-15 connector. YPbPr and Composite signals are simultaneous. This is an HD camera and the SD signals are down converted and are really not the sweet spot of this camera.

10) Composite Video (CVBS) Output: The CVBS output feeds out SD video signals and is configurable with the dip switches to choose between 480i/NTSC or 576i/PAL in 4:3 formats. Squeeze and letterbox modes are also available (see dipswitches 6&7).

11) EZ Power/Video Port:

This RJ-45 connector is only used with the Quick-Connect SR Interface and the Quick- Connect DVI-D/HDMI SR Interface to supply power and return HSDS video from the camera.

12) Slot for Optional Cards:

Optional slot cards can be plugged into the ClearVIEW HD-19 camera (the HD-SDI Slot Card and the EZIM CCU Slot Card are available separately).

⑤

⑥

⑦

⑧

⑨

⑩

⑪

⑫

WallVIEW HD-19 DVI/HDMI Manual 342-0267 Rev. C Page 5 of 24

WallVIEW HD-19 DVI/HDMI

Quick-Connect DVI/HDMI - SR Interface I/O Description

①

1) Blue LED Power Indicator.

2) 24 VDC Power Port: Coax Power Connector, 5.5mm OD x 2.5mm ID, Positive Center.

3) Recessed Color Space Conversion Switch: Toggles between HDMI YCbCr and sRGB (RGBHV) color

4) RS-232 Control Input (from joystick controller, codec or control system).

5) To Camera: RS-232 Control to & from Camera and IR signals returned from the camera.

6) Daisy Chain Control Port: Daisy Chain Control Emulation (DCCE) output to next Quick-Connect DVI/HDMI

7) IR Output Port: Non-modulated (for hard connections) and Modulated for use with IR emitters.

8) DVI-D Output: High Definition Multimedia Interface (HDMI) Transmitter, HDMI (v 1.3 with deep color) and

9) YPbPr Output: Analog Component Video Output on DE-15F (HD-15F) Connector, Resolutions up to

10) EZCamera Power & HD Video Port: Supplies power to camera and return s HD video from the camera via

Installation Basics:

The WallVIEW HD-19 product was designed for installation on a vertical wall surface with Cat-5e cable connectivity for Power, Video and Control signaling (two Cat-5e cables are required). Installation is simplified in that no custom 8-Pin mini-din cables or expensive coax plenum cables are needed and no power outlets are required near the camera bracket. All cabling is routed to the head-end using Cat-5e cables.

Before Installing:

 Locate the camera mounting location paying close attention to camera viewing angles, lighting conditions,

 The CONCEAL Wall Mounting System for the WallVIEW HD-19 can be mounted directly to a 2-gang wall box

RS-232 Cabling: For RS-232, use a standard Cat-5e cable and RJ-45 connectors (568B termination) from the RS-232 port on the back of a Vaddio camera controller or switcher. If the camera is connected to a third-party control system (such as AMX or Crestron), a DB-9 to RJ-45 control adapter cable is supplied. Use of pass-thru type RJ-45

connectors is highly discouraged. The Vaddio Cat-5e wiring standard uses pins 7 and 8 on both the video and the control Cat-5e cables. The pass-through connectors have proven to provide insufficient connectivity for these important signals. They are “ok” for voice and data, but not for video and control.

Videoconferencing Codecs and RS-232:

Depending on the codec and RS-232 port used, special DB-9 to RJ-45 adapters may sometimes be required. Refer to Vaddio’s price list or website for Tech Notes on the WallVIEW HD-19 page on specific diagrams for wiring the camera to videoconferencing codecs. Any special adapters and configuration information will be noted.

Remember to always power up the cameras before booting up the codec.

③

②

space. Change the color space to accommodate either YCbCr or RGBHV monitors.

SR Interface (does not function with the AutoTrak System).

DVI v 1.0 Compliant - use Recessed Color Space Conversion Switch to toggle between HDMI YCbCr and sRGB (RGBHV) color spaces to suit your monitors

1080p/60 with monitor support. Cat-5e. Maximum distance on the Cat-5e cable is 100’ (30.5 m).

possible line of site obstructions, and checking for in-wall obstructions where the camera is to be mounted. Pick a mounting location that will optimize the performance of the camera.

or can be mounted to the drywall using the supplied four (4) drywall anchors.

④⑤ ⑥

⑦

⑨⑧

⑩

WallVIEW HD-19 DVI/HDMI Manual 342-0267 Rev. C Page 6 of 24

WallVIEW HD-19 DVI/HDMI

First Time Set-up with the HD-19:

The ClearVIEW HD-19 was designed to be exceptionally easy to use and operate. There is documentation at the back of the manual for pin-outs for all of the connectors on the ClearVIEW HD-19 camera.

Step 1: Using the HD Video Select Rotary Switch and Camera Settings Dip Switch on the back of the camera, set up the camera’s output resolution and functional preferences. There is a label on the bottom of the camera that identifies the choices.

HD Video Select Switch Camera Settings 10-Pos Dip Switch

HD-19 Rear Panel

Label on the Bottom of HD-19

IR 1

1 & 2 UP

IR 2ONIR 3

1234

DIP SWITCH SETTINGS

IR OUT OFF

9600

bps

38400

bps

NTSC

PAL


SD 4:3

SD LB

FLIP OFF

ON ON

6 & 7 UP

68109

TEST

BARS

OFF

910

1 2 3 4 5 6 7

HD VIDEO SELECT

720p/59.94

1080i/59.94

1080p/59.94

1080p/60

720p/50

1080i/50

1080p/50

480i/29.97

576i/25

8 9 A B C D

1080p/30

1080p/25

 Set the HD output resolution for the camera with the Rotary Switch.  Set the IR frequency of the camera if it is to respond to the IR remote control.  If using RS-232 for control, leave the IR OUT OFF (SW3) and choose 9600 bps  If using the IR forwarding feature, turn the IR OUT ON (SW3).  If inverting the camera, turn the IMAGE FLIP ON (SW8).

Dip Switch Settings:

 IR 1 & 2: The IR remote has the capability of operating up to three different PTZ cameras from one

remote. Use the selector buttons at the top of the IR remote to select the frequency.

 IR Out 3: The IR output is sent out on the RS-232 RJ-45 jack on the back of the camera. Turning on the

IR output will allow IR signals to be transmitted over the Cat-5e cable to the head end. When using RS232 control or Vaddio CCU controllers (also via RS-232), turn the IR OUT to OFF.

 Baud Rate 4: The options for baud rate are either 9600 bps or 38,400 bps. Default is 9600 bps.  SD Format 5: Choose between NTSC or PAL formats  SD Configurations 6 & 7: SD video can be set to standard 4:3, squeeze mode or letterbox mode.  Image Flip 8: To invert the HD-19, turn the IMAGE FLIP ON (switch down).  Test Bars 9: Turning on the non-standard test bars will override the camera video output. These non-

standard test bars are 75% IRE.

 Switch 10: Leave up - or in the OFF position

WallVIEW HD-19 DVI/HDMI Manual 342-0267 Rev. C Page 7 of 24

WallVIEW HD-19 DVI/HDMI

S-232 on Cat-5e

bPr

System Connectivity Example 1:

Basic system connectivity of a Vaddio WallVIEW™ DVI/HDMI HD-19 and Quick-Connect DVI/HDMI SR Interface with Vaddio ProductionVIEW™ Precision Camera Controller and PreVIEW HD Monitors.

WallVIEW DVI/HDMI HD-19 System

Power to Camera HSDS Video from Camera - Cat-5e

Two (2) - Cat-5e Cables Total - Up to 100’ (30.48m)

Quick-Connect DVI/HDMI SR Interface

RS-232 Control - Cat-5e

YPbPr & Power on one (1) Cat-5e up to 100’ (30.5m)

Dancing Bear Camera (Simulated Feed)

*HDMI with

Adapter Cable

WallVIEW HD-19 DVI/HDMI Manual 342-0267 Rev. C Page 8 of 24

Vaddio Precision Camera Controller

(Up to 7 PTZ Cameras can be controlled)

* The Recessed Color Space

Conversion Switch enables the use of either HDMI YCbCr or DVI-D sRGB (RGBHV) color space for added flexibility.

Large Format HDMI Monitor

Vaddio PreVIEW™ HD 7.0 Rack Monitors

(Simulated Video Feeds)

(Simulated Video Feed)

WallVIEW HD-19 DVI/HDMI

(

)

(

)

System Connectivity Example 2: System connectivity of two (2) Vaddio HD-19 cameras and two (2) QuickConnect DVI/HDMI SR Interfaces configured with single control port codec and Daisy Chain Control Emulation (DCCE).

Quick-Connect

DVI/HDMI SR

Interfaces

Codec IR Remote: Forwarded through Main Camera for Codec Control

RS-232

DVI to HDMI Cable

RS-232 & IR Return Cat-5e

WallVIEW DVI/HDMI HD-19

HD Camera Systems

Power to Camera HD Video from Camera - Cat-5e

Two (2) - Cat-5e Cables - up to 100’

RS-232 Daisy Chain Link between

Quick-Connect Interfaces

DVI Cable

30.48m

Power to Camera HD Video from Camera - Cat-5e

RS-232 & IR Return Cat-5e

Two (2) - Cat-5e Cables - up to 100’

30.48m

Computer with DVI Output

ETHERNET

Monitor 1

HDMI

DVI-D

Monitor 2

C60 Codec

Single RS-232 Port Codec with Daisy Chain Camera Control

Microphones

Mounting and Installation Instructions for the CONCEAL Wall Mounting System: Step 1: Determine Camera Mount Location

Note: When locating the camera, consider viewing angles, lighting conditions, possible line of site obstructions and check for in-wall obstructions where the camera is to be mounted. Pick a mounting location to optimize the performance of the camera.

The 2 (two) Cat-5e cables should feed-through a 1” (25.4mm) opening (circular or square shape) centered in the rectangular slot located on the rear flange of the CONCEAL Wall Mount Bracket (see Fig. 1).

Note: Do not cut out the entire rectangular slot opening in the wall! This will not allow the two (2) lower wall anchors to correctly fasten the Conceal Wall Mount to the wall.

If the bracket is to be mounted on a 2-gang wall box, use the screws supplied with the wall box cover plate to attach the CONCEAL Wall Mount Bracket.

HD Video Monitors

(Simulated Video Feeds)

Fig. 1: CONCEAL Wall Mount Bracket:

Cabled and Attached to Wall

WallVIEW HD-19 DVI/HDMI Manual 342-0267 Rev. C Page 9 of 24

WallVIEW HD-19 DVI/HDMI

If mounting to drywall with wall anchors, use the four (4) quality wall anchors/screws provided (see Fig. 1). The mounting holes are slotted and are 90° opposing to provide easy leveling. Level the mount and tighten the mounting screws.

Step 2: System Connectivity:

1) Use the accompanying HD-19 manual to set the switch settings for HD video out resolution, IR frequency and output, baud rate, SD video format and shape, image orientation etc…

2) See “Connectivity Example 1” on page 6. This is the basic two (2) Cat-5e cable system where Power is sent to the camera and HD Video is returned from the camera on one Cat-5e (blue line) and RS-232 control communication and IR feed-through is returned from the camera (dashed grey line):

a. Connect the first Cat-5e cable from the EZCAMERA POWER & HD VIDEO RJ-45 jack on the Quick-

Connect to the EZ POWER VIDEO RJ-45 jack on the back of the camera

b. Connect the 2

Cat-5e cable from the RS-232 CONTROL “TO CAMERA” port to the RS-232 IN/IR OUT jack on the back of the HD-19 camera. Connect the control source (i.e. Vaddio’s Precision Camera Controller, ProductionVIEW HD, ControlVIEW™ XHD, AutoPresenter™ etc…) to the RS-232 CONTROL INPUT.

c. Connect the DVI-D output to a DVI-D video device (or HDMI with a DVI-D to HDMI adapter cable -

sold separately) and/or connect the YPbPr output to a different video destination device. Both the DVI-D and the YPbPr are live images at the same resolution which is set at the camera. The only difference is that the DVI-D signal is digital and the YPbPr is analog. Both are capable of 1080p/60Hz.

d. Check all Cat-5e cables for proper connection and check the cables for continuity in advance of final

connection. Please do not use the “feed-thru” or “EZ” type RJ-45 connectors for professional

installations (see page 3 for Important Safeguards).

Note: Plugging the EZCAMERA POWER & HD VIDEO Cat-5e cable into the wrong RJ-45 may cause damage to the camera system and void the warranty.

Step 3: SECURE THE CAMERA TO THE CONCEAL WALL MOUNT BRACKE T:

After all cables are attached to the camera, place the camera onto the camera mount and insert the two-(1/4”-20) screws into the camera through the two-screw holes in the bottom of the mount. Note: Be sure to align each

side of the camera evenly to all sides of the CONCEAL Wall Mount Bracket before final tightening of the mounting screws (see Fig. 2).

Fig. 2: Vaddio HD-19 Camera aligned

and attached to the CONCEAL Wall Mount Bracket

Step 4: INSTALL THE CONCEAL LOWER COVER PLATE:

Attach lower CONCEAL Lower Cover Plate (see Fig. 3). Slide lower cover plate from front of the mounting bracket toward the rear of the bracket. The two-rear locking tabs will need to be guided into position first and will lock in place as the lower cover plate is pushed toward the rear of the mounting bracket and the front tabs are inserted (see Fig. 4).

Fig. 3: CONCEAL Lower Cover Plate with Locking Tabs

Fig. 4: CONCEAL Lower Cover Plate locked in place

WallVIEW HD-19 DVI/HDMI Manual 342-0267 Rev. C Page 10 of 24

WallVIEW HD-19 DVI/HDMI

Step 5: CONNECT POWER AND TEST:

Connect the 24VDC, 2A power supply to the Quick-Connect and plug it into the wall once all the connections have been checked. The camera will “HOME” to a centered position. To ensure proper continuity of control and operation of the cameras, the RS-232 controller (control system, codec or joystick) should be powered ON after all of the cameras.

Note: Plugging the EZCAMERA POWER & HD VIDEO Cat-5e cable into the wrong RJ-45 may cause damage to the camera system and void the warranty.

Step 6: INSTALL THE CONCEAL REAR CAMERA COVER:

After successful testing of the camera, install the Conceal Rear Camera Cover on the CONCEAL Mounting Bracket with the supplied screw (see Fig. 5 and 6).

Fig. 5: CONCEAL Rear Camera Cover

Fig. 6: Completed CONCEAL Wall

Mount Camera Bracket Installation

RS-232 Cabling

For RS-232, use a standard Cat-5e cable (568B termination for RJ-45 connectors) from the RS-232 port on the back of a Vaddio ProductionVIEW camera controller or switcher. If the camera will be connected to a third-party control system (such as AMX® or Crestron®), a DB-9 to RJ-45 adapter cable is supplied with the camera for RS-

232.

Videoconference Codecs and RS-232

Depending on the codec that is used, and which RS-232 port is used with a codec, special DB-9 to RJ-45 adapters may sometimes be required. Refer to Vaddio’s price list or website for Tech Notes on the HD-19 page on specific diagrams for wiring the camera to videoconference codecs.

Remember to always power up the cameras before booting up the codec.

Step 7: Connect the HD Video Outputs (DVI or HDMI with adapter cable - or - analog HD YPbPr video) into a display device or video console. Please make sure that the video console or the display device is set up to receive the HD camera resolution that was chosen with the rotary switch on page 6. Most monitors are automatic, however all consoles will need set-up prior to termination.

Step 8: Connect the Vaddio 24 VDC, 2.0A power supply to the POWER Connector on the Quick-Connect and plug the power adapter into an AC outlet. Power will travel down the Power/Video Cat-5e cable to the camera. The camera will “Home” to a centered position, return HSDS video back to the Quick-Connect and is ready for control from the IR remote or RS-232 camera controller. Boot Order: Always turn the cameras on first, then

the controller or codec.

WallVIEW HD-19 DVI/HDMI Manual 342-0267 Rev. C Page 11 of 24

WallVIEW HD-19 DVI/HDMI

Daisy Chain Configurations/Installation Instructions: In some cases, daisy chain control situations just can’t be avoided. Because of this, Vaddio added “Daisy Chain Control Emulation” or DCCE™ to the Quick-Connect DVI/HDMI - SR Interface in order to use the HD-19 camera in these situations. See Connectivity Example 2 (previous page) where the codec requires daisy chain control wiring.

1) For daisy chain control, first complete steps above, since all the cabling between the camera and the QuickConnect DVI/HDMI Interface is the same.

2) Instead of running a cable from the 1 Connect DVI/HDMI Interface’s RS-232 CONTROL DAISY CHAIN RJ-45 jack, to the 2

camera to the 2nd camera, run a Cat-5e patch cable from the 1st Quick-

Quick-Connect DVI-

HDMI SR Interface’s RS-232 CONTROL INPUT RJ-45 jack.

3) Within the modified VISCA® protocol that the codec and the HD-19 use, the 1

in the chain will set up as Camera #1, the second will set up as Camera #2 in the chain, allowing the codec IR remote to select which camera it will switch to and which to control.

4) In the case of TANDBERG codecs, use the IR Modulated output of the Quick-Connect and a Xantech IR emitter (282D or 283D) and attach the emitter to the front panel of the codec (in front of the IR receiver).

5) Polycom codecs with IR receivers can connect the IR feed-through the same way as the TANDBERG, but do not use daisy chain control. Several Polycom codecs can also be connected directly with the non-modulated signal to the codec’s IR signal input port.

Basic Daisy Chain Connectivity:

RS-232

To Camera

RS-232

To Camera

Daisy Chain Port Out

RS-232 Control IN

RS-232

RS-232 from Codec

Single Control Port

WallVIEW HD-19 DVI/HDMI Manual 342-0267 Rev. C Page 12 of 24

WallVIEW HD-19 DVI/HDMI

General Specifications:

WallVIEW DVI/HDMI HD-19

Part Numbers

WallVIEW HD-19 (North America) P/N: 999-6946-000 (Black), 999-6946-000AW (Arctic White) WallVIEW HD-19 (International) P/N: 999-6946-001(Black), 999-6946-001AW (Arctic White)

addio HD-19

Image Sensor 1/3-Type Exmor High-speed, Progressive Scan CMOS Sensor with 1.3 Megapixels Video Output

Resolutions

HD: 1080p/60/59.94/50/30/25, 1080i/59.94/50, 720p/59.94/50 SD: 480i/NTSC & 576i/PAL (Crop, Squeeze or Letterbox mode) Color: The Recessed Color Space Conversion Switch enables the use of either HDMI YCbCr or

DVI-D sRGB (RGBHV) color space for added flexibility. Lens/ Focal Length 19X Optical Zoom, F=4.5mm wide to 85mm tele end (F1.6-F2.9), Min. Focus Distance 1.0m Horizontal Viewing Angle 58.1° Wide End to 3.2° Tele End - 16:9 Format Video S/N Ratio >52 dB Minimum Illumination 0.7 LUX (F1.6, 50IRE) Serial Control Protocol RS-232 (Modified VISCA) Pan Range Pan: +170 degrees to -170 degrees, Tilt: +90 degrees to -30 degrees, Invertible for Ceiling

Mount Preset Positions 16 (internal), 6 recalled via IR Remote Tally Light Available through RS-232 Control Connectors

 12 VDC Power Input: EIAJ-04 Coaxial Power Connector

 HD Video Outputs: YPbPr on DE-15 (D-Sub 15-pin HD)

 SD Video Output: BNC Connector

 RS-232/IR Out: RJ-45 Jack (RS-232 Communication and IR Out (with Quick-Connect -SR

Interfaces)

 EZ Po wer HD Video: RJ-45 Jack, for use with Quick-Connect SR Interface or Quick-

Connect DVI/HDMI SR Interface. Supplies power to the camera and returns HD video from

the camera to the Quick-Connect - SR Systems. HD Video Select 16-Position Rotary Switch: Used to set HD Video Resolution Output Camera Settings 10-Position Dip Switch: Settings for IR Select, Baud Rate 9600, Image Flip, SD LB and SQ,

Test Bars OSD (On Screen Display) for fine tuning

Accessories EZIM HD-SDI Slot Card PN# 998-6900-007

EZIM CCU Slot Card PN# 999-6900-006 - For Use with Quick-Connect CCU Only Operating Temperature 32° to 104° F (0° to 40° C) / 20% to 80% Relative Humidity Dimensions (H x W x D) 8.5” (215.9mm) H x 6.75” (171.45mm) W x 7.7” (195.58mm) D Weight 5.79 lbs. (2.625635463kg.)

Quick-Connect DVI/HDMI SR (Short Range) Interface

Connectors

 Power Connector: 5.5mm OD, 2.5mm ID coaxial connector

 RJ-45: Four (4) Control IN, Control OUT, Daisy Chain OUT, EZCamera Power Video Port

 Video Output: DE-15 connector for HD Analog Component (Y,PB,PR) video only (No SD Support)

 IR Output: Transmits modulated or non-modulated IR signals received from the HD-19 IR receiver

 Video Outputs: DVI-D (Female - Single Link) or HDMI with adapter cable (using the Recessed Color

Cat-5e Cable Distance Power Supply Dimensions / Weight

Space Conversion Switch) , DE-15F (High Density D-Sub 15-Pin F) for HD YPbPr

Up to 100’ (30.5m)

24 VDC, 2 Amp

1.6” (40.64mm ) H x 8” (203.2mm) W x 6.751” (171.45mm) D, ½-Rack Size / 1.21 lbs.

(0.548846804 kg)

Accessory Options

1-RU Rack Mount Panel for two (2) units (side by side): P/N: 998-6000-003

1m (3.3’) DVI-D Male to HDMI Male P/N: 440-5643-001

3m (10’) DVI-D Male to HDMI Male P/N: 440-5643-003

CONCEAL Wall Mounting System for Vaddio ClearVIEW HD-19

Dimensions Weight

5.125” H x 6.75” W x 10” D (13 cm x 17.15 cm x 25.4 cm)

Approx. 2.4 lbs. (1.1kg)

WallVIEW HD-19 DVI/HDMI Manual 342-0267 Rev. C Page 13 of 24

WallVIEW HD-19 DVI/HDMI

Compliance and CE Declaration of Conformity - ClearVIEW HD-19

Compliance testing was performed to the following regulations:

 FCC Part 15, Subpart B Class A  ICES-003, Iss ue 4: 2004 Class A  EN 550 22 A: 2006 + A1: 2007(CISPR 22:2005/A1:2005) Class A  AS/NZS CISP R 22: 2009 + A1: 2010 Class A  VCCI V-3/201 0.04 Class A  EMC Directive 2004/108/EC Class A

FCC Part 15 Compliance

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15, Subpart B, of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his/her own expense.

Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) This device must accept any interference including interference that may cause undesired operation of the device. Changes or modifications not expressly approved by Vaddio can affect emission compliance and could void the user’s authority to operate this equipment.

ICES-003 Compliance

This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications. Le présent appareil numérique n’emet pas de bruits radioélectriques dépassant les limites applicables aux appareils numeriques de la classe A préscrites dans le Règlement sur le brouillage radioélectrique édicte par le ministère des Communications du Canada.

European Compliance

This product has been evaluated for Electromagnetic Compatibility under the EMC Directive for Emissions a nd Immunity and meets the requirements for a Class A digital device. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures.

Standard(s) To Which Conformity Is Declared:

EMC Directive 2004/108/EC EN 55024: 1998 + Amendments A1: 2001 + A2: 2003 Immunity

 EN 61000-4-2: 1995 + Amendments A1: 1998 + A2: 2001 Electrostatic Discharge  EN 61000-4-3: 2006 + A1: 2008 Radiated Immunity  EN 61000-4-4: 2004 + Corrigendum 2006 Electrical Fast Transients  EN 61000-4-5: 2006 Surge Immunity  EN 61000-4-6: 2009 Conducted Immunity  EN 61000-4-8: 2010 Power Frequency Magnetic Field  EN 61000-4-11: Second Edition: 2004 Voltage Dips, Interrupts and Fluctuations

WallVIEW HD-19 DVI/HDMI Manual 342-0267 Rev. C Page 14 of 24

WallVIEW HD-19 DVI/HDMI

Compliance and CE Declaration of Conformity - Quick-Connect DVI/HDMI SR Interface

Compliance testing was performed to the following regulations:

 FCC Part 15, Subpart B Class A  ICES-003, Issue 4: 2004 Class A  Eu ropean Standard EN 55022 A: 2006 + A1: 2007(CISPR 22:2005/A1:2005) Class A  EMC Directive 2004/108/EC Class A

FCC Part 15 Compliance

 This equipment has been tested and found to comply with the limits for a Class A digita l device, pursuant to Part 15, Subpart

B, of the FCC Rules. These limits are designed to provide reasonabl e protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential ar ea is likely to cause harmful interference in which case the user will be required to correct the interference at his/her own expense.

 Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) This device must

accept any interference including interference that may cause undesired operation of the device.

 Changes or modifications not expressly approved by Vaddio can affect emission compliance and could void the user’s

authority to operate this equipment.

ICES-003 Compliance

This digital apparatus does not exceed the Class A limits for radio noise emissions from digital ap paratus set out in the Radio Interference Regulations of the Canadian Department of Communications. Le présent appareil numérique n’emet pas de bruits radioélectriques dépassant les limites applicables aux appareils numeriques de la classe A préscrites dans le Règlement sur le brouillage radioélectrique édicte par le ministère des Communications du Canada.

European Compliance

This product has been evaluated for Electromagnetic Compatibility under the EMC Di rective for Emissions and Immunity and meets the requirements for a Class A digital device. In a domestic environment this product may cause radio interfer ence in which case the user may be required to take adequate measures.

Ferrite cylinders are included in order to the Quick-Connect DVI/HDMI SR Interface to strictly comply with the European Community EMC Directives compliance. Use these ferrites to ens ure the elimination of possible EMI interference from cell phones and AC motors.

Standard(s) To Which Conformity Is Declared: EMC Directive 2004/108/EC

EN 55022 A: 2006 + A1 2007 (CISPR 22:2005/A1:2005) Conducted and Radiated Emissions EN 55024: 1998 + Amendments A1: 2001 + A2: 2003 - Electromagnetic Compatibility - Immunity EN 61000-4-2 Electrostatic Discharge EN 61000-4-3 Radiated Immunity EN 61000-4-4 Electrical Fast Transients EN 61000-4-5 Surge Immunity EN 61000-4-6 Conducted Immunity EN 61000-4-8 Power Frequency Magnetic Field EN 61000-4-11 Voltage Dips, Interrupts and F luctuations

WallVIEW HD-19 DVI/HDMI Manual 342-0267 Rev. C Page 15 of 24

WallVIEW HD-19 DVI/HDMI

WARRANTY INFORMATION

(See Vaddio Warranty Policies posted on vaddio.com for complete details): Hardware* Warranty: One year limited warranty on all parts. Vaddio warrants this product against d efects in materials and

workmanship for a period of one year from t he day of purchase from Va ddio. If Vaddio receives notice of such defects during the warranty period, they will, at their option, repair or replace products that prove to be defective.

Exclusions: The above warranty shall not apply to defects resulting from: improper or inadequate maintenance by the customer, customer applied software or interfacing, unauthorized modifications or misuse, operation outside the normal environmental specifications for the product, use of the incorrect power supply, improper extensio n of the power supply cable or improper site operation and maintenance.

Vaddio Customer Service: Vaddio will test, repair, or replace the product or products without charge if the unit is under warranty and is found to be defective. If the product is out of warranty, Vaddio will test then repair the product or products. T he cost of parts and labor charge will be estimated by a tech nician an d confirmed by the customer prior to repair. All components must be returned for testing as a complete unit. Vaddio will not accept responsibility for shipment after it has left the premises.

Vaddio Technical Support: Vaddio technicians will determine and discuss with the customer the criteria for repair costs and/or replacement. Vaddio Technical Support can be contacted through one of the follo wing resources: e-mail support at

support@vaddio.com or online at www.vaddio.com.

Return Material Authorization (RMA) Number: Before returning a product for repair or replacement, request an RMA from Vaddio’s technical support. Provide a technician with a return phone number, e-mail address, shipping address, and product serial numbers and describe the reason for repairs or retur ns as well as the date of purchase and proof of purchase. Include your assigned RMA number in all correspondence with Vaddio. W rite your assigned RMA numb er on the shippi ng label of the box when returning the product. All returns are subject to a restocking fee without exception (see warranty policies at vaddio.com).

Voided Warranty: The warranty does not apply if the original serial number has been removed or if the product has been disassembled or damaged through misuse, accident, modifications, or unauthoriz ed repai r. Cutting the po wer supply cabl e on the secondary side (low voltage side) to extend the power to the device (camera or controller) voids the warr anty for that device.

Shipping and Handling: Vaddio will not pay for inbound shipping transportation or insurance charges or accept any responsibility for laws and ordinances from inbound transit. Vaddio will pay for outbound shipping, transportation, and insurance charges for all items under warranty but wi ll not assume responsibility for loss and/or damage by the outbound freight carrier. If the return shipment appears damaged, retain the origin al boxes and packing material for inspection by the carrier. Contact your carrier immediately.

Products Not Under Warranty: Payment arrangements are required before outbound shipment for all out of warranty products.

*Vaddio manufactures its hardware products from parts and components that are new or equivalent to new in accordance with industry standard practices.

Other General Information: Care and Cleaning

Do not attempt to take this product apart at any time. There are no user-serviceable components inside.

 Do not spi ll liquids or liquid type substances onto the device.  Keep this device away from food or liquid.  For smears or smudges on the devices, wipe with a clean, soft cloth.  Do not use any abrasive pads or caustic chemicals at any time on any Vaddio equipment.

Operating and Storage Conditions:

Do not store or operate the device under the following conditions:

 Temperatures above 40°C (104°F) or temperatures below 0°C (32°F)  High humidit y, condensing or wet environments  In inclement weather  Dusty environments  In a swimming pool or the beach  Dry environments with an excess of static discharge  In a space/time vortex  Under severe v ibration

WallVIEW HD-19 DVI/HDMI Manual 342-0267 Rev. C Page 16 of 24

WallVIEW HD-19 DVI/HDMI

Appendix 1: YPbPr Video Pin-Out for the HD-19 Camera and Quick-Connect SR Interface

Pin YPbPr

1 Pr 2 Y 3 Pb 4 5 6 Pr GND 7 Y GND 8 Pb GND

9 10 11 12 13 14 15 -

EZCamera Power & HD Video RJ-45 Connector Pin-outs

The EZCamera Power and HD Video RJ-45 Connector is for use with either the Quick-Connect SR Interface or the Quick-Connect DVI/HDMI SR Interface ONLY (568B Wiring Standard). The video

signals are differential (HSDS™) and can only be received by the interfaces above.

Pin YPbPr

1 Power+

2 Power-

3 Y+

4 Pb+

5 Pb GND

6 Y GND

7 Pr+

8 Pr-

12345678

WallVIEW HD-19 DVI/HDMI Manual 342-0267 Rev. C Page 17 of 24

WallVIEW HD-19 DVI/HDMI

Appendix 2: ClearVIEW HD-19 Dimensions

WallVIEW HD-19 DVI/HDMI Manual 342-0267 Rev. C Page 18 of 24

WallVIEW HD-19 DVI/HDMI

Appendix 3: Communication Specification Communication Speed: 9600 bps (default)

Start bit: 1 Stop bit: 1 Data bits: 8 Parity: None No Flow control

12345678

Pin # RJ-45 RS-232 and IR Out Pins

1) Unused

2) Unused

3) Unused

4) IR Output (Diff Signal to Quick-Connect SR)

5) IR Ground (Diff Signal to Quick-Connect SR)

6) GND (GND of IR Short Range - Pin 3)

7) RXD (from TXD of control source)

8) TXD (to RXD of control source)

NOTE: The Vaddio ClearVIEW HD-19 Control Protocol is similar, but not identical to the Sony® VISCA™ command set in order to be compatible with several popular control devices. Not all VISCA commands are supported and there are many HD-19 specific commands in the following Command and Inquiry Lists.

HD-19 Command List (1/2)

Command Set Command Command Packet Comments

Address Set Broadcast 88 30 01 FF Address Set (Daisy chain) IF_Clear Broadcast 88 01 00 01 FF IF Clear Command Cancel 8x 2p FF p:socket number(1,2) CAM_Power On

Off(Standby)

CAM_Zoom Stop

Tele(Standard) Wide(Standard) Tele(Variable) Wide(Variable) Direct Direct(Variable)

CAM_Focus Stop

Far(Standard) Near(Standard) Far(Variable) Near(Variable) AutoFocus ManualFocus Auto/Manual Direct

CAM_WB Auto

Manual One Push WB

CAM_RGain Reset

Up Down Direct

CAM_BGain Reset

Up Down Direct

CAM_AE Full Auto

Manual Shutter Priority Iris Priority

CAM_Iris Reset

Up Down Direct

CAM_Gain Reset

Up Down Direct

CAM_Bright Reset

Up Down Direct

8x 01 04 00 02 FF 8x 01 04 00 03 FF 8x 01 04 07 00 FF 8x 01 04 07 02 FF 8x 01 04 07 03 FF 8x 01 04 07 2p FF 8x 01 04 07 3p FF 8x 01 04 47 0p 0q 0r 0s FF 8x 01 7E 01 4A 0v 0p 0q 0r 0s FF 8x 01 04 08 00 FF 8x 01 04 08 02 FF 8x 01 04 08 03 FF 8x 01 04 08 2p FF 8x 01 04 08 3p FF 8x 01 04 38 02 FF 8x 01 04 38 03 FF 8x 01 04 38 10 FF 8x 01 04 48 0p 0q 0r 0s FF 8x 01 04 35 00 FF 8x 01 04 35 05 FF 8x 01 04 35 03 FF 8x 01 04 03 00 FF 8x 01 04 03 02 FF 8x 01 04 03 03 FF 8x 01 04 43 00 00 0p 0q FF 8x 01 04 04 00 FF 8x 01 04 04 02 FF 8x 01 04 04 03 FF 8x 01 04 44 00 00 0p 0q FF 8x 01 04 39 00 FF 8x 01 04 39 03 FF 8x 01 04 39 0A FF 8x 01 04 39 0B FF 8x 01 04 0B 00 FF 8x 01 04 0B 02 FF 8x 01 04 0B 03 FF 8x 01 04 4B 00 00 0p 0q FF 8x 01 04 0C 00 FF 8x 01 04 0C 02 FF 8x 01 04 0C 03 FF 8x 01 04 4C 00 00 0p 0q FF 8x 01 04 0D 00 FF 8x 01 04 0D 02 FF 8x 01 04 0D 03 FF 8x 01 04 4D 00 00 0p 0q FF

Power On/Off

pqrs: Zoom Position* v:(Speed) 0-7

pqrs: Focus position*

pq:00-ff

pq:00-ff Auto Exposure Mode Manual Control Mode Shutter Priority Mode Exposure Priority Mode (default)

pq(0x00-0x11)

pq(0x00-0x24)

pq(0x01-0x64)

WallVIEW HD-19 DVI/HDMI Manual 342-0267 Rev. C Page 19 of 24

WallVIEW HD-19 DVI/HDMI

HD-19 Command List (2/2)

Command Set Command Command Packet Comments

CAM_Backlight On CAM_Aperture Reset

CAM_Memory Reset

CAM_IDWrite 8x 01 04 22 0p 0q 0r 0s FF pqrs:0x0000 – 0xFFFF IR_Receive On

Pan-tiltDrive Up

Tally On Preset Pan Speed Pan/Tilt/Zoom Speed 81 01 7E 01 0B WW SS ZZ FF WW: Pan Speed (0x01-0x18)

Motor Config Hard Motor Stops BLK.Enhance Pedestal No Support No Support

GMA.Enhance Gamma 8x 01 7E 54 00 00 0p 0q FF pq: Gamma (0x00-0x10) CRM.Enhance Chroma 8x 01 7E 55 00 00 0p 0q FF pq: Chroma (0x00-0x64) KNE.Enhance Knee No Support No Support DIS.Enhance Digital Image

SNR.Enhance Super Noise AGC.Enhance AGC Mode 8x 01 7E 59 00 FF

CAM_Shutter Reset

CAM_ExpComp On

CAM_ICR Cut Filter

Off Up

Down Direct

Set Recall

Off On/Off

Down Left Right UpLeft UpRight DownLeft DownRight Stop Absolute Position

Home Reset

Off

Soft Motor Stops

Stabilizer Reduction

Up Down Direct

Off Reset Up Down Direct ICR On ICR Off

8x 01 04 33 02 FF 8x 01 04 33 03 FF 8x 01 04 02 00 FF 8x 01 04 02 02 FF 8x 01 04 02 03 FF 8x 01 04 42 00 00 0p 0q FF 8x 01 04 3F 00 0p FF 8x 01 04 3F 01 0p FF 8x01 04 3F 02 0p FF

8x 01 06 08 02 FF 8x 01 06 08 03 FF 8x 01 06 08 10 FF 8x 01 06 01 VV WW 03 01 FF 8x 01 06 01 VV WW 03 02 FF 8x 01 06 01 VV WW 01 03 FF 8x 01 06 01 VV WW 02 03 FF 8x 01 06 01 VV WW 01 01 FF 8x 01 06 01 VV WW 02 01 FF 8x 01 06 01 VV WW 01 02 FF 8x 01 06 01 VV WW 02 02 FF 8x 01 06 01 VV WW 03 03 FF 81 01 06 02 VV WW 0Y 0Y 0Y 0Y 0Z 0Z 0Z 0Z FF 0Y 0Y 0Y 0Y 0Z 0Z 0Z 0Z FF 8x 01 06 04 FF 81 01 06 05 FF 8x 01 7E 01 0A 00 02 FF 8x 01 7E 01 0A 00 03 FF

8x 01 7E 01 70 00 00 FF 8x 01 7E 01 70 00 01 FF

8x 01 7E 57 02 FF 8x 01 7E 57 03 FF 8x 01 7E 58 02 FF 8x 01 7E 58 03 FF

8x 01 7E 59 01 FF 8x 01 7E 59 02 FF 8x 01 7E 59 03 FF 8x 01 04 0A 00 FF 8x 01 04 0A 02 FF 8x 01 04 0A 03 FF 8x 01 04 4A 00 00 0p 0q FF 8x 01 04 3E 02 FF 8x 01 04 3E 03 FF 8x 01 04 0E 00 FF 8x 01 04 0E02 FF 8x 01 04 0E 03 FF 8x 01 04 4E 00 00 0p 0q FF 8x 01 04 01 02 FF 8x 01 04 01 03 FF

pq(0x00-0x1F)

p:Memory No(=0-0xe)

IR forwarding/Local IR WW: Pan Speed (0x01-0x18) VV:Tilt Speed(0x01-0x14)

YYYY: Pan Position** ZZZZ: Tilt Position**

SS:Tilt Speed(0x01-0x14) ZZ:Zoom Speed(0-7);

On Off On Off Off Low Medium High

pq(0x00-0x23) AutoExposure Off AutoExpouse On

Pq: 0x00-0x24 ICR On - Cut Filter Out ICR Off - Cut Filter In

*Zoom and Focus Data:

CAM_Zoom: Range(0x000–0x6B3) CAM_Focus: Range (0x000-0xC000) dependent on Zoom Position

**Additional Information:

Pan Range: 8044 – 7FBC (-32,700 to +32,700) Tilt Range: E891 – 4C2B (-5,999 to +19,499) Actual Pan/Tilt ranges defined in Inquiry list

WallVIEW HD-19 DVI/HDMI Manual 342-0267 Rev. C Page 20 of 24

WallVIEW HD-19 DVI/HDMI

HD-19 Inquiry List (1/1)

Inquiry Command Command Response Packet Comments

CAM_PowerInq 8x 09 04 00 FF y0 50 02 FF

y0 50 03 FF CAM_ZoomPosInq 8x 09 04 47 FF y0 50 0p 0q 0r 0s FF pqr: 0-0x6B3 CAM_FocusPosInq 8x 09 04 48 FF y0 50 0p 0q 0r 0s FF pqrs: Focus Position CAM_WBModeInq 81 09 04 35 FF y0 50 00 FF

y0 50 05 FF

y0 50 03 FF CAM_RGain 8x 09 04 43 FF y0 50 00 00 0p 0q FF pq:000-0ff CAM_BGain 8x 09 04 44 FF y0 50 00 00 0p 0q FF pq:000-0ff CAM_Iris 8x 09 04 4B FF y0 50 00 00 0p 0q FF pq(0x00-0x11) CAM_Gain 8x 09 04 4C FF y0 50 00 00 0p 0q FF pq(0x00-0x24) CAM_Bright 8x 01 04 4D FF y0 50 00 00 0p 0q FF pq(0x01-0x64) CAM_BacklightModeInq 8x 09 04 33 FF y0 50 02 FF

y0 50 03 FF CAM_ApertureInq 8x 09 04 42 FF y0 50 00 00 0p 0q FF Pq:x00-0x1F CAM_MemoryInq 8x 09 04 3F FF y0 50 0p FF p:Preset 0-0xf CAM_IDInq 8x 09 04 3F FF y0 50 0p 0q 0r 0s FF pqrs:0x0000 – 0xFFFF CAM_ReceiveInq 8x 09 06 08 FF y0 50 02 FF

y0 50 03 FF Pan-TiltMaxSpeedInq 8x 09 06 11 FF y0 50 pp qq FF pp:Pan 0x01-0x18

Pan-tiltPositionInq 8x 09 06 12 FF FF y0 50 0p 0p 0p 0p 0q 0q 0q 0q FF pppp: Pan 0x8044-0x7FB2 TallyInq 8x 09 7E 01 0A FF y0 50 02 FF

y0 50 03 FF PresetSpeedInq 8x 09 7E 01 0B FF y0 50 pp qq rr FF pp:Pan 0x01-0x18

Motor Config 8x 09 7E 01 70 FF y0 50 00 FF

y0 50 01 FF BLK.Enhance No support No Support Pedestal GMA.Enhance 8x 09 7E 54 FF y0 50 00 00 0p 0q FF pq: Gamma (0x00-0x10) CRM.Enhance 8x 09 7E 55 FF y0 50 00 00 0p 0q FF pq: Chroma (0x00-0x64) KNE.Enhance No support No Support Knee DIS.Enhance 8x 09 7E 57 FF y0 50 02 FF

y0 50 03 FF SNR.Enhance 8x 09 7E 58 FF y0 50 02 FF

y0 50 03 FF AGC.Enhance 8x 09 7e 59 FF y0 50 00 FF

y0 50 01 FF

y0 50 02 FF

y0 50 03 FF

y0 50 04 FF CAM_AEModeInq 8x 09 04 39 FF y0 50 00 FF

y0 50 03 FF

y0 50 0A FF

y0 50 0B FF CAM_ShutterPosInq 8x 09 04 4A FF y0 50 00 00 0p 0q FF pq: 0x0-0x23 CAM_ExpCompModeInq 8x 09 04 3E FF y0 50 02 FF

y0 50 03 FF CAM_ExpCompPosInq 8x 09 04 4E FF y0 50 00 00 0p 0q FF pq: ExpComp Pos CAM_ICRModeInq 8x 09 04 01 FF y0 50 02 FF

y0 50 03 FF

On Off(Standby)

Auto Manual One Push WB

On Off

qq:Tilt 0x01-0x14 qqqq: Tilt 0xE890-0x4C2C

On Off

qq:Tilt 0x01-0x14 rr:Zoom 0x00-0x07 Hard Motor Stops Soft Motor Stops

On Off On Off Off Low Medium High Manual AGC Auto Exposure Mode Manual Control Mode Shutter Priority Mode Exposure Priority Mode

On - AE Mode Off Off – AE Mode On

On - ICR filter Out Off – ICR filter In

WallVIEW HD-19 DVI/HDMI Manual 342-0267 Rev. C Page 21 of 24

WallVIEW HD-19 DVI/HDMI

Appendix 3 (continued): Iris Position:

Index F-Stop (Iris Position)

0x11 F1.6 0x10 F2.0 0x0F F2.4 0x0E F2.8 0x0D F3.4 0x0C F4.0 0x0B F4.8 0x0A F5.6 0x09 F6.8 0x08 F8.0 0x07 F9.6 0x06 F11.0 0x05 F14.0 0x04 F16.0 0x03 F19.0 0x02 F22.0 0x01 F28.0 0x00 Close

Gamma Position:

Index Gamma value

0x10 1.00 0xF 0.95 0xE 0.90 0xD 0.85 0xC 0.80 0xB 0.75 0xA 0.70 0x9 0.65 0x8 0.60 0x7 0.55 0x6 0.50 0x5 0.45 0x4 0.40 0x3 0.35 (Default) 0x2 0.30 0x1 0.25 0x0 0.20

Shutter Position( Speed):

Index Shutter (Speed)

0x23 1/30000 0x22 1/10000 0x21 1/5000 0x20 1/2500 0x1F 1/1500 0x1E 1/1000 0x1D 1/700 0x1C 1/600 0x1B 1/500 0x1A 1/480 0x19 1/360 0x18 1/300 0x17 1/250 0x16 1/240 0x15 1/200 0x14 1/180 0x13 1/150 0x12 1/120 0x11 1/100 0x10 1/60 0x0F 1/50 0x0E 1/30 0x0D x2 0x0C x4 0x0B x6 0x0A x8 0x09 x10 0x08 x12 0x07 x14 0x06 x16 0x05 x20 0x04 x24 0x03 x32 0x02 x40 0x01 x48 0x00 x60

WallVIEW HD-19 DVI/HDMI Manual 342-0267 Rev. C Page 22 of 24

ClearVIEW HD-19

Inside Back Cover - Blank

WallVIEW HD-19 DVI/HDMI Manual 342-0267 Rev. C Page 23 of 24

WallVIEW DVI/HDMI HD-19 System

9433 Science Center Drive, Minneapolis, MN 55428

Toll Free: 800-572-2011 ▪ Phone: 763-971-4400 ▪ FAX: 763-971-4464

www.vaddio.com

©2012Vaddio - All Rights Reserved. Reproduction in whole or in part without written permission is prohibited. Specifications and pricing are subject to change without notice. Vaddio, ClearVIEW, ProductionVIEW, Quick-Connect, ControlVIEW™, AutoPresenter, DCCE, WallVIEW, EZCamera, HSDS and PowerRite are registered trademarks of Vaddio. All other trademarks are property of their respective owners. Document Number 342-0267 Rev. C

WallVIEW DVI/HDMI HD-19 Manual ▪ Document Number 342-0267 Rev. A Page 24 of 24

Vaddio HD-19 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
