Owner’s Manual
CAM-MC
Indoor Network Camera
CAM-MC Indoor Network Camera Owners Manual ©2013
Universal Remote Control, Inc.
The information in this manual is copyright protected. No part of this manual may
be copied or reproduced in any form without prior written consent from Universal
Remote Control, Inc.
Universal Remote Control, INC. shall not be liable for operational, technical or editorial errors/omissions made in this manual.
The information in this manual may be subject to change without prior notice.
Total Control is a registered trademark of Universal Remote Control, Inc.
All other brand or product names are trademarks or registered trademarks of their
respective companies or organizations.
500 Mamaroneck Avenue, Harrison, NY 10528
Phone: (914) 835-4484 Fax: (914) 835-4532
TABLE OF CONTENTS
Introduction 1
Features and Benefits 1
Parts Guide 1
CAM-MC Description 2
Basic Installation 3
Communicating with the Camera 4
Navigating the Web Interface - Live View 5
Navigating the Web Interface - Admin 6
Specifications 7
Limited Warranty Statement 8
End User Agreement 11
Federal Communication Commission
Interference Statement 12
Regulatory Information to the user 13
Declaration of Conformity 14
INDOOR NETWORK CAMERA
Introduction
Congratulations on your purchase of the CAM-MC Indoor IP Camera! The
CAM-MC is an indoor IP camera that allows for seamless viewing over the
network with Total Control interfaces such as the TRC-1280, TKP-2000,
TKP-7000, iPad/iPhone (with TC Mobile App installed) as well as any future
Total Control graphical interfaces.
Once networked, it sends its image to compatible Total Control graphical
interfaces or any PC (running Internet Explorer) on the same local area
network.
Features and Benefits
• Outputs live video up to 30 fps at VGA resolution.
• Uses a progressive scan CMOS sensor, H.264/MJPEG dual
encoding and transmission with simultaneous dual streaming
capabilities.
• Video viewable on graphical user interfaces including the TRC-
1280, TKP-2000, TKP-7000, iOS devices or a networked PC.
• Camera requires power via PoE. Use a URC injector (POE-1),
switch (MFSPOE-8) or third party PoE solution.
• The camera has a minimum lux rating of 5.0 for a color image.
Parts Guide
The CAM-MC Indoor Network Camera includes:
1 - CAM-MC Indoor Network Camera
1 – Bracket Body
1 - Bracket Screws
1 - Allen Key
1 - Quick Installation Manual
Page 1
INDOOR NETWORK CAMERA
CAM-MC Description
Front View
Power LED
Lens
LAN LED
Lens Guide
Rear View
Name Description
Power LED Blue – Powered ON
LAN LED Green – Link
Lens Lens for built-in camera
Lens Guide Used to adjust lens for better focus
(when connected to a network)
Reset
Bracket
Connectors
LAN
Connection
Page 2
INDOOR NETWORK CAMERA
Name Description
Reset Pressing the “F.D” button will return the unit
Bracket Connector Screw hole to mount the camera to bracket
LAN Connector Plug an Ethernet cable from the camera’s LAN
back to factory default settings, including the
Admin ID and password.
connection to a PoE router or switch like
URC's MFSPOE-8.
(If a PoE switch is not used, you must use a
PoE injector to supply power to the camera.)
Basic Installation
Follow these basic steps to install the Indoor Network Camera CAM-MC.
1. Fasten the camera to your planned location using the supplied
mounting bracket.
2. Plug an Ethernet cable to the LAN port of the camera.
Note: No separate power supply is needed as the camera
receives power via a PoE supply or a MFSPOE-8 router.
Page 3
INDOOR NETWORK CAMERA
Communicating with the Camera
An IP address is required to view the camera and modify surveillance
options. Once installed, locate the IP address assigned by your router
(which will differ from the default address below). Your router contains a
DHCP table which displays each connected device and its IP address. IP
addresses normally resemble 10.20.30.40 or 192.168.1.xx.
For further information, refer to the router’s documentation.
The camera’s factory default options listed below may have changed
depending upon your router settings made by the Custom Professional
who installed your camera.
Factory Default
Admin ID root
Admin password root
IP address 10.20.30.40
1. Enter the camera’s IP address into the web browser’s address bar.
URC recommends using Internet Explorer to view the live surveillance.
2. The IP camera’s web interface opens. You now have access to the
Live View and Administration sections described next.
Page 4
INDOOR NETWORK CAMERA
Navigating the Web Interface - Live View
Select from the options below to modify the Live View.
Channel Control
r
l Ba
tro
n
Co
Displays multiple camera streams. It modifies the primary and secondary
streams (frame rate, image size, encoding, camera name, rate control
mode, image quality and group of pictures structure) from the Admin
page (Device Configuration> Camera & Motion).
Show Full/Normal Screen
View live video in either full or normal screen. Also capture images or
video by hovering the mouse cursor over the top left corner to reveal the
Snapshot stream and Video icons. Press the Snapshot icon to save JPEG
images or the video icon to save AVI files to your PC. The maximum AVI
recording time is 10 minutes. Press ESC to exit.
Show image in original size
Displays image in its original resolution with zooming capability. Use the
mouse button or keys to zoom-in (+), zoom-out (-), and original size (/).
Draw image by maintaining aspect ratio
Fits video to its original size or to the screen (using the same aspect
ratio). No zooming capability.
Draw image by filling the screen
Resizes the video to fill the entire screen. Zooming is not supported.
Enhanced Draw Mode On/Off
Enhances the image quality of a live video smaller than the original size.
About IP CCTV Information
Shows version information for the CCTV viewer.
Page 5
INDOOR NETWORK CAMERA
Navigating the Web Interface - Admin
Use the Admin interface to modify advanced features for the camera. To
gain acccess to the Admin site, enter the default username and password
(root and root).
Quick Configuration: A guided step-by-step walkthrough to setup your
camera’s configuration settings. Setup your Server Name Setup, Date &
Time, Network Configuration and IP-CCTV DNS Setup.
System Configuration: View and/or modify system configuration settings
pertaining to the Server Name, Date & Time, Admin Password, User Access
Control and User Registration.
Network Configuration: Assign the connection network settings for IP,
Netmask, Gateway, DNS, Network Ports, Bandwidth Control, Network
Status, IP-CCTV DNS and Port Forwarding.
Device Configuration: Setup the connection between the camera and
server by configuring the Serial Ports, adding Privacy Zone screens, as well
as modifying the camera name and image quality for the Primary and
Secondary streams.
Utilities: View the System Log file, Save the Configuration, Reboot the
camera, revert to the camera’s Factory Default state, and update the
camera’s firmware from System Update.
Page 6
INDOOR NETWORK CAMERA
Specifications
Camera Type IP Camera
Image Sensor 1/4" VGA progressive scan CMOS
Indoor / Outdoor Use Indoor Only
Lens 3.8mm F2.0, fixed lens
Min. illumination 5 lux color
Video Compression H.264/MJPEG
Video Resolution
Image quality Control 6 step quality control
Max Streaming Speed Max 30 fps @ VGA resolution
Motion Detection n/a
Network Bandwdth Control
Network Protocol
Viewer
Remote Admin.
Dynamic IP DDNS / uPnP support
Security
Telnet, RARP, PPPoE, SNMP, DHCP, NTP,
IE6 and later, Firefox, Safari, Chrome.
Channel-based user password protection
640X480 (VGA)
320X240 (Q VGA)
160X112 (QQ VGA)
VBR/CBR
(H.264, 32k~12Mbps)
HTTP, RTP/RTSP, TCP/IP, FTP,
SMTP client and etc
VLC, QuickTime, etc
Web based administration,
setup, control, and upgrade
System H/W
LAN Interface 10/100-base-T
Certification FCC/CE, RoHS
Working Conditions
Power Supply PoE support (router, switch or injector)
Power Consumption Max 5W, ( 48V, max 100mA )
Size/Weight
32bit Embedded CPU Embedded Linux
128MByte SDRAM
128MByte NAND FLASH
0°C~ +50°C / 20% ~ 80% RH
40mm(W) x 72mm(D) x 90mm(H)
3.28oz. (Camera Only)
Page 7
INDOOR NETWORK CAMERA
Limited Warranty Statement
1. Limited Warranty and Disclaimers
Universal Remote Control, Inc. (“URC”) warrants that the URC
equipment shall be free from defects in material and workmanship under
normal usage for one (1) year from purchase when such is purchased
from URC. This limited warranty is valid only in the United States of
America. URC warrants that the software will substantially conform in
any material respect to its functional specifications at the time of delivery.
URC SHALL NOT BE LIABLE FOR OPERATIONAL, TECHNICAL OR
EDITORIAL ERRORS AND/OR OMISSIONS MADE IN THE URC
DOCUMENTATION. URC DOES NOT WARRANT THAT THE URC
SOFTWARE IS BUG-FREE OR ERROR FREE OR THAT THERE ARE NO
ERRORS/BUGS IN THE URC SOFTWARE.
URC warrants that at the time of purchase the URC equipment and the
URC software complied with all applicable regulations and policies of
the Federal Communications Commissions (“FCC”) regarding
electromagnetic interference caused by electronic/computing devices and
to the extent that the URC equipment and/or the URC software fails to so
comply, URC shall, at its own expense, take all reasonable measures to
promptly cause such to comply.
URC equipment purchases from other than an authorized URC dealer
or distributor are without warranty.
THIS LIMITED WARRANT DOES NOT COVER TECHNICAL ASSISTANCE
FOR HARDWARE OR SOFTWARE USAGE EXCEPT AS EXPRESSLY
PROVIDED FOR HEREIN, THE EQUIPMENT, SOFTWARE AND
DOCUMENTATION OF URC ARE SUPPLIED “AS IS” WITHOUT ANY
WARRANTY, EXPRESS, STATUTORY OR IMPLIED, OF ANY KIND. TO THE
MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, URC EXPRESSLY
DISCLAIMS ALL WARRANTIES, EXPRESS, STATUTORY OR IMPLIED,
INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE. URC DOES NOT WARRANT,
GUARANTEE, OR MAKE ANY REPRESENTATIONS REGARDING THE USE OF,
OR THE RESULTS OF THE USE OF, THE EQUIPMENT, SOFTWARE OR
DOCUMENTATION IN TERMS OF CORRECTNESS, ACCURACY, RELIABILITY
OR OTHERWISE.
EXCEPT AS EXPRESSLY PROVIDED FOR HEREIN, TECHNICAL SERVICES
Page 8
INDOOR NETWORK CAMERA
ARE SUPPLIED “AS IS”, WITHOUT ANY WARRANTY, EXPRESS,
STATUTORY OR IMPLIED, OF ANY KIND. TO THE MAXIMUM EXTENT
PERMITTED BY APPLICABLE LAW, URC EXPRESSLY DISCLAIMS ALL
WARRANTIES, EXPRESS, STATUTORY OR IMPLIED, INCLUDING BUT
NOT LIMITED TO THE WARRANTIES OF QUALITY OR REASONABLE
SKILL AND CARE, OR OUTCOME OR RESULTS.
WITHOUT IN ANY WAY LIMITING THE GENERALITY OF THE OTHER
PROVISIONS HEREIN, WARRANTY DOES NOT COVER: (I) DAMAGE
FROM MISUSE, NEGLECT OR ACTS OR NATURE, (II) MODIFICATIONS,
(III) INTEGRATION WITH THIRD PARTY CONTENT (IV) BEYOND THE
WARRANTY PERIOD AND/ OR FAILURE TO FOLLOW URC
WARRANTY CLAIM PROCEDURE.
The warranty limitations and warranty disclaimers may not apply to end
user in whole or in part, where such are restricted or excluded by
applicable law and such shall apply to the maximum extent permitted by
applicable law.
In the event of any warranty claim, URC will, at its sole option, repair the
URC equipment using new or comparable rebuilt parts, or exchange the
URC equipment for new or rebuilt equipment. In the event of a defect,
these are the end user’s exclusive remedies.
All the URC equipment returned for service, exchange or repair require
an RGA number. To obtain an RGA number, you must complete a Return
Request Form which you may obtain by calling (914) 835-4484 or
contacting URC at returnrequest@universalremote.com. To obtain
warranty service, end user must deliver the URC equipment, freight
prepaid, in its original packaging or packaging affording adequate
protection to URC at 420 Columbus Avenue, Valhalla, NY 10595. It is
end user’s responsibility to backup any macro programming, artwork,
software or other materials that may have been programmed into the
unit. It is likely that such data, software, or other materials will be lost
during service and URC will not be responsible for any such damage or
loss. A dated purchase receipt, bill of sale, installation contract or other
verifiable proof of purchase is required. For the URC equipment support
and other important information, please visit URC's website available at
www.universalremote.com or call the Customer Service Center at (914)
835-4484.
Page 9
BOX TYPE FOR BABY ROOM NETWORK CAMERA
This limited warranty only covers the URC equipment issues caused by
defects in material or workmanship during ordinary consumer use. It
does not cover product issues caused by any other reason, including but
not limited to product issues due to commercial use, acts of God, thirdparty installation, misuse, limitations of technology, or modification of or
to any part of the URC equipment. This limited warranty does not cover
the URC equipment sold as used, as is, refurbished, so called "B stock" or
consumables (such as batteries). This limited warranty is invalid if the
factory applied serial number has been altered or removed from the URC
equipment. This limited warranty specifically excludes the URC
equipment sold by unauthorized resellers.
With the exception of URC’s IR-only, broad-based consumer remotes,
none of URC’s PC programmable remotes or any of our Total Control®
whole-house equipment are authorized for online internet sales. Buying
URC’s PC programmable remotes or any of our Total Control® wholehouse equipment online means buying equipment that does not have a
URC’s limited warranty. Such equipment is not eligible for URC tech
support or software support, either.
2. URC’S Limitations of Liability
IN NO EVENT SHALL URC BE LIABLE FOR INDIRECT, SPECIAL,
INCIDENTAL, EXEMPLARY, PUNITIVE OR CONSEQUENTIAL DAMAGES
OF ANY KIND OR LOSS OF PROFITS OR BUSINESS OPPORTUNITY,
EVEN IF URC IS ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
IN NO EVENT SHALL URC BE LIABLE FOR LOSS OF OR DAMAGE TO
DATA, COMPUTER SYSTEMS OR COMPUTER PROGRAMS.
URC’S LIABILITY, IF ANY, FOR DIRECT DAMAGES OF ANY FORM
SHALL BE LIMITED TO ACTUAL DAMAGES, NOT IN EXCESS OF
AMOUNTS PAID BY END USER FOR THE URC EQUIPMENT.
IN NO EVENT SHALL URC BE LIABLE FOR ANY EVENTS BEYOND ITS
CONTROL, INCLUDING ANY INSTANCE OF FORCE MAJEURE.
IN NO EVENT SHALL URC BE LIABLE FOR THE ACTS OR OMISSIONS
OF END USER OR ANY THIRD PARTY.
THE LIMITATIONS OF LIABILITY MAY NOT APPLY TO END USER IN
WHOLE OR IN PART, WHERE SUCH ARE RESTRICTED LIMITED OR
EXCLUDED BY APPLICABLE LAW AND SUCH SHALL APPLY TO THE
Page 10
BOX TYPE FOR BABY ROOM NETWORK CAMERA
MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW.
URC SHALL NOT BE HELD RESPONSIBLE FOR THE STATEMENTS
MADE BY OTHERS.
SOME STATES OR JURISDICTIONS DO NOT ALLOW THE EXCLUSION
OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES,
OR ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY
LASTS, SO THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT
APPLY TO END USER. THIS LIMITED WARRANTY GIVES END USER
SPECIFIC LEGAL RIGHTS AND END USER MAY HAVE OTHER RIGHTS
WHICH VARY FROM STATE TO STATE OR JURISDICTION TO
JURISDICTION.
End User Agreement
The terms and conditions of the End User Agreement available at
www.universalremote.com/eua.php shall apply.
Page 11
INDOOR NETWORK CAMERA
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is
encouraged to try to correct the interference by one more of the following measures:
u Reorient or relocate the receiving antenna.
u Increase the separation between the equipment and receiver.
u Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
u Consult the dealer or an experienced radio/TV technician for help.
Warning!
Changes or modifications not expressly approved by the manufacturer could void the
user's authority to operate the equipment.
Note : The manufacturer is not responsible for any Radio or TV interference caused by
unauthorized modifications to this equipment. Such modifications could void the
user's authority to operate the equipment.
FCC Caution
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
Any changes or modifications not expressly approved by the party responsible for compliance could void the authority to operate equipment.
Page 12
INDOOR NETWORK CAMERA
Regulatory Information to the user
n
CE conformity Notice
Products with “CE” marking comply EMC Directive 2004/108/EC, issued by the
commission of the European Community.
1) EMC Directive
lEmission : EN55022:2006+A1:2007
lImmunity : EN61000-3-2:2006+A2:2009
lPower : EN61000-3-3:1995+A1:2001+A2:2005
n
Declaration of Conformity
“Hereby, Universal Remote Control Inc. declares that this CAM-MC is
in compliance with the Essential requirements and other relevant
provisions of EMC Directive 2004/108/EC.”
Certification
Type No.(Model No.) CAM-MC
Batch/Serial No. Power Rating 48.0V 0.06A
Page 13
INDOOR NETWORK CAMERA
EU Declaration of Conformity
Manufacturer :
Address :
We declare our sole responsibility that the product
OH SUNG Electronics Co., Ltd.
181 GONG DAN-DONG, GUMI, GYEONG BUK, KOREA
Product : IP CAMERA
Model Number(s): CAM-MC
to which this declaration relates is in conformity with the following standards
: EN 55022:2006+A1:2007 (Class B)
Information technology equipment-Radio disturbance characteristics-Limits and methods of measurement
: EN61000-3-2:2006+A2:2009
Limits for harmonic current emissions
: EN61000-3-3:2008
Limitation of voltatge changes, voltage fluctuations and flicker in low-voltage supply systems
: EN 50130-4:2011
Alarm systems-Part 4: Electromagnetic compatibility -Product family standard: Immunity requirements for
components of fire, intruder, hold up, CCTV, access control and social alarm systems
Following the provisions of the applicable directives
EMC Directive 2004/108/EC
Authorized
person:
and therefore bears CE marking :
amended by the CE Marking Directive 93/68/EEC
Name
Title
Date
Signature
Page 14
NOTE
Page 15
BOX TYPE FOR BABY ROOM NETWORK CAMERA
Page 16
500 Mamaroneck Avenue, Harrison, NY 10528
Phone: (914) 835-4484 Fax: (914) 835-4532
www.universalremote.com
Page 17
Loading...
