Universal Remote Control Easy Clicker UR3-SR2 Operating Manual
Universal Remote Control, Inc.
www.universalremote.com
UR3-SR2
Operating Manual
For Easy Clicker
1
This remote control is designed to operate most Digital
and Analog Cable Boxes, as well as TVs, and a VCR or
DVD player.
Introduction
Install two
AAA alkaline batteries
as shown here
1
Before you program or operate the remote control, you
must install two new AAA alkaline batteries.
STEP1 Remove the battery compartment cover from the
back of your remote control.
STEP2 Check battery polarity carefully, and install the
batteries as shown in the illustration below.
STEP3 Replace the battery compartment cover.
Replacing Batteries
2
2
Button Functions
3
Programming the Remote Control.
4
A. Manual Pr
A. Manual Pr
ogramming
ogramming
The remote control can be programmed by entering a threedigit code number that corresponds to particular brands and
models of equipment. The three-digit code numbers are listed
in the code tables sections of this instruction manual.
*Note : In this section, when you are instructed to press a
[DEVICE] button, that means you should press either
the CBL, TV, or VCR button, depending on which
device you are programming the remote to operate.
3
STEP1 Turn on the equipment that you want the remote
control to operate Cable Box, TV and VCR(DVD).
STEP2 Press the [DEVICE] button and the [SELECT]
button simultaneously for three seconds. The
corresponding device LED will turn on indicating
that it is ready to be programmed. The LED will
remain on for 20 seconds. The next step must be
entered while the LED is on.
STEP3 Point the remote control toward the equipment
and enter the three-digit code number assigned
to your brand from the code tables. If there are
more than one three-digit number listed for your
brand, try one code number at a time until your
equipment turns off.
*Note : You can verify that you have selected the correct
code by pressing the [MUTE] button. The
equipment should turn on or off.
STEP4 Store the three-digit code by pressing the same
[DEVICE] button once again. The device LED will
blink twice to confirm that the code has been
stored.
*Note : Try all the functions on the remote control. If any
of the functions do not operate as they should,
repeat the instructions from Step 2 using the next
three-digit code number from the same brand list.
B. Auto Sear
B. Auto Sear
ch Method
ch Method
If none of the three digit code numbers assigned to your
brand of equipment works, or the code table does not list
your brand, you can use the Auto Search Method to find the
correct three-digit code number for your equipment by
following steps:
STEP1 Turn on the equipment that you want the remote
control to operate (Cable Box, TV, VCR, or DVD).
4
STEP2 Press the [DEVICE] button and the [SELECT]
button simultaneously for three seconds. The
device LED will turn on indicating that it is ready
to be programmed. The LED will remain on for 20
seconds. The next step must be entered while
the LED is on.
STEP3
Press the [CH+] or [CH-] button one at a time or
keep it pressed. The remote will emit a series of
Power ON/OFF code signals. Release the [CH+] or
[CH-] button as soon as the equipment turns off.
*Note : You can verify that you selected the correct code
by pressing the [MUTE] button. The equipment
should turn On or Off.
STEP4 Press the same [DEVICE] button to store the
code. The Device LED will blink twice to confirm
that the code has been stored.
C.
C. TT
o find the Thr
o find the Thr
ee-Digit Code that W
ee-Digit Code that Wasas
PrProgrammed using the Auto Sear
ogrammed using the Auto Sear
ch
ch
Method
Method
STEP1 Press the appropriate [DEVICE] button and the
[SELECT] button simultaneously for three
seconds. The device LED will turn on for 20
seconds. The next step must be performed while
the LED is on.
STEP2 Press the [INFO] button. The device LED will blink
a number of times indicating the number of each
digit for the code. Each digit is separated by a
one second interval of the LED being off.
Example : One blink, then three blinks, then eight blinks
indicates the code number 138.
*Note : Ten blinks indicates the number 0.
5
D.
D. PrPr
ogramming a Second TV to the VCR
ogramming a Second TV to the VCR
Button
Button
STEP1 Press the [VCR] button and the [SELECT] button
simultaneously for 3 seconds. The VCR LED will
turn on for 20 seconds. The next step must be
performed while the LED is on.
STEP2 Press the [TV] button.
STEP3 Point the remote control toward the TV and enter
the three-digit code for your TV from the TV
codes table.
STEP4 Store the three-digit code by pressing the [VCR]
button. The device LED will blink twice to confirm
that the code has been stored.
E.
E. PrPr
ogramming for Advanced Functions.
ogramming for Advanced Functions.
In the CABLE device mode, the A,B,C and blank macro
buttons can be programmed to act as macro buttons to
send out up to 10 commands with one button press. In this
section, when you’re instructed to press a [MACRO]
button, you need to press either the A, B, C or blank macro
button (depending on which button you are attempting to
program).
*Note : The A, B, and C buttons are not programmable if
you have a Digital Cable Box made by Pace,
Pioneer, or Scientific-Atlanta.
STEP1 Press the [CBL] button to select the CABLE
mode.
STEP2 Press a [MACRO] button and the [SELECT] button
simultaneously for 3 seconds. The CBL device
LED will turn on for 20 seconds. The next step
must be performed while the LED is on.
STEP3 Press up to 10 buttons you wish to store. The CBL
device LED will blink once for each command
entered.
6
STEP4 Press the [CH+] button to store the functions that
are selected. The CBL device LED will blink twice
to confirm the storage of functions.
To erase the Macro programming and return to the
original function:
STEP1 Press the [CBL] button to select the CABLE mode.
STEP2 Press a [MACRO] button and the [SELECT] button
simultaneously for 3 seconds. The CBL device
LED will turn on for 20 seconds. The next step
must be performed while the LED is on.
STEP3 Press the [CH+] button to erase the functions
stored in the button. The CBL device LED will blink
twice to confirm that the memory button has
been erased.
FF.
.
Assigning the V
Assigning the V
olume and Mute keys to a
olume and Mute keys to a
Dif
Dif
fer
fer
ent Device
ent Device
By default, the VOL+, VOL- and MUTE keys operate
through your TV. If you would like those keys to operate
those functions on a different device, follow these
steps.
STEP1 Press the [SELECT] button and [CBL] button
simultaneously for three seconds. The device
LED will turn on for 20 seconds. The next step
must be performed while the LED is on.
STEP2 Press the [VOL +] button. The device LED will
blink.
STEP3 Press the [DEVICE] button corresponding to the
device that you would like the volume and mute
buttons to control. The device LED will blink
twice to confirm the programming.
