On-Premises
Washers & Dryers
Commercial Topload Washer
Commercial Frontload Washer
Commercial Stack Washer/Dryer
Commercial Dryer
Commercial Stack Dryer
Expert Solutions from the Laundry Experts
Specifications
®
opload Frontload
Washer
Width - in (mm) 25 5/8" (651) 26 7/8" (683)
epth - in (mm) 28" (711) 28" (711)
D
eight - in (mm) 43" (1092) 41 3/8" (1054)
H
eight to Work Surface - 36" (914) 41 3/8" (1054)
H
n (mm)
i
peration Manual Control Manual Control
O
asket Volume - 2.8 (79) 2.84 (80)
B
u. ft. (liters)
c
pin Speed - RPM High Speed 710 500, 650,
S
ater Temperatures Hot, Warm and Cold Hot/Cold, Warm/Warm
W
Cycles Normal, Permanent Press Regular, Permanent Press,
ycle Time 16-31 minutes 27 minutes
C
Water Pressure - Pressure fill 20 to 120 Pressure fill 20 to 120
psi (bar) (1.4/8.3) (1.4/8.3)
Cycle Cue Lights Yes Yes
op and Lid Finish Porcelain Porcelain
T
Color White White
Motor 2-speed, 1/2 HP reversing Multi-speed 3/4 HP
Motor
Electrical Specifications 120/60/1-15 amp 120/60/1-15 amp
Net Weight (Approx.) - 190 (86) 240 (109)
lb (kg)
Dom. Shipping Weight 210 (95) 260 (118)
(Approx.) - lb (kg)
Agency Approvals U L UL,
T
WT821 FTUA1
U
Low Speed 473 1000
ot/Cold, Warm/Warm
H
Warm/Cold, Cold/Cold
Warm/Cold, Cold/Cold
or Delicate Delicate, Rinse and Spin
or Spin
lus fill time plus fill time
p
for 1725 or 1140 RPM
S
CULU
ingle Rear Control Single Front Control Stack
Dryers
S
DE807 (Electric) FEU17 (Electric) USE807 (Electric)
U
UDG809 (Gas) FGU17 (Gas) USG809 (Gas)
Width - in (mm) 26 7/8" (683) 26 7/8" (683) 26 7/8" (683)
epth - in (mm) 28" (711) 28" (711) 28" (711)
D
eight - in (mm) 43" (1092) 41 3/8" (1054) 76 5/8" (1946)
H
Height to Work Surface - 36" (914) 41 3/8" (1054) N/A
in (mm)
ylinder Volume - 7.0 (198) 7.0 (198) 7.0 (198)
C
u. ft. (liters)
c
Color White White White
Motor H P 60 Hz: 1/3 HP, 5.5 amp 60 Hz: 1/3 HP, 5.5 amp 60 Hz: 1/3 HP, 5.5 amp
otor R PM 60 Hz: 1725 60 Hz: 1725 60 Hz: 1725
M
tu Per Hour 25,000 (6,300 kcal) 25,000 (6,300 kcal) 25,000 (6,300 kcal)
B
lectrical Requirements Gas: Gas: Gas:
E
120/60/1 - 15 amp 120/60/1 - 15 amp 120/60/1 - 15 amp
Electric: Electric: Electric:
120/240/60/1 - 30 amp 120/240/60/1 - 30 amp 120/240/60/1 - 30 amp
120/208/60/1 - 30 amp 120/208/60/1 - 30 amp 120/208/60/1 - 30 amp
Heating Element 60 Hz: 5350W, 240V 60 Hz: 5350W, 240V 60 Hz: 5350W, 240V
Electric) Also 4750W, 208V Also 4750W, 208V Also 4750W, 208V
(
ype of Gas Factory-equipped for Factory-equipped for Factory-equipped for
T
Gas models only) natural/mixed gas natural/mixed gas natural/mixed gas
(
Convertible to LP gas* Convertible to LP gas* Convertible to LP gas*
Utility Connections - 3/8" N PT (9.5) 3/8" N PT (9.5) 3/8" NPT (9.5)
in (mm)
Air Outlet Diameter - 4" (102) 4" (102) 4" (102)
in (mm)
Exhaust Airflow** 220 (105 liters/sec.) 220 (105 liters/sec.) 220 (105 liters/sec.)
Net Weight (Approx.) - Gas: 140 (64) Gas: 155 (70) Gas: 275 (125)
lb (kg) Electric: 135 (61) Electric: 150 (68) Electric: 265 (120)
Dom. Shipping Weight Gas: 150 (68) Gas: 165 (75) Gas: 290 (132)
(Approx.) - lb (kg) Electric: 145 (66) Electric: 160 (73) Electric: 280 (127)
Agency Approvals UL, CSA UL, CSA UL, CSA
Strong Limited Parts Warranty
UniMac proudly offers the following limited warranties on its topload washer:
Through Three Years* — any part on the entire machine.
Through Five Years* — the transmission assembly.
Through Lifetime* — the stainless steel washtub.
UniMac proudly offers the following limited warranties on its frontload washer:
Through One Year* — any part on the entire machine.
UniMac proudly offers the following limited warranty on its commercial dryer:
Through Three Years* — any part on the entire machine.
* Parts only, labor not included. See UniMac Warranty Bond for specifics.
Stack Washer/Dryer
LTUA7 (Electric)
LTUA9 (Gas)
Width - in (mm) 26 7/8" (683)
Depth - in (mm) 28" (711)
Height - in (mm) 75 1/4" (1911)
Color White
Net Weight (Approx.) - Gas: 355 (161)
lb (kg) Electric: 350 (159)
Dom. Shipping Weight Gas: 385 (175)
(Approx.) - lb (kg) Electric: 380 (172)
Agency Approvals UL, CSA
* IMPORTANT: Any product revisions or conversions must be made by
the Manufacturer’s Authorized Dealers, Distributors, or local service
personnel. Any approvals may vary depending on configuration.
Consult factory for details.
** Measured at point of exit from dryer. Maximum exhaust static back pressure:
60 Hz: 0.6" W.C. Gas models are certified by CSA International; electric
models are Underwriters Laboratories certified.
For the most accurate information the installation guide should be used
for all design and construction puroposes. Due to continuous product
improvements, design and specifications are subject to change without
notice. The quality management systems at all Alliance Laundry Systems
manufacturing facilities have been registered as ISO 9001:2000 compliant.
Features and certifications may vary by model.
©Copyright 2007 Alliance Laundry Systems LLC
Printed in the U.S.A.
Printed on paper manufactured with virgin pulp from
certified sources and a minimum of 10% post-consumer
recovered fiber.
AU07-208
www.uniwash.com
Shepard Street, Ripon, WI 54971 Telephone: 1-800-587-5458
Alliance Laundry Systems
A
t UniMac, washers and dryers are con-
A
sidered more than just laundry equipment.
They are key players in the success of onpremises laundry facilities and as such, must
continuously achieve high levels of efficiency,
quality and durability. UniMac always has
maintained a standard of excellence in laun-
Dryers
dry equipment manufacturing that is recognized around the world. With over 60 years of
engineering expertise, you can be assured
that you are getting the best washers and
dryers on the market that will meet your
needs now and in the future.
Stack Washer/Dryers
Floor Space
By stacking the dryer on
top of the washer, you
gain a large amount of floor space.
These ENERGY STAR® qualified units
are the ultimate space savers. You
can place laundry equipment in places
that were never before possible.
The utility connections are identical
to those used of residential style
equipment. There is no extra work
or floor space required.
Extra-Large 7.0 cu. ft. Capacity
UniMac’s extra-large
capacity drying cylinder
needs very little space,
yet easily handles sizeable wash loads. Smooth
baffles tumble loads
freely for maximum dry
air movement.
Large Door Opening
For ease in loading
and unloading,
UniMac designed
its dryer with a
2.06 sq. ft. door
opening, one of
the largest in
the industry.
Front Serviceability
UniMac’s two-piece front panel increases ease of
service, which can save time and expense. Motor,
blower, heating element, gas valve and thermostats
can be serviced through the lower panel without
disconnecting the door switch.
Frontload Washers
Topload Washers
Utility Cost Savings
Utility costs are a big part
f your laundry dollar.
o
UniMac can help you
reduce your costs with our energy
efficient frontload washers.
The frontload washer is ENERGY
® qualified and excels in energy
STAR
efficiency. The listing was earned by
our washer’s low usage of hot water, low motor energy consumption and high moisture removal. The washer’s super-
high spin speed reduces drying time and energy costs.
You could save hundreds of dollars per year on electricity,
gas, water and sewer fees. These savings are due to less
hot water, less overall water consumption and shorter
drying times.
Saves Time
If you believe time is money, then you will be excited
to experience how UniMac’s frontload washers cut time
from every wash and dry cycle. The super-high spin speed
of 1,000 RPM removes much more water than topload
washers. This greatly reduces the drying time. In fact,
our tests show drying time is reduced as much as 30%!
Rugged Suspension
System
UniMac incorporates a liquid-filled
balance ring at the top of the tub along
with a seven-point suspension system
to handle bulky loads with ease.
Front Serviceability
UniMac engineered its washer
to easily handle large loads while
occupying minimal floor space.
Our 100% front serviceable
design eliminates the need for
extra floor space around the unit,
making it ideal for small or large
laundry rooms. Simple removal
of the front panel or control hood
provides easy access to all major
components from the installed
position, which can save you
time and money.
Front Controls and Supply Dispenser
The unique front control design allows for convenient
storage on top or the washer can easily fit under a
counter. Add your detergent,
bleach or softener with the
automatic front mount supply
dispenser, walk away and
the washer will take care of
the rest.
Liquid Supply Injector
Some installations may require a connection to an automated liquid supply system. There are two supply signals
and two injection ports included within the washer.
Heavy-Duty See-Through Door
Loading and unloading are a breeze
with UniMac’s extra-wide 15 1/2"
door, which boasts a 180° swing.
A heavy-duty stainless steel hinge
ensures the door will stand up to the
rigors of the on-premises laundry.
The see-through door also enables
users to monitor the wash process.
Durable Stainless Steel Tub
To keep linens looking their best
longer, UniMac’s washer features a
stainless steel washtub that will
actually become smoother with
each use, so it won’t pill, fray or
snag fabric. In fact, stainless steel
won’t corrode, chip, crack or pit
under normal use and it is extremely
rust resistant. That’s why we provide a lifetime warranty.
Agitator
For superior washability, UniMac’s wavy
vane agitator offers a 210˚ agitation stroke
that delivers maximum side-to-side,
top-to-bottom washing action to get
linens their cleanest.
