INSTRUCTION MANUAL
UDC-5M
Digital Camera
Congratulations on your purchase of the Uniden UDC-5M Digital Camera.
• Please be sure to read this Instruction Manual before you begin using your
camera.
• Save this manual for future reference.
• Review the separate booklet “SAFETY MANUAL” before operating your camera.
Warning
TO PREVENT THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE
kFOR AMERICAN USERS
The following advisory is included in accordance with the laws of the State of
California (USA):
WARNING:
This product contains chemicals, including lead, known to the State of
California to cause cancer, birth defects or other reproductive harm. Wash
hands after handling.
i This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
h Reorient or relocate the receiving antenna.
h Increase the separation between the equipment and receiver.
h Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
h Consult the dealer or an experienced radio/TV technician for help.
i Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
Declaration of Conformity
Model number: UDC-5M
Trade Name: Uniden Corporation
Address: 4700 Amon Carter Boulevard Ft. Worth TX, 76155 U.S.A
Telephone No.: 817-858-3300
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interfer-
ence that may cause undesired operation.
i English
kFOR CANADIAN USERS
i This Class B digital apparatus complies with Canadian ICES-003.
English ii
GETTING UP AND RUNNING
Install the battery
1 Open the battery/card cover, and insert the batteries.
h The battery/card cover is located on the bottom of the camera.
Batteries
Battery/card cover
2 Press the on/off button to turn the camera on.
h The Shooting Screen appears.
on/off button
180
iii English
Shooting
1 Press the [n] button.
h The display for selecting
shooting mode appears.
Still image shooting
Video clip recording
STILL IMAGE
2 Press the [l] and [m] buttons
to select the shooting mode.
Still image shooting mode:
Select [c].
Video clip recording mode:
Select [t].
3 Press the ok button.
h The shooting mode is
indicated by an icon in the
upper left area of the
monitor.
4 Press the shutter button.
Still image shooting mode:
A still image is captured.
Video clip recording mode:
Recording begins. To stop
recording, press the shutter
button again.
CAUTION
This camera does not record sound.
i For video clip playback, only video data is played back.
c:Still image shooting mode
t:Video clip recording mode
Shutter button
ok button
[n] and [m] buttons
180
English iv
Playback
kStill image playback
1 Press the playback button [=].
h The display switches to the
Playback Screen.
h To view other images, press the
[l] or [m] button.
h If the playback button [=] is
pressed, the display returns to
the Shooting Screen.
Playback button [=]
kVideo clip playback
1 Press the playback button [=].
h The display switches to the
Playback Screen.
h Press the [l] or [m] button to
display the video clip you wish to
play back.
h Video clips are indicated by a
video clip pattern along the top
and bottom of the screen.
2 Press the ok button.
h Playback of the selected video
clip begins.
h If the playback button [=] is
pressed again, the display
changes to the Shooting Screen.
[l] and [m] buttons
Video clip pattern
<Video Clip Playback
Screen>
When you are finished taking pictures...
Press the on/off button to turn the camera off.
ok button
v English
QUICK SEARCH BY OPERATION
Your camera has an abundance of convenient features and functions. From
creating precisely the photo you want, to viewing images using various
techniques, you can locate the exact operation for your purposes in the
following table.
Basic operation
Getting started
shooting
• “Shooting still images”
on page 29
• “Recording a video clip”
on page 36
Shooting/recording
Optimize the photo quality
• “RESOLUTION/VIDEO CLIP SETTING” on page 51
Capture fast-moving subjects
• “USING THE SCENE FUNCTION” (sports mode) on page 40
Convenient
functions
Log the date and
time of your photos
• “DATE AND TIME
SETTINGS” on
page 19
• “DATE IMPRINTING
ON STILL IMAGES” on
page 57
Zoom in on the
subject
• “USING THE ZOOM”
on page 42
Close-up
photography
• “FOCUS RANGE”
(macro mode) on
page 47
Additional functions
Set the focus to a
narrow range
• “FOCUS AREA
SETTING” on page 52
1 English
Basic operation
Shoot in dark conditions
• “EXPOSURE CORRECTION” on page 56
• “FLASH SETTING” on page 43
• “USING THE SCENE FUNCTION” (night view por trait mode) on page 40
Photographing people
• “USING THE SCENE FUNCTION” (cosmetic mode/por trait mode/night view
portrait mode) on page 40
• “FLASH SETTING” (red-eye reduction) on page 43
Photographing landscapes
• “USING THE SCENE FUNCTION” (landscape mode) on page 40
Take a self-photo
• “SELF-TIMER” on page 45
Shooting/recording
Convenient
functions
Increase the camera’s sensitivity
“ISO SENSITIVITY” on page 53
Make images lighter
or darker
• “EXPOSURE
CORRECTION” on
page 56
Change the color of
the images
• “USING THE SCENE
FUNCTION”
(monochrome/sepia)
on page 40
Additional functions
Adjust the camera’s
sensitivity
• “ISO SENSITIVITY” on
page 53
Make white appear
natural
• “WHITE BALANCE” on
page 54
English 2
Basic operation
Getting started
viewing images
• “Playing back the video
clip” on page 37
• “Viewing still images”
on page 31
Playback
Slideshow playback
• “SLIDESHOW PLAYBACK” on page 70
Adjust the monitor brightness
• “ADJUST THE MONITOR BRIGHTNESS” on page 76
Search for image data
• “9-image display playback” on page 32
Delete files
• “Erasing files” on
page 34
Specify the number of prints and date imprint
• “PRINT SETTINGS” on page 64
View the settings that were in effect when the data was recorded
• “DISPLAYING STILL IMAGE PROPERTIES” on page 71
Data managing/processing
Convenient
functions
Search for image
data
• “9-image display
playback” on page 32
Magnify an image
• “Magnifying (zooming
in) the image” on
page 33
Protect images from accidental erasure
• “IMAGE PROTECT” on page 60
Format a card
• “INITIALIZING THE CARD MEMORY AND
INTERNAL MEMORY” on page 84
Additional functions
Change the angle of
view
• “ROTATE IMAGE” on
page 61
3 English
CONTENTS
QUICK SEARCH BY OPERATION ........................................................1
CONTENTS ............................................................................................4
CHECKING THE INCLUDED ACCESSORIES ......................................7
GETTING THE MOST OUT OF YOUR CAMERA ................................10
SYSTEM MAP ......................................................................................11
SETUP
PARTS NAMES ....................................................................................12
INSTALLING THE BATTERIES AND CARD ........................................14
TURNING THE CAMERA ON AND OFF ..............................................17
DATE AND TIME SETTINGS ...............................................................19
BASIC OPERATION
BEFORE TAKING PICTURES .............................................................22
CAPTURING AND PLAYING BACK STILL IMAGES ...........................29
VIDEO CLIP RECORDING AND PLAYBACK ......................................36
USING THE SCENE FUNCTION .........................................................40
USING THE ZOOM ..............................................................................42
FLASH SETTING ..................................................................................43
SELF-TIMER ........................................................................................45
FOCUS RANGE ...................................................................................47
SHOOTING
ACCESSING THE RECORDING MENU ..............................................48
RESOLUTION/VIDEO CLIP SETTING .................................................51
FOCUS AREA SETTING ......................................................................52
ISO SENSITIVITY .................................................................................53
WHITE BALANCE ................................................................................54
EXPOSURE CORRECTION .................................................................56
DATE IMPRINTING ON STILL IMAGES ..............................................57
English 4
CONTENTS
PLAYBACK
DISPLAYING THE PLAYBACK MENU ................................................ 58
IMAGE PROTECT ............................................................................... 60
ROTATE IMAGE .................................................................................. 61
COPY DATA ........................................................................................ 62
PRINT SETTINGS ............................................................................... 64
SLIDESHOW PLAYBACK ................................................................... 70
DISPLAYING STILL IMAGE PROPERTIES ........................................ 71
OPTIONS
DISPLAYING THE OPTION MENU ..................................................... 72
POST-VIEW SETTING ........................................................................ 75
ADJUST THE MONITOR BRIGHTNESS ............................................. 76
SCREEN LANGUAGE ......................................................................... 77
TV SYSTEM SETTING ........................................................................78
AUTO POWER OFF FUNCTION ......................................................... 79
FILE No. RESET FUNCTION .............................................................. 81
INITIALIZING THE CARD MEMORY AND INTERNAL MEMORY ...... 84
RESETTING THE CAMERA SETTINGS ............................................. 86
CHECKING THE REMAINING INTERNAL MEMORY AND
CARD MEMORY ............................................................................. 87
CHECKING THE REMAINING BATTERY CHARGE ........................... 88
5 English
OTHER DEVICES AND CONNECTIONS
CONNECTING TO A TV .......................................................................90
CONNECTING TO A COMPUTER .......................................................91
DIRECT PRINTING ..............................................................................98
APPENDICES
COMMONLY ASKED QUESTIONS ...................................................105
TROUBLESHOOTING ........................................................................111
SPECIFICATIONS ..............................................................................117
HINTS FOR TAKING PICTURES .......................................................124
English 6
CHECKING THE INCLUDED ACCESSORIES
i AA Alkaline Batteries (2) i Video Cable (1)
USB Cable (1)
i
i Wrist Strap (1)
7 English
i “SAFETY MANUAL”
(safety precautions booklet)
Please read this booklet
carefully before using the
digital camera.
Attaching the Wrist Strap
English 8
Media cards that can be used with this camera
The types of card that can be inserted into and used with this camera are:
i SD Memory Card
i Multi Media Card
What “card” means in this manual
i In this manual, SD Memory Cards and Multi Media Cards that can be used
in this digital camera are referred to as “card”.
i The cards in the illustrations in this manual are SD Memory Cards, but all
installation, removal, and formatting procedures are the same for both SD
Memory Cards and Multi Media Cards.
9 English
GETTING THE MOST OUT OF YOUR CAMERA
AUTO
USE AUTO SETTINGS
Your UDC-5M is loaded with lots of functions including an easy-to-understand
display, a large screen, extensive scene functions, and more.
k Abundant scene functions
You can select from a variety of preset modes (aperture, shutter speed, etc.)
for specific shooting conditions.
AUTO
AUTO
USE AUTO SETTINGS
USE AUTO SETTINGS
k Speedy mode-switching
Switch from still image shooting to video clip recording with a single button.
VIDEO CLIP
English 10
SYSTEM MAP
The included accessories can be used to connect your camera to a computer,
printer or TV. By connecting the camera to your computer, you can, for example, copy your photos to the computer’s hard disk. You can connect it to a
printer for direct printing of your photos. Or take the card to a photo shop to
have your photos printed there.
Internet
Computer
USB Cable
Printer
11 English
Video Cable
TV
Commercially
available SD Memory
Card/Multi Media Card
i Card reader
i DPOF-compatible
printer
i Photo shop
PART S N A M E S
SETUP
Front
Shutter button
on/off button
Flash
Self-timer indicator
Lens
USB/VIDEO terminal
cover
English 12
PARTS NAMES
Rear
Illumination sensor
• Detects the ambient
brightness and
automatically
adjusts the
brightness of the
monitor accordingly.
Monitor
Bottom
Zoom switch [W]/[T]
Battery/card cover
Strap holder
Playback button [=]
menu button
[l] button
Tripod stand hole
[n] button
[m] button
ok button
Delete button
[%]
[o] button
13 English
INSTALLING THE BATTERIES AND
CARD
Your camera has an internal memory, which means that you can take photos
even when no card is installed. By using a card, however, you will be able to
take many more photos.
The card can be used after it has been formatted with the camera (page 84).
1 Open the battery/card cover.
h While gently pressing the
battery/card cover, slide it open.
2 Insert the batteries.
h Make sure that the batteries’
polarities (M and N) are
correct.
Battery/card cover
Batteries
English 14
INSTALLING THE BATTERIES AND CARD
3 Insert the card.
h Firmly insert the card until it
clicks into place.
4 Close the battery/card cover.
When removing the card...
h To remove the card, press it
down, and then release. The
card will protrude slightly, and
you can then pull it out.
Keep your finger on the card until it
is completely inserted or released.
i If you remove your finger too soon,
the card may spring out and
become lost or hit someone in the
eye.
[o] mark
1 Open
2 Press and
3 Pull out
Card
release
15 English
CAUTION
Be careful when removing the card.
i Do not attempt to forcibly remove the card.
i Never remove the card when the camera is connected to a computer or
printer, or when the self-timer indicator is flashing quickly. In doing so, you
risk losing the data stored in the card.
Manganese batteries cannot be used.
i Not only do manganese batteries have a short battery life, but there is the
danger of their overheating and causing damage to the digital camera.
Other batteries
i If you wish to use batteries other than the alkaline batteries (LR6), we
recommend the following.
h AA-size nickel metal hydride (NiMH) rechargeable batteries (SANYO
eneloop HR-3UTG) × 2
h AA-size Ni-Cd batteries (SANYO AA-size 2700 Series HR3-UG) × 2
Do not open the battery/card cover when the camera is turned on.
i If the battery/card cover is opened while the power is on, important data
may be lost. Uniden Corporation shall not be held responsible for any
losses that result from failure to comply with this warning.
HINT
Shooting without a card installed
i When a card is installed, images are recorded to and played back from the
card. When no card is installed, images are recorded to and played back
from the camera’s internal memory. When the camera is turned on with no
card installed, the internal memory icon is shown on the monitor to let
you know that the images you capture will be saved to the camera’s
internal memory.
About the internal backup battery
i This camera’s internal battery serves to maintain the date and time
settings, as well as the shooting settings. The backup battery will be fully
charged when the batteries are kept in the camera continuously for about 2
days. In the fully charged state, the backup battery will maintain the
camera settings for about 7 days.
When not using the camera for a long time, remove the batteries.
i A small amount of power is still used even if the camera is turned off, and it
is therefore recommended that the batteries be removed from the camera
if it is not going to be used for a long time. Note that when the batteries are
removed for a long period, the time and date settings may be cleared.
Before using your camera again, be sure to confirm that the camera
settings are correct.
English 16
TURNING THE CAMERA ON AND OFF
Turning on the camera
In the shooting mode
1 Press the on/off button.
h The camera turns on.
h The camera turns on in the
shooting mode that was active
before it was last turned off.
on/off button
In the playback mode
1 Press the playback button [=] for
at least one second.
h The Playback Screen appears on
the monitor (pages 31 and 37).
Monitor
Playback button [=]
Turning off the camera
1 Press the on/off button.
h The camera turns off.
<If the camera was turned on by pressing the playback button [=]>
h When the playback button [=] or on/off button is pressed, the
camera turns off.
17 English
About the auto power off function
In order to preserve battery power when, for example, the camera has
accidentally been left on, the camera is furnished with an “auto power off”
function by which the camera automatically turns off after a certain period of
inactivity (about 1 minute during shooting or about 3 minutes during playback
[factory default settings]).
i If the auto power save function has operated to turn the camera off, press
the on/off button to turn it back on.
i You can change the setting for the time elapsed before the camera
automatically turns off (page 79).
i When the camera is connected to a computer or printer using the USB
Cable, the auto power save function is disabled, and the camera turns off
after about 12 hours.
HINT
If the K icon appears...
i When a picture is taken, the date and time it was captured is recorded with
it. When the date and time cannot be recorded with the image because the
date and time have not yet been set (page 19), the K icon appears. To
have the date and time recorded with images, please make this setting
before capturing images.
English 18
DATE AND TIME SETTINGS
CLOCK SET
OK
The camera will record the date and time an image is captured so that you
can display them during playback. Therefore, before capturing images, make
sure the correct date and time are set.
Example: To set the clock to 7:30 p.m. on December 24, 2006
1 Press the on/off button to turn the
camera on, and press the menu
button.
h The Recording Menu appears
(page 48).
2 Press the [o] button to select the
3 tab.
h The Option Menu appears.
3 Press the [m] button to select
“CLOCK SET”, and press the ok
button or the [m] button.
h The Clock Set Screen appears.
h The current date and time settings
are shown.
h Follow the procedures below to
enable or disable the date display
during playback, to set the display
format for the date, and to set the
date and time.
h To return to the Option Menu, press
the menu button.
RECORDING MENU
RESOLUTION
FOCUS METHOD
ISO
WHITE BALANCE
EXPOSURE
INSERT DATE ON IMAGE OFF
OPTION MENU (1/2)
CLOCK SET
POST VIEW
LCD BRIGHTNESS
LANGUAGE
TV SYSTEM
AUTO POWER OFF
CLOCK SET
CLOCK SET
2006/04/01 12:00
D / M / Y
OK
OK
OK
3SEC
NTSC
19 English
4 Set the date and time.
CLOCK SET
OK
CLOCK SET
OK
CLOCK SET
OK
1 Press the [n] or [o] button to
change the year indication.
h Repeat these steps to select the
month indication and day
indication, and set the date to
December 24, 2006.
2 Press the ok button or the [m]
button to select the time indication.
3 Press the [n] or [o] button to
change the time setting.
4 Press the [m] button to select the
M/D/Y indication.
5 Press the [n] or [o] button to
change the displayed date order.
CLOCK SET
CLOCK SET
2006/12/24 00:00
D / M / Y
OK
OK
OK
CLOCK SET
CLOCK SET
2006/12/24 19:30
D / M / Y
OK
OK
OK
CLOCK SET
CLOCK SET
2006/12/24 19:30
D / M / Y
OK
OK
OK
h Press the [n] button to change the displayed date order as follows:
M / D / Y → Y / M / D → D / M / Y
h Press the [o] button to change it in the reverse order.
English 20
DATE AND TIME SETTINGS
5 Press the ok button.
h The date and time setting is completed, and you are returned to the
Option Menu.
h The Option Menu is canceled when the menu button is pressed.
HINT
i Under normal conditions, while the batteries are being replaced, an
internal battery will maintain the date and time settings. However, there is a
small chance the settings may be lost. (The backup will last for about 7
days.) It is recommended to check that the date and time settings are still
correct after replacing the batteries and before shooting or recording of any
type (follow steps 1 to 4).
To correct the date and time settings
i In step 4, select the indication that you want to change, and follow the
procedure to change the indication.
21 English
BASIC OPERATION
BEFORE TAKING PICTURES
How to hold the camera
Hold the camera securely, keeping your elbows close to your body and
making sure the camera is stable.
Correct hold Incorrect hold
A finger is blocking the lens or flash.
Make sure that the lens and flash are not blocked by your fingers or the Wrist
Strap.
HINT
i Images captured in the still image shooting mode can be rotated when
they are played back (page 61).
i When the optical zoom is used or when the autofocus is operating, the
image may appear to waver, but this is not a malfunction.
English 22
BEFORE TAKING PICTURES
Using the autofocus
The autofocus will work in almost all situations; however, there are certain
conditions that may cause the autofocus function to not work properly.
k Conditions that may cause incorrect focus
The following examples are some of the situations where the autofocus
function may not work.
i Subjects with low contrast, very
bright subjects at the center of the
image or dark subjects or locations
Use the focus-lock function (page 29)
to lock the focus on an object with
contrast at the same distance as the
desired subject.
i Subjects without vertical lines
Use the focus-lock function to lock the
focus while framing the subject
vertically, then re-orient the camera to
compose a horizontally framed image.
23 English
The following examples are some of the situations where the autofocus
function may work, but not as desired.
i When both near and far objects are
present
Use the focus-lock function to lock the
focus on an object at the same
distance as the desired subject, then
reposition the camera to compose the
picture.
i Fast-moving subjects
Use the focus-lock function to lock the
focus on an object at the same
distance as the desired subject, then
reposition the camera to compose the
picture.
English 24
BEFORE TAKING PICTURES
2006.12.24
100-0001
Switching between the shooting mode and
playback mode
Switch between the shooting mode and the playback mode.
1 Press the on/off button to turn the
camera on.
2 Press the playback button [=].
h Each time the playback button is
pressed, the camera switches
between the shooting mode and
the playback mode.
HINT
To turn the camera on in the playback
mode
i Press the playback button [=] for at
least 1 second, and the camera will
turn on in the playback mode.
on/off button
<Shooting mode>
2006.12.24
2006.12.24
<Playback mode>
Playback button
[=]
180
100-0001
100-0001
25 English
How to switch the shooting mode
Your camera can capture single still photos (still image shooting mode) and
record video clips (video clip recording mode).
1 Press the on/off button to turn
the camera on.
2 Press the [n] button.
h The screen to set the shooting
mode and the self timer
appears.
Still image shooting
Video clip recording
STILL IMAGE
3 Press the [m] button to select
the shooting mode.
4 Press the ok button.
h The selected shooting mode is
set.
h An icon in the upper left area of
the monitor indicates the active
shooting mode setting.
on/off button
[n] button
ok button
180
<Shooting mode>
c:Still image shooting mode
t:Video clip recording mode
English 26
BEFORE TAKING PICTURES
Switching the display mode
In the shooting mode, you can select the either the “settings display mode” which allows
you to confirm the shooting settings on the monitor while you shoot, or the “normal display
mode” in which the setting indications are turned off, providing a full view of the subject.
1 Press the on/off button to turn the
camera on.
2 Press the ok button.
h Each time the ok button is
pressed, the camera switches
between the settings display
mode and the normal display
mode.
on/off button
ok button
180
<Settings display mode>
<Normal display mode>
27 English
Hints for taking pictures
Where is the image data saved?
i All the image data is recorded in the camera’s internal memory or on the
card installed in the camera.
i When a card is installed in the camera, the data is recorded on the card. If
no card is installed, the data is recorded in the camera’s internal memory.
Taking pictures in backlight conditions...
i When taking pictures with the light coming from behind the subject, due to
the characteristics of the CCD, light lines or ghost patterns (flare
phenomenon) may appear in the captured image. In this situation, it is
recommended that you avoid taking pictures with the subject lit from
behind.
English 28
CAPTURING AND PLAYING BACK STILL IMAGES
F2.8
1/30
Shooting still images
1 Set the camera to the still
image shooting mode
(page 26).
2 Press the shutter button
halfway.
h Engage the autofocus by
pressing the shutter button
halfway (focus lock).
3 Continue to gently press the
shutter button all the way.
h Press the shutter button
gently, taking care not to
move the camera.
h The image that was
captured appears on the
monitor as long as the
shutter button is kept
pressed (post view).
Shutter button
F2.8
F2.8
1/30
1/30
Still image shooting icon
<Still Image Shooting Screen>
29 English
4 Release your finger from the shutter button.
h The captured image is recorded.
HINT
What is focus lock?
When the shutter button is pressed
i
halfway, the camera focuses on the
subject, and as long as the shutter button
is kept pressed halfway, the focus is fixed
(locked) at the same distance. This is
called “focus lock”. After focusing on the
subject, you can then reorient the camera
while keeping the shutter button pressed
halfway to compose the picture you like.
What is the camera focusing on?
A target mark & on the monitor shows
i
the area the camera is focusing on.
i
The camera automatically determines the
correct focus by measuring from 9
different focus points within the shooting
area. If the target mark is at a position
that is different from the point you wish to
focus on, you can refocus, for example,
by changing the shooting angle.
i The large target mark appears when
the camera focuses on a wide area in
the center of the screen.
About the focus indicator
A green focus indicator appears when
i
the subject is successfully focused, or a
red focus indicator when the camera was not able to focus the subject.
The shutter speed and aperture are displayed
When the camera focuses and the target mark appears, at the same time, the
i
shutter speed and aperture settings are also displayed. You can use them as a
reference when shooting.
If the motion alert icon appears...
i During still image shooting, if the shutter speed is slow and the possibility
that the image may be blurred due to camera shake becomes high, the
motion alert icon may appear on the monitor. In this case, use a tripod to
stabilize the camera when shooting, or set the flash operation mode to
automatic (page 43).
i When shooting with the scene function set to the fireworks ^ mode, the
motion alert icon always appears, but this is normal.
Focus indicator
F2.8
1/30
Shutter speed
Aperture
Motion alert icon
F2.8
1/15
Target mark
English 30
CAPTURING AND PLAYING BACK STILL IMAGES
2006.12.24
100-0001
Viewing still images
5
Press the playback button [=].
h If the playback button [=]
was pressed to turn the
camera on, however, press
the playback button [=] for
at least 1 second.
h The image most recently
captured appears on the
monitor.
Playback button [=]
6 View other images.
h Press the [l] or [m] button to
display the previous or next
image.
To display the previous
image:
Press [l].
To display the next image:
Press [m].
h To return to Shooting Screen,
press the playback button
[=].
<If the camera was turned on
by pressing the playback
=
button [
h When the playback button
]>
[=] or on/off button is
pressed, the camera turns off.
2006.12.24
2006.12.24
100-0001
100-0001
When you are finished viewing images...
i Press the on/off button to turn the camera off.
31 English
9-image display playback
0001
100
0002
0003
0004
0005
0006
0007
0008
0009
1 Press the playback button
[=].
2 Press [W] ([P]) on the
zoom switch.
h The 9-image display
appears.
3 Select the image to play
back.
h Press the arrow buttons to
move the orange frame to
the desired image, and
press the ok button.
Instead of pressing the ok
button, you can press [T]
([]]) on the zoom switch
to show the image full
screen.
Video
clip
Still image
100
100
0001
0001
0004
0004 0005
0007
0007
Folder number
Zoom switch [W]
ok button
Arrow buttons
Orange frame
0003
0002
0002
0005
0008
0008
0003
0006
0006
0009
0009
Image number
English 32
CAPTURING AND PLAYING BACK STILL IMAGES
100%
113%
MOVE
ZOOM I/O
Magnifying (zooming in) the image
1 Display the image that you want to magnify.
2 Press [T] ([]]) on the zoom
switch.
h Magnification is enabled.
h The image is magnified, and the
central portion of image is
displayed.
h Press the arrow buttons to view
different parts of the magnified
image.
To magnify:
Magnification increases with
each press of [T] ([]]) on the
zoom switch.
To return to normal size:
Magnification decreases with
each press of [W] ([P]) on the
zoom switch.
h Press the ok button to return to the
normal (100%) view.
33 English
MOVE
MOVE
OK
100%
100%
ZOOM I/O
ZOOM I/O
113%
113%
Erasing files
DELETE
OK
You can erase files if you no longer need them. You can erase the files one at
a time, or all at once.
1 To erase data from the card,
perform the delete procedure with
the card installed in the camera. To
erase data from the camera’s
internal memory, remove the card
before performing the delete
procedure.
2 Set the camera to the playback
mode, and press the delete [%]
button.
h The Delete Screen appears.
DELETE ALL:
Erases all the data.
DELETE SINGLE:
Erases one file at a time.
EXIT:
Returns to the Playback Screen.
3 Delete the files.
<To delete all the files>
1 Use the [l] and [m] buttons to view the images and check if it is OK
to delete all the files.
2 Press the [n] or [o] button to select “DELETE ALL”.
3 Press the ok button.
h The Delete Confirmation Screen appears. To erase the files, select
“YES”, and press the ok button. When the file delete is completed,
“NO IMAGE” is shown.
Delete button [%]
DELETE
DELETE
DELETE ALL
DELETE SINGLE
OK
OK
OK
EXIT
English 34
CAPTURING AND PLAYING BACK STILL IMAGES
<To delete one file>
1 Use the [l] and [m] buttons to display the file you wish to delete.
2 Press the [n] or [o] button to select “DELETE SINGLE”.
3 Press the ok button.
h The currently displayed file is deleted.
h To delete other files, repeat steps 1 to 3.
CAUTION
About protected images
i Files that are protected from accidental erasure cannot be deleted. To
erase protected files, set the protect setting for the file to off (page 60), and
then follow the file delete procedure.
HINT
To quickly delete a still image immediately after capturing it (direct
delete)
i If you press the delete button [%] while the post-view image is displayed
(page 75), the image is immediately deleted (still images only).
1 While the post-view image is being displayed, press the delete button
[%].
h The screen to confirm the deletion appears.
2 Select “YES”, and press the ok button.
h The currently shown image is deleted, and the display returns to
the Shooting Screen.
h If you do not wish to delete the image, select “NO” and press the
ok button.
35 English
VIDEO CLIP RECORDING AND PLAYBACK
00:02:30
REC00:00:30
Recording a video clip
1 Set the camera to the video
clip recording mode
(page 26).
Shutter button
2 Press the shutter button.
h Video clip recording
begins. During recording,
the video clip length and
the remaining recording
time available are shown
on the monitor.
h It is not necessary to
continue pressing the
shutter button while
shooting.
3 End the recording.
h Press the shutter button
again to stop recording and
save the video clip.
Video clip shooting icon
CAUTION
i This camera records video signals only; it does not record sound.
Video clip length
Remaining recording
time available
00:02:30
00:02:30
REC00:00:30
REC00:00:30
English 36
VIDEO CLIP RECORDING AND PLAYBACK
2006.12.24
100-0008
Playing back the video clip
4 Press the playback button
[=].
h If the playback button [=]
was pressed to turn the
camera on, however, press
the playback button [=] for
at least 1 second.
h The video clip just recorded
appears on the monitor.
h Video clips are indicated by
a video clip pattern along
the top and bottom of the
screen.
5 Press the ok button.
h Video clip playback begins.
h To stop playback, press the
[o] button.
Playback button [=]
2006.12.24
2006.12.24
Video clip pattern
[o] button
100-0008
100-0008
37 English
Outline of playback operation
To do this... Do this
Stop playback During playback, press the [o] button.
Pause
To extract a still image
To play back
one image
at a time
(single-
frame step)
Slow
playback
accelerate
playback
Return to normal playback speed
To
During forward
playback
During reverse
playback
During forward
playback
During reverse
playback
Forward
playback
Reverse
playback
During playback, press the ok button.
During accelerated playback, press the [n] button.
While playback is paused, press the shutter button.
While playback is paused, press the [m]
button.
While playback is paused, press the [l]
button.
While playback is paused, press and hold the
[m] button.
While playback is paused, press and hold the
[l] button.
During forward playback, press the [m] button.
* The playback speed changes each time the
[m] button is pressed, as follows:
Normal playback
Press the [l] button to resume normal
playback speed.
During forward playback, press the [l] button.
* The playback speed changes each time the
[l] button is pressed, as follows:
15x ← 10x ← 5x
Press the [m] button to resume normal
playback speed.
Press the ok button.
→
2x → 5x → 10x → 15x
When you are finished viewing video clips...
i Press the on/off button to turn the camera off.
English 38
VIDEO CLIP RECORDING AND PLAYBACK
CAUTION
If no audio is heard...
i Audio cannot be played back.
The data for a video clip is very large.
i Therefore, be aware that if the video clip is uploaded to a computer to be
played back, the computer may not be able to play back the video fast
enough, making it appear jerky. (The video will always be displayed
properly on the camera monitor.)
If video clip recording stops even when there is card memory
remaining…
i Depending on the card you are using, recording may stop even if there is
remaining memory in the card.
i For video clip recording, it is recommended that a high-speed memory
card be used.
39 English
USING THE SCENE FUNCTION
AUTO
USE AUTO SETTINGS
You can select from a variety of preset settings (aperture, shutter speed, etc.)
for specific shooting conditions.
1 Set the camera to the shooting
mode (page 25), and press the [o]
button.
h The screen to select the settings
suitable for the scene (shooting
conditions) appears.
2 Use the arrow buttons to select the
desired setting.
<Features of each setting>
Scene setting Features
Sports
Por trai t
Flowers
Landscape
Night view
portrait
X
Auto
Y
Z
[
\
]
The camera uses the optimum settings.
Capture a split-second image of a fast-moving subject.
Enhance the three-dimensional feel of the subject by
blurring the background.
Capture the vivid colors of flowers.
For beautiful shots of distant scenery.
Photograph the subject while keeping the background
night scenery.
AUTO
AUTO
USE AUTO SETTINGS
USE AUTO SETTINGS
<Example: In the still
image shooting mode>
(continued on next page)
English 40
USING THE SCENE FUNCTION
Scene setting Features
^
Fireworks
_
Lamp
i
Camera-shake
reduction
7
Cosmetic
8
Monochrome
9
Sepia
?
Sharpness
>
Contrast
@
Vivid
For capturing fireworks at night.
For shooting in very dark conditions.
Increases shutter speed and ISO sensitivity to reduce
blurred image due to camera shake (still image shooting
mode only).
Skin tones are enhanced in close-up shots.
Create monochrome (black-and-white) photos.
Create sepia-tone photos.
Accentuates the outlines in the image.
Accentuates the light and dark areas in the image.
Image colors are more brilliant.
3 Press the ok button.
h This completes the scene function
setting.
h The display returns to the Shooting
Screen.
h The scene function setting is shown
on the monitor.
41 English
180
Scene function setting
(No icon displayed for X
mode)
USING THE ZOOM
Your camera has two zoom functions: optical zoom and digital zoom.
1 Set the camera to the shooting
mode (page 25), and point the
camera lens at the subject.
Zoom switch
2 Press the zoom switch to
compose the desired image.
[T]: Zoom in on the subject.
[W]: Zoom out.
h When the zoom switch is
pressed, the zoom bar appears
on the monitor.
h When the optical zoom factor is
at maximum, zooming stops
temporarily. When [T] on the
zoom switch is pressed again,
the mode changes to the digital
zoom mode and zooming
continues.
3 Take the picture.
HINT
Can’t access the optical zoom?
i During video clip recording, only the digital zoom is available, and the
optical zoom cannot be used.
Monitor
When both optical
and digital zoom are
enabled
Optical zoom
Digital zoom (yellow)
Zoom bar
Point er
English 42
FLASH SETTING
The flash is used for taking pictures where there is insufficient light and when
the subject is in shade or in backlight conditions. Your camera’s flash has four
modes of operation (automatic flash mode, forced flash mode, flash off mode
and red-eye reduction mode). Select the flash mode that is appropriate for the
surrounding conditions. The flash works only when capturing images in the
still image shooting mode.
1 Set the camera to the still image
shooting mode (page 26), and
press the [l] ([?]) button.
h The flash setting appears on the
monitor.
k: The camera will detect the
subject brightness and use the
flash only when required. In a
backlight situation, if only the
center of the image is very dark,
the flash will operate to
compensate (auto flash).
m: The flash will operate with every
image captured regardless of the
conditions. Use this setting
under backlight conditions, when
the subject is in shade, under
fluorescent lighting conditions,
etc. (forced flash).
l: The flash will not operate even in
dark situations. Use this setting
when capturing an image in a
location where flash
photography is prohibited, or
when shooting a night landscape
scene (flash off).
J: The digital camera will detect the subject brightness and use the
flash only when required. At this time the flash will operate in a
manner that reduces the red reflection (“red-eye”) in the subject’s
eyes (red-eye reduction).
[l] ([?]) button
FLASH
Flash mode icon
AUTO
43 English
2 Press the [n] or [o] button to select the desired flash mode, and
press the ok button.
3 Press the shutter button.
h The picture is snapped and the flash operates according to the
selected mode.
HINT
In the automatic flash mode...
i The k icon indicating the flash setting is not shown on the Shooting
Screen.
i In the automatic flash mode, when the subject is in focus, a k icon
appearing on the monitor indicates that the flash will operate.
English 44
SELF-TIMER
Self-timer photography is available in the still image shooting mode.
1 Set the camera to the shooting
mode (page 25), and press the [n]
button.
STILL IMAGE
2 Use the [n] and [o] buttons to select
the self-timer setting.
y: The image is captured about
2 seconds after the shutter button
is pressed.
x: The image is captured about
10 seconds after the shutter button
is pressed.
3 Press the ok button.
h This completes the self-timer setting.
Self-timer menu
45 English
HINT
To pause or cancel the self-timer function...
i If the shutter button is pressed again before the shutter is released, the
self-timer countdown temporarily stops. Press the shutter button one more
time to restart the self-timer.
i To cancel self-timer photography, set the self-timer setting to off c.
i After the self-timer picture is snapped, the self-timer is automatically reset
to off.
When x is selected...
i When the shutter button is pressed,
the self-timer indicator flashes for
approximately 10 seconds, after
which shooting begins.
i About 3 seconds before shooting,
the self-timer indicator flashes
faster.
Self-timer indicator
English 46
FOCUS RANGE
1 Set the camera to the shooting
mode (page 25), and press the [m]
button.
h The screen to set the focus range
appears.
7: The camera automatically
focuses on the subject within a
range of 10 cm (3.94 in.) (Wide
end) or 40 cm (15.75 in.) (Tele
end) to infinity (autofocus).
+: You can focus on a subject within
a range of 5 cm (1.97 in.) (Wide
end) or 40 cm (15.75 in.) (Tele
end) to 70 cm (27.56 in.)
(macro).
2 Press the [n] or [o] button to select the desired focus range, and
press the ok button.
h The specified focus range is set, and the camera returns to the
Shooting Screen.
HINT
i When the focus range is set to macro +, the zoom is set to the wide end.
FOCUS
AUTO
47 English
SHOOTING
ACCESSING THE RECORDING MENU
Detailed shooting settings are accessed from the Recording Menu.
1 Set the camera to a shooting
mode (page 26).
2 Press the menu button.
h The Recording Menu
corresponding to the shooting
mode set in step 1 appears.
h The Recording Menu can be
canceled by pressing the menu
button.
menu button
RECORDING MENU
RESOLUTION
FOCUS METHOD
ISO
WHITE BALANCE
EXPOSURE
INSERT DATE ON IMAGE OFF
English 48
ACCESSING THE RECORDING MENU
Overview of the Recording Menu
RECORDING MENU
1
2
3
4
5
6
RESOLUTION
FOCUS METHOD
ISO
WHITE BALANCE
EXPOSURE
INSERT DATE ON IMAGE OFF
49 English
1 Resolution menu/video clip
mode menu (page 51)
<Still image shooting mode>
u: Shoot at 2,592 × 1,944
pixels
Q: Shoot at 2,048 × 1,536
pixels
h: Shoot at 1,024 × 768
pixels
[: Shoot at 640 × 480 pixels
<Video clip recording mode>
5: Shoot at 320 × 240 pixels
d: Shoot at 640 × 480 pixels
2 Focus mode menu (page 52)
B: 9-point focus mode
C: Spot focus mode
3 ISO sensitivity menu
(page 53)
t: Sets the ISO sensitivity
automatically (corresponds
to ISO64 to 400).
1: Corresponds to ISO64
u: Corresponds to ISO100
v: Corresponds to ISO200
w: Corresponds to ISO400
6: Corresponds to ISO800
i When you specify multiple functions that cannot be simultaneously
enabled, the function which was last set becomes the active setting, and
the other settings accordingly change automatically.
4 White balance menu (page 54)
>: The camera will determine
the setting automatically.
r: For photography in fair
weather (sunny) conditions
o: In overcast conditions
p: Under fluorescent lighting
q: Under incandescent
lighting
]: For setting the most
accurate white balance
5 Exposure correction menu
(page 56)
h Change the brightness of the
image.
6 Date imprint menu (page 57)
h Imprint the date on still images
when shooting (still image
shooting mode only).
English 50
RESOLUTION/VIDEO CLIP SETTING
By setting the image resolution (pixels) to a higher setting, image detail is
enhanced for a smoother, finer picture. However, the file size also becomes large
and uses more memory. Select the resolution setting that suits your purpose.
1 Display the Recording Menu (page 48).
2 In the still image shooting mode
select “RESOLUTION”, or in the
video clip recording mode select
“VIDEO CLIP QTM”, and press the
ok button.
h The resolution menu or video clip
mode menu appears.
<Still image shooting mode>
u: Shoot image at 2,592 × 1,944
pixels
Q: Shoot image at 2,048 × 1,536 pixels
h: Shoot image at 1,024 × 768 pixels
[: Shoot image at 640 × 480 pixels
<Video clip recording mode>
d: Shoot at 640 × 480 pixels
5: Shoot at 320 × 240 pixels
RECORDING MENU
RESOLUTION
FOCUS METHOD
ISO
WHITE BALANCE
EXPOSURE
INSERT DATE ON IMAGE
<Example: In the still
image shooting mode>
3 Select the desired icon, and press the ok button.
h The selected resolution setting or video clip mode setting is set.
51 English
FOCUS AREA SETTING
You can choose from the following 2 types of autofocus when shooting still
images:
9-point range finder focus: The correct focus is determined from 9 different
Spot focus: The camera focuses on the subject in the center
focus points within the shooting area visible on the
monitor. When the image is focused, a target
mark & appears.
of the monitor.
1 Display the Recording Menu
(page 48).
2 Select “FOCUS METHOD” and
press the ok button.
h The focus mode menu appears.
B: 9-point range finder focus is
selected.
C: Spot focus is selected.
h When the spot focus setting is
selected, the focus mark + appears
in the center of the monitor.
3 Select the desired icon, and press
the ok button.
h The focus area is set.
RECORDING MENU
RESOLUTION
FOCUS METHOD
ISO
WHITE BALANCE
EXPOSURE
INSERT DATE ON IMAGE
Focus mark
English 52
12
ISO SENSITIVITY
With the initial settings, the ISO sensitivity is automatically set according to
the brightness of the subject. However, the ISO sensitivity can be set to a
fixed setting.
1 Display the Recording Menu (page 48).
2 Select “ISO” and press the ok
button.
h The ISO sensitivity menu appears.
t: Sets the ISO sensitivity
automatically (equivalent to
ISO64 to 400 [video clip recording
mode: ISO256 to 800]).
1: Sets the sensitivity to ISO64
equivalent (video clip recording
mode: ISO256).
u: Sets the sensitivity to ISO100 equivalent (video clip recording
mode: ISO400).
v: Sets the sensitivity to ISO200 equivalent (video clip recording
mode: ISO800).
w: Sets the sensitivity to ISO400 equivalent (video clip recording
mode: ISO1,600).
6: Sets the sensitivity to ISO800 equivalent (video clip recording
mode: ISO3,200).
RECORDING MENU
RESOLUTION
FOCUS METHOD
ISO
WHITE BALANCE
EXPOSURE
INSERT DATE ON IMAGE
3 Select the desired icon, and press the ok button.
h The ISO sensitivity is set.
HINT
i By setting a higher ISO sensitivity, you can set higher shutter speeds and
capture images in darker locations, but noise in the captured images may
increase.
CAUTION
Does the image appear to flicker when recording a video clip?
i If recording a video clip under fluorescent lights with the ISO sensitivity set
to 6, a noticeable flicker may appear in the image.
53 English
WHITE BALANCE
This camera automatically adjusts the white balance under most lighting
conditions. However, if you want to specify the lighting conditions or change
the overall tone of the image, the white balance can be manually set.
1 Display the Recording Menu (page 48).
2 Select “WHITE BALANCE” and
press the ok button.
h The white balance menu appears.
>: The camera will make the white
balance adjustment automatically
based on the natural and artificial
light conditions. This is the setting
used in the auto mode.
r: For shooting outside on a sunny
day.
o: For shooting outside on a cloudy day.
p: For shooting inside under fluorescent lighting.
q: For shooting inside under incandescent lighting.
]: For more accurate adjustment or when the light source cannot be
specified (one-push).
RECORDING MENU
RESOLUTION
FOCUS METHOD
ISO
WHITE BALANCE
EXPOSURE
INSERT DATE ON IMAGE
English 54
WHITE BALANCE
3 Select the desired icon, and press the ok button.
h If the ] icon was selected, fill the entire screen with white paper,
and press the ok button.
h This completes the white balance setting.
HINT
To cancel the white balance setting
i Perform step 1, select >, and then press the ok button.
55 English
EXPOSURE CORRECTION
When capturing images, you can make the image lighter or darker.
1 Point the camera lens at the
subject, and display the
Recording Menu (page 48).
2 Select “EXPOSURE” and press
the ok button.
h The screen to adjust the
exposure appears.
3 Press the [n] or [o] button to
select the exposure numerical
value, and press the ok button.
h The specified exposure is set,
and you are returned to the
Recording Menu.
RECORDING MENU
[n] or [o] button
ok button
HINT
i The exposure correction setting
returns to ±0 after the camera is turned off.
EXPOSURE
English 56
0
DATE IMPRINTING ON STILL IMAGES
When shooting still images, you can have the date the image was captured
imprinted on the image.
1 Display the Recording Menu
(page 48).
2 Select “INSERT DATE ON IMAGE”,
and press the ok button.
h The date imprint menu appears.
OFF: The date of the capture is not
imprinted on the image.
ON: The date of the capture is
imprinted on the image.
3 Press the [n] or [o] to select the
desired setting, and press the ok
button.
h The date imprint mode is set, and
you are returned to the Recording
Menu.
HINT
If the imprinted date is shown as [- - - - .- - .- -] …
i The date and time settings have not yet been completed. Set the camera
to the correct date and time (page 19).
RECORDING MENU
RESOLUTION
FOCUS METHOD
ISO
WHITE BALANCE
EXPOSURE ON
INSERT DATE ON IMAGE
OFF
57 English
PLAYBACK
PAGE 1 (BASIC SETTINGS)
DISPLAYING THE PLAYBACK MENU
The Playback Menu is used to adjust your camera’s playback settings.
1 Press the playback button [=].
h The display changes to the
Playback Screen.
2 Press the menu button.
h The Playback Menu appears.
h The Playback Menu is canceled
when the menu button is pressed.
Playback button [=]
menu button
PLAYBACK MENU
PROTECT
ROTATE
COPY FILE
PRINT SETTING
SLIDESHOW
English 58
DISPLAYING THE PLAYBACK MENU
Overview of the Playback Menu
PLAYBACK MENU
1
2
3
4
5
PROTECT
ROTATE
COPY FILE
PRINT SETTING
SLIDESHOW
1 [Protect] (page 60)
h Protect data from accidental
erasure (write protect).
2 [Rotate image] (page 61)
h Rotate still images.
3 [Copy file] (page 62)
59 English
4 [Print setting] (page 64)
h Specify the print settings.
5 [Slideshow] (page 70)
h Play back the images in a
slideshow format.
IMAGE PROTECT
Activate file protect?
OK
Cancel file protect?
OK
Prevent accidental erasure of data.
1 Display the data that you want to protect from accidental erasure,
and display the Playback Menu (page 58).
2 Select “PROTECT” and press the ok
button.
h The screen to set the protect
setting appears.
3 Select “YES” and press the ok
button.
h The protect mode is set for the
data.
h The protect mark B indicates that
the data is locked.
CAUTION
i Even if the protect mode is set for certain data files, they will be erased if
the card is reformatted (page 84).
HINT
To select a different image in steps 2 and 3...
i Press the [l] or [m] button.
To cancel the protect mode for an image...
i Display the desired data and repeat steps 1 to 3.
Activate file protect?
Activate file protect?
YES
OK
OK
EXIT
OK
OK
Cancel file protect?
Cancel file protect?
YES
EXIT
OK
OK
English 60
ROTATE IMAGE
Rotate image?
OK
Captured still images can be rotated to the correct orientation for viewing.
1 Display the image you wish to rotate, and display the Playback Menu
(page 58).
2 Select “ROTATE” and press the ok
button.
h The screen to rotate the image
appears.
Rotate image?
Rotate image?
OK
OK
YES
EXIT
3 Select “YES” and press the ok
button.
h Each time the ok button is pressed,
the image is rotated another 90
degrees.
HINT
i On the 9-image display playback, rotated images are shown in their
original orientation.
i An image for which the protect (locked) mode has been set cannot be
rotated.
61 English
OK
COPY DATA
Copy file?
OK
Images recorded in the camera’s internal memory can be copied to the card,
and likewise from the card to the internal memory.
1 Insert the card in the camera (page 14).
2 Display the Playback Menu (page 58).
3 Select “FILE COPY” and press the
ok button.
h The screen to copy files appears.
4 Select the copy direction.
INT MEM CARD:
Copy image data from the internal
memory to the card.
CARD INT MEM:
Copy image data from the card to the
internal memory.
* If no card is set in the camera, you
cannot copy data.
INT MEM
OK
OK
OK
CARD
Copy file?
Copy file?
CARD
INT MEM
English 62
COPY DATA
INT MEM
CARD
OK
5 Press the ok button.
h The screen to select the type of
copy appears.
h The copy source is shown in the
background on the screen.
COPY SINGLE:
Copy the data for one image.
COPY ALL:
Copy all the data from the copy
source to the copy destination.
INT MEM
INT MEM CARD
COPY SINGLE
COPY ALL
EXIT
OK
OK
OK
6 Select the desired type of copy.
<When selecting “COPY SINGLE”>
1 Press the [l] or [m] button to display the image you wish to copy.
2 Press the [n] or [o] button to select “COPY SINGLE”.
<When selecting “COPY ALL”>
1 Press the [n] or [o] button to select “COPY ALL”.
7 Press the ok button.
h The files are copied.
CARD
63 English
PRINT SETTINGS
Specify the printing
instructions?
OK
In addition to using your printer to print out still images captured with your
camera, as with conventional film, you can have prints made at shops offering
digital print services. Moreover, this camera is DPOF-compatible, so you can
use the camera to specify the number of prints, whether or not the date is
displayed on the print, and also to specify an index print.
Display the screen to set the print settings
1 Display the Playback Menu (page 58).
2 Select “PRINT SETTING” and press
the ok button.
h The screen to set the print settings
appears.
EACH IMAGE:
The print settings are specified for
each individual image.
ALL IMAGES:
The specified print settings apply to
all the still images on the card.
ALL CLEAR:
Clear all the print settings.
Specify the printing
Specify the printing
instructions?
instructions?
EACH IMAGE
ALL IMAGES
ALL CLEAR
OK
OK
OK
English 64
PRINT SETTINGS
HINT
About the DPOF format
i DPOF (Digital Print Order Format) is a print order format. You can connect
your camera to a DPOF-compatible printer to produce your prints. You can
also set the print settings (page 102) for the desired images, and then have
the reserved images printed automatically.
About the finished prints
i Images that have been rotated will be printed in their original orientation.
i The quality of the print output will differ depending on the print service and
printer used.
CAUTION
i It is not possible to set the print settings when there are 10,000 or more
files saved on the card.
65 English
Specifying date imprinting and number of prints
Specify the printing
instructions?
OK
EACH IMAGE
OK
You can specify print settings for each individual image (EACH IMAGE), or
apply the print settings to all the images on the card (ALL IMAGES).
1 Display the screen to set the print settings (page 64).
2 Select “EACH IMAGE” or “ALL
IMAGES”.
EACH IMAGE:
The set print settings are applied
only to the image currently
displayed.
ALL IMAGES:
The set print settings are applied to
all the still images on the card.
3 Press the ok button.
h The Date/Copies Print Screen
appears.
h If “EACH IMAGE” was selected,
press the [l] or [m] button to
display the desired image to print.
h The print settings for the currently
displayed image are shown in the
upper right area of the monitor. You
can press the [l] or [m] button to
confirm the print settings for each
image.
Specify the printing
Specify the printing
instructions?
instructions?
EACH IMAGE
ALL IMAGES
ALL CLEAR
OK
OK
OK
EACH IMAGE
EACH IMAGE
DATE
COPIES
EXIT
OK
OK
OK
Print settings status
NO
:
0
:
0
English 66
PRINT SETTINGS
EACH IMAGE
OK
EACH IMAGE
OK
4 Specify the number of prints and
whether the date is imprinted.
h Please specify the number of prints
before setting the date imprint
setting. The date imprint setting
cannot be set until the number of
prints has been entered.
<Specifying the number of prints>
1 Press the [n] or [o] button to
select “COPIES”.
2 Press the ok button.
h The Print Number Screen
appears.
3 Press the [n] or [o] button to
specify the number of prints.
h Press the [n] or [o] button until
the desired number of prints is
displayed.
4 Press the ok button.
h You are returned to the Date/
Copies Print Screen.
<Specifying dated prints>
1 Press the [n] or [o] button to
select “DATE”.
2 Press the ok button.
h The Print Date Screen appears.
3 Press the [n] or [o] button to
select the desired option.
YES:Print the date.
NO: Do not print the date.
4 Press the ok button.
h You are returned to the Date/
Copies Print Screen.
OK
OK
OK
OKOK
OK
OK
DATE
COPIES
DATE
COPIES
EACH IMAGE
EACH IMAGE
EXIT
EACH IMAGE
EACH IMAGE
EXIT
NO
NO
:
0
:
0
:
1
:
1
67 English
5 Select “EXIT”, and press the ok
EACH IMAGE
OK
button.
h You are returned to the display in
step 2.
CAUTION
i When printing images that were captured with the date imprint function
(page 57) set to ON, do not set the “DATE” print setting to “YES”. Images
that were captured with the date imprint function set to ON will be always
be printed with the date displayed. If the “DATE” print setting for such
images is set to “YES”, the date will appear on the photo print twice.
OK
OK
OK
DATE
COPIES
EXIT
EACH IMAGE
EACH IMAGE
YES
1
:
:
1
English 68
PRINT SETTINGS
Specify the printing
instructions?
OK
Clearing all the print settings
Delete the print settings for all images.
1 Display the screen to set the print settings (page 64).
2 Select “ALL CLEAR”.
3 Press the ok button.
h The Confirm All Clear Screen appears.
YES: Clear the print settings for all images.
EXIT: Cancel the clear procedure and return to the screen to set the
print settings.
4 Select “YES”, and press the ok button.
h All the print settings are cleared and you are returned to the screen to
set the print settings.
69 English
Specify the printing
Specify the printing
instructions?
instructions?
EACH IMAGE
ALL IMAGES
ALL CLEAR
OK
OK
OK
SLIDESHOW PLAYBACK
Play files automatically
OK
1 Display the Playback Menu (page 58).
2 Select “SLIDESHOW” and press the
ok button.
h The screen to set the slideshow
appears.
TIME: Adjust the transition speed
EFFECT: Select a transition effect
START: Begin slideshow playback.
<Changing the transition speed or transition effect>
1 Select “TIME” or “EFFECT”, press the ok button.
2 Press the [n] or [o] button to change the setting.
3 Press the ok button.
(the period that an image
is displayed before it
changes to the next
image).
as an image changes to
the next image.
3 Select “START”, and press the ok button.
h Slideshow playback starts.
h To stop slideshow playback, press the ok button or menu button.
Play files automatically
Play files automatically
1SEC
OK
TIME
EFFECT
START
OK
OK
FADE
English 70
DISPLAYING STILL IMAGE PROPERTIES
9
3
The settings that were active when a still image was captured can be
displayed (Information Screen).
1 Display the desired still
image.
2 Press the ok button.
h The Information Screen
appears.
h If the ok button is pressed
again, the Information
Screen is canceled.
1 Resolution setting
2 Resolution
3 Scene function setting
4 Image number
5 Protect setting
6 File size
7 Aperture value
8 Shutter speed
9 Exposure correction
setting
0 Remaining battery power
1
2
INFO
2592x1944
SIZE
IRIS
SHUTTER
EXPOSE 0
100-0004
713KB
F2.8
1/30
4
5
6
7
8
@
71 English
OPTIONS
DISPLAYING THE OPTION MENU
The Option Menu is used to adjust various camera settings.
1 Display the Recording Menu or Playback Menu.
h Recording Menu, see page 48
h Playback Menu, see page 58
2 Press the [n] or [o] button to
select the option tab 3.
h The Option Menu appears.
Option tab
OPTION MENU (1/2)
CLOCK SET
POST VIEW
LCD BRIGHTNESS
LANGUAGE
TV SYSTEM
AUTO POWER OFF
To exit the Option Menu
To return to the Shooting Screen or Playback Screen
→ Press the menu button.
To return to the Recording Menu or the Playback Menu
→ With the option tab 3 selected, press the [n] or [o] button.
English 72
3SEC
NTSC
DISPLAYING THE OPTION MENU
Overview of the Option Menu
OPTION MENU (1/2)
1
2
3
4
5
6
CLOCK SET
POST VIEW
LCD BRIGHTNESS
LANGUAGE
TV SYSTEM
AUTO POWER OFF
3SEC
NTSC
7
8
9
73 English
FILE NO. RESET
FORMAT
RESET SETTINGS
1 [Date and time setting]
(page 19)
h Set the camera’s internal
clock.
2 [Post-view] (page 75)
h Specify how long a still image
is displayed on the monitor
after it is captured.
[LCD brightness] (page 76)
3
h Adjust the brightness of the
monitor.
4 [Screen language] (page 77)
h Select the language in which
the monitor messages are
displayed.
5 [TV system setting] (page 78)
h Select the type of TV signal
that is output from the
camera’s USB/VIDEO
terminal.
6 [Auto power off] (page 79)
h Specify the time elapsed
before the auto power off
function operates to turn the
camera off.
7 [File number reset] (page 81)
h Set the file number reset
function to ON or OFF.
[
Format] (page 84)
8
h Reformat the camera’s internal
memory or the card installed in
the camera.
9 Reset camera settings
(page 86)
h Reset the camera to the
factory-preset settings.
i Icons 7 through 9 are displayed when you press the [n] or [o] button to
scroll.
English 74
POST-VIEW SETTING
Specify the duration that the captured image appears on the monitor (postview) after the shutter button is pressed.
1 Display the Option Menu (page 72).
2 Select “POST VIEW” and press the
ok button.
h The Post View Menu appears.
3 Select the desired setting, and
press the ok button.
h This completes the post-view
setting.
OPTION MENU (1/2)
CLOCK SET
POST VIEW
LCD BRIGHTNESS
LANGUAGE
TV SYSTEM
AUTO POWER OFF
1SEC
2SEC
3SEC
4SEC
5SEC
OFF
75 English
ADJUST THE MONITOR
BRIGHTNESS
The brightness of the monitor is adjustable. Adjust the brightness to the
optimum readability in the ambient light.
1 Display the Option Menu (page 72).
2 Select “LCD BRIGHTNESS” and
press the ok button.
h The Monitor Brightness Menu
appears.
h When set to “AUTO”, the
illumination sensor (page 13)
detects the ambient brightness and
automatically adjusts the brightness
of the monitor accordingly.
3 Select the desired setting, and
press the ok button.
h This completes the monitor
brightness setting.
OPTION MENU (1/2)
LCD BRIGHTNESS
English 76
2
1
0
1
2
SCREEN LANGUAGE
LANGUAGE
OK
You can set the monitor of your camera to display the messages in any one of
several languages.
1 Display the Option Menu (page 72).
2 Select “LANGUAGE” and press the
ok button.
h The screen to select the display
language appears.
3 Select the desired language, and
press the ok button.
h The selected display language is
set.
LANGUAGE
LANGUAGE
OK
OK
OK
77 English
TV SYSTEM SETTING
Specify the type of image signal that is output from your camera’s USB/
VIDEO terminal.
1 Display the Option Menu (page 72).
2 Select “TV SYSTEM” and press the
ok button.
h The TV System Menu appears.
NTSC:
Outputs NTSC video signals.
PA L:
Outputs PAL video signals.
OPTION MENU (1/2)
CLOCK SET
POST VIEW
LCD BRIGHTNESS
LANGUAGE
TV SYSTEM
AUTO POWER OFF
NTSC
PAL
3 Select the desired setting, and
press the ok button.
h The selected TV system is set.
HINT
If no image appears on the TV...
i If the TV system setting is not correct for the connected equipment, no
image will appear on the TV.
English 78
AUTO POWER OFF FUNCTION
AUTO POWER OFF
Your camera has an “auto power off” function whereby the power
automatically turns off after a specified period of inactivity. The auto power off
function works to conserve the battery power when the camera is not being
used, or to prevent the batteries from dying if the camera has accidentally
been left on. You can specify the elapsed time (standby time) before the auto
power off function operates to turn the camera off.
1 Display the Option Menu (page 72).
2 Select “AUTO POWER OFF” and
press the ok button.
h The screen to set the standby time
appears.
RECORDING:
Set the standby time for the
shooting mode.
PLAYBACK:
Set the standby time for the
playback mode.
79 English
AUTO POWER OFF
AUTO POWER OFF
RECORDING
PLAYBACK
OK
OKOKOK
1 min
3 min
3 Select the desired option, and press
AUTO POWER OFF
the ok button.
h The Standby Time Menu appears.
4 Press the [n] or [o] button to select
the standby time.
5 Press the ok button.
h The auto power off function is set.
h To return to the Option Menu, press
the [l] button.
AUTO POWER OFF
AUTO POWER OFF
1 min
RECORDING
PLAYBACK
OK
OKOKOK
<Example: When
“RECORDING” is selected>
3 min
5 min
10 min
English 80
FILE No. RESET FUNCTION
If a newly formatted (page 84) card is used, the file name (image number) of
the captured image automatically begins from 0001. If the card is
subsequently reformatted, or if a different reformatted card is used, the file
names again begin from 0001. This is because the file number reset function
is set to “ON”, and consequently it results in more than one card containing
images with the same numbers. By setting the file number reset function to
“OFF”, even if the card is reformatted or the card is replaced with another
card, the consecutive numbering of file names continues from the last number
recorded by the camera.
<File number reset function “ON”>
File name (image number)
Card A 0001, 0002...... 0012, 0013
Replace card
Card B 0001, 0002...... 0012, 0013
<File number reset function “OFF”>
Card A 0001, 0002...... 0012, 0013
Card B 0014, 0015........0025, 0026
File name (image number)
Replace card
81 English
i If Card B already has image data in it when it replaces Card A, file names
are assigned as follows.
When the highest image number on Card B (before replacing) is
lower than the highest image number on Card A: the file name of the
next recorded image continues from last file name recorded on Card A.
Card A 0001, 0002 ...... 0012, 0013
Replace card
Card B 0001, 0002, 0014, 0015 ...... 0025, 0026
Previously recorded images
When the highest image number on Card B (before replacing) is
higher than the highest image number on Card A: the file name of the
next recorded image continues from last file name recorded on Card B.
Card A 0001, 0002 ...... 0012, 0013
Replace card
Card B 0020, 0021, 0022, 0023 ...... 0025, 0026
Previously recorded images
HINT
What about the internal memory?
i The file number reset function works the same for the internal memory.
English 82
FILE No. RESET FUNCTION
1 Display the Option Menu (page 72).
2 Select “FILE NO. RESET” and press
the ok button.
h The File Number Reset Menu
appears.
ON:
The file number reset function is “ON”.
OFF:
The file number reset function is
“OFF”.
3 Select “OFF”, and press the ok button.
h The file number reset function was set to “OFF”.
HINT
i Until the file number reset function is turned “ON”, consecutive file names
are assigned. It is recommended that the file number reset function be
returned to “ON” at the end of each photography session.
OPTION MENU (2/2)
FILE NO. RESET
FORMAT
RESET SETTINGS
ON
OFF
83 English
INITIALIZING THE CARD MEMORY
FORMAT
CARD
)
OK
AND INTERNAL MEMORY
A card must be formatted with this camera:
i After purchasing, when used for the first time, or
i If it was formatted using a personal computer or another digital camera.
The card cannot be reformatted if the lock switch is set to the “LOCK”
position. Proceed with the reformat procedure after setting the lock switch to
the unlocked position.
1 To reformat a card, install it in the camera. To reformat the camera’s
internal memory, remove the card from the camera.
2 Display the Option Menu (page 72).
3 Select “FORMAT” and press the ok
button.
h The screen to begin formatting
appears.
OK
OK
FORMAT
installed>
(()
CARD
FORMAT
FORMAT CARD
OK
<Example: With card
English 84
)
INITIALIZING THE CARD MEMORY AND
INTERNAL MEMORY
4 Press the ok button.
h The Confirm Format Screen appears.
5 Select “YES”, and press the ok button.
h Formatting begins.
h During formatting, “FORMATTING” and “DO NOT POWER OFF” are
shown on the monitor.
CAUTION
Caution during reformatting
i Please do not turn off the camera or insert/remove the card while the card
is being formatted.
Reformatting erases the data
i When the card or internal memory is initialized, all the recorded data is
erased. Protected data is also erased, so before reformatting a card, any
data you want to keep should be copied to your personal computer’s hard
disk or other storage medium.
Caution regarding disposing/transferring the card (recovering data from
a reformatted card)
i If a card is reformatted or the data is erased from the card using the
camera or a computer, the card’s control data may be merely modified and
the data itself may not be completely erased from the card.
i If you are disposing of a card or are transferring the card to someone else,
it is recommended that you physically destroy it, or use commercially
available software for erasing card data.
HINT
To cancel reformatting
i In step 5, select “EXIT”, and press the ok button.
85 English
RESETTING THE CAMERA SETTINGS
Reset the camera to the factory-preset settings.
1 Display the Option Menu (page 72).
2 Select “RESET SETTINGS” and
press the ok button.
h The Reset Settings Menu appears.
YES:
Reset to the factory-preset settings.
NO:
Do not change the settings, and
return to the Option Menu.
OPTION MENU (2/2)
FILE NO. RESET
FORMAT
RESET SETTINGS
3 Select “YES”, and press the ok
button.
h The camera settings are reset to
the factory-preset settings.
HINT
i Note that the following settings do not change with this procedure:
Date and time setting
Language setting
TV system setting
File No. reset setting
YES
NO
English 86
CHECKING THE REMAINING INTERNAL MEMORY AND CARD MEMORY
You can check the possible number of images and video clip recording time
remaining on the card. For a table showing the maximum number of images
and recording time for the internal memory and for a specific card, please see
“Possible Number of Images/Video Recording Time” on page 122.
1 Press the on/off button to turn the
camera on.
<To check the remaining number of
still images>
Set the shooting mode to the still
image shooting mode (page 26).
<To check the remaining video clip
recording time>
Set the shooting mode to the video
clip recording mode (page 26).
h The remaining recording time is
shown on the monitor.
h The remaining number of images
and video recording time will differ
depending on the resolution setting.
HINT
i When the remaining number of images
or the remaining video recording time is
“0”, you cannot capture any more images. To capture more images, either
install a new card, or save the images to a computer and then erase them
(page 34) from the card.
i When the remaining number of images or the remaining video recording
time is “0”, it may be possible to capture a few more images by changing
the resolution setting or video clip mode setting (page 51).
i The maximum number of images is 9,999, and the maximum video
recording time is 99:59:59. Note that if a large-capacity card is used, the
remaining number of images or recording time may not be correctly
displayed.
Remaining number of images
12
<Still Image Shooting Screen>
Remaining recording time
00:00:25
<Video Clip Recording Screen>
87 English
CHECKING THE REMAINING BATTERY CHARGE
The remaining battery charge can be checked on the monitor. Make sure to
check this indicator before capturing an image. For an indication of the
possible length of time for battery operation, see page 121.
1 Press the on/off button to turn the
camera on.
h The battery remaining charge
indicator appears in the lower right
corner of the monitor.
h Due to the battery characteristics,
when the ambient temperature is
low, may appear early for an
incorrect indication of the remaining
charge.
Also, depending on the conditions
of use of the camera or the ambient
conditions (temperature, etc.), the
indicated remaining charge may
change. Therefore, this indication
can only be used as a general
approximation of the remaining
charge.
Battery
remaining
charge indicator
No indication Nearly full.
Battery remaining charge
Approx. full.
(This indicator appears only in certain
operation modes.)
Power is low.
It will soon be impossible to capture or play
back images.
If this icon flashes when the shutter button
is pressed, images cannot be captured.
Replace the batteries.
180
Battery remaining
charge indicator
English 88
CHECKING THE REMAINING BATTERY CHARGE
HINT
i If any data is present, you can also check the remaining battery charge on
the Information Screen (page 71).
i Battery life may differ even among batteries of the same type.
i Depending on the usage of the camera (such as the number of times the
flash is used, etc.) or the ambient temperature (temperatures below 10°C
[50°F]) the number of images that can be saved on fully charged batteries
will vary greatly.
i It is recommended that you prepare extra batteries when taking pictures at
a wedding or while traveling, for example, so you don’t miss capturing
images of important moments due to the battery power running out. The
same is recommended for taking photos in cold environments. (In a ski
area, for example, the batteries can be kept warm in your pocket until
ready to use.)
89 English
OTHER DEVICES AND CONNECTIONS
CONNECTING TO A TV
Connect the supplied Video Cable from the USB/VIDEO terminal on the
digital camera to the VIDEO input terminals on the TV.
Open
Switch input to VIDEO
Supplied Video
Cable
To the VIDEO input
terminal
VIDEO
USB/
To t h e US B /
VIDEO
terminal
USB/VIDEO
terminal
Playback
i After connecting the digital camera to the television, set the TV input switch
to VIDEO input.
i When a Video Cable is connected, no image appears on the camera’s
monitor.
i The playback method is the same as when viewing images on the
camera’s monitor.
CAUTION
Insert and pull out the cable carefully.
i When connecting the cables, make sure that the cable plugs are correctly
oriented and that they match the shapes of the terminal sockets on the
devices. Push the plugs in straight when connecting them. If undue force is
used to connect a cable, it may permanently damage the connector pins in
the terminal socket.
i Do not use excessive force when connecting and disconnecting cables.
English 90
CONNECTING TO A COMPUTER
The camera can be used as a card reader if it is connected to a computer.
Cautions when mounting your camera as a
removable disk
i Do not alter files or folders in your camera in any way. Doing so may result
in your camera not recognizing that data.
If you want to edit files, first copy them to your computer’s hard drive.
i Cards formatted on your computer cannot be used by your camera. Format
all cards to be used by your camera with your camera.
Operating environment
Windows
A computer with a standard-equipped USB port, and preinstalled with
Windows ME, 2000, XP or later is required. Correct operation cannot be
guaranteed for models that have been upgraded.
Macintosh
A model with a standard-equipped USB port, and preinstalled with Mac OS
9.0, 9.1, 9.2, Mac OS X 10.1 or later is required.
Data file formats
The format of the files saved on the card and the method in which the file
names are determined are explained below.
Type of data Data format File name structure
Still image/
sequential
shots data
Video clip
data
* Consecutive numbers assigned in the order the data was saved.
JPEG
QuickTime
Movie
File name begins with UNI_.
Extension is “.jpg”.
File name begins with UNI_.
Extension is “.mov”.
UNI_****.mov*
91 English
Configuration of directories in the card
ROOT DCIM
MISC
(Location
of DPOF
files)
* Up to 9,999 files can be stored in folder 100UNIDN. If more image files are
made, a folder named 101UNIDN is created, and they will be stored in
there. New folders will then be named in sequence, i.e., 102UNIDN,
103UNIDN, etc.
100UNIDN
Folder number
101UNIDN
102UNIDN
UNI_0003.mov
UNI_0004.mov
number
number
HINT
About video clip data recorded with this camera
i You can use Apple’s QuickTime 3 or later version to play back video clips
on a computer.
i QuickTime can be downloaded free of charge from the Apple Computer
website.
http://www.apple.com/quicktime/download/win.html
(The website URL may change.)
About file names when the card is replaced...
i If the file number reset function is set to off, even when the card is
replaced, consecutive numbering of folder numbers and file names
continues from the previously installed card (page 81).
CAUTION
If you intend to view the images on the camera, do not use a computer
to rewrite the card data.
i If the folders, file names, or their configuration is modified using a personal
computer, it will be impossible to play back the data using the camera, and
the camera may not operate properly.
English 92
CONNECTING TO A COMPUTER
USB CONNECTION
Setting to the card reader mode
1 Start your computer, use the supplied USB Cable to connect your
camera to the computer, and turn the camera on.
h Connect the camera’s USB/VIDEO terminal to the computer’s USB
connector.
h The USB Connection Screen appears on the camera’s LCD monitor.
Open
To USB
connector on
the computer
93 English
Supplied USB
Cable
USB/VIDEO
terminal
To t h e US B /
VIDEO
terminal
USB CONNECTION
USB CONNECTION
CARD READER
PictBridge
CANCEL
2 Select “CARD READER”, and press the ok button.
CAUTION
Insert and pull out the cable carefully.
i When connecting the cables, make sure that the cable plugs are correctly
oriented and that they match the shapes of the terminal sockets on the
devices. Push the plugs in straight when connecting them. If undue force is
used to connect a cable, it may permanently damage the connector pins in
the terminal socket.
i Do not use excessive force when connecting and disconnecting cables.
i Please connect the USB Cable to your computer’s USB connector. Do not
connect it to the USB port on your monitor or keyboard, or to the USB hub.
English 94
Loading...
