ULTIMATE SPEED UKL 12 A1, 106748 Operating Instructions Manual

CAR AIR PURIFIER UKL 12 A1

AUTO-LUFTREINIGER

Bedienungsanleitung

IAN 106748

CAR AIR PURIFIER

Operating instructions

PURIFICATEUR D’AIR
POUR VOITURE

Mode d’emploi

LUFTRENSER TIL BILEN

Betjeningsvejledning

AUTO-LUCHTREINIGER

Gebruiksaanwijzing

GB / IE Operating instructions Page 1
DK Betjeningsvejledning Side 17
FR / BE Mode d’emploi Page 33
NL / BE Gebruiksaanwijzing Pagina 51
DE / AT / CH Bedienungsanleitung Seite 69

Before reading, unfold the page containing the illustrations and familiarise
yourself with all functions of the device.

Før du læser, vend siden med billeder frem og bliv bekendt med alle
apparatets funktioner.

Avant de lire le mode d’emploi, ouvrez la page contenant les illustrations et
familiarisez-vous ensuite avec toutes les fonctions de l’appareil.

Vouw vóór het lezen de pagina met de afbeeldingen open en maak u
vertrouwd met alle functies van het apparaat.

Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen
Sie sich anschließend mit allen Funktionen des Gerätes vertraut.

1

UKL 12 A1

GB

IE

Contents

Introduction ........................2

Intended use ..............................2

Warnings ................................3

Safety instructions ...................4

Initial operation .....................6

Check the items supplied ....................6

Controls ...........................7

Handling and operation ..............7

Functionality and effect of the vehicle air cleaner . 9

Maintenance .......................9

Replacing the fuse .........................9

Cleaning and storage ...............11

Disposal ..........................12

Appendix .........................13

Importer ................................13

Technical details ..........................13

Notes on the Declaration of Conformity .......14

Warranty ...............................14

Service .................................16

GB

IE

2

UKL 12 A1

Introduction

Congratulations on the purchase of your new device.
You have selected a high-quality product. The operat­ing instructions are a constituent of this product. They
contain important information about safety, use and
disposal. Before using the product, familiarise yourself
with all operating and safety instructions. Use this
product only as described and only for the specified
areas of application. Retain these instructions for
future reference. Please also pass these operating
instructions on to any future owner(s).

Intended use

The vehicle air cleaner is only intended for air cleaning
in privately-used vehicles. Any other use is considered to
be improper, and can result in damage and injuries.
Claims of any kind for damage resulting from improper
use or unauthorised modifications will not be consid­ered. This product is for private use only, and is not
intended for commercial use.

3

UKL 12 A1

GB

IE

Warnings

The following warnings are used in these operating
instructions:

DANGER

A warning at this risk level indicates an
imminently hazardous situation.

If the hazardous situation is not avoided, it could
lead to death or serious physical injury.

► Follow the instructions in this warning to avoid

a fatality or serious personal injury.

CAUTION

A warning of this risk level indicates
potential damage to property.

Failure to avoid this situation could result in
damage to property.

► Follow the instructions in this warning to prevent

damage to property.

GB

IE

4

UKL 12 A1

NOTE

►

A note indicates additional information that will
assist you in handling the device.

Safety instructions

■ Check the device for any visible exter-

nal damage before use. Do not use
an device that has been damaged or
dropped.

■ Protect the device from penetration by

moisture and liquids.

■ Never subject the device to extreme

heat or humidity. This applies especially
when storing in a car. Extreme tem­peratures can occur in car interiors and
glove compartments during long peri­ods of immobilisation. Remove electrical

5

UKL 12 A1

GB

IE

and electronic devices from the vehicle.

■ This device may be used by children

aged 8 over and by persons with
reduced physical, sensory or mental
capabilities or lack of experience and
knowledge, provided that they are
under supervision or have been told
how to use the device safely and are
aware of the potential risks. Children
must not use the device as a play­thing. Cleaning and user maintenance
tasks may not be carried out by chil­dren unless they are supervised.

■ Do not operate the device whilst

steering a car or any other vehicle.
This is hazardous to other road users.

■ Do not cover the ventilation slots.

GB

IE

6

UKL 12 A1

Initial operation

Check the items supplied

This device is supplied with the following components
as standard:

▯ Vehicle air cleaner
▯ This operating manual

NOTE

► Before starting to use the device, check that

all items are present and undamaged. If any
items are missing or damaged due to defective
packaging or transportation, please contact the
Service Hotline (see chapter "Service").

Remove all parts from the packaging, and then remove
all packaging material from the device.

7

UKL 12 A1

GB

IE

Controls

 Vehicle plug
 Indicator lamp
 Ventilation slots
 On/Off switch

Handling and operation

♦ Insert the vehicle plug  into the 12V power

socket of your car. As a rule this is the cigarette
lighter socket in the dashboard of your vehicle.

NOTE

The main unit with the ventilation slots  can be
continuously rotated through 90°. The ventilation
slots  must be free and should be pointing
towards the middle of the vehicle interior.

♦ Rotate the main unit with the ventilation slots 

into the required position.

GB

IE

8

UKL 12 A1

♦ Switch the device on by sliding the On/Off switch 

to the "ON" position. The indicator lamp  illumi-
nates and signals that the vehicle air cleaner is
operating. Depending on the vehicle type it is pos­sible that the ignition has to be switched on first.

♦ To switch the device off, set the On/Off switch 

to the "OFF" position. The indicator lamp  goes
out.

CAUTION

► The device also consumes power in standby

mode and therefore must be disconnected from
the on-board power supply after use! Otherwise
the battery will discharge when the engine is
not running.

9

UKL 12 A1

GB

IE

Functionality and effect of the vehicle
air cleaner

The device continuously emits negative ions during
operation. The negative ions the attach themselves to
pollutants, bacteria and germs and make them harm­less by means of their electrical charge. Both scientific
investigations and practical experience have shown
show that enriching the air with negative ions has a
positive effect on human capabilities.

Maintenance

Replacing the fuse

There is a fuse in the 12 V vehicle air cleaner for
protecting the vehicle's on-board power supply. If the
device no longer works, check the fuse and replace if
necessary.

♦ Firstly, disconnect the device from the 12 V con-

nection.

GB

IE

10

UKL 12 A1

♦ Open the 12 V vehicle air cleaner by carefully

unscrewing the fluted screw insert anticlockwise
(using pliers if necessary) and removing it.

♦ Remove the plug tip from the fuse and take out the

fuse.

♦ Now insert a new fuse of type F1AL 250 V into

the 12 V vehicle connector, fit the plug tip to the
slightly protruding end of the fuse and screw the
previously removed screw insert back in.

NOTE

If the device still does not work or the fuse blows
again immediately, the device is defective. In this
case, please contact the Service Hotline (see
chapter "Service").

11

UKL 12 A1

GB

IE

Cleaning and storage

CAUTION

► Disconnect the device before cleaning and

when not in use from the 12 V connection to
avoid the risk of an electric shock.

► The temperatures inside a vehicle can reach

extreme values in summer and winter. Damage
should therefore be avoided by not storing the

device in the vehicle.

♦ Clean the device with a soft, dry cloth.
♦ Store the device in a location that is clean, dry,

dust-free and not in direct sunlight.

GB

IE

12

UKL 12 A1

Disposal

Under no circumstances must the device

be disposed of in the normal domestic
waste. This product is subject to the pro­visions of the European 2012/19/EU
WEEE Directive (Waste Electrical and
Electronic Equipment).

Dispose of the device via an approved disposal com­pany or your municipal waste facility. Please observe
the currently applicable regulations. Please contact
your waste disposal centre if you are in any doubt.

Dispose of all packaging materials in an

environmentally friendly manner.

13

UKL 12 A1

GB

IE

Appendix

Importer

KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
GERMANY

www.kompernass.com

Technical details

Model UKL 12 A1

Input voltage, current 12 V /22 mA
Fuse F1AL/250 V
Protection class

III /

Operating temperature 5°C up to +45°C

Relative humidity

≤ 75%

(no condensation)

Dimensions

approx.

15.7 x 4.0 x 3.9 cm

Weight approx. 65 g

GB

IE

14

UKL 12 A1

Notes on the Declaration of Conformity

With regard to correspondence with the basic
requirements and other relevant regulations,
this device complies with EMC directive
2004/108/EC and
RoHS directive 2011/65/EU.

The full original Declaration of Conformity is
available from the importer.

Warranty

The warranty provided for this device is 3 years from
the date of purchase. This device has been manufac­tured with care and inspected meticulously prior to
delivery.
Please retain your receipt as proof of purchase.
In the event of a warranty claim, please contact your
Customer Service by telephone. This is the only way
to guarantee free return of your goods.

15

UKL 12 A1

GB

IE

NOTE

►

The warranty only covers claims for material

and manufacturing defects, not for transport

damage, worn parts or damage to fragile

components such as buttons or batteries.

This device is intended solely for private use and not
for commercial purposes. The warranty is deemed
void if this product has been subjected to improper or
inappropriate handling, abuse or modifications which
were not carried out by one of our authorised service
centres. Your statutory rights are not restricted in any
way by this warranty. The warranty period is not
prolonged by repairs made under the warranty.
This also applies to replaced and repaired parts.
Damage and defects present at the time of purchase
must be reported immediately after unpacking, or no
later than two days after the date of purchase. Repairs
made after expiry of the warranty period are charge­able.

GB

IE

16

UKL 12 A1

Service

Service Great Britain

Tel.: [phone] (£ 0.10/Min.)
E-Mail: [e-mail]

IAN 106748

Service Ireland

Tel.: [phone]
(0,08 EUR/Min., (peak))

(0,06 EUR/Min., (off peak))
E-Mail: [e-mail]

IAN 106748

Hotline availability:
Monday to Friday 08:00 - 20:00 (CET)

17

UKL 12 A1

DK

Indholdsfortegnelse

Introduktion .......................18

Anvendelsesområde .......................18

Advarsler ...............................19

Sikkerhedsanvisninger ..............20

Første brug ........................22

Kontrol af de leverede dele .................22

Betjeningselementer ................23

Betjening og funktion ...............24

Bil-luftrenserens funktion og virkning ...........25

Vedligeholdelse ....................26

Skift af sikring ............................26

Rengøring og opbevaring ...........27

Bortskaffelse ......................28

Tillæg ............................29

Importør ................................29

Tekniske data ............................29

Info til EF-overensstemmelses-erklæringen ......30

Garanti .................................30

Service .................................32

DK

18

UKL 12 A1

Introduktion

Tillykke med købet af dit nye produkt. Du har valgt et
produkt af høj kvalitet. Betjeningsvejledningen er en del
af dette produkt. Den indeholder vigtige informationer
om sikkerhed, anvendelse og bortskaffelse. Du bedes
sætte dig ind i alle produktets betjenings- og sikkerheds­anvisninger før brug. Brug kun produktet som beskrevet
og kun til de angivne anvendelsesområder. Opbevar
denne vejledning, så du altid kan finde den igen. Lad
vejledningen følge med produktet, hvis du giver det
videre til andre.

Anvendelsesområde

Bil-luftrenseren er kun beregnet til luftrensning af biler,
der bruges privat. Al anden anvendelse betragtes som
værende uden for anvendelsesområdet og kan føre til
skader og personskader. Krav af enhver art på grund
af skader, som er opstået ved anvendelse uden for
anvendelsesområdet eller egne ændringer, er udeluk­kede.

19

UKL 12 A1

DK

Dette produkt er udelukkende beregnet til privat og
ikke til erhvervsmæssigt brug.

Advarsler

I denne betjeningsvejledning anvendes følgende
advarsler:

FARE

En advarsel på dette faretrin markerer
en truende farlig situation.

Hvis den farlige situation ikke undgås, kan det
medføre livsfarlige eller alvorlige personskader.

► Følg anvisningerne i denne advarsel, så livsfarlige

og alvorlige personskader undgås.

DK

20

UKL 12 A1

OBS

En advarsel på dette faretrin angiver
en mulig materiel skade.

Hvis den farlige situation ikke undgås, kan det
føre til materielle skader.

► Følg anvisningerne i denne advarsel for at

undgå materielle skader.

BEMÆRK

► Et 'bemærk' henviser til yderligere oplysninger,

som gør det nemmere at bruge produktet.

Sikkerhedsanvisninger

■ Kontrollér produktet for udvendige,

synlige skader før brug. Brug ikke
produktet, hvis det er beskadiget eller
tabes på gulvet.

21

UKL 12 A1

DK

■ Beskyt produktet mod fugt og ind-

trængende væsker.

■ Udsæt ikke produktet for ekstrem

varme eller høj luftfugtighed. Det
gælder især ved opbevaring i bilen.
Ved længere parkeringstider bliver
temperaturen inde i bilen og i hand­skerummet meget høj. Fjern elektriske
og elektroniske apparater fra bilen.

■ Dette produkt kan bruges af børn

fra 8år og derover og af personer
med nedsatte fysiske, motoriske eller
mentale evner eller manglende erfa­ring og/eller viden, hvis de er under
opsyn eller undervises i sikker brug af
produktet og de farer, der kan være
forbundet med det. Børn må ikke lege

DK

22

UKL 12 A1

med produktet. Rengøring og bruger­vedligeholdelse må ikke udføres af
børn uden opsyn.

■ Betjen ikke produktet, hvis du styrer

en bil eller et andet køretøj. Betjening
af produktet kan være årsag til ulyk­ker i trafikken.

■ Dæk ikke luftåbningerne til.

Første brug

Kontrol af de leverede dele

Produktet leveres som standard med følgende dele:

▯ Bil-luftrenser
▯ Denne betjeningsvejledning

23

UKL 12 A1

DK

BEMÆRK

►

Kontrollér inden første brug, om indholdet er

fuldstændigt, og om der er synlige skader. Hvis

der mangler dele, eller hvis nogle af delene er

defekte på grund af mangelfuld emballage eller

på grund af transporten, bedes du henvende

dig til service-hotline (se kapitlet "Service").

Tag alle delene ud af emballagen, og fjern alle
emballagematerialer fra produktet.

Betjeningselementer

 Bilstik
 Kontrollampe
 Luftåbninger
 Tænd-/slukkontakt

DK

24

UKL 12 A1

Betjening og funktion

♦ Sæt bilstikket  i 12V-tilslutningen på bilen. Det

er som regel cigarettænderen i bilens instrument­bræt.

BEMÆRK

Hovedenheden med luftåbningerne  kan indstil-

les trinløst op til 90°. Luftåbningerne  skal være

åbne og pege mod midten af bilens indvendige

rum.

♦ Indstil hovedenheden med luftåbningerne  i den

ønskede stilling.

♦ Tænd for produktet ved at stille tænd-/slukkontak-

ten  på "ON". Kontrollampen  lyser og viser,
at bil-luftrenseren er i gang. Tændingen skal muligvis
tændes først afhængigt af biltypen.

♦ Stil tænd-/slukkontakten  på "OFF" for at slukke

for produktet. Kontrollampen  slukkes.
