Ubiquiti NS-5ACL-5-US Quick Start Guide

5 GHz airMAX® ac Radio

Model: NS-5ACL

Introduction

Thank you for purchasing the Ubiquiti Networks® NanoStation®
5AC loco. This Quick Start Guide is designed to guide you
through the installation and also includes warranty terms.

Package Contents

5 GHz airMAX® ac Radio

NanoStation

loco

TERMS OF USE: Ubiquiti radio devices must be professionally installed. Shielded Ethernet
cable and earth grounding must be used as conditions of product warranty. TOUGHCable™ is
designed for outdoor installations. It is the professional installer’s responsibility to follow local
country regulations, including operation within legal frequency channels, output power, and
Dynamic Frequency Selection (DFS) requirements.

Zip Tie Quick Start

Model: NS-5ACL

Guide

Installation Requirements

• Shielded Category 5 (or above) cabling with drain wire
should be used for all outdoor wired Ethernet connections
and should be grounded through the AC ground of the PoE.

We recommend that you protect your networks from
harmful outdoor environments and destructive ESD events
with industrial‑grade, shielded Ethernet cable from Ubiquiti
Networks. For more details, visit www.ubnt.com/toughcable

• Surge protection should be used for all outdoor installations.
We recommend that you use two Ethernet Surge Protectors,
model ETH‑SP, one near the NanoStation loco and the other
at the entry point to the building. The ETH‑SP will absorb
power surges and safely discharge them into the ground.

NS-5ACL

ETH-SP

ETH-SP

Diagram Showing Use of Ethernet Surge Protectors

ES-8-150W

To LAN

Hardware Overview

Back View

Mounting

Bracket

Port View

Power

LED

Ethernet

Port

Power LED The Power LED will light blue when the device is

connected to a power source.

Ethernet Port 10/100/1000 Ethernet port used to connect the

power and should be connected to the LAN and DHCP server.

Reset Button To reset to factory defaults, press and hold the

Reset button for more than 10 seconds while the NanoStation

loco is poweredon.

Reset

Button

Hardware Installation

1. Remove the port cover by pressing down on the center of

the cover and sliding the cover out.

2. Connect an Ethernet cable to the Ethernet Port.

3. Replace the port cover.

*640-00349-07*

640-00349-07

Pole Mount

1. Position the NanoStation loco at the desired location on

a pole and insert a Zip Tie into the slot of the Mounting

Bracket.

2. Align the front of the NanoStation loco toward the other

end of the wireless link. Then tighten the Zip Tie around

thepole.

3. Connect the Ethernet cable from the NanoStation loco’s

Ethernet port to a PoE‑enabled Ethernet port on a switch.

WARNING: The switch port must comply with the

power specifications listed in the Specifications
section of this Quick Start Guide.
