Tripp Lite SU8000RT3UPM User Manual
Tripp Lite
1111 West 35th Street
Chicago, IL 60609 USA
Telephone: +(773) 869 1234
E-mail: saleshelp@tripplite.com
Model #: SU8000RT3UPM
SmartOnline 8000VA Power Module - Hot-swappable power module for redundant power applications
Highlights
8000VA on-line 3U rack/tower hot-swappable power module
Ideal for use as a spare or redundant power module for mission-critical UPS
configurations involving SU8000RT3U or SU8000RT3U1TF
Description
8,000 VA (8kVA) on-line, double-conversion UPS power module for spare or redundant UPS configurations involving SU8000RT3U,
SU8000RT3U1TF, SU7500RT3U or SU7500RT3U1TF UPS bundles. POWER MODULE ONLY.
Applications
Power module can be configured for redundant or spare UPS applications involving SU8000RT3U, SU8000RT3U1TF, SU7500RT3U or
SU7500RT3U1TF UPS bundles.
Package Includes
SU8000RT3UPM POWER MODULE ONLY (3u)
Features
8,000VA (8kVA) on-line, double-conversion UPS power module for spare or redundant UPS configurations involving SU8000RT3U,
SU8000RT3U1TF, SU7500RT3U or SU7500RT3U1TF UPS bundles.
POWER MODULE ONLY
Specifications
SYSTEM OVERVIEW
Voltage compatibility 208V AC (200/208/220/230/240v)
Frequency
compatibility
50/60 Hz
OUTPUT
Output VA 8000
Output watts 6400
Output nominal
voltage
208V AC (200/208/220/230/240v)
Output voltage
regulation
Maintains pure sine wave output at all times, regulated within 2% of selected nominal output voltage, less than 3% total
harmonic distortion when used with computer loads
Output frequency
regulation
Regulates line frequency to 50/60Hz +/- 0.05Hz
Outlet quantity / type -
INPUT
Maximum input amps 200V - 38A / 208V - 36A / 220V - 34A / 230V - 33A / 240V - 32A
Input connection type -
BATTERY
Full load runtime n/a
Half load runtime n/a
DC system voltage 240V DC
VOLTAGE REGULATION
Voltage regulation
description
On-line, double-conversion process give this UPS the ability to maintain output voltage within +/-2% of selected nominal
voltage at all times
Overvoltage
correction
Maintains continuous operation without using battery power during overvoltages to 276V AC, regulating output within
2% of selected nominal
Brownout correction Maintains continuous operation without using battery power during brownout / undervoltage conditions to 156V AC,
regulating output within 2% of selected nominal
LEDS ALARMS & SWITCHES
Front panel LEDs 6 LED DISPLAY: line power, bypass, inverter, charger, output AC and battery operation. LED/LCD display panel easily
rotates for viewing in rackmount or tower configurations.
Alarms Multi-function audible alarm offers notification of UPS start, backup operation, low battery, overload, UPS fault, inverter
fault, DC bus fault, overtemperature, remote shutdown, shutdown imminent and shutdown complete
Switches Includes main power off/on switch, plus 2 switches to set and execute scrollable LCD functions
SURGE / NOISE SUPPRESSION
AC suppression
response time
Instantaneous
EMI / RFI AC noise
suppression
Yes
PHYSICAL
Shipping weight (lbs) 91.6
Shipping weight (kg) 41.6
Shipping
Dimensions (HWD/in)
11.25 x 31.5 x 23
Shipping
Dimensions
(HWD/cm)
28.6 x 80 x 58.4
Unit weight (lbs) 57.2
Unit weight (kg) 26
Unit Dimensions
(HWD/in)
5.25 x 17.5 x 26
Unit Dimensions
(HWD/cm)
13.3 x 44.4 x 66
Material of
construction
Steel
Form factors
supported
Rack (3U)
Cooling method Fan
ENVIRONMENTAL
Relative Humidity 0 to 95%, non-condensing
