Tripp-Lite SPIKECUBE Data Sheet

SpikeCube Series 1-Outlet Personal Surge
Protector, Direct Plug-In, 600 Joules, 2
Diagnostic LEDs

MODEL NUMBER: SPIKECUBE

Description

The SPIKECUBE Surge Suppressor from Tripp Lite is a direct plug-in suppressor providing protection on
one AC outlet. Its small size makes it ideal for protecting laptop computers, projectors and other portable
electronics. A green "Protected" and red "Grounded" LED illuminates to indicate that adequate surge
suppression is available. The unit has 600 joules of surge energy absorption. $5,000 Ultimate Lifetime
Insurance (U.S., Canada, and Puerto Rico only).

Highlights

●

1 outlet / direct plug-in

●

600 joule rating

●

Diagnostic LEDs

Package Includes

●

SPIKECUBE Surge Suppressor

●

Warranty and instruction
information

Features

●

1 outlet; direct plug-in

●

Surge energy absorption: 600 joules; 6,500 amps

●

Diagnostic LEDs indicate protection present (green) and ground present (red)

●

$5,000 Ultimate Lifetime Insurance (U.S., Canada, and Puerto Rico only)

Specifications

OVERVIEW

UPC Code 037332010643

INPUT

Nominal Input Voltage(s) Supported 120V AC
Recommended Electrical Service 120V (110-125V)
Input Cord Length Details Direct Plug-In

1 / 3

Voltage Compatibility (VAC) 120
Maximum Surge Amps 36000
Input Plug Type NEMA 5-15P
Input Cord Length (ft.) 0
Right-Angle Plug No
Input Cord Length (m) 0.00
Integrated Cord Clip No

OUTPUT

Frequency Compatibility 50 / 60 Hz
Output (Watts) 1800
Output Receptacles (1) 5-15R
Circuit Breaker (amps) 15
Transformer Accommodation (1) Yes
Right-Angle Outlets No

USER INTERFACE, ALERTS & CONTROLS

Diagnostic LED(s) Yes
Diagnostic LED Details Protected (green) & Grounded (red)

SURGE / NOISE SUPPRESSION

AC Suppression Joule Rating 600
AC Suppression Response Time < 1 ns
Protection Modes Includes full normal mode (H-N) and common mode (N-G / H-G) line surge suppression
Clamping Voltage (RMS) 150
UL1449 Let Through Rating 400, 500, 500
Automatic Shut-Off No

DATALINE SURGE SUPPRESSION

Telephone/DSL Protection No
Cable (Coax) Protection No
Network (Ethernet) Protection No

PHYSICAL

Antimicrobial Coating No
Color Light Gray
Form Factors Supported Direct plug in suppressor supports wall-mounting directly into AC receptacle
