SmartRack™ Assembly Instructions

Models: SR42UBKD, SR42UBEXPKD,

SR48UBKD and SR48UBEXPKD

Copyright © 2008 Tripp Lite. All trademarks are the sole property of their respective owners.

1111 West 35th Street, Chicago, IL 60609 USA

773.869.1234 • www.tripplite.com

1

Parts List

ABC

#1 Phillips #2 Phillips

M6x12 M4x8 with

Lock Washer

x36x24

x6

See Owner’s

Manual

M5x10

x16

x1 x1 x2 x2 x2

Required Tools:

• 5/32” (4 mm) Allen Wrench (Supplied)

• #1 Phillips Screwdriver (User-Supplied)

• #2 Phillips Screwdriver (User-Supplied)

x4

Note: “EXP” models do not
include side panels.

x2 x2 x2 x1

WARNING: The rack enclosure is extremely heavy. Do not attempt to
unpack, move, assemble or install the enclosure without assistance.
Until it has been properly assembled and stabilized, the enclosure is
prone to tipping and could cause property damage and/or personal
injury. Use extreme caution when assembling the enclosure and be
sure to follow all handling and installation instructions. Do not attempt
to install equipment without fi rst stabilizing the enclosure. Refer to
Owner’s Manual.

2

step

1

2

22

C

8

x2

step

2

1

4

2

2-1

x6

2-2

x6

2-3

A

12

x6

3
