TRIAX TD Dishes
Flexible solutions, easy installation
Flexible dish solutions
| Manufactured and tested to the highest standards
Size matters
For maximal signal quality, available in steel or aluminium,
TRIAX dishes are the perfect t.
TD65 TD80 TD100
Full assortment
�Size: 65, 80 or 100 cm available.
�Colours: Light Grey, Anthracite or Red.
Solutions to meet your needs
We know not two customers are alike. That’s why you can
choose from our range of standard solutions, or
customised dishes and packaging upon request.
We can meet most special requests for:
�Sizes
�Colours
�Nuts and bolts
�Customised packaging and/or logo
Please contact us to discuss how we can benet
your business.
*Bulk single pack = 150, 180,
200 or 220 dishes per package.
Accessories are packaged in
individual boxes to match
each dish.
�Reector material: Hot-dip galvanised steel or
Aluminium
�Screws & brackets material: Galvanised steel
�Logistic-friendly packaging: Single or bulk single pack*
�TRIAX-branded reector and packaging
�Mounting kits: 6-edge ange nut with 2 mast brackets
included as standard
Bracket for Steel dishes:
• 2 x U bolts
• ABS LNB holder
• Lock nuts
Bracket for Aluminium single pack dishes:
• 2 x U bolts,
• ALU LNB holder
• Wing nuts
2/6
TRIAX – Your reliable partner
Our comprehensive service and support is
backed up by 2 years’ corrosion and 5 years’
functionality warranty.
The difference is clear
| Unrivalled build quality • Outstanding performance • Easy installation
Unrivalled build quality
Sturdy, galvanised steel mast
brackets and reectors ensure extra
stability and weather protection.
Accurate setting scales allow for
perfect dish adjustment.
�Hot-dip galvanised steel or long lasting aluminium
for extra corrosion protection
�TRIAX’s unique cable protection system
�Every part, every accessory is weatherproofed
Outstanding performance
�High gain for an exceptional signal
Quick and easy installation
�One-click mounting system
�Self-locking screw & nuts
�Fits the full range of TRIAX LNBs
To ensure the feed arm
is in the right position,
it is secured with a bolt
with additional nut on
the back of the dish.
Unique cable
protection: the
coaxial cable runs
through the feed-arm
to the back of the dish.
On all dishes the arm
goes through the
reector to secure a
stable mounting.
A bolt with additional
nut, placed on the back
of the dish to secure
the feed-arm is in the
right position.
The UV-resistant
plastic Ø40 mm LNB
holder is quickly clicked
on to the feed arm.
Aluminium LNB holder
– standard on Alu
dishes, optional extra
on steel dishes
3/6
Accessories
| Everything you need for the perfect installation
Optional brackets for the TD dish
Alu LNB holder
Flexi-Block
Multi-Block
Duo-Block
DiSEqC
TM
switches & wall brackets
Need to connect more LNB units to your set-top box?
�DiSEqC
TM
switches for connection of 2 - 4 universal
single LNB units to a set-top box.
�TRIAX can also supplies a wide range of mounting
brackets, to full all your requirements for dish installation.
Choose between:
�Aluminium LNB holder – optional extra on steel dishes
�3° and 6° Duo-Block – for Ø40 mm LNBs.
Perfect for reception from two satellite positions,
e.g. Eutelsat (Hotbird) and ASTRA
�3° to 10° Flexi-Block – adjustable for two Ø40 mm LNBs.
�3° to 20° Multi-Block – adjustable for four LNBs –
min. 4° between the satellite positions with the right LNB.
with
SCR
dCSS
Quattro
Quad
Single
Wideband V/H
Octo
Twin
Optical
State of the art TRIAX LNB units
TRIAX Universal Ku-band LNBs meet the most critical
demands in today’s market. You are guaranteed extremely
low noise gure in both high and low band
- and excellent cross polarity isolation, build-in LTE lter,
low power consumption.
Available as Single, Twin, Quad and Octo for 1, 2, 4 or 8
set top boxes and in Quattro version for multiswitches
systems.
Others models available like Hi-gain, optical, wideband,
dCSS, SCR and other specic models are available
on request.
4/6
At a glance
| A quick overview of the standard dish range
Colours
A= Anthracite
LG= Light Grey
R= Red
Standard assortment list
Item no. Type Colour RAL Dish reector material Packing method Accessories incl.
TD 65
120500 TDS 65A 7016 Hot-dip galvanised steel Single pack Standard nuts
120501 TDS 65LG 7035 Hot-dip galvanised steel Single pack Standard nuts
120502 TDS 65A 7016 Hot-dip galvanised steel Bulk / single 220 pcs Standard nuts
120503 TDS 65LG 7035 Hot-dip galvanised steel Bulk / single 220 pcs Standard nuts
120504 TDA 65A 7016 Aluminium Single pack Wing nuts + Alu LNB holder
120505 TDA 65LG 7035 Aluminium Single pack Wing nuts + Alu LNB holder
120506 TDA 65A 7016 Aluminium Bulk / single 180 pcs *)
120507 TDA 65LG 7035 Aluminium Bulk / single 180 pcs *)
TD 80
120508 TDS 80A 7016 Hot-dip galvanised steel Single pack Standard nuts
120509 TDS 80LG 7035 Hot-dip galvanised steel Single pack Standard nuts
120510 TDS 80A 7016 Hot-dip galvanised steel Bulk / single 200 pcs Standard nuts
120511 TDS 80LG 7035 Hot-dip galvanised steel Bulk / single 200 pcs Standard nuts
120512 TDA 80R 8012 Aluminium Single pack Wing nuts + Alu LNB holder
120513 TDA 80R 8012 Aluminium Bulk / single 180 pcs *)
120514 TDA 80A 7016 Aluminium Single pack Wing nuts + Alu LNB holder
120515 TDA 80LG 7035 Aluminium Single pack Wing nuts + Alu LNB holder
120516 TDA 80A 7016 Aluminium Bulk / single 180 pcs *)
120517 TDA 80LG 7035 Aluminium Bulk / single 180 pcs *)
TD 100
120518 TDS 100LG 7035 Hot-dip galvanised steel Single pack Standard nuts
120519 TDS 100LG 7035 Hot-dip galvanised steel Bulk / single 150 pcs Standard nuts
*) Wing nuts + Alu LNB holder must be ordered separately.
Accessories
752220 Wing nuts Poly bag with 6x8mm wing nuts 50 bags in a box
128070 Wall Bracket S-Bracket 1 set / 2 pcs
128051 Wall Bracket J-Bracket 1 pcs
300721 LNB Bracket Alu LNB holder (included at TDA-Version) 1 pcs
300715 LNB Bracket TD - 6° DuoBlock 1 pcs
300719
300727 LNB Bracket TD - 3°-20° FlexiBlock - adjustable for 4 LNBs 1 pcs
LNB Bracket
TD - 3°-10° FlexiBlock - adjustable for 2 LNBs 1 pcs
5/6
