Triax ST-HD527CI User Manual

TRIAX ST-HD527 CI

Digital Combo set-top box

305013

Not to be copied, used or translated in part or whole without prior consent in writing except approval of ownership of copyright and copyright law.

Warranty

This warranty does not cover parts which may become defective due to misuse of the information contained in this manual.

Trademark Acknowledgment and license notice

Trade Mark of the DVB Digital Video Broadcasting Project (1991 to

1996)

Declaration of Conformity No. 4296, 22nd August 2006

Manufactured under license from Dolby Laboratories.

"Dolby" and the double-D symbol are trademarks of Dolby Laboratories.

HDMI, the HDMI Logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.

Warning! Important Safety Instruction

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE

COVER(OR BACK).NO USER SERVICEABLE PARTS INSIDE, REFER SERVICING TO

QUALIFIED SERVICE PERSONNEL.

Safety precautions:

The receiver has been manufactured in accordance with international safety standards .For your own safety you should

read the notes on safety precautions carefully, and take note of them ,before operating your new receiver .For your own

safety please be sure to follow these safety precautions ;

1. When installing the receiver, ensure there is a gap of approximately 5cm around

the receiver to enable air to circulate freely and prevent overheating.

2 Do not install this equipment in a confined space such as a book case or similar

unit. The ventilation should not be impeded by covering the ventilation openings with

items such as newspaper, table-cloths, curtains etc.

3, No naked flame sources, such as lighted candles, should be placed on the

apparatus;

4, The receiver shall not be exposed to dripping

No objects filled with liquids, such as vases.

5, The mains plug is used as disconnect device, the disconnect

device shall remain readily operable.

6, Power cord must be placed correctly. Do not touch the power

Cord and switch when your hand is dankest.

7, The normal operating temperature of the receiver is between

5ºC and 40ºC. Use the apparatus only in moderate climates

(Not in tropical climates).

8, The battery shall not be exposed to excessive heat such as sunshine, fire etc. Take attention to the environmental

aspects of battery disposal.

or splashing;

Manufacturer

Dear Customer,

Should you require technical assistance and in the event that your expert dealer is unable to help you, please contact us.

Triax A/S Bjørnkærvej 3 8783 Hornsyld Danmark

Declaration of Conformity

The manufacturer declares herewith that this product meets the following directives and standards:

Low voltage directive 2006/95/EC

European EMC Directive 2004/108/EC

• EN 55 013: 2001+A1 : 2001+A1 : 2005

• EN 55 020: 2007

• EN 61000-3-2: 2006

• EN 61000-3-3: 1995+A1 : 2001+A2 : 2005

Safety: EN 60065:2008

Svend Kristiansen

Quality Manager

Triax A/S Bjørnkærvej 3 8783 Hornsyld Danmark

Table of Contents

1. General Information…………………………………………………………………………… 7

1.1 Main Features……………………………………………………………………………… 7

1.2 For Your Safety…………………………………………………………………………… 7

1.3 Unpacking…………………………………………………………………………………… 8

1.4 General Operation of the TRIAX ST-HD527CI………………………………………… 8

1.5 RCU………………………………………………………………………………………… 9

1.6 Front Panel………………………………………………………………………………… 10

1.7 Rear Panel (connections)………………………………………………………………… 10

2. First time installation ....................................……………………………………………… 11

2.1 Terrestrial…………………………………………………………………………………… 11

2.2 Satellite.................................................................................................................... 12

3. Menu Information……………………………………………………………………………… 12

3.1 User Installation…………………………………………………………………………… 13

3.1.1 Antenna Setup :Fixed…………………………………………………………………… 13

3.2 Channel Search Page……………………………………………………………………… 14

3.3 Channel Search …………………………………………………………………………… 14

3.4 System Setting……………………………………………………………………………… 15

3.5 Parental Lock……………………………………………………………………………… 16

3.6 Factory Default……………………………………………………………………………… 16

4. Common Interface……………………………………………………………………………… 17

4.1 Preparing…………………………………………………………………………………… 17

4.2 Check Manager…………………………………………………………………………… 17

5. General Viewing Function……………………………………………………………………… 18

5.1Select Channel……………………………………………………………………………… 18

5.2 Previous Channel Recall………………………………………………………………… 18

5.3 TV & Radio Mode………………………………………………………………………… 18

5.4 TV & VCR Mode…………………………………………………………………………… 18

5.5 Channel Information……………………………………………………………………… 19

5.6 Volume & Audio Control…………………………………………………………………… 19

5.7 Favourite List……………………………………………………………………………… 19

6. Channel Manager……………………………………………………………………………… 20

6.1 Channel Manager ………………………………………………………………………… 20

6.2 Favourite Channel………………………………………………………………………… 20

6.3 Move Channel……………………………………………………………………………… 20

6.4 Lock………………………………………………………………………………………… 21

6.5 Delete Channel……………………………………………………………………………… 21

7. EPG (Electronic Program Guide)…………………………………………………………… 21

8. Timer…………………………………………………………………………………………… 22

8.1 Time Adjust………………………………………………………………………………… 22

8.2 Time Reservation………………………………………………………………………… 22

9. Receiver Information………………………………………………………………………… 23

General Information

The TRIAX ST-HD527CI allows you to view a variety of satellite programs. This user’s guide covers the installation of the TRIAX ST-HD527CI and the necessary steps to operate various features. It also explains special features available only in this TRIAX ST-HD527CI in detail, and will allow you to take full advantage of these features.

1.1 Main Features

• Support MPEG-1 ISO/IEC 11172-2, MPEG-2 MP@ML and MP@HL, ISO/IEC 13818-2, MPEG-4 AVC MP@L4 and HP@L4.1

• DVB-S (ETS 300 421), DVB-S2 (EN 302 307) compliant

• DVB-T(ETS 300 744)

• 2 Slot common interface for Viaccess, Irdeto, CryptoWorks, Nagravision, Conax, SECA and

• Digital Audio with Dolby Digital support.

• Stores up to 4000 channels

• Easy and fast software upgrade through USB port

• Automatic reserved channel moving system

• Electronic Program Guide (EPG)

• OSD Teletext (DVB ETS 300 706) and Subtitle function support

• Multi video output –Component Video Y/Pb/Pr, Digital Video HDMI, CVBS for TV SCART

OUT (w/ OSD), CVBS for VCR SCART OUT (w/o OSD), CVBS for VCR SCART IN.

• SCPC/MCPC receivable from C/Ku band satellite

• Multi LNB controlled by DiSEqC 1.2 and 22KHz, 0/12 volt switching

• 256 color On-Screen-Display

• Automatic PAL/NTSC conversion

• Automatic last channel saving

1.2 For Your Safety

• Allow clear space around the TRIAX ST-HD527CI for sufficient ventilation

• Do not cover the TRIAX ST-HD527CI or place it on a unit that emits heat

• Use a soft cloth and a mild solution of washing liquid to clean the casing

• Do not connect or modify cables when the TRIAX ST-HD527CI is plugged in

• Do not remove the cover

• Do not allow the unit to be exposed to extreme heat, cold or humid conditions

• Never allow liquids, spray or other materials to come into contact with the inside of the

model.

1.3 Unpacking

Unpack the TRIAX ST-HD527CI and check to make sure that all of the following items are included in the packaging.

• 1 x Remote Control Unit (RCU)

• 1 x User’s Guide

1.4 General Operation of the TRIAX ST-HD527CI

Throughout this manual you will notice that the everyday operation of your TRIAX ST-HD527CI is based on a series of user friendly on screen display and menus. These menus will help you get the most from your TRIAX ST-HD527CI, guiding you through installation, channel organizing, viewing and many other functions.

All functions can be carried out using the buttons on the RCU, and some of the functions can also be carried out using the buttons on the front panel.

If at any time when using the menus you want to return to the normal TV mode, press the TV/AV button.

Please be aware that new software may change the functionality of the TRIAX ST-HD527CI.

Should you experience any difficulties with the operation of your TRIAX ST-HD527CI, please consult the relevant section of this manual, including the Problem Shooting, or alternatively call your dealer or a customer service adviser.
