Operating Manual

SAORVIEW offers the best Irish television – free for everyone.

TR 112

Saorview HD TV Receiver

2

• The illustrations and the OSD in this operation manual are for explanation and guidance purposes only.

• The examples used throughout this manual are based on the TR112 Digital Terrestrial Receiver model.

Dear Triax customer

Thank you for purchasing the TRIAX TR112 (Saorview HD TV Receiver).
To ensure safety and many years of trouble-free operation, please read the Important Safety

Precautions carefully before using this product.

AV Settings 25

Contrast 25
Brightness & Stauration 25
SPDIF 25
Aspect Ratio 25
Video Output 26
Video Resolution 26
HDMI Colour Space 26
HDMI Deep Colour 26

Multimedia 27
Filter Selection Mode 27
Movie File Browser 27
Movie Playback 28
Go To Menu 29
Music 30
Photo File Browser 31
Photo Playback 32
Photo Thumbnail 33
Recorder Manager 34
Rename 35

Disk Manager 36
Disk Manager Browser 36
Rename 36
Move / Copy 36
E-Book Browser 37
E-Book Menu 37

Software Upgrade 38
USB Upgrade 38

Triax TR112 Specification 39

PIN Code Reminder 41

Appendix 42

Trademarks 42
Troubleshooting 43
End of Life Disposal 44

Terms of Guarantee 45

Declaration of Conformity 46

Introduction 3

Important safety precautions 3
Remote control unit 4
Receiver (front view) 5
Receiver (rear view) 5
Supplied accessories 6

Preparation 7
Inserting the batteries 7
Using the remote control unit 7

Quick guide 8
Initial installation overview 8
Before turning on the power 9
Initial auto installation 9

Watching TV 10
Basic Functions 11
Electronic Programme Guide (EPG) 12
Digital Text 13
Subtitles 13
Record & Time Shift 13

Installation 15
Auto Search 15
Manual Search 16
Channel Filter 16
Channel Management 17
Channel Manager 17
Favourites List 18

Preference Settings 19
OSD Language 19
Preferred Subtitle 19
Hard Hearing 19
Preferred Audio 20
Multimedia 20
PVR Config 20

System Settings Menu 22
System Settings Menu 22
Timers 22
Child Lock 23
Date & Time 23
Active Antenna 24
Factory Reset 24
Upgrade 24
Version 24
Auto Standby 24

Operating Manual

Contents

3

Introduction

Important Safety Precautions

• Cleaning - Unplug the AC power adapter from the AC outlet before cleaning the product.

Use a damp cloth to clean the product. Do not use liquid cleaners or aerosol cleaners.

• Use a soft damp cloth to gently wipe the product when it is dirty. To protect the product,

do not use a chemical cloth to clean it. Chemicals may cause damage or cracks in the casing
of the product.

• Water and moisture - Do not expose the unit to wet or damp conditions.

• Do not place vases or any other water-filled containers on this product.

The water may spill onto the product causing fire or electric shock.

• Ventilation - The vents and other openings in the casing are designed for ventilation.

Do not cover or block these vents and openings since insufficient ventilation can cause overheating
and/or shorten the life of the product. Do not place the product on a bed, sofa, rug or other similar
surface, since they can block ventilation openings. This product is not designed for built-in
installation; do not place the product in an enclosed place such as a bookcase or rack, unless
proper ventilation is provided or the manufacturer’s instructions are followed.

• Heat sources - Keep the product away from heat sources such as direct sunlight, radiators, heaters,

stoves and other heat-generating products (including amplifiers).

• To prevent fire, never place any type of candle or naked flames on the top or near the product.

• The product uses power even in Standby. Unplug the product from the AC outlet when you are not

using it.

• Servicing - Do not attempt to service the product yourself. Removing covers can expose you to

electric shock and other dangerous conditions. Maintenance should be performed by a suitably
qualified person.

4

1 TXT

Displays digital text

2 STANDBY

Switch between standby and on

3 TV / RADIO

Select between TV and radio channels

4 NUMBER PAD

Select the channel number directly by entering
its number. Set the page in digital text mode

5 MENU

“MENU” screen on/off

6 EXIT

Exit on-screen display

7 Go To

Displays Go To menu in multimedia mode

8 NAVIGATION  (Cursor)

Move up/down/left/right in menus and on
screen displays

ENTER

Confirm selection in menu/on-screen display

9 COLOURED BUTTONS

For interactive use, navigating menus and multimedia functions

10 PLAYBACK CONTROLS

For multimedia functions

11 CH+ / CH-

Select the channel (Up/Down)

12 VOL + / -

Increase/decrease the volume

13 SUB

Switch subtitles on/off

14 MEDIA

Enter multimedia functions when a USB or external
Hard Disk Drive is connected to the receiver

15 PAGE UP / PAGE DOWN

Move one page at a time when in menu screens

16 MUTE

Volume on/off

17 EPG

Display the Electronic Programme Guide

18 FAV

Display favourite lists

19 INFO

Displays channel information

20 RECALL

Displays last channel and for multimedia functions

21 REC

Use to record a programme in multimedia mode

22 AUDIO

Select audio mode

23 AD

Switch audio description on/off where applicable

Introduction

Remote Control Unit

16

17

18

19

20

21

22

23

1

2

3

6

5

4

7

8

10

11

13
14

15

12

9

5

Introduction

Receiver (Front View)

Receiver (Rear View)

1 DVB-T Antenna In
2 DVB-T Loopthrough
3 SPDIF Optical Output
4 HDMI Output
5 USB
6 TV (SCART)
7 DC Power Socket

STANDBY BUTTON
CHANNEL DOWN

CHANNEL UP

1

2 3 4 65 7

6

Introduction

Supplied Accessories

Remote Control Unit (x1)

TR112 Operating Manual

Power Adaptor (x1)

AAA Batteries (x2)

HDMI Cable (x1)

+-+

-

7

Preparation

Inserting the batteries

Using the remote control unit

Before using the Receiver for the first time, insert the two supplied “AAA” size zinc-carbon batteries.
When the batteries become depleted and the remote control unit fails to operate, replace the batteries
with new “AAA” size batteries.

1 Open the battery cover.
2 Insert the two supplied “AAA” size zinc-carbon batteries.

• Place batteries with their terminals corresponding to the

(+) and (-) indications in the battery compartment.

3 Close the battery cover.

CAUTION

Improper use of batteries can result in chemical leakage or explosion.
Be sure to follow the instructions below.

• Do not mix batteries of different types. Different types of batteries have different characteristics.

• Do not mix old and new batteries. Mixing old and new batteries can shorten the life of new batteries or cause

chemical leakage in old batteries.

• Remove batteries as soon as they have worn out. Chemicals that leak from batteries can cause skin irritation.

If you find any chemical leakage, wipe thoroughly with a cloth.

• If you will not be using the remote control unit for an extended period of time, remove the batteries from it.

• When replacing the batteries, use zinc-carbon batteries instead of alkaline ones.

Note on disposing batteries:

The batteries provided contain no harmful materials such as cadmium, lead or mercury.
Regulations concerning used batteries stipulate that batteries may no longer be thrown out with the household rubbish
Deposit any used batteries free of charge into the designated collection containers set up at your local recycling centre.

Use the remote control unit by pointing it towards the front of the Receiver.
Objects between the remote control unit and sensor may prevent proper operation.

• Do not expose the remote control unit to shock. In addition, do not expose the remote control unit to liquids

and do not place in an area with high humidity.

• Do not place the remote control unit under direct sunlight. The heat may cause deformation of the unit.

• The remote control unit may not work properly if the remote control sensor of the Receiver is under direct

sunlight or strong lighting. In such cases, change the angle of the lighting or the Receiver, or operate the remote
control unit closer to the remote control sensor.

Cautions regarding the remote control unit

+

-

+

-

8

USB

SPDIF

HDMI

2-CHAUDIOOUT

L

R

CO

Quick Guide

Initial installation overview

Preparation

1 2 3

Watch TV

Run the

Initial Settings

1 Connect the antenna
cable to the RF IN
terminal (Page 9)

1 Turn on the standy button
on the Receiver (Page 10)

1 Congratulations!
You can now watch TV

2 If neccessary, adjust
the antenna to attain
maximum signal
reception

2 Run the first time
installation (Page 9)

Ensure the antenna

is connected

Highlight Start Search

Press ENTER to continue

Start Searching Channels

2 Connect the Receiver
to your TV using the
supplied HDMI cable
(Page 9)

3 Connect the power
adapter to the Receiver
and switch socket on.
(Page 9)

Follow the steps below one by one when using the Receiver for the first time

OPTICAL HDMI

R F i n

RF out

9

Quick Guide

Before turning on the power

Initial auto installation

When the Receiver is powered on for the first time, the First Time Installation screen appears.
Follow the on-screen instructions to search for all available channels.

Confirm the following before turning on the power

• Istheantennacableconnected?

• Isthepoweradapterconnectedandpluggedin?

• IstheHDMI™cableconnectedbetweenthereceiverandyourTV?

1 Ensure the antenna cable is connected before switching on.
2 Press the key on the Receiver or Remote Control.

• The First Time Installation screen is displayed.

3 Highlight Start Search, and press ENTER to start the channel search.

• The Receiver will search for, sort and store all receivable channels.

NOTE

• After the First Time Installation has been completed,

the default PIN is automatically set to ‘0000’.
To change the PIN setting, refer to Page 23.

1 Connect the antenna (IEC 169-2) coaxial plug to RF IN.
Use CAI Benchmarked 75 ohm coaxial cable such as Triax TX100
2 Connect the HDMI™ cable
3 Connect the power adaptor and switch socket on

1

2

3

10

Connect the Aerial to RF In and connect the
External Power Supply to the DC Input. Connect
the HDMI or SCART output to the TV.

Initial Power Up - Power On/Off

When in “Standby” mode, press the key on the
remote control to switch on the receiver. Pressing
the key again will put the receiver back in to
“standby” mode.

First Time Installation

On initial power up, the screen below will be
displayed indicating there are no channels stored.

The initial installation screen shows several basic
set-up parameters, as shown below

Watching TV

Getting Started

The user can select the OSD Language, Country,
Time Zone, Active Antenna and LCN from this
menu.
Press “Start Search” to search channels as
shown below:

Volume Adjustment and Mute

Press “Vol +/-” to adjust the volume when the
system is in normal playing mode; A volume bar
is displayed

Press “Mute” to disable the sound, pressing
“Mute” again will enable the sound.

Changing Channels

Press “CH+/-” to switch to the previous or next
programme in the channel list.
Alternatively press the number keys to input the
programme number directly.

11

Basic Functions

Press “ENTER” to display the Quick Channel
Programme List. Press “LEFT/RIGHT” to select
the channel categories. Press “UP/DOWN” to
select the desired programme.

Quick Channel

Press “ENTER” to select channel. If there are
favourite channels set up, press ‘ENTER’ then the
‘Left/Right’ key to select the required ‘FAV’ list.

Press “UP/DOWN” to select the required
channels, Press “ENTER” to confirm the
selection.

Press the “i” key twice to show information on the
current programme.

Press the “EXIT”key to return to the previous
selected channel.

Press the “AUDIO” key to switch the audio
language of the current programme and switch
between

stereo  left right  (stereo  left channel 
right channel)

Press LEFT/RIGHT to switch between stereo
 left right  (stereo  left channel  right
channel).

Press UP/DOWN to switch the audio language.

Press “ENTER” to confirm the selection and
return to normal play mode.

Programme Information

Audio Language Key and
L/R Channel Key

12

Electronic Programme Guide

Entering the EPG

You can press the “EPG” key on the remote
control to enter into the EPG page. As shown
below:

Enter the EPG menu, “Weekly” mode, (7 Day
EPG), is the default setting, this menu has 7
parts:

Tab 1 shows the title
Tab 2 shows the time and date
Tab 3 shows selected date
Tab 4 shows programme list, press “UP/
DOWN” to switch between
programmes
Tab 5 shows the time range and
programme information
Tab 6 shows detailed programme
information from Tab 5
Tab 7 shows information for keys,
corresponding to the coloured keys
on the remote control

Press “LEFT/RIGHT” to switch between
programmes in the list

Press the “RED” key to enter into DAILY/
WEEKLY” mode which displays the channels and
programme information in different time ranges,
as shown in the picture.

Press the “YELLOW” & “BLUE” key to switch
between days in Tab 3

Press “UP/DOWN” key to move upward and
downwards to switch between the different
programmes in Tab 5

Press “LEFT/RIGHT” key to view the programme
information in different time ranges in Tab 6.

When a programme is selected, press the “i” key
to select the detailed information corresponding
to the current program, as shown below.

When a programme is selected in Tab 5,
press the green key to set a timer to book the
programme, as shown in the diagram overleaf:

4

3

6

5

7

1

2

13

Default subtitle setting is off. To switch on
subtitles, press the “SUB” key on the remote
control to enter the subtitle menu of the current
programme, as shown in the picture below:

Press the “UP/DOWN” key to choose the
required language. Press ‘ENTER’ to leave the
menu.

*In order to use these features an external USB
memory device must be connected.

At playback screen press “REC” key to start
recording, the system will take approximately 3
seconds to initialise. This is shown below:

Digital Text

Accessing digital text

1 Select a channel which broadcasts digital text.

2 Press or the button.

• Not all channels broadcast digital text.

• You may not be able to receive digital text if you

have a poor quality signal.

Buttons for digital text operation

Buttons Description

Some channels are broadcast with digital
text which contains pages of information and
entertainment. News, weather, sports information,
stock exchange prices and programme previews
are among the many services.

Navigate the digital text index
page and menu system

Coloured

Buttons

Numeric

Buttons 0-9

EXIT / TEXT

Access digital text shortcuts.
These are often displayed on
the bottom of the page

Directly select a page

Exit digital text

///

Subtitles

Record & Time Shift*

Press “EXIT” to leave the EPG

14

When a recording has been initialised, the LED on
the front panel will flash slowly between red and
blue. This shows the current programme is being
recorded. Pressing “i” displays the information on
the current recording.

Pressing the stop key while recording, will prompt
a ‘Confirm Stop Rec’ message and resume normal
playback.

When recording, you can also use the “REC” key
to set a timer to stop recording, pressing “REC”
again allows you to reset the timer.

If there is insufficient memory space while
recording, the system will show a prompt
message, stop recording and resume normal
playback mode.

If a recording fails due to memory storage
problems, the system will show a prompt
message and try again.

During recording, you can also operate the
Menu, EPG, TTX, Subtitle and so on, as if in
normal playback mode.

Time Shift Mode is only available when an
external memory device is connected to the
receiver.

(1) In time shift mode, you can pause a live
programme.

Time Shift Mode

15

(2) Pressing the “PAUSE” key will start the time
shift mode. The “Time Shift” icon will be shown
on the screen this operation is available:

(a) In normal playback mode, when time shift is
set to Auto or Pause within the PVR Config Menu.

(b) In recording mode.

(3) Pressing the “<<” key when in time shift mode,
will fast rewind the programme. This operation
is available :

(a) In normal playback mode, when time shift is
set to Auto or Pause within the PVR Config
Menu.

(b) In recording mode.

(4) In time shift mode, when the “STOP” key is
pressed, it will exit time shift mode and return to
playing the live programme. Any recording will
continue to record as normal.

(5) In time shift mode, Fast Forward will catch
up with the live programme, when the time
shift catches up with the live programme, it
automatically exits time shift mode, and returns to
the current program. Any recording being made
will carry on as normal.

There are two kinds of Installation modes these
are outlined below:

(1) Auto Search

(2) Manual Search

You select the “Installation menu” from the “Main
Menu”. A PIN Number is required. (default PIN
is 0000)

Auto Search is an intelligent and convenient
mode of programs searching. It searches all
frequencies within countries of region.

Countries include Ireland/UK/Germany/Italy/
France/Spain/Holland/Taiwan/China/Norway/
Finland, etc. Select “Auto Search”, then press
the “ENTER” key to start the “Auto Search”.

Installation

Auto Search

Installation

16

To carry out a manual search, you need to
configure the relevant parameters including:

(1) Frequency (kHz): The default frequency
depends on the selected country, you can input
relevant information to modify it.

(2) Bandwidth: The default value of bandwidth
depends on the selected country. It can be set to
6 MHz,7 MHz, or 8 MHz.

(3) Press the “ENTER” key after configuration to
start manual scan.

(4) Press the ‘EXIT’ key to return to normal
viewing.

A scan of all channels or free to air only channels
can be selected, this is illustrated in the picture
below:

After selecting the “Auto Search” page, the
receiver will scan all frequencies one by one for
the selected country.

During scanning, you can press the “EXIT” key to
stop the scanning process and exit.

If any programmes are detected and the scanning
process has finished the system will exit the
scanning page, save the programmes and return
to the “installation menu”, this is shown below:

If you know the frequency of the channels, or
if you want to scan a channel at a particular
frequency, you can select manual search.

Move the cursor to “Manual Search” using the
“UP/DOWN” key when in the “installation menu”,
press “ENTER” to select the manual search page,
this is shown in the picture below:

Manual Search

Channel Filter

17

Channel management features include channel
deleting, marking, moving, locking, renaming and
grouping.

There are two independant pages for channel
management, TV and RADIO, this is illustrated
below:

The channel manager page includes channel
deleting, moving, locking and renaming of
channels. You can enter the page as shown
below, by using the “MENU > channel > channel
manager on the remote control.

If there are no channels saved a channel not
available will be displayed, and it will not enter
into the channel organiser page.

Channel Management

Channel Manager

The channel organiser menu includes: Delete
Channel, Skip Channel, Lock Channel and
Channel Rename.

Press the “UP/DOWN” key to choose the
channel, then press the 4-colour keys on the
remote control. Press the RED key to Set and
Cancel Channel Lock. The GREEN key to Set or
Cancel Delete Channel. The YELLOW key to Set
or Cancel Skip Channel. The BLUE key to Set or
Cancel Rename Channel; After setting, A typical
screen is shown below.

To rename a channel, press the “UP/DOWN” key
to choose the channel to be renamed. Press the
BLUE key to enter the channel rename page.
This is shown below:

Press the BLUE key again to exit the channel
rename page.

18

To Set or Cancel Lock Program, the system
will prompt you to input your password (default
“0000”). You will be asked to confirm the change,
press ‘ENTER’.

To Delete a programme, the system will show

adialoguebox“DeleteSelectedChannels?”,

press the ‘LEFT/RIGHT’ keys and select “YES” to
confirm delete of the chosen channel select “NO”
to Cancel.

Press the “EXIT” key to exit the Channel Manager
menu and save the edited results.

Enter the page as shown in the figure below via
“Main Menu > Channel > Favourite List

If there are no channels saved a dialogue box
prompting favourite channel not available will be
displayed and it will not enter into the channel
grouping page.

Press UP/DOWN key to choose the channel to
be grouped, then press the coloured keys on the
remote control to set different channel grouping.

After a channel is edited, the EXIT key is pressed
to exit from the menu, if any channels have been
edited, the system will carry out favourite list
update, displaying “Data Saving” message on the
screen.

Favourites List

When the Favourite Lists have been set up,
they are accessed by pressing the ‘FAV’ key on
the Remote Control. Once a Favourite List is
displayed, use the ‘Left and Right’ keys on the
Remote Control to select the desired list.

19

(3) Press the ENTER key to confirm the selected
language, the setting is then activated and the
OSD language changes to the chosen language.

(1) You can set the subtitle language to your
preferred language type. These include English,
French, German, Italian, Spanish, Portuguese,
Danish, Czech, Dutch, Finnish, Swedish, Greek,
Russian, Welsh, or Gaelic.

(2) When the preferred subtitle has been
selected, it will display the selected subtitles
automatically while the stream has the suited
subtitle.

(3) The user can set another subtitle language in
the 2nd preferred subtitle field

Enables/Disables the “Hearing Impaired
Feature”.

Preference Settings

The receiver can be configured according to the
user preferences, by pressing MAIN MENU >
PREFERENCE.

This is shown below:

OSD Language option: The user interface
supports several languages, you can set the
language via the OSD language option.

(1) Move the cursor onto the language option,
press RIGHT key to enter the OSD language list.
is shown below:

(2) Press the UP/DOWN key to choose the
required language

OSD Language

Preferred Subtitle

Hard Hearing

20

You can enter the PVR Configuration page
(as shown in the picture below) via “Menu >
Preference > PVR Config”, this menu contains
six options as follows:

• PVRFileFormat

• FileSize

• PreferredStorage

• Timeshift

• TimeShiftLength

• TimeshifttoRecord

(1) PVR File Format:

You can select either, TS/PS, to set the format
of the file to be stored; if TS mode is selected,
related psi/si table information in code stream
can be recorded during the programme, if PS
mode is selected, AV data is recorded only.

(2) File Size:

You can select from 4G/3G/2G/1G. This sets the
size of the file to be recorded; if the size of the
file exceeds the setting size during the recording
of the programme, the recording will divide the
file into separate files with the set sizes.

(1) Sets the preferred audio to “English,
French, German, Italian, Spanish, Portuguese,
Danish,Czech, Dutch, Finnish, Swedish, Greek,
Russian, Welsh, or Gaelic”.

(2) 1st preferred audio option: Press the RIGHT
key to enter the currently supported audio
language list. In the audio language list, press
UP/DOWN key to choose the required language,
press the ENTER key to confirm.

(3) 2nd preferred audio option: Press the RIGHT
key to enter the currently supported audio
language list. In the audio language list, press
UP/DOWN key to choose the required language,
press the ENTER key to confirm.

If used in Media mode, you can configure the
setting according to your own preference, This is
shown below:

Preferred Audio PVR Config

PVR Config Setting Page

Multimedia

21

(3) Preferred Storage:

Sets the USB as storage.

(4) Timeshift:

Any of options, AUTO/OFF/ PAUSE, can be
selected to set the status of the current timeshift,
if AUTO is selected, the timeshift operation will
perform automatically in the background, the
user can change channel but this discards the
previous timeshift buffer and restarts a new one;
if OFF is selected, the timeshift operation will
stop; if PAUSE is selected, the timeshift operation
will manually start by pressing the Pause key.
The screen freezes at once, it can be resumed
by pressing the Play key. During timeshift you
can only select another channel within the same
multiplex. The timeshift buffer only records the
first channel; and if the preceding three options
are changed when AUTO is selected, timeshift will
restart.

(5) Timeshift Length:

The options, AUTO/30min/1h/2h, can be selected
to set the duration of the timeshift; if AUTO is
selected, the duration of the timeshift is dependant
on the available size of the USB memory. If any of
the options, 30min/1h/2h, are selected, the usable
duration of the timeshift is 30min/1h/2h provided
that the USB memory is big enough, where by, the
usable duration of the timeshift is dependant on
the available USB memory.

(6) Timeshift to Record:

Either of options, ON/OFF, can be selected. If
ON is selected, timeshift operation will stop and
the recorded file buffered by the timeshift will be
stored in USB memory; if OFF is selected, timeshift
will operate continuously and the recorded file
buffered by the timeshift will not be stored in USB
memory.

22

The following options can be accessed in the
“System Settings Menu”. To enter this menu
press Main Menu > Settings, then press ‘Enter’
see below:

If you want to watch a channel at a certain time or
record programmes, reminders can be set in the
Timers menu, This is shown below in the picture.

• Providesalistwheretimerscanbeadded,

viewed, edited, or deleted

• “TimerMode”shalllistallthetimersthatare

added via the “EPG” as well as the timers
that are manually added by the user through
the “Timer Menu”

• AMaximumof10timerscanbeset.

System Settings Menu

System Settings Menu

Timers

In the Timer Edit menu, the system can support
up to 10 events. Date:Specifies the timer date

Programme Name:

Specifies the channel for which the timer is set

Start Time:

Specifies the start time of the timer

End Time:

Specifies the end time of the timer

Duration:

Specifies the duration time of the timer

Mode:

Specifies the frequency of the timer, the duration
can be any of the following:

• Once-timerwillbetriggeredonlyonce.

• Daily -timerwillbetriggereddailyatthe

specified time.

• Weekly-timerwillbetriggeredeveryweek

at the specified time.

• Monthly-timerwillbetriggeredevery 

Month at the specified time.

Type:

Specifies the channel type for which the timer is
set. The user can select the channel, Recorder,
VCR, On and Standby in this option. The user
selects Recorder type, you can Enable or
Disable the following options such as AD
Record.

23

(1) Press the 0 - 9 numerical keys on the remote
control to input the Old Password, the system
default password is “0 0 0 0”.

(2) If the password is input correctly, the cursor
will move to Input “New Password” option,
press the 0 - 9 numerical keys on the remote
control to input the new 4-digit password.

(3) You will then be asked to Confirm the New
Password.

The “Time Menu” contains different time
settings. The following menu layout shows the
Time Settings Page:

Pressing the ENTER key will return the system
to the previous menu. As shown overleaf in the
picture.

Press EXIT’ to resume normal viewing.

The Child Lock Menu allows selected channels to
be locked, as shown below:

(1) Here you can Enable or Disable the system
lock, the parental rating age from 0 - 18 years can
also be set.

(2) You can also enter a new password of your
choice, this process is achieved by entering the
old password,and then entering a new one of
your choice. It is recommended that you keep this
password in a safe place. This is shown below.

Child Lock

Date & Time

24

If the Time Mode is set to Auto then, Time Zone
and DST shall be active for editing. If the Mode is
Manual these options shall be disabled.

If the Time Mode is set to Manual then, Date
and Time shall be active for editing. If the Mode is
“Auto” these options shall be disabled.

In ‘MAIN MENU > INSTALLATION’, the Active
Antenna option allows the 5V antenna powering
on the RF Input to be Enabled or Disabled.

This will restore all “Default Settings” The system
will prompt the user to input a password (default
“0 0 0 0 “) to activate “Factory Reset”.

Refer to SOFTWARE UPGRADE Section on page
41 for details.

Active Antenna

Factory Reset

Upgrade

Displays the Receiver Information.
This is shown below.

This shows the system information, including the
H/W Version, S/W Version, F/W Version, Build
Date and Time. Press the BACK key to return to
the previous menu.

Enables/Disables the “Auto Standby”. The user
can select 1 Hr, 2Hrs or 3 Hrs, (Default setting
is 3 Hrs). If the receiver receives no commands,
either from the Remote Control or Front Panel
buttons, for the set time, the receiver will
automatically enter standby. This feature can be
disabled, in the menu, if required.

Version

Auto Standby

25

To adjust the Brightness and Saturation settings,
follow the same process as for the Contrast
setting above.

This setting is used to select AVC Mode - Mute,
PCM and Bitstream.

The Aspect Ratio settings are used to select
the video output mode in order to match the
receiving equipment.

Select the Aspect Ratio option, press ENTER to
select.
Press the UP/DOWN key to toggle between
options;
Aspect Ratio can be set as 16: 9, 4: 3 PanScan,
4: 3 LetterBox,16:9 PanScan

Press ENTER to save the setting

To enter this menu, press ‘MAIN MENU > AV’,
then press ‘ENTER’.

The AV setup menu is shown in the picture below

You can set the system Contrast by using the
Contrast option.

(1) To select the Contrast option, press the RIGHT
key to move the cursor into the properties list,
press “ENTER” to select contrast menu. Press
LEFT/RIGHT to adjust the contrast. As shown
below:

(2) The Contrast can be set from 0 to 24.

(3) The default Contrast setting is 12.

AV Settings

Contrast

Brightness & Saturation

SPDIF

Aspect Ratio

26

This allows the user to change the video output
mode. You can adjust the settings to suit the
receiving equipment.

Select Video Output, press the ENTER key to
select.
Press the UP/DOWN key to toggle between
options;
Video Output can be set as RGB, YUV, S-Video;
Default: Scart RGB
Press ENTER to save the setting;

Video Resolution mode changes the Resolution
of the video output. You can adjust the settings to
suit the receiving equipment.

Select the Video Resolution, press the ENTER
key to select. Press the UP/DOWN key to toggle
between settings.
The Video Resolution can be set as:

576i_25,720p_50,1080i_25,1080p_50,576p_50;

Default: 720p_50.

Press ENTER to save the setting.

Video Output

Video Resolution

HDMI Colour Space changes the HDMI Output
Mode. You can adjust the settings to suit the
receiving equipment.

Select the HDMI Colour Space, press the ENTER
key to select,

Press the UP/DOWN key to toggle between
settings.

The Output mode can be set as YCbCr 4:4:4,
xvColor, RGB, YCbCr 4:2:2.
Default: RGB;

Press ENTER to save the setting;

HDMI Deep Colour changes the HDMI Output
mode. You can adjust the settings to suit the
receiving equipment.

Select HDMI Deep Colour, press the ENTER key
to select.

Press the UP/DOWN key to toggle between
settings.

The Output can be set as 12 Bits, 8 Bits or 10
Bits. Default: 8 Bits.
Press ENTER to save the settings.

HDMI Colour Space

HDMI Deep Colour

27

Multi Media

Filter Selection Mode

Movie File Browser

Key Stroke Action

Changes from filter selection
mode to file list.

Changes the filter selection
mode, for instance from movie
to music, from music to photo
etc.

The Same as KEY_LEFT

KEY_RIGHT

KEY_LEFT

KEY_DOWN

Multimedia - Filter Selection Mode Icons

Filter selection mode is “Movie”

Filter selection mode is”Music”

Filter selection mode is “Photo”

Filter selection mode is ”Recorder Manager”

Filter selection mode is “Disk Manager”

Filter selection mode is”E-book”

The Triax TR 112 has a USB Interface. This can
be used to connect external equipment such as
Memory Devices, Media Players and can also be
used for system software upgrades. This product
supports MP3, JPEG and MPEG.

To enter the Multimedia Mode press the ‘MEDIA’
key on the Remote Control.

Please note a USB or external hard disk drive
needs to be connected to access the options
on this menu.

This allows the Filter Mode to be changed from
movie to music or from music to photo etc. For
example if the current filter selection is movie, the
image below shows the Filter Selection Menu.

There are three keys used in this menu.
The following table shows the keys.

The following table shows all the available filter
selection modes and their corresponding icons.

Press ‘RECALL’ to return to Filter Selection Mode.

This menu helps the user to select and play
a movie from a list that is stored in the USB
device.

Supported file formats are MPG, AVI, VOB, DAT,
ASF, MKV, RM, WMV, TSF, QT. The following
menu shows the “Movie Menu”.

28

Key Stroke

Key Stroke

Action

Action

KEY_LEFT

KEY_PAUSE

KEY_PAGEUP

KEY_NEXT

KEY_PLAY

KEY_PAGEDOWN

KEY_RIGHT

KEY_STOP

KEY_ENTER

KEY_FF

KEY_RECALL

KEY_FR

KEY_NUM

KEY_MENU

KEY_MEDIA

KEY_DOWN

KEY_PREV

KEY_UP

KEY_RED

Highlights the previous Item
in file list. If it passes the first
item, the last item will be
highlighted.

Highlights the next Item in the
file list. If it passes the last
item, the first item will be
highlighted.

Moves up the list by one page.

Moves down the list by one
page.

If the current file has a parent
folder, pressing this key will
return from the current list to
the parent folder.

If current highlighted item is a
folder, it enters the folder.

If the highlighted item is a
folder, pressing KEY_ENTER
enters the folder. If it is a file
then pressing the key will play
the selected video.

If the highlighted item is in
the file list, pressing KEY_
RECALL returns to the filter
selection mode. If it is playing
a video, pressing the key
returns to the previous layout .

If the input number is larger
than the number on the file
list, an incorrect message is
shown.

Toggles between the FILE
BROWSER and MAIN MENU.

Changes the source to DVB.

Movie Playback

Zooms in and out the image.

Stops the current movie and
plays the previous movie in
the list.

Stops the current movie and
plays the next movie in the list.

If the movie is paused, FF, FB,
SF or SB, it will change to play
and show play icon.

If playing, this key will pause
the movie and show pause
icon.

Stops the movie.

Fast forwards the movie. It
cycles through the sequence
2x->4x->8x->16x->1x, and the
playback mode is displayed in
the upper left corner.

Fast reverses the movie. It can
cycle through the sequence
2x->4x->8x->16x->1x, and the
playback mode is displayed in
the upper left corner.

The keys for this menu are shown in the table.
Settings are saved when they are changed.

29

Key Stroke Action

KEY_i

KEY_GOTO

KEY_MUTE

KEY_VOLUME

KEY_RECALL

KEY_SLOW

Slow Replay.

The same as KEY_STOP

Activates the MUTE function ­Audio goes off.

Adjusts the volume

Displays information on the
current movie.

The Go To menu is displayed
when this key is pressed.

Zooms in and out of the image

Stops the current movie and plays
the previous movie in the list.

Stops the current movie and plays

the next movie in the list.

Play

Pause

Stop

Fast Reverse, (1x, 2x, 4x, 8x, 16x).

Fast Forward, (1x, 2x, 4x, 8x, 16x).

Slow replay

Fast replay.

The keys in this menu are shown below.

Switches between Time edit
mode and time move mode.

The same as KEY_UP.

In time edit mode moves the
highlighted curser or in move
control mode moves the mark.

The same as KEY_LEFT.

Moves the currently playing
movie to the selected time.

Exits the Go To menu.

Exit from the Go To menu.

Key Stroke Action

KEY_RIGHT

KEY_ENTER

KEY_RECALL

KEY_GOTO

KEY_LEFT

KEY_DOWN

KEY_UP

Go To Menu

The information icons shown while video playing
are shown below:

When the video is playing, the following
information is displayed on the OSD:

(a) File name.
(b) Total time and the current time for the file.
(c) Play state of this video.
(d) Progress bar.
(e) File size and resolution of this video.
(f) Repeat mode such as off/one/dir.

30

Music

Key Stroke Action

KEY_PAGEUP

KEY_PAGEDOWN

KEY_LEFT

KEY_RIGHT

KEY_RECALL

KEY_PREV

KEY_NEXT

KEY_PLAY

KEY_PAUSE

KEY_STOP

KEY_FF

KEY_DOWN

KEY_UP

Highlights the previous Item in
the file list. If it passes the first
item, it highlights the last item
in the file list.

Highlights the next Item in the
file list. If it passes the last
item, it highlights the first item
in the file list.

Moves up the file list by one
page.

Moves down the file list by
one page.

If the highlighted file has a
parent folder, it returns from
the current list to the parent
folder.

If the highlighted file and the
current highlighted item is a
folder, it can be entered into
the folder.

If the highlighted file is in
a file list, pressing KEY_
RECALL returns from the file
list to the filter selection mode.
If a music track is playing,
KEY_RECALL willl stop it.

If the highlighted file is music
and the music is playing,
pressing this key stops this
track and plays the previous
track.

If the highlighted file is music
and the music is playing,
pressing this key will stop this
track and plays the next track.

If the music is paused, FF, FB,
SF, SB or stopped, it will start
playing the track and show
play icon. The name of the
current track will be displayed.

If the music is playing,
pressing this key will pause the
music and the pause icon is
displayed.

Stops the music and shows
the stop icon.

Fast forwards the music. The
FF icon is shown and the
speed, (1x 2x, 4x, 8x, 16x)
shall be displayed.

This menu allows the user to select and play a
track from a list of music stored in the storage
device.

The following formats are supported WMA, WAV,
DTS, RA and MP3.

The following table shows the Music menu.

The following points explain the Music menu
above.

(1) The file list is the list of folders and music.

(2) On the left of the file list shows the Folder
information and files, for example if filter
selection is in music mode, it shows the
equaliser, progress, play state, total time
and file size of the selected track.
(3) It is background music, so when music is
playing, the user can change directory or
make changes in the filter list to select other
modes such as movie, photo, e-book etc.
The keys used in this menu are shown below.

31

Key Stroke

Key Stroke

Action

Action

KEY_MENU

KEY_PAGEUP

KEY_LEFT

KEY_RIGHT

KEY_ENTER

KEY_RECALL

KEY_NUM

KEY_MENU

KEY_MEDIA

KEY_YELLOW

KEY_MEDIA

KEY_PAGEDOWN

KEY_NUM

KEY_DOWN

KEY_FR

KEY_UP

Fast reverses the music. The
FR icon is shown and the
speed, (1x 2x, 4x, 8x, 16x)
shall be displayed.

Enter the number directly. If the
input number is larger than the
number of file list, an incorrect
message will be shown.

File browser menu disappears
and shows the main menu or
main menu disappears and
shows the file browser again.

Change the source to DVB

Photo File Browser

The keys in this menu are shown in the table
below the image.

Highlights the previous item in
file list. If it passes the
first item, it highlights the last
item in file list.

Highlights the next item in the
file list. If it passes the
last item, it highlights the first
item.

Moves up the file list by one
page.

Moves down the file list by
one page.

Pressing this key moves from
the current list to the parent
folder.

If the current highlighted item is
a folder, then pressing this key
enters the folder.

If the highlighted item is a
folder, pressing KEY_ENTER
enters the folder. If it is a file
then pressing the key will show
the selected photo.

In the file list, pressing KEY_
RECALL returns from the file list
to the filter selection mode.

Allows a number to be entered
directly. If the input number is
larger than the number in the
file list an incorrect message
will be shown

The file browser menu
disappears and the main menu
is shown, OR, vice-versa.

Changes the media.

Shows the thumbnail menu.

Stops this track and plays the previous track in the list

Stops this track and plays the next track in the list

Play

Pause

Stop

Fast Reverse

Fast Forward

This menu contains the Photos that are stored in
the storage device. Supported file formats are
JPG, TIF, PNG, GIF and BMP.

Following menu layout shows the Photo menu.

When a music track is playing, the following icons
are displayed:

32

Photo Playback

Rotates the image 0 degrees.

Rotates the image 180
degrees.

Rotates the image 270
degrees.

Rotates the image 90 degrees.

Displays the previous image in
the List. If the displayed image
is the first one then the key is
ignored.

Displays the next image in the
List. If the displayed image is
the last one then the key is
ignored.

Displays information on the
photograph, (see images
above).

Pauses the slide show.

Plays the slide show.

Stops the slide show and
returns to the Photo menu

Exits the displayed image and
returns to the Photo menu.

Zooms in and out of the
image.

Key Stroke Action

KEY_LEFT

KEY_PREV

KEY_NEXT

KEY_i

KEY_PAUSE

KEY_PLAY

KEY_STOP

KEY_RECALL

KEY_RED

KEY_RIGHT

KEY_DOWN

KEY_UP

The keys for operating Photo Mode are
shown below

Zoom-in / out of a photo (x4)

Closes the current photo and shows the previous
photo in the list

Closes the current photo and shows the next
photo in the list

Selects and shows photo

Pause photo / Slide show

Return to the file list

When an image is displayed in full screen then
the following keys are active:

The Photo Playback Menu shown below shows
the menu available while photographs are being
shown. The images below shows the playback
menu for displaying a single photograph and
setting up a slide show.

33

Photo Thumbnail

Key Stroke Action

KEY_PAGEUP

KEY_LEFT

KEY_RIGHT

KEY_ENTER

KEY_RECALL

KEY_MEDIA

KEY_NUM

KEY_PAGEDOWN

KEY_DOWN

KEY_UP

Highlights the previous item
in the same column. If the
top KEY_UP of the column
is reached, it highlights the
bottom item in the column.

Highlights the next item in the
same column. If the bottom
of KEY_DOWN the column is
reached, it highlights the top
item in the column

Moves up the column by one
page.

Moves down the column by
one page.

Highlights the item to the left.

Highlights the item to the right.

If the selected item is a folder.
pressing KEY_ENTER will enter
the folder.

Shows the Photo menu.

Changes the source to DVB.

Allows a number to be entered
directly. If the input number is
larger than the number in the
file list, an incorrect message
will be displayed.

This menu displays the thumbnail view for the
photographs stored in the selected folder. The
following table shows the thumbnail menu.

The keys in this menu are shown below:

34

Recorder Manager

Highlights the previous item in
the file list. If the first item is
reached, it highlights the last
item in the file list.

Highlights the next item in
the file list. If the last item is
reached, it highlights the first
item.

This key works in the file list
only, It moves Up the list by
one page.

The same as KEY_PAGEUP,
it only works in the file list. It
moves Down the list by one
page.

Returns from current list to the
parent folder.

Allows you to enter a folder.
If a folder is selected, pressing

KEY_ENTER enters into the
folder. If it is a file then pressing
the key will play the selected
recorded program.

When in the file list, pressing
KEY_RECALL returns from file
list to the filter selection mode.
If it is playing a recorded
program, pressing the key
returns to “Recorder Manager
Menu.

If in the root directory, pressing
this key sets a partition. If in
the sub directory pressing it will
delete the selected item.

If in the root directory, pressing
this key formats the card to
FAT32, If in the sub directory
pressing it will rename the
selected item.

If in the root directory, pressing
this key formats the card to
NTFS.

Enter a number directly. If the
input number is larger than the
number of file list, incorrect
message will be shown.

The File browser menu
disappears and shows the
main menu, or main menu
disappears and shows the file
browser again.

Change the media to DVB

Key Stroke Action

KEY_PAGEUP

KEY_LEFT

KEY_RIGHT

KEY_ENTER

KEY_RECALL

KEY_MEDIA

KEY_RED

KEY_GREEN

KEY_YELLOW

KEY_NUM

KEY_MENU

KEY_PAGEDOWN

KEY_DOWN

KEY_UP

The picture below shows the Recorder Manager
menu. All recorded programms will appear in this
menu.

35

Rename

Highlights the previous item in
the same column. If the first
item is reached, it highlights
the last item in the same
column.

Highlights the next item in the
same column. If the last item
is reached, it highlights the first
item in the same column.

Highlights the next item in the
same row. If the last item is
reached, it highlights the first
item in the same row.

Highlights the last item in the
same row. If the first item is
reached, it highlights the last
item in the same row.

Change the media to DVB

Changes the characters
between capital and lowercase

Enters a space

Deletes the current character

Confirms the modification
to the name and the menu
returns to Recorder manager
Menu.

Key Stroke Action

KEY_YELLOW

KEY_BLUE

KEY_LEFT

KEY_RIGHT

KEY_MEDIA

KEY_RED

KEY_GREEN

KEY_DOWN

KEY_UP

The picture below shows the Rename Menu
In this menu the user can change the program’s
name to their own preference.

36

Disk Manager

Disk Manager Browser

Rename

Move / Copy

Show move/copy menu.

Show rename menu.

Delete the selected item.

Key Stroke Action

KEY_YELLOW

KEY_GREEN

KEY_RED

Highlights the previous item in
the file list. If the first item is
reached, it highlights the last
item in file list.

Highlights the next item in
the file list. If the last item
is reached, it highlights the
first item.

Moves up the list by one page.

Moves down the list by one
page.

Change the selected file from
one side to the other side.

The same as KEY_LEFT.

If the selected item is a folder,
press KEY_ENTER to
enter the folder.

Return to parent folder.

Return to disk manager menu.

Select the highlighted item
and move to the other side.

Copy the content of the
selected item to the other side

Move the selected item to the
other side

The file browser menu
disappears and shows the
main menu, or the main menu
disappears and shows the file
browser again

Changes the source to DVB

Key Stroke Action

KEY_PAGEUP

KEY_LEFT

KEY_RIGHT

KEY_ENTER

KEY_RECALL

KEY_MEDIA

KEY_GREEN

KEY_YELLOW

KEY_EXIT

KEY_MENU

KEY_BLUE

KEY_PAGEDOWN

KEY_DOWN

KEY_UP

The Disk Manager Menu is like the file browser
menu, the keys work as in the same way but the
function of the four colour keys are different. The
following table shows the functions of the four
coloured keys. The other keys are the same as
those in the file browser menus.

The Rename Menu is same Layout and
functionality as discussed earlier in this manual.

The Menu shown in the picture below is the
Move/copy Menu. In this menu the user can
move files or folders from one side to the other.
It can also copy the content from one side to the
other.

37

E-Book Browser

E-Book Menu

Key Stroke Action

KEY_PAGEUP

KEY_PREV

KEY_NEXT

KEY_NUM

KEY_ENTER

KEY_RECALL

KEY_MEDIA

KEY_EXIT

KEY_MENU

KEY_PAGEDOWN

Move to previous page, if it is
already the first page, it will
not move.

Move to next page, if it is
already the last page, it will
not move.

The same as KEY_PAGEUP

The same as KEY_PAGEDOWN

User can input number key to
select the required page.

When a page number has been
entered, then pressing this key
will go to the corresponding
page.

Return to file browser menu of
e-book.

The same as KEY_RECALL.

The E-book menu disappears
and shows the Main Menu or
Main Menu disappears and
shows the E-book again.

Changes the media to DVB

The e-book menu is like the file browser menu,
the keys work as in the file browser menu. The
four coloured keys have no function. Other keys
are the same as the keys in the other file browser
menus. For instance, KEY_UP/KEY_DOWN can
move the selected file and KEY_ENTER plays the
selected e-book etc.

The picture below shows the E-Book Menu. In
this menu the user can read text files, the menu
also shows the name of the current file, the total
number of pages and the current page.

38

Software Upgrade

USB Upgrade

The receiver software can be upgraded. The
software upgrade menu can be accessed through
Menu > Settings > Upgrade. This is shown below:

The USB upgrade is a fast and convenient way
to upgrade the system software, You simply
copy the upgrade file onto a USB memory stick,
and plug the USB device into the system USB
interface. You can then upgrade the software as
follows:

• BeforeaUSBupgrade,youmustprepare

the upgrade file. The file name is usually a
*.bin (not case sensitive), Otherwise the
system can not enter the upgrade mode.

• ThesizeoftheUSBupgradelemustbe

less than or equal to 4M bytes, if not it may
result in a failure to upgrade.

• USBupgrade:

- Enter the USB upgrade menu
press(menu -> setting -> upgrade ->
USB upgrade)
Enter the USB directory list page, as
shown below:

- Select the upgrade file and press the
“enter” key to start the upgrade. Enter
the upgrade page to show information
and prompt the user on the upgrade
process:

• ThewholeUSBupgradeprocessmaytake

a couple of minutes.

• DONOTswitchoffthepowerduringthe

upgrade process.

• Whentheupgradehasnished,thesystem

will automatically restart with the new
firmware.

39

Triax TR112 Specification

Tuner / Demodulator Standard DVB-T

Input Frequency* VHF/UHF Band
Channel Bandwidth* 7 MHz/8 MHz Switchable
Power for Active Antenna 5V@30mA with overload Protection through Coaxial Cable
COFDM System 2K, 8K Carrier, Hierarchical Supported
Demodulation Type QPSK, 16QAM, 64QAM, 256QAM
Guard Interval 1/32, 1/16, 1/8, 1/4 Active Symbol Duration
FEC 1/2, 2/3, 3/4, 5/6, 7/8

System CPU / Clock Sunplus 1500
Transport DVB Demultiplexer
Flash Memory 4Mbytes SPI
System Memory 512MBits X 2 DDR2

Video CPU Core 667Mhz 32bit
Video Standards MPEG-1 ISO/IEC 11172-2
MPEG-2 MP@ML and MP@HL, ISO/IEC 13818-2
MPEG-4 AVC MP@L4 and HP@L4.1
Field / Frame Rate 60/30 Hz for NTSC or 50/25 Hz for PAL
Aspect Ratio 4:3, 16:9 & Letter Box
Video Input / Output Digital Video HDMI with HDCP supported CVBS,
R/G/B for TV SCART OUT
Output Modes HD
1080p / 1080i / 720p / 576p
Output format changed by specific hot-key (software switchable)
SD
576i

Teletext / Subtitle Decoding and display for supporting Closed Captions & Teletext

Audio CPU Core 667Mhz 32bit

Audio Standards MPEG-1 layer I & layer II, MP3
MPEG-2 layer II , Dolby Digital
MPEG-2 AAC/AAC+
Audio Input / Output AL/AR for TV SCART OUT (Volume adjustable)
Optical Digital Audio SPDIF
Digital Audio SPDIF IEC-60958 for PCM data
Output Format IEC-61937 for Encoded Bitstream Data
Sampling Rate 32, 44.1, 48, and 96 KHz

Connectivity USB Port Software Upgrade and Diagnostic (Reserved Internally)

Support external H.D.D. (with 1A current protection)

Software Upgrade Over Air Download No
RS-232 or USB Port Yes

Front Panel Keypad 3 Keypads: Power/ standby, CH Up/Down,
IR Sensor Yes

40

Rear Panel RF Input Connector* IEC type, Female (for PAL), 75 Ohm
Loop Through
Output Connector IEC type, Male, 75 Ohm
Stereo (left & right) Audio Single SCART for TV
CVBS, R/G/B video output For TV SCART: w/ OSD and Volume adjustable

Digital Video & Audio Output HDMI Connector
Optical Digital Audio SPDIF TosLink Interface

Power Interface Input Voltage 100~240 VAC, 50/60 Hz (2A adaptor , T.B.D. )
Power Consumption Normal Operation: TBD, Standby Mode: Less than 1W

Others Power indicator, 2 colours, As same FP as TR105
Blue/Red, FP:type Q8
Accessory Remote Controller & Batteries
User Manual
HDMI Cable (1.5m)
EMC / Safety Compliant to CE (standard)
ATC HDMI 1.3, HDCP
Dolby Compliant to DD+

Triax reserves the right to change the specifications without prior notification.

41

PIN CODE Reminder

NOTE

You need to insert the PIN code here and refer it to the pages in the manual where this is covered.

IMPORTANT

Removal of a lost PIN code could be subject to a service charge.

42

Appendix

Trademarks

This product is capable of receiving and decoding
Dolby Digital Plus. Manufactured under licence from
Dolby Laboratories. Dolby and the double-D symbol
are trademarks of Dolby Laboratories.

This product has a HDMI connector so that you can
watch high definition TV with a HDMI lead when
connected to a HD Ready TV.
HDMI, the HDMI logo and High-Definition Multimedia
Interface are trademarks or registered trademarks of
HDMI Licensing LLC.

The Saorview word and logos are trademarks of RTÉ
and are used under licence.

Information on the software license for this product

Software composition

The software included in this product is comprised of various software components whose individual
copyrights are held by TRIAX UK Ltd or by third parties.

Software developed by TRIAX and open source software

The copyrights for the software components and various relevant documents included with this product
that were developed or written by TRIAX are owned by TRIAX UK LTD and are protected by the Copyright
Act, international treaties, and other relevant laws. This product also makes use of freely distributed
software and software components whose copyrights are held by third parties. These include software
components covered by a GNU General Public License (hereafter GPL), a GNU Lesser General Public
License (hereafter LGPL) or other license agreement.

Obtaining source code

We are unable to answer any questions about the source code for the open source software. The source
code for the software components whose copyrights are held by TRIAX are not distributed.

®

43

Appendix

Troubleshooting

The following conditions in the table below do not always indicate a problem. Please perform the checks
described below before calling for service. If the problem cannot be corrected by the use of this manual,
remove the mains plug from the power socket and contact the Helpline on 00 44 1443 778910 to obtain
service or advice (Normal operator charges apply).

Alternatively you can email us at: [e-mail].

In the unlikely event of this equipment requiring repair during the guarantee period, you will need to
provide proof of purchase to your point of sale. Please keep your purchase invoice or receipt in a safe
place.

WARNING

Under no circumstances should you try and repair this product yourself. This will invalidate the
guarantee. Do not open the unit as there is risk of electric shock.

No power

The receiver cannot
be operated

Remote control unit does
not operate

Picture format incorrect

Power is suddenly
turned off

No picture

No sound

Freezing / Blocking

• Checkifyoupressedontheremotecontrolunit

• IstheACpoweradapterdisconnected?

• Checkifyoupressedonthereceiver

• TurnoffreceiveratACadaptor,leavefortwominutesandswitchbackon

• Arebatteriesinsertedwithpolarity(+,-)aligned?

• Arebatterieswornout?(Replacewithnewbatteries.)

• Areyouusingitunderstrongoruorescentlighting?

• Isauorescentlightilluminatingtheremotecontrolsensor?

• Refertopage25.

• Isautostandbyactivated?(Page24)

• Areconnectionstoexternalequipmentcorrect?(Page9)

• Istheinputsignaltypeselectedcorrectlyafterconnection?(Page9)

• Isthecorrectoutputsourceselected?(Page26)

• Istheantennaconnectedproperly?(Page9)

• Isthevolumetoolow?

• Checkifyoupressedmuteontheremotecontrolunit.

• CheckSCARTleadisinsertedcorrectlyifused.

• Checkreceptioninformationasshownonthecoverofthismanual.

• Refertopage9toperformtheFirstTimeInstallation.

Problem Possible Solution

44

Appendix

End of life disposal

A. Information on Disposal for Users (private households)

1. In the European Union

Attention: If you want to dispose of this equipment, please recycle.

Used electrical and electronic equipment must be treated separately and
in accordance with legislation that requires proper treatment, recovery and
recycling of used electrical and electronic equipment.

Following the implementation by member states, private households within
the EU states may return their used electrical and electronic equipment to
designated collection facilities free of charge*. In some countries your local
retailer may also take back your old product free of charge if you purchase a
similar new one.

* Please contact your local authority for further details.

If your used electrical or electronic equipment has batteries or accumulators,
please dispose of these separately beforehand according to local
requirements.

By disposing of this product correctly you will help ensure that the waste
undergoes the necessary treatment, recovery and recycling and thus prevent
potential negative effects on the environment and human health which could
otherwise arise due to inappropriate waste handling.

The battery supplied with this product contains traces of Lead.

For EU: The crossed-out wheeled bin implies that used batteries should not
be put to the general household waste! There is a separate collection system
for used batteries, to allow proper treatment and recycling in accordance with
legislation. Please contact your local authority for details on the collection and
recycling schemes.

Attention:

Your product is marked
with this symbol. It means
that used electrical and
electronic products should
not be mixed with general
household waste. There
is a separate collection
system for these products.

45

Terms of Guarantee

This product is supplied with a 12 month manufacturers guarantee from date of original purchase.

In the unlikely event of an issue occurring within this period, please contact your point of sale.
Proof of purchase will need to be supplied.

1 This guarantee only applies to defects due to faulty workmanship or materials.
It does not cover faults or damage caused by (but not limited to) accident, misuse, fair wear and
tear, signal related issues, neglect, tampering with the product or repair other than by a facility
appointed by Triax UK Ltd.

2 This product is intended for private domestic use only.
The guarantee will not apply if the product is used in the course of a business, trade or profession.

3 The product must be correctly installed and operated in accordance with the instructions contained
in this operating manual.

4 Triax UK Ltd disclaims any liability for incidental or consequential damages.

5 This guarantee is in addition to, and does not diminish your statutory or legal rights.

46

Declaration of Conformity

Company Name: Triax UK Ltd

Company Address: Abergorki Industrial Estate,

Treorchy, Rhondda-Cynon-Taff
CF42 6DL, UK

Object of the Declaration: Triax TR 112, Part Number 305107.

The object of the declaration described above is in conformity with the requirements
of the following documents:

Low voltage directive 2006/95/EC
EMC Directive 2004/108/EC
WEEE Directive 2002/96/EC
Batteries and Accumulators Directive 2006/66/EC
RoHS Directive 2002/95/EC
REACH Regulation 1907/2006/EC
CE Marking Directive 93/68/EEC
Packaging Directive 94/62/EC

The product identified above complies with the relevant EC Directives by meeting the following
standards:

BS EN55013:2001+A1:2003+A2:2006 Test Limits for STB Receivers Disturbance Characteristics
BS EN55020:2007 Test Limits for STB Receivers Immunity Characteristics
BS EN60065:2002:A1:2006+A11:2008 Audio and Video Equipment Safety Requirements
BS EN 61000-3-2:2006 Test Limits for EMC Harmonic Currents
BS EN61000-3-3:2008 Test Limits for EMC Voltage Changes and fluctuations

The Declaration of Conformity is made in relation to the associated tests carried out and verified by our
suppliers and their authorised test facilities.

Signed for and on behalf of:

TRIAX UK LTD

KEVIN EDWARDS…………………………………………………………………QUALITY MANAGER.
30th November 2010

48

Issue 2
