Guia de Instalação Rápida
TU2-EX12
1.01
Índice
Português 1
1.
Antes de Iniciar
2. 2
Instalação de Hardware
Technical Specifications 3
Troubleshooting 4
1
Version 02.14.2011
Compatibilidade com
Sistemas Operacionais
CPU
Memoria
Windows Vista (32/64-bit)
Windows 7 (32/64-bit)
Mac OS X (10.5)
Windows XP (32/64-bit)/ 2000
Mac OS X (10.6)
800MHz ou superior
1GHz ou superior
867MHz ou superior
300MHz ou superior
Intel Processor
512MB RAM ou superior
1GB RAM ou superior
512MB RAM ou superior
256MB RAM ou superior
256MB RAM ou superior
333MHz ou superior
Mac OS X (10.4)
256MB RAM ou superior
300MHz ou superior
Mac OS X (10.1-10.3)
1GB RAM ou superior
1. Antes de Iniciar
Português
Requisitos Mínimos do Sistema
ŸComputador com uma porta USB 1.1 ou 2.0 disponível
Conteúdo da Embalagem
TU2-EX12 (12 meters/39 feet)
Ÿ
ŸGuia de Instalação Rápida Multilínguas
1
2. Instalação de Hardware
1. Plugue o conector USB tipo A macho do
TU2-EX12 em uma porta USB disponível em
seu computador.
2. O computador detectará e instalará
automaticamente os drivers.
USB Camera
USB Hub
PORTUGUÊS
USB Speaker
USB Printer
3. Plugue um dispositivo USB no conector USB
tipo A fêmea do TU2-EX12.
Sua instalação está completa.
Workstation
USB Drive
2
Technical Specifications
Data Rate
Interface
Weight
Certifications
USB 2.0, 1.1, 1.0 compliant (Type A)
High-Speed: 480Mbps
Full-Speed: 12Mbps
Low-Speed: 1.5Mbps
USB Type A Male to Female
36 meters (118 feet)
430g (15.2 oz.)
Connector
Cable Length
Max Distance
Temperature
12 meters (39 feet)
Humidity
Hardware
Operating: 0° ~ 60° C (32° ~ 140° F)
Storage: -20° ~ 85° C (-4° ~ 185° F)
Max. 90% (non-condensing)
FCC, CE
3
Troubleshooting
1. Meu computador não detecta meu dispositivo USB quando eu o conecto ao TU2-EX12. O
que devo fazer?
1. Confirme que seu computador atende aos requisitos de sistema conforme especificado na
seção 1.
2. Acesse o Gerenciador de dispositivo e confirme que o dispositivo USB no computador
está adequadamente instalado.
1. Para acessar o gerenciador de dispositivo no Windows 7, clique no ícone do Windows
no canto direito inferior, clique “Computer”, clique “System Properties” e então clique
“Device Manager”. Faça duplo clique em “Universal Serial Bus Controllers”.
Certifique-se de que “Generic USB Hub” está listado e que não há nenhum sinal de
interrogação ou de exclamação associado a ele.
2. Para acessar o gerenciador de dispositivo no Windows Vista, clique “Computer” com o
botão direito, clique “Properties” e então clique “Device Manager”. Faça duplo clique
em “Universal Serial Bus Controllers”. Certifique-se de que “Generic USB Hub” está
listado e que não há nenhum sinal de interrogação ou de exclamação associado a ele.
3. Para acessar o gerenciador de dispositivo no Windows XP, clique “My Computer” com o
botão direito, clique “Properties”, clique na aba Hardware e então clique “Device
Manager”. Faça duplo clique em “Universal Serial Bus Controllers”. Certifique-se de
que “Generic USB Hub” está listado e que não há nenhum sinal de interrogação ou de
exclamação associado a ele.
Clique Hardware, e então clique Device Manager.
4.
3. Experimente conectar o dispositivo a uma outra porta USB do computador.
2. Meu dispositivo USB está obtendo taxa de transferência de dados inferior a 480 Mbps
quando conectado através do TU2-EX12
1. Confirme estar o TU2-EX12 conectado a uma porta USB 2.0 do computador.
2. Certifique-se de que seu dispositivo USB suporta USB 2.0.
3. Posso cascatear 2 ou mais TU2-EX12?
É possível cascatear um total de três TU2-EX12.
Se você ainda encontrar problemas ou tiver perguntas referentes TU2-EX12, favor entrar em
contato com o Departamento de Suporte Técnico da TRENDnet.
4
