Trendnet TPL-110AP Frequently Asked Questions (FAQ)
TPE-110AP F.A.Q.
Q: How do I change the username & password on my TPL-110AP?
Step 1. Open your web browser and type the IP address of the TPL-110AP in the address bar.
A:
The default IP address is 10.0.0.3. At the login, enter your username (admin) and
password (admin).
Step 2. Click on “Basic” at the top of the page. You can change the username & password in
the corresponding fields.
Q: What can I do if I forgot my password or want to reset back to factory defaults.
Step 1. Locate the reset button on the side of the TPL-110AP.
A:
Step 2. Press and hold in the reset button for approximately 15 seconds.
This will reset the unit back to its default configuration.
Q: What is the default IP address of my TPL-110AP?
The default IP address for the TPL-110AP is 10.0.0.3.
A:
Q: What is the default username and password for the TPL-110AP?
The default username & password for the TPL-110AP are both (admin).
A:
Q: What is the default HomePlug password for the TPL-110AP?
The default HomePlug password for the TPL-110AP is (HomePlug).
A:
TPE-110AP F.A.Q.
Q: How do I change the IP Address of my TPL-110AP?
A:
Step 1. Open your web browser and type the IP address of the TPL-110AP in the address bar.
The default IP address is 10.0.0.3. At the login, enter your username (admin) and
password (admin).
Step 2. Click on “LAN” at the top of the page.
Step 3. You can change the IP Address of the unit in the corresponding IP Address field.
Q: How do I configure the TPL-110AP?
First configure your Wireless Ethernet Adapter to connect to the “default” SSID.
A:
Note: If you are using a hard-wired computer through another PowerLine device you will use the
Local Area Connection that is bound to your Ethernet Adapter.
Step.1 Click Start then click on the Control Panel. For Windows 2000 click on Start, highlight
settings then click on the Control Panel.
Step 2. Double-Click on the Network Connection icon.
Step 3. Right-Click on the Wireless Network Connection icon then click on Properties. For
Windows 2000 it will be listed as Local Area Connection. Make sure you are selecting
the Local Area Connection that is bound to your Wireless Ethernet Adapter.
TPE-110AP F.A.Q.
Step 4. Highlight the Internet Protocol (TCP/IP) then click on Properties.
Step 5. Select Use the following IP address.
Step 6. Enter in 10.0.0.50 into the IP address field and enter 255.255.255.0 into the Subnet
mask field then click OK.
Step 7. Click OK.
Step 8. Your computer is now ready to access and configure the TPL-110AP.
Step 9. Open your web browser and type the IP address of the TPL-110AP in the address bar.
The default IP address is 10.0.0.3. At the login, enter your username (admin) and
password (admin).
