TPE-TG240g
24-Port Gigabit PoE+ Switch
TPE-TG240g (v1.0R)
• 24 x Gigabit PoE+ ports
• 370 Watts total power budget
• 48 Gbps switching capacity
• Sturdy metal switch
• Rack mount brackets included
• Limited Lifetime Warranty
TRENDnet’s 24-Port Gigabit PoE+ Switch, model TPE-TG240g, offers 24 x Gigabit PoE+ ports, a 48 Gbps switching capacity, and a PoE power budget
of 370 Watts. This rugged metal switch comes with a rack mount kit.
TPE-TG240g
PoE Camera Flexibility
The switch recognizes non-PoE, PoE (15.4 W),
and PoE+ (30 W) cameras (or other PoE
devices) and supplies the required amount of
power automatically.
Networking Solution
Full PoE Power
The large 370 Watt PoE power budget supplies
full PoE power to every port, thereby
maximizing the number of allowable connected
PoE devices.
Gigabit Networking
All Gigabit ports produce a 48 Gbps switching
capacity and support Jumbo Frames up to 10
KB.
TPE-TG240g
PoE+
Supplies up to 30 Watts of PoE power per port with a
370 Watt power budget
Ports
24 x Gigabit PoE+ ports
Switching Capacity
48 Gbps switching capacity
Jumbo Frame
Sends larger packets, or Jumbo Frames (up to 10 KB)
for increased performance
Rack Mountable
Rack mountable metal enclosure with included
mounting kit
LED Indicators
LED indicators convey port status
Specifications
Standards
• IEEE 802.3
• IEEE 802.3u
• IEEE 802.3x
• IEEE 802.3ab
• IEEE 802.3af
• IEEE 802.3at
• IEEE 802.3az
Device Interface
• 24 x Gigabit PoE/PoE+ ports
• LED indicators
Data Transfer Rate
• Ethernet: 10 Mbps (half duplex), 20 Mbps (full duplex)
• Fast Ethernet: 100 Mbps (half duplex), 200 Mbps (full duplex)
• Gigabit: 2000 Mbps (full duplex)
Performance
• Data RAM Buffer: 512 KB
• Switch Fabric: 48 Gbps
• MAC Address Table: 8 K entries
• Forwarding rate: 35.7 Mpps (64-byte packet size)
• Jumbo Frame: 10 KB
Power
• Input: 110-240 V AC, 50/60 Hz, 0.75 A
• Consumption: 36 Watts (Max. without PD)
TPE-TG240g
PoE
• PoE budget: 370 Watts
• Pin 3,6 for power+ and pin 1,2 for power- (mode A)
• Over current protection
• Circuit sorting protection
Operating Temperature
• 0 – 40 °C (32 - 104 °F)
Operating Humidity
• Max. 90% non-condensing
Dimensions
• 440 x 250 x 44 mm (17.3 x 9.8 x 1.7 in.)
Weight
• 3.6 kg (8 lbs.)
Certifications
• CE
• FCC
Warranty
• Limited Lifetime Warranty
Package Contents
• TPE-TG240g
• Quick Installation Guide
• Rack mount kit
• Power cord
TRENDnet offers a limited lifetime warranty for all of its metal-enclosed network switches that have been purchased in the United States/Canada on or after 1/1/2015. Cooling fan and internal power supply carry a one-year
warranty.
20675 Manhattan Place • Torrance • CA 90501 • USA • T: 1-888-326-6061 • F: 1-310-961-5511 • sales@trendnet.com • www.TRENDnet.com
TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet products and is subject to change at any time, without notice. For the most
recent product information please visit http://www.trendnet.com. Copyright © TRENDnet. All Rights Reserved.
Updated: 8/7/2015
