Page 1
TPE-E110
Gigabit PoE+ Extender/Amplifier
TPE-E110 (v2.0R)
• Easy installation
• Extends 100m for a total distance of up to 200m (656 ft.)
• Daisy chain up to 5 units for a total PoE+ network extension of 600m (1,968 ft.)*
• PoE/PoE+ powered
• Wall mountable
• Durable metal housing
TRENDnet’s Gigabit PoE+ Extender/Amplifier, model TPE-E110, takes a single PoE+ connection and extends it an additional 100m (328 ft.) for remote PoE/
PoE+ device installation. The TPE-E110 auto-detects a PoE (15.4W) or PoE+ (30W) connection and extends it for a total distance of up to 200m (656 ft.)
from the power sourcing equipment. Daisy chain up to 5 units for a total PoE+ network extension of 600m (1,968 ft.) *. The extended range and convenient
wall mounting design allows for greater installation flexibility.
Page 2
TPE-E110
PoE Powered
Extends a single PoE+ network connection
up to 100m (328 ft.) for a remote PoE
(15.4W) or PoE+ (30W) device installation.
Networking Solution
Daisy-Chainable
Daisy-chain up to 5 units for a total PoE+
network extension of 600m (1,968 ft.) *.
Wall Mountable
Features a convenient wall mountable
design for greater installation flexibility.
Extension Distance
Extends a PoE/PoE+ network
connection an additional 100m for a total
distance of up to 200m (656 ft.) from the
PoE power source equipment
PoE/PoE+
Auto-sensing technology conveniently
delivers the correct wattage needed to
power your PoE (15.4W) or PoE+ (30W)
device
Gigabit Ports
Features one gigabit PoE+ input port
and one gigabit PoE+ output port
Daisy-Chain
Connect up to 5 units for a PoE+
network extension of up to 600m (1968
ft.)
PoE Powered
No AC adapter required – this PoE
extender is powered via a PoE switch or
injector
LED Indicators
LED indicators convey Link, Activity,
Power, and PoE status
Page 3
Special Features • Extends a PoE/PoE+ network connection an additional 100
meters for a total distance of up to 200m (656 ft.)
• Daisy-chain up to 5 units* without optional power adapter
• Wall mountable
Daisy Chain
Number of Daisy
Chains from PSE
Max. PoE output (approx.) Without
optional power adapter
• 1 (up to 100m) • 30W input: 24.5W
• 15.4W input: 12W
• 2 (up to 200m) • 30W input: 19.6W
• 15.4W input: 8.5W
• 3 (up to 300m) • 30W input: 15.5W
• 15.4W input: 6.5W
• 4 (up to 400m) • 30W input: 11.9W
• 15.4W input: 4W
• 5 (up to 500m) • 30W input: 9.9W
• 15.4W input: N/A
Number of Daisy
Chains from PSE
Max. PoE output (approx.) With
Optional power adapter
• 1 (up to 100m) • 30W input: 24.5W
• 15.4W input: 12W
• 2 (up to 200m) • 30W input: 19.6W
• 15.4W input: 8.5W
• 3 (up to 300m) • 30W input: 15.5W
• 15.4W input: 6.5W
• 4 (up to 400m)
Add power adapter
• 30W input: 24.5W
• 15.4W input: 12W
• 5 (up to 500m) • 30W input: 19.6W
• 15.4W input: 8.5W
• 6 (up to 600m) • 30W input: 15.5W
• 15.4W input: 6.5W
• 7 (up to 700m)
Add power adapter
• 30W input: 24.5W
• 15.4W input: 12W
• 8 (up to 800m) • 30W input: 19.6W
• 15.4W input: 8.5W
• 9 (up to 900m) • 30W input: 15.5W
• 15.4W input: 6.5W
PoE • PoE Mode A: Pins 1,2 for power and pins 3,6 for power
• PD auto classification
• Over current/short circuit protection
Power • Powered via PoE/PoE+ switch or injector
• Max. consumption: 1.6W
Optional Power
Adapter
• Input: 100 – 240V AC 50/60Hz, 1.2A
• Output: 54V DC, 0.7A
• Max. consumption: 32W (with use of power adapter sold
separately)
Operating
Temperature
• 0° – 40° C (32° – 104° F)
Operating
Humidity
• Max. 90% non-condensing
Dimensions • 121 x 75 x 26mm (4.77 x 2.95 x 1 in.)
Weight • 242g (8.5 oz.)
Certifications • CE
• FCC
Warranty • 3 year
PACKAGE CONTENTS
• TPE-E110
• Quick Installation Guide
Standards • IEEE 802.3
• IEEE 802.3u
• IEEE 802.3x
• IEEE 802.3ab
• IEEE 802.3az
• IEEE 802.3af
• IEEE 802.3at
Device Interface • 1 x Gigabit PoE/PoE+ in port
• 1 x Gigabit PoE/PoE+ out port
• 1 x Power port (optional power adapter model name
54VDC0700 sold separately)
• LED indicators
Data Transfer Rate • Ethernet: 10Mbps (half duplex), 20Mbps (full duplex)
• Fast Ethernet: 100Mbps (half duplex), 200Mbps (full duplex)
• Gigabit: 2000Mbps (full duplex)
Performance • RAM buffer: 128KB
• MAC Address Table: 2K
• Jumbo Frame: 9K
Specifications
TPE-E110
* Optional power supply required to daisy chain more than the suggested number of units.
20675 Manhattan Place • Torrance • CA 90501 • USA • T: 1-888-326-6061 • F: 1-310-961-5511 • sales@trendnet.com • www.TRENDnet.com
TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet products and is subject
to change at any time, without notice. For the most recent product information please visit http://www.trendnet.com. Copyright © TRENDnet. All Rights Reserved.
Updated: 8/29/2018
