TPE-3026L
26-Port Gigabit 400 Watt AV PoE+ Switch
TPE-3026L (v1.0R)
• 24 x Gigabit PoE+ ports
• 2 x SFP slots
• 400 Watt PoE+ budget
• 52 Gbps switching capacity
• Rack mount brackets included
• Rear panel ports for easy network integration with your AV rack
• Convenient front-panel 4-digit seven-segment LED display
• Limited Lifetime Warranty*
TRENDnet’s 26 Port Gigabit 400 Watt AV PoE+ Switch, model TPE-3026L, offers 24 x Gigabit PoE+ ports and 2 x SFP slots, with a total Power budget
of 400 Watts. View total power, available power, and power-per-port with a convenient front-panel 4-digit seven-segment LED display. Ports conveniently
located in the back for improved cable management.
TPE-3026L
Hardware Design
Provides 24 x Gigabit PoE+ ports, 2 x SFP slots, a
PoE+ Power budget of 400 Watts, and includes
rackmount brackets.
7-Segment LED Display
View total power, available power, and power-per-port
PoE Camera Flexibility
The switch recognizes non-PoE, PoE (15.4
Watts), and PoE+ (30 Watts) cameras (or other
PoE devices) and supplies the required
amount of power automatically.
PoE Power
A 400 Watt PoE power budget supplies up to
twenty-six Power over Ethernet devices with
PoE power.
Power Budget
Up to 400 Watts PoE+
Rack Mountable
Standard 19” 1U design (brackets included)
Gigabit Networking
All Gigabit ports produce a 52 Gbps switching
capacity and support Jumbo Frames up to 10
KB.
AV Switches: Sample Applications
TPE-3026L
Application 1: Restaurants and Bars
In most business environment’s, TRENDnet’s AV
switches will serve a dual purpose. The switches
allow business owners to simultaneously manage AV
equipment, IP surveillance cameras, and wireless
access points.
Application 2: Homes with Multi-Room AV
TRENDnet AV Series Switches easily expands a
home’s existing wired network for high bandwidth
devices, especially those devices dedicated to
multimedia sharing and home security.
Application 3: NVR and AV Switches Solution
With both sets of ports on the back, TRENDnet AV
Series Switches are ideal for use with TRENDnet
NVRs. The AV switches are equipped to provide all
the power needed to run several TRENDnet
surveillance cameras simultaneously.
Specifications
Standards
• IEEE 802.3
• IEEE 802.3u
• IEEE 802.3x
• IEEE 802.3z
• IEEE 802.3ab
• IEEE 802.3af
• IEEE 802.3at
Device Interface
• 24 x Gigabit Ethernet ports
• 2 x SFP ports
• LED indicators
• 4-Digit Seven-Segment LED Display
Data Transfer Rate
• Ethernet: 10 Mbps (half-duplex), 20 Mbps (full-duplex)
• Fast Ethernet: 100 Mbps (half-duplex), 200 Mbps (full-duplex)
• Gigabit Ethernet: 2000 Mbps (full-duplex)
Performance
• Broadcast storm control
• Auto-learning network configurations
• Data RAM Buffer: 400 KB
• Switch Fabric: 52 Gbps
• MAC Address Table: 8 K entries
• Forwarding rate: 38.7 Mpps (64-byte packet size)
• Jumbo Frame: 9.6 KB
Power
• Input: 110 – 240 V AC, 50/60 Hz
TPE-3026L
• Consumption: 7 Watts (Max. without PD)
PoE
• PoE overall budget: 400 Watts
• PoE budget per port: 30 Watts
• Pin 3,6 for power+ and pin 1,2 for power- (mode A)
• Over current protection
• Short circuit protection
Operating Temperature
• 0 – 40 °C (32 – 104 °F)
Operating Humidity
• Max. 90% non-condensing
Dimensions
• 440 x 280 x 44 mm (17.3 x 11 x 1.7 in.)
Weight
• 3.5 kg (7.7 lbs.)
Certifications
• CE
• FCC
• UL
Warranty
• Limited Lifetime Warranty*
Package Contents
• TPE-3026L
• Quick Installation Guide
• Rack mount kit
• Power cord
TRENDnet offers a limited lifetime warranty for all of its metal-enclosed network switches that have been purchased in the United States/Canada on or after 1/1/2015.
Cooling fan and internal power supply carry a one-year warranty.
20675 Manhattan Place • Torrance • CA 90501 • USA • T: 1-888-326-6061 • F: 1-310-961-5511 • sales@trendnet.com • www.TRENDnet.com
TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet products and is subject to change at any time, without notice. For the most
recent product information please visit http://www.trendnet.com. Copyright © TRENDnet. All Rights Reserved.
Updated: 5/19/2016
