TRENDnet User’s Guide

Cover Page

TRENDnet User’s Guide

Table of Contents

Contents

Product Overview ........................................................................... 1

Package Contents .......................................................................................................... 1

Features ......................................................................................................................... 1

Product Hardware Features........................................................................................... 2

System Requirements .................................................................................................... 2

Application Diagram ...................................................................................................... 3

Installing your Wireless Adapter ...................................................... 4

Connect to your wireless network using WPS .................................. 9

Technical Specifications................................................................. 11

Troubleshooting ............................................................................ 13

Appendix ...................................................................................... 14

TRENDnet User’s Guide

TEW-807ECH

Product Overview

Features

TRENDnet’s AC1200 High Power Wireless Dual Band PCIe Adapter, model TEW-807ECH, upgrades a standard or low profile Windows® tower computer to Wireless AC1200. Quickly connect to a high performance Wireless AC network at 867 Mbps or to a Wireless N network at 300 Mbps. A high power 500 mW radio with detachable 5 dBi antennas increase wireless coverage. A convenient 1 m (3.3 ft.) extension cable and a magnetic mounting base provide installation flexibility.

Easy Setup

Get up and running in minutes with the intuitive guided setup

AC1200 Dual Band

Connect to an extreme performance 867 Mbps Wireless AC or 300 Mbps Wireless N network*

Wireless Coverage

Extended wireless coverage with high power 500 mW radio and detachable 5 dBi antennas

PCIe Slot

PCI Express slot (1x)

Heat Sink

TEW-807ECH

Package Contents

In addition to your wireless adapter, the package includes:

 CD-ROM (Drivers)  Multi-Language Quick Installation Guide  2 x High Gain Detachable Dual Band Antennas  1 x Magnetic Antenna Base with 1 m (3.3 ft) extension cable  Standard & Low Profile Brackets

If any package contents are missing or damaged, please contact the retail store, online retailer, or reseller/distributor from which the product was purchased.

Heat sink minimizes heat loading and optimizes processing performance

Tower Brackets

Includes standard and low profile tower brackets

Extension Cable

Convenient 1 m (3.3 ft.) extension cable provides installation flexibility

Magnetic Base

Adjustable magnetic mounting base attaches to the side of a tower computer or other metal surface

LED Indicator

LED indicator conveys device status

Operating Systems

Compatible with Windows operating systems

* Maximum wireless signal rates are referenced from IEEE 802.11 theoretical specifications. Actual data throughput and coverage will vary depending on interference, network traffic, building materials and other conditions. For maximum performance of up to 867Mbps, connect to an 867 Mbps 802.11ac wireless router or access point.

TRENDnet User’s Guide

TEW-807ECH

Activity LED

Indicator

PCIe 1x Interface

Detachable High

Gain Antenna

Low Profile

Bracket

Magnetic

Mounting Base

Extension Cable

Connectors

Detachable High

Gain Antenna

Product Hardware Features

 PCIe 1x Interface – The PCIe interface connects your adapter to PCIe slots on your

computer.

 Activity LED Indicator –The LED will blink rapidly to indicate WPS has been

activated. The LED will blink every 5 sec. when disconnected. When connected, the LED will blink rapidly during wireless data transmission.

 Detachable High Gain Antennas – The high gain antennas can be connected to the

external mounting base for flexible and optimized antenna placement or connected directly to the antenna connectors on the adapter.

 Mounting Base – It is recommended to attach the antennas to the external

mounting base to achieve the best possible placement and wireless coverage. The mounting base is also magnetic and can attach to metallic surfaces. When using the mounting base, the extension cable connectors will be connected to the antenna connectors located on the adapter.

 Low Profile Bracket – The low profile bracket can be used to install the adapter on

low profile computer towers.

System Requirements

 Windows® 8.1, 8, 7, Vista, or XP  Available PCIe slot on your computer.  CD-ROM Drive (Utility and Driver Installation with included CD)

TRENDnet User’s Guide

TEW-807ECH

Application Diagram

The AC1200 High Power Wireless Dual Band PCIe Adapter can provide wireless AC or wireless N connectivity through the use of an available PCIe slot on your computer to a wireless AC/N network (router/access point). The external mounting base allows for flexible and optimal antenna placement to achieve the best possible wireless coverage and connectivity

TRENDnet User’s Guide

TEW-807ECH

Installing your Wireless Adapter

This section describes how to install the software driver for the wireless adapter.

3. At the installation window, click Next.

1. Insert the included CD-ROM into your computer’s CD-ROM drive.

Note: If you do not have the included CD-ROM, you can download the utility and drivers from http://www.trendnet.com/downloads/.

2. At the CD Autorun Prompt window, click Run Autorun.exe. Note: If the Autorun prompt does not appear automatically, open the CD contents and

double-click Autorun.exe.

At the CD-ROM main menu, click Install Drivers.

TRENDnet User’s Guide

TEW-807ECH

4. You will be prompted to accept the end user license agreement. Select I accept the terms of the license agreement and click Next.

5. Wait for the utility and drivers installation to complete. This may take a few minutes.

Note: If you do not receive a security prompt, continue to the next step. If prompted, click Install this driver software anyway.

TRENDnet User’s Guide

TEW-807ECH

6. After the process is completed, click Finish.

8. Please shut down your computer.

9. Locate an available PCIe slot inside of your computer. Insert the adapter into the available PCIe slot.

TRENDnet User’s Guide

TEW-807ECH

10. Attach the high gain detachable antennas to the antenna connectors on the mounting base and attach the extension cable connectors from the mounting base to the antenna connectors on the adapter. It is recommended to place the mounting base at the highest point possible (ex. table top or on top of the computer tower) and position the antennas at opposite angles as shown for optimal coverage. The mounting base is magnetic and attaches to the metallic surfaces for flexible placement. The antennas may also be directly connected to the antenna connectors on the adapter.

11. Power on your computer.

12. After the driver is successfully installed, click the icon in the system tray to scan for available wireless networks.

TRENDnet User’s Guide

TEW-807ECH

13. Click the network you would like to connect.

14. Enter the WiFi Key (password).

15. The status will display “Connected” to indicate a successful connection.

Note: If the connected message does not display, double check your WiFi key (password) and re-enter it.

TRENDnet User’s Guide

TEW-807ECH

Connect to your wireless network using WPS

WPS (Wi-Fi Protected Setup) is a feature that makes it easy to connect devices to your wireless network. If your wireless router/access point supports WPS, you can use this feature to easily connect wireless devices to your network.

Note: You can typically find out if you if your wireless router/access point supports WPS just by looking at the physical device. There should be a WPS push button located on the exterior casing of the device, if not, your device may not support WPS or you may need to reference your device documentation as to how WPS can be initiated on the device. If your device does not have an identifiable WPS push button on the exterior location, we would recommend using the standard connection method on the previous page.

1. Click the WiFi icon in the system tray to scan for available wireless networks.

3. Leave this window open.

2. Click the network you would like to connect.

TRENDnet User’s Guide

TEW-807ECH

4. On your wireless router/access point, push the WPS button.

Note: Typically, the WPS button hold time is 3-5 sec., then release. For TRENDnet routers/access points, the WPS hardware push button hold time is 3 seconds. If you are using another brand device, you may need to refer to your device documentation for WPS operation.

15. The status will display “Connected” to indicate a successful connection.

Note: If the connected message does not display, double check your WiFi key (password) and re-enter it.

Note: If the WPS process fails, you will receive not receive a message “Connected”. You may need to attempt the WPS process again. Please refer to your wireless router/access point documentation regarding the operation of WPS.

TRENDnet User’s Guide

TEW-807ECH

Technical Specifications

Standards

 PCI Express 1.0a  IEEE 802.11a  IEEE 802.11b  IEEE 802.11g  IEEE 802.11n (up to 300 Mbps)  IEEE 802.11ac (up to 867 Mbps)

Hardware Interface

 PCI Express x1 (Version 1.0a)  LED indicator  2 x RP-SMA antenna connectors  Magnetic Antenna Base with 1 m (3.3 ft) extension cable  2 High Gain Detachable Dual Band Antennas  Standard and low profile tower brackets

Encryption

 Wireless encryption: WEP, WPA/WPA2-PSK, WPA/WPA2-RADIUS

Compatibility

 Windows® 8.1, 8, 7, Vista, XP

Special Features

 2 high gain dual band detachable antennas and integrated high powered

amplifiers for long range connectivity

 Magnetic Antenna Base for easy mounting and antenna positioning for optimal

signal reception

 High-speed 802.11ac connectivity

Quality of Service

 WMM  WMM-SA

Frequency

 2.4GHz: (FCC) 2.412 – 2.462GHz, (ETSI) 2.412 – 2.472GHz  5GHz: (FCC) 5.745 - 5.825GHz, (ETSI) 5.150 – 5.250GHz/5.260 – 5.320GHz/5.500

– 5.700GHz

Modulation

 802.11b: CCK, DQPSK, DBPSK  802.11a/g: OFDM with BPSK, QPSK and 16/64-QAM  802.11n: BPSK, QPSK, 16-QAM, 64-QAM with OFDM  802.11ac: OFDM with BPSK, QPSK and 16/64/256-QAM

Antenna Gain

 2.4 GHz/5 GHz: 2 x 5 dBi (max.) dual band external/detachable

Wireless Output Power

 802.11a: 28 dBm (max.) @ 54 Mbps  802.11b: 27 dBm (max.) @ 11 Mbps  802.11g: 27 dBm (max.) @ 54 Mbps  802.11n (2.4GHz): 27 dBm (max.) @ 300 Mbps  802.11n (5GHz): 27 dBm (max.) @ 300 Mbps  802.11ac: 27 dBm (max.) @ 867 Mbps

Receiving Sensitivity

 802.11a: -90 dBm (typical) @ 54 Mbps  802.11b: -91 dBm (typical) @ 11 Mbps  802.11g: -87 dBm (typical) @ 54 Mbps  802.11n (2.4GHz): -85 dBm (typical) @ 300 Mbps  802.11n (5GHz): -90 dBm (typical) @ 300 Mbps  802.11ac: -58 dBm (typical) @ 867 Mbps

TRENDnet User’s Guide

TEW-807ECH

Wireless Channels

 2.4GHz: (FCC) 1-11, (ETSI) 1-13  5GHz: (FCC) 149, 153, 157, 161, 165, (ETSI) 36, 40, 44, 48, 52, 56, 60, 64, 100,

104, 108, 112, 116, 120, 124, 128, 132, 136, 140

Power

 Consumption: Max. 6 W

Operating Temperature

 00 - 55 C (32 – 141 F)

Operating Humidity

 Max. 90% non-condensing

Certifications

 CE  FCC

Dimensions

 84 x 64 x 17 mm (3.3 x 2.5 x 0.7 in.)

Weight

 80 g (2.8 oz.)  Antenna Base: 114 g (4 oz.)

*Disclaimers*

TRENDnet User’s Guide

TEW-807ECH

Troubleshooting

Q: I inserted the Utility & Driver CD-ROM into my computer's CD-ROM Drive and the

installation menu does not appear automatically. What should I do? Answer:

1. For Windows® 8.1/8/7, if the installation menu does not appear automatically,

click on the Windows Icon on the bottom left hand corner of the screen,, click

the “Search programs and files” box, and type D:\Autorun.exe, where “D” in “D:\Autorun.exe” is the letter assigned to your CD-ROM Drive, and then press the

ENTER key on your keyboard

2. For Windows® Vista, if the installation menu does not appear automatically, click

Start, click the Start Search box, and type D:\Autorun.exe where "D" in "D:\autorun.exe" is the letter assigned to your CD-ROM Drive, and then press the ENTER key on your keyboard.

3. For Windows® XP, if the installation menu does not appear automatically, click

Start, click Run, and type D:\Autorun where "D" in "D:\Autorun.exe" is the letter assigned to your CD-ROM

Drive, and then press the ENTER key on your keyboard.

Q: I completed all the steps in the quick installation guide, but my Wireless USB

Adapter is not connecting to my access point. What should I do? Answer:

1. Verify that the SSID (Network Name) matches your wireless router or access

point's SSID

2. Please check with your network administrator for security key in order to access a

secured wireless access point or router. Please refer to the User's Guide for more information regarding wireless network security.

3. Check your TCP/IP properties to ensure that Obtain an IP address automatically is

selected.

4. Double-click the Wireless Configuration Utility icon, click Available Networks and

then click Refresh to check and see if there are any available wireless networks listed.

Q: Windows is unable to recognize my hardware. What should I do?

Answer:

1. Make sure your computer meets the minimum requirements as specified in

Section 1 of this quick installation guide.

2. You must complete the installation of the Wireless Configuration Utility (as

described in Section 2) before connecting the Wireless USB Adapter to your computer.

3. Connect the Wireless USB Adapter to a different USB port on your computer.

Q: I cannot open the Wireless Configuration Utility. What should I do?

Answer:

Access your device manager to make sure the adapter is installed properly.

1. To access the device manager on Windows® 8.1/8/7, click on the Windows icon

on the bottom left-hand corner, click Computer, click System Properties and then click Device Manager.

2. To access the device manager on Windows® Vista, right-click Computer, click

Properties and then click Device Manager.

3. To access the device manager on Windows® XP, right-click My Computer, click

Properties, click the Hardware tab, and then click Device Manager.

If you see a networking device with a yellow question mark or exclamation point:

1. Uninstall the device from device manager

2. Remove the adapter from the computer

3. Click the Windows / Start icon, click All Programs, click TRENDnet Wireless Utility

and then click Uninstall.

TRENDnet User’s Guide

TEW-807ECH

Appendix

How to choose the type of security for your wireless network

Setting up wireless security is very important. Leaving your wireless network open and

unsecure could expose your entire network and personal files to outsiders. TRENDnet

recommends reading through this entire section and setting up wireless security on your

new router.

There are a few different wireless security types supported in wireless networking each

having its own characteristics which may be more suitable for your wireless network

taking into consideration compatibility, performance, as well as the security strength

along with using older wireless networking hardware (also called legacy hardware).

It is strongly recommended to enable wireless security to prevent unwanted users from

accessing your network and network resources (personal documents, media, etc.).

In general, it is recommended that you choose the security type with the highest

strength and performance supported by the wireless computers and devices in your

network. Please review the security types to determine which one you should use for

your network.

 WPA: This encryption is significantly more robust than the WEP technology.

Much of the older 802.11a or 802.11g hardware has been upgraded (with

firmware/driver upgrades) to support this encryption standard. Total wireless

speeds under this encryption type however are limited to 54Mbps.

 WPA-Auto: This setting provides the router with the ability to detect wireless

devices using either WPA or WPA2 encryption. Your wireless network will

automatically change the encryption setting based on the first wireless device

connected. For example, if the first wireless client that connects to your

wireless network uses WPA encryption your wireless network will use WPA

encryption. Only when all wireless clients disconnect to the network and a

wireless client with WPA2 encryption connects your wireless network will then

change to WPA2 encryption. NOTE: WPA2 encryption supports 802.11n speeds

and WPA encryption will limit your connection speeds to 54Mbps

 WPA2: This is the most secure wireless encryption available today, similar to

WPA encryption but more robust. This encryption standard also supports the

highest connection speeds. TRENDnet recommends setting your router to this

encryption standard. If you find that one of your wireless network devices does

Wireless Encryption Types

 WEP: Legacy encryption method supported by older 802.11a/b/g hardware.

This is the oldest and least secure type of wireless encryption. It is generally not

recommended to use this encryption standard, however if you have old 802.11

b, 802.11g or 802.11a wireless adapters or computers with old embedded

wireless cards(wireless clients), you may have to set your router to WEP to

allow the old adapters to connect to the router. Note: This encryption standard

will limit connection speeds to 54Mbps.

Note: Check the specifications of your wireless network adapters and wireless appliances to verify the highest level of encryption supported.

not support WPA2 encryption, then set your router to either WPA or WPA-Auto

encryption.

TRENDnet User’s Guide

TEW-807ECH

Security Standard

WEP

WPA

WPA2

Compatible Wireless Standards

IEEE 802.11a/b/g (802.11n devices will operate at

802.11g to connect using this standard)

IEEE 802.11a/b/g (802.11n/ac devices will operate at 802.11g to connect using this standard)

IEEE 802.11a/b/g/n/ac

Highest Performance Under This Setting

Up to 54Mbps

Up to 867Mbps 11ac** Up to 300Mbps 11n*

Encryption Strength

Low

Medium

High

Additional Options

Open System or Shared Key, HEX or ASCII, Different key sizes

TKIP or AES, Preshared Key or RADIUS

Recommended Configuration

Open System ASCII 13 characters

TKIP Preshared Key 8-63 characters

AES Preshared Key 8-63 characters

*Dependent on the maximum 802.11n data rate supported by the device (300Mbps)

WEP Key Format

HEX

ASCII

Character set

0-9 & A-F, a-f only

Alphanumeric (a,b,C,?,*, /,1,2, etc.)

64-bit key length

10 characters

5 characters

128-bit key length

26 characters

13 haracters

Open or Shared \ WEP – Enter the WEP key for your wireless network. Wireless network has WEP security enabled, open or shared. Please note that the Key Index 1-4 must also match the same index configured on the wireless router/access point.

WPA/WPA2-PSK/TKIP or AES – Wireless network has WPA/WPA2-PSK security enabled, TKIP or AES. Note: 8-63 alphanumeric characters (a,b,C,?,*, /,1,2, etc.)

Below is brief comparison chart of the wireless security types and the recommended configuration depending on which type you choose for your wireless network.

**Dependent on the maximum 802.11ac data rate supported by the device (867Mbps)

How to find your IP address?

Note: Please note that although the following procedures provided to follow for your operating system on configuring your network settings can be used as general guidelines, however, it is strongly recommended that you consult your computer or operating system manufacturer directly for assistance on the proper procedure for configuring network settings.

Command Prompt Method

Windows® XP/Vista/7/8/8.1

1. On your keyboard, press Windows Logo+R keys simultaneously to bring up the Run dialog box.

2. In the dialog box, type cmd to bring up the command prompt.

3. In the command prompt, type ipconfig /all to display your IP address settings.

Note: If you are experiencing difficulties, please contact your computer or operating system manufacturer for assistance.

How to configure your network settings to obtain an IP address automatically or use DHCP?

Windows® 8/7

a. Go into the Control Panel, click Network and Sharing Center. b. Click Change Adapter Settings, right-click the Local Area Connection icon. c. Then click Properties and click Internet Protocol Version 4 (TCP/IPv4). d. Then click Obtain an IP address automatically and click OK.

Windows® Vista

a. Go into the Control Panel, click Network and Internet. b. Click Manage Network Connections, right-click the Local Area Connection icon and click Properties. c. Click Internet Protocol Version (TCP/IPv4) and then click Properties.

TRENDnet User’s Guide

TEW-807ECH

d. Then click Obtain an IP address automatically and click OK.

Windows® XP

a. Go into the Control Panel, double-click the Network Connections icon b. Right-click the Local Area Connection icon and the click Properties. c. Click Internet Protocol (TCP/IP) and click Properties.

d. Then click Obtain an IP address automatically and click OK.

Note: If you are experiencing difficulties, please contact your computer or operating system manufacturer for assistance.

How to connect to a wireless network using the built-in Windows utility?

Windows® 8.1/8/7

1. Open Connect to a Network by clicking the network icon ( or ) in the notification area.

2. In the list of available wireless networks, click the wireless network you would like to connect to, then click Connect.

4. You may be prompted to enter a security key in order to connect to the network.

5. Enter in the security key corresponding to the wireless network, and click OK.

Windows® Vista

Windows XP

1. Right-click the network icon in the notification area, then click View Available Wireless Networks.

2. In Connect to a Network, under Available Networks, click the wireless network you would like to connect to.

3. You may be prompted to enter a security key in order to connect to the network.

4. Enter in the security key corresponding to the wireless network, and click Connect.

1. Open Connect to a Network by clicking the Start Button. and then click Connect To.

2. In the Show list, click Wireless.

3. In the list of available wireless networks, click the wireless network you would like to connect to, then click Connect.

4. You may be prompted to enter a security key in order to connect to the network.

5. Enter in the security key corresponding to the wireless network, and click OK.

TRENDnet User’s Guide

TEW-807ECH

Federal Communication Commission Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures:

 Reorient or relocate the receiving antenna.  Increase the separation between the equipment and receiver.  Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

 Consult the dealer or an experienced radio/TV technician for help.

FCC Caution: To assure continued compliance, any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. (Example - use only shielded interface cables when connecting to computer or peripheral devices).

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation

FCC Radiation Exposure Statement

This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body.

This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter.

RoHS

Europe – EU Declaration of Conformity

TRENDnet hereby declare that the product is in compliance with the essential requirements and other relevant provisions under our sole responsibility.

Safety

EN60950-1 : 2006 + A11 : 2009 + A1: 2010 + A12: 2011

EMC

EN 301 489-1 V1.9.2: 09-2011 EN 301 489-17 V2.2.1: 09-2012 EN 55022 2010 + AC: 2011 (Class B)

Radio Spectrum & Health

EN 300 328 V1.8.1 : 06-2012 EN 62311 2008

This product is herewith confirmed to comply with the Directives.

Directives

Low Voltage Directive 2006/95/EC and 2014/35/EU EMC Directive 2004/108/EC R&TTE Directive 1999/5/EC EMF Directive 1999/519/EC RoHS Directive 2011/65/EU REACH Regulation (EC) No. 1907/2006

This product is RoHS compliant.

TRENDnet User’s Guide

TEW-807ECH

Česky [Czech]

TRENDnet tímto prohlašuje, že tento TEW-807ECH je ve shodě se

základními požadavky a dalšími příslušnými ustanoveními směrnice

2006/95/ES, 2014/35/EU, 2004/108/ES, 1999/5/ES, 2009/125/ES, 2011/65/EU, a REACH (ES) 1907/2006.

Dansk [Danish]

Undertegnede TRENDnet erklærer herved, at følgende udstyr TEW807ECH overholder de væsentlige krav og øvrige relevante krav i direktiv 2006/95/EF, 2014/35/EU, 2004/108/EF, 1999/5/EF, 2009/125/EF, 2011/65/EU, og REACH (EF) 1907/2006.

Deutsch

[German]

Hiermit erklärt TRENDnet, dass sich das Gerät TEW-807ECH in Übereinstimmung mit den grundlegenden Anforderungen und den übrigen einschlägigen Bestimmungen der Richtlinie 2006/95/EG, 2014/35/EU, 2004/108/EG, 1999/5/EG, 2009/125/EG, 2011/65/EU, und REACH (EG) 1907/2006 befindet.

Eesti [Estonian]

Käesolevaga kinnitab TRENDnet seadme TEW-807ECH vastavust direktiivi 2006/95/EÜ, 2014/35/EU, 2004/108/EÜ, 1999/5/EÜ, 2009/125/EÜ 1999/5/EÜ, 2011/65/EU, ja REACH (EÜ) 1907/2006 põhinõuetele ja nimetatud direktiivist tulenevatele teistele asjakohastele sätetele.

English

Hereby, TRENDnet, declares that this TEW-807ECH is in compliance with the essential requirements and other relevant provisions of Directive 2006/95/EC, 2014/35/EU, 2004/108/EC, 1999/5/EC, 2009/125/EC, 2011/65/EU, and REACH (EC) 1907/2006.

Español

[Spanish]

Por medio de la presente TRENDnet declara que el TEW-807ECH cumple con los requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 2006/95/CE, 2014/35/EU, 2004/108/CE, 1999/5/CE, 2009/125/CE, , 2011/65/EU, y REACH (CE) 1907/2006.

Ελληνική

[Greek]

ΜΕ ΤΗΝ ΠΑΡΟΥΣΑTRENDnet ΔΗΛΩΝΕΙ ΟΤΙTEW807ECHΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ 2006/95/EK, 2014/35/EU, 2004/108/EK, 1999/5/EK, 2009/125/EK, 2011/65/EU, REACH (EK) 1907/2006 και.

Français

[French]

Par la présente TRENDnet déclare que l'appareil TEW-807ECH est conforme aux exigences essentielles et aux autres dispositions pertinentes de la directive 2006/95/CE, 2014/35/EU, 2004/108/CE, 1999/5/CE, 2009/125/CE, 2011/65/EU, REACH (CE) 1907/2006 et.

Italiano[Italian]

Con la presente TRENDnet dichiara che questo TEW-807ECH è

conforme ai requisiti essenziali ed alle altre disposizioni pertinenti stabilite dalla direttiva 2006/95/CE, 2014/35/EU, 2004/108/CE, 1999/5/CE, 2009/125/CE, 2011/65/EU, e REACH (CE) 1907/2006..

Latviski [Latvian]

AršoTRENDnetdeklarē, ka TEW-807ECH atbilst Direktīvas 2006/95/EK, 2014/35/EU, 2004/108/EK, 1999/5/EK, 2009/125/EK, 2011/65/EU, un REACH (EK) 1907/2006 būtiskajāmprasībām un

citiemar to saistītajiemnoteikumiem.

Lietuvių

[Lithuanian]

Šiuo TRENDnet deklaruoja, kad šis TEW-807ECH atitinka esminius reikalavimus ir kitas 2006/95/EB, 2014/35/EU, 2004/108/EB, 1999/5/EB, 2009/125/EB, 2011/65/EU, ir REACH (EB) 1907/2006 Direktyvos nuostatas.

Nederlands

[Dutch]

Hierbij verklaart TRENDnet dat het toestel TEW-807ECH in overeenstemming is met de essentiële eisen en de andere relevante bepalingen van richtlijn 2006/95/EG, 2014/35/EU, 2004/108/EG, 1999/5/EG, 2009/125/EG, 2011/65/EU, en REACH (EG) 1907/2006.

Malti [Maltese]

Hawnhekk, TRENDnet, jiddikjara li dan TEW-807ECH jikkonforma malħtiġijiet essenzjali u ma provvedimenti oħrajn relevanti li hemm fidDirrettiva 2006/95/KE, 2014/35/EU, 2004/108/KE, 1999/5/KE, 2009/125/KE, 2011/65/EU, u REACH (KE) 1907/2006.

Magyar

[Hungarian]

Alulírott, TRENDnet nyilatkozom, hogy a TEW-807ECHmegfelel a vonatkozó alapvetõ követelményeknek és az 2006/95/EK, 2014/35/EU, 2004/108/EK, 1999/5/EK, 2009/125/EK, 2011/65/EU, irányelv, a REACH (EK) 1907/2006 irányelv egyéb elõírásainak.

Polski [Polish]

Niniejszym TRENDnet oświadcza, że TEW-807ECH jest zgodny z

zasadniczymi wymogami oraz pozostałymi stosownymi

postanowieniami Dyrektywy 2006/95/WE, 2014/35/EU, 2004/108/WE, 1999/5/WE, 2009/125/WE, 2011/65/EU, i REACH (WE) 1907/2006.

Português

[Portuguese]

TRENDnet declara que este TEW-807ECH está conforme com os requisitos essenciais e outras disposições da Directiva 2006/95/CE, 2014/35/EU, 2004/108/CE, 1999/5/CE, 2009/125/CE, 2011/65/EU, e REACH (CE) 1907/2006.

Slovensko

[Slovenian]

TRENDnet izjavlja, da je ta TEW-807ECH v skladu z bistvenimi zahtevami in ostalimi relevantnimi določili direktive 2006/95/ES, 2014/35/EU, 2004/108/ES, 1999/5/ES, 2009/125/ES, 2011/65/EU, in REACH (ES) 1907/2006.

TRENDnet User’s Guide

TEW-807ECH

Slovensky

[Slovak]

TRENDnettýmtovyhlasuje, že TEW-807ECHspĺňazákladnépožiadavky a všetkypríslušnéustanoveniaSmernice 2006/95/ES, 2004/108/ES,

2014/35/EU, 1999/5/ES, 2006/95/ES, 2004/108/ES, 1999/5/ES, 2009/125/ES, 2009/125/ES, 2011/65/EU, a REACH (ES) 1907/2006.

Suomi [Finnish]

TRENDnet vakuuttaa täten että TEW-807ECH tyyppinen laite on direktiivin 2006/95/EY, 2014/35/EU, 2004/108/EY, 1999/5/EY, 2009/125/EY,1999/5/EY, 2011/65/EU, ja REACH (EY) 1907/2006 oleellisten vaatimusten ja sitä koskevien direktiivin muiden ehtojen mukainen.

Svenska

[Swedish]

Härmed intygar TRENDnet att denna TEW-807ECH står I överensstämmelse med de väsentliga egenskapskrav och övriga relevanta bEYtämmelser som framgår av direktiv 2006/95/EG, 2014/35/EU, 2004/108/EG, 1999/5/EG, 2009/125/EG, 2011/65/EU, och REACH (EG) 1907/2006.

TRENDnet User’s Guide

TEW-807ECH

Industry Canada Statement

This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.

Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.

Radiation Exposure Statement: This equipment complies with IC radiation exposure limits set forth for an uncontrolled

environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.

Déclaration d'exposition aux radiations: Cet équipement est conforme aux limites d'exposition aux rayonnements IC établies pour un environnement non contrôlé. Cet équipement doit être installé et utilisé avec un minimum de 20 cm de distance entre la source de rayonnement et votre corps.

Caution:

(i) the device for operation in the band 5150-5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems;

(ii) the maximum antenna gain permitted for devices in the bands 5250-5350 MHz and 54705725 MHz shall comply with the E.I.R.P. limit; and

(iii) the maximum antenna gain permitted for devices in the band 5725-5825 MHz shall comply with the E.I.R.P. limits specified for point-to-point and non point-to-point operation as appropriate.

(iv) Users should also be advised that high-power radars are allocated as primary users (i.e. priority users) of the bands 5250-5350 MHz and 5650-5850 MHz and that these radars could cause interference and/or damage to LE-LAN devices.

Avertissement:

(i) les dispositifs fonctionnant dans la bande 5150-5250 MHz sont réservés uniquement pour

une utilisation à l’intérieur afin de réduire les risques de brouillage préjudiciable aux

systèmes de satellites mobiles utilisant les mêmes canaux; (ii) le gain maximal d’antenne permis pour les dispositifs utilisant les bandes 5 250-5 350

MHz et 5 470-5 725 MHz doit se conformer à la limite de P.I.R.E.;

(iii) le gain maximal d’antenne permis (pour les dispositifs utilisant la bande 5 725-5 825 MHz) doit se conformer à la limite de P.I.R.E. spécifiée pour l’exploitation point à point et non point à point, selon le cas.

(iv) De plus, les utilisateurs devraient aussi être avisés que les utilisateurs de radars de haute puissance sont désignés utilisateurs principaux (c.-à-d., qu’ils ont la priorité) pour les bandes 5 250-5 350 MHz et 5 650-5 850 MHz et que ces radars pourraient causer du brouillage et/ou des dommages aux dispositifs LAN-EL.

This device has been designed to operate with a dipole antenna have a maximum gain of 5 dBi. Antenna having a higher gain is strictly prohibited per regulations of Industry Canada. The required antenna impedance is 50 ohms.

Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (E.I.R.P.) is not more than that necessary for successful communication.

This radio transmitter (IC: 6337-TEW807ECH) has been approved by Industry Canada to operate with the antenna types listed below with the maximum permissible gain and required antenna impedance for each antenna type indicated. Antenna types not included in this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited for use with this device.

Ce dispositif a été conçu pour fonctionner avec une antenne ayant un gain maximal de dipole antenne avec 5 dBi. Une antenne à gain plus élevé est strictement interdite par les règlements d'Industrie Canada. L'impédance d'antenne requise est de 50 ohms.

Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peutfonctionner avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pourl'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage radioélectriqueà l'intention des autres utilisateurs, il faut choisir le type d'antenne et son gain de sorte que lapuissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité

Le présent émetteur radio (IC: 6337-TEW807ECH) a été approuvé par Industrie Canada pour fonctionner avec les types d'antenne énumérés ci-dessous et ayant un gain admissible maximal et l'impédance requise pour chaque type d'antenne. Les types d'antenne non inclus dans cette liste, ou dont le gain est supérieur au gain maximal indiqué, sont strictement interdits pour l'exploitation de l'émetteur.

TRENDnet User’s Guide

Limited Warranty

TRENDnet warrants its products against defects in material and workmanship, under normal use and service, for the following lengths of time from the date of purchase.

TEW-807ECH – 3 Years Warranty

AC/DC Power Adapter, Cooling Fan, and Power Supply carry 1 year warranty.

If a product does not operate as warranted during the applicable warranty period, TRENDnet shall reserve the right, at its expense, to repair or replace the defective product or part and deliver an equivalent product or part to the customer. The repair/replacement unit’s warranty continues from the original date of purchase. All products that are replaced become the property of TRENDnet. Replacement products may be new or reconditioned. TRENDnet does not issue refunds or credit. Please contact the point-of-purchase for their return policies.

TRENDnet shall not be responsible for any software, firmware, information, or memory data of customer contained in, stored on, or integrated with any products returned to TRENDnet pursuant to any warranty.

There are no user serviceable parts inside the product. Do not remove or attempt to service the product by any unauthorized service center. This warranty is voided if (i) the product has been modified or repaired by any unauthorized service center, (ii) the product was subject to accident, abuse, or improper use (iii) the product was subject to conditions more severe than those specified in the manual.

Warranty service may be obtained by contacting TRENDnet within the applicable warranty period and providing a copy of the dated proof of the purchase. Upon proper submission of required documentation a Return Material Authorization (RMA) number will be issued. An RMA number is required in order to initiate warranty service support for all TRENDnet products. Products that are sent to TRENDnet for RMA service must have the RMA number marked on the outside of return packages and sent to TRENDnet prepaid, insured and packaged appropriately for safe shipment. Customers shipping from outside of the USA and Canada are responsible for return shipping fees. Customers shipping from outside of the USA are responsible for custom charges, including but not limited to, duty, tax, and other fees.

WARRANTIES EXCLUSIVE: IF THE TRENDNET PRODUCT DOES NOT OPERATE AS WARRANTED ABOVE, THE CUSTOMER’S SOLE REMEDY SHALL BE, AT TRENDNET’S OPTION, REPAIR OR REPLACE. THE FOREGOING WARRANTIES AND REMEDIES ARE EXCLUSIVE AND ARE IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED, EITHER IN FACT OR BY OPERATION OF LAW, STATUTORY OR OTHERWISE, INCLUDING

WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. TRENDNET NEITHER ASSUMES NOR AUTHORIZES ANY OTHER PERSON TO ASSUME FOR IT ANY OTHER LIABILITY IN CONNECTION WITH THE SALE, INSTALLATION MAINTENANCE OR USE OF TRENDNET’S PRODUCTS.

TRENDNET SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS TESTING AND EXAMINATION DISCLOSE THAT THE ALLEGED DEFECT IN THE PRODUCT DOES NOT EXIST

OR WAS CAUSED BY CUSTOMER’S OR ANY THIRD PERSON’S MISUSE, NEGLECT,

IMPROPER INSTALLATION OR TESTING, UNAUTHORIZED ATTEMPTS TO REPAIR OR MODIFY, OR ANY OTHER CAUSE BEYOND THE RANGE OF THE INTENDED USE, OR BY ACCIDENT, FIRE, LIGHTNING, OR OTHER HAZARD.

LIMITATION OF LIABILITY: TO THE FULL EXTENT ALLOWED BY LAW TRENDNET ALSO EXCLUDES FOR ITSELF AND ITS SUPPLIERS ANY LIABILITY, WHETHER BASED IN CONTRACT OR TORT (INCLUDING NEGLIGENCE), FOR INCIDENTAL, CONSEQUENTIAL, INDIRECT, SPECIAL, OR PUNITIVE DAMAGES OF ANY KIND, OR FOR LOSS OF REVENUE OR PROFITS, LOSS OF BUSINESS, LOSS OF INFORMATION OR DATE, OR OTHER FINANCIAL LOSS ARISING OUT OF OR IN CONNECTION WITH THE SALE, INSTALLATION, MAINTENANCE, USE, PERFORMANCE, FAILURE, OR INTERRUPTION OF THE POSSIBILITY OF SUCH DAMAGES, AND LIMITS ITS LIABILITY TO REPAIR, REPLACEMENT, OR REFUND OF THE PURCHASE PRICE PAID, AT TRENDNET’S OPTION. THIS DISCLAIMER OF LIABILITY FOR DAMAGES WILL NOT BE AFFECTED IF ANY REMEDY PROVIDED HEREIN SHALL FAIL OF ITS ESSENTIAL PURPOSE.

Governing Law: This Limited Warranty shall be governed by the laws of the state of California.

Some TRENDnet products include software code written by third party developers. These codes are subject to the GNU General Public License ("GPL") or GNU Lesser General Public License ("LGPL").

Go to http://www.trendnet.com/gpl or http://www.trendnet.com Download section and look for the desired TRENDnet product to access to the GPL Code or LGPL Code. These codes are distributed WITHOUT WARRANTY and are subject to the copyrights of the developers. TRENDnet does not provide technical support for these codes. Please go to http://www.gnu.org/licenses/gpl.txt or http://www.gnu.org/licenses/lgpl.txt for specific terms of each license.

PWP05202009v2 2015/6/19

TRENDnet TEW-807ECH User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Product Overview

Features

Package Contents

Product Hardware Features

System Requirements

Application Diagram

Installing your Wireless Adapter

Connect to your wireless network using WPS

Technical Specifications

Troubleshooting

Appendix
