User’s Guide
F-xM-MM-05
Stand-Alone Media Converter
• 10 Mb/s Ethernet
• 16 Mb/s Token Ring
• SM to MM
Transition Networks F-SM-MM-05 and the
F-MM-MM-05 Media Converters extend
Ethernet or Token Ring networks over
singlemode fiber-optic cable up to 20 km and
multimode to 2 km.
Part Number Port One - Fiber-Optic Port Two - Fiber-Optic
F-SM-MM-05 ST, 850 nm multimode
2 km (1.2 miles)*
ST, 1310 nm singlemode
20 km (12.4 miles)*
F-MM-MM-05 ST, 850 nm multimode
2 km (1.2 miles)*
ST, 850 nm multimode
2 km (1.2 miles)*
* Typical maximum cable distance. (Actual distance is dependent upon the physical
characteristics of the network.)
Optional Accessories (sold separately)
Installation . . . . . . . . . . . . . . . . . . . . .2
Operation . . . . . . . . . . . . . . . . . . . . .3
Cable Specifications . . . . . . . . . . . . . .4
Technical Specifications . . . . . . . . . . .5
Troubleshooting . . . . . . . . . . . . . . . .6
Contact Us . . . . . . . . . . . . . . . . . . . .7
Compliance Information . . . . . . . . . .8
Part No Description
SPS-2460-SA Optional External Power Supply; 18-72VDC Stand-Alone
Output: 12.6VDC, 1.0 A
SPS-2460-CC Optional External Power Supply; 18-72VDC Piggy-back;
Output: 12.6VDC, 1.0 A
E-MCR-05 12-Slot Media Converter Rack (includes universal internal power supply)
17 x 15 x 5 in. (432 x 381 x 127 mm)
WMBL Optional Wall Mount Brackets
Length: 4.0 in. (102 mm), Fits converter length: 4.7 in. (119 mm)
WMBV Optional Vertical Mount Bracket; Length: 5.0 in. (127 mm)
WMBD Optional DIN Rail Mount Bracket; Length: 5.0 in. (127 mm)
WMBD-F Optional DIN Rail Mount Bracket (flat); Length: 3.3in. (84 mm)
2
F-xM-MM-05
Tech Support: 800-260-1312 International: 952-941-7600 7am-6pm CST
Installation
Installing the Cable
Fiber
1. Locate or build fiber cable with male, two-stranded TX to RX connectors
installed at both ends.
2. Connect the fiber cables to the Media Converter as described:
• Connect the male TX cable connector the female TX port.
• Connect the male RX cable connector to the female RX port.
3. Connect the fiber cables to the other device (another media converter, hub,
etc.) as described:
• Connect the male TX cable connector the female RX port.
• Connect the male RX cable connector to the female TX port.
RX
TX
TX
RX
Device
Device
Power the Media Converter
AC
1. Install the power adapter cord to the back of the Media Converter.
2. Connect the power adapter plug to AC power.
3. Verify that the Media Converter is powered by observing the illuminated LED
power indicator light.
DC
Consult the User’s Guide for the Transition Networks SPS2460-xx DC External
Power Suppy for powering the Media Converter.
techsupport@transition.com -- Select the “Transition Now” Link for a Live Web Chat
3
Link
PWR
Multimod e
TX RXTX RX
Link
Multimod e
Link
PWR
Single Mode
TX RXTX RX
Link
Multimode
F-MM-MM-05
F-SM-MM-05
Operation
Using Status LEDs
Use the status LEDs to monitor the Media Converter operation in the network.
Pwr Steady LED indicates connection to external AC or DC power.
Link (left) Steady LED indicates multimode fiber link connection.
Link (right) Steady LED indicates single mode fiber link connection (F-SM-MM-05
only).
4
F-xM-MM-05
Tech Support: 800-260-1312 International: 952-941-7600 7am-6pm CST
Cable Specifications
The physical characteristics must meet or exceed IEEE802.5j specifications.
Bit Error Rate: <10
-10
Multimode 850 nm
Recommended: 62.5/125 µm
Optional: 100/140, 85/125, 50/125 µm
Fiber Optic Transmitter Power: min: -19.0 dBm max: -14.0 dBm
Fiber Optic Receiver Sensitivity: min: -32.5 dBm max: -14.0 dBm
Link Budget: 13.5 dB
Typical maximum cable distance* 2 km (1.2 miles)
Single mode 1310 nm
Recommended: 9 µm
Fiber Optic Transmitter Power: min: -23.0 dBm max: -14.0 dBm
Fiber Optic Receiver Sensitivity: min: -32.5 dBm max: -14.0 dBm
Link Budget: 9.5 dB
Typical maximum cable distance* 20 km (12.4 miles)
* Actual distance is dependent upon the characteristics of the
network installation.
5
techsupport@transition.com -- Select the “Transition Now” Link for a Live Web Chat
Technical Specifications
For use with Transition Networks Model F-SM-MM-05 or equivalent
Product is certified by the manufacturer to comply with DHHS Rule 21/CFR,
Subchapter J applicable at the date of manufacture.
Standards: IEEE802.5j
Data Rate: 4 to 16 Mb/s
Case Dimensions: 4.7" x 3.0" x 1.0" (119 mm x 76 mm x 25 mm)
Weight: 10 oz. (283 g) (approximate)
Power Consumption: 3.1 W
Power Supply 12VDC, 0.4 A (minimum)
DC Output: minimum output regulation: 5%
Connector: 2.1mm barrel, center pin positive
MTBF: 51,185 hours (MIL217F2 V5.0) (MIL-HDBK-217F)
124,339 hours (Bellcore7 V5.0)
Environment: Tmra*: 0 to 50°C (32 to 122°F)
Storage Temp: -20 to 85°C (-4 to 185°F)
Humidity: 10 to 90%, non condensing
Altitude: 0 to 10,000 feet
Warranty: Lifetime
*Manufacturer’s rated ambient temperature.
CAUTION:
Visible and Invisible Laser Radiation When Open. Do Not Stare Into
Beam Or View Directly With Optical Instruments.
CAUTION:
Use of controls, adjustments or the performance of procedures other
than those specified herein may result in hazardous radiation exposure.
6
F-xM-MM-05
Tech Support: 800-260-1312 International: 952-941-7600 7am-6pm CST
Troubleshooting
If the Media Converter fails, isolate and correct the failure by determining the
answers to the following questions and then taking the indicated action:
1. Is the PWR LED on the Media Converter illuminated?
NO
• Is the power adapter the proper type of voltage and cycle frequency for
the AC outlet?
• Is the power adapter properly installed in the Media Converter and in
the outlet?
• Contact Technical Support: US/Canada: 1-800-260-1312, International:
00-1-952-941-7600.
YES
• Proceed to step 2.
2. Is the multimode Link LED (on the left) illuminated?
NO
• Check the fiber cables for proper connection.
• Verify that the TX and RX cables on the Media Converter are connected
to the RX and TX ports, respectively, on the other device.
• Contact Technical Support: US/Canada: 1-800-260-1312, International:
00-1-952-941-7600.
YES
• Proceed to step 3.
3. Is the singlemode Link LED (on the right) illuminated?
NO
• Check the fiber cables for proper connection.
• Verify that the TX and RX cables on the Media Converter are connected
to the RX and TX ports, respectively, on the other device.
• Contact Technical Support: US/Canada: 1-800-260-1312, International:
00-1-952-941-7600.
YES
• Contact Technical Support: US/Canada: 1-800-260-1312, International:
00-1-952-941-7600.
DECLARATION OF CONFORMITY
Name of Mfg: Transition Networks
10900 Red Circle Drive, Minnetonka MN 55343 U.S.A.
Model: F-SM-MM-05 & F-MM-MM-05Series Media Converters
Part Number(s): F-SM-MM-05 & F-MM-MM-05
Purpose: To declare that the F-SM-MM-05 and F-MM-MM-05 to which this
declaration refers is in conformity with the following standards.
EMC-CISPR 22: 1985 Class A; EN 55022: 1988 Class A; EN 50082-1:1992;
A4:1997; IEC 801.2, 801.3, 801.4; IEC 950; CFR Title 21 Section 1040.10 Class I
I, the undersigned, hereby declare that the equipment specified above conforms to the
above Directive(s) and Standard(s).
July, 2011
Stephen Anderson, Vice-President of Engineering Date
techsupport@transition.com -- Select the “Transition Now” Link for a Live Web Chat
7
Contact Us
Technical Support
Technical support is avialable 7:00 AM - 6:00 PM CST (GMT -6:00)
US and Canada: 1-800-260-1312
International: 00-1-952-941-7600
Transition Now
Chat live via the Web with Transition Networks Technical Support.
Log onto www.transition.com and click the Transition Now link.
Web-Based Seminars
Transition Networks provides seminars via live web-based training.
Log onto www.transition.com and click the Learning Center link.
E-Mail
Ask a question anytime by sending an e-mail to our technical support staff.
techsupport@transition.com
Address
Transition Networks
10900 Red Circle Drive
Minnetonka, MN 55343, U.S.A.
telephone: 952-941-7600
toll free: 800-526-9267
fax: 952-941-2322
Compliance Information
FCC Regulations
This equipment has been tested and found to comply with the limits for a class A digital device,
pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference, in which
case the user will be required to correct the interference at the user's own expense.
Canadian Regulations
This digital apparatus does not exceed the Class A limits for radio noise for digital apparatus set
out on the radio interference regulations of the Canadian Department of Communications.
Le présent appareil numérique n'émet pas de bruits radioélectriques dépassant les limites
applicables aux appareils numériques de la class A prescrites dans le Règlement sur le brouillage
radioélectrique édicté par le ministère des Communications du Canada.
European Regulations
Warning
This is a Class A product. In a domestic environment this product may cause radio interference in
which case the user may be required to take adequate measures.
Achtung !
Dieses ist ein Gerät der Funkstörgrenzwertklasse A. In Wohnbereichen können bei Betrieb dieses
Gerätes Rundfunkstörungen auftreten, in weichen Fällen der Benutzer für entsprechende
Gegenmaßnahmen werantwortlich ist.
Attention !
Ceci est un produit de Classe A. Dans un environment domestique, ce produit risque de créer des
interférences radioélectriques, il appartiendra alors à l'utilsateur de prende les measures
spécifiques appropriées.
Trademark Notice
All trademarks and registered trademarks are the property of their respective owners.
Copyright Restrictions
© 1997 - 2011 Transition Networks.
All rights reserved. No part of this work may be reproduced or used in any form or by any means
- graphic, electronic, or mechanical - without written permission from Transition Networks.
Printed in the U.S.A.
In accordance with European Union Directive 2002/96/EC of the European Parliament
and of the Council of 27 January 2003, Transition Networks will accept post usage
returns of this product for proper disposal. The contact information for this activity can
be found in the 'Contact Us' portion of this document.
CAUTION: RJ connectors are NOT INTENDED FOR CONNECTION TO THE
PUBLIC TELEPHONE NETWORK. Failure to observe this caution could result in
damage to the public telephone network.
Der Anschluss dieses Gerätes an ein öffentlickes Telekommunikationsnetz in den EGMitgliedstaaten verstösst gegen die jeweligen einzelstaatlichen Gesetze zur Anwendung der
Richtlinie 91/263/EWG zur Angleichung der Rechtsvorschriften der Mitgliedstaaten über
Telekommunikationsendeinrichtungen einschliesslich der gegenseitigen Anerkennung ihrer
Konformität.
33063.E
