Traceable 98767-31 User manual

SPECIFICATIONS

Range: –58 to 500°F / –50 to 250°C
Resolution: 0.1° above –20° and

Accuracy:

Sampling
Rate:

Attachments: Clip, magnet, and stand

below 200° otherwise 1.0°
±0.5°C at tested points, ±1°C

otherwise (–20.0 to 100.0°C)

1 second

ULTRA™ THERMOMETER ACCURACY

Ultra™ thermometers are tested at selected test
points to be within tighter than normal tolerances to
assist in providing improved accuracy. Other points
will not necessarily fall within the same accuracy
as those found at the selected test points, but will
be within an accuracy of ±1°C between –20.0 and

100.0°C.

OPERATION

Slide the ON/OFF switch to ON to turn the unit
on. Slide the °C/°F switch to °F to display the
temperature in Fahrenheit or °C to display the
temperature in Celsius. Insert the probe into the
material to be measured. Slide the ON/OFF switch
to OFF to turn the unit off. Always turn the unit off

when not in use to conserve battery life.
NOTE: Both the probe and cable may be totally
immersed in liquid.

ALL OPERATIONAL DIFFICULTIES

If this unit does not function properly for any
reason, replace the battery with a new high-quality
battery (see “Battery Replacement” section). Low
battery power can occasionally cause any number

RI³DSSDUHQW´RSHUDWLRQDOGLI¿FXOWLHV5HSODFLQJ

the battery with a new fresh battery will solve most

GLI¿FXOWLHV

BATTERY REPLACEMENT

Erratic readings, a faint display, or no display are
all indications that the battery must be replaced
Remove the battery cap by turning it 1/4 turn coun­ter clockwise. Remove the exhausted battery and
replace with a new 1.5 volt silver oxide battery.
Make certain that the positive (+) side is facing
you. Replace the battery cap.

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

TRACEABLE

FULL-SCALE

THERMOMETER

INSTRUCTIONS

®
