SPECIFICATIONS:
Display: ½” LCD
Range: 99 Minutes, 59 seconds to
zero
Resolution: 1 second
Accuracy: 0.01%
Alarm: 1 Minute audible alarm,
bright red LED flashing
visual alarm
Function: Countdown timing
Features: Water-resistant, Audible
alarm, Flashing red LED
when time is up, Infinite
timeouts, Supplied with
lanyard and suction cup.
CONTROLS/INDICATORS
Separate START and STOP buttons, and
ten time-setting buttons, numbered “1”
through “10”.
OPERATION
1. Select desired countdown time with
buttons “1” through ”10”.
2. Press the “START” button to begin
countdown.
3. Press the “STOP” button for timeouts
or to stop the countdown.
4. When zero is reached a bright red
LED flashes and an audible alarm
sounds for one minute.
5. Alarm can be turned off by pressing
any of the buttons on the unit.
6. To clear the time entry, press the
“STOP” button twice.
ALL OPERATIONAL DIFFICULTIES
If this unit does not function properly for
any reason, replace the battery with a
new high-quality battery (see “Battery Replacement” section). Low battery power
can occasionally cause any number
of “apparent” operational difficulties.
Replacing the battery with a new fresh
battery will solve most difficulties.
BATTERY REPLACEMENT
Erratic readings, a faint display or no
display are all indicators that the batteries must be replaced. The two battery
compartments located on the back of the
unit can be opened with a screw driver
(turn in the direction indicated). Replace
exhausted batteries with two new 1.5 volt
batteries. When replacing battery compartment covers, carefully ensure that
each cover is properly in place in order to
maintain the unit’s water-resistance.
Find Qua lity Produ cts Onlin e at: sales@Gl obalTestSupply.c om
www.GlobalTestSupply.com
Page 2
©2017 92-5036-40 Rev. 0 072617
Find Qua lity Produ cts Onlin e at: sales@Gl obalTestSupply.c om
www.GlobalTestSupply.com
TRACEABLE
WATER-
RESISTANT,
FLASHING TIMER
INSTRUCTIONS
®
