SPECIFICATIONS

Range:
–58 to 302°F / –50 to 150°C

Accuracy:
Cat# 4049- ±1°C between –20 and 100°C
Cat# 4355- ±1°C between –20 and 100°C
Cat# 4374- ±0.3°C (–20 and 100°C) otherwise ±1°C

Resolution:

0.1° above –20° and below 200°
1° below –20° and above 200°

Sampling Rate:
1 second

ULTRA™ THERMOMETER ACCURACY

Ultra™ thermometers are tested at selected test points
to be within tighter than normal tolerances to assist
in providing improved accuracy. Other points will not
necessarily fall within the same accuracy as those found
at the selected test points, but will be within an accuracy
of ±1°C.

OPERATION

Slide the ON/OFF switch to ON to turn the unit on. Slide
the °C/°F switch to °F to display the temperature in
Fahrenheit or °C to display the temperature in Celsius.
Insert the stem into the material to be measured. Slide
the ON/OFF switch to OFF to turn the unit off. To
conserve battery life, always turn the unit off when not
in use.

ALL OPERATIONAL DIFFICULTIES

If this unit does not function properly for any reason,
replace the battery with a new high-quality battery (see
“Battery Replacement” section). Low battery power can
occasionally cause any number of “apparent” operational

GLI¿FXOWLHV5HSODFLQJWKHEDWWHU\ZLWKDQHZIUHVKEDWWHU\
ZLOOVROYHPRVWGLI¿FXOWLHV

BATTERY REPLACEMENT

Erratic readings, a faint display, or no display are all
indications that the battery must be replaced. To replace
the battery, remove the battery cap screw. Remove
the battery cap by turning it in the direction of the arrow
(counter clockwise). Remove the exhausted battery
and replace it with a new 1.5 volt size G-13 battery.
Equivalent replacement batteries are: Ray-O-Vac RW42,
Duracell D357, Eveready 357. Make certain that the
positive (+) side is facing you. Replace the battery cap.
Replace the battery cap screw and tighten securely.

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

TRACEABLE

JUMBO DISPLAY

DIAL

THERMOMETER

INSTRUCTIONS

®
