AC1900 Wi-Fi Router
Dual Band | MU-MIMO
Archer C80
1300 Mbps 5 GHz +
600 Mbps 2.4 GHz
†
4 Antennas for
Superior Coverage
Faster Wi-Fi
†
with MU-MIMO
Smart Connect
Full Gigabit
Ports
Highlights
Speeds up to 1900 Mbps
1300 Mbps on the 5 GHz band and 600 Mbps on the 2.4 GHz are ideal for both
everyday tasks and lag-free online entertainment.
†
Smart Connect
Smart Connect unites 2.4 GHz and 5 GHz band into a single Wi-Fi SSID and helps
the router automatically switch each device’s connection to the best available
Wi-Fi band.
SSID 1
2.4 GHz
SSID 2
5 GHz
600
Mbps
1300
Mbps
√ Archer C80
TP-Link
AC1900 Wi-Fi Router
C80
Highlights
Vast Wi-Fi Coverage
Four external omni-directional antennas create strong, clear, dependable Wi-Fi
throughout your home. Beamforming detects the location of your connected
devices and concentrates the Archer C80’s signal towards them to optimize
wireless connections.
†
MU-MIMO
MU-MIMO technology serves multiple devices at once, reducing wait time,
increasing Wi-Fi throughput for every device, and making each stream more
ecient.
‡
Archer C80 Regular Router
Traditional
Router
TP-Link
MU-MIMO
Router
AC1900 Wi-Fi Router
C80
Highlights
Airtime Fairness
Equally divides network time between new devices, such as your gaming rig and
older devices to improve your overall Wi-Fi performance and reliability.
Easy Setup and Use
Installation is simple, thanks to an intuitive web interface and the powerful
TP-Link app, Tether. Tether lets you manage your network settings with
your smartphone.
C80
Time
Time
Slower clients take up more time
Scan the QR code to download TP-Link Tether.
Time is fairly distributed among clients
TP-Link
AC1900 Wi-Fi Router
C80
Features
Speed Wi-Fi Range Reliability
· 802.11ac Technology – Powered by 802.11ac Wi-Fi
technology, Archer C80 creates a reliable, blazing-fast
network.
· Ultimate Wireless Speed – 1300 Mbps on 5 GHz + 600 Mbps
on 2.4 GHz
· Gigabit Internet Access – Take full advantages of broadband
speeds up to 1 Gbps
· Ultimate Range Wi-Fi – Four external antennas deliver a Wi-Fi
signal to every corner of your home, making all of your
connections more ecient and stable
· Beamforming Technology – Concentrates Wi-Fi signals
towards individual devices to ensure stronger connections
· Airtime Fairness – Balances airtime usage of connected devices
to improve overall throughput and eciency
· Smart Connect – Intelligently switches each device’s connection
to the optimum available Wi-Fi band
· Vxworks System – Utilizes the real-time Vxworks system, which
has pre-assigned RAM strategy to provide more stable and
high-responsive experience.
TP-Link
AC1900 Wi-Fi Router
C80
Features
Easy Management Security
· Intuitive Web UI – Ensures quick and simple Installation without
hassle
· Hassle-free Management with Tether App – Network
management is made easy with the TP-Link Tether App,
available on any Android and iOS device
· TP-Link ID – Binds the router to your TP-Link ID and other family
member’s accounts to manage the router
· Encryptions for Secure Network – WPA-PSK and WPA2-PSK
encryptions provide active protection against security threats
· Guest Network – Keeps your main network secure by creating a
separate network for friends and visitors
· Parental Controls – Restricts internet access time and contents
for children devices
Ease of Use
· Wi-Fi Sharing – Easily shares your Wi-Fi access with a QR code
· Wi-Fi Schedule –The wireless network can be automatically o
within a specied period when you do not need the wireless
connection
· LED Control – Automatically turns your router‘s LEDs o within
a specied period
TP-Link
AC1900 Wi-Fi Router
C80
Specications
Hardware
· Ethernet Ports: 1× 10/100/1000 Mbps WAN Port, 4×10/100/1000 Mbps LAN Port
· Buttons: WPS/Wi-Fi Button, Power On/O Button, Reset Button
· Antennas: 4 Fixed Omni Directional Antennas
· External Power Supply: US version 12V/1.5A
EU version 12V/1A
· Dimensions (W x D x H): 8.5 × 4.6 × 1.26 in (215 × 117 × 32mm)
Power
WPS/Wi-Fi On/O
Wireless
· Wireless: 1300 Mbps on 5 GHz + 600 Mbps on 2.4 GHz
· Frequency: 2.4 GHz and 5 GHz
· Transmit Power:
CE: <20dBm(2.4 GHz), <23dBm(5.15 GHz~5.25 GHz)
FCC:<30dBm(2.4 GHz & 5 GHz)
· Reception Sensitivity:
5 GHz:
11a 6Mbps:-98dBm, 11a 54Mbps:-78dBm
11ac VHT20_MCS0:-98dBm, 11ac VHT20_MCS8:-72dBm
11ac VHT40_MCS0:-92dBm, 11ac VHT40_MCS9:-68dBm
11ac VHT80_MCS0:-89dBm, 11ac VHT80_MCS9:-64dBm
2.4 GHz:
11g 6Mbps:-97dBm, 11a 54Mbps:-77dBm
11n VHT20_MCS0:-97dBm, 11n VHT20_MCS8:-72dBm
11n VHT40_MCS0:-92dBm, 11n VHT40_MCS9:-67dBm
· Wireless Function: Enable/Disable Wireless Radio, WMM
· Wireless Security: 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryptions
Gigabit LAN PortsGigabit WAN PortsPower On/O
Reset
TP-Link
AC1900 Wi-Fi Router
C80
Specications
OthersSoftware
· Quality of Service: Device Prioritization
· WAN Type: Dynamic IP/Static IP/PPPoE(Dual Access)/PPTP(Dual Access)/L2TP(Dual
Access)
· Management: Access Control, Local Management, Remote Management
· DHCP: Server, DHCP Client List, Address Reservation
· Port Forwarding: Port Forwarding, Port Triggering, UPnP, DMZ
· Dynamic DNS: DynDns, NO-IP, TP-Link
· Access Control: Parental Controls, Local Management Control, White List, Black List
· Firewall Security: SPI Firewall, IP and MAC Address Binding
· Protocols: IPv4, IPv6
· Guest Network: 2.4 GHz Guest Network, 5 GHz Guest Network
· Certication:
CE, FCC, RoHS
· System Requirements:
Microsoft Windows 98SE/NT/2000/XP/Vista™/7/8/8.1/10, MAC OS,
NetWare, UNIX or Linux
Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other
Java-enabled browser
Cable or DSL Modem
Subscription with an internet service provider (for internet access)
· Environment:
Operating Temperature: 0℃~40℃ (32℉ ~104℉)
Storage Temperature: -40℃~70℃ (-40℉ ~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
· Package Contents
Wireless Router Archer C80
Power Adapter
RJ45 Ethernet Cable
Quick Installation Guide
For more information, please visit
https://www.tp-link.com/products/details/?model=Archer+C80_V1
or scan the QR code left
Attention: This device may only be used indoors in all EU member states and EFTA countries.
Specications are subject to change without notice. TP-Link is a registered trademark of TP-Link Technologies Co., Ltd. Other brands and product names are trademarks or registered trademarks of their respective holders. Copyright ©2019 TP-Link Technologies Co., Ltd. All rights reserved.
†Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specications. Actual wireless data throughput and wireless coverage are not guaranteed and will vary as a result of network conditions, client limitations, and environmental factors, including building materials,
obstacles, volume and density of trac, and client location.
‡Use of MU-MIMO requires clients to also support MU-MIMO.
