TOYOTA Sequoia User Manual
TABLE OF CONTENTS
Item Page no.
OVERVIEW
Engine compartment 7
Fuel tank door opener and cap 6
Hood release lever 6
Indicator symbols 4-5
Instrument cluster 4-5
Instrument panel 2-3
Mirrors-Power side view 7
FEATURES/OPERATIONS
Air conditioning/heating 15
Audio 16-17
Auto lock functions- Programmable
Automatic transmission 9
Clock 11
Cruise control 19
Cup holders 19
Engine immobilizer 19
Four-wheel drive 10
Keyless entry
2
Lights2& turn signals 12
Moonroof
2
Multi-information display (HomeLink®)
Power outlets 18
Seat adjustments-Front 11
Seat adjustments-Rear 11
Seats-Head restraints 12
Tilt steering wheel 14
Windows
Window-Back
2
2
Wiper & washer lever-Front/Rear 13
SAFETY AND EMERGENCY FEATURES
ATRAC (Active Traction Control) 21
Airbag-Supplemental Restraint System 22-23
Door locks 20
Doors-Child safety locks 20
Parking brake 21
Rollover information 24
Seat belts 20
Seat belts-Shoulder belt anchor 21
Spare tire & tools 25
Tire Pressure Warning System 22
TRAC (Traction Control) 21
VSC (Vehicle Stability Control) 21
1, 2
3
OVERVIEW
8
8
FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
18
13
14
14
1
Programmable by consumer.
2
Visit your Toyota dealer for information on
customizing this feature.
3
HomeLink®is a registered trademark of Johnson Controls, Inc.
1
OVERVIEW
Instrument panel
OVERVIEW FEATURES/OPERATIONS
Two-wheel drive models
Four-wheel drive models
Power back window switch
Driving position memory switches
1
Headlight, turn signal and front fog light1controls
Ignition switch
Wiper and washer controls
Automatic transmission shift lever
Emergency flasher switch
Automatic transmission shift position “L” switch
(“SHIFT L” switch)
Audio or navigation system
1, 2
Front/Rear air conditioning controls
Front passenger occupant classification indicator
light/front passenger’s seat belt reminder light
Back window and outside rearview mirror
defogger
1
switch
Clock
Cup holder
Glass breakage sensor
1
2
115V Power outlet main switch
Height control switch
1
Height control mode select switch
1
1
Ashtray
Cigarette lighter
Front drive control switches
1
“TRAC OFF” (Traction Control “OFF”) switch
Center differential lock switch
1
Cruise control lever
Tire Pressure Warning reset switch (below
steering column)
Audio steering wheel switches
1
Tilt steering lock release lever
“RSCA OFF” (Roll Sensing of Curtain shield
Airbags “OFF”) switch
1
Instrument panel light control
1
If installed
2
For details, refer to the Navigation System
Owner’s
Manual.
3
1
SAFETY AND EMERGENCY FEATURES
OVERVIEW
Instrument cluster
Limited model option
OVERVIEW FEATURES/OPERATIONS
Service reminder indicators and lights
Oil pressure gauge
Tachometer
Speedometer
Fuel gauge
Indicator symbols
Brake system warning light
Driver’s seat belt reminder light
Front passenger’s seat belt reminder light
Battery warning light
Malfunction indicator light
Low fuel level warning light
Anti-lock Brake System warning light
When the Anti-lock Brake System (ABS) function is in
action, you may feel the brake pedal pulsating and
hear a noise. In this situation, to let the Anti-lock
Brake System work for you, just hold the brake pedal
down more firmly. Do not pump the brake as this will
result in reduced braking performance.
•Vehicle Stability Control warning light
•Traction Control warning light
•Active Traction Control warning light
Open door warning light
Airbag SRS warning light
Automatic transmission fluid temperature
warning light
1
Low Tire Pressure Warning light
Low windshield washer fluid level warning
1
light
1
For details, refer to “Service reminder indicators and warning
buzzers,” Section 1-6, 2005 Owner’s Manual.
2
If this light flashes, refer to “Four-wheel drive system,” Section
1-7, 2005 Owner’s Manual.
4
1
1
1
1
1
1
1
1
1
1
1
1
Engine coolant temperature gauge
Trip meter reset knob
Odometer and two trip meters
Height control indicator lights
Volt meter
Engine oil replacement reminder light
Theft deterrent/Engine immobilizer system
indicator light
Front passenger occupant classification indicator
light
1
Roll Sensing of Curtain shield Airbags off
indicator light
1
Headlight low beam indicator light
Turn signal indicator light
Headlight high beam indicator light
Automatic transmission indicator lights
Overdrive-off indicator light
High speed four-wheel drive indicator light
Low speed four-wheel drive indicator light
Center differential lock indicator light
2
2
2
Slip indicator light
Traction Control off indicator light
SAFETY AND EMERGENCY FEATURES
Vehicle Stability Control off indicator light
Height control indicator lights
Manual control mode indicator light
Cruise control indicator light
3
If this light flashes, refer to “Rear height control air
suspension,” Section 1-7, 2005 Owner’s Manual.
4
If this light flashes, refer to “Cruise control,” Section 1-7, 2005
Owner’s Manual.
5
3
4
OVERVIEW
Fuel tank door opener and cap Engine compartment
Windshield and back window washer fluid tank
Power steering fluid reservoir
Engine oil level dipstick
Engine oil filler cap
Brake fluid reservoir
Fuse blocks
To open the fuel tank door from driver side
seat Pull up on the opener.
To remove the fuel tank cap Turn the cap
counterclockwise 90 degrees, then turn it an
additional 30 degrees. Pause slightly before
removing it.
The removed cap can be stored on the fuel
tank door.
To replace the fuel tank cap Turn clockwise until
a click is heard. If not tightened enough, Check
Engine “ ” indicator may illuminate.
Hood release lever
Battery
Engine coolant reservoir
A/C condenser
Radiator
Note: Regularly scheduled maintenance, including
oil changes, will help extend the life of
your vehicle and maintain performance.
Please refer to the “Owner’s Warranty
Information Booklet,” “Scheduled
Maintenance Guide” or “Owner’s Manual
Supplement.”
Mirrors-Power side view
OVERVIEW FEATURES/OPERATIONS
To release the hood Pull the lever inside vehicle.
To open the hood Insert finger through the
opening through the grill. Pull up on the catch
lever inside the compartment and lift the hood.
6
Fold mirrors in
SAFETY AND EMERGENCY FEATURES
Return mirrors to
original position
To select left or right mirror
Push to “L” (left) or “R” (right).
To adjust the mirror Push in the desired
direction.
To fold/unfold mirrors (Limited model only)
Key must be in the “ACC” or “ON” position.
7
