Toyota 86 2018 Quick Reference Guide
86
2 0 18
QUICK REFERENCE GUIDE
2018
Toyota 86
This Quick Reference Guide is a summary of basic vehicle
operations. It contains brief descriptions of fundamental
operations so you can locate and use the vehicle’s main
equipment quickly and easily.
The Quick Reference Guide is not intended as a substitute for
the Owner’s Manual located in your vehicle’s glove box. We
strongly encourage you to review the Owner’s Manual and
supplementary manuals so you will have a better understanding
of your vehicle’s capabilities and limitations.
Your dealership and the entire staff of Toyota Motor North
America, Inc. wish you many years of satised driving in your
new 86.
A word about safe vehicle operations
This Quick Reference Guide is not a full description of 86 operations. Every 86
owner should review the Owner’s Manual that accompanies this vehicle.
Pay special attention to the boxed information highlighted in color throughout
the Owner’s Manual. Each box contains safe operating instructions to help you
avoid injury or equipment malfunction.
All information in this Quick Reference Guide is current at the time of printing.
Toyota reserves the right to make changes at any time without notice.
INDEX
OVERVIEW
Engine maintenance 8
Fuel tank door release & cap 7
Hood release 8
Indicator symbols 5
Instrument cluster 4
Instrument panel 2-3
Instrument panel light control 8
Keyless (and remote) entry 6
Smart Key system 7
FEATURES & OPERATIONS
Air conditioning/heating 18
Automatic transmission 9
AUX/USB port 17
Clock 16
Cruise control 10
Cup/bottle holders 15
Door locks 16
Driving modes 10-11
Hill-start Assist Control (HAC) 11
Lights & turn signals 12
Manual transmission 9
Multi-Information Display (MID) 14
Parking brake 9
Power outlets 17
Rear view monitor system 19
Seat adjustments-Front 13
Seats-Fold down rear seats 13
Seats-Head restraints 12
Steering lock release 19
Steering wheel switches 15
Tilt & telescopic steering wheel 16
Trunk release 16
Windows 13
Windshield wipers & washers 12
SAFETY & EMERGENCY FEATURES
Floor mat installation 23
Seat belts 20
Spare tire & tools 21
Star Safety System
™
22-23
Tire Pressure Monitoring
(warning) System (TPMS) 20
PAIRING BLUETOOTH® PHONE FOR
THE FIRST TIME 24-25
OVERVIEWFEATURES & OPERATIONSSAFETY & EMERGENCY FEATURES
1
OVERVIEW
Instrument panel
Paddle shift switches*
Meter control switches*
Ignition switch*
Audio control
switches
Cruise control switch
Steering wheel controls
Meters/Multi-Information Display (MID)
Wiper and washer controls
Headlight, turn signal and
fog light* controls
Instrument panel light control
Trunk opener
Fuel tank door release lever
Hood lock release lever
Tilt and telescopic steering lock release lever
2
“ENGINE START
STOP” switch*
Emergency flasher switch
Clock
Air conditioning controls
Manual air conditioning controls
Automatic air conditioning cont
rols
*
If equipped
Rear window and outside rear
view mirror defogger*/rear
window deffoger* switch
OVERVIEWFEATURES & OPERATIONSSAFETY & EMERGENCY FEATURES
Seat heaters*
Power outlet
AUX/USB port
TRACK mode switch
SPORT or SNOW
mode switch*
Vehicle Stability Control (VSC)/TRAC OFF switch
3
OVERVIEW
Instrument cluster
Monochrome display
Analog speedometer
km/h MPH switch
Tachometer
Fuel gauge
Display switch
Color display
km/h MPH switch
Odometer/trip meter
display change switch
Odometer/trip meter
display change switch
Analog speedometer
Odometer/Trip meter
/Multi-Information Display
Tachometer
Fuel gauge
Engine coolant temperature
Digital speedometer
Service indicators and reminders
Digital speedometer
Odometer/Trip meter
/Multi-Information Display
Service indicators and reminders
4
Indicator symbols
For details, refer to “Indicators and warning lights,” Section 2-2, 2018 Owner’s
Manual.
AIR BAG ON/OFF indicator
Airbag SRS warning
1
Anti-lock Brake System (ABS) warning
Automatic headlight leveling
system warning
Automatic Transmission fluid
temperature warning
Brake system warning
Charging system warning
Cruise control indicators
5
1
1
2
Electric power steering system warning
Front fog light indicator
5
Fuel tank door position
Headlight high beam indicator
Hill-start assist control ON indicator
Low engine coolant temperature
5
indicator
Low engine oil pressure warning
Low fuel level warning
1
Low outside temperature indicator
Low Tire Pressure Warning
1
5
1
Malfunction/
Check Engine indicator
Master warning
1
Open door warning
1
1,5
5
OVERVIEWFEATURES & OPERATIONSSAFETY & EMERGENCY FEATURES
REV (engine RPM) indicator
Seat belt reminder (alarm will
sound if speed is over 12 mph)
Security indicator
Shift position and shift range
3,5
indicator
Shift position indicator
1
Shift-up indicator
Slip indicator
Smart Key system indicator
SNOW indicator
SPORT indicator
4,5
4,5
1
5
3,5
3,5
TRACK mode indicator
TRAC OFF indicator
1
Turn signal indicator
Upshift/downshift indicator
3,5
Vehicle Stability Control OFF indicator1
1
If indicator does not turn off within a few seconds of starting engine, there may be a malfunction.
Have vehicle inspected by your Toyota dealer.
2
If these lights come on in yellow, refer to “Cruise control” Section 2-4, 2018 Owner’s Manual.
3
Vehicle with an automatic transmission.
4
Vehicle with a manual transmission.
5
If equipped.
5
OVERVIEW
Keyless (and remote) entry
UNLOCKING OPERATION
Smart Key
Push
ONCE: Driver door
TWICE: All doors
Carry remote
Smart Key feature
Driver door unlock*
Grasp
NOTE: If a door is not opened within 60 seconds of unlocking, all doors will
relock for safety.
* Driver door unlocking function can be programmed to unlock driver door only, or
all doors. Grasping passenger door handle will unlock all doors.
LOCKING OPERATION
Smart Key
Push
TRUNK LID
Smart Key
Carry remote
Smart Key feature
All-door lock
Touch
PANIC BUTTON
Push and hold
Push
Smart Key
Push and hold
6
Smart Key system (if equipped)
START FUNCTION
NOTE: Carry the electronic key to enable start function. Gear shift lever must
be in P and brake pedal depressed. (Automatic transmission)/Gear shift lever
must be in N and clutch pedal depressed. (Manual transmission)
POWER (WITHOUT STARTING ENGINE)
Without depressing the brake pedal (automatic transmission)/ the clutch pedal
(manual transmission), pressing the engine switch will change the operation mode
in succession from:
Accessories such as the radio will operate.
Power ON; the engine not running.
OVERVIEWFEATURES & OPERATIONSSAFETY & EMERGENCY FEATURES
All systems OFF.
Fuel tank door release & cap
Pull up
Turn to open
Store
NOTE: Tighten until one click is heard. If the cap is not tightened enough,
Check Engine “
” indicator may illuminate.
7
