Toshiba 52Z3500A, 52Z3500E, 52Z3500T, 57Z3500A, 57Z3500E Owner's Manual

O

WNER'S

M

LCD Color TV

ANUAL

52Z3500A
52Z3500E
52Z3500T
57Z3500A
57Z3500E
57Z3500T

Owner's Record

You will find the model number and serial number on
the back of the TV. Record these numbers in the spaces
provided below. Refer to them whenever you call upon
your TOSHIBA dealer regarding this product.

Model number:

Serial number:

VX1A00054000

Contents

Introduction

Welcome to Toshiba . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . 3

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Important information. . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Getting started

Connecting an antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Exploring your new TV . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Installing the remote control batteries . . . . . . . . . . . . 7

TV front and side panel controls . . . . . . . . . . . . . . . . . . . 8

TV back panel connections. . . . . . . . . . . . . . . . . . . . . . . . 9

Learning about the remote control . . . . . . . . . . . . . . . . . 10

Location of controls . . . . . . . . . . . . . . . . . . . . . . . . . 10

Turning the TV on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Switching on the TV . . . . . . . . . . . . . . . . . . . . . . . . 11

Switching off the TV . . . . . . . . . . . . . . . . . . . . . . . . 11

Learning about the menu system . . . . . . . . . . . . . . . . . . 11

Displaying the menu chart . . . . . . . . . . . . . . . . . . . . 11

Watching TV programs . . . . . . . . . . . . . . . . . . . . . . . . . 12

Selecting the menu language . . . . . . . . . . . . . . . . . . 12

Changing the program position . . . . . . . . . . . . . . . . 12

Switching between two program positions . . . . . . . 12

Displaying the on-screen information . . . . . . . . . . . 12

Programming channels into the TV’s channel memory . 12

Programming channels automatically . . . . . . . . . . . 12

Manually setting channels in the channel memory . 13

Sorting program position . . . . . . . . . . . . . . . . . . . . . 13

Using the TV’s features

Picture adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Selecting the picture size . . . . . . . . . . . . . . . . . . . . . 14

Using the picture still . . . . . . . . . . . . . . . . . . . . . . . . 15

Adjusting the picture position . . . . . . . . . . . . . . . . . 15

Resetting the picture position. . . . . . . . . . . . . . . . . . 15

Selecting the picture mode . . . . . . . . . . . . . . . . . . . . 15

Adjusting the basic picture quality . . . . . . . . . . . . . . 16

Activating the black stretch . . . . . . . . . . . . . . . . . . . 16

Activating the MPEG NR (Noise Reduction) . . . . . 16

Activating the DNR (Digital Noise Reduction) . . . . 16

Selecting the color temperature . . . . . . . . . . . . . . . . 16

Adjusting the color management . . . . . . . . . . . . . . . 17

Resetting the base color adjustment . . . . . . . . . . . . . 17

Using the active backlight control . . . . . . . . . . . . . . 17

Using the cinema mode . . . . . . . . . . . . . . . . . . . . . . 17

Using the meta brain PRO 100. . . . . . . . . . . . . . . . . 17

Film Stabilization . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Sound adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Setting the MTS (Multi-channel TV Sound) . . . . . . 18

Selecting the dual 1 or dual 2 mode . . . . . . . . . . . . . 18

Selecting the stereo programs . . . . . . . . . . . . . . . . . 18

Selecting the bilingual programs . . . . . . . . . . . . . . . 18

Adjusting the sound quality . . . . . . . . . . . . . . . . . . . 18

Using the SRS WOW® surround sound . . . . . . . . . 19

Using the stable sound . . . . . . . . . . . . . . . . . . . . . . . 19

Activating the speaker . . . . . . . . . . . . . . . . . . . . . . . 19

Selecting the woofer internal/external mode . . . . . . 19

Using the bass boost. . . . . . . . . . . . . . . . . . . . . . . . . 19

Using an external woofer system . . . . . . . . . . . . . . . 20

Selecting the audio output . . . . . . . . . . . . . . . . . . . . 20

Other features settings . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Selecting the timer menu. . . . . . . . . . . . . . . . . . . . . . 20

Using the auto format . . . . . . . . . . . . . . . . . . . . . . . . 20

Activating blue screen. . . . . . . . . . . . . . . . . . . . . . . . 21

Adjusting the brightness of side panel . . . . . . . . . . . 21

Selecting the video input source to view. . . . . . . . . . . . . 21

Setting the manual setting menu . . . . . . . . . . . . . . . . 21

Using REGZA-LINK . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

REGZA-LINK one touch play . . . . . . . . . . . . . . . . . 22

REGZA-LINK system standby . . . . . . . . . . . . . . . . . 22

REGZA-LINK system audio control . . . . . . . . . . . . 22

REGZA-LINK functions. . . . . . . . . . . . . . . . . . . . . . 22

To set the REGZA-LINK . . . . . . . . . . . . . . . . . . . . . 23

REGZA-LINK input source selection. . . . . . . . . . . . 23

To control the REGZA-LINK device . . . . . . . . . . . . 23

Teletext . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Setting up the teletext mode . . . . . . . . . . . . . . . . . . . 24

Teletext general information . . . . . . . . . . . . . . . . . . . 24

Using Auto mode . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Using LIST mode . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Teletext buttons on the remote control . . . . . . . . . . . 25

Using the double-window . . . . . . . . . . . . . . . . . . . . . . . . 26

Displaying the double-window . . . . . . . . . . . . . . . . . 26

Selecting the headphone mode . . . . . . . . . . . . . . . . . 26

Adjusting the headphone volume (Mode 2) . . . . . . . 27

Using a headphone . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Connecting your TV

Side connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Connection example . . . . . . . . . . . . . . . . . . . . . . . . . 28

Back connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Connection example . . . . . . . . . . . . . . . . . . . . . . . . . 28

Connecting an HDMI or DVI device . . . . . . . . . . . . . . . 29

Connecting an HDMI or DVI device . . . . . . . . . . . . 29

Connecting an HDMI device . . . . . . . . . . . . . . . . . . 29

Connecting a DVI device . . . . . . . . . . . . . . . . . . . . . 29

REGZA-LINK connection . . . . . . . . . . . . . . . . . . . . . . . 30

Selecting the PC/HDMI1 audio mode . . . . . . . . . . . . . . . 31

Setting the HDMI1 audio mode . . . . . . . . . . . . . . . . . . . 31

Using the HDMI setting . . . . . . . . . . . . . . . . . . . . . . 31

xvYCC selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Connecting a computer . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Using the PC setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Adjusting the picture size/position . . . . . . . . . . . . . . 33

Adjusting the clock phase of the picture . . . . . . . . . . 33

Adjusting the sampling clock . . . . . . . . . . . . . . . . . . 33

Resetting the PC setting . . . . . . . . . . . . . . . . . . . . . . 33

PC Media Window . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Reference section

Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Symptom and solution . . . . . . . . . . . . . . . . . . . . . . . 34

Broadcast system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Broadcast transmission systems of each country or

region . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

LCD color television . . . . . . . . . . . . . . . . . . . . . . . . . 35

2

Introduction

Welcome to Toshiba

• Thank you for purchasing this Toshiba LCD Color
Television. This manual will help you use the exciting
features of your new TV.

• Instructions in this manual are based on using the remote
control.

• You also can use the controls on the TV if they have the
same name as those referred to on the remote control.

• Please read all safety and operating instructions in this
manual carefully, and keep this manual for future reference.

Important Safety Instructions

Be sure to observe the following instructions and precautions
to ensure safe use of this TV.

Installation

1) Always connect the power plug to an appropriate

electrical outlet equipped with A model: 220-240V,
AC 50Hz, E model: 220-240V, AC 50/60Hz and T
model: 110-240V, AC 50/60Hz.

Never use the TV outside the specified voltage range. It
may cause a fire or an electric shock.

Ex. 220-240V AC, 50/60Hz

3) Never place the TV in an unstabilized location such
as on a shaky table, incline or location subject to
vibration.

The TV may drop or fall off which may cause an injury
or damage.

4) Never block or cover the slots and openings in the
cabinet.

• Never place the TV so that it is facing upward or on

its side.

• Never place the TV in a closet, bookcase or other

similar area where the ventilation is poor.

• Never drape a newspaper, tablecloth or curtain on the

TV.

• When installing the TV against a wall, always keep

the TV at least 10 cm away from the wall.

• Never place the TV on a soft unstable surface, such

as a carpet, or a cushion.
The inside of this TV will overheat if the ventilation holes
are covered, blocked or sealed, which may result in a
fire.

Check!

WARNING ABOUT THREE-WIRE GROUNDING­TYPE PLUG: (For E model only)

• This product shall be connected to a main socket
outlet with a protective earthing connection.

• Never remove the earthing pin on the power plug.
This system is equipped with a three pin earthing­type power plug. This plug will only fit an earthing­type power outlet. This is a safety feature. If you are
unable to insert the plug into the outlet, contact an
electrician to replace the wall outlet.

• Never defeat the purpose of the earthing plug.

About the fuse

In a three pin earthing-type, the fuse fitted in this plug is
approved by ASTA or BSI to BS1362. It should only be
replaced by a correctly rated and approved type and the
fuse cover must be refitted.

2) Never insert or remove the power plug with wet
hands.

This may cause an electric shock.

5) Never place the TV near a heater or in direct
sunlight.

The surface of the cabinet or power cord may melt and
result in a fire or an electric shock.

6) Never place the TV in an area exposed to high
humidity levels, such as in a bathroom or close to a
humidifier.

This may cause a fire or an electric shock.

3

Introduction

S

7) Never place the TV next to a stove where it will be
exposed to oil, smoke, or steam, or in a location
where there is a large quantity of dust.

This may cause a fire or an electric shock.

8) Install the TV in a horizontal, stable location.
Connect between two clips on the back of the TV
and a wall, pillar, etc., with a sturdy tie and clip of
supplied accessories (- page 36).

• Use as short a tie as possible to ensure the TV is

stable.

• If the TV is not installed securely, it may lean or fall

over and cause an injury.

• To prevent injury, use the exclusive optional stand or

wall-hanging bracket to install this TV on the floor or
wall securely in accordance with a qualified
technician.

10cm min.

Clip

turdy tie

(as short as possible)

Clip

Clip

10) Precautions for installing on outdoor antenna

An outside antenna system should not be located in the
vicinity of overhead power lines, or other electric light or
power circuits.
If the antenna falls down or drops, it may cause an injury
or an electric shock.

Use

1) Never place hot objects or open flame sources,
such as lighted candles or nightlights, on or close
to the TV.

High temperatures can melt plastic and lead to fires.

Side view op view

T

9) Precautions for moving the TV

• When moving the TV, be sure to remove the plug
from the wall outlet and disconnect the antenna cable
and audio/video cables, any steady ties. A fire or an
electric shock may result if the power cord is
damaged.

• When carrying the TV, at least two people are
needed. Be sure to carry it upright.

• Never carry the TV with the screen facing up or down.

2) The apparatus shall not be exposed to dripping or
splashing and that no objects filled with liquids,
such as vases, shall be placed on the apparatus.

When liquids are spilled or small items are dropped
inside the TV, this may cause a fire or an electric shock.
If small objects drop inside the TV, turn off the TV and
remove the power plug from the outlet immediately and
contact a service technician.

3) Never insert objects (metal or paper) or pour water
inside the TV through ventilation holes and other
openings.

These items may cause a fire or an electric shock.
If these objects are inserted inside the TV, turn off the
TV and remove the power plug from the outlet
immediately and contact a service technician. Be
especially careful that children do not insert objects in
the TV.

4

Clip

Introduction

4) Never stand or climb on the TV.

Be especially careful in households with children to
prevent them through climbing on top of the TV.
It may move, fall over, break, become damaged or
cause an injury.

5) When the TV will not be used for a long period of
time, such as during vacation or travel, remove the
power plug from the wall outlet for safety.

• The TV is not completely disconnected from the

power supply line, as minute current is consumed
even when the ! Power switch is turned off.

• The Mains plug or an appliance coupler is used as the

disconnect device, therefore the disconnect device
shall remain readily operable.

6) Never pull on the power cord when removing the
plug from the wall outlet.

Always hold the plug firmly when removing it. If the
power cord is yanked, the cord may become damaged
and a fire or an electric shock may occur.

8) If there is thunder or lightning, never touch the
antenna cable or other connected cables.

You may suffer an electric shock.

Service

1) Never repair, modify or disassemble the TV by
yourself.

It may cause a fire or an electric shock. Consult a
service technician for inspection and repairs.

2) When a malfunction occurs, or if smoke or an
unusual odor comes from the TV, turn off the TV
and remove the power plug from the outlet
immediately.

Make sure that the smoke or smell has stopped, then
contact a service technician. If the TV is still used in this
condition, it may cause a fire or an electric shock.

7) Never cut, break, modify, twist, bunch up or bent the
cord or apply excessive force or tension to it.

Never place heavy objects on the cord or allow it to
overheat as this may cause damage, a fire or an electric
shock. Contact a service technician if the power cord is
damaged.

3) If the TV is dropped or the cabinet is broken, turn off
the TV and remove the power plug from the outlet
immediately.

If the TV is still power used in this condition, it may
cause a fire or an electric shock. If the cabinet is broken,
be careful when handling the TV to prevent an injury.
Contact a service technician for inspection and repair.

5

Introduction

4) When the TV reaches the end of its useful life, ask a
qualified service technician to properly dispose of
the TV.

Note:
The lamp unit contains a small amount of mercury.
Disposal of mercury may be regulated due to
environmental considerations.
Dispose of the used lamp unit by the approved method
for your area. For disposal or recycling information,
please contact your local authorities.

Cleaning

1) Remove the power plug before cleaning.

Never use solvents such as benzine or thinner to clean
the TV.

• These solvents may distort the cabinet or damage its

finish.

• If rubber or vinyl products remain in contact with the

TV for a long time, a stain may result.
If the cabinet becomes dirty, clean it with a soft, dry
cloth.
When cleaning the surface of the LCD display, wipe the
panel surface gently with a soft, dry cloth.

Important information

1) About LCD screen

• If you have the LCD screen facing to the sun, the LCD
screen will be damaged. Be aware of locating the TV
in the place such as window side or outside of the
room.

• Never press the LCD screen strongly or scratch it,
and never put anything on it. These actions will
damage the LCD screen.

2) About cabinet and LCD screen

Never spray volatile compounds such as insecticide on
the cabinet and LCD screen.
This may cause a discoloration or damage the cabinet
and LCD screen.

3) Some pixels of the screen do not light up

The LCD display panel is manufactured using an
extremely high level of precision technology, however
sometimes some pixels of the screen may be missing
picture elements or have luminous spots. This is not a
sign of a malfunction.

4) About Interference

The LCD display may cause interference in image,
sound, etc. of other electronic equipment that receives
electromagnetic waves (e.g. AM radios and video
equipment).

5) About using under the low temperature places

If you use the TV in the room of 0°C or less, the picture
brightness may vary until the LCD monitor warms up.
This is not a sign of a malfunction.

2) Periodically disconnect the power plug from the
outlet and check it.
If dust has collected on the power plug connectors,
clean off the dust with a dry cloth.

This dust may cause a fire due to reduced insulation on
the plug.

Clean here

6) About afterimage

If a still picture is displayed, an afterimage may remain
on the screen, however it will disappear.
This is not a sign of malfunction.

Exemptions

• Toshiba is not liable for any damage caused by fires, natural
disaster (such as thunder, earthquake, etc.), acts by third
parties, accidents, owner’s misuse, or uses in other improper
conditions.

• Toshiba is not liable for incidental damages (such as profit
loss or interruption in business, modification or erasure of
record data, etc.) caused by use or inability to use of product.

• Toshiba is not liable for any damage caused by neglect of
the instructions described in the owner’s manual.

• Toshiba is not liable for any damage caused by misuse or
malfunction through simultaneous use of this product and
the connected equipment.

6

Getting started

Connecting an antenna

Optimum reception of color requires a good signal and will
generally mean that an outdoor antenna must be used.

The exact type and positioning of the antenna will depend upon
your particular area.

Your Toshiba dealer or service personnel can best advise you
on which antenna to use in your area.

Before connecting the antenna cable, turn off all main power
switches.

VHF and/or
UHF antenna

Media Recorder

IN

OUT

Antenna cable (75 7 coaxial)
(not supplied)

300 7 twin-lead feeder

TV back view

Exploring your new TV

Installing the remote control batteries

Remove the battery cover.

Insert two R03 (AAA) batteries matching the –/+ polarities of
the battery to the –/+ marks inside the battery compartment.

Cautions:

• Dispose of batteries in a designated disposal area. Never
throw batteries into a fire.

• Attention should be drawn to the environmental aspects of
battery disposal.

• Never mix battery types or combine used batteries with new
ones.

Notes:

• If the remote control does not operate correctly, or if the
operating range becomes reduced, replace both batteries
with new ones.

• If the batteries are dead or if you will not use the remote
control for a long time, remove the batteries to prevent
battery acid from leaking into the battery compartment.

Antenna adaptor
(not supplied)

75 7 coaxial cable

Plug
(not supplied)

75 7
antenna
terminal

75 7 antenna
terminal

Effective range

within 5 m

7

Getting started

TV front and side panel controls

• You can operate your TV using the buttons on the side panel or the remote control. The back and side of the panel provide the

terminal connections to connect other equipment to your TV (- “Connecting your TV” pages 28 - 32).

• For the use of each control, see the pages in brackets.

Right side view TV front view Control panel

4

5

6

7
8

9

10

1 3 2

Headphones
(Not supplied)

11

1 4 (Timer LED) — Timer indicator (- page 20).
2 ! (Power LED) — Power indicator (- page 11).
3 (Remote sensor) — Point the remote control toward

this remote sensor (- page 7).

4 ! (Power on/Standby) — Press to turn the TV on/

standby (-page 11).

5 pBb (Program position) — When no menu is on-

screen, these buttons select the program position.
(- page 13).

Uu (MENU up/down) — When a menu is on-screen,
these buttons function as up/down menu navigation
buttons (- page 11).

6 2 – + (Volume) — When no menu is on-screen, these

buttons adjust the volume level (- page 10).
I i (MENU left/right) — When a menu is on-screen,

these buttons function as left/right menu navigation
buttons or adjust settings (- page 11).

7 MENU — Press to access the menu system (- page 11).
8 o (Input source selection) — When no menu is on-

screen, this button selects the input source (- page 21).
OK — When a menu is on-screen, this button functions

as the next menu navigation button (- page 11, 21).

9 o HDMI3 (input terminal) —High-Definition

Multimedia Interface input receives digital audio and
uncompressed digital video from an HDMI device
(- page 29).

10 o (2) (Video 2 input terminals) — Optional S-video

or standard video and standard audio inputs (- page 28).

11 D (Headphone jack) — For use with headphones (-

page 27).

8

TV back panel connections

12

13

15 16

Getting started

TV back view

* You can use the cable

holder to hold antenna
cable, video and audio
cables etc.

When moving the TV,

never hold this holder.

14

17

18

19 20 21 22

12 o (C1) (COMPONENT VIDEO INPUT terminals)

—High-definition component video and standard audio
inputs (- page 28).

13 o PC/HDMI1 (AUDIO) (input terminals) — PC

audio input terminals are shared with HDMI1 analog
audio input terminals, and their use can be configured in
the SET UP menu. (- page 29, 32).

14 o (C2) (COMPONENT VIDEO INPUT terminals)

— High-definition component video and standard audio
inputs (- page 28).

15 o (1) (Video 1 input terminals) — Optional S-video

or standard (composite) video and standard (analog)
stereo audio inputs (- page 28).

16 O WOOFER (VARIABLE) (output terminal) — For

use when connecting woofer system (variable) (- page

28).

17 O AUDIO (FIXED/VARIABLE) (output terminals)

— Standard audio outputs (fixed/variable) (- page 28).

Power cord

Cable holder*

18 O MONITOR (output terminals) — Standard video

and standard audio outputs (- page 28).

19 A (Antenna input terminal) — Analog antenna signal

input (- page 7).

20 o RGB/PC (input terminal) — For use when

connecting a personal computer (PC) (- page 32).

21 o HDMI1 (input terminal) — High-Definition

Multimedia Interface input receives digital audio and
uncompressed digital video from an HDMI device or
uncompressed digital video from a DVI device (- page

29).

22 o HDMI2 (input terminal) — High-Definition

Multimedia Interface input receives digital audio and
uncompressed digital video from an HDMI device
(- page 29).

9

Getting started

Learning about the remote control

Location of controls

To select device mode (T/R/D)*

*

T: TV mode
R:

REGZA-LINK mode

D: DVD mode

Number buttons (0-9)
(- pages 12, 20)(T/R/D)

To return to the previous program (T)
(

-

page 12)

Volume – + (T/R/D)
(These buttons adjust the volume level.)

TOP MENU To access top Menu (R/D)

-

• Menu  (T/R/D)(

• OK (T/R/D)(

-

page 11, 21)

page 11)

• MENU (T)

• DVD Menu (R/D)

• Teletext control buttons (T)(

-

page 24)

• To work interactive service control
on device (R)

Picture mode selection (T/R/D)
(

-

page 15)

Picture size selection (T/R/D)
(

-

page 14)

REGZE-LINK or D VD mode :

p r ess to EJECT
p r ess to STOP
p r ess to PL A Y
p r ess to P AUSE/STEP
p r ess to SKIP REVERSE
p r ess to FAST REVERSE
p r ess to FAST FORWARD
p r ess to SKIP FO R W ARD

TV
REGZA-LINK
D VD

1 2 3

4 5 6

Power on/Standby

(

-

page 11)

(T/R/D)

• Input source selection (T)(- page 21)
(TV, o1, o2, oC1, oC2, HDMI1, HDMI2,
HDMI3, PC)

• To select line input (R/D)

7 8 9

0

+

CONTENTS

MENU

P

-

T OP MENU

SET UP

(This button turns off/on the sound)

• Program position U u (T/R)(- page 12)

• Teletext U u (T)(- page 24)

• Double-window on/off (T) (- page 26)

• To display Contents menu (R)

• F G H Double-window picture/sound
selection (T)(- page 26)

Sound mute

SET UP To access Setup menu (R/D)

OK

• EXIT (T)(- page 11)

• To return to previous Menu (R/D)

D VD MENU

RETURN

EXIT MENU

• CALL (T)(- page 12)

•

Initial/index function for Teletext (T)(- page 25)

• TEXT Teletext on/text media window/off (T)
(- page 24)

• AUDIO Sound mode selection (R/D)

CALL

A UDIO

TEXT

When in TV mode :

T elet e xt function

(T/R/D)

Bass boost on/off (- page 19)
External Woofer on/off (- page 20)
Stereo/bilingual

selection (- page 18)
Pictu r e still ( - page 15)

T o r eveal concealed text

(- page 25)

T o hold a wanted page

(- page 25)

T o enlarge teletext display size

(- page 25)

To access sub-pages
(- page 24)

• T o select a page while viewing
a no r mal pictu r e

(- page 25)

• T o select the time display

(- page 25)

REGZA-LINK mode switch on the TV remote control allows the control of connected REGZA-LINK device being watched
(- page 22, 23).

Note:

These functions are dependent on the connected device. Not all the remote control buttons may be available. Please refer to the
owner’s manual for all the connected devices.

10

Getting started

Turning the TV on

Switching on the TV

Connect the power cord to a wall outlet, the ! power
indicator lights in red (standby mode).

1 Press 1 on the remote control or ! on the TV right side

panel. The ! power indicator lights in green.

Note:

If you watch black and white programs when the color system
mode is set to Auto, color noise may appear on the screen. In
this case select the appropriate Color system (For the system
of each country or region, refer to pages 13 and 35).

Switching off the TV

1

Press 1 on the remote control or ! on the TV right side
panel to switch to the standby mode.

Notes:

• When the TV will not be used for a long period of time, such

as during vacation or travel, remove the power plug from the
wall outlet.

• The TV will automatically turn itself off after approximately 15

minutes if it is tuned to a vacant channel or a station that
completes its broadcast for the day. This function does not
work in external input or Blue screen Off mode.
The TV will automatically turn itself off after approximately 2
hours if you do not operate the TV after turned on by on timer
function.

• If power is cut off while you are viewing the TV, the Last

Mode Memory function turns on the TV automatically when
power is applied again. If power is going to be off for a long
time and you are going to be away from your TV, unplug the
power cord to prevent the TV from turning on in your
absence.

Learning about the menu system

We suggest you familiarize yourself with the display charts
before using the menu system:

•Press M to display menu, then press  or  to select main

menu headings.

•Press  or  to select an item.

•Press  or  to select or adjust setting.

• Press Q to display the next menu.

•Press P, to close the menu display instantly.

•Press M, to return the previous menu.

• The menu display will disappear automatically, if you do
not make a selection for a while.

Note:

Depending on the input signal, selecting function or settings,
the items in the menu display may be different or unable to be
selected. Please refer to individual functional explanation.

Displaying the menu chart

1/2

3D Color management

Base color adjustment

Picture settings

Active Backlight Control
Cinema mode
Film Stabilization
meta brain PRO 100

MENU

Back Watch TV

Balance

WOW
Stable sound
Speaker
Bass boost
Bass boost level

MTS
Dual
Headphone

Headphone level

Bass
Treble

MENU

Back Watch TV

Language

Auto tuning
Manual tuning
AV connection
Picture position

MENU

Back Watch TV

Enable REGZA-LINK

TV Auto Input Switch
TV Auto Power
Auto Standby
Speaker Preference

MENU

Back Watch TV

Sleep timer

On timer
On timer Position

MENU

Back Watch TV

Teletext

Teletext language
Auto for mat
Blue screen
Side panel

MENU

Back Watch TV

menu

Picture settings
Active Backlight Control
Cinema mode
Film Stabilization
meta brain PRO 100

xvYCC selection xvYCC selection

MENU

SOUND
menu

MTS
Dual
Headphone

Headphone level

Bass
Tre bl e

MENU

SET UP
menu

Language
Auto tuning
Manual tuning
AV connection
Picture position

MENU

REGZA-LINK
menu

Enable REGZA-LINK
TV Auto Input Switch
TV Auto Power
Auto Standby
Speaker Preference

MENU

TIMER
menu

Sleep timer
On timer
On timer Position

MENU

FUNCTION
menu

Teletext
Teletext language
Auto format
Blue screen
Side panel

MENU


EXIT

Back Watch TV

SOUND 1/ 2

EXIT

Back Watch TV

SET UP

EXIT

Back Watch TV

REGZA-LINK

EXIT

Back Watch TV

TIMER

EXIT

Back Watch TV

FUNCTION

EXIT

Back Watch TV

OK

On
On Off
Off
On

Auto
Dual 1
Mode 1

0
0

English

OK
OK
OK
OK

On
On
On
On

TV Speakers

00:00
00:00

01

Auto

1
On
On

1

PICTURE 2/ 2


EXIT

SOUND 2/ 2

SOUND

EXIT

SET UP

EXIT

REGZA-LINK

EXIT

TIMER

EXIT

FUNCTION

EXIT

On

OK

OK

Off

On
On

0

OK

Off
On

On
70

Auto

Dual 1

Mode 1

0
0

English

OK
OK
OK
OK

On
On
On
On

TV Speakers

00:00

00:00

01

Auto

1
On
On

1

1/2

1/2

11

Getting started

Watching TV programs

Selecting the menu language

Choose from 9 different languages (English, Chinese (CS),
Malay, Thai, Vietnamese, Russian, Arabic, Persian or French)
for the on-screen display.

1 Press M, then press  or  to display SET UP menu.
2 Press  or  to select Language.
3 Press  or  to select the desired language.

SET UP

Language

Auto tuning
Manual tuning
AV connection
Picture position

MENU

EXIT

Back Watch TV

Changing the program position

1

Enter the desired program position number using the
Number buttons on the remote control.
For program positions below 10, use 0 and the required
number e.g., for program position 1.

2 You can also change the program position by using PU or

Pu.

The program position will be displayed on the screen with
the Mono/Stereo/Dual audio status.

Note:

The program position selection change between different
format channels takes several seconds.

Switching between two program positions

You can switch two program positions without entering actual
position number each time.

1 Select the first program position you want to view.
2 Select the second program position with the Number

buttons (0-9).

3 Press :. The previous channel will be displayed.

Each time you press :, the TV will switch back and forth
between the two program positions.

English

OK
OK
OK
OK

Displaying the on-screen information

1

Press K to display the following on-screen
information.

ABCD4

Stereo

The information will disappear in 6 seconds.

• Program position or external input mode selected

• Program skip on/off information

• Label (if set)

• Mono/Stereo/Dual audio status

2 To erase the display instantly, press K again.

Programming channels into the
TV’s channel memory

• First, use the Auto tuning function to preset all the active
channels in your area automatically. Then, arrange the
preset channels with the Manual tuning function so that you
can tune into only desired channels.

• Use the Manual tuning operation if desired channels cannot
be preset with the Auto tuning or if you would like to preset
channels to specific position numbers one by one.

Programming channels automatically

1

From the SET UP menu, press  or  to select Auto
tuning.

2 Press Q to display the Auto tuning menu.

Auto tuning

Press OK key to start.

!

EXIT for no change.

MENU

3 Press Q to start the automatic search.

The search will begin for all available stations.

Searching
Pos :2

EXIT

The slide bar will move along the line as the search
progresses.
If you make a mistake, simply repeat steps 1-3 to start
again from the beginning.

4 When the automatic search is completed, the TV will

automatically return to the first program position.

5 Press  or  to view the programmed position.

Note:

When you preset the program channel which sound of
broadcast transmission system adopts “M” system, the sound
system may not be tuned correctly if the radio waves transmit
badly. At that time, preset the channel by Manual tuning.
The countries such as Myanmar, Brazil, Chile, Colombia apply
to this case. See page 35 for more details.

EXIT

Back Watch TV

Auto tuning

Stop

12

Getting started

Manually setting channels in the channel
memory

1

From the SET UP menu, press  or  to select Manual
tuning.

2 Press Q to display the Manual tuning menu.

Press  or  to select the program position you want to
arrange.

Prog. Label

OK
MENU

Manual tuning

1

2
3
4
5
6

Select

Back Watch TV

EXIT

Sort

3 Press Q to display the breakdown menu.

Press  or  to select an item, then press  or  to
select the item as shown below.

Manual tuning

Program

A

1

B/G

OK

Store

MENU

ACE

A. Program position selection
B. Sound system (- page 35)
C. Color system (- page 35)

A : Automatic (factory set), P : PAL, S : SECAM
N4 : NTSC 4.43 (MHz), N3 : NTSC 3.58 (MHz)

If the color of a certain channel is abnormal, the
automatic color system selection (A) may have
malfunctioned, or sound system selection is wrong. In
such a case, select another color and/or sound system
(- page 35).

D. Program position skip selection

Press  or  to turn the program position skip option
on “8” or off “(”.
The program position will then be skipped when you
select channels with PU or Pu.
The “8” mark will appear beside a program position
number when you use the Number button on the
remote control.

E. Channel search operation

Press  to search up the band or  to search down the
band.
Press  or  repeatedly until your desired channel is
displayed.
When a station/satellite is found, it will be displayed.
NEVER PRESS ANY OTHER BUTTONS WHILE
THE SET IS TUNING.

F. Auto Fine Tuning

Press  or  to turn the Auto Fine Tuning option on
“9” or off “0”.
The Auto Fine Tuning function automatically corrects
slight fluctuations when receiving signals.

Manual Fine Tuning

While the Auto Fine Tuning turn off “0”, press  or
 so that the better picture and sound are obtained.

EXIT

Back Watch TV

G

BDF H

G. ANT ATT (Antenna attenuator)

Press  or  to turn the ANT ATT option on “&”
or off “6”, when visual interference occurs, set the
ANT ATT to on.

H. Label

Station labels appear under the program position
display each time you turn on the TV, select a channel,
or press K.

To change or create station labels:

1) Press  or  repeatedly to select a character for
the first space, then press .

*(blank space)

2) Repeat step 1) to enter the rest of the characters. If
you would like a blank space in the label name, you
must choose a blank space from the list of
characters.

Press Q to store your settings.

Sorting program position

• The TV is capable of receiving a number of different
channels depending upon where you live.

• Sorting program position is an easy way of storing each
channel on the program position of your choice.

Ex.: To swap channel ABCD (Prog.1) for channel MNOP
(Prog.4):

1 From the SET UP menu, press  or  to select Manual

tuning menu, then press Q.

2 Press  or  to select the channel ABCD, then press .

Prog. Label

OK
MENU

Manual tuning

1
2
3
4
5
6

Select

Back Watch TV

EXIT

ABCD

EFGH
IJKL
MNOP

Sort

3 Press  to select the new position “4”, then press .

Prog.

MENU

Manual tuning

Label

EXIT

EFGH
IJKL
MNOP

1
2
3
4
5
6

Store

Back Watch TV

ABCD

4 Press  to select the channel MNOP, then press .
5 Press  to select the new position “1”, then press .

6 Confirm new Manual tuning menu.

Prog. Label

OK
MENU

Manual tuning

EXIT

MNOP

EFGH
IJKL
ABCD

1
2
3
4
5
6

Select Sort

Back Watch TV

13

Using the TV’s features

Picture adjustment

Selecting the picture size

1

Press to display the picture size list, then press  or 
to select the appropriate picture size (or press
repeatedly to select required picture size directly).

Ex. HDMI 1080i input signal

Exact Scan
PC

Wide

Super Live 2
Cinema 2
4:3
Super Live 1
Cinema 1

Subtitle
14:9

2 Press Q.

Note:

Depend on the input signals, selectable picture size may be
different.

Wide

Use this setting when watching a wide-screen DVD, wide­screen video tape or a 16:9 broadcast (when available). Due to
the range of wide-screen formats (16:9, 14:9, 20:9 etc.), you
may see bars on the top and bottom of the screen.

4:3

Use this setting to view a true 4:3 broadcast.

Super Live 1

When receiving “4:3 format” signal, this setting will enlarge
the image to fit the screen by stretching the image vertically
and horizontally, holding the better proportions at the center of
the image.

Cinema 1

When watching “letterbox format” films/video tapes, this
setting will eliminate or reduce the black bars at the top and
bottom of the screen by zooming in and selecting the image
without distortion.

Super Live 2

When receiving “side panel format” signal, this setting will
enlarge the image to fit the screen by stretching the image
vertically and horizontally, holding the better proportions at
the center of the image. Also the black bars on the both sides
of the screen will eliminate or reduce.

Cinema 2

When watching “all sides panel format” films/video tapes, this
setting will eliminate or reduce the black bars on all the sides
of the screen by zooming in and selecting the image without
distortion.

Subtitle

When subtitles are included on a letterbox format broadcast,
this setting will raise the picture so that the most of text is
displayed.

Subtitle

14:9

Use this setting when watching a 14:9 broadcast.

14

Using the TV’s features

Exact Scan

When receiving 1080i or 1080p signal format, this setting will
display the image corrrectly without distortion or picture
clipping.

PC

Use this setting for PC via HDMI. When receiving 1080i,
1080p or 720p signal format of HDMI input, this setting will
display the image correctly without distortion or picture
clipping.

Notes:

• Using the special functions to change the size of the

displayed image (e.g. changing the height/width ratio) for
the purpose of public display or commercial gain may
infringe on copyright laws.

• If the aspect ratio of the selected format is different from the

one of the TV transmission or video program, it can cause a
difference in vision. Change to the correct aspect ratio
picture size.

• In the PC input mode (

selection is wide, normal or PC Media Window only.

• When using the PC input mode, the moving image quality

may be deteriorated.

• When using Exact Scan you may observe a shift in picture

position. This is due to the signal source and is not a defect
of the TV.

- page 21), the picture size

Adjusting the picture position

Adjustment to the position of the picture may be made to suit
your viewing preferences.

1 Press M, then press  or  to display the SET UP

menu.

2 Press  or  to select Picture position.

Language
Auto tuning
Manual tuning
AV connection

Picture position

MENU

SET UP

EXIT

Back Watch TV

English

OK
OK
OK
OK

3 Press Q, then press  or  to select an item you want

to adjust.

Picture position

Horizontal position

Vertical position
Reset

MENU

EXIT

Back Watch TV

0

0

OK

4 Press  or  to adjust the settings as required.

Horizontal position 0

Note:

When the picture format is in Wide or 4:3 mode, only the
Horizontal position can be adjusted.

Resetting the picture position

This function resets your picture position settings to the factory
settings.

1 From the Picture position menu, press  or  to

select Reset.

2 Press Q.

Using the picture still

•Press r to freeze the picture.
Even if an image is frozen on the TV screen, the pictures are

running on the input source. Audio continues to be output as
well.

To return to a moving picture, press

(Moving) (Still)

Notes:

• If you use this function except for the purpose of your private

viewing and listening, it may infringe the copyright protected
by the copyright laws.

• In the PC input mode (

available.

- page 21), this function is not

r again.

Selecting the picture mode

You can select the picture quality instantly among three preset
modes and one user-set mode.

• Press to select the desired picture quality.

Dynamic

Mode Picture quality

Dynamic bright and dynamic picture

Standard standard picture

Mild soft picture

Memory the picture quality you set

Note:

In the PC input mode (
If you select Dynamic, Standard or Mild, 3D Color

management automatically set to Off.

- page 21), this mode is not available.

15

Using the TV’s features

Adjusting the basic picture quality

1

Press M, then press  or  to display the PICTURE
menu.

Picture settings
Active Backlight Control
Cinema mode
Film Stabilization
meta brain PRO 100

xvYCC selection

MENU


EXIT

Back Watch TV

OK

On
On
Off
On

1/2

2 Press  or  to select the Picture settings menu, then

press Q.

Back light

Contrast
Brightness
Color
Tint
Sharpness

MENU

Back Watch TV

Picture settings 1/ 2

EXIT

100

100

50
50

0
0

3 Press  or  to select an item you want to adjust, then

press  or  to adjust the settings as required.

Contrast 100

Selection



Pressing



Back light darker brighter

Contrast lower higher

Brightness darker brighter

Color paler deeper

Tint reddish greenish

Sharpness softer sharper

Notes:

• The Tint may only be adjusted on NTSC signal.

• In the PC input mode (

- page 21), Color, Tint and

Sharpness modes are not available.

Activating the black stretch

This function increases the strength of dark areas of the picture
which improves definition.

1 Press M, then press  or  to display the PICTURE

menu.

Picture settings
Active Backlight Control
Cinema mode
Film Stabilization
meta brain PRO 100

xvYCC selection

MENU


EXIT

Back Watch TV

OK

On
On
Off
On

1/2

2 Press  or  to select the Picture settings menu, then

press Q.

3 Press  or  to select Black stretch on the 2nd page.

Black stretch

MPEG NR
DNR
Color Temperature

Picture settings 2/ 2

High

Low
Auto
Cool

4 Press  or  to select High, Off, Low or Middle.

Black stretch

Note:

In the PC input mode (

- page 26) this mode is not available.

(

- page 21), and double-window mode

High

Activating the MPEG NR (Noise Reduction)

If the receiving signal of MPEG is a mosquito (grained) noise
depending on the compression and conversion, the noise may
be reduced when using this function.

1 From the Picture settings menu, press  or  to

select MPEG NR on the 2nd page.

2 Press  or  to select Off, Low, Middle or High.

MPEG NR

Note:

In the PC input mode (

- page 26) this mode is not available.

(

- page 21), and double-window mode

High

Activating the DNR (Digital Noise
Reduction)

If the receiving signal is weak and the picture is blurry, the
picture may be improved when using this function.

1 From the Picture settings menu, press  or  to

select DNR on the 2nd page.

2 Press  or  to select Auto, Off, Low, Middle, or

High.

DNR

Note:

In the PC input mode (

- page 26) this mode is not available.

(

- page 21), and double-window mode

Auto

Selecting the color temperature

You can change the tone of the picture by selecting from three
preset color temperatures: Cool, Natural or Warm.

1 From the Picture settings menu, press  or  to

select Color Temperature on the 2nd page.

2 Press  or  to select mode you prefer.

Color Temperature

Cool: Lends a blue hue to the picture.
Natural: Neutral
Warm: Lends a red hue to the picture.

Cool

MENU

EXIT

Back Watch TV

16

Using the TV’s features

Adjusting the color management

You can adjust the picture color quality by selecting from 6
base color adjustments : Red, Green, Blue, Yellow,

Magenta or Cyan.

1 From the PICTURE menu, press  or  to select 3D

Color management on the 2nd page.

2 Press  or  to select On.

3D Color management

On

3 Press  or  to select Base color adjustment, then

press Q.

Base color adjustment

Hue

Saturation

Brightness

0

Red

Green
Blue
Yel l ow
Magenta
Cyan

Reset

MENU

Back Watch TV

EXIT

0

0
0
0
0
0

0

0

0

0

0

0

0

0

0

0

0

OK

4 Press  or  to select an item you want to adjust, then

press .

Hue0Saturation0Brightness

Red

0

5 Press  or  to select Hue, Saturation or

Brightness.

6 Press  or  to adjust the settings as required.

Notes:

• If you select 3D Color management Off mode, Base color

adjustment is not available.

• In the PC input mode (

24) and double-window mode (

- page 21), teletext mode (- page

- page 26) this mode is not

available.

Resetting the base color adjustment

The Reset function adjusts the base color adjustment to the
factory settings.

Note:

In the PC input mode (

24) and double-window mode (

- page 21), teletext mode (- page

- page 26) this mode is not

available.

Using the cinema mode

A movie film’s picture runs at 24 frames a second, whereas
movie software such as DVD, etc., that you enjoy watching on
television at home runs at 30 (NTSC) or 25 (PAL) frames a
second. To convert this signal to reproduce a smooth motion
and picture quality, select the On mode.

Effective signal and setup conditions:

• When the external video input mode is selected.

• When the input signal format is 480i, 576i and 1080i signals.

1 From the PICTURE menu, press  or  to select

Cinema mode.

2 Press  or  to select On or Off.

Notes:

• When a DVD movie with subtitle is playing back, this mode
may not work correctly.

• In the PC input mode (

- page 26) this mode is not available.

mode (

- page 21), and double-window

Using the meta brain PRO 100

This function improves the viewing quality of a motion
picture.

1 From the PICTURE menu, press  or  to select meta

brain PRO 100.

2 Press  or  to select On or Off.

Notes:

• If on-screen noise occurs when activated, select the Off
mode.

• In the double-window mode (
available.

- page 26), this mode is not

1 From the Base color adjustment menu, press  or 

to select Reset.

2 Press Q.

Using the active backlight control

In order to optimize screen visibility, the active backlight
control sets the screen brightness automatically according to
ambient light conditions.

1 From the PICTURE menu, press  or  to select

Active Backlight Control.

2 Press  or  to select On or Off.

Picture settings

Active Backlight Control

Cinema mode
Film Stabilization
meta brain PRO 100

xvYCC selection

MENU


EXIT

Back Watch TV

OK

On

On
Off
On

1/2

Film Stabilization

With Cinema mode and meta brain PRO 100 are set to
On, the Film Stabilization feature allows the adjustment of

motion smoothness.

1 From the PICTURE menu, press  or  to select Film

Stabilization.

2 Press  or  to select Smooth, Standard or Off.

Note:

In the PC input mode (

- page 24) and double-window mode (- page 26) , this

(
mode is not available.

- page 21), text media window mode

17

Using the TV’s features

Sound adjustment

Setting the MTS (Multi-channel TV Sound)

Auto mode

The MTS Auto mode automatically recognize stereo/bilingual
programs depending on the broadcast signal.

1 Press M, then press  or  to display the SOUND

menu.

MTS
Dual
Headphone

Headphone level

Bass
Tre bl e

MENU

SOUND 1/ 2

EXIT

Back Watch TV

2 Press  or  to select MTS, then press  or  to select

Auto or Mono.

Mono mode

If you experience noise or poor reception of any stereo/
bilingual program, set the MTS mode to Mono.
Noise will be reduced and reception may improve.

Note:

If you experience noise with a particular program on whose
channel reception is usually good, try setting MTS mode to
Auto, then switch

g to e Mono (monaural) (- page 18).

Selecting the dual 1 or dual 2 mode

You can hear only dual 1 or dual 2 sound selected, whenever
bilingual programs are received.

1 Press M, then press  or  to display the SOUND

menu.

2 Press  or  to select Dual, then press  or  to select

Dual 1 or Dual 2.

Notes:

• When the MTS setting is in Mono mode, the Dual menu is

not selectable.

• The Dual menu setting status remains even if the TV is

turned off.

Auto

Dual 1

Mode 1

0
0

Selecting the bilingual programs

1

When a bilingual program is received, j Dual appears.

2 Press g to select the sound to be heard. The sound

differs according to the transmission system: NICAM or
German stereo/bilingual broadcast.

Dual 1

Sound to be heard

Display

NICAM

German stereo/
bilingual broadcast

j Dual 1 Sub I sound Main sound
J Dual 2 Sub II sound Sub sound
e Mono Main sound —

Note:

These settings are not stored in the TV memory.

Adjusting the sound quality

1

Press M, then press  or  to display the SOUND
menu.

MTS
Dual
Headphone

Headphone level

Bass
Tre bl e

MENU

SOUND 1/ 2

EXIT

Back Watch TV

Auto

Dual 1

Mode 1

0
0

2 Press  or  to select an item you want to adjust, then

press  or  to adjust the settings as required.

Bass 0

Selection  Pressing

Bass weaker stronger

Treble weaker stronger

Balance decreases the right

channel

decreases the left
channel



Selecting the stereo programs

1

When a stereo program is received, d Stereo appears.

2 Press g to select the stereo/monaural mode.

d Stereo and e Mono appear cyclically on the screen.

Stereo

18

Using the TV’s features

Using the SRS WOW® surround sound

SRS WOW® is a special combination of SRS Labs audio
technologies that creates a thrilling surround sound experience
with deep, rich bass from stereo sound sources. Your TV’s
audio will sound fuller, richer and wider.

SRS WOW
FOCUS

®

consists of three features; SRS 3D®, SRS

®

, and SRS TruBass®, being turned on.

1 From the SOUND menu, press  or  to select WOW

on the 2nd page, then press Q.

Balance

WOW

Stable sound
Speaker
Bass boost
Bass boost level

MENU

SOUND 2/ 2

EXIT

Back Watch TV

OK

Off
On

On

0

70

2 Press  or  to select an item you want to adjust, then

press  or  to adjust the settings as required.

SRS 3D

FOCUS
TruBass

MENU

WOW

EXIT

Back Watch TV

SRS 3D: To turn the surround effect On or Off.
FOCUS: To turn the vocal emphasis effect On or Off.
TruBass: To select the desired bass expansion level

(Off, Low or High).

Notes:

• If the broadcast is monaural, the SRS 3D

work.

• WOW, SRS and

Inc.

• WOW technology is incorporated under license from SRS

Labs, Inc.

• The SRS WOW

from the speaker.

• This feature is not available through headphones.

l symbol are trademarks of SRS Labs,

®

effect is active only when the sound outputs

Off

On

High

®

effect does not

Activating the speaker

Use this function to turn the TV speakers off when you connect
an audio system (- page 28).

1 From the SOUND menu, press  or  to select

Speaker on the 2nd page.

2 Press  or  to select On or Off.

Selecting the woofer internal/external
mode

1

Press M, then press  or  to display the SET UP
menu.

Language
Auto tuning
Manual tuning
AV connection
Picture position

MENU

SET UP

EXIT

Back Watch TV

English

OK
OK
OK
OK

2 Press  or to select AV connection, then press Q to

display the AV connection menu.

AV connection

PC/HDMI1 audio

HDMI1 audio

HDMI setting

Woofer

Audio output

MENU

EXIT

Back Watch TV

PC

Digital

On

External

Fixed

3 Press  or  to select Woofer, then press  or  to

select Internal or External.

• Internal is to use the bass boost.

• External is to use an external woofer system.

Using the bass boost

When you select Internal Woofer from the AV connection
menu, you can set the bass boost level.

Using the stable sound

The Stable sound function limits the highest volume level to
prevent extreme changes in volume when the signal source
changes (for example, to prevent the sudden increase in
volume that often happens when a TV program switches to a
commercial).

1 From the SOUND menu, press  or  to select Stable

sound on the 2nd page.

2 Press  or  to select On or Off.

Note:

The Stable sound effect is active only when the sound outputs
from the speaker.

1 From the SOUND menu, press  or  to select Bass

boost on the 2nd page.

2 Press  or  to select On.

Balance
WOW
Stable sound
Speaker

Bass boost

Bass boost level

MENU

SOUND 2/ 2

EXIT

Back Watch TV

OK

Off
On

On

0

70

3 Press to  select Bass boost level.
4 Press  or  to adjust the Bass boost level.
5 To turn off the Bass boost, press  or  to display Bass

boost, then press  or  to select Off.

19

Using the TV’s features

Alternatively, you may adjust the bass boost level directly
using t.

1 Press

t

to display Bass boost level.

Bass boost 70

2 While the Bass boost display is on the screen, press 

or  to adjust the Bass boost level.

3 To turn off the Bass boost, press

t

to display Bass

boost Off.

Bass boost Off

Note:

The Bass Boost effect is active only when the sound outputs
from the speaker or an external woofer system.

Using an external woofer system

Connect an external woofer to the WOOFER output terminal
located on the rear of the TV (- page 28).

1 Select the woofer External mode from the AV

connection menu.

2 From the SOUND menu, press  or  to select

External Woofer on the 2nd page.

3 Press  or  to select On.
4 Press to  select External Woofer level.
5 Press  or  to adjust the External Woofer level.
6 To turn off the External Woofer, press  or  to select

External Woofer, then press  or  to select Off.

Alternatively, you may adjust the External Woofer level
directly using t.

1 Press

t

to display External Woofer level, then press

 or  to adjust the External Woofer level.

2 To turn off the External Woofer, press t to display

External Woofer Off.

Other features settings

Selecting the timer menu

The Timer is especially useful if you want the TV to turn itself
on or off after a selected period of time.

1 Press M, then press  or  to display the TIMER menu.

Sleep timer
On timer
On timer Position

MENU

TIMER

EXIT

Back Watch TV

2 Press  or  to select the required timer mode (Sleep

timer (Turn off the TV) or On timer).

3 Press the Number buttons (0-9),  or  to set the On or

Off delay time, e.g. on in 30 minutes and On timer
Position 3 selected.

4 Press P to exit the menu. When setting the On timer,

press  or  to select the On timer Position and enter
the program position number you want to watch. Set the
Standby mode by pressing 1 on the remote control.
Activation of the Timer is indicated by the green “On­timer indicator”, on the front of the TV (- page 8).

Notes:

• The TV will automatically turn itself off after approximately 2
hours if you do not operate the TV after turned on by on timer
function.

• If you press and hold
the timer display will set by 30 minutes, up to 12 hours 30
minutes.

 or  to set the On or Off delay time,

Using the auto format

When the TV receives a true HDMI signal picture and the auto
format is On, it will automatically be displayed in HDMI
signal format, irrespective of the TV’s previous setting.

00:00
00:00

01

Selecting the audio output

With the audio output function “Variable”, you can use the
TV’s remote controller to adjust the sound volume of the
external audio system connected (- page 28).

To select the sound volume from AUDIO output
terminals:

1 From the AV connection menu, press  or  to select

Audio output.

2 Press  or  to select Variable or Fixed.

Note:

Make sure the volume control of your audio amplifier is set to a
moderate listening level.

20

1 Press M, then press  or  to display the FUNCTION

menu.

Teletext
Teletext language
Auto for mat
Blue screen
Side panel

MENU

FUNCTION

EXIT

Back Watch TV

Auto

On
On

1

1

2 Press  or  to select Auto format, then press  or 

to select On or Off.

Using the TV’s features

Activating blue screen

With the blue screen function On, the screen will
automatically turn blue and the sound will be muted when no
signal is being received.

1 From the FUNCTION menu, press  or  to select

Blue screen.

2 Press  or  to select On or Off.

Note:

In the PC input mode (

24) or double-window mode (
available.

- page 21), teletext mode (- page

- page 26), this function is not

Adjusting the brightness of side panel

You can adjust the brightness of side panel in 14:9 or 4:3, etc.
mode.

1 From the FUNCTION menu, press  or  to select

Side panel.

2 Press  or  to adjust the settings as required.

Side panel

1

Selecting the video input source to
view

1 Press o or press Q on the remote control until the video

input mode list appears on the screen, then press  or 
to select appropriate input source (or press o on the TV
right side panel or o on the remote control repeatedly to
select required input source directly).

Ex. o

TV

1
2
C1
C2

HDMI1

REGZA-LINK

HDMI2
HDMI3

PC

Ex. PC VGA mode

PC VG A

2 Press Q.

o 1 (o (1), video 1 input) or o 1S (S-video input)
o 2 (o (2), video 2 input) or o 2S (S-video input)
o C1 (o (C1), COMPONENT VIDEO INPUT),
o C2 (o (C2), COMPONENT VIDEO INPUT),

HDMI1 (o HDMI 1 input),
HDMI2 (o HDMI 2 input),
HDMI3 (o HDMI 3 input),
PC (o RGB/PC, PC input)

Notes:

• When

oC1, oC2, PC or HDMI input is selected, the

MONITOR output terminals (

- page 28) output audio

signal only.

• When external video input mode is selected, Auto tuning
and Manual tuning in the SET UP menu are not available.

• When

o1, o2, oC1, or o C2 is selected, Manual setting

will appears in the SET UP menu.

• When PC is selected , PC Setting will appears in the SET
UP menu.

Setting the manual setting menu

1

Press M, then press  or  to display the SET UP
menu.

Language
Manual setting
AV connection
Picture position

MENU

SET UP

EXIT

Back Watch TV

English

OK
OK
OK

2 Press  or  to select Manual setting, then press Q.
3 Press  or  to select an item, then press  or  to

select the item as shown below.

Manual setting

Color system:Auto

A

EXT1

OK

Store

MENU

A. Color System

Confirm that color system is set to “A” (Auto). If not,
select “A” with  or .

B. Video label

The video label allows you to label each input source
for your TV.
To change or create video labels:

1) Press  or  repeatedly to select a character for
the first space, then press .

2) Repeat step 1) to enter the rest of the characters.
If you would like a blank space in the label name,
you must choose a blank space from the list of
characters.

3) Press Q to store your settings.

Note:

oC1 or oC2 is selected, Color System selection in the

When
Manual setting is not available.

EXIT

Back Watch TV

AB

*(blank space)

21

Using the TV’s features

Using REGZA-LINK

This feature uses CEC (Consumer Electronics Controls)
technology and allows the control of Toshiba REGZA-LINK
compatible devices from the TV remote control via HDMI
connection (- page 10).

Notes:

• Not all Toshiba products currently support REGZA-LINK.

• Please consult your local dealers for more information on the

availability of the REGZA-LINK compatible device.

REGZA-LINK one touch play

When connected device is turn on REGZA-LINK will
automatically detect the TV through the input selection. If the
TV is in standby it will be turn on automatically. This feature
is selected in the REGZA-LINK menu.

Note:

Even if the device is showing a menu the TV may automatically
show the video input source on-screen display.

REGZA-LINK system standby

This feature automatically turns the connected device into
standby when the TV goes into standby and conversely for the
TV to switch into standby when connected device goes into
standby.

REGZA-LINK system audio control

Using the Speaker Preference feature allows the TV remote
control to adjust the volume or mute the sound of the speakers
connected to the TV via an AV amplifier.

Ensure that the connected AV amplifier and REGZA-LINK
device are selected in the input source selection and that the

Speaker Preference is set to Amplifier in the REGZA­LINK setup menu.

Notes:

• When you turn on the AV amplifier, change its input source,

or adjust the sound volume, the sound will be output from
the AV amplifier’s speakers even if the TV Speakers has
been selected. Turn the TV to standby and on again to
output the sound from the TV’s speaker.

• The proper function may not work by operating AV Amplifier.

REGZA-LINK functions

When the Enable REGZA-LINK is set to On, it allows the
following functions to be enabled by setting them to On.

• TV Auto Input Switch

If a connected HDMI device displays an OSD menu or starts
playing video or audio, the TV will automatically switch to
the appropriate HDMI input.

• TV Auto Power

If a REGZA-LINK device is turned on or off, the TV turns
on or standby automatically.

• Auto Standby

If the TV is set to standby, the TV will send a message to
turn off the selected REGZA-LINK device connected to the
TV.

• Speaker Preference

From this item, you can set your audio output preference to
the TV speakers or the AV amplifier speakers. When this
item is set to Amplifier, the TV remote control can be used
to adjust or mute the volume of the audio. This item will be
grayed out unless a REGZA-LINK compatible AV
amplifier is connected.

Notes:

• When you turn on the AV amplifier, change its input source,

or adjust the sound volume, the sound will be output from
the AV amplifier’s speakers even if TV Speakers has been
selected. Turn the TV to standby and on again to output the
sound from the TV’s speakers.

• The above functions are dependent on the connected

device and TV setting.

• If you display double-window, you cannot choose Speaker

Preference in the REGZA-LINK and Speaker Preference
automatically set to off.

• If you display double-window, the sub input source list of the

REGZA-LINK will not appear.

• When you activate the TV Auto input switch in the REGZA-

LINK, the appropriate HDMI input will display on the window

with speaker sound turns on.

22

(continued)

Using the TV’s features

To set the REGZA-LINK

1

Press M and  or  to select the REGZA-LINK menu.

2 Press  or  to select Enable REGZALINK, then press

 or  to select On.

Enable REGZA-LINK

TV Auto Input Switch
TV Auto Power
Auto Standby
Speaker Preference

MENU

REGZA-LINK

EXIT

Back Watch TV

Note:

If you set Enable REGZA-LINK to Off, the all other items
will be grayed out.

On

On
On
On

TV Speakers

3 Press  or  to select the REGZA-LINK set up item you

want to use, and press  or  to select On/Off or the
desired speakers mode.

• TV Auto Input Switch: On/Off

• TV Auto Power: On/Off

• Auto Standby: On/Off

• Speaker Preference: TV Speakers/Amplifier/
Off (See details on the previous page.)

REGZA-LINK input source selection

When any devices using CEC technology has connected,
REGZA-LINK icon shows on the video input mode list.

To control the REGZA-LINK device

First select the HDMI input source with the desired REGZA­LINK device connected, then switch the mode on the remote
control to REGZA-LINK and press the available button on

the remote control (- page 10).

The TV features that can be controlled by the
connected device remote control are:

Power standby, Volume, Program channel, Sound mute, Input
selection, Number buttons, Previous program channel.

Note:

These functions are dependent on the connected device. Not
all the remote control buttons may be available. Please refer to
the owner’s manual for all the connected devices.

1 Press o or Q on the remote control, and a list will

appear on the screen showing modes and all stored
external equipment.

2 Press  to highlight the input source showing the

REGZA-LINK logo.

3 Press  and a sub input source list will appear showing

all connected REGZA-LINK equipment.

o :

1

TV

o 1
o 2
o C1
o C2

HDMI1
HDMI2
HDMI3
PC

CH4

DVD

AV Processor

2

Player

3

Recorder

4

PC

4 Use  or  to select appropriate input source, then press

Q.

Notes:

• This function depend on the devices connected.

• When the TV is switched on, it will take a few minutes for the

REGZA-LINK icon to appear in the list; when an HDMI cable
is removed, it will take a few minutes for the icon to
disappear.

• If the HDMI cable from connected device is changed or

HDMI cable from connected device setting are changed,
Enable REGZA-LINK in the REGZA-LINK menu may need
to be reset On.

23

Using the TV’s features

Teletext

This TV has a multi-page teletext memory, which takes a few
moments to load and it offers two ways of viewing Teletext
Auto and LIST which are explained below.

Setting up the teletext mode

To select a language for teletext:

The language 1-4 option enables the display of different
language when using Teletext.

1 Press M, then press  or  to display the FUNCTION

menu.

Teletext
Teletext language
Auto format
Blue screen
Side panel

MENU

FUNCTION

EXIT

Back Watch TV

2 Press  or  to select Teletext language, then press

 or  to select the required language.

• Language 1: English, German, Dutch, Flemish,

Russian, Byelorussian, Bulgarian, Ukranian, Lettish,
Lithuanian, Czech, Slovak, Estonian

• Language 2: Polish, German, Dutch, Flemish,

Estonian, Lettish, Lithuanian, French, Serbian,
Croatian, Slovenian, Czech, Slovak, Rumanian

• Language 3: English, French, Hebrew, Turkish,

Arabic

• Language 4: English, French, Hebrew, Turkish,

Farsi (Iranian/Persian)

To select teletext mode:

Select a channel position with the desired teletext service.

1 Press M, then press  or  to display the FUNCTION

menu.

2 Press  or  to select Teletext, then press  or  to

select Auto or LIST mode.

Note:

When you are watching the teletext program, SET UP menu
and FUNCTION menu are not selectable.

Auto

1
On
On

1

Teletext general information

d button:

Press d once to view teletext. Press again the screen will
split into two sections with the last channel viewed on the left
and the text page on the right (text media window mode). Press
again to return to normal TV mode. Program cannot be
changed until teletext is cancelled.

When you first press

d to access the text service, the first

page you see will be the initial page.
In Auto mode, this displays the main subjects available and

their relevant page numbers.
In LIST mode, you will see the page numbers currently stored

on the each color button.

Note:

If you press r while the text media window mode is activated,
this mode is not available on the teletext mode.

Sub-pages:

Once in this chosen page, if there are sub-pages they will
automatically load into memory without changing the one you
are reading. If there are many sub-pages, it will take a long
time for them all to load and this will depend on the speed with
which the broadcaster transmits them.

To access the sub-pages in memory, press l, then use PU
and Pu to view them.

Using Auto mode

There are two Modes: Auto will display FASTEXT, if
available. LIST will display your four favorite pages. In either
mode, as an alternative to the colored buttons, you can access
a page by entering a 3-digit number, using the Number
buttons on the remote control, or to advance to the next page,
press PU, to go back to the previous page press Pu.

To change between Auto and LIST, see above.

• Press

If FASTEXT is available, you will see 4 colored titles at the
bottom of the TV screen. To access any given subject, simply
press the relevant colored button on the remote control.

If FASTEXT is not available, you can access any page simply
by entering a 3-digit page number or pressing the
corresponding colored button.

For further information on your particular text system(s), see
the broadcast teletext index page or consult your local Toshiba
dealer.

d to access teletext.

100 Spor t 14:57:55

Green

Red

Yellow

SwimmingRacingBaseballFootball

Blue

24

Using the TV’s features

Using LIST mode

1

Press d to access teletext.

100 TEXT M00 14:58:55

100 200 300 400

Green

Red

The four choices at the bottom of the screen are now
number – 100, 200, 300 and 400, which have been
programmed into the TV’s memory.

Yellow

Blue

2 To view these pages, use the colored prompt buttons.

e.g. press the Green button to view page 200.

3 If you want to change these stored pages, press the

colored button for the color you want to change.
e.g. Press the Green button and enter the 3-digit number.

100 TEXT M00 14:58:59

100 250 300 400

This number will change in the top left of the screen and
in the colored highlight.

4 Press Q to store your choice. The bars at the bottom of

the screen will flash white.

5 You may view other pages by simply entering the 3-digit

page number – but NEVER press Q or you will lose the
favorite already stored.

Teletext buttons on the remote control

Below is an introduction to the teletext buttons on your remote
control and their functions.

d To display a page of teletext:

Press d to display teletext mode. Press again to the text
media window mode. Press again to return to normal TV
mode.

k To display an index/initial page:

In Auto-mode

Press k to access the index page. The one displayed is
dependant on the broadcaster.

In LIST-mode

Press k to return to the 100 page or initial page.

A To reveal concealed text:

Some pages cover topics such as quizzes and jokes. To
discover the solutions, press A.

B To hold a wanted page:

This function is included as it is part of the broadcast teletext
system but you will not need it as this TV allows you to control
the display of sub-pages.

C To enlarge the teletext display size:

Press C once to enlarge the top half of the page, press again
to enlarge the bottom half of the page. Press again to revert to
the normal size.

D To select a page while viewing a normal
picture:

When in teletext mode, if a page selection is made and then
D is pressed, a normal picture will be displayed. The TV
will indicate when the page is present by displaying the title
bar of the text page at the top of the screen. Press
the page.

Note:

It will not be possible to change program position while in
Teletext mode, you will have to cancel the teletext first by
pressing

d to return to a normal TV picture.

d to view

To select the time display:

If you press D while watching a normal TV broadcast,
you will see a time display from the broadcaster. It will remain
on the screen for about 5 seconds.

9:56 and 25 seconds p.m.

21:56:25

25

Using the TV’s features

Using the double-window

• The double-window function allows you to split the screen
into a Main and Sub window and watch two programs at the
same time. You can display the TV program or the video
input on the Main and Sub window.

• When you watch one channel simultaneously in the double­window mode, differences in image quality between the
Main picture and Sub-picture occurs (except for HDMI
mode).

• If a window displaying an HDMI input signal, the other
window is unable to select any HDMI input again.

Displaying the double-window

1

Press e to display the double-window.

Stereo

Main
window
source

4 ABCD

Main Picture Sub-Picture

AB

2 Select the TV program you want to watch.

Notes:

• When you select the TV program of the Sub-window, the
sound is monaural only.

• In the PC input mode (

- page 21) or teletext mode (-

page 24), this mode is not available.

• The still mode will be cancelled if it receives a different input
signal when changing program position or video mode is
selected, etc.

• If you display double-window, you cannot choose Speaker
Preference in the REGZA-LINK and Speaker Preference
automatically set to off.

• If you display double-window, the sub input source list of the

REGZA-LINK will not appear.

• When you activate the TV Auto input switch in the REGZA­LINK, the appropriate HDMI input will display on the window

with speaker sound turns on.

3 Press F G H w or W to select a program position or

video input source, or switch and adjust speaker sound for
each window (A, B).

4

Stereo

ABCD 2 EFGH

A B

• PUu, o: available for A

• r: A

• Speaker sound: A

• 2 – +: available for A

2 EFGH

Sub-window
source

4 ABCD

Stereo

2 EFGH

A B

• PUu, o: available for B

• r: B

• Speaker sound: A

• 2 – +: available for A

4 ABCD

Stereo

2 EFGH

A B

• PUu, o: available for B

• r: B

• Speaker sound: B

• 2 – +: available for B

4

Stereo

ABCD 2 EFGH

A B

• PUu, o: available for A

• r: A

• Speaker sound: B

• 2 – +: available for B

Selecting the headphone mode

You can select either Mode 1 or Mode 2.
Mode 1: Linked with the selected window
Mode 2: Linked with another window

1 Press M, then press  or  to display the SOUND

menu.

MTS
Dual
Headphone

Headphone level

Bass
Tre bl e

MENU

SOUND 1/ 2

EXIT

Back Watch TV

2 Press  or  to select Headphone, then press  or 

to select Mode 1 or Mode 2.

Auto

Dual 1

Mode 1

0
0

26

MTS
Dual

Headphone

Headphone level
Bass
Tre bl e

MENU

SOUND 1/ 2

EXIT

Back Watch TV

Auto

Dual 1

Mode 2

30

0
0

Using the TV’s features

Adjusting the headphone volume (Mode 2)

When you use the double-window, you can select the
Headphone level.

1 From the SOUND menu, press  or  to select

Headphone.
Press  or  to select Mode 2.

2 Press  or  to select Headphone level.

Press  or  to adjust the Headphone volume.

Headphone level 30

Using a headphone

Connect a headphone to the headphone jack on the right side
of the TV (- page 8).

When in a single window:

Headphone

mode

Mode 1 Sound comes out

Mode 2 Sound comes out

Headphone Speakers

(

2 – + is available.)

(Headphone level menu
is available.)

Headphone sound is the same as speaker sound.

No sound

Sound comes out
(

2 – + is

available.)

When in double-window:

Headphone

mode

Mode 1 A (or B)

Mode 2 B (or A)

Headphone Speakers

(

2 – + is available.)

(Headphone level menu
is available.)

No sound

A (or B)
(

2 – + is

available.)

A: Main window B: Sub-window

27

Connecting your TV

Side connections

You can connect a wide variety of auxiliary equipment via the
terminals located on the right side of the panel o (2) and
oHDMI3

Please always refer to the owner’s manual of the equipment to
be connected for full details.

Connection example

TV right side view

HDMI device

Back connections

Connection example

DVD video player

(with component

video outputs)

TV back view

Set Top Box

Audio system

(S-Video or Normal)

VCR

Woofer system with amplifier

VCR

(Recording)

DVI device

TV back view

• Before connecting any external equipment, turn off all main
power switches.

• The unauthorized recording of television programs, DVDs,
video tapes and other materials may infringe upon the
provisions of copyright law.

• If you connect both of the S-VIDEO input terminal and
VIDEO input terminal, the S-VIDEO signal will appear on

Camcorder Camcorder with

• To select the side inputs, press and hold o until the video

input mode list appears on the screen, then press  or  to
select o2 or oHDMI3 (- page 21), then press Q.

• Before connecting any external equipment, turn off all main
power switches.

• If you connect both of the S-VIDEO input terminal and
VIDEO input terminal, the S-VIDEO signal will appear on
the screen (display changes to o 2S).

• You can enjoy Video Games with this TV. However
shooting games, where the player shoots at a target on the
TV screen with a light gun, may not work because of the
LCD Color TV properties.

• oHDMI3 on the side panel and oHDMI1/2 on the back
can be connected to the REGZA-LINK compatible device to
enjoy the REGZA-LINK features, see page 30.

• Please consult your local dealers for more information on
the availability of the REGZA-LINK compatible device.

Video Games

S-Video

the screen (display changes to o 1S).

• The COMPONENT VIDEO INPUT consists of three
component video signals (Y, P
the best picture performance. These terminals can only be
used with the component video compatible equipment e.g.
DVD video player, etc.

• Additional equipment and cables shown are not supplied
with this TV.

HDMI device

B/CB, PR/CR) and provides

28

Connecting your TV

Connecting an HDMI or DVI device

• When turning on your electronic components, turn on the
TV first, and then the HDMI or DVI device.

• When turning off your electronic components, turn off the
HDMI or DVI device first, and then the TV.

• This TV may not be compatible with features and/or
specifications that may be added in the future.

• This TV is only operable with L-PCM on 32/44.1/48 kHz
and 16/20/24 bits. If there is no sound when using HDMI,
use the analog audio cables to connect the TV and the HDMI
device, and select Analog in HDMI1 audio of the AV
connection menu (- page 31).

• This TV is able to connect with HDMI devices. But it is
possible that some HDMI devices may not operate properly
with this TV.

Connecting an HDMI or DVI device

The HDMI input on your TV receives digital audio and
uncompressed digital video from an HDMI device or
uncompressed digital video from a DVI device.

This input is designed to accept HDCP program material in
digital from EIA/CEA-861/861D compliant consumer
electronic devices (such as a set top box or DVD player with
HDMI or DVI output).

The HDMI input is designed for best performance with 1080i
(50 Hz/60 Hz) and 1080p (50 Hz/ 60 Hz) high-definition video
signals, but will also accept and display 480i, 480p, 576i, 576p,
720p (50 Hz/60 Hz) and VGA signals.

• HDMI: High-Definition Multimedia Interface

• DVI: Digital Video Interface

• HDCP: High-bandwidth Digital Content Protection

• EIA/CEA-861/861D compliance covers the transmission of
uncompressed digital video with high-bandwidth digital
content protection, which is being standardized for
reception of high-definition video signals. Because this is an
evolving technology, it is possible that some devices may
not operate properly with the TV.

• VGA: VESA 640 5 480 @ 60 Hz

• L-PCM: Linear-Pulse Code Modulation

Note:

Some of legacy HDMI sources may not work properly with your
latest HDMI TV, due to the adoption of a new standard. Please
try to disconnect your HDMI cable first and then to set Off the
following three options (Lip Sync, Deep Color, xvYCC). Your
legacy HDMI source should operate properly with your TV.

- page 31).

(

Connecting an HDMI device

One HDMI cable (type A connector)

TV back view

HDMI device

VIDEO AUDIO

LR

IN

OUT

HDMI OUT

For proper operation, it is recommended that you use a short
HDMI cable.

HDMI cable transfers both video and audio.

The HDMI3 terminal is located at the side of the TV.

Connecting a DVI device

One HDMI (type A connector)-to-DVI adapter cable and
audio cables

TV back viewTV back view

DVI device

VIDEO AUDIO

LR

IN

OUT

HDMI (type A connector)-to-DVI adapter cable

The recommended HDMI-to-DVI adapter cable length is 2m.

Standard analog audio cables

An HDMI-to-DVI adapter cable transfers only video.

Separate analog audio cables are required.

Note:

HDMI, the HDMI logo, and High-Definition Multimedia
Interface are trademarks or registered trademarks of HDMI
Licensing, LLC.

DVI

OUT

29

Connecting your TV

REGZA-LINK connection

You can control the basic functions of connected audio/video devices using the TV’s remote control if you connect a REGZA­LINK compatible audio receiver or playback device. For an explanation of setup and operations, see pages 22 – 23.

TV lower back panel

AV Amplifier

Playback device

Before controlling the device(s):

• After completing the above connections, set the REGZA­LINK menu as you desire (- page 23).

• The connected devices must also be set. For details, see the
owner’s manual for each device.

• The REGZA-LINK feature uses the CEC technology as
regulated by the HDMI standard.

• The HDMI3 terminal is located at the side of the TV.

Playback device

Notes:

• If several devices are connected, REGZA-LINK feature may

not operate properly.

• For proper operation, it is recommended that you use HDMI

cables with the HDMI Logo ( ).

• This feature is limited to models incorporating Toshiba’s

REGZA-LINK. However, Toshiba is not liable for those
operations. Refer to the individual owner’s manuals for
compatibility information.

30

Connecting your TV

Selecting the PC/HDMI1 audio mode

You can select PC audio or HDMI audio when using this
function (- page 29).

1 Press M, then press  or  to display the SET UP

menu.

Language
Manual setting
AV connection
Picture position

MENU

SET UP

EXIT

Back Watch TV

English

OK
OK
OK

2 Press  or  to select AV connection, then press Q

to display the AV connection menu.

AV connection

PC/HDMI1 audio

HDMI1 audio

HDMI setting
Woofer
Audio output

MENU

EXIT

Back Watch TV

PC

Digital

OK

External

Fixed

3 Press  or  to select PC/HDMI1 audio, then press 

or  to select PC or HDMI1.

Setting the HDMI1 audio mode

Using the HDMI setting

HDMI (Deep Color), if available from the DVD source, will
subtly enhance the color. Some older DVD players may not
display color correctly, if so switch the feature to Off. Lip

Sync can syncronize the sound and picture.

1 From the AV connection menu, press  or  to select

HDMI setting and press Q.

2 Press  and  to select an option, then  or  to adjust

the settings.

HDMI setting

Deep Color
xvYCC

Lip Sync

MENU

EXIT

Back Watch TV

• Deep Color: On

This feature allows to HDMI source to increase available
colors bits within the boundaries defined by the RGB or
YCbCr color space.

• xvYCC: On

This feature expands the acceptable color range (limits) in
the HDMI signals, then allows sending wider color signals
from HDMI source.

• Lip Sync: On

This option activates an auto audio/video display timing
adjustment function that allows HDMI source devices to
accurately perform synchronization automatically.

Off
Off

On

You can select sound of an HDMI or DVI device connected to
the HDMI input terminals (- page 29) from three modes:
Auto, Digital or Analog.

Note:

This function is available only when the PC/HDMI1 audio mode
is set to

HDMI1.

1 From the AV connection menu, press  or  to select

HDMI1 audio.

o

PC/HDMI1 audio

HDMI1 audio

HDMI setting
Woofer
Audio output

MENU

AV connection

HDMI1

Auto

OK

External

Fixed

EXIT

Back Watch TV

2 Press  or  to select Auto, Digital or Analog.

xvYCC selection

The color range xvYCC is an international standard and
enables a wider color range than conventional video
applications.

If the xvYCC selection is set to Auto, your TV will
automatically detect image supported xvYCC.

When the xvYCC in the HDMI setting menu is set to On, it
allows this function to be selectable.

1 From the PICTURE menu, press  or  to select

xvYCC selection.

2 Press  or  to select On, Off or Auto.

Notes:

• HDMI, the HDMI logo, High-Definition Multimedia Interface

and Deep Color are trademarks or registered trademarks of
HDMI Licensing, LLC.

• All above HDMI settings are available in the HDMI input

mode and need proper HDMI source device. If HDMI source
products does not support these features, the TV may not
work properly by activating these features.

• If your HDMI connection is capable of 1080p and/or your TV

is capable of refresh rates greater than 60 Hz or supports
Deep Color
Conventional HDMI/DVI cable may not work properly with
this mode.

TM

, you will need a Category 2 cable.

31

Connecting your TV

Connecting a computer

To connect a PC to the RGB/PC terminal on the TV:

An analog RGB (15 pin) computer cable can be connected.

TV back view TV back view

Mini D-sub 15 pin

Computer

RGB PC cable

Conversion adapter
(if necessary)

Audio cable for PC-to-TV connection

Connect a PC cable from the computer to the o RGB/PC
terminal on the back of the TV.

The following signals can be displayed:

• VGA: VESA 640 5 480 @ 60/75 Hz

• SVGA: VESA 800 5 600 @ 60/75 Hz

• XGA: VESA 1024 5 768 @ 60/70/75 Hz

• W-XGA: VESA 1280 5 768 @ 60/75 Hz

• W-XGA: VESA 1360 5 768 @ 60 Hz

• S-XGA: VESA 1280 5 1024 @ 60/75 Hz

However, these signal formats are converted to match the
number of pixels of the LCD panel.

Therefore, the TV may not display small text properly.

Notes:

• Some PC models cannot be connected to this TV.

• Certain PC signal formats may not be detected correctly.

• There is no need to use an adapter for computers with DOS/

V compatible mini D-sub 15 pin terminal.

• A bar may appear at the edges of the screen, or parts of the
picture may be obscured depending on some signals. This
is not the malfunction.

• If the edges of the picture are stretched, readjust the picture
position adjustments in the PC Setting menu.

• Depending on the specification of the PC you are playing
the DVD-Video on, and the DVD’s title, some scenes may be
skipped, or you may not be able to pause during multi-angle
scenes.

Signal names for mini D-sub 15 pin connector

Pin assignment for RGB/PC terminal

5
10

15 11

1

6

Pin No. Signal name Pin No. Signal name

1R9NC

2 G 10 Ground

3B11NC

4 NC (not

12 NC

connected)

5 NC 13 H-sync

6 Ground 14 V-sync

7 Ground 15 NC

8 Ground

To connect a PC to the HDMI terminal on the TV:

When connecting a PC to the HDMI terminal on the TV, use
an HDMI-to DVI adapter cable and analog audio cables.

If connecting a PC with an HDMI terminal, use an HDMI cable

(type A connector). Separate analog cables are not necessary.

TV back view TV back view

Audio cable
for PC-to-TV

Computer

The HDMI input can accept and display VGA, 480i, 480p,
576i, 576p, 720p, 1080i, and 1080p signal formats.

Notes:

• The edges of the images may be hidden.

• If receiving a 720p, 1080i, or 1080p signal program, PC

mode scales the video to display the entire picture within the
borders of the screen (e.g. no overscanning) (

connection

- page 14).

32

Connecting your TV

Using the PC setting

• In the PC input mode, you cannot select the Color, Tint,
Sharpness, Black stretch, MPEG NR and DNR in the
Picture setting menu, 3D color management, Active
backlight control and Cinema mode (- page 16, 17).

• In the PC input mode, the Manual setting (- page 21) is
not displayed.

• First press o until the video input mode list appears on the
screen, then press  or  and Q in order to select the PC
input mode (- page 21).

• This function may not be available for some signal or if no
signal is received.

• The optimum points of the clock phase and sampling clock
adjustments may be incomprehensible according to the
input signals.

Adjusting the picture size/position

1

Press M, then press  or  to display the SET UP
menu.

2 Press  or  to select PC Setting.

Language
AV connection

PC Setting

MENU

SET UP

EXIT

Back Watch TV

3 Press Q to display the PC Setting menu.

Horizontal position

Horizontal width
Vertical position
Vertical height
Clock phase
Sampling clock

MENU

PC Setting 1/ 2

EXIT

Back Watch TV

4 Press  or  to select an option you want to adjust. Press

 or  to adjust the settings as required.

Horizontal position 0

English

OK
OK

0

0
0
0
0
0

Adjusting the clock phase of the picture

If the clock phase, which synchronize the PC signal and LCD
display, is not optimized, the picture will blur.

This function enables you to adjust clock phase and display a
clear picture.

1 From the PC Setting menu, press  or  to select

Clock phase.

2 Press  or  to obtain a clear picture.

Clock phase 0

Adjusting the sampling clock

If the sampling clock does not match with the dot clock
frequency of the PC, blurred picture detail will occur, or screen
width will change, or drift patterns in vertical lines may be
apparent.

This function enables you to adjust it and optimize the picture.

1 From the PC Setting menu, press  or  to select

Sampling clock.

2 Press  or  to optimize the picture.

Sampling clock 0

Resetting the PC setting

The Reset function adjusts the PC Setting to the factory
settings.

1 From the PC Setting menu, press  or  to select

Reset on the 2nd page.

Reset

MENU

Back Watch TV

PC Setting 2/ 2

EXIT

0

OK

2 Press Q.

PC Media Window

This feature displays another smaller window screen allowing
a broadcast program to be viewed at the same time as a
connected PC.

1 Press to display the picture size list, then press  or 

to select the PC Media Window (or press repeatedly)
and press Q. The screen will show the picture from a
connected PC and the last broadcast channel being
viewed.

2 You can also change the program position by using PU or

Pu.

Note:

When a PC is connected using HDMI none of these functions
will be available.

33

Reference section

Troubleshooting

Before calling a service technician, please check the following
table for a possible cause of the symptom and some solutions.

Symptom and solution

TV will not turn on

• Make sure the power cord is plugged in, then press !

1.

and

• The remote control batteries may be dead. Replace the
batteries.

No picture, no sound

• Check the antenna connections.

No sound, picture OK

• The sound may be muted. Press Y, y or U.

• The station may have broadcast difficulties. Try another
channel.

• Check that the Speaker function in SOUND menu is
properly set.

Poor sound, picture OK

• The station may have broadcast difficulties. Try another
channel.

Poor picture, sound OK

• Check the antenna connections.

• The station may have broadcast difficulties. Try another
channel.

• Adjust the PICTURE menu.

Poor reception of broadcast channels

• Check the antenna connections.

• The station may have broadcast difficulties. Try another
channel.

• Make sure the Color system is properly set.

Teletext problems

• Check the antenna connections.
Good performance of text depends on a good strong
broadcast signal.

Some pixels of the screen do not light up

• The LCD display panel is manufactured using an
extremely high level of precision technology, however,
sometimes some pixels of the screen may be missing
picture elements or have luminous spots. This is not a sign
of a malfunction.

The brightness of the screen comes down, or flickers
of the screen are caused, or some parts of the screen
do not light up.

• When you just buy and start to use this TV, a flickering
may be caused in the screen. In this case, switch off the
TV, then switch on it again to cure the condition.

• The cold cathode fluorescent lamp used for the back light
on this TV has longevity. When the brightness of the
screen comes down, or the flickers of the screen are
caused, or some parts of the screen do not light up, it may
reach the end of its life. Contact a service technician.

The picture brightness varies when you display
switch the TV on.

• If you switch the TV on at 0°C and under, wait until the
warms up.

Multiple images

• The station may have broadcast difficulties. Try another
channel.

• Antenna reception may be poor. Use a high directional
outdoor antenna.

• Check if the direction of the antenna has changed.

Poor color or no color

• The station may have broadcast difficulties. Try another
channel.

• Adjust the Tint and/or Color in the PICTURE menu.

The remote control does not operate

• Remove all obstructions between the remote control and
the remote control sensor on the TV.

• The remote control batteries may be dead. Replace the
batteries.

• Check that the TV /REGZA-LINK/DVD switch on the
remote control is properly set.

No REGZA-LINK operation

• Depending on the connected REGZA-LINK compatible
devices, not all the REGZA-LINK feature is available.

• Make sure the HDMI cables with HDMI logo are used.

• When the connected REGZA-LINK device does not work
correctly after you have changed setting of the device, turn
off your TV and unplug the power cord, then plug and turn
on again.

• If several devices are connected, REGZA-LINK feature
may not operate properly.

• Read the owner’s manual furnished with the connected
REGZA-LINK device.

HDMI problems

• For HDMI cables

Make sure the HDMI cables with the HDMI Logo
( ) are used.

• For HDMI Deep Color

You should need to use Category 2 cable to work
properly. Normal HDMI cable or DVI cable may not work
with this option.

• For Legacy HDMI source

Some of legacy HDMI sources may not work properly
with latest HDMI TV products, due to new standard
adoption. Please try to set Off the HDMI settings
(Lip Sync, Deep Color, xvYCC). Your legacy HDMI
source should operate properly with this TV products.

TM

34

Reference section

Broadcast system

Broadcast transmission systems of each
country or region

Asia M.E.

Country or region Color Sound

Bahrain, Kuwait, Israel, Oman,
Qatar, United Arab Emirates,
Yemen, etc. Indonesia, Malaysia,
Singapore, Thailand, etc.

China PAL D/K

China Hong Kong PAL I

Iraq, Islamic Republic of Iran,
Lebanon, Saudi Arabia, etc.

Russian Federation, etc. SECAM D/K

Myanmar, etc. NTSC M

Oceania

Country or region Color Sound

Australia, New Zealand, etc. PAL B/G

Africa

Country or region Color Sound

Republic of South Africa, etc. PAL I

South America

Country or region Color Sound

Argentina, Paraguay, Uruguay, etc. PAL N

Brazil PAL M

Chile, Colombia, etc. NTSC M

Note:

PAL, SECAM and NTSC 3.58 (MHz) are different color signal
broadcast transmission systems applicable to different
countries or region. NTSC 4.43 (MHz) is used in special VCRs
to playback NTSC recorded video tapes through PAL
television equipment.

PAL B/G

SECAM B/G

Specifications

LCD color television

Model

52Z3500A, 52Z3500E, 52Z3500T,
57Z3500A, 57Z3500E, 57Z3500T

Power source

52/57Z3500A: 220V-240V, AC 50 Hz
52/57Z3500E: 220V-240V, AC 50/60 Hz
52/57Z3500T: 110V-240V, AC 50/60 Hz

Power consumption

52Z3500A/E/T: 338W, <1W (standby)
57Z3500A/E/T: 474W, <1W (standby)

Dimensions

52Z3500A/E/T: 1280 mm (W) 847 mm (H) 390 mm (D)
57Z3500A/E/T: 1365 mm (W) 896 mm (H) 390 mm (D)

Mass (Weight)

52Z3500A/E/T: 44.8 kg
57Z3500A/E/T: 57.9 kg

Television system (Antenna input)

Channel coverage:

PAL B/G (CCIR) VHF 2 - 12

UHF 21 - 69
CATV X - Z+2, S1 - S41

PAL I (UK) VHF -

UHF 21 - 69
CATV -

PAL D/K (CHINA) VHF 1 - 12

UHF 13 - 57
CATV Z1 - Z38

SECAM B/G (CCIR) VHF 2 - 12

UHF 21 - 69
CATV X - Z+2, S1 - S41

SECAM D/K (OIRT) VHF 1 - 12

UHF 21 - 69
CATV X1 - X19

NTSC M (US) VHF 2 - 13

UHF 14 - 69
CATV A6 - A1, A - W, AA -

ZZ, AAA, BBB

NTSC M (JAPAN) VHF 1 - 12

UHF 13 - 62
CATV M1 - M10, S1 - S41

Special RF signal:

NTSC 4.43 color system 5.5/6.0/6.5 MHz sound system
PAL 60 Hz color system 5.5/6.0/6.5 MHz sound system

COMPONENT VIDEO INPUT terminals (the signal
format)

480i, 480p, 576i, 576p, 720p (50/60 Hz), 1080i (50/60 Hz)
(These signal formats are converted to match the number of
pixels of the LCD panel.)

Color system

PAL, SECAM, NTSC 3.58/4.43

Aspect ratio

16 : 9

Visible size (diagonal)

52Z3500A/E/T: 132.1 cm
57Z3500A/E/T: 144.8 cm

Number of pixels

1920 (H) dots 5 1080 (V) dots

Audio power

10 W + 10 W (10% THD)

Speakers

Main 100 mm (Diameter) 2 pcs

35

Reference section

Input/Output terminals Operating condition

o

(1) Input

4 pin S-video
Phono jacks A/V

o (2) Input (Side)

4 pin S-video
Phono jacks A/V

Temperature 0°C - 35°C
Humidity 20% - 80% (No moisture condensation)

Supplied accessories

Owner’s manual (1), Remote control (1), Batteries (2),
Clip (1)

o (C1) Input

Component video Y, P
Phono jacks Audio L/Mono + R

B/CB, PR/CR

This is used to fix the TV to a wall, pillar, etc. (

o (C2) Input

Component video Y, P
Phono jacks Audio L/Mono + R

O MONITOR Output

Phono jacks A/V

O AUDIO Output

Audio L + R (Fixed/Variable)

B/CB, PR/CR

• Design and specifications are subject to change without
notice.

• Never service or remodel the TV by yourself. It may expose
you to a fire hazard or dangerous voltages.

O WOOFER Output

Phono jacks Bass Line out

(Variable)

o RGB/PC Input

Mini D-sub 15 pin Analog RGB

o PC/HDMI1

(AUDIO)

Input
Phono jacks Audio L+R

o HDMI1 Input (type A)

19 pin A/V Digital

o HDMI2 Input (type A)

19 pin A/V Digital

o HDMI3 Input (type A) (Side)

19 pin A/V Digital

Headphone jack 3.5 mm (Diameter) stereo

- page 4).
