SQPB

Video Cassette Recorder

W-528

W-522

W-422

OWNER’S MANUAL

SAFETY PRECAUTIONS

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN

OR MOISTURE. DANGEROUS HIGH VOLTAGES ARE PRESENT INSIDE THE ENCLOSURE. DO NOT OPEN THE CABINET. REFER SERVICING TO QUALIFIED PERSONNEL ONLY.

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

Product Name: Video Cassette Recorder

Model Number: W-528/ W-522/ W-422

FCC Notice: “Declaration of Corformity”.

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful Interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Contact: Toshiba America Consumer Products, Inc.

Address: 1420 Toshiba Drive, Lebanon, TN 37087

Telephone: 615-449-2360

User Installer Caution: Changes or modification made to this equipment not expressly approved by Toshiba Corporation or parties authorized by Toshiba Corporation could void the user’s authority to operate the equipment.

Note to CATV system installer:

This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.

Copyright

It is permissible to record television programs, film, video tapes and other material only in the event that third party copyrights and other rights are not violated.

In the spaces provided below, record the Model and Serial No. located at the rear of your video cassette recorder.

Model No.



Serial No.

Retain this information for future reference.

2

IMPORTANT PRECAUTIONS

Save Original Packing Materials

The original shipping carton and packing materials will come in handy if you ever have to ship your VCR. For maximum protection, repack the set as it was originally packed at the factory.

Avoid Volatile Liquid

Do not use volatile liquids, such as an insect spray, near the unit.

Do not leave rubber or plastic products touching the unit for a long time. They will mar the finish.

Moisture Condensation

Never operate this unit immediately after moving it from a cold location to a warm location. When the VCR is exposed to such a change in temperature, moisture may condense on the cylinder inside, one of its most crucial internal parts. To prevent the VCR from possible damage, do not use the unit for at least 2 hours when there is an extreme or sudden change in temperature.

Compatibility

This video cassette recorder (VCR) is compatible with any other VCR bearing the mark. HQ VHS equipment is also compatible with existing, non-HQ VHS equipment.

As an ENERGY STAR® Partner, TOSHIBA has determined that this product or product model meets the ENERGY STAR® guidelines for energy efficiency.

INTRODUCTION

3

IMPORTANT SAFETY

INSTRUCTIONS

CAUTION: PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS GIVEN IN THIS OWNER’S MANUAL AND THOSE MARKED ON THE UNIT. RETAIN THIS BOOKLET FOR FUTURE REFERENCE.

This set has been designed and manufactured to assure personal safety. Improper use can result in electric shock or fire hazard. The safeguards incorporated in this unit will protect you if you observe the following procedures for installation, use and servicing. This unit is fully transistorized and does not contain any parts that can be repaired by the user.

DO NOT REMOVE THE CABINET COVER, OR YOU MAY BE EXPOSED TO DANGEROUS VOLTAGE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL ONLY.

1. Read owner’s manual

After unpacking this product, read the owner’s manual carefully, and follow all the operating and other instructions.

2. Power Sources

This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your product dealer or local power company. For products intended to operate from battery power, or other sources, refer to the operating instructions.

3. Grounding or Polarization

This product may be equipped with a polarized alternating current line plug (a plug having one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.

4. Ventilation

Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the product and to protect it from overheating, and these openings must not be blocked or covered. The openings should never be blocked by placing the product on a bed, sofa, rug or other similar surface. This product should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions have been adhered to.

5. Heat

The product should be situated away from heat sources such as radiators, heat registers, stoves, or other products (including amplifiers) that produce heat.

4

6.Water and Moisture

Do not use this product near water - for example, near a bath tub, wash bowl, kitchen sink, or laundry tub; in a wet basement; or near a swimming pool and the like.

7.Cleaning

Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.

8.Power-Cord Protection

Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the product.

9.Overloading

Do not overload wall outlets; extension cords, or integral convenience recep- tacles as this can result in a risk of fire or electric shock.

10.Outdoor Antenna Grounding

If an outside antenna or cable system is connected to the product, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges. Article

810 of the National Electrical Code, ANSI/NFPA 70, provides information with regard to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.

INTRODUCTION

EXAMPLE OF ANTENNA GROUNDING AS PER

NATIONAL ELECTRICAL CODE

ANTENNA

LEAD IN

WIRE

GROUND

CLAMP

ANTENNA

DISCHARGE UNIT

ELECTRIC (NEC SECTION 810-20)

SERVICE

EQUIPMENT

GROUNDING CONDUCTORS (NEC SECTION 810-21)

GROUND CLAMPS

POWER SERVICE GROUNDING ELECTRODE SYSTEM

(NEC ART 250, PART H)

NEC – NATIONAL ELECTRICAL CODE

S2898A

11.Power Lines

An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

5

IMPORTANT SAFETY

INSTRUCTIONS

12. Lightning

For added protection for this product during storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the product due to lightning and power-line surges.

13. Object and Liquid Entry

Never push objects of any kind into this product through openings as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill liquid of any kind on the product.

14. Attachments

Do not use attachments not recommended by the product manufacturer as they may cause hazards.

15. Accessories

Do not place this product on an unstable cart, stand, tripod, bracket, or table. The product may fall, causing serious injury to a child or adult, and serious damage to the product. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer, or sold with the product. Any mounting of the product should follow the manufacturer’s instructions, and should use a mounting accessory recommended by the manufacturer.

A product and cart combination should be moved with care. Quick stops, S3125A excessive force, and uneven surfaces may cause the product and cart combination to overturn.

16.Damage Requiring Service

Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following conditions:

a)When the power-supply cord or plug is damaged.

b)If liquid has been spilled, or objects have fallen into the product.

c)If the product has been exposed to rain or water.

d)If the product does not operate normally by following the operating instructions. Adjust only those controls that are covered by the operating instructions as an improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the product to its normal operation.

e)If the product has been dropped or damaged in any way.

f)When the product exhibits a distinct change in performance - this indicates a need for service.

17. Servicing

Do not attempt to service this product yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

18.Replacement Parts

When replacement parts are required, be sure the service technician has used replacement parts specified by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock, or other hazards.

19. Safety Check

Upon completion of any service or repairs to this product, ask the service technician to perform safety checks to determine that the product is in proper operating condition.

6

Contents

INTRODUCTION

Provides important notes and general explanation of the VCR, including names of the buttons, jacks, etc.

SAFETY PRECAUTIONS ....................

2

IMPORTANT PRECAUTIONS .............

3

IMPORTANT SAFETY



INSTRUCTIONS ...................................

4

Contents ..............................................

7

Identification of Controls ...................

8

Front Panel

Remote Control

VCR Display

Rear Panel

PREPARATION

Explains what you need to do before operating the VCR.

How to Use the Remote Control ......

11

Connections ......................................

12

Auto Set Up .......................................

14

Initial Settings Using On-screen



Display ...............................................

15

Setting the Language

Optional settings on the SET UP screen

Setting the Clock

Storing Channels on the VCR ..........

17

Video Cassette Use ..........................

19

PLAYBACK

Explains variable functions concerning playback.

Playback ............................................

20

Basic Playback

Double Speed Playback

S-VHS Quasi Playback (SQPB)







• Still Picture

21

INTRODUCTION

Variable Speed Playback .................



• Picture Search





• Commercial Movie Skip





• Frame Advance





• Slow-motion Picture





Useful Functions in Tape





Operation ...........................................

23



• Counter Function

• Tape Remaining Time

• Memory Stop Feature

RECORDING

Explains recording functions.

Recording a TV Program ..................

25

Basic Recording

Watching a TV program while recording another

Skipping unnecessary scenes while recording

Recording off time setting

Timer Program Recording ...............



26

MTS Broadcast Compatibility ..........



29

ADDITIONAL INFORMATION





Remote Control





for TOSHIBA TVs ..............................



30

Before Calling Service Personnel ...

31

Specifications ...................................



33

Accessories ......................................



33

Memo..................................................



34

LIMITED WARRANTY .............

Back cover

7

Toshiba W-528, W-522, W-422 User Manual

INTRODUCTION

Identification of Controls

See the page in for details.

This manual shows the names of buttons in italics.

Front Panel model W-528

15 POWER Cassette compartment 25 REC

19 EJECT

















































































































































































































































































































































































































































































































































































































































































































































































LINE IN 2 AUDIO

Remote

20

20

20

20















REW PLAY FF STOP











(L/MONO, R) jacks

Sensor





LINE IN 2 VIDEO jack

25 CHANNEL

VCR Display

















































































































Front Panel model W-522

15 POWER Cassette compartment

25 REC





19 EJECT

LINE IN 2 AUDIO

VCR Display

20

20

20

20

(L/MONO, R) jacks 25





REW PLAY FF STOP

CHANNEL













LINE IN 2 VIDEO jack

Remote Sensor

Front Panel model

W-422







15

POWER

Cassette compartment

25

REC

19 EJECT





CHANNEL 25

VCR Display

20

20

20

20

Remote Sensor

REW PLAY FF

STOP





8

Remote Control

To operate your TV.

TV

30











VCR 15

VCR

TV



POWER

To operate this VCR.















1

2

3



Number buttons 18

4

5

6















CM SKIP



A.SELECT

29

7

8

9





A.SELECT







(only for model W-528/W-522 )





0

100















PLAY *

20











EJECT

19

EJECT











PLAY





REW *

20

REW

ENTER

F F













SLOW 22



STOP















DISPLAY 23

SLOW

REMAIN/

COUNT

PAUSE/STILL







DISPLAY

COUNTER

RESET

SP/ SLP

REMAIN/COUNTER 23

I.SELECT

REC



TIMER





25





I.SELECT

TV VOL

PROG. CANCEL







REC 25

TV VOL 30

15

POWER



20

CH/TRK

INTRODUCTION

25

TV/VCR



21

CM SKIP



18

100



15

ENTER



20

PLAY *



20

FF *



20STOP *

21PAUSE/STILL

25 SP/SLP

23 COUNT RESET

27TIMER

28CANCEL

15PROG.

*These buttons are used to control the cursor on the screen.

VCR Display

Cassette indicator



Timer recording indicator



TIMER



VCR

Hi-Fi



Hi-Fi indicator



(only for model W-528/W-522)







VCR indicator

Multifunctional indicator

9

Rear Panel model W-528/W-522

RF IN (FROM ANT.) terminal

LINE OUT AUDIO jacks (L, R)

LINE IN 1 AUDIO jacks (L, R)

LINE

LINE

IN

OUT

IN 1

(FROM ANT.)



R





AUDIO





L

OUT RF



VIDEO

(TO TV)



CH





3

4



LINE IN 1 VIDEO jack

To wall outlet

LINE OUT VIDEO jack

CH selector (3/4)

RF OUT (TO TV) terminal

LINE IN 1 AUDIO (Rear), 2 (Front) jacks

If the connected equipment is monaural (has one audio output jack), connect the L (MONO) side, the same sound is recorded on both L and R on the Hi-Fi track.

Rear Panel model W-422

RF IN (FROM ANT.) terminal

LINE OUT AUDIO jack

LINE IN AUDIO jack

IN

(FROM ANT.)

AUDIO

OUT IN

OUT RF

(TO TV)

CH

3 4

VIDEO

LINE IN VIDEO jack

To wall outlet LINE OUT VIDEO jack

CH selector (3/4)

RF OUT (TO TV) terminal

10

PREPARATION

How to Use the Remote Control

This section explains how to get ready for remote control operation.

Setting up the Remote Control

1 Open the battery compartment lid on the rear panel.

2 Install 2 batteries (“AA” size) following



the polarity diagrams.

+



+

3 Close the battery compartment lid.

4 Point the remote control at the VCR and press the buttons within the operating range.

Distance: within about 7 m from the front of the remote sensor Angles: within about 30˚ in every direction

PREPARATION

Notes on batteries

The life of the batteries is about 1 year depending on the conditions of use.

If the remote control does not operate correctly, replace all batteries with new ones.

If the remote control is not to be used for a long period of time, remove the batteries to avoid possible damage from battery corrosion.

Caring for the remote control

Do not expose the remote sensor of the VCR to a strong light source such as direct sunlight or illumination (especially high-frequency lighting) when using the remote control.

Be careful not to spill water on the remote control or to place it on anything wet, and avoid sharp impacts.

11
