Toshiba SD-K710 User Manual

Download
Introduction
2
DIGITAL VIDEO
DVD VIDEO PLA YER
SD-K710
OWNER’S MANUAL
Connections
Basic playback
playback
Quick control
Function setup
Others
18
26
34
46
56
68
79077212
S
PM0004523011
© 2002 Toshiba Corporation

Introduction

SAFETY PRECAUTIONS
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
AVIS
WARNING : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USERSERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY
ATTENTION: POUR EVITER LES CHOCS ELECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA
CAUTION: This Digital Video Disc Player employs a Laser System.
RISQUE DE CHOC ELECTRIQUE NE
PAS OUVRIR
TO RAIN OR MOISTURE. DANGEROUS HIGH VOLTAGES ARE PRESENT INSIDE THE ENCLOSURE. DO NOT OPEN THE CABINET . REFER SERVICING TO QUALIFIED PERSONNEL ONL Y .
INSERT.
FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU FOND.
To ensure proper use of this product, please read this owner’s manual carefully and retain for future reference. Should the unit require maintenance, contact an authorized service location ­see service procedure.
Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.
To prevent direct exposure to laser beam, do not try to open the enclosure. Visible and invisible laser radiation when open and interlocks defeated. DO NOT STARE INTO BEAM.
The lightning flash with arrowhead symbol, within an equilat­eral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclo­sure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is in­tended to alert the user to the presence of important operat­ing and maintenance (servicing) instructions in the literature accompanying the appliance.
The symbol for CLASS II (Double Insulation)
FCC NOTICE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rule. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
WARNING: Changes or modifications made to this equipment, not expressly approved by Toshiba, or
parties authorized by Toshiba, could void the user’s authority to operate the equipment.
2
The instructions shall state that an ALL-POLE MAINS SWITCH with a contact separation of at least 3 mm in each pole shall be incorporated in the electrical installation of the building.
CAUTION: These servicing instructions are for use by qualified service personnel only. To reduce the risk of
electric shock do not perform any servicing other than that contained in the operating
instructions unless you are qualified to do so. In the spaces provided below, record the Model and Serial No. located on the rear panel of your DVD player. Model No. Serial No. Retain this information for future reference.
Location of the required label
PRODUCT IS CERTIFIED BY THE MANUFACTURER TO COMPLY WITH DHHS RULE 21 CFR SUBCHAPTER J APPLICABLE AT THE DATE OF MANUFACTURE.
MANUFACTURED
1-1,SHIBAURA 1-CHOME,MINATO-KU. TOKYO 105-8001,JAPAN
Introduction
3
Introduction
IMPORTANT SAFETY INSTRUCTIONS
CAUTION: PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS GIVEN IN THIS
OWNER’S MANUAL AND THOSE MARKED ON THE UNIT. RET AIN THIS BOOKLET FOR FUTURE REFERENCE.
This set has been designed and manufactured to assure personal safety. Improper use can result in electric shock or fire hazard. The safeguards incorporated in this unit will protect you if you observe the following procedures for installation, use and servicing. This unit is fully transistorized and does not contain any parts that can be repaired by the user.
DO NOT REMOVE THE CABINET COVER, OR YOU MA Y BE EXPOSED T O DANGEROUS VOL T AGE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL ONLY.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
4
7. Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves,
or other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10.Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
Introduction
11.Only use attachments/accessories specified by the manufacturer.
12.Use only with the cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.
S3125A
5
Introduction
IMPORTANT SAFETY INSTRUCTIONS
13.Unplug this apparatus during lightning storms or when unused for long periods of time.
14.Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
15.When you use headphones, keep the volume at a moderate level. If you use the headphones continuously with high volume sound, it may cause hearing damage.
16.Do not overload wall outlets; extension cords, or integral convenience receptacles as this can result in a risk of fire or electric shock.
17.Never insert objects of any kind into this apparatus through openings as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill liquid of any kind on the apparatus.
6
18.Keep your fingers well clear of the disc tray as it is closing. Neglecting to do so may cause serious personal injury.
19.Do not place a heavy object on or step on the apparatus. The object may fall, causing serious personal injury and serious damage to the apparatus.
20. Do not use a cracked, deformed, or repaired disc. These discs are easily broken and may cause serious personal injury and apparatus malfunction.
Introduction
7
Introduction
Precautions
Notes on handling
When shipping the DVD player, the original shipping carton and packing materials come in handy. For maximum protection, repack the unit as it was originally packed at the factory. Do not use volatile liquids, such as insect spray, near the DVD player. Do not leave rubber or plastic products in contact with the DVD player for a long time. They will leave marks on the finish. The top and rear panels of the DVD player may become warm after a long period of use. This is not a malfunction. When the DVD player is not in use, be sure to remove the disc and turn off the power. If you do not use the DVD player for a long period, the unit may not function properly in the future. Turn on and use the DVD player occasionally.
Notes on locating
Place the DVD player on a level surface. Do not use it on a shaky or unstable surface such as a wobbling table or inclined stand. The loaded disc may come off the proper position and cause damage to the DVD player. When you place this DVD player near a TV, radio, or VCR, the playback picture may become poor and the sound may be distorted. In this case, place the DVD player away from the TV, radio, or VCR.
Notes on moisture condensation
Moisture condensation damages the DVD player. Please read the following carefully.
Moisture condensation occurs, for example, when you pour a cold drink into a glass on a warm day. Drops of water form on the outside of the glass. In the same way, moisture may condense on the optical pick-up lens inside this unit, one of the most crucial internal parts of the DVD player.
E
Moisture condensation occurs during the following cases.
When you bring the DVD player directly from a cold place to a warm place. When you use the DVD player in a room where you just turned on the heater, or a place where the cold wind from the air conditioner directly hits the unit. In summer, when you use the DVD player in a hot and humid place just after you move the unit from an air conditioned room. When you use the DVD player in a humid place.
f
o
m
e
o
l
p
i
s
m
a
x
n
o
c
t
u
r
e
s
n
a
e
t
i
d
o
n
!
Optical pick-up
lens
It’s too
warm!
Notes on cleaning
Use a soft, dry cloth for cleaning.
For stubborn dirt, soak the cloth in a weak detergent solution, wring well and wipe. Use a dry cloth to wipe it dry. Do not use any type of solvent, such as thinner and benzine, as they may damage the surface of the DVD player. If you use a chemical saturated cloth to clean the unit, follow that product’s instructions.
To obtain a clear picture
The DVD player is a high technology, precision device. If the optical pick-up lens and disc drive parts are dirty or worn down, the picture quality deteriorates. To obtain a clear picture, we recommend regular inspection and maintenance (cleaning or parts replacement) every 1,000 hours of use depending on the operating environment. For details, contact your nearest dealer.
8
Do not use the DVD player when moisture condensation may occur.
If you use the DVD player in such a situation, it may damage discs and internal parts. Remove the disc, connect the power cord of the DVD player to the wall outlet, turn on the DVD player, and leave it for two or three hours. After two or three hours, the DVD player will have warmed up and evaporated any moisture. Keep the DVD player connected to the wall outlet and moisture condensation will seldom occur.
Wait!
Wall outlet
Notes on Discs
On handling discs
Do not touch the playback side of the disc.
Playback side
Do not attach paper or tape to discs.
On cleaning discs
Fingerprints and dust on the disc cause picture and sound deterioration. Wipe the disc from the center outwards with a soft cloth. Always keep the disc clean.
Structure of disc contents
Normally, DVD video discs are divided into titles, and the titles are sub-divided into chapters. VIDEO CDs/ audio CDs are divided into tracks.
DVD video disc
Title 1
Chapter 1 Chapter 2 Chapter 1 Chapter 2 Chapter 3
VIDEO CD/Audio CD
Track 1 Track 2 Track 3 Track 4 Track 5
Each title, chapter or track is assigned a number, which is called “title number”, “chapter number” or “track number” respectively. There may be discs that do not have these numbers.
Title 2
Notes on copyright
Introduction
If you cannot wipe off the dust with a soft cloth, wipe the disc lightly with a slightly moistened soft cloth and finish with a dry cloth. Do not use any type of solvent such as thinner, benzine, commercially available cleaners or antistatic spray for vinyl LPs. It may damage the disc.
On storing discs
Do not store discs in a place subject to direct sunlight or near heat sources. Do not store discs in places subject to moisture and dust such as a bathroom or near a humidifier. Store discs vertically in a case. Stacking or placing objects on discs outside of their case may cause warping.
It is forbidden by law to copy, broadcast, show, broadcast on cable, play in public, and rent copyrighted material without permission.
DVD video discs are copy protected, and any recordings made from these discs will be distorted.
This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.
9
Introduction
Notes on Discs (continued)
About this owner’s manual
This owner’s manual explains the basic instructions of this DVD player. Some DVD video discs are produced in a manner that allows specific or limited operation during playback. As such, the DVD player may not respond to all operating commands. This is not a defect in the DVD player. Refer to instruction notes of discs.
” may appear on the TV screen during operation.
“
” means that the operation is not permitted by the
A “ DVD player or the disc.
Notes on region numbers
The region number of this DVD player is 1. If region numbers, which stand for their playable area, are printed
ALL
1
or
on your DVD video disc and you do not find
, disc playback will not be allowed by the player. (In this case, the DVD player will display a message on-screen.)
On VIDEO CDs
This DVD player supports VIDEO CDs equipped with the PBC (Version 2.0) function. (PBC is the abbreviation of Playback Control.) You can enjoy two playback variations depending on types of discs.
• VIDEO CD not equipped with PBC function
(Version 1.1)
Sound and movie can be played on this DVD player in the same way as an audio CD.
• VIDEO CD equipped with PBC function
(Version 2.0)
In addition to operation of a VIDEO CD not equipped with the PBC function, you can enjoy playback of interactive software with search function by using the menu displayed on the TV screen (Menu Playback). Some of the functions described in this owner’s manual may not work with some discs.
Playable discs
This DVD player can play the following discs.
Disc Mark Contents
DVD video discs
VIDEO CDs
Audio CDs
The following discs are also available.
DVD-R discs of DVD video format CD-R/CD-RW discs of CD-DA format
Some of these discs may be incompatible.
DIGITAL VIDEO
video
(moving
pictures)
+
Audio
video (moving pictures)
+
Audio
Audio
• You cannot play discs other than those listed above.
• You cannot play DVD-RAM discs or non-standardized discs, etc., even if they may be labeled as above.
• This DVD player uses the NTSC color system, and cannot play DVD video discs recorded in any other color system (PAL, SECAM, etc.).
Disc Size
12 cm
8 cm
12 cm
8 cm
12 cm
8 cm
(CD single)
10

Table of Contents

Introduction
SAFETY PRECAUTIONS ..........................2
IMPORT ANT SAFETY INSTRUCTIONS ...4
Precautions ...............................................8
Notes on Discs..........................................9
Notes on region numbers ...............................10
Table of Contents....................................11
Identification of Controls .......................12
Front panel ..................................................... 12
Rear panel...................................................... 12
DVD display.................................................... 13
Remote control ...............................................14
Loading batteries............................................ 15
Operating with the remote control .................. 15
Connections
Connecting to a TV .................................18
Connecting to a TV......................................... 18
Connecting to an audio system and TV
equipped with component video inputs ........ 19
Connecting to Optional Equipment ......20
Connecting to an amplifier equipped with a
Dolby Digital decoder ................................... 21
Connecting to an amplifier equipped with
Dolby Surround Pro Logic ............................ 21
Connecting to an amplifier equipped with a
DTS decoder ................................................ 22
Connecting to an amplifier equipped with an
MPEG2 audio decoder.................................22
Connecting to an amplifier equipped with a
digital audio input ......................................... 23
Basic playback
Playing a Disc .........................................26
Basic playback ...............................................26
Variable Speed Playback........................28
Playing in fast reverse or
fast forward directions .................................. 28
Playing frame by frame .................................. 28
Playing in slow-motion.................................... 29
Resuming playback from the same location... 29
Locating a Desired Section ...................30
Locating a title using the top menu................. 30
Locating a desired section by entering its
corresponding number ................................. 31
Locating a specific chapter or track................ 31
Playing an MP3 Encoded CD .................32
Playing an MP3 Encoded CD......................... 32
Advanced playback
Accessing a Specific Location Directly ..
Entering the elapsed time of the desired
location.........................................................34
Playing Repeatedly.................................35
Repeating a title, chapter, or track..................35
Repeating a specific segment ........................ 35
Playing in a Favorite Order ....................36
Setting titles, chapters, or tracks in a favorite
order.............................................................36
Playing in Random Order.......................37
Playing titles, chapters, or tracks in random
order.............................................................37
Zooming a Picture ..................................38
Zooming a picture........................................... 38
Selecting the Sound Enhancement
(E.A.M.) ....................................................39
Selecting the sound enhancement .................39
Selecting the Camera Angle ..................40
Changing the camera angle ........................... 40
Selecting Subtitles .................................41
Selecting a subtitle language .........................41
Selecting a Language.............................42
Selecting a playback audio setting .................42
Quick control
Using the Virtual Remote Control
- V-REMOTE -...........................................46
Selecting the Playback Function
- QUICK -..................................................47
Accessing Features
- NA VI -.....................................................48
Function setup
Customizing the Function Settings ......56
Setting procedure ...........................................56
Setting details................................................. 58
Table of Languages ................................65
Others
Before Calling Service Personnel ......... 68
Specifications .........................................69
LIMITED WARRANTY DVD PLAYER ......70
Introduction
34
11
Introduction
Identification of Controls
See the page in for details.
Front panel
ON/STANDBY indicator
ON/STANDBY
ON/STANDBY button
Rear panel
VIDEO OUT (Y/PB/PR) (Component video) jacks
VIDEO OUT jack
18
26
OPEN/CLOSE button
Disc tray
DVD display
26
13
26
When connecting the optical digital cable, remove the cap and fit the connector into the jack firmly. When not using the jack, keep the cap inserted to protect it from dust intrusion.
19
BITSTREAM/PCM OPTICAL (DIGITAL) AUDIO OUT jack
21 22 23
PAUSE button
26
STOP button
PLAY button
STOP
OPEN/CLOSE PLAY
PAUSE
SKIP buttons
SKIP
31
PROGRESSIVE indicator
27
27
26
19
12
SELECT
I
VIDEO OUT
VIDEO
P
S
P
R
Y
B
P
L
R
COAXIAL
ANALOG DIGITAL
BITSTREAM/PCM COAXIAL (DIGITAL) AUDIO OUT jack
ANALOG AUDIO OUT (L/R) jacks
S VIDEO OUT jack
SELECT (I/P) switch
AUDIO OUT
BITSTREAM
/PCM
OPTICAL
Power cord
21 22 23
18 19
18
19
DVD display
Pressing of the FL DIMMER button on the remote control changes the brightness of the display.
FL
DIMMER
Normal
Dimmed
Off
Introduction
Play mode indicator
Title number indicator
Chapter number indicator
Memory playback indicator
Track number
Random playback indicator
M A-BR
TITLE
indicator
CHP TRK
DVD
VCD
Multifunctional indicator (indicates operating status or messages, etc.)
DVD/VIDEO CD/CD indicator
When you start playback, the elapsed time indicators appear. Pressing the FL SELECT button switches them to the title/chapter/track number indicators. Some discs may not permit this operation.
The indicators vary depending on the kinds of discs you play.
Angle icon indicator
Repeat playback indicator
DVD video disc
• During playback:
Example
DVD
Some discs may not display chapter numbers or elapsed time.
TITLE
Playing chapter 3 of title 2
CHP
VIDEO CD
• During playback:
Example
TRK
VCD
Playing track 6
Some discs may not display track numbers or elapsed time.
Audio CD
• During playback:
Example
TRK
CD
Playing track 6
13
Introduction
Identification of Controls (continued)
The instructions in this manual describe the functions on the remote control. See the page in for details.
Remote control
OPEN/CLOSE button
PROGRESSIVE button FL DIMMER button E.A.M. button
V-REMOTE button QUICK button
TOP MENU button Direction buttons
39
46
47
30
56
( / / / )
CLEAR button REV button
FWD button
31
28
28
PAUSE/STEP button STOP button
ANGLE button SUBTITLE button
27
40
41
13
27
26
19
OPEN/CLOSE
PROGRESSIVE
E.A.M.
K
C
I
U
Q
U
N
E
M
P
O
T
REV
PAUSE/STEP
ANGLE
SETUP
FL
DIMMER
M
O
E
R
-
V
ENTER
FWD
STOP PLAY
SUBTITLE
ZOOM
BRIGHTNESS
T
E
N
A
V
I
RETURNCLEAR
SKIP
SLOW
FL SELECT
AUDIO DNR
SEARCH
SETUP button
Power button
BRIGHTNESS buttons
ZOOM buttons
M
E
N
U
NAVI button
56
26
52
38
48
MENU button*
ENTER button
RETURN button
SKIP buttons PLAY button
SLOW buttons FL SELECT button DNR button
T321
AUDIO button
56
56
31
26
29
13
52
42
Number buttons
RANDOM button MEMORY button
14
31
37 36
4
56
7890
RANDOM
MEMORY REPEAT A-B RPT
+
10
T button
A-B RPT button REPEAT button
31
35
35
* MENU button
Use the MENU button to display the menu included on many DVD video discs. To operate a menu, follow the instructions in “Locating a title using the top menu.”
30
Loading batteries
Operating with the remote control
Introduction
Open the cover.
1
Insert batteries (AAA size).
2
Make sure to match the + and – on the batteries to the marks inside the battery compartment.
Close the cover.
3
Point the remote control at the remote sensor and press the buttons.
30°
30°
Within about 7 m (23 feet)
Distance:About 7 m (23 feet) from the front of the
remote sensor
Angle: About 30° in each direction of the front of
the remote sensor
* Do not expose the remote sensor of the DVD player
to a strong light source such as direct sunlight or other illumination. If you do so, you may not be able to operate the DVD player via the remote control.
Notes on batteries
Improper use of batteries may cause battery leakage and corrosion. To operate the remote control correctly, follow the instructions below.
• Do not insert batteries into the remote control in the wrong direction.
• Do not charge, heat, open, or short-circuit the batteries. Do not throw batteries into a fire.
• Do not leave dead or exhausted batteries in the remote control.
• Do not use different types of batteries together, or mix old and new batteries.
• If you do not use the remote control for a long period of time, remove the batteries to avoid possible damage from battery corrosion.
• If the remote control does not function correctly or if the operating range becomes reduced, replace all batteries with new ones.
• If battery leakage occurs, wipe the battery liquid from the battery compartment, then insert new batteries.
Notes on the remote control
• Direct the remote control at the remote sensor of the DVD player.
• Do not drop or give the remote control a shock.
• Do not leave the remote control near an extremely hot or humid place.
• Do not spill water or put anything wet on the remote control.
• Do not open the remote control.
15

Connections

Read this chapter first to make all necessary preparations.
Connecting to a TV Connecting to an audio system
and TV equipped with component video inputs
Connecting to an amplifier equipped with a Dolby Digital decoder
Connecting to an amplifier equipped with Dolby Surround Pro Logic
Connecting to an amplifier equipped with a DTS decoder
Connecting to an amplifier equipped with an MPEG2 audio decoder
Connecting to an amplifier equipped with a digital audio input
Connections
Connecting to a TV
Connect the DVD player to your TV.
For details of output sound, see 43.
Connecting to a TV
SELECT
I
To S VIDEO OUT
SELECT
I
P
Set to “I.”
S video cable (not supplied)
VIDEO
P
S
VIDEO OUT
Y
R ANALOG DIGITAL
(yellow)
To VIDEO OUT
AUDIO OUT
BITSTREAM
P
R
P
B
/PCM
L
OPTICAL
COAXIAL
(red)
T o ANALOG AUDIO OUT
(white)
Audio/video cable (supplied)
If the TV has an S video input, connect the DVD player with an S video cable. When using an S video cable, do not connect the yellow video cable.
To audio inputs
To video input
To S video input
To wall outlet
TV or monitor with
(white)
audio/video inputs
(red)
(yellow)
Signal flow
• Make the following setting.
On-screen display
“Digital Output”
Select:
“Bitstream”
or
“PCM”
Notes
• Refer to the owner’s manual of the connected TV as well.
• When you connect the DVD player to your TV, be sure to turn off the power and unplug both units from the wall outlet before making any connections.
• If your television set has one audio input, connect the left and right audio outputs of the DVD player to a Y cable adapter (not supplied) and then connect to your TV.
• Connect the DVD player directly to your TV. If you connect the DVD player to a VCR, TV/VCR combination or video selector, the playback picture may be distorted as DVD video discs are copy protected.
18
Page
56 59
INTERLACED outputs/inputs (ColorStream®)
Some TVs or monitors are equipped with component video inputs. Connecting to these inputs allows you to enjoy higher quality picture playback. Actual labels for component video inputs may vary depending on the TV manufacturer. (ex. Y, R-Y, B-Y or Y, CB, CR) In some TVs or monitors, the color levels of the playback picture may be reduced slightly or the tint may change. In such a case, adjust the TV or monitor for optimum performance.
PROGRESSIVE outputs/inputs (ColorStream®Pro)
Some TVs or monitors are equipped with component video inputs that are capable of reproducing a progressively scanned video signal. Connecting to these inputs allows you to view the highest quality pictures with less flicker.
Connecting to an audio system and TV equipped with component video inputs
Connections
Signal flow
B
L
(white)
AUDIO OUT
BITSTREAM
PR
OPTICAL
COAXIAL
To PR VIDEO OUT
/PCM
To PB VIDEO OUT
To Y VIDEO OUT
To wall outlet
(red)
SELECT
I
VIDEO OUT
VIDEOYP
P
S
R
ANALOG DIGITAL
To audio inputs of the amplifier
(red) (white)
To PB video input To PR video input
Audio system
Switching the output signal (interlaced/ progressive) using the remote control (only when the SELECT (I/P) switch is set to “P”)
T o Y video input
TV or monitor equipped with component video (INTERLACED) inputs or TV or monitor equipped with component video (PROGRESSIVE) inputs
SELECT
I
SELECT I
P
P
* After setting this switch (I/P), be sure to
power off the DVD player then turn it on to activate the setting.
Set to “I.”
Set to “P.”
You can temporarily switch the output signal for better picture quality . Press PROGRESSIVE on the remote control. While the DVD player is outputting progressive signals, the indicator on the right side on the front panel illuminates.
• Make the following setting.
On-screen display
“Digital Output”
Select:
“Bitstream”
or
“PCM”
Page
56 59
Notes
• Refer to the owner’s manual of the connected equipment as well.
• When you connect the DVD player to other equipment, be sure to turn off the power and unplug all of the equipment from the wall outlet before making any connections.
• If you place the DVD player near a tuner or radio, the radio broadcast sound might be distorted. In this case, place the DVD player away from the tuner and radio.
• The output sound of the DVD player has a wide dynamic range. Be sure to adjust the receiver’s volume to a moderate listening level. Otherwise, the speakers may be damaged by a sudden high volume sound.
• Turn off the amplifier before you connect or disconnect the DVD player’s power cord. If you leave the amplifier power on, the speakers may be damaged.
• The S VIDEO OUT jack and the VIDEO OUT jack cannot output video signals simultaneously, if you select progressive signal when the SELECT (I/P) switch is set to “P.”
19
Connections
Connecting to Optional Equipment
You can enjoy high quality dynamic sounds by connecting the DVD player to optional audio equipment.
• For connection to your TV, see “Connecting to a TV”
18
19
.
• For details of output sound, see
43
.
• This section uses the following reference marks.
: Front speaker : Rear speaker : Sub woofer : Center speaker : Signal flow
Notes
• DO NOT connect the BITSTREAM/PCM (DIGITAL) AUDIO OUT jack of the DVD player to the AC-3 RF input of a Dolby Digital Receiver. This input on your A/V Receiver is reserved for Laserdisc use only and is incompatible with the BITSTREAM/PCM (DIGITAL) AUDIO OUT jack of the DVD player.
• Connect the BITSTREAM/PCM (DIGITAL) AUDIO OUT jack of the DVD player to the “DIGITAL (OPTICAL)” or “DIGITAL (COAXIAL)” input of a Receiver or Processor.
• Refer to the owner’s manual of the connected equipment as well.
• When you connect the DVD player to other equipment, be sure to turn off the power and unplug all of the equipment from the wall outlet before making any connections.
• The output sound of the DVD player has a wide dynamic range. Be sure to adjust the receiver’s volume to a moderate listening level. Otherwise, the speakers may be damaged by a sudden high volume sound.
• Turn off the amplifier before you connect or disconnect the DVD player’s power cord. If you leave the amplifier power on, the speakers may be damaged.
Warning
• When you are connecting (via the BITSTREAM/PCM (DIGITAL) AUDIO OUT jack) an AV decoder that does not have Dolby Digital or MPEG2 decoding function, be sure to set “Digital Output” to “PCM” from the on-screen displays damage your hearing as well as the speakers.
• DO NOT play DTS-encoded discs when you are connecting an AV decoder that does not have DTS decoding function.
• When playing DTS-encoded discs (audio CDs), excessive noise may be output from the analog audio output jacks. To avoid possible damage to the audio system, you should take proper precautions when the analog audio output jacks of the DVD player are connected to an amplification system. To enjoy DTS Digital Surround™ playback, an external 5.1 channel DTS Digital Surround™ decoder system must be connected to the BITSTREAM/PCM (DIGITAL) AUDIO OUT jack of the DVD player.
56
59
. Otherwise, high volume sound may
20
Connecting to an amplifier equipped with a Dolby Digital decoder
Dolby Digital
Dolby Digital is the surround sound technology used in theaters showing the latest movies, and is now available to reproduce this realistic effect in the home. You can enjoy motion picture and live concert DVD video discs with this dynamic realistic sound by connecting the DVD player to a 6 channel amplifier equipped with a Dolby Digital decoder or Dolby Digital processor. If you have a Dolby Surround Pro Logic decoder, you will obtain the full benefit of Pro Logic from the same DVD movies that provide full 5.1-channel Dolby Digital soundtracks, as well as from titles with the Dolby Surround mark.
AUDIO OUT
VIDEO OUT
YP
BPR
Amplifier equipped with a Dolby Digital decoder
T o OPTICAL type digital audio input
T o COAXIAL type digital audio input
Connect either.
75 Ω coaxial cable Optical digital cable
VIDEO
R
COAXIAL
L
OPTICAL
S
BITSTREAM/PCM
ANALOG
Manufactured under license from Dolby Laboratories. “Dolby”, “Pro Logic” and the double-D symbol are trademarks of Dolby Laboratories. Confidential unpublished works. Copyright 1992-1997 Dolby Laboratories. All rights reserved.
• Use DVD video discs encoded via the Dolby Digital recording system.
• Make the following setting.
On-screen display
“Digital Output”
Recording system
Select:
“Bitstream”
Connecting to an amplifier equipped with Dolby Surround Pro Logic
Connections
Page
56 59
42
D
Dolby Surround Pro Logic
You can enjoy the dynamic realistic sound of Dolby Surround Pro Logic by connecting an amplifier and speaker system (right and left front speakers, a center speaker, and one or two rear speakers).
With an amplifier equipped with Dolby Digital
Connect the equipment the same way as described in “Connecting to an amplifier equipped with a Dolby Digital decoder.” Refer to that amplifier’s owner’s manual and set the amplifier so you can enjoy Dolby Surround Pro Logic sound.
With an amplifier not equipped with Dolby Digital
Connect the equipment as follows.
AUDIO OUT
VIDEO OUT
BPR
YP
*
Amplifier equipped with Dolby Surround Pro Logic
To audio input
ANALOG AUDIO OUT
Audio cable
VIDEO
COAXIAL
R
OPTICAL
L
S
BITSTREAM/PCM
ANALOG
• Make the following setting.
On-screen display
“Digital Output”
Select:
“Bitstream”
or
“PCM”
Page
56 59
Be sure to set “Digital Output” to “Bitstream” or “PCM” when you enjoy sounds of Dolby Surround Pro Logic using this connection.
* Connect one or two rear speakers. The output sound from the rear speakers will be monaural even if you connect two rear speakers.
21
Connections
Connecting to Optional Equipment (Continued)
Connecting to an amplifier equipped with a DTS decoder
Digital Theater Systems (DTS)
DTS is a high quality surround technology used in theaters and now available for home use, on DVD video discs or audio CDs. If you have a DTS decoder or processor, you can obtain the full benefit of 5.1 channel DTS encoded sound tracks on DVD video discs or audio CDs.
“DTS” and “DTS Digital Out” are trademarks of Digital Theater Systems, Inc.
• Use DVD video discs or audio CDs encoded via the DTS recording system.
Amplifier equipped with a DTS decoder
T o OPTICAL type digital audio input
T o COAXIAL type digital audio input
Connect either.
75 Ω coaxial cable Optical digital cable
AUDIO OUT
VIDEO OUT
BPR
YP
VIDEO
COAXIAL
R
L
OPTICAL
S
BITSTREAM/PCM
ANALOG
• Make the following setting.
On-screen display Select:
“Digital Output”
Recording system DTS
“Bitstream”
or
“PCM”
Connecting to an amplifier equipped with an MPEG2 audio decoder
MPEG2 sound
You can enjoy motion picture and live concert DVD video discs with dynamic realistic sound by connecting an amplifier equipped with an MPEG2 audio decoder or MPEG2 audio processor.
AUDIO OUT
VIDEO OUT
YP
B PR
Amplifier equipped with an MPEG2 audio decoder
T o OPTICAL type digital audio input
T o COAXIAL type digital audio input
Connect either.
75 Ω coaxial cable Optical digital cable
VIDEO
R
COAXIAL
L
OPTICAL
S
BITSTREAM/PCM
ANALOG
• Use DVD video discs encoded via the MPEG2 recording system.
• Make the following setting.
On-screen display
“Digital Output”
Recording system MPEG2
Select:
“Bitstream”
Page
56 59
42
Page
56 59
42
22
Connecting to an amplifier equipped with a digital audio input
Connections
2 channel digital stereo
You can enjoy the dynamic sound of 2 channel digital stereo by connecting an amplifier equipped with a digital audio input and speaker system (right and left front speakers).
AUDIO OUT
VIDEO OUT
YP
BPR
Amplifier equipped with a digital audio input
T o OPTICAL type digital audio input
T o COAXIAL type digital audio input
Connect either.
75 Ω coaxial cable
Optical digital cable
VIDEO
R
COAXIAL
L
OPTICAL
S
BITSTREAM/PCM
ANALOG
• Make the following setting.
On-screen display Select:
“PCM”“Digital Output”
Page
56 59
23

Basic playback

Begin your operation.
Playing a Disc Variable Speed Playback Locating a Desired Section Playing an MP3 Encoded CD
Basic playback
PLAY
Playing a Disc
This section shows you the basics on how to play a disc.
CAUTION
Keep your fingers well clear of the disc tray as it is closing. Neglecting to do so may cause serious personal injury.
ON/STANDBY indicator
3
2, 4
PAUSE
PLAY
1
DVD display
DVD-VCDVCD
Preparations
• When you want to view a disc, turn on the TV and select the video input connected to the DVD player.
• When you want to enjoy the sound of discs from the audio system, turn on the audio system and select the input connected to the DVD player.
1
Basic playback
Press the power button (ON/ST ANDBY).
ON/STANDBY
When the DVD player is turned on for the first time, an on-screen display will appear to provide initial settings. Press the buttons to select an item, and press the ENTER button. See the pages in make a selection using the press the ENTER button.
On-Screen Language TV Shape
After making all the settings, select “ press the ENTER button.
The DVD player turns on and the ON/STANDBY indicator on the player illuminates.
/
, and
/ buttons, then
60
58
” and
Press OPEN/CLOSE to close the disc tray.
4
OPEN/CLOSE
If you insert a DVD video disc that contains a top menu, a menu may appear. See “Locating a title using the top menu.” You may need to press the TOP MENU or MENU button to display disc menu (depending on the actual DVD video disc.)
Note
If the disc tray contains a disc you have already played, playback will begin from the location where you last stopped playback.
29
Playback starts.
30
STOP
26
Press OPEN/CLOSE.
2
OPEN/CLOSE
The disc tray opens.
Place a disc on the disc tray.
3
With the playback side down.
• There are two different disc sizes. Place the disc in the correct guide on the disc tray. If the disc is out of the guide, it may damage the disc and cause the DVD player to malfunction.
• Do not place a disc which is unplayable in this DVD player.
T o start playback in the stop mode
Press PLAY.
1 2, 4
TOP MENU MENU
ENTER /
PLAY STOP
PAUSE/STEP
To obtain a higher quality picture
Occasionally , some picture noise not usually visible during a normal broadcast may appear on the TV screen while playing a DVD video disc because the high resolution pictures on these discs include a lot of information. While the amount of noise depends on the TV you use with this DVD player, you should generally reduce the sharpness adjustment on your TV when viewing DVD video discs.
About
The function described under that heading.
DVD-V CDVCD
DVD-V CDVCD
DVD-V
: DVD video discs.
CD
: Audio CDs.
icons on the heading bar show the playable discs for the
VCD
: VIDEO CDs.
To pause playback (still mode)
Press PAUSE/STEP during playback.
PAUSE/STEP
To resume normal playback, press the PLAY button.
• Sound is muted during still mode.
To stop playback
Press STOP.
STOP
To remove the disc
Press OPEN/CLOSE.
OPEN/CLOSE
Be sure to press the OPEN/CLOSE button to close the disc tray after you remove the disc.
Remove the disc after the disc tray opens completely.
About the screen saver
If you pause a picture of a DVD video disc and leave it still for a long while, the screen saver of the DVD player automatically appears (when “Screen Saver” is set to
62
“On” button.
). To turn off the screen saver, press the PLAY
Automatic Power Off function
If the DVD player is stopped, or the screen saver is engaged for approximately 20 minutes, the DVD player will automatically turn itself off.
Basic playback
Notes
• Do not move the DVD player during playback. Doing so may damage the disc.
• Use the OPEN/CLOSE button to open and close the disc tray. Do not push the disc tray while it is moving. Doing so may cause the DVD player to malfunction.
• Do not push up on the disc tray or put any objects other than discs on the disc tray. Doing so may cause the DVD player to malfunction.
• In many instances, a menu screen will appear after playback of a movie is completed. Prolonged display of an on-screen menu may damage your television set, permanently etching that image onto its screen. To avoid this, be sure to press the STOP button twice on your remote control once the movie is completed.
27
Basic playback
Variable Speed Playback
You can play discs at various speeds, and resume playback from the location where you stopped playback.
FWD REV PLAY PAUSE/STEP
DVD-VCDVCD
Playing in fast reverse or fast forward directions
Press REV or FWD during playback.
REV FWD
DVD-VCDVCD
Playing frame by frame
REV : Fast reverse playback FWD: Fast forward playback
Each time you press the REV or FWD button, the playback speed changes.
Press P AUSE/STEP during still playback.
PAUSE/STEP
Each time you press the PAUSE/ STEP button, the picture advances one frame.
T o resume normal playback
Press PLAY.
PLAY
Notes
• The DVD player mutes sound and omits subtitles during reverse and forward scan of DVD video discs.
• The playback speed may differ depending on the disc.
T o resume normal playback
Press PLAY.
PLAY
28
Note
The sound is muted during frame by frame playback.
DVD-VCDVCD
SLOW
PLAY STOP
Playing in slow-motion
Press SLOW during playback.
SLOW
SLOW
DVD-VCDVCD
Resuming playback from the same location
Each time you press the SLOW button, the slow-motion speed changes.
If you press the SLOW during playback, you can view the picture in reverse slow-motion. (Only when using a DVD video disc.)
Each time you press the SLOW button, the slow-motion speed changes.
button
Press STOP at the location where you want to interrupt playback.
1
STOP
The DVD player memorizes the location where playback is stopped.
Press PLAY.
2
PLAY
To start playback from the beginning regardless of the location where you stopped playback
1 Press STOP twice.
STOP
The DVD player resumes playback from the location where you stopped playback.
The DVD player erases the previous location from its memory.
To resume normal playback
Press PLAY.
PLAY
Notes
• The sound is muted during slow-motion playback.
• The playback speed may differ depending on the disc.
2 Press PLAY.
PLAY
• If you want to return to the beginning of a DVD video
disc, open and close the disc tray once with the OPEN/CLOSE button before pressing the PLAY button.
Notes
• Resuming cannot function when: –you change the parental lock setting 62 or select a disc
menu language 60.
–you play a PBC-featured VIDEO CD while “PBC” 64 is
set to “On.”
–you open the disc tray.
• There may be a difference in the location where playback resumes depending on the disc.
• Settings you changed using the on-screen displays while the DVD player keeps a location in the memory may function only after the memory is cleared.
DVD-V
Playback starts from the beginning of the current title. Playback starts from the
VCD
beginning of the disc.
CD
Basic playback
29
Basic playback
Locating a Desired Section
TOP MENU / / /
ENTER
Normally, DVD video discs are divided into titles, and the titles are sub-divided into chapters. VIDEO CDs and audio CDs are divided into tracks. You can quickly locate any specific title, chapter, or track.
DVD video disc
Title 1 Title 2
Chapter 1 Chapter 2 Chapter 1 Chapter 2 Chapter 3
DVD-VCDVCD
Locating a title using the top menu
Press TOP MENU.
1
N
E
M
P
O
T
The top menu appears on the TV
U
screen. e.g.
TITLE 1
TITLE 2
Track 1 Track 2
3
VIDEO CD/Audio CD
Track 3
Press ENTER.
Playback starts from chapter 1 of the
ENTER
selected title.
Track 4
Track 5
TITLE 3
TITLE 4
Press / / / to select the title you want.
2
If the titles in the top menu are assigned a number, you can directly
ENTER
locate a specific title by pressing its designated number with the number buttons.
Notes
• The instructions above describe basic procedures which may vary depending on the contents of the DVD video disc. If different instructions appear on the TV screen, follow those instructions.
• If you display the top menu during playback and press the TOP MENU button again without selecting any title, the DVD player may resume playback from the point where you first pressed the TOP MENU button (depending on the actual DVD video disc.)
• This method of locating a title is available only on a disc that contains a top menu.
• Instruction notes of discs may refer to the button that displays the top menu as TITLE button.
30
Number buttons
T
PLAY
SKIP
CLEAR
/ / / ENTER
DVD-VCDVCD
Locating a desired section by entering its corresponding number
Press T .
1
If you are using a VIDEO CD/audio CD, skip steps 1 and 2. Then at step 3, enter the number for the track you want using the number buttons.
SEARCH
T
e.g.
–:––:––
1
1
Press / to select a section you want to locate.
2
e.g. When you want to locate a chapter.
ENTER
1
–:––:––
1
Press / to enter a number of the section.
3
Also the number buttons are available.
ENTER
e.g. To enter 25
25
or
+
+
10
10
Repeat steps 2 and 3 if necessary.
Basic playback
4
Press PLAY or ENTER.
5
Notes
• Pressing the CLEAR button resets the numbers. To clear the
• This method of locating a title is available only on a disc that
5
PLAY
ENTER
display, press the T button several times. contains title numbers.
Playback starts from the selected location.
DVD-VCDVCD
Locating a specific chapter or track
Press SKIP or repeatedly to display the chapter or track number you want.
Playback starts from the selected chapter or track.
SKIP
SKIP
To locate succeeding chapters or tracks.
Playback starts from the beginning of the current chapter or track. When you press twice, playback starts from the beginning of the preceding chapter or track.
Notes
• Some titles may not display chapter numbers.
• When you set “Title Stop” to “Off” 64, you can access chapters in another title. If you go back to the preceding title by pressing the SKIP button, the DVD player locates the first chapter of the title. When “Title Stop” is set to “On,” you can access chapters only within the current title.
• If you press and hold the SKIP or button on the front panel during playback, the DVD player performs fast reverse or fast forward playback. You can vary the speed by pressing the button further. To locate chapters or tracks during fast reverse or fast forward playback, first press the PLAY button to resume normal playback, then use the SKIP or button.
31
Basic playback
PAUSE/STEP
Playing an MP3 Encoded CD
You can play MP3 files on this DVD player.
Playing an MP3 encoded CD
MP3 disc compatibility with this player is limited as follows:
• Playable discs: CD-ROM, CD-R (650MB / 74 min. only) CD-RW is not recommendable.
• Sampling Frequency: 44.1 kHz only
• Bit rate 32 kbps-320 kbps
• CD physical format: Mode 1, Mode 2 XA Form 1
• File system: ISO9660 Level 1
• File names are limited to eight characters or less and must incorporate “MP3” extension. e.g.“********.MP3”
• File names cannot contain special characters such as “?!><+*}{`[@]:;\ /.,” etc.
• Total number of files on the disc should not exceed 254.
Preparations
• When you playback an MP3 encoded CD, set “Priority Contents” to “ MP3
> JPG ”.
64
2
MENU / / /
ENTER PLAY
3
PAUSE/STEP
T o pause playback
Press P AUSE/STEP during playback.
To resume normal playback, press the PLAY button.
Selecting a track (file) in the disc
1 If a track list is not displayed, press the MENU button
to show it. The current track being played is highlighted in red.
2 Press the
want to play. The selected track is highlighted in green.
3 Press the ENTER button to begin playback of the
selected track.
/ / / buttons to select a track you
Place a CD that contains MP3 files on the disc tray .
1
Press OPEN/CLOSE to load the disc.
2
OPEN/CLOSE
T o stop playback, press ST OP.
3
STOP
Playback starts. To start playback from stop mode,
press the PLAY button.
Notes
• Some discs may not permit this operation.
• If you stop playback by pressing the STOP button, and then press the PLAY button, playback will start from the beginning of the track.
• The SKIP 31, REPEAT 35 and RANDOM 37 functions are also available.
This DVD player requires discs/recordings to meet certain technical standards in order to achieve optimal playback quality. Pre-recorded DVDs are automatically set to these standards. There are many different types of recordable disc formats (including CD-R containing MP3 files). Given the fact that technology in this area is still maturing, Toshiba cannot guarantee that all genre of recordable discs will produce optimal playback quality. The technical criteria set out in this owner’s manual are meant as a guide only.
Customers should also note that permission is required in order to download MP3 files and music from the internet. Toshiba has no right to grant such permission. Permission should always be sought from the copyright owner.
32

Advanced playback

Customizing the performance of your DVD player.
Accessing a Specific Location Directly
Playing Repeatedly Playing in a Favorite Order Playing in Random Order Zooming a Picture Selecting the Sound
Enhancement (E.A.M.) Selecting the Camera Angle Selecting Subtitles Selecting a Language
Advanced playback
Accessing a Specific Location Directly
You can access a specific location by entering its corresponding elapsed time (hours, minutes, seconds).
3 3
1 2
DVD-VCDVCD
1
2
3
Entering the elapsed time of the desired location
Press T several times.
SEARCH
T
Press the number buttons to enter the elapsed time.
e.g.
Press PLAY or ENTER.
PLAY
You may have to press further depending on the disc. Press the button repeatedly until the clock icon is highlighted.
e.g.
–:––:––
1
1
2150
3
1:25:30
1
1
Playback starts from the desired location.
Notes
• Some discs may not respond to this process.
• Some scenes may not be located precisely as you specified.
• This method for accessing specific locations is available only within the current title of the DVD video disc or within the current track of the VIDEO CD/audio CD.
34
ENTER
Playing Repeatedly
You can play a specific title, chapter, track, or segment repeatedly.
DVD-VCDVCD
Repeating a title, chapter , or track
/ PLAY CLEAR
REPEAT A-B RPT
Press REPEAT.
1
REPEAT
The repeat mode menu appears.
Press REPEAT or / repeatedly to select the repeat playback mode.
2
REPEAT
ENTER
Chapter Repeat: Repeats the current chapter. Track Repeat: Repeats the current track. Title Repeat Repeats the current title. All Repeat: Repeats the entire disc. Repeat Off: Resumes normal playback.
DVD-VCDVCD
Repeating a specific segment
The mode changes as follows (when using the REPEAT button):
Chapter Repeat
DVD-V
Title Repeat
DVD-V
Track Repeat
VCD
CD
DVD-V
VCD
All Repeat
CD
Repeat off
If you select the repeat mode during playback, the DVD player automatically starts repeat playback after finishing the current title, chapter, or track.
Press PLAY.
3
Note
Some discs may not permit repeat operation.
PLA Y
To resume normal playback
Press CLEAR.
CLEAR
The DVD player starts repeat playback. Press the PLAY button within about 5 seconds after you press the REPEAT button.
Advanced playback
Press A-B RPT at the beginning of the segment (point A) you want to play
1
repeatedly.
A-B RPT
A–
Press A-B RPT again at the end of the segment (point B).
2
A-B RPT
The DVD player automatically returns to point A and starts repeat playback of the selected segment (A-B).
A–B Repeat
To resume normal playback
Press CLEAR.
CLEAR
Notes
• Some discs may not permit A-B repeat operation.
• You cannot set the A-B repeat function for a segment that includes multiple camera angles 40.
• You can specify a segment only within the current title.
• There may be a slight difference between point A and the location where playback actually resumes depending on the disc.
35
Advanced playback
3
1
2
CLEAR
/ / / ENTER
Playing in a Favorite Order
You can combine your favorite titles, chapters, or tracks and play them in the order you determine. You can program up to 30 selections into the memory. (Memory playback)
DVD-VCDVCD
Setting titles, chapters, or tracks in a favorite order
Insert a disc and press MEMORY during stop.
1
MEMORY
T: Title number CT: Chapter number
or track number
The following display appears.
Memory List
:
:
--
---
1
T
CT
:
:
--
---
2
T
CT
:
:
--
---
3
T
CT
:
:
--
---
4
T
CT
:
:
--
---
5
T
CT
:
:
--
---
6
T
CT
:
:
--
---
7
T
CT
Select the items in the order you want by pressing the number buttons, then
2
ENTER for each item.
Each time you press the / buttons, the spaces of “T” and “CT” are highlighted in turn. Highlight where you want to enter, then press the corresponding number buttons.
To select another chapter in the same title, you do not need to select the title number.
To select tracks from a VIDEO CD/audio CD in order, press the number buttons for the track, then press the ENTER button for each selection you want.
Press PLAY while the display appears on the TV screen.
3
PLAY
The DVD player starts memory playback.
T o change the programmed selections
1 While the display appears on the TV screen, press
/ / / buttons to highlight the item you
the want to change.
2 Change the selection following the instructions in
step 2.
T o cancel the programmed selections
1 While the display appears on the TV screen, press
/ buttons to highlight the item you want to
the cancel.
2 Press CLEAR.
T o resume normal playback from memory playback
Press CLEAR.
CLEAR
The memory playback indicator disappears.
Notes
• Some discs may not permit memory playback operation.
• If you press the REPEAT button during memory playback, the DVD player repeats the current memory playback.
• If you press the MEMORY or RETURN button while the display appears on the TV screen, the display disappears.
• The programmed selections will be cleared when: – you turn off the DVD player. – you open the disc tray.
36
Playing in Random Order
PLAY
You can play titles, chapters, or tracks in random order. (Random playback)
2 3
CLEAR
1, 2
DVD-VCDVCD
Playing titles, chapters, or tracks in random order
Press RANDOM.
RANDOM
1
The random mode menu appears.
Press RANDOM or / repeatedly to select the random playback mode.
2
RANDOM
ENTER
The mode changes as follows (when using the RANDOM button):
DVD-V
Chapter Random
DVD-V
Title Random
VCD
Track Random
CD
Track Random
Plays the chapters within the current title in random order.
Plays titles in random order. Plays tracks in random order. Plays tracks in random order.
To resume normal playback
Press CLEAR.
CLEAR
Advanced playback
Notes
• Some discs may not permit random playback operation.
• You cannot use the random playback function in conjunction with the memory playback function.
Press PLAY.
3
Random Off
Resumes normal playback.
If you select the random mode during playback, the DVD player automatically starts random playback after finishing the current title, chapter, or track.
The DVD player starts random playback. Press the PLAY button within about 5 seconds after you press the RANDOM button.
37
Advanced playback
58
Zooming a Picture
You can magnify areas within a picture.
DVD-VCDVCD
1
Zooming a picture
During normal, slow or still playback, press ZOOM, ZOOM+ or ZOOM–.
ZOOM
The DVD player enters the zoom playback mode, and a monitor scope and an icon appear.
e.g.
ZOOM/ZOOM+/ZOOM–
/ / / ENTER
Zoom point
To shift:
Press the
ENTER
To hide the monitor scope and the icon during zoom playback
Press / / / to select “EXIT,” and press ENTER.
/ / / buttons.
Select the zoom point and magnification level.
2
Magnification level
• To use the fixed levels: You can select from the following.
– Magnification – Image reduction – Normal playback
ZOOM
ENTER
• To zoom in (or to zoom out):
Press the ZOOM button repeatedly.
Alternatively press the “ZOOM” on the icon, and
press the ENTER button repeatedly.
Press repeatedly or press and hold the ZOOM+ (or ZOOM–) button.
/ / / buttons to select
ENTER
T o resume normal playback
Press ZOOM repeatedly until the monitor scope and the icon disappear.
Alternatively press icon, and press ENTER repeatedly until the monitor scope and the icon disappear.
Notes
• Some discs may not respond to zoom feature.
• During some scenes, the buttons may not work as described.
• Zooming does not work on subtitles or menus included on DVD video discs.
• While the icon is displayed, the / / / /ENTER buttons cannot work on menus included on DVD video discs. If you want to view the menus, cancel the zoom playback.
• The magnification level varies depending on the picture size you select.
/ / / to select “ZOOM” on the
38
Selecting the Sound Enhancement (E.A.M.*)
2
1, 2
ENTER
You can easily switch a preferred audio enhancement.
*E.A.M.: Enhanced Audio Mode
DVD-VCDVCD
Selecting the sound enhancement
Press E.A.M.
1
E.A.M.
The sound enhancement menu appears.
Press E.A.M or / repeatedly to select the sound enhancement.
2
E.A.M.
ENTER
Normal:
Normal sound.
3D:
To obtain expansive virtual surround sound effects from just two speakers.
To exit the audio enhancement selection
Press ENTER.
ENTER
Alternatively leave the DVD player unattended for about 5 seconds after having made a selection.
Notes
• Actual effects to sounds may vary depending on the speaker systems. Make selection according to your preference.
• Actual effects to sounds may vary depending on the disc.
• When the DVD player is connected to an amplifier equipped with Dolby Surround Pro Logic, select “Normal”. Otherwise, Dolby Surround Pro Logic may function differently than usual.
• Selecting “Dialogue” disables “Dynamic Range Control” function 59.
Spatializer® 3-Dimensional Sound Processing provided by Desper Products. Inc. Certain audio features of this product manufactured under a license from Desper Products, Inc., Spatializer device are trademarks owned by Desper Products, Inc.
®
and the circle-in-square
Advanced playback
Dialogue:
To control critical center channel information to make dialogue more intelligible (only when playing a DVD video disc recorded on the Dolby Digital recording system).
• To use this enhancement on sounds output from the BITSTREAM/PCM (DIGITAL) AUDIO OUT jack, be sure to set “Digital Output” to “PCM”.
59
39
Advanced playback
CLEAR
2
1, 2
Selecting the Camera Angle
If the scene was recorded from multiple angles, you can easily change the camera angle of the scene you are watching.
DVD-VCDVCD
Changing the camera angle
Press ANGLE while playing a scene recorded with multiple angles.
1
ANGLE
While playing a scene recorded with multiple angles, the angle icon ( flashes in the DVD display. Press the ANGLE button while the angle icon is flashing.
e.g.
1 2 3
Press ANGLE or / while the angle number is displayed on the TV screen.
2
ANGLE
ENTER
Each time you press the ANGLE button or the camera angle changes.
/ buttons, the
T o turn off the angle number display
Press CLEAR.
CLEAR
)
Notes
• You can change the camera angle during still playback. The camera angle changes to the new setting when you resume normal playback.
• If you pause a picture immediately after changing a camera angle, the resumed playback picture may not display the new camera angle.
40
You can change the camera angle directly by pressing the number buttons corresponding to its angle number instead of using the
/ buttons.
Selecting Subtitles
You can display subtitles on the TV screen and select a subtitle language from those included on the DVD video disc.
/ / / ENTER
DVD-VCDVCD
Good evening!
Selecting a subtitle language
Bonsoir!
¡Buenas tardes!
Press SUBTITLE during playback.
1
SUBTITLE
The current subtitle setting is displayed.
e.g.
Off
E
NG
1
FRE1
A
1
SP
The abbreviation of the language appears instead of the language name. Refer to the list of languages and their abbreviations.
65
Press SUBTITLE or / while the subtitle setting is displayed on the TV
2
screen.
SUBTITLE
Each time you press the SUBTITLE button or the subtitle languages included on the DVD video disc change.
/ buttons, the
SUBTITLE
To turn subtitles on or off
1 Press SUBTITLE during playback.
SUBTITLE
2 Press
Notes
• Some DVD video discs are set to display subtitles automatically, and you cannot turn them off even if you set the subtitle function to off.
• During some scenes, the subtitles may not appear immediately after you select “On.”
• Some DVD video discs will allow you to make subtitle selections and turn subtitles on or off only via the disc menu.
/ while the subtitle setting is displayed on
the TV screen, to select “On” or “Off.”
ENTER
Advanced playback
ENTER
To turn off the subtitle setting display, press the ENTER button.
Notes
• When you turn on the DVD player or replace a disc, the player returns to the initial default setting 61. When you select a subtitle language which is not included on the disc, the DVD player plays a prior language programmed on the disc.
• During some scenes, the subtitles may not appear immediately after you change the subtitle language.
41
Advanced playback
DVD-VCDVCD
1, 2
2
CLEAR
Selecting a Language
You can select a preferred language and sound recording system from those included on the disc.
Good morning!
Bonjour!
¡Buenos días!
Selecting a playback audio setting
Press AUDIO during playback.
1
2
AUDIO
The current audio setting is displayed.
e.g.
ENG1 PCM 2CH E
NG
2 2CHD
The abbreviation of the language appears instead of the language name. Refer to the list of languages and their abbreviations.
65
Press AUDIO or / while the audio setting is displayed on the TV screen.
AUDIO
Each time you press the AUDIO button or the settings included on the disc change.
/ buttons, the audio
Selecting sound channels of VIDEO CDs
You can switch left and right channels by pressing the AUDIO button repeatedly during playback.
AUDIO
Notes
• When you turn on the DVD player or replace a disc, player returns to the initial default setting 61. If you select a sound track which is not included on the disc, the DVD player plays a prior sound track programmed on the disc.
• Some discs allow you to change audio selections only via the disc menu. If this is the case, press the MENU button and choose the appropriate language from the selections on the disc menu.
42
ENTER
To turn off the audio setting display, press the CLEAR button.
Output sound conversion table
BITSTREAM/PCM jack
“Digital Output”
“Bitstream”
Bitstream PCM
PCM PCM
Bitstream Bitstream
Bitstream
PCM PCM
PCM PCM
Bitstream Bitstream
PCM PCM
56 59
“PCM”
PCM
ANALOG AUDIO
OUT Jacks
Noise
Input
DVD
video disc
VIDEO CD
Audio CD
Output
Dolby Digital
Dolby Digital
Linear PCM
DTS
MPEG1, MPEG2
MPEG1
Linear PCM 44.1 kHz/16 bit
DTS
MP3
: 3D sound enhancement can function.
• Signals of 96kHz from the BITSTREAM/PCM jack are depressed to 48 kHz by down sampling process when: – “3D” is selected. – “PCM Down Sampling” is set to “On.”
39
59
– a copyright protected disc is played.
• Quantization bit of signals of 20 bit or higher which is output from the BITSTREAM/PCM jack is 16 bit if they are in a copyright protected disc.
Advanced playback
43

Quick control

Simple use of a single button and the cursor control enables you to direct your playback, without manipulating many actual buttons.
Using the Virtual Remote Control - V-REMOTE -
Selecting the Playback Function
- QUICK ­Accessing Features
- NAVI -
Quick control
31
34
Using the Virtual Remote Control
- V -REMO TE -
Pressing one button can display a graphics based on-screen remote control that allows you to control playback as if you were doing it from the actual remote control.
DVD-VCDVCD
1
2
To turn off the Virtual Remote
Press V-REMOTE.
Note
Some discs may not permit this operation.
Using the virtual remote control
During playback, press V-REMOTE.
M
O
E
T
R
-
V
Press / / / to select the icon, and press ENTER.
ENTER
M
O
E
T
R
-
V
The graphic remote control (Virtual
E
Remote) appears. For the meaning of each icon, see right.
DVD-V
e.g.
1:25:30
1
1
E
Icons and features
See the pages in for details on the features.
Icon Function Page
** ** **
* You can access a desired location. After step 2,
perform the steps below:
** After step 2, a sub menu will appear. Perform step 2
on the page in
1 2
*
Current title/track number
*
Current chapter number
*
Elapsed time of the current title/track Audio setting Subtitle setting Angle setting Reverse slow motion playback Pause / Frame by frame playback To begin slow motion playback Playback starts from the beginning of
the current chapter or track. Normal playback To locate succeeding chapters or
tracks. Fast reverse playback To stop playback. Fast forward playback To turn off the Virtual Remote.
/ : steps 3 to 5 on
: steps 2 and 3 on
.
– – –
42 41 40
29 28 29
31
26
31
28 27 28
46
Selecting the Playback Function - QUICK -
Pressing one button can display a list of playback functions which are relevant to your current playback mode. You can check and modify them from the list.
1 2 - 5
DVD-VCDVCD
Selecting the playback function
During playback, press QUICK.
1
K
C
I
U
Q
The following on-screen display appears. (The actual display will vary depending on the playback status.)
e.g.
DVD-V
Quick
Memory
RepeatRepeat
A–B (Set A)
Random Bit Rate
Text Exit
Press / to select a desired item.
2
ENTER
e.g. To change the repeat mode:
Quick
Memory
RepeatRepeat
A–B (Set A)
Random Bit Rate
Text Exit
Press ENTER.
3
ENTER
e.g. The mode menu appears.
Chapter Repeat
Title Repeat All Repeat Repeat Off
Press ENTER.
5
ENTER
Quick menu
Memory : To program memory playback. Repeat : To select the repeat playback mode.
A-B (Set A) : At the beginning of a segment you want
Random : To select the random playback mode. Bit Rate : To activate the bitrate display.
Text : To activate the Text display.
Exit : To quit the on-screen display.
The on-screen display disappears and playback will resume according to your selection.
36
For the mode selections, see page to repeat, press the ENTER button. Then
at the end of the segment, press the ENTER button again. The segment is played repeatedly.
For the mode selections, see page (Bit rate: data transfer rate (Mbit/s)
Refers to the amount of picture, sound and subtitle data in the DVD video disc transferred per second. The larger the value, the more data processed, but this does not necessarily insure better picture quality.)
Text display: Displays DVD-Text data or CD-Text data if included on the disc. (Some content on the disc may not be displayed properly depending on the disc.)
35
Quick control
35
.
37
.
Press / to change the setting.
4
ENTER
e.g. To select the title repeat mode:
Chapter Repeat
Title Repeat
All Repeat Repeat Off
Note
Pressing the QUICK button again also exits the on-screen display.
47
Quick control
Accessing Features - NAVI -
The NAVI menu provides an icon based display from which you can easily access key playback function or setting.
DVD-VCDVCD
1
NAVI menu items
Press NAVI.
N
A
V
The NAVI menu appears.
I
e.g.
DVD-V
T o exit the NAVI menu
Press NA VI.
Alternatively press icon to the center position, and press ENTER.
C
Exit
C
1 2
3
N
A
V
I
/ to remove the highlight from an
ENTER
Press / / / to select a desired
2
feature icon.
For details on each feature, refer to the list on the next page.
ENTER
Press ENTER.
3
ENTER
Refer to the list on the next page and
4
follow the instructions detailed on subsequent pages.
Selection details appears.
Note
Depending on the disc, some features cannot be accessed.
48
Navi menu selections
STROBE VIEWER
SETUP
PREVIEW
CAPTURE
ANGLE VIEWER
PICTURE SETTING
E.A.M.
V-REMOTE
You can divide a desired scene into stop action frames for careful analysis.
You can change the default settings to customize performance to your preference.
You can display thumbnail views of the first scenes of titles or chapters and select a preferred one.
You can sample a scene from a playback picture and transform it into a background picture.
You can display all camera angles simultaneously and select a preferred one from them.
You can fine tune picture quality and store up to 3 custom picture settings in the memory of the DVD player.
You can easily switch a preferred audio enhancement.
You can control key playback functions using the graphics based on-screen remote control.
50
56
Quick control
50
51
51
52
39
46
C
C
DISPLAY
CLOSED CAPTION
You can view information about a disc and its operational status on the TV screen.
You can display closed captions included on a DVD disc without connecting a closed caption decoder to your TV.
53
53
49
Quick control
IntervalChapterTitle
>><<
Preview
54 6
1 2 3
Accessing Features - NAVI - (continued)
NAVI menu items
STROBE VIEWER
You can divide a desired scene into stop action frames for careful analysis.
After selecting this icon and pressing ENTER, the following on-screen display appears:
e.g.
FastNormalSlow
Strobe Viewer
>>
1 Press / / / to select.
ENTER
Slow: Still pictures at shorter intervals. Normal:Still pictures at normal intervals. Fast: Still pictures at longer intervals. >>: To view the next series of 6 pictures.
: To quit the on-screen display.
2 Press ENTER.
ENTER
PREVIEW
You can display thumbnail views of the first scenes of titles or chapters and select a preferred one.
After selecting this icon and pressing ENTER, the following on-screen display appears:
e.g.
1 Press / / / to select.
ENTER
1 - 6: To locate the scene. Title: To display the first scenes of titles (1 to 6). Chapter:To display the first scenes of chapters
(1 to 6).
Interval: To display scenes at intervals of about 10
minutes apart. << : To go to the previous page. >> : To go to the next page.
: To quit the on-screen display.
2 Press ENTER.
Note
Some discs or scenes may not permit this operation.
50
ENTER
Notes
• Some discs or scenes may not permit this operation.
• Some items may not be selected depending on the disc or scene.
• Some of the first scenes may not picked up depending on the disc.
CAPTURE
You can sample a scene from a playback picture and transform it into a background picture.
ANGLE VIEWER
You can display all camera angles simultaneously and select a preferred one from them.
After selecting this icon and pressing ENTER, the following on-screen display appears:
e.g.
Capture
Storing
Exit
1 Pause playback at a scene you want to capture. 2 Press / to select.
ENTER
Storing: To sample and store the current picture
in the player memory.
Exit: To quit the on-screen display.
3 Press ENTER.
After selecting this icon and pressing ENTER, the following on-screen display appears:
e.g.
1 2 3
5 64
8 97
Angle Viewer
When the scene contains 9 camera angles:
1 Press / / / to select.
ENTER
1-9 : To select the camera angle.
: To quit the on-screen display.
2 Press ENTER.
ENTER
Quick control
ENTER
The stored picture will be displayed as a background picture when the player is in the stop mode. It is necessary to confirm this process via
62
the setup menu
.
Notes
• You can store only one picture. Storing a new picture will erase the old one.
• No other operations are permitted while in the process of sampling and storage of background picture.
• Some discs or scenes may not permit this operation.
Note
Some discs or scenes may not permit this operation.
51
Quick control
Accessing Features - NAVI - (continued)
NAVI menu items
PICTURE SETTING
You can fine tune picture quality and store up to 3 custom picture settings in the memory of the DVD player.
After selecting this icon and pressing ENTER, the following on-screen display appears:
e.g.
1
2
3
1 Press / to select, and press ENTER.
ENTER
1, 2, 3: Select the desired custom memory
number. (Follow steps 2 to 4 below.)
3 Press ENTER.
The sub menu appears.
4 Press
/ to adjust the value, and press ENTER.
e.g.
Color
+
2
Contrast : -7 (Lower) to +7 (Higher) Brightness : -7 (Darker) to +7 (Brighter) Color: -7 (Duller) to +7 (Brighter) Tint : -7 (Redder) to +7 (Greener)
1
: On / Off
DNR* Edge Enhance*
2
: On / Off
All Reset : To restore all the elements to
the normal setting. A message will appear. Follow the procedure displayed on-screen.
*1: DNR: Digital Noise Reduction.
To view a picture with less video noise.
Notes
• Actual picture enhancement may vary depending on the quality of the disc.
• While the DNR feature can provide additional improvement in the reduction of noise in the video signal, it may produce undesirable picture artifacts on some discs.
• Depending on the disc, some kinds of picture details may be lost by the picture enhancement.
52
2 Press
/ to select the element.
e.g. When you select “Color”:
Picture Setting Contrast Brightness Color Tint DNR Edge Enhance All Reset
0 0 0 0 Off Off
*2: To enhance picture edges.
Note
The Tint adjustment is not available when connecting to a TV via the component video jacks (Y, P
B, PR).
Using the remote control to adjust the brightness
-
Press BRIGHTNESS (+/
). Each time you press the button, the brightness changes.
Using the remote control to select the DNR feature
Press DNR. Each time you press the button, the feature turns on or off.
DISPLAY
You can view information about a disc and its operational status on the TV screen.
After selecting this icon and pressing ENTER, the following on-screen display appears:
e.g.
Title : 1 Chapter : 23 Time : 1:23:45 Audio : ENG 1 D 2CH Subtitle : ENG 1 On Angle : 1/3 E.A.M. : Normal Zoom : Off Chapter repeat
CLOSED CAPTION
You can display closed captions
C
C
included on a DVD disc without connecting a closed caption decoder to your TV.
After selecting this icon and pressing ENTER, the following on-screen display appears:
e.g.
On Off
Quick control
To quit the on-screen display, press ENTER.
Note
Some discs or scenes may not permit this operation.
1 Press / to select.
ENTER
On : To display closed captions. Off: To disable closed captions.
2 Press ENTER.
ENTER
Notes
• While you are using on-screen displays (including the above one), you cannot view closed captions.
• When “On” is selected, some displays such as “ be disabled.
” may
53

Function Setup

You can change the default settings to customize performance to your preference.
Customizing the Function Settings
Table of Languages
Function setup
1, 6
2, 3, 4
RETURN
Customizing the Function Settings
You can change the default settings to customize performance to your preference.
DVD-VCDVCD
Setting procedure
Press SETUP during stop.
SETUP
The following on-screen display appears.
C
B
A
Picture TV Shape Progressive 4:3 Output Progressive Conversion Pause/Still Auto
4:3 LB Full Auto
Press / to select a symbol for the setting you want to change.
2
(See the next page.)
ENTER
Picture performance settings
Press / to select the setting you want to change, then press ENTER.
31
ENTER
Change the selection by / or other buttons, by referring to the
4
corresponding pages 58, then press ENTER.
ENTER
Repeat steps 3 and 4 to change other settings.
5
To select another operation, go back to step 2.
56
Press SETUP.
SETUP
Output sound settings
Language settings
C
B
A
Display settings
Operational settings
Initializing
6
T o return to the previous display
Press RETURN.
RETURN
Notes
• The on-screen display disappears also when you select “ ” and press the ENTER button.
• The SETUP button can function even during normal playback, however some operations may be inaccessible, and a message will appear. In this case, try again after playback is stopped.
The on-screen display disappears.
Setting Details
Page
TV Shape
Progressive 4:3 Output
DVD-V
DVD-V
VCD
To select a picture size according to the aspect ratio of your TV .
To select the video output of pictures recorded in 4:3 format. (Only when connected to a
58
58
PROGRESSIVE TV .)
Progressive Conversion
DVD-V
To select the system of output signal. (Only
58
when connected to a PROGRESSIVE TV .)
Pause/Still
DVD-V
To select the resolution of still pictures.
58
(Field/Frame)
PCM Down Sampling
DVD-V
To select a sound processing option according
59 to performance of the connected equipment. (Only when the BITSTREAM/PCM (DIGITAL) AUDIO OUT jack is connected.)
Digital Output
DVD-VCDVCD
To select an output sound format corresponding
59 to your system connection.
Dynamic Range Control
DVD-V
To turn on or off a function that makes faint sounds easier to hear even if you lower the
59 volume during late hours playback.
Karaoke V ocal
DVD-V
To turn on or off the vocal output during DVD
60 KARAOKE disc playback.
On-Screen Language
C
B
A
Disc Menu Language
Audio Language
DVD-VCDVCD
DVD-V
DVD-V
To select a preferred language for on-screen displays.
To select a preferred language for disc menus.
To select a preferred language for the sound
60
60
61
Function setup
track.
Subtitle Language
DVD-V
To select a preferred language for subtitles.
61
On-Screen Displays
Background
Screen Saver
Parental Lock
Remote Confirmation
Title Stop
PBC
Priority Contents
Initialize
DVD-VCDVCD
DVD-VCDVCD
DVD-V
DVD-V
DVD-VCDVCD
DVD-V
VCD
DVD-VCDVCD
To turn on or de-activate the operational status display on the TV screen.
To select the background color or background picture.
To turn the screen saver on or off.
To turn the parental lock function on or off.
To turn on or off the confirmation beeper announcing when each remote command received.
To turn on or off a feature that automatically stops playback after a title has been viewed.
To use the menu screen when playing a PBC­controllable VIDEO CD.
To select the playback priority between JPEG (picture) files and MP3 (audio) files.
To restore all settings to the factory set.
62
62
62
62
64
64
64
64
64
57
Function setup
Customizing the Function Settings (continued)
Setting details
C
B
A
Picture TV Shape Progressive 4:3 Output Progressive Conversion Pause/Still Auto
4:3 LB Full Auto
Progressive 4:3 Output
Select the video output of pictures recorded in 4:3 format. (Only when connected to a PROGRESSIVE TV.)
Full: Displays pictures expanded horizontally to fill
the 16:9 screen.
DVD-V VCD
TV Shape
DVD-V
4:3 Letterbox: Select when a standard 4:3 TV is
connected. Displays theatrical images with masking bars above and below the picture.
4:3 Normal: Select when a standard 4:3 TV is
connected. Displays pictures cropped to fill your TV screen. Either or both sides of the picture are cut off.
16:9 Widescreen: Select when a 16:9 wide TV is
connected.
Notes
• The displayable picture size is preset on the DVD video disc. Therefore, the playback picture of some DVD video discs may not conform to the picture size you select.
• When you play DVD video discs recorded in the 4:3 picture size only, the playback picture always appears in the 4:3 picture size regardless of the TV shape setting.
• If you select “16:9 Widescreen” and you own a 4:3 TV set, the DVD playback picture will be horizontally distorted during playback. Images will appear to be horizontally compressed. Always be sure that your TV shape conforms to the actual TV in use.
4:3: Displays images in 4:3 aspect ratio with
masking bars to the left and right of the picture. (Select this option when a connected TV cannot select 4:3 picture size. However, subtitles or menus may not work properly.)
Progressive Conversion
DVD-V
There are two types of source content in pictures recorded in DVD video discs: film content (pictures recorded from films at 24 frames per second) and video content (video signals recorded at 30 frames per second). Make this selection according to the type of content being viewed.
Auto: Select this position normally.
The DVD player automatically detects source content, film or video, of playback source, and converts that signal to the progressive output format in an appropriate method.
Video: The DVD player filters video signal, and
converts it to the progressive output format appropriately. Suitable for playback of video content pictures.
Film: The DVD player converts film content pictures
to the progressive output format appropriately. Suitable for playback of film content pictures. The progressive output feature will be most effective under this selection.
58
Note
Depending on the disc, pictures may be cut off or doubled. In this case, select “Video.”
Pause/Still
DVD-V
Auto: For normal use. Still and fast motion images
can be paused.
Frame: The resolution of still pictures is improved,
so that you can make a motionless picture more clearer when you pause it.
C
B
A
Audio PCM Down Sampling Digital Output
Dynamic Range Control Karaoke Vocal
Off Bitstream On Off
Digital Output
DVD-V CDVCD
Select the output sound format corresponding to your system connection. For details of sound recording systems, see 43.
PCM Down Sampling
DVD-V
Make this selection only when you use your audio equipment (e.g. receiver) connecting to the DVD player via the BITSTREAM/PCM (DIGITAL) AUDIO OUT jack.
According to performance of your connected receiver, select a sound processing option for playback of a disc that contains high frequency signals (sampling frequency 96 kHz).
Off: Select when your connected receiver processes
high frequency signals of 96 kHz. The DVD player outputs these signals as they are on the disc.
On: Select when your connected receiver does not
process high frequency signals of 96 kHz. The DVD player outputs these signals in a disc depressing the frequencies to 48 kHz.
Notes
• Regardless of this setting, high frequency signals on a DVD disc are down-converted to 48 kHz if that disc is copy protected.
• If you select “Off” because your connected receiver does not process high frequency signals of 96 kHz, you will not hear output sound from those signals.
Bitstream: Select when connected to an amplifier
equipped with a Dolby Digital, DTS,
21
MPEG1 or MPEG2 decoder.
22
The DVD player outputs digital audio information in the bitstream format when you play a DVD video disc recorded on the Dolby Digital, DTS, MPEG1 or MPEG2 recording system.
PCM: Select when connected to a 2 channel
digital stereo amplifier.
23
The DVD player outputs sounds in the PCM 2ch format when you play a DVD video disc recorded on the Dolby Digital, MPEG1 or MPEG2 recording system.
Note
When you make a connection to a TV, or Dolby Surround Pro Logic or stereo system via the analog audio jacks, select “Bitstream” or “PCM.”
Dynamic Range Control
DVD-V
Off: Full dynamic range is maintained. On: Dynamic range is reduced.
Notes
• This function works only during playback of Dolby Digital recorded discs.
• The level of Dynamic Range Reduction may differ depending on the DVD disc.
Function setup
59
Function setup
A
B
C
Language
Disc Menu Language Audio Language Subtitle Language
On-Screen Language
ENG ENG ENG – – –
A
B
C
Language
Disc Menu Language Audio Language Subtitle Language
On-Screen Language
ENG English
French Spanish Others
Code
E
S
ENG ENG – – –
A
B
C
Customizing the Function Settings (continued)
Setting details
Karaoke V ocal
DVD-V
Off: The primary vocal is not output. On: The primary vocal is output when it is recorded
on the disc.
Notes
• The vocal output feature is used during playback of Dolby Digital (multi-channel) recorded DVD KARAOKE discs. This feature allows you to turn off vocal audio tracks, or restore them for background accompaniment.
• When playing KARAOKE, connect appropriate audio equipment such as an amplifier to the DVD player.
On-Screen Language
DVD-V CDVCD
English: To view on-screen displays in English. Français:To view on-screen displays in French. Español: To view on-screen displays in Spanish.
Disc Menu Language
DVD-V
English: To display disc menus in English. French: To display disc menus in French. Spanish: To display disc menus in Spanish. Others: To make a further choice.
After pressing the ENTER button, follow steps 1) - 4) below.
1) Obtain the abbreviation of the preferred
65
language from the list
.
2) Select the first character by pressing the buttons.
3) Press the second character by pressing the
/ buttons to shift and select the
/ buttons.
/
60
4) Press the ENTER button.
Note
Some DVD video discs may not include your pre­selected language. In this case, the DVD player automatically displays disc menus consistent with the disc’s initial language setting.
Audio Language
Language
Disc Menu Language Audio Language Subtitle Language
On-Screen Language
ENG English
French Spanish No Subtitle Others
Code
A
A
ENG ENG – – –
A
B
C
DVD-V
English: To play sound tracks in English. French: To play sound tracks in French. Spanish: To play sound tracks in Spanish. Others: To make a further choice.
After pressing the ENTER button, follow steps 1) - 4) below.
1) Obtain the abbreviation of the preferred
65
language from the list
.
2) Select the first character by pressing the buttons.
3) Press the second character by pressing the
/ buttons to shift and select the
/ buttons.
C
B
A
Language On-Screen Language Disc Menu Language Audio Language Subtitle Language
ENG English
ENG
French Spanish
ENG
Others
– – –
Code
S
E
4) Press the ENTER button.
Note
Some DVD video discs may be played in a different language than you selected. A prior language may be programmed on the disc.
3) Press the / buttons to shift and select the second character by pressing the
/ buttons.
/
4) Press the ENTER button.
Notes
• Some DVD video discs may be set to display subtitles
in a different language than you selected. A prior subtitle language may be programmed on the disc.
• Some DVD video discs allow you to change subtitle
selections only via the disc menu. If this is the case, press the MENU button and choose the appropriate subtitle language from the selection on the disc menu.
Function setup
Subtitle Language
English: To display subtitles in English. French: To display subtitles in French. Spanish: To display subtitles in Spanish. No Subtitle: To disable subtitles. Others: To make a further choice.
1) Obtain the abbreviation of the preferred
2) Select the first character by pressing the
After pressing the ENTER button, follow steps 1) - 4) below.
language from the list buttons.
DVD-V
65
.
/
61
Function setup
Operation Parental Lock Remote Confirmation Title Stop
Off On Off
PBC
On
A
B
C
Priority Contents
JPG
>
MP3
Parental Lock
Security Code
– – – –
Customizing the Function Settings (continued)
Setting details
C
B
A
Display On-Screen Displays Background Screen Saver
On Gray On
On-Screen Displays
DVD-V CDVCD
Off: Operational modes (e.g. “ ”, “ ”) are not
displayed.
On: Operational modes (e.g. “ ”, “ ”) are
displayed on-screen.
Background
DVD-V CDVCD
Blue: Blue background. Gray: Gray background. Capture: To use a picture you sampled and stored in
the memory using the Capture feature
51
as a background.
Jacket: To use the jacket picture included on some
discs as a background. If it is not included, a gray background will be substituted.
Screen Saver
DVD-V
Off: The screen saver is disengaged. On: The screen saver operates.
Parental Lock
DVD-V
DVD video discs equipped with the parental lock function are rated according to their content. The contents allowed by a parental lock level and the way a DVD video disc can be controlled may vary from disc to disc. For example, if the disc allowed you could edit out violent scenes unsuitable for children and replace them with more suitable scenes, or lock out playback of the disc altogether.
• DVD video discs may or may not respond to the parental lock settings. This is not a defect in the DVD player. Make sure this function works with your DVD video discs.
Off: The parental lock feature does not function.
After pressing the ENTER button, follow step 1) below.
On: To activate the parental lock feature or change
the settings. After pressing the ENTER button, follow steps
1) - 3) below.
62
1) Press the number buttons to create a personal
Parental Lock
Area Code
U
S
Level
7
4-digit security code, then press the ENTER button. If you make a mistake before pressing the ENTER button, press the CLEAR button and enter your 4-digit security code again.
2) Enter the code of a country/area whose standards were used to rate the DVD video disc, referring to the list below.
Country/Area AUSTRALIA BELGIUM CANADA CHINA CHINA HONG KONG DENMARK FINLAND FRANCE GERMANY INDONESIA ITALY JAPAN MALAYSIA NETHERLANDS NORWAY PHILIPPINES RUSSIAN FEDERATION SINGAPORE SPAIN SWEDEN SWITZERLAND TAIWAN THAILAND UNITED KINGDOM UNITED STATES
Code
AU BE CA
CN
HK DK
FI FR DE
ID IT
JP
MY
NL
NO
PH
RU SG
ES SE
CH TW
TH
GB
US
a) Select the first character by pressing the
/ buttons.
b) Press the
the second character by pressing the
/ buttons to shift and select
/
buttons.
c) Press the ENTER button.
3) Press the
/ buttons to select the parental
lock level, then press the ENTER button.
You cannot play DVD video discs rated higher than the level you selected unless you cancel the parental lock function. For example, when you select level 7, discs rated higher than level 7 are locked out and cannot be played.
The parental lock level is equivalent to the following USA movie ratings.
Level 7: NC-17 Level 6: R Level 4: PG 13 Level 3: PG Level 1: G
The parental lock levels for other countries/areas than U.S. are included for future use. Check the appropriate parental lock level when you buy a DVD video disc equipped with the parental lock feature in the future.
To change the parental lock level
Follow steps 1) - 3).
To change your 4-digit security code
1) After selecting “On” or “Off,” press the STOP
button four times, then press the ENTER button.
STOP
STOP
STOP
STOP
ENTER
The 4-digit security code is cleared.
2) Press the number buttons to create a new
4-digit security code.
3) Press the ENTER button.
Function setup
Note
After making the “Parental Lock” setting, the on-screen display will disappear. To make other settings, press the SETUP button again to display them.
63
Function setup
Initialize All settings will be restored to pre-set levels.
Exit Yes
A
B
C
Customizing the Function Settings (continued)
Setting details
Remote Confirmation
Off: The beeper does not sound. On: The beeper sounds with each remote operation.
Title Stop
Off: The DVD player continues after playback of a
title is completed.
On: The DVD player stops after playback of a title is
completed.
PBC
Off: When playing a VIDEO CD without using the
menu.
On: To use the menu when playing a PBC-featured
VIDEO CD.
DVD-V
VCD
DVD-V CDVCD
Priority Contents
To select the playback priority between JPEG (picture) files and MP3 (audio) files.
JPG > MP3 : JPEG files take priority over MP3 MP3 > JPG : MP3 files take priority over JPEG
Refer to the separate booklet “Digital Photo Viewer” on how to play a disc containing JPEG format files.
files. files.
Initialize
To restore all settings to the factory set.
DVD-V CDVCD
1) Press the / buttons to select “Yes,” and press the ENTER button.
ENTER
2) Read the message, and if you really want to restore all settings, press the
/ buttons to
select “Yes,” and press the ENTER button.
ENTER
64
The message of completion appears.
Note
The “Parental Lock” setting is not restored to the factory set.
Table of Languages
Table of languages and their abbreviations
Abbreviation
– – –
CHI (ZH) DUT (NL) ENG (EN) FRE (FR) GER (DE) ITA (IT) JPN (JA) KOR (KO) MAY (MS) SPA (ES)
AA AB AF AM AR AS AY AZ BA BE BG BH BI BN BO BR CA CO CS CY DA DZ EL EO ET EU FA FI FJ FO FY GA GD GL
Language
No alternate language Chinese Dutch English French German Italian Japanese Korean Malay Spanish Afar Abkhazian Afrikaans Amharic Arabic Assamese Aymara Azerbaijani Bashkir Belorussian Bulgarian Bihari Bislama Bengali, Bangla Tibetan Breton Catalan Corsican Czech Welsh Danish Bhutani Greek Esperanto Estonian Basque Persian Finnish Fiji Faroese Frisian Irish Scottish Gaelic Galician
Abbreviation
GN GU HA HI HR HU HY IA IE IK IN IS IW JI JW KA KK KL KM KN KS KU KY LA LN LO LT LV MG MI MK ML MN MO MR MT MY NA NE NO OC OM OR PA PL PS
Language
Guarani Gujarati Hausa Hindi Croatian Hungarian Armenian Interlingua Interlingue Inupiak Indonesian Icelandic Hebrew Yiddish Javanese Georgian Kazakh Greenlandic Cambodian Kannada Kashmiri Kurdish Kirghiz Latin Lingala Laotian Lithuanian Latvian, Lettish Malagasy Maori Macedonian Malayalam Mongolian Moldavian Marathi Maltese Burmese Nauru Nepali Norwegian Occitan (Afan) Oromo Oriya Panjabi Polish Pashto, Pushto
Abbreviation
PT QU RM RN RO RU RW SA SD SG SH SI SK SL SM SN SO SQ SR SS ST SU SV SW TA TE TG TH TI TK TL TN TO TR TS TT TW UK UR UZ VI VO WO XH YO ZU
Language
Portuguese Quechua Rhaeto-Romance Kirundi Rumanian Russian Kinyarwanda Sanskrit Sindhi Sango Serbo-Croatian Singhalese Slovak Slovenian Samoan Shona Somali Albanian Serbian Siswati Sesotho Sundanese Swedish Swahili Tamil Telugu Tajik Thai Tigrinya Turkmen Tagalog Setswana Tongan Turkish Tsonga Tatar Twi Ukrainian Urdu Uzbek Vietnamese Volapük Wolof Xhosa Yoruba Zulu
Function setup
65

Others

Before Calling Service Personnel
Specifications LIMITED WARRANTY DVD
PLA YER
Others
Before Calling Service Personnel
Check the following guide for the possible cause of a problem before contacting service.
Symptoms and correction
Symptom
No power.
The DVD player turned off by itself.
No picture.
No sound.
The playback picture has occasional distortion.
Brightness is unstable or noises are present in the playback pictures.
The DVD player does not start playback.
Playback does not follow the course of the disc’s program.
Buttons do not work.
The remote control does not work properly.
Cause
• The power plug is disconnected.
• The automatic power off function turned the unit off.
• The TV is not set to receive DVD signal output.
• The video cable is not connected securely.
• The equipment connected with the audio cable is not set to receive DVD signal output.
• The audio cable is not connected securely.
• The audio receiver or TV is turned off.
• The setting of output sound format is incorrect.
• The disc is dirty.
• It is in fast forward or fast reverse playback.
• The effect of copy protection.
• No disc is inserted.
• An unplayable disc is inserted.
• The disc is placed upside down.
• The disc is not placed within the guide.
• The disc is dirty.
• The parental lock function is set.
• It is in the mode of repeat playback, memory playback, etc.
• Power supply fluctuations or other abnormalities such as static electricity may interrupt correct operations.
• The remote control is not pointed at the remote sensor of the DVD player.
• The remote control is too far from the DVD player.
• The batteries in the remote control are exhausted.
Correction
• Connect the power plug securely into the wall outlet.
• Press the PLAY button.
• Select the appropriate video input mode on the TV so the picture from the DVD player appears on the TV screen.
• Connect the video cable securely into the appropriate jacks.
• Select the correct input mode of the audio receiver so you can listen to the sound from the DVD player.
• Connect the audio cable securely into the appropriate jacks.
• Turn on the equipment connected with the audio cable.
• Select the proper audio setting.
• Eject the disc and clean it.
• Sometimes a small amount of picture distortion may appear. This is not a malfunction.
• Connect the DVD player directly to the TV. Avoid connecting the DVD player to a VCR or TV/VCR combination.
• Insert a disc.
• Insert a playable disc. (Check the disc type.)
• Place the disc with the playback side down.
• Place the disc correctly inside the guide on the disc tray.
• Clean the disc.
• Cancel the parental lock function or change the parental lock level.
• These operations may prevent a proper progress of the contents.
• Press and hold the ON/STANDBY button on the front panel for more than about 3 seconds. The DVD player turns off. Press the button again to turn it on. If the buttons still do not work, disconnect the power plug and insert it into the wall outlet again.
• Point the remote control at the remote sensor of the DVD player.
• Operate the remote control within about 7 m.
• Replace the batteries with new ones.
Page
18
27
26
18, 19
26
18-23
26
42, 56
59
9 –
18
26 10
26
26
9
56, 62
–
–
15
15
15
68
Specifications
DVD player / outputs / supplied accessories
DVD player
Power supply 120 V AC, 60 Hz Power consumption 16 W Mass 2.5 kg External dimensions 430 × 69 × 219 mm (W/H/D) Signal system Standard NTSC Laser Semiconductor laser, wavelength 650 nm / 780 nm Frequency range DVD linear sound : 48 kHz sampling 4 Hz to 22 kHz
96 kHz sampling 4 Hz to 44 kHz Signal-to-noise ratio More than 112 dB Audio dynamic range More than 108 dB Harmonic distortion Less than 0.002 % Wow and flutter Below measurable level (less than ±0.001 % (W.PEAK)) Operating conditions Temperature: 5 °C to 35 °C, Operation status: Horizontal
Outputs
Video output 1.0 V (p-p), 75 Ω, negative sync., pin jack × 1 S video output (Y) 1.0 V (p-p), 75 Ω, negative sync., Mini DIN 4-pin × 1
(C) 0.286 V (p-p), 75 Ω
Component video output (Y) 1.0 V (p-p), 75 Ω, negative sync., pin jack × 1
(P
B)/(PR) 0.7 V (p-p), 75 Ω, pin jack × 2
Audio output (BITSTREAM/PCM Optical connector × 1 OPTICAL)
Audio output (BITSTREAM/PCM 0.5 V (p-p), 75 Ω, pin jack × 1 COAXIAL)
Audio output (ANALOG AUDIO) 2.0 V (rms), 680 Ω, pin jacks (L, R) × 1
Supplied Accessories
Audio/video cable ................................................. 1
Remote control (SE-R0070) ................................. 1
Batteries (AAA) ..................................................... 2
• Designs and specifications are subject to change without notice.
Others
69
Others
LIMITED W ARRANTY DVD PLAYER
Toshiba America Consumer Products, Inc. (“TACP”), Toshiba Hawaii (“THI”) and Toshiba Canada Limited (“TCL”) make the following limited warranties. These limited warranties extend to original purchaser or any person receiving this set as a gift from the original purchaser and to no other purchaser or transferee.
Limited Ninety (90) Day Warranty
TACP/THI warrant this product against defects in materials or workmanship for a period of ninety (90) days after the date of original retail purchase. During this period, TACP/ THI will repair or replace a defective product or part, at their option, with a new or refurbished product or part without charge to you. You must deliver the entire product to a TACP/THI Authorized Service Station. You are responsible for all transportation and insurance charges for the unit to and from the Authorized Service Station. If you live in the U.S.A. you may, at your option, return your DVD Unit to:
Toshiba America Consumer Products Inc. Returns Center 1420C Toshiba Dr.
Lebanon, TN 37087 Upon receipt we will, at our option, exchange the DVD Unit with a new or refurbished unit. Canadian consumers are
requested to contact TCL. In Hawaii consumers are requested to contact THI.
Limited One (1) Y ear Warranty
TACP/THI further warrant the parts in this product against defects in materials or workmanship for a period of one (1) year after the date of original retail purchase. During this period, TACP/THI will repair or replace a defective product or part, at their option, with a new or refurbished product or part without charge to you, except that if a defective part is replaced after ninety (90) days from the date of the original retail purchase you pay labor charges involved in the replacement. You must also deliver the entire product to a TACP/THI Authorized Service Station. You are responsible for all transportation and insurance charges for the unit to and from the Authorized Service Station. If you live in the U.S.A. you may, at your option, return your DVD Unit to:
Toshiba America Consumer Products Inc.
Returns Center
1420C Toshiba Dr.
Lebanon, TN 37087 Upon receipt we will, at our option, exchange the DVD Unit with a new or refurbished unit. Canadian Consumers are
requested to contact TCL. In Hawaii consumers are requested to contact THI.
Rental Units
The warranty for rental units begin with the first rental or thirty (30) days from the date of shipment to the rental firm, whichever comes first.
Commercial Units
Products sold and used for commercial use have a limited ninety (90) day warranty for all parts and labor.
Owner’s Manual
You should read the owner’s manual thoroughly before operating this product. You should complete and mail the enclosed Demographic card within ten (10) days after you, or the person who has given you this product as a gift, purchased this product. This is one way to enable TACP to provide you with better customer service and improved products. Failure to return the card will not affect your rights under this warranty.
Your Responsibility
The above warranties are subject to the following conditions: (1) You must retain your bill of sale or provide other proof of
purchase.
(2) You must notify a TACP/THI/TCL /Authorized Service
Station within thirty (30) days after you discover a defective product or part.
(3) All warranty servicing of this product must be made by a
TACP/THI/TCL Authorized Service Station.
(4) U.S.A. warranties are effective only if the product is
purchased and operated in the Continental U.S.A. or Puerto Rico.
(5) Labor service charges for set installation. Set up,
adjustment of customer controls and installation or repair of antenna systems are not covered by this warranty. Reception problems caused by inadequate antenna systems are your responsibility.
(6) Warranties extend only to defects in materials or
workmanship as limited above and do not extend to any product or parts which have been lost or discarded by you or to damage to products or parts caused by misuse, accident, damage caused by Acts of God, such as lighting or fluctuations in electric power, improper installation, improper maintenance or use in violation of instructions furnished by us; or to units which have been altered or modified without authorization of TACP/ THI/TCL or to damage to products or part thereof which have had the serial number removed, altered, defaced or rendered illegible.
(7) Should you elect to return your DVD Unit to TACP after
the ninety (90) days and within one (1) year, or after the warranty period has expired: Call (800)-631-3811 to receive information concerning an exchange price. Payment must be enclosed with product in the form of a certified check or money order including reason for return.
(8) Physically damaged DVD Units are not acceptable for
repair or exchange whether in or out of warranty and will be returned as received.
70
How to Obtain Warranty Service
(1) Refer to the troubleshooting guide in your owner’s manual. This check list may solve your problem. (2) In the U.S.A., only call the TACP toll free number 800-631-3811, or if in Hawaii or Canada see listing below within (30)
days after you find a defective product or part.
(3) Arrange for the delivery of the product to the TACP/THI/TCL Authorized Service Station or TACP Return Center.
Products shipped to the Service Station must be insured and safely and securely packed, preferably in the original shipping carton, and a letter explaining the defect and also a copy of the bill of sale or other proof of purchase must be enclosed.
In the Continental United States contact:
Toll Free 800-631-3811
In Hawaii contact:
Toshiba Hawaii Inc. 327 Kamakee Street Honolulu, HA 96814 (808)-521-5377
In Canada contact:
Consumer Electronics Group 191 McNabb Street Markham, Ontario L3R 8H2 (905)-470-5400
Consumer Electronics Group 1643 North Service Road Droval, QC H9P 1J1 (514)-856-4100
Consumer Electronics Group 22171 Fraserwood Way Richmond, B.C. V6W 1J5 (604)-303-2500
All warranties implied by state law, including the implied warranties of merchantability and fitness for a particular purpose, are expressly limited to the duration of the limited warranties set forth above. With the exception of any warranties implied by state law as hereby limited, the foregoing warranty is exclusive and in lieu of all other warranties, guarantees, agreements and similar obligations of manufacturer or seller with respect to the repair or replacement of any parts. In no event shall TACP/THI be liable for consequential or incidental damages. No person, agent, distributor, dealer or company is authorized to change, modify or extend the terms of these warranties in any manner whatsoever. The time within which an action must be commenced to enforce any obligation of TACP/THI arising under the warranty or under any statute, or law of the United States or any state thereof, is hereby limited to ninety (90) days from the date you discover or should have discovered, the defect. This limitation does not apply to implied warranties arising under state law. This warranty gives you specific legal rights and you may also have other rights which may vary from state to state. Some states do not allow limitation on how long an implied warranty lasts, when an action may be brought, or the exclusion or limitation of incidental or consequential damages, so the above provisions may not apply to you.
ATTENTION CANADIAN CONSUMERS:
Canadian consumers are requested to complete the special Canadian “Warranty Registration Form” enclosed, and forward this completed form with a copy of bill of sale to TOSHIBA OF CANADA to “Register and Validate” their warranty. Product must be purchased from an Authorized Canadian Dealer. Products purchased in the U.S.A. and used in Canada are not covered by these warranties.
Others
IMPORTANT: PACKING AND SHIPPING INSTRUCTION
When you send the product to a Service Station, you must use the original carton box and packing material, then insert the original carton box containing the unit into another carton using more packing material.
71
Printed in China
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
