Introduction
2
DIGITAL VIDEO
DVD VIDEO PLAYER
SD-K510
OWNER’S MANUAL
Connections
Basic playback
Advanced
playback
Function setup
Others
18
26
34
48
58
79077224
S
PM0005171011
©2002 Toshiba Corporation
Introduction
SAFETY PRECAUTIONS
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
AVIS
WARNING : TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USERSERVICEABLE
PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY
ATTENTION: POUR EVITER LES CHOCS ELECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA
CAUTION: This Digital Video Disc Player employs a Laser System.
RISQUE DE CHOC ELECTRIQUE NE
PAS OUVRIR
TO RAIN OR MOISTURE. DANGEROUS HIGH VOLTAGES ARE PRESENT INSIDE THE
ENCLOSURE. DO NOT OPEN THE CABINET. REFER SERVICING TO QUALIFIED PERSONNEL
ONLY.
INSERT.
FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU FOND.
To ensure proper use of this product, please read this owner’s manual carefully and retain for
future reference. Should the unit require maintenance, contact an authorized service location see service procedure.
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of
uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk
of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature
accompanying the appliance.
The symbol for CLASS II (Double Insulation)
Use of controls or adjustments or performance of procedures other than those specified herein
may result in hazardous radiation exposure.
To prevent direct exposure to laser beam, do not try to open the enclosure.
Visible and invisible laser radiation when open and interlocks defeated.
DO NOT STARE INTO BEAM.
FCC NOTICE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rule. These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for help.
WARNING: Changes or modifications made to this equipment, not expressly approved by Toshiba, or parties
authorized by Toshiba, could void the user’s authority to operate the equipment.
2
The instructions shall state that an ALL-POLE MAINS SWITCH with a contact separation of at least 3 mm in
each pole shall be incorporated in the electrical installation of the building.
CAUTION: These servicing instructions are for use by qualified service personnel only. To reduce the risk of
electric shock do not perform any servicing other than that contained in the operating
instructions unless you are qualified to do so.
In the spaces provided below, record the Model and Serial No. located on the rear panel of your DVD video
player.
Model No. Serial No.
Retain this information for future reference.
Location of the required label
PRODUCT IS CERTIFIED BY THE MANUFACTURER TO
COMPLY WITH DHHS RULE 21 CFR SUBCHAPTER J
APPLICABLE AT THE DATE OF MANUFACTURE.
MANUFACTURED
1-1,SHIBAURA 1-CHOME,MINATO-KU.
TOKYO 105-8001,JAPAN
Introduction
3
Introduction
IMPORTANT SAFETY INSTRUCTIONS
CAUTION: PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS GIVEN IN THIS
OWNER’S MANUAL AND THOSE MARKED ON THE UNIT. RETAIN THIS BOOKLET FOR
FUTURE REFERENCE.
This set has been designed and manufactured to assure personal safety. Improper use can result in electric
shock or fire hazard. The safeguards incorporated in this unit will protect you if you observe the following
procedures for installation, use and servicing. This unit is fully transistorized and does not contain any parts that
can be repaired by the user.
DO NOT REMOVE THE CABINET COVER, OR YOU MA Y BE EXPOSED T O DANGEROUS VOL T AGE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL ONLY.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
4
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stov es, or other appar atus (including
amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades
with one wider than the other. A g rounding type plug has two blades and a third g rounding prong. The wide
blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet,
consult an electrician for replacement of the obsolete outlet.
10.Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
Introduction
11.Only use attachments/accessories specified by the manufacturer.
12.Use only with the cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to avoid injury from tip-over.
S3125A
5
Introduction
IMPORTANT SAFETY INSTRUCTIONS
13.Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate
normally, or has been dropped.
ADDITIONAL SAFETY INSTRUCTIONS
15.When you use headphones, keep the volume at a moder ate lev el. If you use the headphones continuously
with high volume sound, it may cause hearing damage.
16.Do not overload wall outlets; extension cords, or integral convenience receptacles as this can result in a
risk of fire or electric shock.
17.Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases,
shall be placed on the apparatus.
6
18.Keep your fingers well clear of the disc tra y as it is closing. Neglecting to do so ma y cause serious personal
injury.
19. Do not place a heavy object on or step on the apparatus. The object may fall, causing serious personal
injury and serious damage to the apparatus.
20.Do not use a cracked, deformed, or repaired disc. These discs are easily broken and may cause serious
personal injury and apparatus malfunction.
Introduction
7
Introduction
Precautions
Notes on handling
When shipping the DVD video player, the original
shipping carton and packing materials come in handy.
For maximum protection, repack the unit as it was
originally packed at the factory.
Do not use volatile liquids, such as insect spray, near
the DVD video player. Do not leave rubber or plastic
products in contact with the DVD video player for a
long time. They will leave marks on the finish.
The top and rear panels of the DVD video player may
become warm after a long period of use. This is not a
malfunction.
When the DVD video player is not in use, be sure to
remove the disc and turn off the power.
If you do not use the DVD video player for a long
period, the unit may not function properly in the
future. Turn on and use the DVD video player
occasionally.
Notes on locating
Place the DVD video player on a level surface. Do not
use it on a shaky or unstable surface such as a
wobbling table or inclined stand. The loaded disc may
come off the proper position and cause damage to
the DVD video player.
When you place this DVD video player near a TV,
radio, or VCR, the playback picture may become poor
and the sound may be distorted. In this case, place
the DVD video player away from the TV, radio, or
VCR.
Notes on moisture condensation
Moisture condensation damages the DVD video
player. Please read the following carefully.
Moisture condensation occurs, for example, when you
pour a cold drink into a glass on a warm day. Drops of
water form on the outside of the glass. In the same way,
moisture may condense on the optical pick-up lens
inside this unit, one of the most crucial internal parts of
the DVD video player.
f
o
m
e
o
l
p
i
s
m
a
x
E
n
o
c
Moisture condensation occurs during the
following cases.
When you bring the DVD video player directly from a
cold place to a warm place.
When you use the DVD video player in a room where
you just turned on the heater, or a place where the
cold wind from the air conditioner directly hits the unit.
In summer, when you use the DVD video player in a
hot and humid place just after you move the unit from
an air conditioned room.
When you use the DVD video player in a humid place.
t
u
r
e
s
n
a
e
t
i
d
o
n
!
Optical pick-up
lens
It’s too
warm!
Notes on cleaning
Use a soft, dry cloth for cleaning.
For stubborn dirt, soak the cloth in a weak detergent
solution, wring well and wipe. Use a dry cloth to wipe
it dry.
Do not use any type of solvent, such as thinner and
benzine, as they may damage the surface of the DVD
video player.
If you use a chemical saturated cloth to clean the unit,
follow that product’s instructions.
To obtain a clear picture
The DVD video player is a high technology, precision
device. If the optical pick-up lens and disc drive parts
are dirty or worn down, the picture quality becomes
poor. To obtain a clear picture, we recommend regular
inspection and maintenance (cleaning or parts
replacement) every 1,000 hours of use depending on
the operating environment. For details, contact your
nearest dealer.
8
Do not use the DVD video player when moisture
condensation may occur.
If you use the DVD video player in such a situation, it
may damage discs and internal parts. Remove the
disc, connect the power cord of the DVD video player
to the wall outlet, turn on the DVD video player, and
leave it for two or three hours. After two or three
hours, the DVD video player will have warmed up and
evaporated any moisture. Keep the DVD video player
connected to the wall outlet and moisture
condensation will seldom occur.
Wait!
Wall outlet
Notes on Discs
On handling discs
Do not touch the playback side of the disc.
Playback side
Do not attach paper or tape to discs.
On cleaning discs
Fingerprints and dust on the disc cause picture and
sound deterioration. Wipe the disc from the center
outwards with a soft cloth. Always keep the disc
clean.
Structure of disc contents
Normally, DVD video discs are divided into titles, and
the titles are sub-divided into chapters. VIDEO CDs and
audio CDs are divided into tracks.
DVD video disc
DVD video disc
Title 1 Title 2
Chapter 1 Chapter 2 Chapter 1 Chapter 2 Chapter 3
VIDEO CD/audio CD
VIDEO CD/audio CD
Track 1 Track 2 Track 3 Track 4 Track 5
Each title, chapter or track is assigned a number, which
is called “title number”, “chapter number” or “track
number” respectively.
There may be discs that do not have these numbers.
Introduction
If you cannot wipe off the dust with a soft cloth, wipe
the disc lightly with a slightly moistened soft cloth and
finish with a dry cloth.
Do not use any type of solvent such as thinner,
benzine, commercially available cleaners or antistatic
spray for vinyl LPs. It may damage the disc.
On storing discs
Do not store discs in a place subject to direct sunlight
or near heat sources.
Do not store discs in places subject to moisture and
dust such as a bathroom or near a humidifier.
Store discs vertically in a case. Stacking or placing
objects on discs outside of their case may cause
warping.
Notes on copyright
It is forbidden by law to copy, broadcast, show,
broadcast on cable, play in public, and rent copyrighted
material without permission.
DVD video discs are copy protected, and any recordings
made from these discs will be distorted.
This product incorporates copyright protection
technology that is protected by method claims of certain
U.S. patents and other intellectual property rights owned
by Macrovision Corporation and other rights owners.
Use of this copyright protection technology must be
authorized by Macrovision Corporation, and is intended
for home and other limited viewing uses only unless
otherwise authorized by Macrovision Corporation.
Reverse engineering or disassembly is prohibited.
9
Introduction
Notes on Discs (continued)
About this owner’s manual
This owner’s manual explains the basic instructions of
this DVD video player. Some DVD video discs are
produced in a manner that allows specific or limited
operation during playback. As such, the DVD video
player may not respond to all operating commands. This
is not a defect in the DVD video player. Refer to
instruction notes of discs.
” may appear on the TV screen during operation.
“
” means that the operation is not permitted by the
A “
DVD video player or the disc.
Notes on region numbers
The region number of this DVD video player is 1. If
region numbers, which stand for their playable area, are
printed on your DVD video disc and you do not find
ALL
or
, disc playback will not be allowed by the player.
1
(In this case, the DVD video player will display a
message on-screen.)
On VIDEO CDs
This DVD video player supports VIDEO CDs equipped
with the PBC (Version 2.0) function. (PBC is the
abbreviation of Playback Control.) You can enjoy two
playback variations depending on types of discs.
• VIDEO CD not equipped with PBC function
(Version 1.1)
Sound and movie can be played on this DVD video
player in the same way as an audio CD.
• VIDEO CD equipped with PBC function
(Version 2.0)
In addition to operation of a VIDEO CD not equipped
with the PBC function, you can enjoy playback of
interactive software with search function by using the
menu displayed on the TV screen (Menu Playback).
Some of the functions described in this owner’s
manual may not work with some discs.
Playable discs
This DVD video player can play the following discs.
Disc Mark
DVD
video
discs
VIDEO
CDs
Audio
CDs
The following discs are also available.
Some of these discs may be incompatible.
DIGITAL VIDEO
DVD-R discs of DVD video format
CD-R/CD-RW discs of CD-DA or VIDEO CD format
Contents
Audio
(moving
pictures)
Audio
video
(moving
pictures)
Audio
Disc
Size
12 cm
+
video
8 cm
12 cm
+
8 cm
12 cm
8 cm
(CD
single)
• You cannot play discs other than those listed above.
• You cannot play DVD-RAM discs or
non-standardized discs, etc., even if they may be
labeled as above.
• This DVD video player uses the NTSC color system,
and cannot play DVD video discs recorded in any
other color system (PAL, SECAM, etc.).
Maximum
playback time
Approx. 4 hours
(single sided disc)
Approx. 8 hours
(double sided disc)
Approx. 80 minutes
(single sided disc)
Approx. 160 minutes
(double sided disc)
Approx. 74 minutes
Approx. 20 minutes
Approx. 74 minutes
Approx. 20 minutes
10
Table of Contents
Introduction
SAFETY PRECAUTIONS .......................... 2
IMPORTANT SAFETY INSTRUCTIONS ... 4
Precautions ...............................................8
Notes on Discs .......................................... 9
Notes on region numbers ............................... 10
Table of Contents ................................... 11
Identification of Controls .......................12
Front panel ..................................................... 12
Rear panel ...................................................... 12
DVD display .................................................... 13
Remote control ............................................... 14
Loading batteries ............................................ 15
Operating with the remote control .................. 15
Connections
Connecting to a TV ................................. 18
Connecting to a TV ......................................... 18
Connecting to an audio system and TV
equipped with component video inputs ........ 19
Connecting to Optional Equipment ...... 20
Connecting to an amplifier equipped with a
Dolby Digital decoder ................................... 21
Connecting to an amplifier equipped with
Dolby Surround Pro Logic ............................ 21
Connecting to an amplifier equipped with a
DTS decoder ................................................ 22
Connecting to an amplifier equipped with an
MPEG2 audio decoder ................................. 22
Connecting to an amplifier equipped with a
digital audio input ......................................... 23
Basic playback
Playing a Disc ......................................... 26
Basic playback ................................................ 26
Variable Speed Playback ....................... 28
Playing in fast reverse or fast forward
directions ...................................................... 28
Playing frame by frame ................................... 28
Playing in slow-motion .................................... 29
Resuming playback from the same location ... 29
Locating a Desired Section ...................30
Locating a title using the top menu ................. 30
Locating a desired section by entering the
corresponding number ................................. 31
Locating a specific chapter or track ................ 31
Playing an MP3 Encoded CD ................. 32
Playing an MP3 encoded CD ......................... 32
Advanced playback
Accessing a Specific Location Directly ...
Entering the time counter of the desired
location ......................................................... 34
Playing Repeatedly ................................. 35
Repeating a title, chapter, or track .................. 35
Repeating a specific segment ........................ 35
Playing in a Favorite Order .................... 36
Setting titles, chapters, or tracks in a favorite
order ............................................................. 36
Playing in Random Order ......................37
Playing titles, chapters or tracks in random
order ............................................................. 37
Zooming a Picture .................................. 38
Zooming a picture ........................................... 38
Selecting the Picture Enhancement
(E.P.M.) .....................................................39
Selecting the picture enhancement ................ 39
Selecting the Sound Enhancement
(E.A.M.) .................................................... 40
Selecting the sound enhancement ................. 40
Selecting the Camera Angle ..................41
Changing the camera angle ........................... 41
Selecting Subtitles .................................42
Selecting a subtitle language ......................... 42
Selecting a Language............................. 43
Selecting a playback audio setting ................. 43
On-screen Display Operation ................44
On-screen display operation ........................... 44
Function setup
Customizing the Function Settings ...... 48
Setting procedure ........................................... 48
Setting details ................................................. 50
Table of Languages ................................ 56
Others
Before Calling Service Personnel .........58
Specifications ......................................... 59
LIMITED WARRANTY DVD VIDEO
PLAYER ................................................... 60
Introduction
34
11
Introduction
Identification of Controls
See the page in for details.
Front panel
ON/STANDBY indicator
ON/STANDBY
Remote sensor
ON/STANDBY button
Rear panel
26
26
15
DVD display
Disc tray
26
OPEN/CLOSE button
13
PLAY button
OPEN/CLOSE
26
SKIP buttons
PAUSE button
26
PAUSE
STOP
SKIP
PLAY
STOP button
27
31
27
VIDEO OUT jack
S VIDEO OUT jack
12
18
VIDEO OUT (Y/PB/PR)
(Component video) jacks
BPR
YP
VIDEO
R
S
ANALOG
COAXIAL
L
BITSTREAM/PCM
DIGITAL
VIDEO OUT
AUDIO OUT
BITSTREAM/PCM DIGITAL COAXIAL
AUDIO OUT jack
21 22 23
ANALOG AUDIO OUT (L/R) jacks
18
19
Power cord
18 19
DVD display
Pressing of the FL DIM button on the remote
control changes the brightness of the display.
Total playing time indicator
FL DIM
Normal
Dimmed
Introduction
Off
Play mode indicator
Chapter number indicator
Title number indicator
Memory playback indicator
Track number
Random playback indicator
M A-BR
TITLE TOTAL
indicator
CHP TRK
DVD
VCD
Multifunctional indicator (indicates operating status or
messages, etc.)
DVD/VIDEO CD/CD indicator
When you start playback, the elapsed time indicators appear. Pressing the FL SELECT button switches
them to the title/chapter/track number indicators. Some discs may not permit this operation.
The indicators vary depending on the kinds of discs you play.
Angle icon indicator
Repeat playback indicator
DVD video disc
• During playback:
Example
DVD
Some discs may not display chapter
numbers or elapsed time.
TITLE
Playing chapter 3 of title 2
CHP
VIDEO CD
• During playback:
Example
TRK
VCD
Playing track 6
Some discs may not display track
numbers or elapsed time.
Audio CD
• During playback:
Example
TRK
CD
Playing track 6
13
Introduction
Identification of Controls (continued)
The instructions in this manual describe the functions on the remote control. See the page in for details.
Remote control
OPEN/CLOSE
OPEN/CLOSE button
REV button
28
26
FWD
Power button
SKIPREV
26
FWD button
28
PAUSE/STEP button
STOP button
27
TOP MENU button
Direction buttons
48
( / / / )
CLEAR button
ANGLE button
SETUP button
DISPLAY button
SUBTITLE button
E.A.M. button
E.P.M. button
Number buttons
31
41
48
44
42
40
39
31
30
27 28
PAUSE/STEP
TOP MENU
CLEAR
ANGLE SUBTITLE AUDIO
SETUP SLOWZOOMDISPLAY
E.A.M. E.P.M.
456
78390
RANDOM
STOP PLAY
ENTER
FL SELECT
21
MEMORY
REPEAT
MENU
RETURN
FL DIM
SEARCH
T
+10
A-B RPT
SKIP buttons
PLAY button
ENTER button
31
26
48
MENU button*
RETURN button
AUDIO button
SLOW button
ZOOM button
FL DIM button
43
29
38
13
FL SELECT button
T button
31
48
13
14
RANDOM button
MEMORY button
37
36
A-B RPT button
REPEAT button
35
35
* MENU button
Use the MENU button to display the menu included on
many DVD video discs. To operate a menu, follow the
instructions in “Locating a title using the top menu.”
30
About the illustrations of the battery compartment
There are two types of battery compartment in the
supplied remote controls. (This does not mean a
difference in performance between the two.)
Refer to either illustration depending on the actual
remote control.
Loading batteries
Operating with the remote control
Introduction
Open the cover.
1
2
1
Insert batteries (AA size).
2
Make sure to match the + and – on the batteries
to the marks inside the battery compartment.
Close the cover.
3
Notes on batteries
Improper use of batteries may cause battery leakage and
corrosion. To operate the remote control correctly, follow the
instructions below.
• Do not insert batteries into the remote control in the wrong
direction.
• Do not charge, heat, open, or short-circuit the batteries.
Do not throw batteries into a fire.
• Do not leave dead or exhausted batteries in the remote
control.
• Do not use different types of batteries together, or mix old
and new batteries.
• If you do not use the remote control for a long period of
time, remove the batteries to avoid possible damage from
battery corrosion.
• If the remote control does not function correctly or if the
operating range becomes reduced, replace all batteries
with new ones.
• If battery leakage occurs, wipe the battery liquid from the
battery compartment, then insert new batteries.
Point the remote control at the remote
sensor and press the buttons.
30°
30°
Within about 7 m (23 feet)
Distance: About 7 m (23 feet) from the front of the
remote sensor
Angle: About 30° in each direction of the front of
the remote sensor
* Do not expose the remote sensor of the DVD video
player to a strong light source such as direct
sunlight or other illumination. If you do so, you may
not be able to operate the DVD video player via the
remote control.
Notes on the remote control
• Direct the remote control at the remote sensor of the DVD
video player.
• Do not drop or give the remote control a shock.
• Do not leave the remote control near an extremely hot or
humid place.
• Do not spill water or put anything wet on the remote
control.
• Do not open the remote control.
15
Connections
Read this chapter first to make all necessary
preparations.
Connecting to a TV
Connecting to an audio system
and TV equipped with
component video inputs
Connecting to an amplifier
equipped with a Dolby Digital
decoder
Connecting to an amplifier
equipped with Dolby Surround
Pro Logic
Connecting to an amplifier
equipped with a DTS decoder
Connecting to an amplifier
equipped with an MPEG2 audio
decoder
Connecting to an amplifier
equipped with a digital audio
input
Connections
Connecting to a TV
Connect the DVD video player to your TV.
For details of output sound, see 43.
Connecting to a TV
Signal flow
BPR
YP
VIDEO
R
S
ANALOG
COAXIAL
L
BITSTREAM/PCM
DIGITAL
VIDEO OUT
AUDIO OUT
To S VIDEO
OUT
(yellow)
To VIDEO
OUT
(red) (white)
To ANALOG AUDIO OUT
S video cable (not supplied)
If the TV has an S video input, connect the
DVD video player with an S video cable.
When using an S video cable, do not
connect the yellow video cable.
Audio/video cable (supplied)
To wall outlet
To video input
(yellow)
To S video input
TV or monitor with
audio/video inputs
• Make the following setting.
On-screen display
“Audio Out Select”
To audio inputs
(red)
Select:
“Analog 2ch”
(white)
Page
48
50
Notes
• Refer to the owner’s manual of the connected TV as well.
• When you connect the DVD video player to your TV, be sure to turn off the power and unplug both units from the wall outlet
before making any connections.
• If your television set has one audio input, connect the left and right audio outputs of the DVD video player to a Y cable
adapter (not supplied) and then connect to your TV.
• Connect the DVD video player directly to your TV. If you connect the DVD video player to a VCR, TV/VCR combination or
video selector, the playback picture may be distorted as DVD video discs are copy protected.
18
Connecting to an audio system and TV equipped with component video inputs
Connections
Signal flow
BPR
YP
VIDEO
R
S
ANALOG
(red)
COAXIAL
L
BITSTREAM/PCM
DIGITAL
VIDEO OUT
AUDIO OUT
(white)
To ANALOG AUDIO OUT
To P R
VIDEO
OUT
To P B
VIDEO
OUT
To Y
VIDEO
OUT
To audio inputs of
the amplifier
(red) (white)
To Y video input
To P B video input
To P R video input
Audio system
Component video (ColorStream®) outputs/inputs
Some TVs or monitors are equipped with component video inputs. Connecting to
these inputs allows you to enjoy higher quality picture playback.
Actual labels for component video inputs may vary depending on the TV
manufacturer. (ex. Y, R-Y, B-Y or Y, C
B, CR)
In some TVs or monitors, the color levels of the playback picture may be reduced
slightly or the tint may change. In such a case, adjust the TV or monitor for
optimum performance.
To wall outlet
TV or monitor with
component video inputs
• Make the following setting.
On-screen display
“Audio Out Select”
Select:
“Analog 2ch”
Page
48
50
Notes
• Refer to the owner’s manual of the connected equipment as well.
• When you connect the DVD video player to other equipment, be sure to turn off the power and unplug all of the equipment
from the wall outlet before making any connections.
• If you place the DVD video player near a tuner or radio, the radio broadcast sound might be distorted. In this case, place the
DVD video player away from the tuner and radio.
• The output sound of the DVD video player has a wide dynamic range. Be sure to adjust the receiver’s volume to a moderate
listening level. Otherwise, the speakers may be damaged by a sudden high volume sound.
• Turn off the amplifier before you connect or disconnect the DVD video player’s power cord. If you leave the amplifier power
on, the speakers may be damaged.
19
Connections
Connecting to Optional Equipment
You can enjoy high quality dynamic sounds by connecting the DVD video player
to optional audio equipment.
• For connection to your TV, see “Connecting to a TV”
18
19
.
• For details of output sound, see
43
.
• This section uses the following reference marks.
: Front speaker
: Rear speaker
: Sub woofer
: Center speaker
: Signal flow
Notes
• DO NOT connect the BITSTREAM/PCM AUDIO OUT jack
of the DVD video player to the AC-3 RF input of a Dolby
Digital Receiver. This input on your A/V Receiver is
reserved for Laserdisc use only and is incompatible with
the BITSTREAM/PCM AUDIO OUT jack of the DVD video
player.
• Connect the BITSTREAM/PCM AUDIO OUT jack of the
DVD video player to the “DIGITAL (COAXIAL)” input of a
Receiver or Processor.
• Refer to the owner’s manual of the connected equipment
as well.
• When you connect the DVD video player to other
equipment, be sure to turn off the power and unplug all of
the equipment from the wall outlet before making any
connections.
• The output sound of the DVD video player has a wide
dynamic range. Be sure to adjust the receiver’s volume to
a moderate listening level. Otherwise, the speakers may
be damaged by a sudden high volume sound.
• Turn off the amplifier before you connect or disconnect the
DVD video player’s power cord. If you leave the amplifier
power on, the speakers may be damaged.
Warning
• When you are connecting (via the BITSTREAM/PCM
AUDIO OUT jack) an AV decoder that does not have
Dolby Digital, Digital Theater Systems (DTS) or MPEG2
decoding function, be sure to set “Audio Out Select” to
“PCM” from the on-screen displays
high volume sound may damage your hearing as well
as the speakers.
• When playing DTS-encoded discs (audio CDs),
excessive noise may be output from the analog audio
output jacks. To avoid possible damage to the audio
system, you should take proper precautions when the
analog audio output jacks of the DVD video player are
connected to an amplification system. To enjoy DTS
Digital Surround™ playback, an external 5.1 channel
DTS Digital Surround™ decoder system must be
connected to the BITSTREAM/PCM AUDIO OUT jack of
the DVD video player.
48
50
. Otherwise,
20
Connecting to an amplifier equipped with a Dolby Digital decoder
Connections
Dolby Digital
Dolby Digital is the surround sound technology used in theaters showing the
latest movies, and is now available to reproduce this realistic effect in the home.
You can enjoy motion picture and live concert DVD video discs with this dynamic
realistic sound by connecting the DVD video player to a 6 channel amplifier
equipped with a Dolby Digital decoder or Dolby Digital processor. If you have a
Dolby Surround Pro Logic decoder, you will obtain the full benefit of Pro Logic
from the same DVD movies that provide full 5.1-channel Dolby Digital
soundtracks, as well as from titles with the Dolby Surround mark.
Manufactured under license from Dolby
Laboratories. “Dolby” “Pro Logic” and
the double-D symbol are trademarks of
Dolby Laboratories. Confidential
unpublished works. ©1992-1997 Dolby
Laboratories. All rights reserved.
• Use DVD video discs encoded via
the Dolby Digital recording
system.
• Make the following setting.
B PR
YP
Amplifier equipped with a
Dolby Digital decoder
To COAXIAL type
digital audio input
To BITSTREAM/
PCM AUDIO OUT
VIDEO
VIDEO OUT
AUDIO OUT
COAXIAL
R
L
S
ANALOG
BITSTREAM/PCM
DIGITAL
On-screen display Select:
“Bitstream”“Audio Out Select”
Recording system
D
75 Ω coaxial cable
Connecting to an amplifier equipped with Dolby Surround Pro Logic
Dolby Surround Pro Logic
You can enjoy the dynamic realistic sound of Dolby Surround Pro Logic by
connecting an amplifier and speaker system (right and left front speakers, a
center speaker, and one or two rear speakers).
With an amplifier equipped with Dolby Digital
Connect the equipment the same way as described in “Connecting to an
amplifier equipped with a Dolby Digital decoder.” Refer to that amplifier’s
owner’s manual and set the amplifier so you can enjoy Dolby Surround Pro
Logic sound.
With an amplifier not equipped with Dolby Digital
Connect the equipment as follows.
BPR
YP
*
Amplifier equipped with
Dolby Surround Pro Logic
To audio input
To ANALOG
AUDIO OUT
Audio cable
VIDEO
VIDEO OUT
AUDIO OUT
COAXIAL
L
R
S
ANALOG
BITSTREAM/PCM
DIGITAL
• Make the following setting.
On-screen display
“Audio Out Select”
Select:
“Analog 2ch”
Be sure to set “Audio Out Select”
to “Analog 2ch” when you enjoy
sounds of Dolby Surround Pro
Logic using this connection.
* Connect one or two rear speakers.
The output sound from the rear speakers
will be monaural even if you connect two
rear speakers.
Page
48
50
43
Page
48
50
21
Connections
Connecting to Optional Equipment (Continued)
Connecting to an amplifier equipped with a DTS decoder
Digital Theater Systems (DTS)
DTS is a high quality surround technology used in theaters and now available for
home use, on DVD video discs or audio CDs.
If you have a DTS decoder or processor, you can obtain the full benefit of 5.1
channel DTS encoded sound tracks on DVD video discs or audio CDs.
“DTS” and “DTS Digital Out” are
trademarks of Digital Theater Systems,
Inc.
• Use DVD video discs or audio
CDs encoded via the DTS
recording system.
• Make the following setting.
BPR
YP
Amplifier equipped with
a DTS decoder
To COAXIAL type
digital audio input
To BITSTREAM/
PCM AUDIO OUT
VIDEO
VIDEO OUT
AUDIO OUT
COAXIAL
R
L
S
ANALOG
BITSTREAM/PCM
DIGITAL
On-screen display
“Audio Out Select”
Select:
“Bitstream”
Recording system DTS
75 Ω coaxial cable
Connecting to an amplifier equipped with an MPEG2 audio decoder
MPEG2 sound
You can enjoy motion picture and live concert DVD video discs with
dynamic realistic sound by connecting an amplifier equipped with an
MPEG2 audio decoder or MPEG2 audio processor.
YP
Amplifier equipped with an
MPEG2 audio decoder
To COAXIAL type
digital audio input
75 Ω coaxial cable
To BITSTREAM/
PCM AUDIO OUT
VIDEO
L
R
S
ANALOG
BITSTREAM/PCM
BPR
VIDEO OUT
AUDIO OUT
COAXIAL
DIGITAL
• Use DVD video discs encoded via
the MPEG2 recording system.
• Make the following setting.
On-screen display Select:
“Bitstream”“Audio Out Select”
Recording system MPEG2
Page
48
50
43
Page
48
50
43
22
Connecting to an amplifier equipped with a digital audio input
Connections
2 channel digital stereo
You can enjoy the dynamic sound of 2 channel digital stereo by connecting an
amplifier equipped with a digital audio input and speaker system (right and left
front speakers).
BPR
YP
Amplifier equipped with
a digital audio input
To COAXIAL type
digital audio input
75 Ω coaxial cable
To BITSTREAM/
PCM AUDIO OUT
VIDEO
VIDEO OUT
AUDIO OUT
COAXIAL
R
L
S
ANALOG
BITSTREAM/PCM
DIGITAL
• Make the following setting.
On-screen display
“Audio Out Select”
Select:
“PCM”
Page
48
50
23
Basic playback
Begin your operation.
Playing a Disc
Variable Speed Playback
Locating a Desired Section
Playing an MP3 Encoded CD
Basic playback
OPEN/CLOSE
30
Playing a Disc
This section shows you the basics on how to play a disc.
CAUTION
Keep your fingers well clear of the disc tray as it is closing.
Neglecting to do so may cause serious personal injury.
ON/STANDBY indicator
ON/STANDBY
2, 43
STOP PLAY
PAUSE
OPEN/CLOSE
SKIP
STOP
PLAY
1
DVD
VCD
Basic playback
CD
Preparations
• When you want to view a disc, turn on the TV and select the video input connected to the DVD video player.
• When you want to enjoy the sound of discs from the audio system, turn on the audio system and select the input connected
to the DVD video player.
Press the power button (ON/STANDBY).
1
The DVD video player turns on.
The ON/STANDBY indicator on the
player illuminates.
When the DVD video player is turned on for
the first time, a message appears. Press
ENTER, and make the proper settings before
proceeding to step 2.
55
Press OPEN/CLOSE.
2
The disc tray opens.
Press OPEN/CLOSE to close the disc
4
tray.
Playback starts.
OPEN/CLOSE
If you insert a DVD video disc that contains a top
menu, a menu may appear. See “Locating a title
using the top menu.”
• You may need to press the TOP MENU or MENU
button to display disc menu (depending on the actual
DVD video disc.)
Note
If the disc tray contains a disc you have already played,
playback will begin from the location where you last stopped
playback.
29
PAUSE
Place the disc on the disc tray.
3
With the playback
side down
To start playback in the stop mode
Press PLAY.
PLAY
26
• There are two different disc sizes. Place the disc in
the correct guide on the disc tray. If the disc is out of
the guide, it may damage the disc and cause the
DVD video player to malfunction.
• Do not place a disc which is unplayable in this DVD
video player.
2, 4
1
PAUSE/STEP
PLAY
STOP
MENU
ENTER
/
TOP MENU
To obtain a higher quality picture
Occasionally, some picture noise not usually visible during a normal broadcast
may appear on the TV screen while playing a DVD video disc because the high
resolution pictures on these discs include a lot of information. While the amount of
noise depends on the TV you use with this DVD video player, you should generally
reduce the sharpness adjustment on your TV when viewing DVD video discs.
About
The
DVD VCD CD
DVD VCD CD
icons on the heading bar show the playable discs for the
function described under that heading.
DVD
: You can use this function with DVD video discs.
VCD
: You can use this function with VIDEO CDs.
CD
: You can use this function with audio CDs.
To pause playback (still mode)
Press PAUSE/STEP during playback.
PAUSE/STEP
To resume normal playback, press
the PLAY button.
• The sound is muted during still
mode.
To stop playback
Press STOP.
STOP
To remove the disc
Press OPEN/CLOSE.
Remove the disc after the disc tray
OPEN/CLOSE
opens completely.
Be sure to press the OPEN/CLOSE button to close
the disc tray after you remove the disc.
About the screen saver
If you pause a picture of a DVD video disc and leave it
still for a long while, the screen saver of the DVD video
player automatically appears (when “Screen Saver” is
53
set to “On”
). To turn off the screen saver, press the
PLAY button.
Automatic Power Off function
If the DVD video player is stopped, or the screen saver
is engaged for approximately 20 minutes, the DVD
video player will automatically turn itself off.
Basic playback
Notes
• Do not move the DVD video player during playback. Doing so may damage the disc.
• Use the OPEN/CLOSE button to open and close the disc tray. Do not push the disc tray while it is moving. Doing so may
cause the DVD video player to malfunction.
• Do not push up on the disc tray or put any objects other than discs on the disc tray. Doing so may cause the DVD video
player to malfunction.
• In many instances, a menu screen will appear after playback of a movie is completed. Prolonged display of an on-screen
menu may damage your television set, permanently etching that image onto its screen. To avoid this, be sure to press the
STOP button on your remote control once the movie is completed.
27
Basic playback
Variable Speed Playback
You can play discs at various speeds, and resume playback from the location
where you stopped playback.
DVD
VCD
Playing in fast reverse or fast forward directions
CD
REV
FWD
PLAY
STOP
PAUSE/STEP
SLOW
Press REV or FWD during playback.
REV FWD
DVD
Playing frame by frame
VCD
REV: Fast reverse playback
FWD: Fast forward playback
Each time you press the REV or
FWD button, the playback speed
changes.
Press PAUSE/STEP during still playback.
PAUSE/STEP
Each time you press the PAUSE/
STEP button, the picture advances
one frame.
To resume normal playback
Press PLAY.
PLAY
Notes
• The DVD video player mutes sound and subtitles during
reverse and forward scan of DVD video discs. However, the
DVD video player plays sound during fast forward or fast
reverse play of audio CDs.
• The playback speed may differ depending on the disc.
To resume normal playback
Press PLAY.
PLAY
Note
The sound is muted during frame by frame playback.
28
DVD
Playing in slow-motion
VCD
Press SLOW during playback.
SLOW
DVD
VCD
Resuming playback from the same location
CD
Each time you press the SLOW
button, the slow-motion speed
changes.
Press STOP at the location where you
want to interrupt playback.
1
STOP
The DVD video player memorizes
the location where playback is
stopped.
Press PLAY.
Press PLAY.
Note
The sound is muted during slow-motion playback.
To start playback from the beginning regardless
of the location where you stopped playback
1 Press STOP twice.
2 Press PLAY.
2
To resume normal playback
PLAY
The DVD video player resumes
playback from the location where
you stopped playback.
• If you want to return to the beginning of a DVD video
PLAY
STOP
PLAY
disc, open and close the disc tray once with the
OPEN/CLOSE button before pressing the PLAY
button.
The DVD video player effaces the
memory of the location.
DVD
Playback starts from the
beginning of the current title.
VCD
Playback starts from the
CD
beginning of the disc.
Basic playback
Notes
• Resuming cannot function when:
– you change the parental lock setting 53 or select a disc
menu language 51.
– you play a PBC-featured VIDEO CD while “PBC” 55 is set
to “On”.
– you open the disc tray.
• There may be a difference in the location where playback
resumes depending on the disc.
• Settings you changed using the on-screen displays while the
DVD video player keeps a location in the memory may
function only after the memory is cleared.
29
Basic playback
ENTER
/ / /
ENTER
TOP MENU
Locating a Desired Section
Normally, DVD video discs are divided into titles, and the titles are sub-divided into chapters. VIDEO CDs and audio CDs are
divided into tracks. You can quickly locate any specific title, chapter, or track.
DVD video disc
Title 1 Title 2
Chapter 1 Chapter 2 Chapter 1 Chapter 2 Chapter 3
DVD
Locating a title using the top menu
Track 1
VIDEO CD/audio CD
Track 2 Track 3 Track 4 Track 5
Press TOP MENU.
1
TOP MENU
Press / / / to select the title you
want.
2
ENTER
The top menu appears on the TV
screen.
e.g.
TITLE 1
TITLE 3
If the titles in the top menu are
assigned a number, you can directly
locate a specific title by pressing its
designated number with the number
buttons.
TITLE 2
TITLE 4
Press ENTER.
3
Playback starts from chapter 1 of the
selected title.
Notes
• The instructions above describe basic procedures which
may vary depending on the contents of the DVD video disc.
If different instructions appear on the TV screen, follow those
instructions.
• If you display the top menu during playback and press the
TOP MENU button again without selecting any title, the DVD
video player may resume playback from the point where you
first pressed the TOP MENU button (depending on the actual
DVD video disc.)
• This method of locating a title is available only on a disc that
contains a top menu.
• Instruction notes of discs may refer to the button that
displays the top menu as TITLE button.
30
PLAY
SKIP
PLAY
/ / /
ENTER
CLEAR
T
Number buttons
DVD
VCD
Locating a desired section by entering the corresponding number
CD
Press T.
1
If you are using a VIDEO CD/audio CD, skip step 2.
Then at step 3, enter the number for the track you
want using the number buttons.
SEARCH
T
Press / to select a section you want
to locate.
2
ENTER
Press / to enter a number of the
section.
3
ENTER
e.g.
e.g. When you want to locate a chapter.
Also the number buttons are
available.
e.g. To enter 25
1
1
52
1
1
+10 +10
or
–:––:––
–:––:––
Repeat steps 2 and 3 if necessary.
4
Press PLAY or ENTER.
5
Playback starts from
ENTER
Notes
• Pressing the CLEAR button resets the numbers. To clear the
display, press the T button several times.
• This method of locating a title is available only on a disc that
contains title numbers.
5
the selected section.
Basic playback
DVD
VCD
Locating a specific chapter or track
CD
Press SKIP or repeatedly to display
the chapter or track number you want.
Playback starts from the selected chapter or track.
SKIP
SKIP
To locate succeeding chapters or
tracks.
Playback starts from the beginning of
the current chapter or track.
When you press twice, playback starts
from the beginning of the preceding
chapter or track.
Notes
• Some titles may not display chapter numbers.
• If you press and hold the SKIP or button on the front
panel during playback, the DVD video player performs fast
reverse or fast forward playback. You can vary the speed by
pressing the button repeatedly.
To locate chapters or tracks during fast reverse or fast
forward playback, first press the PLAY button to resume
normal playback, then use the SKIP
• When you set “Title Stop” to “Off”
chapters in another title. If you go back to the preceding title
by pressing the SKIP button, the DVD video player
locates the first chapter of the title. When “Title Stop” is set
to “On,” you can access chapters only within the current title.
or button.
55
, you can access
31
Basic playback
/ / /
PLAY
ENTER
DISPLAY
PAUSE/STEP
2
3
Playing an MP3 Encoded CD
You can play MP3 files on this DVD video player.
Playing an MP3 encoded CD
MP3 disc compatible with this player is limited as follows:
• Playable discs: CD-ROM, CD-R (650MB / 74 min. only)
* CD-RW is not recommendable.
• Sampling Frequency: 44.1 kHz only
• Bit rate 32 kbps-320 kbps
• CD physical format: Mode 1, Mode 2 XA Form 1
• File system: ISO9660 Level 1
• File names are limited to eight characters or less and must incorporate “MP3” extension.
e.g.“********.MP3”
• File names cannot contain special characters such as “?!><+*}{`[@]:;\ /.,” etc.
• Total number of files on the disc should not exceed 254.
Place a CD that contains MP3 files on
the disc tray.
1
Press OPEN/CLOSE to load the disc.
2
OPEN/CLOSE
To stop playback, press STOP.
3
STOP
To pause playback
Press PAUSE/STEP during playback.
PAUSE/STEP
Selecting a track (file) in the disc
1 Press the DISPLAY button.
2 Select the MP3 icon using the
press the ENTER button.
A list of tracks appears.
3 Press the
want to play.
The current track being played is highlighted in
green.
4 Press the ENTER button to begin playback of the
selected track.
Playback starts.
To resume normal playback, press the
PLAY button.
/ buttons then
/ / / buttons to select a track you
Notes
• Some discs may not permit this operation.
• If you stop playback by pressing the STOP button, and then
press the PLAY button, playback will start from the beginning
of the track.
• The SKIP 31, REPEAT 35 and RANDOM 37 functions
are also available.
This DVD video player requires discs/recordings to meet
certain technical standards in order to achieve optimal
playback quality. Pre-recorded DVDs are automatically
set to these standards. There are many different types of
recordable disc formats (including CD-R containing MP3
files). Given the fact that technology in this area is still
maturing, Toshiba cannot guarantee that all genre of
recordable discs will produce optimal playback quality.
The technical criteria set out in this owner’s manual are
meant as a guide only.
Customers should also note that permission is required
in order to download MP3 files and music from the
internet. Toshiba has no right to grant such permission.
Permission should always be sought from the copyright
owner.
32
Advanced playback
Customizing the performance of your DVD video player.
Accessing a Specific Location
Directly
Playing Repeatedly
Playing in a Favorite Order
Playing in Random Order
Zooming a Picture
Selecting the Picture
Enhancement (E.P.M.)
Selecting the Sound
Enhancement (E.A.M.)
Selecting the Camera Angle
Selecting Subtitles
Selecting a Language
On-screen Display Operation
Advanced playback
2
1
3
3
Accessing a Specific Location Directly
You can access a specific location by entering its corresponding time (hours,
minutes, seconds).
DVD
VCD
Entering the time counter of the desired location
CD
Press T several times.
1
SEARCH
T
Press the number buttons to enter the
time.
2
e.g.
1 2 5 3 0
Press PLAY or ENTER.
You may have to press further
depending on the disc. Press the
button repeatedly until the clock icon
is highlighted.
e.g.
1
1
–:––:––
1
1:25:30
1
3
PLAY
ENTER
Playback starts from
the desired location.
Notes
• Some discs may not respond to this process.
• Some scenes may not be located precisely as you specified.
• This method for accessing specific locations is available
only within the current title of the DVD video disc or within
the current track of the VIDEO CD/audio CD.
34
Playing Repeatedly
You can play a specific title, chapter, track, or segment repeatedly.
(Title repeat, chapter/track repeat, A-B repeat)
DVD
VCD
Repeating a title, chapter, or track
CD
PLAY
CLEAR
REPEAT
A-B RPT
Press REPEAT.
1
REPEAT
DVD
VCD
Repeating a specific segment
CD
Press A-B RPT at the beginning of the
segment (point A) you want to play
1
repeatedly.
A-B RPT
Press A-B RPT again at the end of the
segment (point B).
2
A-B RPT
Each time you press the REPEAT
button, the repeat mode changes as
follows.
Chapter Repeat
DVD
Chapter Repeat
Title Repeat
DVD
VCD
Track Repeat
CD
DVD
VCD
All Repeat
CD
Repeat Off
A–
The DVD video player automatically
returns to point A and starts repeat
playback of the selected segment
(A-B).
Repeats the current
chapter.
Repeats the current
title.
Repeats the current
track.
Repeats the entire
disc.
Resumes normal
playback.
Press PLAY.
2
PLAY
To resume normal playback
Press CLEAR.
CLEAR
Note
Some discs may not permit repeat operation.
To resume normal playback
Press CLEAR.
CLEAR
Notes
• Some discs may not permit A-B repeat operation.
• You cannot set the A-B repeat function for a segment that
includes multiple camera angles 41.
• You can specify a segment only within the current title or
track (VIDEO CD).
• There may be a slight difference between point A and the
location where playback actually resumes depending on the
disc.
The DVD video player starts repeat
playback.
Press the PLAY button within about
5 seconds after you press the
REPEAT button.
Advanced playback
A–B
35
Advanced playback
Playing in a Favorite Order
You can combine your favorite titles, chapters, or tracks and play them in the
order you determine. You can program up to 30 selections into the memory.
(Memory playback)
DVD
VCD
Setting titles, chapters, or tracks in a favorite order
CD
3
/ / /
2
CLEAR
2
1
Insert a disc and press MEMORY during
stop.
1
MEMORY
The following display appears.
e.g.
:
:
--
---
1
T
CT
:
:
--
---
2
T
CT
:
:
--
---
3
T
CT
:
:
--
---
4
T
T: Title number
CT: Chapter number
or track number
CT
:
:
--
---
5
T
CT
:
:
--
---
6
T
CT
:
:
--
---
7
T
CT
Select the items in the order you want
by pressing the number buttons, then
2
ENTER for each item.
Each time you press the / button, the space
of “T” and “CT” is highlighted in turn. Highlight
where you want to enter, then press the
corresponding number buttons.
To select another chapter in the same title, you do
not need to select the title number.
To select tracks from a VIDEO CD/audio CD in
order, press the number buttons for the track,
then press the ENTER button for each selection
you want.
Note
The space of “T (Title)” may be showing a number.
Neglect this number when using a VIDEO CD/audio
CD.
To change the programmed selections
1 While the display appears on the TV screen, press
/ / / to move the highlighted bar to the item
you want to change.
2 Change the selection following the instructions in
step 2.
To cancel the programmed selections
1 While the display appears on the TV screen, press
/ to move the highlighted bar to the item you
want to cancel.
2 Press CLEAR.
To resume normal playback from memory
playback
Press CLEAR.
CLEAR
The memory playback indicator
disappears.
To program during playback
If you press the MEMORY button during playback, a
programming display appears.
Follow steps 2 and 3.
Notes
• Some discs may not permit memory playback operation.
• If you press the REPEAT button during memory playback,
the DVD video player repeats the current memory playback.
• If you press the MEMORY or RETURN button while the
display appears on the TV screen, the display disappears.
• The programmed selections will be cleared when you turn off
the DVD video player.
36
Press PLAY while the display appears
on the TV screen.
3
PLAY
The DVD video player starts memory
playback.
Playing in Random Order
You can play titles, chapters within a title, or tracks in random order.
(Random playback)
DVD
VCD
Playing titles, chapters or tracks in random order
CD
2
CLEAR
1
Press RANDOM.
1
RANDOM
DVD
DVD
VCD
CD
Each time you press the RANDOM
button, the random playback mode
changes as follows.
Chapter Random
Chapter Random
Title Random
Track Random
Random Off
If you press the RANDOM button
during playback, the DVD video
player automatically starts random
playback after finishing the current
title, chapter or track.
Plays the chapters
within the current title
in random order.
Plays the titles in
random order.
Plays the tracks in
random order.
Resumes normal
playback.
To resume normal playback
Press CLEAR.
CLEAR
Advanced playback
Notes
• Some discs may not permit random playback operation.
• You cannot use the random playback function in conjunction
with the memory playback function.
Press PLAY.
2
PLAY
The DVD video player starts random
playback.
Press the PLAY button within about
5 seconds after you press the
RANDOM button.
37
Advanced playback
/ / /
ZOOM
CLEAR
ENTER
50
Zooming a Picture
You can magnify areas within a picture.
DVD
Zooming a picture
Press ZOOM during normal, slow or still
playback.
ZOOM
e.g.
The DVD video player enters the
zoom playback mode and displays
the icon.
: As you repeatedly press the ENTER
(or ZOOM) button while “ZOOM” is
selected, the magnification level
changes.
Variation of the levels includes
image reduction.
: If you press the ENTER button while
“EXIT” is highlighted, you can turn
off the icon, keeping the current
magnification level.
You can shift the highlight within the
icon by the
/ / / buttons.
To resume normal playback
While “ZOOM” is selected, press ZOOM repeatedly to
turn off the icon.
Picture restores the size when the icon disappears.
ZOOM
• The ENTER button cannot cancel zoom playback if
you have turned off the icon by selecting “EXIT.” To
restore normal picture size, press the ZOOM button
to display the icon, then further press the ZOOM
button until the icon turns off.
Notes
• Some discs may not respond to zoom feature.
• During some scenes, the buttons may not work as
described.
• Zooming does not work on subtitles or menus included on
DVD video discs.
• While the icon is displayed, the / / / buttons cannot
work on menus included on the DVD video discs. If you want
to view the menus, turn off the icon.
• The magnification level varies depending on the picture size
you select.
CLEAR
ENTER
If you press and hold the
buttons, the zoom point shifts.
Pressing the CLEAR button restores
/ / /
the zoom point to the center of the
picture.
38
Selecting the Picture Enhancement (E.P.M.*)
ENTER
You can easily select a preferred picture enhancement.
*E.P.M.: Enhanced Picture Mode
DVD
VCD
Selecting the picture enhancement
CD
Press E.P.M.
1
E.P.M.
The picture enhancement menu
appears.
2
ENTER
1, 2
To exit the picture enhancement selection
Press ENTER.
Alternatively leave the DVD video
player unattended for about 5
seconds after having made a
selection.
Note
Actual effect to picture may vary depending on the TV. Make
selection according to your preference.
Advanced playback
Select the picture enhancement by
pressing E.P.M. or / .
2
Each time you press the button, the picture
enhancement changes.
Normal:
Standard black level (7.5 IRE).
Enhanced Black Level:
Enhanced Black Level (0 IRE).
Movie1:
Brightness levels raised for
enhanced picture clarity.
Movie2:
For deeper, richer color
reproduction.
Animation:
For enhanced color contrast.
39
Advanced playback
ENTER
Selecting the Sound Enhancement (E.A.M.*)
You can easily switch a preferred audio enhancement.
*E.A.M.: Enhanced Audio Mode
DVD
VCD
Selecting the sound enhancement
CD
Press E.A.M.
1
E.A.M.
The sound enhancement menu
appears.
Select the sound enhancement by
pressing E.A.M. or / .
2
2
ENTER
1, 2
To exit the audio enhancement selection
Press ENTER.
Alternatively leave the DVD video
player unattended for about 5
seconds after having made a
selection.
Notes
• Actual effects to sounds may vary depending on the speaker
system. Make selection according to your preference.
• Actual effects to sounds may vary depending on the disc.
• When the DVD video player is connected to an amplifier
equipped with Dolby Surround Pro Logic, select “Normal”.
Otherwise, Dolby Surround Pro Logic may function
differently than usual.
• Selecting “Dialogue” disables “Dynamic Range Control”
function 50.
Each time you press the button, the sound
enhancement changes.
Normal:
Normal sound.
3D*:
To obtain expansive virtual surround
sound effects from just two speakers.
Dialogue*:
To control dynamic range to make
dialogue more intelligible.
• To use this enhancement on sounds
output from the BITSTREAM/PCM
jack, be sure to set “Audio Out
Select” to “PCM.”
* Effective only during playback of
Dolby Digital recorded discs.
50
Manufactured under license from QSound Labs, Inc. U.S. patent
Nos. 5,105,462, 5,208,860 and 5,440,638 and various foreign
counterpart. Copyright QSound Labs, Inc. 1998-2002. QXpander
is a trademark of QSound Labs, Inc. All rights reserved.
TM
40
Selecting the Camera Angle
If the scene was recorded from multiple angles, you can easily change
the camera angle of the scene you are watching.
DVD
Changing the camera angle
2
ENTER
1, 2
CLEAR
Press ANGLE while playing a scene
recorded with multiple angles.
1
ANGLE
While playing a scene recorded with
multiple angles, the angle icon (
flashes in the DVD display.
Press the ANGLE button while the
angle icon is flashing.
e.g.
1
2
3
Press ANGLE or / while the angle
number is displayed on the TV screen.
2
ANGLE
ENTER
Each time you press the ANGLE
button, the camera angle changes.
You can change the camera angle
directly by pressing the number
buttons corresponding to its angle
number instead of using the
buttons.
Notes
• You can change the camera angle during still playback. The
camera angle changes to the new setting when you resume
normal playback.
• If you pause a picture immediately after changing a camera
)
angle, the resumed playback picture may not display the new
camera angle.
/
Advanced playback
To turn off the display, press the
CLEAR or ENTER button.
41
Advanced playback
SUBTITLE
/ / /
CLEAR
ENTER
Selecting Subtitles
You can display subtitles on the TV screen and select a subtitle language
from those included on the DVD video disc.
Bonsoir!Good evening! `Buenas tardes!
DVD
Selecting a subtitle language
Press SUBTITLE during playback.
1
SUBTITLE
The abbreviation of the language appears instead
of the language name. Refer to the list of
languages and their abbreviations.
Press SUBTITLE or / while the subtitle
setting is displayed on the TV screen.
2
SUBTITLE
ENTER
The current subtitle setting is
displayed.
e.g.
Off
JPN 1
FRE 1
SPA 1
56
Each time you press the SUBTITLE
button, the subtitle languages
included on the DVD video disc
change.
To turn subtitles on or off
1 Press SUBTITLE during playback.
SUBTITLE
2 Press
the TV screen, to select “On” or “Off.”
Notes
• Some DVD video discs are set to display subtitles
automatically, and you cannot turn them off even if you set
the subtitle function to off.
• During some scenes, the subtitles may not appear
immediately after you select “On.”
• Some DVD video discs will allow you to make subtitle
selections and turn subtitles on or off only via the disc menu.
/ while the subtitle setting is displayed on
ENTER
To turn off the subtitle setting display,
press the CLEAR or ENTER button.
Notes
• When you turn on the DVD video player or replace a disc, the player returns to the initial default setting 52.
When you select a subtitle language which is not included on the disc, the DVD video player plays a prior language
programmed on the disc.
• During some scenes, the subtitles may not appear immediately after you change the subtitle language.
42
Selecting a Language
ENTER
You can select a preferred language and sound recording system from those
included on the DVD video disc.
Good morning!
DVD
Selecting a playback audio setting
VCD
Bonjour!
¡Buenos días!
2
ENTER
1, 2
CLEAR
Press AUDIO during playback.
12
AUDIO
The current audio setting is
displayed.
Press AUDIO or / while the audio
setting is displayed on the TV screen.
AUDIO
Each time you press the AUDIO
button, the audio settings included
on the DVD video disc change.
e.g.
ENG1 PCM 2CH
ENG2 D 2CH
The abbreviation of the language appears instead
of the language name. Refer to the list of
languages and their abbreviations.
56
Selecting sound channels of VIDEO CDs
You can switch left and right channels by pressing the
AUDIO button repeatedly during playback.
If you press the
can select output sound format.
To turn off the audio setting display, press the
CLEAR or ENTER button.
Notes
• When you turn on the DVD video player or replace a disc,
player returns to the initial default setting 52.
If you select a sound track which is not included on the disc,
the DVD video player plays a prior sound track programmed
on the disc.
• Some discs allow you to change audio selections only via
the disc menu. If this is the case, press the MENU button
and choose the appropriate language from the selections on
the disc menu.
/ buttons, you
Output sound conversion table (sampling frequency/quantization bit)
and output jacks on the rear panel
jack
5048
ANALOG AUDIO
OUT jacks
48 kHz/20 bit
48 kHz/16 bit
48 kHz/20 bit
48 kHz/24 bit
96 kHz/16 bit
96 kHz/20 bit
96 kHz/24 bit
48 kHz/16 bit 48 kHz/16 bit 48 kHz/16 bit
44.1 kHz/16 bit 44.1 kHz/16 bit 44.1 kHz/16 bit
44.1 kHz/16 bit44.1 kHz/16 bit
BITSTREAM/PCM
48 kHz/16 bit
48 kHz/16 bit
48 kHz/16 bit
48 kHz/16 bit
48 kHz/16 bit
48 kHz/16 bit
44.1 kHz/16 bit
: 3D sound enhancement can function.
jack
“PCM”
ANALOG AUDIO
OUT jacks
48 kHz/16 bit
48 kHz/20 bit
48 kHz/24 bit
48 kHz/16 bit
48 kHz/20 bit
48 kHz/24 bit
44.1 kHz/16 bit
Discs
DVD video
discs
VIDEO CDs
Audio CDs
Recording system
Dolby Digital
Linear PCM
MPEG1, MPEG2
MPEG1
Linear PCM
48 kHz/16 bit
48 kHz/20 bit
48 kHz/24 bit
96 kHz/16 bit
96 kHz/20 bit
96 kHz/24 bit
DTS
44.1 kHz/16 bit
DTS
Audio selection from the menu
BITSTREAM/PCM
“Bitstream”“Analog 2ch”
jack
Bitstream 48 kHz/16 bit 48 kHz/20 bit
48 kHz/16 bit
48 kHz/16 bit
48 kHz/16 bit
48 kHz/16 bit
48 kHz/16 bit
48 kHz/16 bit
Bitstream
Bitstream
44.1 kHz/16 bit 44.1 kHz/16 bit
ANALOG AUDIO
OUT jacks
48 kHz/20 bit
48 kHz/16 bit
48 kHz/20 bit
48 kHz/24 bit
48 kHz/16 bit
48 kHz/20 bit
48 kHz/24 bit
48 kHz/16 bit
44.1 kHz/16 bit44.1 kHz/16 bit
BITSTREAM/PCM
Bitstream
48 kHz/16 bit
48 kHz/16 bit
48 kHz/16 bit
Bitstream
Bitstream
44.1 kHz/16 bit
Advanced playback
50
(Noise)Bitstream(Noise)Bitstream(Noise)Bitstream
43
Advanced playback
DISPLAY
ENTER
/
38
On-screen Display Operation
When you turn on the on-screen display, you can view information on operational
status and access features and settings.
DVD
VCD
On-screen display operation
CD
Press DISPLAY.
DISPLAY
The following display appears.
Each time you press the DISPLAY button, the on-screen display changes as follows.
If you press the
/ buttons to select an icon, then press the ENTER button, you can access the
specific feature.
When you select an icon (
See the pages in
), there is no need to press the ENTER button.
*
for details on the features.
e.g. When playing a DVD video disc
0:08:16
3
2
Press DISPLAY again.
-0:21:28
3
2
: Title number (Track number)
*
Locate a title or track using the number buttons.
: Chapter number
*
Locate a chapter using the number buttons.
: Elapsed time of the current title
*
To enter the time to locate a desired location.
: Audio setting
: Subtitle setting
: Angle setting
: To turn off the display.
: Title number (Track number)
*
Locate a title or track using the number buttons.
: Chapter number
*
Locate a chapter using the number buttons.
: Remaining time of the current title
*
To enter the time to locate a desired location.
: E.A.M. (Enhanced Audio Mode) setting
43
42
41
31
31
34
31
31
34
40
39
: E.P.M. (Enhanced Picture Mode) setting
: To zoom a picture.
: “Audio Out Select” setting
BST: Bitstream 2CH: Analog 2ch PCM: PCM
: To turn off the display.
50
44
Press DISPLAY again.
28
28
: Title number (Track number)
*
Locate a title or track using the number buttons.
: Chapter number
*
Locate a chapter using the number buttons.
31
31
Advanced playback
23
Press DISPLAY again.
2 3
To turn off the on-screen display, press
DISPLAY again.
0:08:16
OFF
9.6
: To stop playback.
27
: Playback starts from the beginning of the
current chapter or track.
31
: Fast reverse playback
: To start playback.
26
: Fast forward playback
: To locate succeeding chapters or tracks.
: To begin slow motion playback.
: To pause playback.
27
29
31
: To turn off the display.
The on-screen display will vary depending on the disc.
DVD
: Data transfer rate (Mbit/s)
= Amount of picture, sound and subtitle data in the
DVD video disc transferred per second.
The larger the value is, the more data processed,
but this does not necessarily insure better picture
quality.
CD
: CD-Text
Displays CD-Text data if included on the audio
CDs. (Some letters may not be displayed properly
depending on the disc.)
VCD
: The on-screen display turns off.
45
Function setup
You can change the default settings to customize
performance to your preference.
Customizing the Function
Settings
Table of Languages
Function setup
SETUP
Customizing the Function Settings
You can change the default settings to customize performance to your
preference.
DVD
VCD
Setting procedure
CD
2
RETURN
3, 4
1, 6
Press SETUP during stop.
SETUP
The following on-screen display
appears.
C
B
A
TV Shape
4:3 LB
Pause/Still
Auto
Press / to select a symbol for the
setting you want to change.
2
(See the next page.)
ENTER
Picture performance settings
Output sound settings
Press / to select the setting you
want to change, then press ENTER.
31
ENTER
ENTER
Change the selection by / or other
buttons, by referring to the
4
corresponding pages (50 – ), then
press ENTER.
ENTER
ENTER
Repeat steps 3 and 4 to change other
settings.
5
To select another operation, go back to step 2.
Press SETUP.
6
The on-screen display disappears.
48
C
B
A
Language settings
Display settings
Operational settings
Initial setup
To return to the previous display
Press RETURN.
RETURN
Notes
• The on-screen display disappears when you press the
SETUP button.
• The SETUP button can function even during normal
playback, however some operations may be inaccessible,
and a message will appear. In this case, try again after
playback is stopped.
Setting Details
Page
TV Shape
DVD
To select a picture size according to the aspect
50
ratio of your TV.
Pause/Still
DVD
To select the resolution of still pictures.
50
(Field/Frame)
Audio Out Select
Dynamic Range Control
DVD
VCD
DVD
To select an output sound format
CD
corresponding to your system connection.
To turn on or off a function that makes faint
50
50
sounds easier to hear even if you lower the
volume during late hours playback.
Karaoke Vocal
DVD
To turn on or off the vocal output during DVD
51
KARAOKE disc playback.
On-Screen Language
C
B
A
Disc Menu Language
Audio Language
DVD
VCD
DVD
DVD
CD
To select a preferred language for on-screen
displays.
To select a preferred language for disc menus.
To select a preferred language for the sound
51
51
52
track.
Subtitle Language
On-Screen Displays
Background
Screen Saver
DVD
DVD
VCD
DVD
VCD
DVD
CD
CD
To select a preferred language for subtitles.
To turn on or de-activate the operational status
display on the TV screen.
To select the background color or background
picture.
To turn the screen saver on or off.
52
53
53
53
Function setup
Parental Lock
Title Stop
PBC
On-Screen Language
TV Shape
Audio Out Select
DVD
DVD
VCD
DVD
VCD
To turn the parental lock function on or off.
To turn on or off a feature that automatically
53
55
stops playback after a title has been viewed.
To use the menu screen when playing a PBC-
55
controllable VIDEO CD.
To install the initial system setting.
CD
55
49
Function setup
Audio
Dynamic Range Control
Karaoke Vocal
Audio Out Select
Bitstream
On
Off
A
B
C
Customizing the Function Settings (continued)
Setting details
C
B
A
TV Shape
4:3 LB
Pause/Still
Auto
TV Shape
DVD
4:3 Letterbox: Select when a standard 4:3 TV is
connected.
Displays theatrical images with
masking bars above and below the
picture.
4:3 Normal: Select when a standard 4:3 TV is
connected.
Displays pictures cropped to fill
your TV screen. Either or both
sides of the picture are cut off.
16:9 Widescreen: Select when a 16:9 wide TV is
connected.
Notes
• The displayable picture size is preset on the DVD video
disc. Therefore, the playback picture of some DVD
video discs may not conform to the picture size you
select.
• When you play DVD video discs recorded in the 4:3
picture size only, the playback picture always appears
in the 4:3 picture size regardless of the TV shape
setting.
• If you select “16:9 Widescreen” and you own a 4:3 TV
set, the DVD playback picture will be horizontally
distorted during playback. Images will appear to be
horizontally compressed. Always be sure that your TV
shape conforms to the actual TV in use.
Pause/Still
DVD
Auto: For normal use. Still and fast motion images
can be paused.
Frame: The resolution of still pictures is improved,
so that you can make a motionless picture
more clearer when you pause it.
Audio Out Select
DVD
VCD
CD
Select the output sound format corresponding to your
system connection.
For details of sound recording systems, see 43.
Bitstream: Select when connected to an amplifier
equipped with a Dolby Digital, DTS,
21
MPEG1 or MPEG2 decoder.
22
The DVD video player outputs digital
audio information in the bitstream
format when you play a DVD video disc
recorded on the Dolby Digital, DTS,
MPEG1 or MPEG2 recording system.
Analog 2ch: Select when connected to a TV, or
Dolby Surround Pro Logic or stereo
system via the analog audio jacks.
18
19
21
PCM: Select when connected to a 2 channel
digital stereo amplifier.
23
The DVD video player outputs sounds
in the PCM 2ch format when you play a
DVD video disc recorded on the Dolby
Digital, MPEG1 or MPEG2 recording
system.
Dynamic Range Control
DVD
Off: Full dynamic range is maintained.
On: Dynamic range is reduced.
Notes
• This function works only during playback of Dolby
Digital recorded discs.
• The level of Dynamic Range Reduction may differ
depending on the DVD video disc.
50
Karaoke Vocal
Language
Disc Menu Language
Audio Language
Subtitle Language
On-Screen Language
ENG
ENG
ENG
– – –
A
B
C
Language
Disc Menu Language
Audio Language
Subtitle Language
On-Screen Language
ENG English
French
Spanish
Others
Code
E
S
ENG
ENG
– – –
A
B
C
DVD
Off: The primary vocal is not output.
On: The primary vocal is output when it is recorded
on the disc.
Notes
• The vocal output feature is used during playback of
Dolby Digital (multi-channel) recorded DVD KARAOKE
discs. This feature allows you to turn off vocal audio
tracks, or restore them for background
accompaniment.
• When playing KARAOKE, connect appropriate audio
equipment such as an amplifier to the DVD video
player.
C
B
A
On-Screen Language
DVD
VCD
CD
English: To view on-screen displays in English.
Français: To view on-screen displays in French.
Español: To view on-screen displays in Spanish.
Function setup
Disc Menu Language
DVD
English: To display disc menus in English.
French: To display disc menus in French.
Spanish To display disc menus in Spanish.
Others: To make a further choice.
After pressing the ENTER button, follow
steps 1) - 4) below.
1) Obtain the abbreviation of the preferred
56
language from the list
2) Select the first character by pressing the
.
/
buttons.
3) Press the
second character by pressing the
/ buttons to shift and select the
/ buttons.
4) Press the ENTER button.
Note
Some DVD video discs may not include your preselected language. In this case, the DVD video player
automatically displays disc menus consistent with the
disc’s initial language setting.
51
Function setup
Language
Disc Menu Language
Audio Language
Subtitle Language
On-Screen Language
ENG English
French
Spanish
No Subtitle
Others
Code
A
A
ENG
ENG
– – –
A
B
C
Customizing the Function Settings (continued)
Setting details
Audio Language
DVD
English: To play sound tracks in English.
French: To play sound tracks in French.
Spanish: To play sound tracks in Spanish.
Others: To make a further choice.
After pressing the ENTER button, follow
steps 1) - 4) below.
1) Obtain the abbreviation of the preferred
56
language from the list
.
2) Select the first character by pressing the
buttons.
3) Press the
second character by pressing the
/ buttons to shift and select the
/ buttons.
C
B
A
Language
On-Screen Language
Disc Menu Language
Audio Language
Subtitle Language
ENG English
ENG
French
Spanish
ENG
Others
– – –
Code
S
E
4) Press the ENTER button.
Note
Some DVD video discs may be played in a different
language than you selected. A prior language may be
programmed on the disc.
3) Press the / buttons to shift and select the
second character by pressing the
/ buttons.
/
4) Press the ENTER button.
Notes
• Some DVD video discs may be set to display subtitles
in a different language than you selected. A prior
subtitle language may be programmed on the disc.
• Some DVD video discs allow you to change subtitle
selections only via the disc menu. If this is the case,
press the MENU button and choose the appropriate
subtitle language from the selection on the disc menu.
52
Subtitle Language
DVD
English: To display subtitles in English.
French: To display subtitles in French.
Spanish: To display subtitles in Spanish.
No Subtitle: To disable subtitles.
Others: To make a further choice.
After pressing the ENTER button,
follow steps 1) - 4) below.
1) Obtain the abbreviation of the preferred
56
language from the list
.
2) Select the first character by pressing the
buttons.
/
A
Operation
Parental Lock
Title Stop
PBC
Off
Off
On
A
B
C
Operation
Parental Lock
Title Stop
PBC
Off
Security Code
On
Off
Off
On
A
B
C
– – – –
Display
On-Screen Displays
Background
Screen Saver
On
Gray
On
C
B
On-Screen Displays
DVD
VCD
CD
Off: Operational modes (e.g. “ ”, “ ”) are not
displayed.
On: Operational modes (e.g. “ ”, “ ”) are
displayed on-screen.
Background
DVD
VCD
CD
Blue: Blue background.
Gray: Gray background.
Picture: To use the picture which appears when you
turn on the DVD video player as a
background.
Jacket: To use the jacket picture included on some
discs as a background. If it is not included,
a gray background will be substituted.
Screen Saver
DVD
Off: The screen saver is disengaged.
On: The screen saver operates.
Parental Lock
DVD
DVD video discs equipped with the parental lock
function are rated according to their content. The
contents allowed by a parental lock level and the way
a DVD video disc can be controlled may vary from
disc to disc. For example, if the disc allowed you
could edit out violent scenes unsuitable for children
and replace them with more suitable scenes, or lock
out playback of the disc altogether.
• DVD video discs may or may not respond to the
parental lock settings. This is not a defect in the DVD
video player. Make sure this function works with your
DVD video discs.
Off: The parental lock feature does not function.
After pressing the ENTER button, follow step 1)
below.
On: To activate the parental lock feature or change
the settings.
After pressing the ENTER button, follow steps
1) - 3) below.
Function setup
(Continued)
53
Function setup
Operation
Parental Lock
Title Stop
PBC
Area Code
Off
Off
On
A
B
C
U
S
Level
7
Customizing the Function Settings (continued)
Setting details
(Continued)
1) Press the number buttons to create a personal
4-digit security code, then press the ENTER
button.
If you make a mistake before pressing the
ENTER button, press the CLEAR button and
enter your 4-digit security code again.
2) Enter the code of a country/area whose
standards were used to rate the DVD video
disc, referring to the list below.
Country/Area
AUSTRALIA
BELGIUM
CANADA
CHINA
CHINA HONG KONG
DENMARK
FINLAND
FRANCE
GERMANY
INDONESIA
ITALY
JAPAN
MALAYSIA
NETHERLANDS
NORWAY
PHILIPPINES
RUSSIAN FEDERATION
SINGAPORE
SPAIN
SWEDEN
SWITZERLAND
TAIWAN
THAILAND
UNITED KINGDOM
UNITED STATES
Code
AU
BE
CA
CN
HK
DK
FI
FR
DE
ID
IT
JP
MY
NL
NO
PH
RU
SG
ES
SE
CH
TW
TH
GB
US
a) Select the first character by pressing the
/ buttons.
b) Press the
/ buttons to shift and select
the second character by pressing the
buttons.
c) Press the ENTER button.
3) Press the
/ buttons to select the parental
lock level, then press the ENTER button.
You cannot play DVD video discs rated higher than
the level you selected unless you cancel the parental
lock function.
For example, when you select level 7, discs rated
higher than level 7 are locked out and cannot be
played.
The parental lock level is equivalent to the following
USA movie ratings.
Level 7: NC-17
Level 6: R
Level 4: PG 13
Level 3: PG
Level 1: G
The parental lock levels for other countries/areas
than U.S. are included for future use. Check the
appropriate parental lock level when you buy a DVD
video disc equipped with the parental lock feature in
the future.
To change the parental lock level
Follow steps 1) - 3).
To change your 4-digit security code
1) After selecting “On” or “Off,” press the STOP
button four times, then press the ENTER
button.
STOP STOP STOP STOP
ENTER
/
The 4-digit security code is cleared.
2) Press the number buttons to create a new
4-digit security code.
3) Press the ENTER button.
54
Title Stop
DVD
VCD
CD
Initial Setup
TV Shape
Audio Out Select
On-Screen Language
ENG
4:3 LB
Bitstream
A
B
C
ENTER
DVD
Off: The DVD video player continues after playback
of a title is completed.
On: The DVD video player stops after playback of a
title is completed.
VCD
PBC
Off: When playing a VIDEO CD without using the
menu.
On: To use the menu when playing a PBC-featured
VIDEO CD.
Initial Setup
1) Press the / buttons to select “On-Screen
Language,” and press the ENTER button.
Function setup
ENTER
2) Select a language pressing the
/ buttons,
and press the ENTER button.
See page
51
, “On-screen Language.”
ENTER
ENTER
3) Make your selection in the same manner as
step 1) then step 2).
50
See page
See page
, “TV Shape.”
50
, “Audio Out Select.”
55
Function setup
Table of Languages
Table of languages and their abbreviations
Abbreviation
– – –
CHI (ZH)
DUT (NL)
ENG (EN)
FRE (FR)
GER (DE)
ITA (IT)
JPN (JA)
KOR (KO)
MAY (MS)
SPA (ES)
AA
AB
AF
AM
AR
AS
AY
AZ
BA
BE
BG
BH
BI
BN
BO
BR
CA
CO
CS
CY
DA
DZ
EL
EO
ET
EU
FA
FI
FJ
FO
FY
GA
GD
GL
Language
No alternate
language
Chinese
Dutch
English
French
German
Italian
Japanese
Korean
Malay
Spanish
Afar
Abkhazian
Afrikaans
Amharic
Arabic
Assamese
Aymara
Azerbaijani
Bashkir
Belorussian
Bulgarian
Bihari
Bislama
Bengali, Bangla
Tibetan
Breton
Catalan
Corsican
Czech
Welsh
Danish
Bhutani
Greek
Esperanto
Estonian
Basque
Persian
Finnish
Fiji
Faroese
Frisian
Irish
Scottish Gaelic
Galician
Abbreviation
GN
GU
HA
HI
HR
HU
HY
IA
IE
IK
IN
IS
IW
JI
JW
KA
KK
KL
KM
KN
KS
KU
KY
LA
LN
LO
LT
LV
MG
MI
MK
ML
MN
MO
MR
MT
MY
NA
NE
NO
OC
OM
OR
PA
PL
PS
Language
Guarani
Gujarati
Hausa
Hindi
Croatian
Hungarian
Armenian
Interlingua
Interlingue
Inupiak
Indonesian
Icelandic
Hebrew
Yiddish
Javanese
Georgian
Kazakh
Greenlandic
Cambodian
Kannada
Kashmiri
Kurdish
Kirghiz
Latin
Lingala
Laotian
Lithuanian
Latvian, Lettish
Malagasy
Maori
Macedonian
Malayalam
Mongolian
Moldavian
Marathi
Maltese
Burmese
Nauru
Nepali
Norwegian
Occitan
(Afan) Oromo
Oriya
Panjabi
Polish
Pashto, Pushto
Abbreviation
PT
QU
RM
RN
RO
RU
RW
SA
SD
SG
SH
SI
SK
SL
SM
SN
SO
SQ
SR
SS
ST
SU
SV
SW
TA
TE
TG
TH
TI
TK
TL
TN
TO
TR
TS
TT
TW
UK
UR
UZ
VI
VO
WO
XH
YO
ZU
Language
Portuguese
Quechua
Rhaeto-Romance
Kirundi
Rumanian
Russian
Kinyarwanda
Sanskrit
Sindhi
Sango
Serbo-Croatian
Singhalese
Slovak
Slovenian
Samoan
Shona
Somali
Albanian
Serbian
Siswati
Sesotho
Sundanese
Swedish
Swahili
Tamil
Telugu
Tajik
Thai
Tigrinya
Turkmen
Tagalog
Setswana
Tongan
Turkish
Tsonga
Tatar
Twi
Ukrainian
Urdu
Uzbek
Vietnamese
Volapük
Wolof
Xhosa
Yoruba
Zulu
56
Others
Before Calling Service
Personnel
Specifications
LIMITED WARRANTY DVD
VIDEO PLAYER
Others
Before Calling Service Personnel
Check the following guide for the possible cause of a problem before contacting service.
Symptoms and correction
Symptom
No power.
The DVD video player turned
off by itself.
No picture.
No sound.
The playback picture has
occasional distortion.
Brightness is unstable or
noises are present in the
playback pictures.
The DVD video player does
not start playback.
Playback does not follow the
course of the disc’s program.
Buttons do not work.
The remote control does not
work properly.
Cause
• The power plug is disconnected.
• The automatic power off function turned
the unit off.
• The TV is not set to receive DVD signal
output.
• The video cable is not connected securely.
• The equipment connected with the audio
cable is not set to receive DVD signal
output.
• The audio cable is not connected securely.
• The audio receiver or TV is turned off.
• The setting of output sound format is
incorrect.
• The disc is dirty.
• It is in fast forward or fast reverse
playback.
• The effect of copy protection.
• No disc is inserted.
• An unplayable disc is inserted.
• The disc is placed upside down.
• The disc is not placed within the guide.
• The disc is dirty.
• The parental lock function is set.
• It is in the mode of repeat playback,
memory playback, etc.
• Power supply fluctuations or other
abnormalities such as static electricity may
interrupt correct operations.
• The remote control is not pointed at the
remote sensor of the DVD video player.
• The remote control is too far from the DVD
video player.
• The batteries in the remote control are
exhausted.
Correction
• Connect the power plug securely into the
wall outlet.
• Press the PLAY button.
• Select the appropriate video input mode
on the TV so the picture from the DVD
video player appears on the TV screen.
• Connect the video cable securely into the
appropriate jacks.
• Select the correct input mode of the
audio receiver so you can listen to the
sound from the DVD video player.
• Connect the audio cable securely into the
appropriate jacks.
• Turn on the equipment connected with
the audio cable.
• Select the proper audio setting.
• Eject the disc and clean it.
• Sometimes a small amount of picture
distortion may appear. This is not a
malfunction.
• Connect the DVD video player directly to
the TV. Avoid connecting the DVD video
player to a VCR or TV/VCR combination.
• Insert a disc.
• Insert a playable disc. (Check the disc
type and color system.)
• Place the disc with the playback side
down.
• Place the disc correctly inside the guide
on the disc tray.
• Clean the disc.
• Cancel the parental lock function or
change the parental lock level.
• These operations may prevent a proper
progress of the contents.
• Press and hold the ON/STANDBY button
on the front panel for more than about 3
seconds. The DVD video player turns off.
Press the button again to turn it on. If the
buttons still do not work, disconnect the
power plug and insert it into the wall
outlet again.
• Point the remote control at the remote
sensor of the DVD video player.
• Operate the remote control within about
7 m.
• Replace the batteries with new ones.
Page
18
27
26
18, 19
26
18 – 23
26
43, 48
50
9
–
18
26
10
26
26
9
48, 53
–
–
15
15
15
58
Specifications
DVD video player / outputs / supplied accessories
DVD Video Player
Power supply 120 V AC, 60 Hz
Power consumption 14 W
Mass 2.2 kg
External dimensions 430 × 60 × 222 mm (W/H/D)
Signal system Standard NTSC
Laser Semiconductor laser, wavelength 650/780 nm
Frequency range DVD linear sound : 48 kHz sampling 4 Hz to 22 kHz
96 kHz sampling 4 Hz to 44 kHz
Signal-to-noise ratio More than 112 dB
Audio dynamic range More than 102 dB
Harmonic distortion Less than 0.002 %
Wow and flutter Below measurable level (less than ±0.001 % (W.PEAK))
Operating conditions Temperature: 5 °C to 35 °C, Operation status: Horizontal
Others
Outputs
Video output 1.0 V (p-p), 75 Ω, negative sync., pin jack × 1
S video output (Y) 1.0 V (p-p), 75 Ω, negative sync., Mini DIN 4-pin × 1
(C) 0.286 V (p-p), 75 Ω
Component video output (Y) 1.0 V (p-p), 75 Ω, negative sync., pin jack × 1
(P
B)/(PR) 0.7 V (p-p), 75 Ω, pin jack × 2
Audio output (BITSTREAM/PCM 0.5V (p-p), 75 Ω, pin jack × 1
COAXIAL)
Audio output (ANALOG) 2.0 V (rms), 680 Ω, pin jacks (L, R) × 1
Supplied Accessories
Audio/video cable ................................................. 1
Remote control (SE-R0047) ................................. 1
Batteries (AA) ....................................................... 2
• Designs and specifications are subject to change without notice.
59
Others
LIMITED W ARRANTY DVD VIDEO PLAYER
Toshiba America Consumer Products, Inc. (“TACP”) and Toshiba Hawaii, Inc. (“THI”) make the following limited warranties to
original consumers for DVD Players purchased and used in the United States. THESE LIMITED WARRANTIES EXTEND TO
THE ORIGINAL CONSUMER PURCHASER OR ANY PERSON RECEIVING THIS DVD PLAYER AS A GIFT FROM THE
ORIGINAL CONSUMER PURCHASER AND TO NO OTHER PURCHASER OR TRANSFEREE.
PRODUCTS PURCHASED IN THE U.S.A. AND USED IN CANADA ARE NOT COVERED BY THESE WARRANTIES.
PRODUCTS PURCHASED IN CANADA AND USED IN THE U.S.A. ARE NOT COVERED BY THESE WARRANTIES.
Limited One (1) Y ear Warranty*
TACP/THI warrants this DVD Player against defects in
materials or workmanship for a period of one (1) year after
the date of the original retail purchase. DURING THIS
PERIOD TACP/THI WILL, AT TACP/THI’S OPTION,
REPAIR OR EXCHANGE A DEFECTIVE DVD PLAYER
WITH A NEW OR REFURBISHED DVD PLAYER, AT TACP/
THI’s OPTION. DURING THE INITIAL NINETY (90) DAYS,
THIS REPAIR OR EXCHANGE WILL BE WITHOUT
CHARGE TO YOU, EXCEPT YOU MUST PAY FOR ALL
TRANSPORTATION AND INSURANCE CHARGES FOR
THE DVD PLAYER TO BE SHIPPED TO THE
DESIGNATED TACP/THI FACILITY. AFTER THE INITIAL
NINETY (90) DAYS AND FOR THE REMAINDER OF THE
WARRANTY PERIOD, AN ADDITIONAL HANDLING FEE
WILL APPLY. YOU MUST DELIVER THE ENTIRE DVD
PLA YER AND ALL A CCESSORIES (SUCH AS PO WER
CORDS, CABLES, AND THE UNIT’S REMOTE CONTROL
DEVICE) TO THE DESIGNATED TACP/THI FACILITY, AS
INSTRUCTED BY TACP/THI. TACP/THI IS NOT
RESPONSIBLE IF YOUR DVD PLAYER IS LOST OR
DAMAGED DURING SHIPMENT.
*Commercial Units
DVD Players sold and used for commercial purposes have
a limited ninety (90) day warranty.
Rental Units
The warranty period for rental units begins with the first
rental or thirty (30) days from the date of shipment to the
rental firm, whichever comes first.
Owner’s Manual and Demographic Card
You should read this owner’s manual thoroughly before
operating this DVD Player. You should complete and mail
the enclosed Demographic Card within ten days after you,
or the person who has given you this product as a gift,
purchased this DVD Player. This is one way to enable
TACP/THI to provide you with better customer service and
improved products. Failure to return the Demographic Card
will not affect your rights under this warranty.
Your Responsibility
THE ABOVE LIMITED WARRANTIES ARE SUBJECT TO
THE FOLLOWING CONDITIONS:
(1) You must provide your bill of sale or other proof of
purchase. For rental firms, proof of first rental is also
required.
(2) The limited warranties from TACP and THI are effective
only if the DVD Player is purchased and operated in the
U.S.A. or Puerto Rico.
(3) Labor service charges for installation, set up, and
adjustment of customer controls are not covered by
these limited warranties.
(4) These limited warranties extend only to defects in
materials or workmanship as limited above and do not
extend to any DVD Player or accessories which have
been lost or discarded by you, or to damage to any
DVD Player or accessories caused by misuse, accident,
Acts of God (such as lightning), or to fluctuations in
electric power, improper installation, improper
maintenance or use in violation of instructions furnished
by TACP/THI; or to units which have been modified or
which have had the serial number removed, altered,
defaced or rendered illegible.
(5) Physically damaged DVD Players are not acceptable
for repair or exchange whether in or out of warranty and
will be returned as received.
How to Obtain Warranty Services
If, after following all of the operating instructions in this
manual and checking the “Troubleshooting” section, you
find that service is needed, call one of the following
Customer Solutions Centers to obtain further instructions.
Have your proof of purchase and your model and serial
numbers available when you call.
For DVD Players purchased in the United States,
except Hawaii, call TACP, toll free at 1-866-583-7353.
For DVD Players purchased in Hawaii, call THI. at
808-591-9281.
For additional updates, visit TACP’s web site:
www.toshiba.com/tacp.
60
LIMITATION OF IMPLIED WARRANTIES
ALL WARRANTIES IMPLIED BY THE LAW OF ANY STATE
OF THE U.S.A., INCLUDING THE IMPLIED WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, ARE EXPRESSLY LIMITED TO
THE DURATION OF THE LIMITED WARRANTIES SET
FORTH ABOVE.
Time for T aking Action
The time within which action must be commenced to
enforce any obligation of TACP or THI arising under this
limited warranty or under any law of the United States or of
any state thereof is hereby limited to 90 days from the date
you discovered, or should have discovered, the defect. This
limitation does not apply to implied warranties arising under
the law of any state of the U.S.A.
LIMITATION OF WARRANTY
WITH THE EXCEPTION OF ANY WARRANTIES IMPLIED
BY THE LAW OF ANY STATE OF THE U.S.A. AS HEREBY
LIMITED, THE FOREGOING LIMITED WARRANTY IS
EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES,
GUARANTEES, A GREEMENTS AND SIMILAR
OBLIGATIONS OF TACP OR THI WITH RESPECT TO
YOUR DVD PLAYER.
HOW STATE LAW RELATES T O WARRANTY
THIS WARRANTY GIVES YOU SPECIFIC LEGAL
RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS
WHICH MAY VARY FROM STATE TO STATE IN THE
U.S.A.
SOME STATES OF THE U.S.A. DO NOT ALLOW
LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY
LASTS, WHEN AN ACTION MAY BE BROUGHT, OR THE
EXCLUSION OF DAMAGES
IN NO EVENT SHALL TACP OR THI BE LIABLE FOR
CONSEQUENTIAL OR INCIDENTAL DAMAGES.
EXCLUSION OR LIMITATION OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES, SO THE ABOVE
LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO
YOU UNDER SUCH CIRCUMSTANCES.
No Change, Modification, or Extension
No person, agent, distributor, dealer or company is
authorized to change, modify or extend the terms of these
limited warranties in any manner whatsoever.
ATTENTION CANADIAN CONSUMERS:
Canadian consumers are requested to complete the special Canadian “Warranty Registration Form” enclosed, and
forward this completed form with a copy of bill of sale to TOSHIBA OF CANADA to “Register and Validate” their warranty.
Product must be purchased from an Authorized Canadian Dealer. Products purchased in the U.S.A. and used in Canada
are not covered by these warranties.
Contact: Toshiba of Canada Limited
Consumer Electronics Group
191 McNabb Street
Markham, Ontario L3R 8H2
(905)-470-5400
Consumer Electronics Group
22171 Fraserwood Way
Richmond, B.C. V6W 1J5
(604)-303-2500
Consumer Electronics Group
1643 North Service Road
Droval, QC H9P 1J1
(514)-856-4100
Others
IMPORTANT: PACKING AND SHIPPING INSTRUCTION
When you send the product to a Service Station, you must use the original carton box and packing material, then insert the
original carton box containing the unit into another carton using more packing material.
61
Printed in China
Loading...
