TOSHmBA

V B D E O _ DIGHTALAUDHO

DVD VIDEO PLAYER

SD.3960SU

OWNER'S MANUAL

Page 2

SAFETY PRECAUTIONS

The lightning flash with arrowhead symbol, within an equi-

lateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage" within the product's en-

closure that may be of sufficient magnitude to constitute a

risk of electric shock to persons.

The exclamation point within an equilateral triangle is in- tended to alert the user to the presence of important operat-

ing and maintenance (servicing) instructions in the litera-

ture accompanying the appliance.

The symbol for CLASS II (Double Insulation)

WARNING:

CAUTION:

ATTENTION:

CAUTION:

FCC NOTICE:

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAiN OR MOISTURE. DANGEROUS HiGH VOLTAGES ARE PRESENT iNSiDE THE

ENCLOSURE. DO NOT OPEN THE CABINET. REFER SERVICING TO QUALIFIED PERSONNEL ONLY.

TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

POUR EVITER LES CHOCS ELECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU'AU FOND.

This Digital Video Disc Player employs a Laser System. To ensure proper use of this product, please read this owner's manual carefully and retain for

future reference. Should the unit require maintenance, contact an authorized service location -

see service procedure. Use of controls or adjustments or performance of procedures other than those specified herein

may result in hazardous radiation exposure. To prevent direct exposure to laser beam, do not try to open the enclosure.

Visible and invisible laser radiation when open and interlocks defeated. DO NOT STARE INTO BEAM.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rule. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

Changes or modifications made to this equipment, not expressly approved by Toshiba, or parties authorized by Toshiba, could void the user's authority to operate the equipment.

Page 3

TheinstructionsshallstatethatanALL-POLEMAINSSWITCHwithacontactseparationofatleast3mmin eachpoleshallbeincorporatedintheelectricalinstallationofthebuilding.

CAUTION: Theseservicinginstructionsareforusebyqualifiedservicepersonnelonly.Toreducetherisk

ofelectricshockdonotperformanyservicingotherthanthatcontainedintheoperating instructionsunlessyouarequalifiedtodoso.

Inthespacesprovidedbelow,recordtheModelandSerialNo.locatedontherearpanelofyourDVDvideo player.

ModelNo. SerialNo. Retainthisinformationforfuturereference.

Location of the required label

MANUFACTURED

O- c

¢b

SERIAL NO.

Be aware that this equipment is still powered even after the ON/STANDBY indicator turns off (standby mode) by pressing the ONISTANDBY button. To disconnect this equipment completely from the mains power, pull out the

power plug from the wall outlet.

Page 4

IMPORTANT SAFETY INSTRUCTIONS

CAUTION: PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS GIVEN IN THIS

OWNER'S MANUAL AND THOSE MARKED ON THE UNIT RETAIN THIS BOOKLET FOR FUTURE REFERENCE.

This set has been designed and manufactured to assure personal safety. Improper use can result in electric shock or fire hazard. The safeguards incorporated in this unit will protect you if you observe the following procedures for installation, use and servicing. This unit is fully transistorized and does not contain any parts that

can be repaired by the user. DO NOT REMOVE THE CABINET COVER, OR YOU MAY BE EXPOSED TO DANGEROUS VOLTAGE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL ONLY.

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

Page 5

7. Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.

Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet,

consult an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

O- c

¢b

11. Only use attachments/accessories specified by the manufacturer.

12.Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

Page 6

IMPORTANT SAFETY INSTRUCTIONS

13. Unplug this apparatus during lightning storms or when unused for long periods of time.

14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate

normally, or has been dropped.

ADDITIONAL SAFETY INSTRUCTIONS

15. When you use headphones, keep the volume at a moderate level. If you use the headphones continuously with high volume sound, it may cause hearing damage.

16. Do not overload wall outlets; extension cords, or integral convenience receptacles as this can result in a risk of fire or electric shock.

17.Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall be placed on the apparatus.

Page 7

18.Keep your fingers well clear of the disc tray as it is closing. Neglecting to do so may cause serious personal injury.

19.Do not place a heavy object on or step on the apparatus. The object may fall, causing serious personal injury and serious damage to the apparatus.

20. Do not use a cracked, deformed, or repaired disc. These discs are easily broken and may cause serious personal injury and apparatus malfunction.

21. If the apparatus should smoke or smell, immediately disconnect the power cord from the wall outlet. Wait until the smoke or smell stops, then ask your dealer for a check and repair. Neglecting to do so may cause

fire.

O- c

22.While it is thundering, do not touch the connecting cables or the apparatus.

23.The apparatus includes lead, an ingredient of solder used on the PCB, which is a harmful substance to

human and the environment. When disposing of this apparatus, follow the rules and regulations in your area.

Page 8

• When shipping the DVD video player, the original shipping carton and packing materials come in handy.

For maximum protection, repack the unit as it was

originally packed at the factory. Take care not to give it a shock or shake when carrying.

• Do not use volatile liquids, such as insect spray, near the DVD video player. Do not leave rubber or plastic

products in contact with the DVD video player for a long time. They will leave marks on the finish.

• The top and rear panels of the DVD video player may become warm after a long period of use. This is not a

malfunction.

• When the DVD video player is not in use, be sure to remove the disc and turn off the power.

• If you do not use the DVD video player for a long period, the unit may not function properly in the

future.Turn on and use the DVD video player occasionally.

• Place the DVD video player on a level surface. Do not use it on a shaky or unstable surface such as a wobbling table or inclined stand. The loaded disc may come off the proper position and cause damage to the DVD video player.

• When you place this DVD video player near a TV, radio, orVCR, the playback picture may become poor and the sound may be distorted. In this case, place

the DVD video prayer away from the TV, radio, or VCR.

Moisture condensation damages the DVD video player. P_ease read the following carefully.

Moisture condensation occurs, for example, when you pour a cold drink into a glass on a warm day. Drops of

water form on the outside of the glass. In the same way,

moisture may condense on the optical pick-up lens inside this unit, one of the most crucial internal parts of

the DVD video player.

Moisture condensation occurs during the following cases.

When you bring the DVD video player directly from a cold place to a warm place. When you use the DVD video player in a room where you just turned on the heater, or a place where the cold wind from the air conditioner directly hits the

unit. In summer, when you use the DVD video player in a

hot and humid place just after you move the unit from an air conditioned room.

When YOUUS_ +he F_\,'_ video player irbah_mid place.

o ©

o '_ FI < _dltstoo4

,, o " i J 'J L-/ warm,

Use a soft, dry cloth for cleaning.

• For stubborn dirt, soak the cloth in a weak detergent solution, wring well and wipe. Use a dry cloth to wipe it dry. Do not use any type of solvent, such as thinner and

benzine, as they may damage the surface of the DVD

video player.

• If you use a chemical saturated cloth to clean the unit, follow that product's instructions.

The DVD video player is a high technology, precision device. If the optical pick-up lens and disc drive parts

are dirty or worn down, the picture quality becomes

poor. To obtain a clear picture, we recommend regular inspection and maintenance (cleaning or parts

replacement) every 1,000 hours of use depending on

the operating environment. For details, contact your

nearest dealer.

Do not use the DVD video player when moisture condensation may occur.

If you use the DVD video player in such a situation, it may damage discs and internal parts. Remove the disc, connect the power cord of the DVD video player to the wall outlet, turn on the DVD video player, and

leave it for two or three hours. After two or three hours, the DVD video player will have warmed up and

evaporated any moisture. Keep the DVD video player connected to the wall outlet and moisture

condensation will seldom occur.

_--J'\ \

Page 9

on Discs

IOn handling discs

• Do not touch the playback side of the disc.

Playback side

• Do not attach paper or tape to discs.

• Fingerprints and dust on the disc cause picture and sound deterioration, Wipe the disc from the center

outwards with a soft cloth, Always keep the disc clean,

disccontents

Normally, DVD video discs are divided into titles, and the titles are sub-divided into chapters. VIDEO CDs and

audio CDs are divided into tracks.

DVD video disc

Title 2

Chapter1 Chapter2 Chapter

VIDEO CD/audio CD

Track 1 Track 2 Track 3 Track 4 Track 5

Each title, chapter or track is assigned a number, which is called "title number", "chapter number" or "track number" respectively. There may be discs that do not have these numbers.

O- c db

• If you cannot wipe off the dust with a soft cloth, wipe the disc lightly with a slightly moistened soft cloth and

finish with a dry cloth.

• Do not use any type of solvent such as thinner, benzine, commercially available cleaners or antistatic

spray for vinyl LPs. It may damage the disc.

• Do not store discs in a place subject to direct sunlight or near heat sources.

• Do not store discs in places subject to moisture and dust such as a bathroom or near a humidifier.

• Store discs vertically in a case. Stacking or placing objects on discs outside of their case may cause warping.

It is forbidden by law to copy, broadcast, show, broadcast on cable, play in public, and rent copyrighted material without permission.

DVD video discs are copy protected, and any recordings made from these discs will be distorted.

This product incorporates copyright protection technology that is protected by method claims of certain

U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights

owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is

intended for home and other limited viewing uses only unless otherwise authorized by Macrovision

Corporation. Reverse engineering or disassembly is prohibited.

Page 10

on Discs (continued)

About this owner's manual

This owner's manual explains the basic instructions of this DVD video player. Some DVD video discs are produced in a manner that allows specific or limited operation during playback. As such, the DVD video player may not respond to all operating commands. This is not a defect in the DVD video player. Refer to

instruction notes of discs.

'_ "may appear on the TV screen during operation.

A "Q" means that the operation is not permitted by the

DVD video player or the disc.

The region number of this DVD video player is 1. If region numbers, which stand for their playable area, are

printed on your DVD video disc and you do not find or _, disc playback will not be allowed by the player_."

(In t_s case, the DVD video player will display a message on-screen.)

This DVD video player supports VIDEO CDs equipped

with the PBC (Version 2.0) function. (PBC is the

abbreviation of Playback Control.)You can enjoy two playback variations depending on types of discs.

• VIDEO CD not equipped with PBC function (Version 1.1) Sound and movie can be played on this DVD video player in the same way as an audio CD.

• VIDEO CD equipped with PBC function (Version 2.0) In addition to operation of a VIDEO CD not equipped

with the PBC function, you can enjoy playback of

interactive software with search function by using the menu displayed on the TV screen (Menu Playback).

Some of the functions described in this owner's manual may not work with some discs.

This DVD video player can play the following discs.

Disc Maximum

Disc Mark Contents Size playback time

Approx. 4 hours

(single sided disc)

12cm

Audio Approx.8 hours

DVD _ + (doublesideddisc)

v I D E o video video (moving discs _ pictures) Approx.80 minutes

(singlesideddisc)

_ 8 cm

Approx. 160 minutes

(double sided disc)

video

Audio

12 cm Approx 74minutes

8 cm Approx. 20 minutes

12 cm

Approx. 74 minutes

8 cm

(CD

Approx. 20 minutes

single)

Audio

CDs (moving

_ pictures)

AudioCDs (_ _o_@

DHGHTAL AUDHO

The following discs are also available.

• DVD-R discs of DVD video format

• CD-R/CD-RW discs of CD-DA format Some of these discs may be incompatible.

• You cannot play discs other than those listed above.

• You cannot play DVD-RAM discs or non-standardized discs, etc., even if they may be

labeled as above.

• This DVD video player uses the NTSC color system, and cannot play DVD video discs recorded in any other color system (PAL, SECAM, etc.).

I10

Because of problems and errors that can occur during the creation of DVD software and/or the manufacture of

DVD discs, Toshiba America Consumer Products, Inc., Toshiba Hawaii, Inc. and Toshiba of Canada, Ltd. cannot

guarantee that this player will play every feature of every DVD bearing the DVD logo. As one of the creators of DVD technology, Toshiba DVD players are manufactured to the highest standards of quality and, as a result, such incompatibilities are very rare. If you happen to experience and difficulty playing a DVD on a Toshiba DVD player, please feel free to call our Contact listed in

"How to Obtain Warranty Services" [_.

Page 11

Introduction

• SAFETY PRECAUTIONS .......................... 2

• IMPORTANT SAFETY INSTRUCTIONS .... 4

• Precautions ................................................ 8

• Notes on Discs ........................................... 9

Notes on region numbers ............................... 10

• Table of Contents ..................................... 11

• Identification of Controls ........................... 12

Front panel ..................................................... 12

Rear panel ...................................................... 13

Remote control ............................................... 14

Loading batteries ........................................... 15

Operating with the remote control .................. 15

Connections

• Connecting to a TV .................................. 18

Connecting to a TV ......................................... 18

Connecting to an audio system and TV

equipped with component video inputs ....... 19

• Connecting to Optional Equipment ........... 20

Connecting to an amplifier equipped with a

Dolby Digital decoder ................................... 21

Connecting to an amplifier equipped with

Dolby Surround Pro Logic ............................ 21

Connecting to an amplifier equipped with a

DTS decoder ................................................ 22

Connecting to an amplifier equipped with an

MPEG2 audio decoder ................................. 22

Connecting to an amplifier equipped with a

digital audio input ......................................... 23

Basic playback

• Playing a Disc .......................................... 26

Basic playback ............................................... 26

• Variable Speed Playback ......................... 28

Playing in fast reverse or fast forward

directions ...................................................... 28

Playing frame by frame .................................. 28

Playing in slow-motion ................................... 29

Resuming playback from the same location .. 29

• Locating a Desired Section ...................... 30

Locating a title using the top menu ................ 30

Locating a desired section by entering the

corresponding number ................................. 31

Locating a specific chapter or track ............... 31

Advanced playback

• Accessing a Specific Location Directly ........ 34

Entering the time counter of the desired

location ......................................................... 34

• Repeating a Specific Segment ................. 34

Repeating a specific segment ........................ 34

• Playing in a Varied Order .......................... 35

Playing titles, chapters or tracks in a varied

order ............................................................. 35

• Playing in a Favorite Order ....................... 36

Setting titles, chapters, or tracks in a favorite

order ............................................................. 36

• Zooming a Picture .................................... 37

Zooming a picture .......................................... 37

• Selecting the Picture Enhancement

(E.P.M.)....................................................38

Selecting the picture enhancement ................ 38

• Selecting the Sound Enhancement

(E.A.M.) .................................................... 39

Selecting the sound enhancement ................. 39

• Selecting the Camera Angle ..................... 40

Changing the camera angle ........................... 40

• Selecting Subtitles .................................... 41

Selecting a subtitle language ......................... 41

• Selecting a Language .............................. 42

Selecting a playback audio setting ................. 42

• On-screen Display Operation ................... 44

On-screen display operation .......................... 44

• Playing MP3/WMA Files ........................... 48

Playing MP3/WMA files .................................. 48

• Viewing JPEG Files .................................. 50

Starting from a thumbnail view ....................... 50

Viewing a single image .................................. 53

Playing slide show .......................................... 55

Selecting a folder ........................................... 56

Function setup

• Customizing the Function Settings ........... 60

Setting procedure ........................................... 60

Setting details ................................................. 62

• Table of Languages .................................. 70

Others

• Before Calling Service Personnel ............. 72

• Specifications ........................................... 73

• LIMITED WARRANTY DVDVIDEO

PLAYER ................................................... 74

O- c

¢b

111

Page 12

See the page in I_ fordetails.

ON/STANDBY indicator [26} ON: Lit in green

Standby mode: Not mit°

DVD dispmay 137

ON/STANDBY button ii_}

PAUSE button 27:_

STOP button 2[_V

Page 13

VmDEOOUT jack 118_

ANALOG AUDmOOUT (L/R)jacks 11_} 11_}

S VmDEO OUT jack

VmDEOOUT (Y/PB/PR) (Component video) jacks ii§--}

BFSTREAM/POM DmGFAL COAXmAL

AUDmOOUT jack 21_ _ 231_

O- c

131

Page 14

The instructions in this manual describe the functions on the remote control. See the page in [_ for details.

OPEN/CLOSE POWER

OPEN!CLOSE button [_ -

SKmPbuttons %_ --

-- ON/STANDBY button

--REW button [_

-- FWD button

SUBTFLE button _ --

SUBTFLE ANGLE CLEAR RETURN

CLEAR button

button ANGLE button _ -- AUDRO button _ -----

STOP button _ -- TOP MENU button _ i

PAUSE/STEP PLAY

--PLAY button 2_ .-- PAUSE/STEP button 2_ [_

-- ENTER button_

--MENU button *

Direction buttons [_ --

NAVNbutton [_ DmSPLAY button _ --

PBC button

E°A.M. button %_

Number buttons

SETUP button _ -- MEMORY button

PBC E.A.M.

E JU _ _ =

E.P._L_PJ_OYd_SSmVE

* MENU button

Use the MENU button to display the menu included on many DVD video discs. Tooperate a menu, follow the instructions in "Locating a title using the top menu."

ZOOM button[_

-- SLOW button [_

.... E.P.M. button

-- PROGRESSmVE button

--T button

--AoB RPT button "%- PLAY MODE button [_

Page 15

• About the illustrations of the battery compartment There are two types of battery compartment in the supplied remote controls. (This does not mean a difference in performance between the two.) Refer to either illustration depending on the actual

remote control.

Loading batteries

Open the cover.

Insert batteries (AA size).

Make sure to match the + and - on the batteries

to the marks inside the battery compartment.

Close the cover.

Operating with the remote control 1

Point the remote control at the remote 8' sensor and press the buttons.

Within about 7 m (23 feet)

Distance: About 7 m (23 feet) from the front of the

remote sensor

Angle: About 30 ° in each direction of the front of

the remote sensor

* Do not expose the remote sensor of the DVD video

player to a strong light source such as direct sunlight or other illumination. If you do so, you may

not be able to operate the DVD video player via the remote control.

Notes on batteries Improper use of batteries may cause battery leakage and

corrosion. To operate the remote control correctly, follow the instructions below.

• Do not insert batteries into the remote control in the

wrong direction.

• Do not charge, heat, open, or short-circuit the batteries.

Do not throw batteries into a fire.

• Do not leave dead or exhausted batteries in the remote

control.

• Do not use different types of batteries together, or mix old

and new batteries.

• If you do not use the remote control for a long period of

time, remove the batteries to avoid possible damage from battery corrosion.

• If the remote control does not function correctly or if the

operating range becomes reduced, replace all batteries with new ones.

• If battery leakage occurs, wipe the battery liquid from the

battery compartment, then insert new batteries.

Notes on the remote control

• Direct the remote control at the remote sensor of the DVD video player.

• Do not drop or give the remote control a shock.

• Do not leave the remote control near an extremely hot or

humid place.

• Do not spill water or put anything wet on the remote control.

• Do not open the remote control.

151

Page 16

Page 17

to,,rv

Connect the DVD video player to your TV.

For details of output sound, see [_.

Connecting to a TV

s gna F ow

connect the DVD video player with an S video cable. When using an

S video cable, do not connect the yellow video cable.

Notes

• Refer to the owner's manual of the connected TV as well.

• When you connect the DVD video player to your TV, be sure to turn off the power and unplug both units from the wall outlet before making any connections.

• If your television set has one audio input, connect the left and right audio outputs of the DVD video player to a Y cable adapter (not supplied) and then connect to your TV.

• Connect the DVD video p_ayer directly to your TV. if you connect the DVD video player to a VCR, TV/VCR combination or video selector, the playback picture may be distorted as DVD video discs are copy protected.

TV or monitor with audio/video inputs

Make the following setting,

On-screendisplay Select: Page

"Digital Output" or

'Bitstream" _

"PCM"

118

Page 18

Interlaced outputs/inputs (ColorStream _) Some TVs or monitors are equipped with component video inputs. Connecting to these inputs allows you to enjoy higher quality picture playback. Actual labels for component video inputs may vary depending on the TV manufacturer. (ex. Y, R-Y, B-Y orY,

CB, OR)

In some TVs or monitors, the color levels of the playback picture may be reduced slightly or the tint may change. In

such a case, adjust the TV or monitor for optimum

performance.

Progressive outputs/inputs (ColorStream'_Pro) Some TVs or monitors are equipped with component video

inputs that are capable of reproducing a progressively scanned video signal. Connecting to these inputs allows

you to view the highest quality pictures with Iess flicker.

l Connecting to an audio system and TV equipped with component video inputs ]

SignamFlow

To audio inputs of

the amplifier

(white)

ToY video input

ToPBvideoinput

ToPRvideo input

Audio system

• Switching the output signal (interlaced/progressive) using the remote control

(only when "Progressive" is set to "Enable" [_) You can temporarily switch the output signal for better

picture quality.

Press PROGRESSIVE on the remote control.

Notes

• Refer to the owneCs manual of the connected equipment as well.

• When you connect the DVD video player to other equipment, be sure to turn off the power and unplug all of the equipment from the wail outlet before making any connections.

• If you place the DVD video player near a tuner or radio, the radio broadcast sound might be distorted. In this case, place the DVD video player away from the tuner and radio.

• The output sound of the DVD video player has a wide dynamic range. Be sure to adjust the receiveCs volume to a moderate listening level. Otherwise, high volume sound may damage your hearing as well as the speakers.

• Turn off the amplifier before you connect or disconnect the DVD video playeCs power cord. If you leave the amplifier power on, the speakers may be damaged.

TV or monitor with

component video inputs

Make the following setting.

On-screen display Select: Page

'Digital Output" or

you connect a progressive TV, set

"Progressive" to "Enable" [_.

"Bitstream" _

"PCM"

191

Page 19

nnecting to Optional Equipment

You can enjoy high quality dynamic sounds by connecting the DVD video player to optional audio equipment.

• For connection to your TV, see "Connecting to a TV"

• For details of output sound, see [_.

• This section uses the following reference marks.

: Front speaker

: Rear speaker

: Sub woofer

:Center speaker

: Signal flow

Notes

• DO NOT connect the BITSTREAM/PCM AUDIO OUT jack of the DVD video player to the AC-3 RF input of a Dolby

Digital Receiver. This input on your AtV Receiver is reserved for Laserdisc use only and is incompatible with the BITSTREAM/PCM AUDIO OUT jack of the DVD video

player.

• Connect the BITSTREAM/PCM AUDIO OUT jack of the DVD video player to the "DIGITAL (COAXIAL)" input of a

Receiver or Processor.

• Refer to the owner's manual of the connected equipment as well.

• When you connect the DVD video player to other equipment, be sure to turn off the power and unplug all of

the equipment from the wall outlet before making any

connections.

• The output sound of the DVD video player has a wide dynamic range. Be sure to adjust the receiver's volume to

a moderate listening level. Otherwise, the speakers may be damaged by a sudden high volume sound.

• Turn off the amplifier before you connect or disconnect the DVD video player's power cord. If you leave the

amplifier power on, the speakers may be damaged.

Warning

• When you are connecting (via the BITSTREAM/PCM AUDIO OUT jack) an AV decoder that does not have

Dolby Digital, Digital Theater Systems (DTS) or MPEG2 decoding function, be sure to set "Digital Output" to

"PCM" from the on-screen displays [_[_. Otherwise, high volume sound may damage your hearing as we_l

as the speakers.

• When playing DTS-encoded discs (audio CDs), excessive noise may be output from the analog audio output jacks. To avoid possible damage to the audio

system, you should take proper precautions when the analog audio output jacks of the DVD video player are

connected to an amplification system. To enjoy DTS

Digital Surround TM playback, an external 5.1 channel DTS Digital Surround TM decoder system must be

connected to the BITSTREAM/PCM AUDIO OUT jack of the DVD video player.

120

Page 20

Dolby Digital Dolby Digital is the surround sound technology used in theaters showing the latest movies, and is now available to reproduce this realistic effect in the home. You can enjoy motion picture and live concert DVD video discs with this dynamic realistic sound by connecting the DVD video player to a 6 channel amplifier equipped with a Dolby Digital decoder or Dolby Digital processor. If you have a Dolby Surround Pro Logic decoder, you will obtain the full benefit of Pro Logic from the same DVD movies that provide full 5.1-channel Dolby Digital soundtracks, as well as from titles with the Dolby Surround mark.

Manufactured underlicensefromDolby

• Use DVD video discs encoded via the Dolby Digital recording

system.

• Make the following setting.

_DomPIifier equipped with a ""I

tbyDigitaldecoder |

digitalaudioinput ToBITSTREAM/

PCMAUDIO OUT

l To COAXIALtype

75 _,_coaxiaI cable

Dolby Surround Pro Logic You can enjoy the dynamic realistic sound of Dolby Surround Pro Logic by

connecting an amplifier and speaker system (right and left front speakers, a center speaker, and one or two rear speakers).

• With an amplifier equipped with Dolby Digital Connect the equipment the same way as described in "Connecting to an

amplifier equipped with a Dolby Digital decoder." Refer to that amplifier's owner's manual and set the amplifier so you can enjoy Dolby Surround Pro Logic sound.

• With an amplifier not equipped with Dolby Digital Connect the equipment as follows.

On-screendisplay Select: Page

"DigitalOutput.... Bitstream"

Recordingsystem [7[7 U [_

Make the following setting.

On-screen display Select: Page

"Digital Output" or

* Connect one or two rear speakers The output sound from the rear speakers wiII be monaural even if you connect two rear speakers

"Bitstream"

"PCM"

211

Page 21

6 nnecting to Optional Equipment (Continued)

Digital Theater Systems (DTS) DTS is a high quality surround technology used in theaters and now available for

home use, on DVD video discs or audio CDs.

If you have a DTS decoder or processor, you can obtain the full benefit of 5.1

channel DTS encoded sound tracks on DVD video discs or audio CDs.

Amplifier equipped w{th _/ '%[_ '

TOCOAXIALtype digitataudio input ToBITSTREAM/ _,

/ PCMAUDIO OUT _ J 75 _,_coaxial cable |

MPEG2 sound

You can enjoy motion picture and live concert DVD video discs with

dynamic realistic sound by connecting an amplifier equipped with an MPEG2 audio decoder or MPEG2 audio processor.

- . £ •

_mptifier equipped withal_-_]

trademarks of Digital Theater Systems,

I "DTS" and "DTS Digital Out" are 1

inc

• Use DVD video discs or audio CDs encoded via the DTS

recording system. Make the following setting.

On-screen display Select: Page

"Digital Output" or

Recording system DTS [_

• Use DVD video discs encoded via the MPEG2 recording system.

• Make the following setting.

On-screendisplay Select: Page

"DigitalOutput.... Bitstream"

Recordingsystem MPEG2 [_

"Bitstream"

"PCM"

122

digital audie ir_put _°cBMKASJ_ Epg/T

1TOOOAXtAktype

75 ,,_co?xiai cable

Page 22

I Connecting to an amplifier equipped with a digital audio input ]

2 channel digital stereo You can enjoy the dynamic sound of 2 channel digital stereo by connecting an amplifier equipped with a digital audio input and speaker system (right and left front speakers).

ToCOAXIALtype

Amplifier equipped with _'_] ci_i__

I digitalaudio input [, 75 _ coa_iaI

Make the following setting.

On-screendisplay Select: Page

"DigitalOutput.... PCM'_ 6_

231

Page 23

Page 24

CAUTION

Keep your fingers well clear of the disc tray as it is closing.

This section shows you the basics on how to play a disc.

Neglecting to do so may cause serious personal injury.

ON/STANDBY indicator PAUSE PLAY

1 3 2, 4. STOP

Preparations

• When you want to view a disc, turn on the TV and select the video input connected to the DVD video player.

• When you want to enjoy the sound of discs from the audio system, turn on the audio system and select the input connected

to the DVD video player.

Press the ON/STANDBY button.

POVVER

When the DVD video player is turned on for the first time, a message appears. Press ENTER, and make the proper settings before proceeding

to step 2. [_

Press OPEN/CLOSE.

OPEN/CLOSE The disc tray opens.

Place the disc on the disc tray.

The DVD video player turns on. The ON/STANDBY indicator on the

player illuminates.

With the playback side down

Press OPEN/CLOSE to close the disc tray.

OPEN/CLOSE

If you insert a DVD video disc that contains a top

menu, a menu may appear. See "Locating a title using the top menu." [_

• You may need to press the TOP MENU or MENU button to display disc menu (depending on the actual

DVD video disc.)

Note For resuming playback, see.

• To start playback in the stop mode Press PLAY.

PLAY

Playback starts.

• There are two different disc sizes. Place the disc in the correct guide on the disc tray. If the disc is out of

the guide, it may damage the disc and cause the

DVD video player to malfunction.

• Do not place a disc which is unplayable in this DVD video player.

Page 25

00{_ 0 000 0

0{-)0 0

000 0

--STOP

--PLAY

-%_

2,4

PAUSE MENU •

ENTER

A/V TOP MENU

To obtain a higher quality picture Occasionally, some picture noise not usually visible during a normal broadcast

may appear on the TV screen while playing a DVD video disc because the high resolution pictures on these discs include a lot of information. While the amount of

noise depends on the TV you use with this DVD video player, you should generally reduce the sharpness adjustment on your TV when viewing DVD video discs.

About _@@ The _@ icons on the heading bar show the playable discs for the

function described under that heading.

:You can use this function with DVD video discs.

_ :You can use this function with VIDEO CDs. _c-5_ :You can use this function with audio CDs.

• To pause playback (still mode) Press PAUSE/STEP during playback.

PAUSE/STEP To resume normal playback, press

the PLAY button.

• The sound is muted during still mode.

• To stop playback Press STOP.

STOP

• To remove the disc Press OPEN/CLOSE.

OPEN/CLOSE

Be sure to press the OPEN/CLOSE button to close the disc tray after you remove the disc.

Remove the disc after the disc tray

opens completely.

• To turn the power off (To enter the standby mode) Press ON/STANDBY to turn the ON/STANDBY indicator off.

Note

Be aware that this equipment is still powered even after the ON/STANDBY indicator turns off (standby mode) by pressing

the ON/STANDBY button. To disconnect this equipment completely from the mains power, pull out the power plug

from the wall outlet.

• About the screen saver If you pause a picture of a DVD video disc and leave it

still for a long while, the screen saver of the DVD video player automatically appears (when "Screen Saver" is set to "On" [_). To turn off the screen saver, press the

PLAY button.

• Automatic Power Off function If the DVD video player is stopped, or the screen saver

is engaged for approximately 20 minutes, the DVD video player will automatically turn itself off.

,.<:

1313

_3 (3-

Notes

• Do not move the DVD video player during playback. Doing so may damage the disc.

• Use the OPENICLOSE button to open and close the disc tray. Do not push the disc tray while it is moving. Doing so may cause the DVD video player to malfunction.

• Do not push up on the disc tray or put any objects other than discs on the disc tray. Doing so may cause the DVD video player to malfunction.

• In many instances, a menu screen will appear after playback of a movie is completed. Prolonged display of an on-screen menu may damage your television set, permanently etching that image onto its screen. To avoid this, be sure to press the

STOP button on your remote control once the movie is completed.

271

Page 26

table Speed Playback

You can play discs at various speeds, and resume playback from the location where you stopped playback.

REV FWD

OOC)O

PLAY PAUSE

STOP

dO o ¢--- SLOW

OOO 0 000 0

C-] C_ C-) db

Press REV or FWD during playback.

REV FWD REV: Fast reverse playback

_ (_ FWD:Fastforvvardplayback

Each time you press the REV or FWD button, the playback speed changes.

Press PAUSE/STEP during still playback.

PAUSE/STEP Each time you press the PAUSE/

STEP button, the picture advances one frame.

• To resume normal playback Press PLAY.

PLAY

Notes

• The DVD video player mutes sound and subtitles during

reverse and forward scan of DVD video discs. However, the DVD video player plays sound during fast forward or fast

reverse play of audio CDs.

• The playback speed may differ depending on the disc.

• To resume normal playback

Press PLAY.

PLAY

Note

The sound is muted during frame by frame playback.

Page 27

Press SLOW during playback.

SLOW

Each time you press the SLOW button, the slow-motion speed changes.

• To resume normal playback Press PLAY.

PLAY

Note The sound is muted during slow-motion playback.

,.<:

1313

(3-

Press STOP at the location where you

want to interrupt playback.

STOP The DVD video player memorizes

the location where playback is stopped,

Press PLAY.

PLAY The DVD video player resumes

playback from the location where

you stopped playback.

• To start playback from the beginning regardless of the location where you stopped playback

1 Press STOP twice.

STOP The DVD video player deletes the

(_ of the location.

2 Press PLAY.

PLAY _ Playback starts from the

• If you want to return to the beginning of a DVD video disc, open and close the disc tray once with the OPEN/CLOSE button before pressing the PLAY

button.

Notes

• Resuming cannot function when:

-you change the parental lock setting [_ or select a disc menu language 6L6_.

-you play a PBC-featured VIDEO CD while "PBC" [_ is set to "On".

-you open the disc tray.

-you disconnect the power plug of the DVD video player.

• There may be a difference in the location where playback resumes depending on the disc.

• Settings you changed using the on-screen displays while the DVD video player keeps a location in the memory may

function only after the memory is cleared.

memory

beginning of the current title.

_ebb Playback starts from the _c_ beginning of the disc.

291

Page 28

a Desired Section

TOP MENU

0000

ENTER

OOC) 0 0(-)0 0

O00 0 O00 O

OOO 0

Normally, DVD video discs are divided into titles, and the titles are sub-divided into chapters. VIDEO CDs and audio CDs are divided into tracks. You can quickly locate any specific title, chapter, or track.

DVD video disc

Track 2 Track 3

VIDEO CD/audio C_

Press TOP MENU.

TOPMENU The top menu appears on the TV

O screen,

e.g I ,ti E ;{_,_ ÷__-:,

Press ENTER.

Playback starts from chapter 1 of

the selected title.

i:i¸

TmE:I _ ;_i 4

Press • / • / -,I/ t,- to select the title you

want.

d_ If the titles inthe top menu are

assigned a number, you can directly

@ locate a specific title by pressing its

designated number with the number buttons.

Notes

The instructions above describe basic procedures which may vary depending on the contents of the DVD video disc.

If different instructions appear on the TV screen, follow those instructions.

If you display the top menu during playback and press the TOP MENU button again without selecting any title, the DVD

video player may resume playback from the point where you first pressed the TOP MENU button (depending on the

actual DVD video disc.) This method of locating a title is available only on a disc that

contains a top menu. Instruction notes of discs may refer to the button that

displays the top menu as TITLE button.

Page 29

J SKIP

--CLEAR

--PLAY

_BNTER

c) c) c) 0

--T Number buttons

Locating a desired section by entering the corresponding number 1

Press T

If you are using a VIDEO CD/audio CD, skip step 2.

Then at step 3, enter the number for the track you

want using the number buttons.

SEARCH e.g,

Repeat steps 2 and 3 if necessary.

Press PLAY or ENTER.

PLAY

Playback starts from

the selected section.

Press -_/ D,-to select a section you want to

locate.

e.g. When you want to locate a chapter.

[

Notes

• Pressing the CLEAR button resets the numbers. To clear the display, press the T button several times.

• This method of locating a title is available only on a disc that contains title numbers.

,.<

1313

_3 (3-

Press •/•to enter a number of the

section.

Also the number buttons are available.

e.g. To enter 25

Press SKIP I_ or _,¢%repeatedly to access the

chapter or track number you want.

Playback starts from the selected chapter or track.

SKIP

To locate succeeding chapters or tracks.

Playback starts from the beginning of the current chapter or track.

When you press twice, playback starts

from the beginning of the preceding

chapter or track.

Notes

• Some titles may not display chapter numbers.

• If you press and hold the SKIP 144 or _1 button on the

front panel during playback, the DVD video player performs fast reverse or fast forward playback. You can vary the

speed by pressing the button repeatedly. To locate chapters or tracks during fast reverse or fast

forward playback, first press the PLAY button to resume normal playback, then use the SKIP 144 or _1 button.

• When you set "Title Stop" to "Off" ['6_,

chapters in another title. If you go back to the preceding title by pressing the SKIP H@_button, the DVD video player

locates the first chapter of the title. When "Title Stop" is set to "On," you can access chapters only within the current title.

you

can access

311

Page 30

Page 31

a Specific Location Directly

You can access a specific location by entering its corresponding time (hours, minutes, seconds).

Press T several times.

SEARCH You may have to press further

(_ the disc. Press the

Press the number buttons to enter the

time.

e.g.

depending button repeatedly until the time counter is highlighted.

e.g.

Press PLAY or ENTER.

PLAY the desired location.

Notes

Some discs may not respond to this process. Some scenes may not be located precisely as you

specified. This method for accessing specific locations is available

only within the current title of the DVD video disc or within the current track of the VIDEO CD/audio CD.

O C) C) 0

-- SKIP CLEAR

PLAY

ENTER

T Number buttons

Playback starts from

a Specific Segment

You can specify a desired segment and repeat it.

Press A-B RPT at the beginning of the

segment (point A) you want to play

repeatedly.

A-BRPT_ I[A:

Press A-B RPT again at the end of the

segment (point B).

A-BRPT The DVD video player automatically

returns to point A and starts repeat playback of the selected segment (A-B).

'_)w __(_

<>_c_-- CLEAR O(_C)O

0_0

000

0000

(_) L) 0 0

OC.)O O O(DO 0

0¢ )00

o o o <_--A-B RPT

• To resume normal playback Press CLEAR or A-B RPT.

CLEAR A-B RPT

Notes

• Some discs may not permit A-B repeat operation.

• You cannot set the A-B repeat function for a segment that includes multiple camera angles [_.

• You can specify a segment only within the current title or track (VIDEO CD).

• There may be a slight difference between point A and the location where playback actually resumes depending on the

disc.

Page 32

in a VariedOrder

You can play titles, chapters within a title, or tracks in a varied order.

©O©

O00 0

C) O0 0 OOO 0

000 O CD(D () 0

o o

-- CLEAR

--2

--1

Press PLAY MODE.

PLAYMODE

e.g.

Chapter Repeat

Title Repeat

All Repeat

Chapter Random Title Random

-- Random Off

Chapter Repeat: Repeats the current chapter.

Title Repeat: Repeats the current title.

Track Repeat: Repeats the current track.

All Repeat: Repeats the entire disc.

Chapter Random: Plays the chapters within the current title in random

order. Title Random:

Plays the titles in random order. Track Random:

Plays the tracks in random order. Random Off (Repeat Off):

Resumes normal playback.

Each time you press the PLAY MODE button, the playback mode changes as follows.

1 l

i rack Repeat

All Ripeat

Track Random Rand_om Off

Press PLAY.

PLAY The DVD video player starts

playback in the selected mode. Press the PLAY button within about

5 seconds after you press the PLAY MODE button.

• To resume normal playback Press CLEAR.

CLEAR

Note Some discs may net permit these operations.

o c0

o..

a_3

,,<:

If you press the PLAY MODE button during playback, the DVD video player automatically enters the selected playback mode after

finishing the current title, chapter or track.

351

Page 33

a Favorite Order

You can combine your favorite titles, chapters, or tracks and play them in the order you determine. You can program up to 30 selections into the memory• (Memory playback)

_ O (_ O

(_(_C_ i

(Z) C) C) O

CLEAR

Insert a disc and press MEMORY during

stop.

MEMORY The following display appears.

O eg

T: Title number CT: Chapter number

or track number

Select the items in the order you want by

pressing the number buttons, then ENTER

for each item. Each time you press the _ / _ button, the space

of "T" and "CT" is highlighted in turn. Highlight where you want to enter, then press the corresponding number buttons.

To select another chapter in the same title, you do not need to select the title number.

To select tracks from a VIDEO CD/audio CD in order, press the number buttons for the track, then

press the ENTER button for each selection you want.

Press PLAY while the display appears on

the TV screen.

PLAY The DVD video player starts

(_ memory playback.

;,, < : .......

: < : .......

: < ......

• To change the programmed selections 1 While the display appears on the TV screen, press

• / • / _1/ _ to move the highlighted bar to the item you want to change.

2 Change the selection following the instructions in

step 2.

• To cancel the programmed selections 1 While the display appears on the TV screen, press

• / • to move the highlighted bar to the item you want to cancel.

2 Press CLEAR.

• To resume normal playback from memory playback

Press CLEAR.

The memory playback indicator

CLEAR disappears.

• To program during playback

If you press the MEMORY button during playback, a

programming display appears.

Follow steps 2 and 3.

Notes

• Some discs may not permit memory playback operation.

• If you press the PLAY MODE button during memory

playback, the DVD video player repeats the current memory playback.

• If you press the MEMORY or RETURN button while the

display appears on the TV screen, the display disappears•

• The programmed selections will be cleared when you turn

off the DVD video player•

Page 34

a Picture

You can magnify areas within a picture.

©©©©

C) 0 CD 0 000 0

000 0

O00 O

-- CLEAR

A/_'/_/_* ENTER

ZOOM

Press ZOOM during normal, slow or still playback.

ZOOM The DVD video player enters the

zoom playback displays

mode and

the icon,

e.g.

As you repeatedly press the ENTER

(or ZOOM) button while "ZOOM" is selected, the magnification level changes.

Variation of the levels includes

image reduction.

F l:

If you press the ENTER button while "EXIT" is highlighted, you can turn

off the icon, keeping the current magnification level.

You can shift the highlight within the

icon by the • / • / _1/ I_ buttons.

• To resume normal playback While "ZOOM" is selected, press ZOOM repeatedly to

turn off the icon. Original picture is restored when the icon disappears.

ZOOM

• The ENTER button cannot cancel zoom playback if you have turned off the icon by selecting "EXIT." To

restore normal picture size, press the ZOOM button to display the icon, then further press the ZOOM

button until the icon turns off.

Notes

• Some discs may not respond to zoom feature.

• During some scenes, the buttons may not work as described.

• Zooming does not work on subtitles or menus included on

DVD video discs.

• While the icon is displayed, the • / • / _ / I_ buttons cannot work on menus included on the DVD video discs. If you

want to view the menus, turn off the icon.

• The magnification level varies depending on the picture size you select. [_

93 0

CO C_

CLEAR

If you press and hold the • / • / _ /

buttons, the zoom point shifts.

Pressing the CLEAR button restores the zoom point to the center of the picture.

371

Page 35

ed__i_yback

_i!!_¸ _x_iiii_ °

cting the Picture Enhancement (E.RM. *)

You can easily select a preferred picture enhancement.

*E.RM.: Enhanced Picture Mode

©OO©

() () C) CD

Press E.RM

E.PM The picture enhancement menu

O appears.

r .......

i:N ii , ,

i EnhancedBlack level i Movie1 i Movie2

i Animation

() () (_ 0

o o oXg_

s v \ J \s

) r_ 0( _)._

0 0 0 \_r_

ENTER

--1,2

• To exit the picture enhancement selection Press ENTER.

Alternatively leave the DVD video

player unattended for about 5 seconds after having made a selection,

Note Actual effect to picture may vary depending on the TV. Make

selection according to your preference.

Select the picture enhancement by

pressing ERM or • / V.

Each time you press the button, the picture enhancement changes.

Normal: Standard black level (7.5 IRE).

Enhanced Black Level: Enhanced Black Level (0 IRE).

Movie1 : Brightness levels raised for enhanced picture

clarity. Movie2:

For deeper, richer color reproduction. Animation:

For enhanced color contrast.

Page 36

: t ti.g theSo..a

You can easily switch a preferred audio enhancement.

*E.A.M.: Enhanced Audio Mode

Press E.A.M Press ENTER.

E.A.M. The sound enhancement menu

appears.

F j_

©©,,©

oo()o OLbOO

000 0

000 ©

• To exit the audio enhancement selection

Alternatively leave the DVD video player unattended for about 5

seconds after having made a

ii¸¸

selection.

ENTER

il,2

3D DiaJogue

Select the sound enhancement by

pressing E.AM. or • / T.

Each time you press the button, the sound

enhancement changes.

Normal: Normal sound•

3D*: To obtain expansive virtual surround sound effects

from just two speakers.

Dialogue**:

To control dynamic range to make dialogue more

intelligible•

• To use this enhancement on sounds output from the BITSTREAM/PCM jack, be sure to set

"Digital Output" to "PCM." [_

N-

Notes

• Actual effects to sounds may vary depending on the speaker system. Make selection according to your

preference.

• Actual effects to sounds may vary depending on the disc.

• When the DVD video player is connected to an amplifier equipped with Dolby Surround Pro Logic, select "Normal".

Otherwise, Dolby Surround Pro Logic may function

differently than usual.

• Selecting "Dialogue" disables "Dynamic Range Control" function [_.

* Effective in playback of a DVD video disc or a

VIDEO CD.

**Effective only during playback of Dolby Digital

recorded discs.

3oI

Page 37

iii lecttng the Camera Angle

If the scene was recorded from multiple angles, you ear_easily change

the camera angle of the scene you are watching.

QQQ©

OOOO

@ @

Press ANGLE while playing a scene

recorded with multiple angles.

ANGLE While playing a scene recorded with

multiple angles, the angle icon (_) flashes in the DVD display. Press the ANGLE button while the

angle icon is flashing.

e.g.

Press ANGLE or A / • while the angle

number is displayed on the TV screen.

ANGLE

Each time you press the ANGLE button, the camera angle changes.

@@@®®

Notes

• You oan change the camera angle during still playback. The camera angle changes to the new setting when you resume

normal playback.

• If you pause a picture immediately after changing a camera angle, the resumed playback picture may not display the

new camera angle.

Fs C-

......C_

¢_"CDC7 _'}

OOO 0

ENTER

--1,2

140

You can change the camera angle directly by pressing the number

buttons corresponding to its angle number instead of using the A l •

buttons.

Toturn off the display, press the CLEAR or ENTER button.

Page 38

You can displaysubtitleson the TVscreen and select a subtitle language

from those included on the DVD video disc.

® Selecting a subtitle language

• To turn subtitles on or off

Press SUBTITLE during playback.

SUBTITLE The current subtitle setting is

displayed.

e.g.

1 Press SUBTITLE during playback.

2 Press _ / _,-while the subtitle setting is displayed on

Fh F_

_.yO0_._ __CLEAR

_m cb G)_t-'C'7_>

OOO 0

CDCD0 0

0 (_) C) 0

000 ©

CO0 O

SUBTITLE

the TV screen, to select "On" or "Off."

SUBTITLE

ENTER

o.. <:

C) Co C_

The abbreviation of the language appears instead

of the language name. Refer to the list of languages and their abbreviations. [_

Press SUBTITLE or • / • while the subtitle

setting is displayed on the TV screen.

SUBTITLE Each time you press the SUBTITLE

Notes

• Some DVD video discs are set to display subtitles automatically, and you cannot turn them off even if you set

the subtitle function to off.

• During some scenes, the subtitles may not appear immediately after you select "On."

• Some DVD video discs will allow you to make subtitle selections and turn subtitles on or off only via the disc

menu.

button, the subtitle languages included on the DVD video disc

change.

............ To turn off the subtitle setting

Notes

• When you turn on the DVD video player or replace a disc, the player returns to the initial default setting [_. When you select a subtitle language which is not included on the disc, the DVD video player plays a prior language programmed on the disc.

• During some scenes, the subtitles may not appear immediately after you change the subtitle language.

display, press the CLEAR or ENTER button.

411

Page 39

a Language

You can select a preferred language and sound recording system from those

included on the DVD video disc.

Press AUDIO during playback.

AUDIO The current audio setting is

displayed,

Press AUDIO or • / • while the audio

setting is displayed on the TV screen.

O button, the audio included

O 1,2

©©O©

©o_ CLEAR

.__)o LDO

ENTER

o ,,o CD o

fmrm

000 ©

COO O

AUDIO Each time you press the AUDIO

settings

on the DVD video disc change.

The abbreviation of the language appears instead of the language name. Refer to the list of

languages and their abbreviations. [_

• Selecting sound channels of VIDEO CDs You can switch left and right channels by pressing the

AUDIO button repeatedly during playback.

AUDIO

To turn off the audio setting display, press the CLEAR or ENTER button.

Notes

• When you turn on the DVD video player or replace a disc, returns to the initial default setting [_.player

If you select a sound track which is not included on the disc, the DVD video player plays a prior sound track programmed on the disc.

• Some discs allow you to change audio selections only via

the disc menu. If this is the case, press the MENU button and choose the appropriate language from the selections on the disc menu.

Page 40

• Output sound conversion table

BUTSTREAM/PCM jack

"Digital Output" [_

"Bitstream"

Bitstream

Bitstream Bitstream --

Bitstream

PCM PCM O

Bitstream Bitstream Noise

PCM POM O

'PCM"

ANALOG AU[ mO

OUT Jack_

: 3D sound enhancement can function.

Unput

DVD

video disc

VIDEO CD

Audio CD

Output

Ddby DigitaU

Linear PCM

DTS

MPEG1,MPEG2

MPEG1

LinearPCM 44.1 kH_16 bit

OTS

MP3_MA

• Signals of 96kHz from the BITSTREAM/PCM jack are depressed to 48 kHz by down sampling process when:

-"3D" is selected. [_

- "PCM Down Sampling" is set to "On." [_

- a copyright protected disc is played.

• Quantization bit of signals of 20 bit or higher which is output from the BITSTREAM/PCM jack is 16 bit if they are in a copyright protected disc.

z)_ <z #3

C) G)

O-

x:3 ,,<

O-

431

Page 41

-screen Display Operation

When you turn on the on-screen display, you can view information on operational status and access features and settings.

Press NAVI.

NAVI

e.g.When playing a DVD video disc

The following display appears. Each time you press the NAVI button, the on-screen display changes as follows.

See the pages in [_ for details on the features.

Select by pressing _ /_ then press ENTER (except *) to access the feature.

OOOO

OOLb_

C) 0 CD 0 00_) 0

000 0

ENTER NAVl

-PLAY 4+++++_¢+ +++++Er++mr

N+m£+r++?++&i _ ........

.;,-+:sd_:+ ..1+:cha_+p.........

Off

++]+ +++.,+,], p++_ +

, + ++

+++

+ + i+

6,4

i6.4

P+h#+

Bit rate display To display, select "On"

Meaning of the +conand the status information

Page 42

• Features ( * :There is no need to press the ENTER button.)

Title number (Track number) Locate a title or track using the number

buttons. [_

(..................

L:::: ::::ec ..................

Chapter number Locate a chapter using the number buttons.

: To stop playback.

: Playback starts from the beginning of the

current chapter or track. [_

: Fast reverse playback 1_

: To start playback. [_

: Fast forward playback [_

: To locate succeeding chapters or tracks. 1_

To jump to the bookmark:

1 During stop, press NAVl so that the

on-screen display appears.

2 Press 41 / I_ to select" _:! ". 3 Press ENTER.

Notes

• You can save only one bookmark. Setting a new one will erase the existing one.

• There may be a difference between a marked point and the location you actually jump to.

• Some points may not be marked.

• A bookmark cannot be set when playin#__ PBC-featured VIDEO CD while "PBC" 6L6L6L6L6L6L6L6L6L6_ is

set to "On."

• A bookmark will be erased when:

- you turn off the power of the DVD video player.

- you open the disc tray.

- you change the parental lock settit_ [_ or select a disc menu language 6L6_.

• If a bookmark is not set, selecting "i P;:!"then pressing the ENTER button

during stop will start playback from the beginning of the title or the disc. (in this case,

PBC control of a VIDEO CD will be disabled.)

• A bookmark on an MP3/WMA file always makes you jump to the beginning of the track.

o.. 93 O

Co C_

O-

: To begin slow motion playback. [_

: To pause playback. [_

: Marker

You can set a bookmark.

To set a bookmark:

1 During playback, press 41 / I_ to select

2 Locate a desired point. (Pause the

playback if necessary.)

3 Press ENTER.

The point is registered as a bookmark.

Elapsed time of the current title or track To enter the time to locate a desired location.

: Audio setting I_

: Subtitle setting 1_

: Angle setting [_

(Continued)

Page 43

!:ii, -screen Display Operation (Continued)

IOn-screen u,s .,ay o .era.,o,, : : : : :

: DNR

You can view a picture with less video noise. Press • / • to select then press ENTER.

Off: The DNR picture enhancement does not

On: The DNR picture enhancement

Notes

• Actual picture enhancement may vary

• While the picture enhancement can provide

• Depending on the disc, some kinds of picture

: Closed Caption

You can display closed captions included on

a disc without connecting a dosed caption decoder to your TV.

Press • / • to select "On" or "Off" then press ENTER.

Off: To disable closed captions. On: To display closed captions.

Notes

• While you are using on-screen displays

• When "On " is selected, some displays such

t,ll _1 i,

activate.

activates,

depending on the quality of the disc.

improvement in the reduction of noise in the

video signal, it may produce undesirabIe

picture artifacts on some discs. Should this

occur, select "Off."

details may be Iost by the picture enhancement.

(including the bit rate display), you cannot view closed captions. After selecting "On"

then turning off the on-screen display, closed captions will appear.

as "_;," may be disabled.

: Bit rate (Mbit/s)

Amount of picture, sound and subtitle data in the DVD video disc transferred per second. The larger the value is, the more data processed, but this does not necessarily insure better picture quality.

To keep the bit rate display on-screen: Press • / • to select "On" then press ENTER.

io_i

Bi} Rare : On

:Selecf :Refurn

To turn it off, select "Off." The following operations also select "Off".

- Opening the disc tray.

-Turning the power off.

6,4i

Page 44

• Viewing the operational status 1 Press DISPLAY.

The following display appears.

OOOO

-- ENTER

o _ NAVI

ooo o c) (D cD o

c)oo o 00o o

000 0

Time counter _v_ Elapsed time / remaining time of the current title

@_<_Elapsed time / remaining time of the current track

e.g.

[.... 2 ....... 3 ('0:06:241 ...... -0:03:57

2: PREPARATION

Current selections. For details, see the respective pages.

[A>

Time bar Rough graph of the (_ Title

elapsed time <_-_ Disc

L,,,,Displays DVD-Text data (or CD-Text data when p)aying an audio CD)

if included on the disc. (Some letters may not be displayed properly depending on the disc.)

O Co

O-

2 To turn off the display, press DISPLAY again.

Notes

• The time bar will not appear when playing:

PBC-featured VIDEO CD while "PBC" [_ is set to

*'On".

- a menu included on a DVD video disc.

- a title which does not display the elapsed time.

• Some discs may not display the time counter.

• When playing a PBC-featured VIDEO CD while "PBC"

[_ is set to "On," the time counter may not above properly.

work

471

Page 45

Me3 MAril s

You can play MP3NVMA files that have been recorded on a CD-R or CD-ROM on the DVD video player.

PAUSE PLAY

ENTER

• Preparations

• Make sure that a disc you want to_y is compatible with this DVD video player. Set "Priority Contents" to "Audio", 6[_

• Selecting a track (file) in the disc

Place a CD that contains MP3/WMA files

on the disc tray.

Press OPEN/CLOSE to load the disc. OPEN/0LOSEPlayback starts.

-i-ostop playback, press STOR

STOP

• To pause playback Press PAUSE/STEP during playback.

PAUS_STEP

Toresume normal playback, press the PLAY button.

1 Press NAVI twice.

2 Select the "@ "icon using _1 / I_ then press

ENTER. A list of tracks appears.

3 Press • / • / 41 / I_ to select a track you want to

play. (Pressing 41/I_ turns the pages.)

The current track being played is highlighted in green.

4 Press ENTER to begin playback of the selected

track.

Notes

• You can select a track also by designating a track number. Press the T button, and press the • / • buttons to select

a trask number, then press the ENTER button.

• To turn off the on-screen display, press the NAVI button several times.

• Letters of a file/folder name overflowing the given space

are not displayed.

ooo 0

CDC-3(-) N

NAVI

Notes

• Some discs may not permit this operation.

• WMA tracks copy-protected cannot be played.

• The BITSTREAM/PCM jack outputs MP3/WMA sounds in the linear PCM format regardless of the current "Digital Output"

selection [_[_.

• If you stop playback by pressing the STOP button, and then press the PLAY button, playback will start from the beginning of the track.

• The SKIP [_> and PLAY MODE _ functions are also available.

Page 46

• Playable files

MP3/WMA disc compatibility with this player is limited as follows:

• Playable discs: CD-ROM, CD-R (650MB / 74 min. only) CD-RW is not recommendable.

• Sampling Frequency: 44.1 kHz only

• Bit rate: WMA: 48 kbps - 192 kbps (CBR) MP3:32 kbps - 320 kbps (CBR)

• CD physical format: Mode 1, Mode 2 XA Form 1

• File system: ISO9660 Level 1,2 or Joliet

• File name: A file name should be in alphabet and numerals only, and must incorporate "MP3" or "WMA" extension.

e.g.' ......... .MP3", .......... .WMA"

• Total number of folders: Less than 256

• Total number of files: Less than 1000

• WMA codec version: V7 orV8 (Stereo sound only)

This DVD video player requires discs/recordings to meet certain technical standards in order to achieve

optimal playback quality. Pre-recorded DVDs are automatically set to these standards. There are many

different types of recordable disc formats (including CD-R containing

MP3/WMA files). Given the fact that technology in this area is still maturing, Toshiba cannot guarantee that all

genre of recordable discs will produce optimal playback quality. The technical criteria set out in this owner's

manual are meant as a guide only.

C3.

93 C_

G) C_

O-

Customers should also note that permission is required in order to download MP3 files and music from the

internet. Toshiba has no right to grant such permission. Permission should always be sought from the copyright

owner.

Microsoft, Windows Media, and the Windows Logo are trademarks or registered trademarks

of Microsoft Corporation in both the United States and other countries.

. _Windows

Designed for

491

Page 47

You can play JPEG files that have been recorded on a CD-R or CD-ROM on the DVD video player. You can select a preferred view: a page of 6 thumbnail images, a single image view, and slide

show of a selected folder. Also, rotating, enlarging and shifting of each image can be possible.

Thumbnail view Single image view

• Preparations

• Prepare a disc that contains JPEG files you want to view. [_

• Set "Priority Contents" to "Photo". [_

• Make your TV shape conform to the 4:3 picture size. Only 4:3 pictures can be played regardless of the function settings via the on-screen displays of the DVD video player. If the TV is adjusted to other sizes, e.g. "WIDE,"

images will appear to be horizontally expanded. For details, refer to the owner's manual of your TV.

Press OPEN/CLOSE to open the disc tray.

OPEN/CLOSE

Place a disc that contains JPEG flies on the disc tray.

Stide show

Press OPEN/CLOSE.

OPEN/CLOSE

__d_ The disc tray closes, and the DVD video player reads the loaded disc.

After completion of reading, the OVO video player enters either of the following modes, and provides the respective displays, depending on the condition of the disc contents. Proceed to steps described below.

A thumbnail view appears.

(Automatic mode)

e.g.

Icon of reverse order

Number of a current sebction / Number of images to pmay

Proceed to step 4 on _. Refer to [_, "Selecting a folder."

A list of folders in the disc appears.

(Selection mode)

e.g.

Page 48

Turn the page if necessary.

Press • / • / _ / D,-to select the last image of 6, then press m,..

(Press • / • / .,i/ _,-to select the first image of 6, then press _.)

Selecting _m; (or -_') then pressing the ENTER button also turns the pages.

Alternatively,

Press SKIR

SKIP

:To view the succeeding 6 images. :To view the previous 6 images.

000 © C) () () 0

000 0 000 0

000 0

--4

1,3

4 4

£3. < #3

0 CO

_<_

(3-

The page changes as follows:

Select the viewing options at your preference.

- Viewing a single image: See [_.

- Playing slide show: See [_.

To quit the JPEG playback, press STOR

STOP

Notes

• If you display a thumbnail view from the automatic mode and leave it unattended for approximately 20 seconds, slide show starts automatically.

• When "Screen Saver" is set to "On" [_, a thumbnaii view which is unattended for about 10 minutes automatically changes to slide show.

• Some files may not display their own entire images depending on the size.

• If yOU press the PLAY button after pressing the STOP button, you can return to the thumbnail view.

• Pressing the OPEN/CLOSE button to open the disc tray can also quit the playback.

511

Page 49

wmg JPEG Files (Continued)

0 0

o0o 0 00 (:) o (_)00 o

o0o o

ANGLE

ENTER

• To reverse the order Some cameras may have given the first fi_e number

(e.g. 01 ) always to the latest photo, When you play such fi)es, reverse the order of images. You can view

them in order of time,

Press • / • / 41/ I_ to select" "then press ENTER,

Note

The order of images will be restored when you open the disc tray or turn the power off.

• To set an image rotation on a thumbnail view

1 Select an image by pressing • / • / 4 / _.

• To display a folder list 1 Press • / • / .,t t_- to select" i-_ "

2 Press ENTER.

A folder list appears.

You can select a folder to play. For details, see page

2 Press ANGLE repeatedly.

ANGLE

Note Quitting the JPEG playback restores a rotated image to its

original posture.

Each time you press the ANGLE button, you can set a rotation of the

image in 90 ° increment.

Page 50

On a thumbnail view, select an image by

pressing • / • / _ / t,-.

1 2

C:)CD() _-- T 000 0

000 0

• To change the image To view the succeeding image, press _ or ENTER.

Press ENTER.

The selected image is displayed.

To quit the JPEG playback, press STOR

STOP • If you press the PLAY button after

Notes

• Some files may not display their own entire image depending on the size.

• When "Screen Saver" is set to "On" [_, a which is unattended for about 10 minutes automatically

changes to slide show.

pressing the STOP button, slide show [_ starts.

• Pressing the OPEN/CLOSE button to open the disc tray can also quit the playback.

single image

To view the previous image, press _1.

Notes

• Change of images will be reversed if you reverse the order of images.

• You can view the succeeding image also by pressing the

PAUSE/STEP or SKIP _.J button.

• To reverse the order 1 Press MENU.

MENU The following menu appears for

about 5 seconds. e.g.

Li_t Reverse

o.. 93 C)

Co C_

O- O3

• To confirm a photo number Press T. SEARCH

Notes

• To turn it off, press the T button.

• You can locate an image by entering its number. While displaying a photo number, press the number buttons to

enter a number then press the ENTER button. Slide show will start from the located image.

2 Press • / • to select "Reverse" then press ENTER.

Note

Whenever you change the order, the first or last of images to be played will be located.

531

Page 51

wmg JPEG Files (Continued)

QQ©©

_)00o o0oo

o0oo

ANGLE

ZOOM

ENTER

• To magnify an image Press ZOOM repeatedly,

ZOOM

Each time you press the ZOOM button, the magnification level changes as follows:

"Zoom Off" (The icon and monitor scope appear.) "Zoom1" _ "Zoom2" _ "Zoom3" (Maximum) "Shrink".-_ Original size (The icon and monitor scope disappear.)

Notes

• To turn off the icon and monitor scope, press the

• / • / _1/ I_ buttons to select "EXIT" in the icon, then press the ENTER button.

• While changing the magnification level, you can shift the image. Press and hold the • / • / _1/ ib buttons.

• Exiting an image cancels the current selection of the magnification level.

• To rotate an image Press ANGLE repeatedly.

ANGLE

Notes

• If you rotate an image of which magnification level is changed, the size of the image is restored momentarily.

• Quitting the JPEG playback restores a rotated image to its original posture.

• The DVD video player may redo displaying an image if

you rotate it.

The image rotates by clockwise 90- degree.

• To display a folder list 1 Press MENU.

MENU The following menu appears for

2 Press • / • to select "List" then press ENTER.

about 5 seconds.

List

R_ver_e

A folder list appears.

You can select a folder to play. For details, see

page [_.

• To return to the thumbnail view 1 Press MENU.

2 Press • / • to select "Thumbnail" then press

ENTER.

Page 52

Playing slide show ...... ...........

• To confirm a photo number

On a thumbnail view, select an image from See [_.

which you want to start slide show. You can skip this step. Slide show will start from a • To magnify an image

photograph currently selected. See _.

Press PLAY. Note

Slide show pauses if you press the ZOOM button.

PLAY Slide show starts. • To rotate an image

_) SeeI_.

• To display a folder list

To quit the JPEG playback, press STOR See [_.

• If you press the PLAY button after • To return to the thumbnail view

STOP pressing the STOP button, the See [_.

slide show resumes.

• Pressing the OPEN/CLOSE button to open the disc tray can also quit the playback.

Fh Fh

000 0

000 0 () C} ¢) 0

0_0 0 C)O0 0

000 0

--3

--2

PAUSE/STEP

o.. 93 C_

Co C_

0- I)3

• To view a single image (To pause slide show) Press PAUSE/STEP.

PAUSE/STEP

551

Page 53

" JeEC,Files Continuea)

You can designate a folder to play.

On a single image view or during slide

show, press MENU.

MENU The following menu appears for

To display a folder list also from a thumbnail view, follow the procedure on [_, and skip to step 3.

about 5 seconds. e.g.

ooo 0 c) (l) c) o

(_)oo o ooo o

00o o

Press _ / _ to select a folder.

I_- : If you press this button while

selecting a sub folder, you can view the contents of the folder.

• Sub folders will appear if contained in the selected

folder.

• If the selected folder contains a

file to view, a thumbnail image

of the file will appear in the background.

_1: If you press this button while

selecting a current folder, you can go back to the previous

folder.

Press • / • to select "List" then press

ENTER.

A folder list appears.

Path

Current folder

Sub folders

Press • / • to select a folder.

After thumbnails appear in the background,

press ENTER.

The thumbnail view of the current

folder appears.

For operations of thumbnail view, see [_.

Notes

• The first thumbnail view provided by the automatic mode may not return once you display a folder list. You can retrieve

it if you load the disc again.

• Letters of a folder/path name overflowing the given space are not displayed.

Page 54

JPEG files compatibility

Discs whose compatibility with this DVD video player has been confirmed by TOSHIBA are as follows. Many of these discs, when loaded, will make the DVD video player enter the automatic mode [_ to play a prescribed

folder in the disc. To play other folders, display a folder list and select a folder.

CANON QuickCD FUJICOLOR CD

Kodak Picture CD NORITSU QSS CD

JPEG disc compatibility with this DVD video player is limited as follows:

• Playable discs: CD-ROM, CD-R (650MB / 74 min. only)

• CD physical format:

• File system:

• File name: "JPG"

• Total number of folders:

• Total number of files:

Some files may not display their own entire image depending on the size.

Some discs may not permit this operation. Especially, the following conditions of included files will increase the disc's disability.

1. Pixels over 3072 _ 2048 in height and/or width

2. File format except Exif

Less than 256 Less than 1000

CD-RW is not recommendable.

Mode 1, Mode 2 XA Form 1 ISO9660 Level 1,2 or Joliet

A file name should be in alphabet and numerals only, and must incorporate

extension.

e.g.' ......... .JPG"

93 C)

G) C_

(3- _3

571

Page 55

Page 56

Page 57

ii: stomizing the Function Settings

You can change the default settings to customize performance to your preference.

C) C) C) 0 OOO O

C) C) () O

3,4

RETURN

--2

--1,6

Press SETUP during stop.

SETUP The following on-screen display (_ appears.

Press • / 1_to select a symbol for the

setting you want to change.

(Seethenext page)

Picture performance settings

Output sound settings

Press • / • to select the setting you want

to change, then press ENTER.

(_ iii i,'

Change the selection by • / • or other

buttons, by referring to the corresponding

i!il

pages ([_-), then press ENTER.

Repeat steps 3 and 4 to change other

settings.

Toselect another operation, go back to step 2.

Press SETUR

SETUP

The on-screen display disappears.

ii!!!i i¸

Language settings

Display settings

Operational settings

Initial setup

• To return to the previous display Press RETURN.

RETURN

Notes

• To quit the procedure, press the SETUP button to turn off the on-screen display.

• The SETUP button can function even during normal playback, however some operations may be inaccessible,

and a message will appear. In this case, try again after playback is stopped.

Page 58

Setting Details Page

TV Shape _ To select a picture size according to the aspect ratio 62

Progressive 62

Progressive Conversion 62

Pause/Still 63

PCM Down Sampling _b To select a sound processing option for PCM 63

Digital Output Dynamic Range Control 6_-)

Karaoke Vocal c_T¢__.>

On-Screen Language _ To select a preferred language for on-screen

Disc Menu Language c_-> To select a preferred language for disc menus. 65

Audio Language <6%b To select a preferred language for the sound track. 65

Subtitle Language cb_ To select a preferred language for subtitles. 65

(5_ To select the resolution of still pictures.

v_ 65 (__ displays.

of your TV. To select whether you send progressive

signals to the connected TV or not. To select the system of output signal. (Only when

connected to a PROGRESSIVE TV.)

sounds if they are high frequency signals of 96 kHz.

To select an output sound format corresponding to 64 your system connection.

To turn on or off a function that makes faint sounds 64 easier to hear even if you lower the volume during

late hours playback. To turn on or offthe vocal output during DVD 64

KARAOKE disc playback.

On-Screen Displays _ To turn on or de-activate the operational status 66

Background C_bb To select the background color or background 66

Screen Saver @_,_b To turn the screen saver on or off. 66

Parental Lock To turn the parental lock function on or off.

Title Stop <#';%> PBC

Priority Contents

t ii;d ii

ii{iiii¸¸ _i_iiiii iii

i TV oHp"'-a-e

On-Screen Language

display on the TV screen.

_ picture.

c_ 67

To turn on or off a feature that automatically stops playback after a title has been viewed.

C@Lb

To use the menu screen when playing a PBC- controllable VIDEO CD.

To select the playback priority between JHEG (picture) files and MP3/WMA (audio) files. 68

To install the initial system setting.

611

Page 59

ii: stomizing the Function Settings (continued)

Setting details ...........................................................................................................................................................................................................................................................................................................................................................................................................................................................

4:3 Letterbox: Select when a standard 4:3 TV is

connected. Displays theatrical images with

masking bars above and below the picture.

4:3 Normal: Select when a standard 4:3 TV is

connected. Displays pictures cropped to fill

your TV screen. Either or both sides of the picture are cut off.

16:9 Widescreen: Select when a 16:9 wide TV is

connected.

16:9 Shrink: Select when a 16:9 wide

progressive TV is connected and it cannot fit 4:3 video signal

automatically to its 16:9 screen. Displays 4:3 pictures of the

progressive video signal in the correct ratio with masking bars to

the left and right of the picture.

Notes

• The displayable picture size is preset on the DVD video disc. Therefore, the playback picture of some

DVD video discs may not conform to the picture size you select.

• If you select "I6:9 Widescreen" and you own a 4:3 TV set, the DVD playback picture will be horizontally

distorted during playback. Images will appear to be horizontally compressed. Always be sure that your TV

shape conforms to the actual TV in use.

Disable: Select when a standard (non-

TV is connected. ['_-_1-_'_

L,:**C./ L.:**ZJ

Enable:

progressive)

Select whena,_A_rogressive TV is connected.

Press PROGRESSIVE on the remote control to switch the output signal for better picture quality.

Note

When "Enable" is set and you select the progressive output signal, no video signals are output from the

VIDEO OUT jack and the S VIDEO OUT jack.

There are two types of source content in pictures

recorded in DVD video discs: film content (pictures recorded from films at 24 frames per second) and

video content (video signals recorded at 30 frames per second). Make this selection according to the

type of content being viewed.

Auto: Select this position normally.

The DVD video player automatically detects source content, film or video, of playback

source, and converts that signal to the

progressive output format in an appropriate method.

Video: The DVD video player filters video signal, and

converts it to the progressive output format appropriately.

Suitable for playback of video content

pictures.

Film: The DVD video player converts film content

pictures to the progressive output format

appropriately. Suitable for playback of film content pictures.

The progressive output feature will be most effective under this selection.

Note Dependh_g on the disc, pictures may be cut off or doubled. In this case, select Video."

Page 60

Auto: For normal use. Still and fast motion images

can be paused.

Frame: The resolution of still pictures is improved,

so that you can make a motionless picture more clearer when you pause it.

According to performance of your connected audio system, select a sound processing option for

playback of a disc that contains high frequency

signals (sampling frequency 96 kHz),

Off: Select when you make a connection via the

ANALOG AUDIO OUT jacks. The DVD video player outputs PCM signals

with no conversion. However, if the PCM signals are copy-

protected, they are not output from the BITSTREAM/PCM DIGITAL AUDIO jack,

unless they are 48 kHz/16 bit signals.

Auto: Select when your connected audio system

processes high frequency signals of 96 kHz. The DVD video player outputs PCM signals

with no conversion. However, if the PCM signals are copy-

protected, they are down-sampled to 48 kHz/ 16 bit.

On: Select when your connected audio system

does not process high frequency signals of 96 kHz.

The DVD video player down-samples PCM signals to 48 kHz.

"13

Note If you select "Off" or "Auto" because your connected audio system does not process high frequency signals

of 96 kHz, you wil! not hear output sound from those signals.

631

Page 61

Setting details

Select the output sound format corresponding to your system connection.

For details of sound recording systems, see [_. Bitstream:

Select when connected to an amplifier equipped with a Dotby Digital__DDTS_,

MPEG1 or MPEG2 decoder. 2[_ 2L2L2L_ The DVD video player outputs digital

audio information in the bitstream format when you play a DVD video disc

recorded on the Dolby Digital, DTS, MPEG1 or MPEG2 recording system.

PCM: Select when connected to a 2 channel

digital stereo amplifier. [_ The DVD video player outputs sounds in the PCM 2ch format when you play

a DVD video disc recorded on the Dolby Digital, MPEG1 or MPEG2

recording system.

Note

When you make a connection to a TV, or Dolby

Surround Pro Logic or stereo system via the analog audio jacks, select "Bitstream" or "PCM."

Off: Full dynamic range is maintained. On: Dynamic range is reduced.

Off: The primary vocal is not output. On: The primary vocal is output when it is recorded

on the disc.

Notes

• The vocal output feature is used during playback of Dolby Digital (multi-channel) recorded DVD KARAOKE

discs. This feature allows you to turn off vocal audio tracks, or restore them for background

accompaniment.

• When playing KARAOKE, connect appropriate audio equipment such as an amplifier to the DVD video

player.

Note

The level of Dynamic Range Reduction may differ depending on the DVD disc.

Page 62

English: To view on-screen displays in English. Fran(2ais: To view on-screen displays in French.

Espa_ol: To view on-screen displays in Spanish.

English: To display disc menus in English. French: To display disc menus in French.

Spanish To display disc menus in Spanish. Others: To make a further choice.

After pressing the ENTER button, fo ow steps !) - 4) below.

1) Obtain the abbreviation of the preferred from the list [_.language

2) Select the first character by pressing the • / • buttons.

3) Press the -,11/ • buttons to shift and select the second character by pressing the • / •

buttons.

English: To play sound tracks in English. French: To play sound tracks in French.

Spanish: To play sound tracks in Spanish. Others: To make a further choice.

After pressing the ENTER button, follow steps 1) - 4) below.

1) Obtain the abbreviation of the preferred language from the list [_.

2) Select the first character by pressing the • / • buttons.

3) Press the -,I / I_ buttons to shift and select the

second character by pressing the • / • buttons.

"1"!

.... j

4) Press the ENTER button.

Note Some DVD video discs may be played in a different

language than you selected. A prior language may be programmed on the disc.

4) Press the ENTER button.

Note Some DVD video discs may not include your pre-

selected language, in this case, the DVD video player automatically displays disc menus consistent with the

disc's initial language setting.

English: To display subtitles in English. French: To display subtitles in French.

Spanish: To display subtitles in Spanish.

No Subtitle: To disable subtitles.

Others: To make a further choice.

After pressing the ENTER button, follow steps 1) - 4) below.

1) Obtain the abbreviation of the preferred

language from the list [_.

2) Select the first character by pressing the • / • buttons.

(Continued)

651

Page 63

stomtzmg the Function Settings (continued)

(Continued)

3) Press the _1/ 1_buttons to shift and select the second character by pressing the • / • buttons.

[_nguage ....................

On.Screentanguage ENG [iEngli_h [li_Menu[anguage ENG [ French Audiotan uage ENG liSpani_h

4) Press the ENTER button.

Notes

• Some DVD video discs may be set to display subtitles in a different language than you selected. A prior

subtitle language may be programmed on the disc.

• Some DVD video discs allow you to change subtitle selections only via the disc menu. If this is the case, press the MENU button and choose the appropriate

subtitle language from the selection on the disc menu.

Bo&_nd Gray

} _cree_ _aver On

Off: Operational modes (e.g." _", "_ ") are not

displayed.

On: Operational modes (e.g." _", "_-_> ") are

displayed on-screen.

Blue:

Gray:

Picture:

Blue background. Gray background. To use the picture which appears when you

turn on the DVD video player as a

background.

Jacket:

To use the jacket picture included on some

DVD video discs as a background. If it is not

included, a gray background will be substituted.

Off: The screen saver is disengaged. On: The screen saver operates.

Off: Normal brightness. Half: The DVD display is dimmed.

Full: The DVD display does not illuminate.

Page 64

Ti(le_lop off

PBC On

P_!_!!y_t_._ Ph_!_.....

Press the number buttons to create a personal

4-digit security code, then press the ENTER

button. If you make a mistake before pressing the

ENTER button, press the CLEAR button and enter your 4-digit security code again•

Enter the code of a country/area whose standards were used to rate the DVD video

disc, referring to the list below.

DVD video discs equipped with the parental lock

function are rated according to their content. The contents allowed by a parental lock level and the way

a DVD video disc can be controlled may vary from disc to disc. For example, if the disc allowed you

could edit out violent scenes unsuitable for children and replace them with more suitable scenes, or lock out playback of the disc altogether.

• DVD video discs may or may not respond to the parental lock settings. This is not a defect in the DVD

video p{ayer. Make sure this function works with your

DVD video discs.

Off: The parental lock feature does not function.

After pressing the ENTER button, follow step 1)

below.

On: To activate the parental Iock feature or change

the settings.

After pressing the ENTER button, follow steps

1) - 3) below.

i Title Stop off [_

Priority Content _ p hno,o

Country/Area Code

AUSTRALIA AU

BELGIUM BE CANADA CA

CHINA CN CHINA HONG KONG HK

DENMARK DK FINLAND FI

FRANCE FR GERMANY DE

INDONESIA ID ITALY IT

JAPAN JP MALAYSIA MY

NETHERLANDS NL NORWAY NO

PHILIPPINES PH RUSSIAN FEDERATION RU

SINGAPORE SG SPAIN ES

SWEDEN SE SWITZERLAND CH

TAIWAN TW THAILAND TH

UNITED KINGDOM GB UNITED STATES US

a) Select the first character by pressing the

• / • buttons•

b) Press the 41/ • buttons to shift and select

the second character by pressing the • / • buttons.

c) Press the ENTER button•

"13

(Continued)

671

Page 65

stomtzmg the Function Settings (continued)

I Setting details

(Continued)

3) Press the • / • buttons to select the parental lock level, then press the ENTER button.

Title Stop Off _*rl[

Opera io n

Priority Contents Photo Ar_ Code _[_1

You cannot play DVD video discs rated higher than the level you selected unless you cancel the parental

lock function. For example, when you select level 7, discs rated higher than level 7 are locked out and cannot be played.

The parental lock level is equivalent to the following

USA movie ratings.

Level 7:NC-!7

Level 6: R Level 4: PG !3

Level 3: PG Level 1: G

The parental lock levels for other countries/areas than U.S. are included for future use. Check the

appropriate parental lock level when you buy a DVD video disc equipped with the parental lock feature in

the future.

Qf¢[

Off: The DVD video player continues after playback

of a title is completed.

On: The DVD video player stops after playback of a

title is completed.

Off: When playing a VIDEO CD without using the

menu.

On: To use the menu when playing a PBC-featured

VIDEO CD.

To select the playback priority between JPEG (picture) files and MP3/WMA (audio) files.

Photo: JPEG files take priority over MP3/WMA

Audio: MP3/WMA files take priority over JPEG

Note If this selection does not correspond to disc contents, the DVD video player will take a longer time to start playback

of the disc.

files.

fi_es.

• To change the parental lock level Follow steps 1) - 3).

• To change your 4-digit security code

1) After selecting "On" or "Off," press the STOP button four times, then press the ENTER

button.

STOP STOP STOP STOP

The 4-digit security code is cleared.

2) Press the number buttons to create a new 4-digit security code.

3) Press the ENTER button.

Page 66

.............................:%_ii¸¸¸_......................................._ _i

1) Press the • / • buttons to select "On-Screen Language," and press the ENTER button.

2) Select a language pressing the • / • buttons, and press the ENTER button.

See page [_, "On-screen Language."

-N

3) Make your selection in the same manner as step 1)then step 2).

See page [_, "TV Shape."

691

Page 67

of Languages

Abbreviation Language

No alternate language

CHI (ZH) DUT (NL)

ENG (EN) FRE (FR) GER (DE)

ITA (iT) JPN (JA)

KOR (KO) MAY (MS)

SPA (ES)

AA AB

AF AM

AS AY

AZ BA

BE BG

BH BI

BN BO

CA CO

CS CY

DA DZ

EL EO

ET EU

FA FI

FJ FO

FY GA

GD GL

Chinese Dutch English

French

German Italian Japanese

Korean Malay

Spanish Afar

Abkhazian Afrikaans

Amharic Arabic

Assamese Aymara Azerbaijani

Bashkir Belorussian Bulgarian

Bihari Bislama

Bengali, Bangla

Tibetan

Breton Catalan Corsican

Czech Welsh

Danish Bhutani

Greek Esperanto

Estonian Basque

Persian Finnish Fiji

Faroese Frisian

Irish Scottish Gaelic Galician

Abbreviation Language

GN GU

HA HI

HR HU

HY IA

IE IK

IN IS

IW JI

JW KA

KK KL

KM KN

KS KU

KY LA

LN LO

LT LV

MG MI

MK ML

MN MO

MR MT

MY NA

NE NO

OC OM

OR PA

PL PS

Guarani Gujarati

Hausa Hindi

Croatian

Hungarian

Armenian

_nterlingua Interlingue Inupiak

Indonesian Icelandic

Hebrew

Yiddish Javanese

Georgian Kazakh Greenlandic

Cambodian Kannada

Kashmiri Kurdish

Kirghiz Latin

Lingala Laotian

Lithuanian Latvian, Lettish Malagasy

Maori Macedonian Malayalam Mongolian

Moldavian Marathi

Maltese Burmese

Nauru Nepali

Norwegian

Occitan (Afan) Oromo Oriya

Panjabi Polish

Pashto, Pushto

Abbreviation Language

PT QU

RM RN

RO RU RW

SA SD

SG SH

Sl SK

SL SM

SN SO

SQ SR

SS ST

SU SV

SW TA

TE TG

TH TI

TK TL

TN TO

TR TS

TT TW

UK UR

UZ Vl

VO WO

XH YO

Portuguese Quechua

Rhaeto-Romance Kirundi

Rumanian Russian Kinyarwanda

Sanskrit Sindhi Sango

Serbo-Croatian Singhalese

Slovak Slovenian

Samoan Shona

Somali Albanian

Serbian Siswati

Sesotho Sundanese Swedish

Swahili

Tamil Telugu

Tajik Thai

Tigrinya Turkmen

Tagalog Setswana

Tongan Turkish

Tsonga Tatar

Twi Ukrainian

Urdu

Uzbek Vietnamese VolapQk

Wolof Xhosa

Yoruba Zulu

Page 68

Page 69

Calling Service Personnel

Check the following guide for the possible cause of a problem before contacting service.

Symptoms and correction

Symptom No power.

The DVD video player turned off by itself.

No picture.

No saund.

The playback picture has occasional distortion.

Brightness is unstable or noises are present in the

playback pictures.

The DVD video player does

not start playback.

Playback does not follow the course of the disc's program.

Buttons do not work.

The remote control does not work properly.

Cause

• The power plug is disconnected.

• The automatic power off function turned the unit off.

• The TV is not set to receive DVD signal output.

• The video cable is not connected securely.

• The equipment connected with the audio cable is not set to receive DVD signal

output.

• The audio cable is not connected securely.

• The audio receiver or TV is turned off.

• The setting of output sound format is incorrect.

• The disc is dirty.

• It is in fast forward or fast reverse playback.

• The effect of copy protection.

• No disc is inserted.

• An unplayable disc is inserted.

• The disc is placed upside down.

• The disc is not placed within the guide.

• The disc is dirty.

• The parental lock function is set.

• It is in the mode of repeat playback,

memory playback, etc.

• Power supply fluctuations or other

abnormalities such as static electricity may interrupt correct operations.

• The remote control is not pointed at the

remote sensor of the DVD video player.

• The remote control is too far from the DVD video player.

• The batteries in the remote control are exhausted.

Correction Page

• Connect the power plug securely into the 18 wal! outlet.

• Press the PLAY button. 27

• Select the appropriate video input mode 26 on the TV so the picture from the DVD

video player appears on the TV screen.

• Connect the video cable securely into the appropriate jacks.

• Select the correct input mode of the audio receiver so you can listen to the

sound from the DVD video player.

• Connect the audio cable securely into the appropriate jacks.

• Turn on the equipment connected with the audio cable.

• Select the proper audio setting.

• Eject the disc and clean it.

• Sometimes a small amount of picture distortion may appear. This is not a

malfunction.

• Connect the DVD video player directly to 18 the TV. Avoid connecting the DVD video

player to a VCR or TV/VCR combination.

• Insert a disc. 26

• Insert a playable disc. (Check the disc 10 type and color system.)

• Place the disc with the playback side 26 down.

• Place the disc correctly inside the guide 26 on the disc tray.

• Clean the disc. 9

• Cancel the parental (ock function or 60, 67

change the parental tack level.

• These operations may prevent a proper

progress of the contents.

• Press and hold the ON/STANDBY

button on the front panel for more than about 3 seconds. The DVD video player turns off. Press the button again to turn

it on. if the buttons stil! do not work, disconnect the power plug and insert it

into the wal! outlet again.

• Point the remote control at the remote 15

sensor of the DVD video player.

• Operate the remote control within about 15

7m.

• Replace the batteries with new ones. 15

18, 19

18 - 23

43,60

Page 70

i!Jii{!_ii!!:i'!!_i'i!i!;'!!i!:_!!_!:_!!_!:_!!_!:_!i¸i_i!i!!i_!iJ!!!!J!!!!ii!i!!!!!!_!i!_!!!_!_!;_!!i!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!_!:_!!i

I DVD video player / outputs / supplied accessories

DVD Video Player

Power supply 120 V AC, 60 Hz Power consumption 14 W

Mass 2.2 kg External dimensions 430 x 50 x 200 mm (W/H/D) Signal system Standard NTSC

Laser Semiconductor laser, wavelength 650/780 nm Frequency range DVD linear sound : 48 kHz sampling 4 Hz to 22 kHz

96 kHz sampling 4 Hz to 44 kHz

Signal-to-noise ratio More than 112 dB

Audio dynamic range More than 102 dB

Harmonic distortion Less than 0.002 %

Wow and flutter Below measurable level (less than +0.001% (W.PEAK)) Operating conditions Temperature: 5 °C to 35 °C, Operation status: Horizontal

Outputs

Video output 1.0 V (p-p), 75 _, negative sync., pin jack _ 1 S video output (Y) 1.0 V (p-p), 75 _, negative sync., Mini DIN 4-pin _ 1

Component video output (Y) 1.0 V (p-p), 75 _, negative sync., pin jack o_1

(PB)I(PR) 0.7 V (p-p), 75 _, pin jack _ 2

Audio output (BITSTREAM/PCM 0.5V (p-p), 75 £_, pin jack _ 1 COAXIAL)

Audio output (ANALOG) 2.0 V (rms), 680 £_, pin jacks (L, R) _ 1

¢9

Supplied Accessories

Audio/video cable .................................................. 1

Remote control (SE-R0107) .................................. 1

Batteries (AAA) ...................................................... 2

• Designs and specifications are subject to change without notice.

731

Page 71

LIMITED WARRANTY DVD VIDEO PLAYER

Toshiba America Consumer Products, Inc. ("TACP") and Toshiba Hawaii, Inc. ("THI") make the following limited warranties to original consumers for DVD Players purchased and used in the United States. THESE LIMITED WARRANTIES EXTEND TO

THE ORIGINAL CONSUMER PURCHASER OR ANY PERSON RECEIVING THIS DVD PLAYER AS A GIFT FROM THE ORIGINAL CONSUMER PURCHASER AND TO NO OTHER PURCHASER OR TRANSFEREE.

PRODUCTS PURCHASED IN THE U.S.A. AND USED IN CANADA ARE NOT COVERED BY THESE WARRANTIES. PRODUCTS PURCHASED IN CANADA AND USED IN THE U.S.A. ARE NOT COVERED BY THESE WARRANTIES.

Limited One (1) Year Warranty*

TACP/TH! warrants this DVD Player against defects in

materials or workmanship for a period of one (1) year after

the date of the original retail purchase. DURING THIS

PERIOD TACP/TH! WILL, AT TACP/TH!'S OPTION,

REPAIR OR EXCHANGE A DEFECTIVE DVD PLAYER WITH A NEW OR REFURBISHED DVD PLAYER, AT TACP/TH!'s OPTION. DURING THE INITIAL NINETY (90)

DAYS, THIS REPAIR OR EXCHANGE WILL BE WITHOUT

CHARGE TO YOU, EXCEPT YOU MUST PAY FOR ALL

TRANSPORTATION AND INSURANCE CHARGES FOR

THE DVD PLAYER TO BE SHIPPED TO THE

DESIGNATED TACP/TH! FACILITY. AFTER THE INITIAL

NINETY (90) DAYS AND FOR THE REMAINDER OF THE WARRANTY PERIOD, AN ADDITIONAL HANDLING FEE

WILL APPLY. YOU MUST DELIVER THE ENTIRE DVD

PLAYER AND ALL ACCESSORIES (SUCH AS POWER

CORDS, CABLES, AND THE UNIT'S REMOTE CONTROL

DEVICE) TO THE DESIGNATED TACP/THI FACILITY, AS

INSTRUCTED BY TACP/THI. TACP/THI IS NOT

RESPONSIBLE IF YOUR DVD PLAYER IS LOST OR

DAMAGED DURING SHIPMENT.

*Commercial Units

DVD Players sold and used for commercial purposes have

a limited ninety (90) day warranty.

Rental Units

The warranty period for rental units begins with the first

rental or thirty (30) days from the date of shipment to the

rental firm, whichever comes first.

Owner's Manual and Demographic Card

You should read this owner's manual thoroughly before

operating this DVD Player.You should complete and mail

the enclosed Demographic Card within ten days after you,

or the person who has given you this product as a gift,

purchased this DVD Player. This is one way to enable

TACP/TH! to provide you with better customer service and

improved products. Failure to return the Demographic Card

will not affect your rights under this warranty.

Your Responsibility THE ABOVE LIMITED WARRANTIES ARE SUBJECT TO

THE FOLLOWING CONDITIONS: (!) You must provide your bill of sale or other proof of

purchase. For rental firms, proof of first rental is also required.

(2) The limited warranties from TACP and TH! are effective

only if the DVD Player is purchased and operated in the

U.S.A. or Puerto Rico.

(3) Labor service charges for installation, set up, and

adjustment of customer controls are not covered by these limited warranties.

These limited warranties extend only to defects in

(4)

materials or workmanship as limited above and do not

extend to any DVD Player or accessories which have

been lost or discarded by you, or to damage to any DVD Player or accessories caused by misuse,

accident, Acts of God (such as lightning), or to fluctuations in electric power, improper installation,

improper maintenance or use in violation of instructions

furnished by TACP/TH!; or to units which have been

modified or which have had the serial number removed, altered, defaced or rendered illegible.

(5) Physically damaged DVD Players are not acceptable

for repair or exchange whether in or out of warranty and will be returned as received.

How to Obtain Warranty Services If, after following all of the operating instructions in this

manual and checking the "Troubleshooting" section, you find that service is needed, call one of the following

Customer Solutions Centers to obtain further instructions. Have your proof of purchase and your model and serial

numbers available when you call.

For DVD Players purchased in the United States, except Hawaii, call TACP, toll free at 1-866-583-7353.

For DVD Players purchased in Hawaii, call THI. at 808-591-9281.

For additional updates, visit TACP's web site: www.toshiba.comttacp.

Page 72

LIMITATION OF IMPLIED WARRANTIES ALL WARRANTIES IMPLIED BY THE LAW OF ANY

STATE OF THE U.S.A., INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS

FOR A PARTICULAR PURPOSE, ARE EXPRESSLY LIMITED TO THE DURATION OF THE LIMITED

WARRANTIES SET FORTH ABOVE.

Time for Taking Action The time within which action must be commenced to enforce any obligation of TACP orTHI arising under this

limited warranty or under any law of the United States or of any state thereof is hereby limited to 90 days from the date

you discovered, or should have discovered, the defect. This limitation does not apply to implied warranties arising under

the law of any state of the U.S.A.

LIMITATION OF WARRANTY WITH THE EXCEPTION OF ANY WARRANTIES IMPLIED

BY THE LAW OF ANY STATE OF THE U.S.A. AS HEREBY LIMITED, THE FOREGOING LIMITED WARRANTY IS

EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES, GUARANTEES, AGREEMENTS AND SIMILAR

OBLIGATIONS OF TACP OR THI WITH RESPECT TO YOUR DVD PLAYER.

EXCLUSION OF DAMAGES IN NO EVENT SHALL TACP OR THI BE LIABLE FOR

CONSEQUENTIAL OR INCIDENTAL DAMAGES.

No Change, Modification, or Extension No person, agent, distributor, dealer or company is

authorized to change, modify or extend the terms of these limited warranties in any manner whatsoever.

ATTENTION CANADIAN CONSUMERS: Canadian consumers are requested to complete the special Canadian "Warranty Registration Form" enclosed, and

forward this completed form with a copy of bill of sale to TOSHIBA OF CANADA to "Register and Validate" their warranty. Product must be purchased from an Authorized Canadian Dealer. Products purchased in the U.S.A. and used in Canada

are not covered by these warranties.

Contact: Toshiba of Canada Limited Consumer EIectronics Group Consumer EIectronics Group Consumer Electronics Group

191 McNabb Street 22171 Fraserwood Way 1643 North Service Road

Markham, Ontario L3R 8H2 Richmond, B.C. V6W 1J5 Droval, QC H9P IJ 1 (905)-470-5400 (604)-303-2500 (514)-856-4100

HOW STATE LAW RELATES TO WARRANTY THIS WARRANTY GIVES YOU SPECIFIC LEGAL

RIGHTS, ANDYOU MAY ALSO HAVE OTHER RIGHTS WHICH MAY VARY FROM STATE TO STATE IN THE U.S.A.

SOME STATES OF THE U.S.A. DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY

LASTS, WHEN AN ACTION MAY BE BROUGHT, OR THE EXCLUSION OR LIMITATION OF INCIDENTAL OR

CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO

YOU UNDER SUCH CIRCUMSTANCES.

IMPORTANT: PACKING AND SHIPPING INSTRUCTION

When you send the product to a Service Station, you must use the original carton box and packing material, then insert the original carton box containing the unit into another carton using more packing material.

751

Page 73

TOSHIBA

Printed in China

8! 1-SD39A1-010

Toshiba SD-3960SU User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
