Introduction

CAUTION: VISIBLE LASER RADIATION WHEN

OPEN. DO NOT STARE INTO BEAM.

SAFETY PRECAUTIONS

English

WARNING:

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. DANGEROUS HIGH VOLTAGES ARE PRESENT INSIDE THE ENCLOSURE. DO NOT OPEN THE CABINET. REFER SERVICING TO QUALIFIED PERSONNEL ONLY.

CAUTION:

PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS GIVEN IN THIS OWNER' S MANUAL AND THOSE MARKED ON THE UNIT. RETAIN THIS BOOKLET FOR FUTURE REFERENCE.

CAUTION:

USE OF ANY CONTROLS, ADJUSTMENTS, OR PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

Changes or modications made to this equipment, not expressly approved by Toshiba, or parties

authorized by Toshiba, could void the user' s authority to operate the equipment.

This symbol is intended to alert the user

of the presence of uninsulated 'dangerous

voltage' within the product' s enclosure that may be of sufcient magnitude

to constitute a risk of electric shock to people.

The exclamation point within an equila-

teral triangle is intended to alert the user to the presence of important operating

and maintenance (servicing) instructions

in the literature accompanying the appliance.

The symbol for CLASS II (Double Insulation)

IMPORTANT SAFETY INSTRUCTIONS

This unit has been designed and manufactured to assure personal safety. Improper use can result in electric shock

or re hazard. The safeguards incorporated in this unit will protect you if you observe the following procedures for installation, use and servicing. This unit is fully transistorized and does not contain any parts that can be repaired by the

user. DO NOT REMOVE THE CABINET COVER, OR YOU MAY BE EXPOSED TO DANGEROUS VOLTAGE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL ONLY.

1. Read these instructions.

2. Keep these instructions.

3. Read all warnings.

4. Follow all instructions.

5. Do not use this appliance near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including ampliers) that produce heat.

9. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

10. Only use attachments/accessories specied by the manufacturer.

11. Use only with the cart, stand, tripod, bracket, or table specied by the manufacturer, or sold with

the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

12. Unplug this apparatus during lightning storms or when unused for long periods of time.

13. Refer all servicing to qualied service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the

apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

14. Do not overload wall outlets; extension cords, or integral convenience receptacles as this can result in a risk of re

or electric shock.

15. Apparatus shall not be exposed to dripping or splashing and no objects lled with liquids, such as vases, shall be

placed on the apparatus.

16. Keep your ngers well clear of the disc tray as it is closing. Neglecting to do so may cause serious personal injury.

17. Do not place a heavy object on or step on the apparatus. The object may fall, causing serious personal injury and

serious damage to the apparatus.

Introduction

18. Do not use a cracked , deformed, or repaired disc. These discs are easily broken and may cause serious personal

injury and apparatus malfunction.

19. If the apparatus should smoke or smell, immediately disconnect the power cord from the wall outlet. Wait until the smoke or smell stops, then ask your dealer for a check and repair. Neglecting to do so may cause re.

20. While it is thundering, do not touch the connecting cables or the apparatus.

SOME DOS AND DON'TS ON THE SAFE USE OF EQUIPMENT

This equipment has been designed and manufactured to meet international safety standards but, like any electrical equipment, care must be taken if you are to obtain the best results and safety is to be assured. So, please read the points below for your own safety. They are of a general nature, intended to help you with all your electronic consumer products and some points may not apply to the goods you have just purchased.

read the operating instructions before you attempt to use the equipment.

ensure that all electrical connections (including the mains plug, extension leads and inter- connections between

the pieces of equipment) are properly made and in accordance with the manufacturer's instructions. Switch off and withdraw the mains plug before making or changing connections.

consult your dealer if you are ever in doubt about the installation, operation or safety of your equipment.

be careful with glass panels or doors on equipment.

remove any xed cover as this may expose dangerous voltages.

DON'T

obstruct the ventilation openings of the equipment with items such as newspapers, tablecloths, curtains, etc.

DON'T

Overheating will cause damage and shorten the life of the equipment.

allow electrical equipment to be exposed to dripping or splashing, or objects lled with liquids, such as vases,

DON'T

to be placed on the equipment.

place hot objects or naked ame sources such as lighted candles or nightlights on, or close to equipment. High

DON'T

temperatures can melt plastic and lead to res.

use makeshift stands and NEVER fix legs with wood screws - to ensure complete safety always fit the

DON'T

manufacturer's approved stand or legs with the xings provided according to the instructions.

listen to headphones at high volume, as such use can permanently damage your hearing.

DON'T

leave equipment switched on when it is unattended unless it is specifically stated that it is designed for

DON'T

unattended operation or has a stand-by mode. Switch off using the switch on the equipment and make sure that your family know how to do this. Special arrangements may need to be made for inrm or handicapped people.

continue to operate the equipment if you are in any doubt about it working normally, or if it is damaged in any

DON'T

way - switch off, withdraw the mains plug and consult your dealer.

ABOVE ALL

-NEVER let anyone especially children push anything into holes, slots or any other opening in the case - this could result in a fatal electrical shock;

-NEVER guess or take chances with electrical equipment of any kind

-it is better to be safe than sorry!

The following information applies only to the model for U.K..

General Information

This appliance may be tted with a non-rewireable plug. If it is necessary to change the fuse in a non-rewireable

plug the fuse cover must be refitted. If the fuse cover is lost or damaged, the plug must not be used until a replacement available from the appliance manufacturer is obtained. If the plug has to be changed because it is not suitable for your socket, or becomes damaged, it should be cut off and an appropriate plug tted following the wiring instructions below. The plug removed must be disposed of safely as it is hazardous if inserted into a live socket.

English

IMPORTANT

The wires in this mains lead are coloured in accordance with the following code: BLUE: NEUTRAL BROWN: LIVE As the colours of the wires in the mains lead of this unit may not correspond with the coloured markings identifying

the terminals in your plug, proceed as follows:

The wire that is coloured blue must be connected to the terminal in the plug which is marked with the letter N or

coloured black.

The wire that is coloured brown must be connected to the terminal which is marked with the letter L or coloured red.

Do not connect either wire to the earth terminal which is marked by the letter E or by the safety earth symbol or coloured green or green-and-yellow.

Use a 5A BS1362 fuse which is approved by ASTA or BSI. Always replace the fuse cover after changing the fuse.

Introduction

CAUTION:

This Digital Video Disc Player employs a Laser System.

To ensure proper use of this product, please read this owner’s manual carefully and retain for future reference

English

Should the unit require maintenance, contact an authorized service location. Use of controls or adjustments or performance of procedures other than those specied herein may result in hazardous radiation exposure. To prevent direct exposure to laser beam, do not try to open the enclosure. Visible and invisible laser radiation when open and interlocks defeated.

DO NOT STARE INTO BEAM.

CAUTION: These servicing instructions are for use by qualied service personnel only. To reduce the risk of electric shock do not perform any servicing other than that contained in the operating instructions unless you are qualied to do so.

Be aware that this equipment is still powered when in standby mode. To disconnect this equipment completely from the mains power, pull out the power plug from the wall outlet.

Environmental Information

All unnecessary packaging has been omitted. The packaging has been made easy to separate into three materials; cardboard (box), polystyrene foam (buffer) and polyethylene (bags, protective foam sheet). Your DVD player consists of materials which can be recycled and reused if disassembled by a specialised company. Please observe the local regulations regarding the disposal of packaging materials, exhausted batteries and old equipment.

LASER Type Semiconductor laser

InGaAIP(DVD) AIGaAs(CD) Wave length 657 nm(DVD) 790 nm(CD) Output Power 5.5 mW(DVD)

7.0 mW(VCD/CD) Beam divergence 60 degrees

Where the MAINS plug or an appliance coupler is used as the disconnect device, the disconnect device shall remain

readily operable.

In the spaces provided below, record the Model and Serial No. located on the rear panel of your DVD video player.

Model No. Serial No. Retain this information for future reference.

10cm (4.0")

5cm (2.0")

Introduction

WARNING: RISK OF ELECTRIC SHOCK!

Never attempt to service this product yourself. Opening and removing the covers may expose you

to dangerous voltage or other hazards. Failure to follow this WARNING may result in death or serious injury. Refer all servicing not specied in this manual to a Toshiba Authorized Service Center.

Setup

Finding a suitable location

-Place the set on a at, hard and stable surface.

-Do not place the set on a carpet.

-Do not position the set on top of other equipment that might heat it up (e.g., receiver or amplier).

-Do not put anything under the set (e.g.CDs, magazines).

-Install this unit near the AC outlet and where the AC power plug can be reached easily.

Space for ventilation

-Place the apparatus in a location with adequate ventilation to prevent internal heat build up. Allow at least 10 cm (4.0'') clearance from the rear and the top of the set and 5 cm (2.0'') from the left and right to prevent overheating.

Avoid high temperatures, moisture, water and

dust

-Apparatus shall not be exposed to dripping or

splashing.

-Do not place any sources of danger on the

apparatus (e.g., liquid lled objects, lighted candles).

Cleaning discs

Some problems occur because the disc inside the

system is dirty (frozen picture, sound disruptions, picture distortions). To avoid these problems, discs

should be cleaned on a regular basis.

To clean a disc, use a micro bre cleaning cloth

and wipe the disc from the center to the edge in a

straight line. Do not touch the playback side of the

disc.

CAUTION!

Do not use solvents such as benzene, thinner, commercially available cleaners, or anti-static sprays

intended for analog discs. Since the optical unit

(laser) of the DVD system operates at a higher

power than regular DVD or CD players, cleaning

CDs intended for DVD or CD players may damage

the optical unit (laser). Therefore, refrain from using

a cleaning CD.

Moisture Condensation

Moisture condensation damages the DVD player.

Please read the following carefully. Moisture condensation occurs, for example, when you pour a cold drink into a glass on a warm day. Drops of water form on the outside of the glass. In the same way, moisture may condense on the optical pick-up lens

inside this unit, one of the most crucial internal parts of the DVD player.

If you use the DVD player in such a situation, it may

damage discs and internal parts. Remove the disc, connect the power cord of the DVD player to the wall outlet, turn on the DVD player, and leave it for two or three hours. After two or three hours, the DVD player will have warmed up and evaporated any moisture. Keep the DVD player connected to the wall outlet and moisture condensation will seldom occur.

Region Codes

This DVD player is designed to support the Region

Management System. Check the regional code number on the disc package. If the number does not match the player' s region number (see table on

page 5), the player may be unable to playback the

disc.

Tips:

-It may not be possible to play CD-R/RW , DVD+R/

RW , or DVD+R DL in all cases due to the type of disc or condition of the recording.

-If you are having trouble playing a certain disc, remove the disc and try a different one. Improperly formatted disc will not play on this DVD Player.

English

Introduction

ALL

Region

U.S.A. and Canada regions

U.K., Europe regions and

Asia Paci c, Taiwan, Korea

Australia, New Zealand, Latin America

Russia and India regions

China, Calcos Islands, Walls and Futuna

Islands

ALL

Discs that can

be played

ALL

Japan

English

This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights

owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is

prohibited.

Notes on copyright

The unauthorized recording, use, distribution, or revision of television programs, videotapes, DVDs and other materials, is prohibited under the Copyright Laws of the United States and other countries, and may subject you to civil and/or criminal liability.

EU Conformity Statement

“This product is marked with “CE” and complies therefore with the applicable harmonized European standards listed under the Low Voltage Directive 2006/95/EC and the EMC Directive 2004/108/EC.”

Responsible for CE-marking is TOSHIBA INFORMATION SYSTEMS (U.K.) LTD, Toshiba Court, Weybridge

Business Park, Addlestone Road, Weybridge,Surrey, KT15 2UL, United Kingdom.

Fo llowi ng in fo rm at ion is only for EUmember States:

The use of the symbol indicates that this product may not be treated as household

waste. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of

this product. For more detailed information about recycling of this product, please

contact your local city ofce, your household waste disposal service or the shop where you

purchased the product.

Following inf orma tion is only val id EUmember States:

Pb,Hg,Cd

Disposal of batteries and/or accumulators

The crossed out wheeled dust bin symbol

indicates that batteries and/or accumulators must be collected and disposed of separately

from household waste.

If the battery or a ccumulator contains more

th an the spe ci fi ed values of lea d (P b) , mercury (Hg), and/or cadmium (Cd) defined in the Battery Directive (2006/66/EC), then the chemical symbols for lead (Pb), mercury (Hg) and/or cadmium (Cd) will appear below the crossed out wheeled dust bin symbol.

By par tic ip ati ng in separa te collec tio n of

batteries, you will help to assure the proper

di sp osa l of pr odu ct s an d batt er ie s an d

th us hel p to pr ev ent po tential negativ e co ns eq uences for the en vironment and

human health.

Fo r more de ta iled inf or matio n abo ut the

collection and recycling programmes available

in your country, please contact your local city

office or the shop where you purchased the

product.

Introduction

Table of Contents

Introduction

SAFETY PRECAUTIONS 1

IMPORTANT SAFETY INSTRUCTIONS 1-3

Setup 4 Cleaning discs 4 Moisture Condensation 4

Region Codes 4-5

Table of Contents 6

Connections

Connecting to television 7

Connecting to a Stereo System 8

Connecting to a Digital AV Receiver 8 Connecting the power cord 9

Product Overview

Front and Rear panels 10 Remote Control 11

Getting Started

Inserting Batteries 12

Finding your viewing channel 12

Setting the language 12-13 .

Playback from Disc

Playable discs 13

Playback Feature

Starting disc playback 14 Basic playback control 14

Operations for video playback (DVD/VCD/SVCD) 14-15 Selecting various repeat functions 15 Viewing the disc playback Information 15

Special DVD Features 16 Special VCD and SVCD Features 16

Playing a DivX® Disc 16 Playing MP3/JPEG/Kodak picture CD 16-17

DVD Menu Options

Using the Language setup menu 18

Using the Video setup menu 18-19 Using the Audio setup menu 19-20 Using the Rating setup menu 20-21 Using the Misc (Miscellaneous) setup menu 21-22

Tray Lock 22

Others

Specications 23 Troubleshooting 24-25

Glossary 26

English

Connections

Connecting to television

English

IMPORTANT!

– You only need to make one video connection

from the following options, depending on the

capabilities of your television. – Connect the DVD player directly to the television.

Using SCART socket

Use the scart cable to connect the DVD SCART OUT

to the corresponding scart input socket on the TV (cable not supplied).

If your DVD player will not be connected to a Stereo

System or AV Receiver to hear better sound, scart is

enough for both audio and video connections.

Using Composite Video Jack(CVBS)

A Use the composite video cable (yellow) to connect

the DVD player' s VIDEO(CVBS) jack to the video input jack(or labelled as A/V in, Video In or

Composite) on the TV(cable not supplied).

To hear the sound of this DVD player through your

TV, use the audio cables(white/red)to connect AUDIO OUT(L/R)jacks of the DVD player to corresponding AUDIO IN jacks on the TV(cable not supplied).

Helpful hint: Before making or changing any connections, make sure that all the devices are disconnected from the power outlet.

Connections

Connecting to a Stereo System

Stereo System with Left/Right Audio In Jacks

A Select one of the video connections (CVBS VIDEO

IN or SCART IN)

depending on the options available on your TV.

B Use the audio cables (white/red) to connect AUDIO

OUT (L/R) jacks of the DVD Player to the

corresponding AUDIO IN jacks on the stereo system

(cable not supplied).

Connecting to a Digital AV Receiver

Receiver has a PCM, Dolby Digital or MPEG

decoder

A Select one of the video connections (CVBS VIDEO IN

or SCART IN) depending on the options available on

your TV.

B Connect the COAXIAL jack of the DVD player to the

corresponding Digital Audio In jack on your Receiver (cable not supplied).

C Set the DVD Player' s Digital Output to PCM or All

depending on the capabilities of your Receiver (see page 20 {Digital Output}).

Tip:

-If the audio format of the Digital Output does not match the capabilities of your receiver, the receiver will produce a strong, distorted sound or no sound at all.

English

Helpful hint: Before making or changing any connections, make sure that all the devices are disconnected from the power outlet.

Connections

Connecting the power cord

English

After everything is connected properly, plug in the AC

power cord to the power outlet.

Never make or change any connections with the

power switched on.

Helpful hint: Before making or changing any connections, make sure that all the devices are disconnected from the power outlet.

Front and Rear panels

Product Overview

Disc tray

- Place a disc here

OPEN/CLOSE

- Opens or closes the disc tray

IR Sensor

- Points the remote control towards this sensor

MAINS ~

- Connects to a standard AC outlet

AUDIO OUT (Left/Right)

- Connects to Audio input of a TV, an amplier, receiver or stereo system

COAXIAL(Digital audio out)

- Connects to coaxial Audio input of a digital audio equipment

I/2

- Turns the player on or switches it to standby

ON/STANDBY

mode

B/X PLAY/ PAUSE

- Starts or pauses playback

- Stops playback

- Shows information about the current status

STOP

Display

of the DVD Player

SCART OUT

- Connects to SCART input of a TV

VIDEO Out (CVBS)

- Connects to CVBS Video input of a TV

English

DVD display

Multifunctional indicator (indicates

operating status or messages, etc.)

No disc Bad disc

DVD video disc

•During playback: Example

Power Off LoadingOpen

VIDEO CD Audio CD

•During playback: Example

Product Overview

Remote Control

English

See the page in [ ] for details.

[ 15 ]

-Displays information on

TV screen during playback

-Open/close the disc tray

[ 14, 15, 21 ]

-Selects numbered items in a menu

-Press to enter number greater than 9

-Press +10 button repeatedly to select

Control (PBC) mode (for VCD 2.0 /

-Press to view a page of 9 thumbnail

-Skip to previous / next chapter /track

-Repeats playback from point A to B on

-Delete the mistyped entries or cancel

[ 14 ]

-Press to enter track/chapter/title numbers or password directly

-Enters or exits the disc menu

-Switches on or off the Playback

-Acknowledge menu selection

-To go back to previous menu

images during JPEG playback

-Do a forward/reverse search

[ 14, 16, 17 ]

-Selects various repeat mode

DISPLAY

OPEN/CLOSE

Number Buttons

[ 14 ]

+10 button

10,20,30...etc

[ 14, 16 ]

SVCD only)

[ 12 ]

[ 16 ]

RETURN

[ 16, 17 ]

TITLE

-Show title menu

[ 15 ]

F.R & F.F

PREV & NEXT

[ 15 ]

REPEAT

[ 15 ]

A-B

a disc

[ 15 ]

-Do a slow forward

SLOW

[ 14 ]

CLEAR

some functions

REMOTE SIGNAL EMITTER

[ 12 ]

-Point remote control to the sensor on

the front panel

ON / STANDBY

-To switch the DVD player to ON or

standby mode

T - SEARCH

-Start playback from a designated

point

[ 12, 18 ]

SETUP

-Enters or exits the system setup

[ 14, 15, 16, 17 ]

   

-Cursor buttons for moving to the left / right / up / down

-To rotate the JPEG picture during

playback

STEP

-Play video frame by frame

PLAY/PAUSE

-Starts or pauses playback

[ 14 ]

STOP

-Stops play

SUBTITLE

-To access subtitle language

[ 15 ]

ANGLE

-Switch the camera angle during

playback

[ 16 ]

AUDIO

-Selects an audio setting (DVD) or an audio channel (VCD)

[ 15, 17 ]

ZOOM

-Enlarge a picture on the TV

RANDOM

-Toggles between Normal and

Random playback

[ 14]

PROG

-To program playback or cancel the

program playback

[ 14 ]

[ 15 ]

[ 14, 15, 16 ]

[ 16 ]

[ 17 ]

Inserting Batteries

OPEN/CLOSE DISPLAY

ON/STANDBY

30 30

Within about 6m (19 feet)

Audio : English

DivX Subtitle

: English

DVD Menu

: English

OSD language English

Subtitle

Language

Video

Audio

Misc

Rating

Polski

Hungarian

Português

Français

Deutsch

OSD language

: English

Subtitle

: Auto

Language

Video

Audio

Misc

Rating

DivX Subtitle : Standard

DVD Menu

Audio

English

German

Polish

Hungarian

Portuguese

French

A Open the battery compartment. B Insert two batteries type R03 or AAA, following the

indications (+ / - ) inside the compartment.

C Close the cover.

CAUTION:

- Never throw batteries into a re.

- The batteries shall not be exposed to excessive heat

such as sunshine, re or the like.

Note:

- Be sure to use AAA size batteries.

- Dispose of batteries in a designated disposal area.

- Batteries should always be disposed of with the environment in mind. Always dispose of batteries in accordance with applicable laws and regulations.

- If the remote control does not operate correctly, or if

the operating range becomes reduced, replace batteries

with new ones.

- When necessary to replace batteries in the remote control, always replace both batteries with new ones. Never mix battery types or use new and used batteries

in combination.

- Always remove batteries from remote control if they

are dead or if the remote control is not to be used for an

extended period of time. This will prevent battery acid

from leaking into the battery compartment.

Using the Remote Control to Operate the System

Getting Started

Usually these channels are between the lowest

and highest channels and may be called FRONT, A/V IN or VIDEO. See your TV' s manual for more details.

Or, you may go to channel 1 on your TV, then

press the Channel down button repeatedly until you

see the Video In channel.

Or, the TV remote control may have a button that

chooses different video modes.

C If you are using external equipment, (such as

audio system or receiver), turn it on and select the

appropriate input source for the DVD player output.

Refer to the equipment user’s manual for detail.

Setting the language

Choose your desired On-Screen Display(OSD)language

where available.

On-Screen Display (OSD) Language

The On-screen language for the system setup menu will remain as you set it, regardless of various disc

languages.

Press SETUP.

Press / to select { Language }.

Press  to highlight { OSD language }, then press .

Press / to select a language and press OK to

conrm.

Subtitle, DivX Subtitle, Audio and DVD

Menu language

You can choose your own preferred language or

soundtrack from Subtitle, DivX Subtitle, Audio and

DVD Menu languages. If the language selected is not

available on the disc, the disc’s default language will

be used instead.

English

A Aim the Remote Control directly at the remote sensor

(IR) on the front panel.

B Do not put any objects between the Remote Control

and DVD Player while operating the DVD Player.

Finding your viewing channel

A Press I/2ON/STANDBY on the DVD player to turn it

on.

B Turn on the TV and set it to the correct Video-In

channel. You should see the blue DVD background screen.

Helpful hint: Press  to go back to previous menu item. Press SETUP to exit the menu item.

Press SETUP.

Press / to select { Language }, then press .

Press / to highlight one of the options below,

then press . { Subtitle } Select this to change the subtitle language. { DivX Subtitle }

Select this to change the DivX® subtitle language.

Getting Started/Playback from disc

{ Audio }

Select this to change the disc soundtrack language.

English

{ DVD Menu } Select this to change the language of the disc menu.

Use / to select a language and press OK to

conrm.

Repeat steps C - D for other language settings.

IMPORTANT!

- DVD discs and players are designed with regional restrictions. Before playing a disc, make sure the disc is for the same zone as your player.

- If ' 'appears on the TV screen when a button is pressed, it means the function is not available on the current disc or at the current time.

Playable discs

Using this DVD player, you can playback on the

following discs. Some of these discs may be

incompatible.

DVD Video disc(Digital Versatile Disc)

DVD+R/RW (DVD Recordable / Re-

writable), DVD+R DL (Dual layer) of

DVD Video format or Audio/Video

formats (e.g., MP3, JPEG and DivX les).

CD-R (CD-Recordable) Audio/Video formats (e.g., MP3,

JPEG and DivX® les).

CD-RW (CD-Rewritable) Audio/Video formats (e.g., MP3, JPEG and DivX® les).

Audio CD (Compact Disc Digital Audio)

Video CD

(Formats 1.0, 1.1, 2.0)

Super Video CD

MP3-Disc

is a trademark of DVD Format/Logo Licensing

Corporation.

Because of problems and errors that can occur

during the creation of DVD and CD software and/or

the manufacture of DVD and CD discs, Toshiba

cannot assure that this DVD player will successfully play every disc bearing the DVD and CD logos. If you happen to experience any difculty playing a DVD

and/or CD disc on this DVD player, please contact

Toshiba Customer Service.

This DVD player requires discs/recordings to meet

Helpful hint: Press  to go back to previous menu item. Press SETUP to exit the menu item.

certain technical standards in order to achieve optimal playback quality. There are many different types of recordable disc formats (including CD-R containing MP3 les). Not all recordable discs will operate or produce optimal playback quality. The technical criteria set forth in this owner's manual are meant only as a guide. Use of CD-RW for MP3 les

is not recommended.

You must obtain any required permission from

content. Toshiba cannot and does not grant such permission.

Tip:

- MPEG Layer-3 audio coding technology licensed from Fraunhofer IIS and Thomson.

Supported Formats

MP3 tracks

-The le extensions have to be '.mp3 '.

-ISO format.

-Maximum 8 characters display for folder name.

-Maximum 15 characters display for le name.

-Supported sampling frequencies & corresponding bit-rates;

32kHz, 64-320 kbps

44.1kHz, 48kHz 80-320 kbps

JPEG/Pictures

-The le extensions have to be '.JPG' or '.JPEG'.

-JPEG/ISO format.

-Maximum of 5760×3840 resolution can be

supported.

-Maximum le size: 5 Mbytes.

-Maximum of 500 les and 200 folders are supported.

-When the number of les(or folders) reaches the maximum limit, the rest of the les(or folders) cannot

be displayed.

-It can only display DCF-standard still pictures or

JPEG pictures such as TIFF.

DivX

-The le extensions have to be '.DIVX

DivX

-Q-pel accurate motion compensation.

Global Motion Compensation (GMC) playback.

3.11, 4.x, 5.x and 6.0.

-DivX® Certied to play DivX® video, including

premium content.

-ABOUT DIVX VIDEO: DivX ® is a digital video format created by DivX,Inc.

This is an ofcial DivX Certied device that plays DivX video. Visit www.divx.com for more information and software tools to convert your les into DivX video.

-ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certied ® device must be registered in order to play DivX Video-on-Demand (VOD) content. To generate the registration code, locate the DivX VOD section in the device setup menu. Go to vod.divx.com with this code to complete the registration process and learn more about DivX VOD.

Tips: – Maximum 100 sessions for CD and 10 multi border for DVD are supported. – For DVD-R and DVD-RW multi border, only

nalized disc can be supported.

– For DVD+R and DVD+RW multi border, both

nalized and unnalized disc cannot be supported.

.XVID' or '.AVI'.

', '

Pro gram

Tra ck 1

Tra ck 2

Tra ck 3

Tra ck 4

Tra ck 5

Tra ck 6

Pla y

Cle ar

Cle ar Al l

Prog ram

Titl e 1

Titl e 2

Titl e 3

Titl e 4

Play

Clea r

Clea r Al l

Playback Feature

Starting disc playback

Turn on the TV and select the video input connected

to the DVD player.

Press 2ON/STANDBY to turn on the DVD player.

Press OPEN/CLOSE to open the disc tray.

Place a disc onto the disc tray with the label facing

up, then press OPEN/CLOSE.

For double-sided discs, load the side which you

 

want to play facing up.

Playback may start automatically. If not, press PLAY/

PAUSE .

If a disc menu appears on the TV, see page 14,



'Using the disc menu'.

If the parental control was activated for the



inserted disc, you have to enter your four-digit password, see page 21.

For more playback features, see pages 14 - 17.



Tips:

- Do not overturn the DVD player while disc loading, playing or ejecting.

- Do not close the disc tray manually if the power is switched off.



Basic playback control

If you press STOP  again, the DVD player will



cancel the resume function.

Tips:

- Screen saver will start automatically if the disc playback is stopped for about 2 minutes.

- The player will automatically switch to Power Standby mode if you do not press any buttons for about 22 minutes after the disc has stopped playing.

Program playback

During playback, press PROG, then the OSD will

appear as below:

For VCD:

For DVD:

Unless otherwise stated, all operations described are

based on Remote Control use.

Pausing playback

During playback, press PLAY/PAUSE to pause

playback and display a still picture.

Sound will be muted.

 

To resume normal playback, press PLAY/PAUSE

location where you stopped playback.

again.

Skipping chapter/track

Press PREV / NEXT to go to the previous



or next chapter/track during playback.

When PREV is pressed after the 5 seconds of



playback, playback will start from the beginning of the current chapter/track. If you press the button within the 5 seconds, playback will start from the beginning

of the preceding chapter/track.

Press DISPLAY to display the disc information for



title/chapter/track.

Use Number buttons to enter valid chapter / track



number directly. For the track/chapter numbers which

are greater than ＂9＂, use ＂+10＂ button. Each press increases the number by 10. Then press the second digit of track/Chapter number.

The playback skips to the selected chapter / track.



Tip:

- For VCD 2.0 / SVCD discs, accessing tracks using number buttons is not possible if the PBC mode is turned on.

Stopping playback

During playback, press STOP .

Helpful hint: Some discs cannot be played on this DVD player due to the conguration and characteristics of the disc, or due to the condition of recording and authorizing software.

The DVD player memorises the stopped point.



Press PLAY/ PAUSE to resume playback from the

Use the / and OK button to select your desired

title/chapter/track in the list.

When you have nished programming, press  to

move the cursor to the 'Play', then press the OK

button or directly press PLAY/PAUSE button to start the program playback.

Press CLEAR or select ' Clear ' to delete one by one

from last chosen track / title /chapter or select 'Clear All' to clear all the programmed tracks/titles/chapters.

Press STOP twice to cancel program playback.

Operations for video playback (DVD/

VCD/SVCD)

Using the disc menu

Depending on the disc, a menu may appear on the

TV screen once you load in the disc.

To select a playback feature or item

Use /// or number buttons on the remote

 

control, then press OK to start playback.

To access or remove the menu.

Press MENU on the remote control.

 

English

Playback Feature

Zooming In

English

This function allows you to enlarge the picture on the

TV screen and to pan through the enlarged picture.

During playback, press ZOOM repeatedly to display

the picture with different scales.

Use /// to pan through the enlarged picture.

 

Playback will continue.

 

Press ZOOM repeatedly to return to the original size.

Slow Motion

Press SLOW during playback to select the required

speed: 1/2, 1/4, 1/8( forward only ).

Sound will be muted.

 

To return to normal speed, press PLAY/ PAUSE .

Forward/ Reverse Searching

You can fast forward or fast reverse a disc during

playback and select a desired search speed.

For DVD,VCD, SVCD,CD, MP3

During playback, press F.R/ F.F to select the required

speed: X2, X8, X30, X100(backward or forward).

Sound will be muted (DVD/VCD/SVCD/MP3) or

intermittent (CD).

To return to normal speed, press PLAY / PAUSE .

Selecting various repeat functions

Repeat play mode

The repeat play options vary depending on the disc

type.

While playing a disc, press REPEAT repeatedly to

choose a repeat option.

For DVD

-Repeat Chapter (currently playing chapter)

-Repeat Title (currently playing title)

-Off (cancel)

For Video CD, Audio CD

-Repeat Single (currently playing track)

-Repeat All (entire disc)

-Off (cancel)

For MP3, JPEG

-Repeat Single (currently playing le)

-Repeat All (current folder)

-Off (cancel)

Tip:

-For VCD2.0/SVCD discs, repeat playback is not possible if the PBC mode is turned on.

Repeating a section within a title/track

You can repeat the playback of a specic segment

within a title or track. To do this, you must mark the start and end of the segment you want.

While playing a disc, press A - B at your chosen

starting point.

Press A - B again at your chosen end point.

The section will now repeat continuously.

 

To exit the sequence, press A - B.

Helpful hint： The operating features described here might not be possible for certain discs.

Always refer to the instructions supplied with the discs.

Viewing the disc playback Information

You can view the disc information (such as current

title/chapter/track number, total playing time or

remaining time on the disc) without interrupting the

disc playback.

During playback, press DISPLAY repeatedly on the

remote control.

The available disc information appears on the TV

 

screen with the following sequence.

DVD Video

Time

Time 00：03：33/01：24：46

Title

Title 1/1

Chapter

Chapter 2/8

Audio

Audio 1/1 D 5.1Ch Eng

Subtitle

Subtitle 1/8 Eng

Angle

Angle 1/4

VCD2.0

Time

Time 00：03：33/00：05：00

Track

Track 3/24

OR Time

Time 00：03：33/00：05：00

PBC On

(DVD)

(VCD)

Title/Chapter/Track/Time selection

Press T-SEARCH, then press / to select

{ Time }, { Title }, { Chapter } or { Track }.

For VCD

For DVD:

Use the number buttons ( 0-9 ) to input a valid

Press OK to conrm.

 

 

press ANGLE button on the remote control

 

：

PBC OFF

Track

Time

Disc Time

Title

Chapter

Time

number or time("0" cannot be input as the rst number). (This function only apply to DVD/VCD/CD/ SVCD.)

The playback skips to the selected title/chapter/

track/time.

---

--:--:--

---

--:--:--

Angle

When {Angle} information appears on the screen,

repeatedly to switch between different angles.

Playback will go to the selected angle.

(DVD)

(VCD)

(VCD PBC OFF)

(VCD PBC ON) (VCD PBC ON)

(desired time of the current track) (desired time of the disc)

(desired time of the disc)

Playback Feature

Filter

Press OK to conrm.

Press SUBTITLE on the remote control will turn on

Special DVD Features

Playing a Title

Press TITLE.

The disc title menu appears on the TV screen.

Use /// or number buttons (0-9) to select a

play option.

Press OK to conrm.

Changing the Audio Language

For DVD

Press AUDIO repeatedly to select different audio

Changing the Audio Channel For VCD

 

 Press SUBTITLE repeatedly to select different

：

languages.

：

Press AUDIO to select the available audio channels provided by the disc (Left, Right, Mix, Stereo).

Subtitles

subtitle languages.

Special VCD and SVCD Features

For VCD with Playback Control ( PBC ) feature

(version 2.0 only)

Press MENU to toggle between ' PBC On ' and '

 

PBC Off '.

If you select 'PBC On', the disc menu (if available)

will appear on the TV.

Use the number buttons ( 0-9 ) to select a play

option.

Press PREV / NEXT to go to the previous

 

or next track.

When PREV is pressed after the 5 seconds

 

of playback, playback will start from the beginning of the current track. If you press the button within the 5 seconds, playback will start from the beginning of the

preceding track.

During playback, pressing RETURN will return to

 

the menu screen (if PBC is on).

If you want to skip the index menu and playback

directly from the beginning.

Press MENU on the remote control to turn the PBC

 

off.

Playing a DivX® Disc

This DVD player supports the DivX® movie playback

that you download from your computer onto a CD-R/ RW or DVD+R/RW (see page 13 for more

information).

Load a DivX® disc.

The data disc menu appears on the TV screen.

Press / to select the folder and press OK to open

the folder.

Press / to select a le.

Helpful hint： The operating features described here might not be possible for certain discs.

Always refer to the instructions supplied with the discs.

 

or off the subtitle.

If multilingual subtitles are embedded on the

 

DivX® disc, pressing SUBTITLE will change the



subtitle language during playback.

Tips:

–Subtitle les with the following lename extensions

(.srt, .smi, .sub, .ssa, .txt, .ass) are supported but do

not appear on the le navigation menu.

–The subtitle lename(.sub) has to be saved under

the same lename as the movie(.avi) in the same

folder.

[For example, Folder A: abc.avi and abc.sub]

Playing MP3/JPEG/ Kodak picture CD

IMPORTANT! You have to turn on your TV and set to

the correct Video In channel. (See page 12, ‘ Finding your viewing channel ‘ ).

General Operation

Load a disc.

The disc reading time may exceed 30 seconds due

 

to the complexity of the directory/le conguration.

The data disc menu and ID3 (MP3) information

 

(including at least title, singer and album) appears on

the TV screen.

Press  /  to select the folder and press OK to

open the folder.

Press  /  to select a track/le.

Press OK to conrm.

Tips:

- If you highlight on a jpeg le, a preview will appear.

- During MP3 playback, the LED will display the elapsed time of the current playback.

- During JPEG playback, the LED will display the le

number.

Playback Selection

During playback, you can;

Press PREV / NEXT to select the

 

previous/next track/le in the current folder.

Press PLAY/PAUSE repeatedly to pause/

 

resume playback.

For MP3

Within the rst 5 seconds, press PREV to go

 

back to the previous track.

After the rst 5 seconds of playback, press PREV

 

to go back to the beginning of current track.

During playback, press / to access fast

 

forward or fast reverse with the required speed: X2,

X8, X30, X100.

English

Playback Feature

Filter

Play modes for DivX®/MP3/Audio CD/

English

JPEG

You are able to modify the play modes through the

toolkit which appears on the right of below picture

on the screen. Press  /  to navigate between the

windows and  /  buttons to select les/ tracks or

play mode items. Then press OK . Please refer to

below steps to playback les /tracks in the Program View list:

Select Edit Mode in the toolkit then press OK to

start edit mode.

Select a le/track or more les/tracks you want in the

original view list.

Select Add To Program in the toolkit then press

OK.

will disappear from screen. It means that

' √ '

the les/tracks you have selected already added into

the Program View list.

Select Program View in the toolkit then press OK to

open the le/track in the Program View list that you

already selected in step B.

Press PLAY / PAUSE to playback all les/tracks

in the Program View list.

The Toolkit has the following play mode items:

Filter ( Audio/Photo/Video ): Sets le lters

 

(Filter is not applicable to Audio CD.)



Repeat (Off/Single/ All):

 

Off: Resumes normal playback

Single: Repeats the current track/le. All: Repeats all les on the current folder or all

tracks on the disc.

Mode(Normal/Random)

 

This mode can also be toggled by using RANDOM

button.

Normal: Resumes normal playback Random: Playbacks track/le in random order. During MP3/CD-DA/JPEG /DivX® les playback;

- If Repeat All(or Repeat Off) and Random are selected, all the tracks will be played randomly and

endlessly.

- If Repeat Single is selected, Random cannot be



selected and vice versa.

Edit Mode: Program operation works only when

 

Edit Mode is selected. After nished storing the les/

tracks you want into the Program View list, select “Edit Mode” again and press OK to release edit

mode.

Program View: To view tracks/les in the

 

Program View list. It is disabled if the Program View

list is empty.

 Add To Program: Add les/tracks to the Program

View list. It is disabled if Edit Mode is not selected. (The maximum number of les/tracks can be added is 30.)

Browser View: To view les/tracks in the Original

 

View list.

Clear Program: Delete the les/tracks in the

 

Program View list.

Helpful hint： The operating features described here might not be possible for certain discs.

Always refer to the instructions supplied with the discs.

Select a le/track or more you want to delete in

stop mode.' track.Select Clear Program and then press OK . It is

disabled if Edit mode is not selected.



Preview ( JPEG)

During playback, press TITLE to view a page of 9



thumbnail images.

 Use  /  /  /  to select an image.

Press OK to view the selected image in full-screen

and subsequent images will be displayed one after another automatically. See page 19 for JPEG Interval

setting.

 Press PREV / NEXT to view the previous

or next thumbnail screen.



Zoom picture ( JPEG)

During playback, press ZOOM repeatedly to

 

display the picture with different scales.

Use  /  /  /  to view the zoomed picture.

 

Rotate picture (JPEG)

During playback, press  /  /  /  to rotate the

 

picture on the TV screen.

 /



rotate the picture anti-clockwise by 90º

 

：

rotate the picture clockwise by 90º

 

：

Tip:

- It may not be possible to play certain MP3/JPEG

disc due to the conguration and characteristics of

the disc or condition of the recording.

will appear besides the deleted le/

√

ip the picture vertically by 180º

：

DVD Menu Options

Aspect Ratio :

View Mode :

4:3

Auto Fit

Aspect Ratio :

View Mode :

4:3

Auto Fit

Aspect Ratio :

View Mode :

4:3

Auto Fit

Video Out

Smart Picture :

:RGB

Standard

JPEG Interval :

5 Seconds

Language

Video

Audio

Misc

Rating

TV System :PAL

OSD language :

Subtitle :

Audio

DVD Menu

English

Off

English

Language

Video

Audio

Misc

Rating

DivX Subtitle :Standard

This DVD Player setup is carried out via the TV,

enabling you to customise the DVD player to suit your

particular requirement.

Using the Language setup menu

Press SETUP on the remote control.

The system setup menu appears.

  

Press  /  to select {Language }, then press .

Press  /  to select an item, then press  to

access. Example: { OSD language }

The options for the selected item appears.



If the selection in the menu is greyed out, that



means the feature is not available or not possible to

change at the current state.

Use / to select a setting and press OK to conrm.

Example: { English }

The setting is selected and setup is completed.



To exit, press SETUP.

OSD Language

This menu contains various language options for the

language displayed on the screen.

Subtitle/Audio/DVD Menu

These menus contain various language options for Subtitle, Audio and DVD Menu which may be

recorded on the DVD.

Tips:

-Some DVD video discs may be set to display subtitles in a different language other than you selected. A prior subtitle language may be programmed on the disc.

-Some DVD video discs allow you to change subtitle selections only via the disc menu. If this is the case, press the MENU button and choose the appropriate subtitle language from the selection on the disc menu.

-Some DVD video discs may not be played in a different audio language that you selected. A prior language may be programmed on the disc.

-Some DVD discs may not include your pre-selected language . In this case, the DVD player automatically displays discs menus consistent with the disc’s initial language setting.

DivX® Subtitle

If your DivX for the supported le formats), then you may select a supported DivX® subtitle language by region.

In ‘Language’, press / to select { DivX Subtitle },

then press .

{

Albanian, Danish, Dutch, English, Finnish, French,

Gaelic, German, Italian, Kurdish (Latin), Norwegian,

Helpful hint: Press  to go back to previous menu item. Press SETUP to exit the menu item.

Standard

les include a subtitle le (see page 16

}

Portuguese, Spanish, Swedish and Turkish.

{ Central European }

Albanian, Croat, Czech, Dutch, English,

German, Hungarian, Irish, Polish, Romanian,

Slovak, Slovene and Sorbian.

{ Cyrillic } Bulgarian, Belorussian, English, Macedonian,

Moldavian, Russian, Serbian and Ukrainian.

{ Greek } English and Modern Greek only.

{ Hebrew } English and Modern Hebrew only.

Use / to select a setting and press

conrm.

OK to

Using the Video setup menu

Press SETUP on the remote control.

The system setup menu appears.

 

Press  /  to select { Video }, then press

Press  /  to select an item, then press  to

access.

Example: { TV System }

The options for the selected item appears.

 

If the selection in the menu is greyed out, that

 

means the feature is not available or not possible to

change at the current state.

Use  /  to select a setting and press OK to

conrm. Example: { PAL }

The setting is selected and setup is completed.

 

To exit, press SETUP.

Aspect Ratio

The picture shape can be adjusted to t your TV and

the format must be available on the playback disc. Otherwise, the TV display will not affect the picture

during playback.

In ' Video ', press  /  to select {Aspect Ratio },

then press .

{ 4:3 }

Select this if you have a normal TV. A 'wide-screen'

source display with black bars on the top and bottom will be displayed on the TV screen.



{ 16:9 }

Select this for wide-screen TV (frame ratio 16:9).

Use  /  to select a setting and press OK to

conrm.

View Mode

Use view mode to scale an image that ts to the TV

screen's width and height.

In ' Video ', press  /  to select { View Mode }, then

press .

{ Fill }

Fill the screen with decoded image.

English

DVD Menu Options

Brig htnes s

Cont rast

Tint

Colo r

Digital Output

Night Mode

Down Sampling

All

Language

Video

Audio

Misc

Rating

3D Effects

{ Original }

Display image as its original size.

English

{ Height Fit }



Fit the screen height with image height.

{ Width Fit }

Fit the screen width with image width.

{ Auto Fit }

Automatically display the decoded image on screen

at a suitable size.

{ Pan Scan }



Automatically display decoded image on full screen

without distortion.

Use  /  to select a setting and press OK to

conrm.

Tip:

-Depending on the type of disc, you may not be able

to view the mode as selected.

TV System

The video standard of the DVD player output can be

selected from “NTSC”, “PAL” or “Multi”.

{ NTSC }: Select if your TV system is NTSC. { PAL }: Select if your TV system is PAL. { Multi }: The DVD video player automatically

identies PAL or NTSC video system of a disc. Connect a multisystem TV (PAL/NTSC compatible) to view a picture.

A playback picture may be distorted when detected a

signal change between PAL and NTSC on the disc.

 With the disc tray opened, you can also press

number button “3” to switch between “NTSC” and “PAL”.

Video Out

The video output of the DVD player is set to “RGB”.

In ' Video ', press  /  to select { Video Out }, then

press .

{ RGB }

Select this for Scart connection.

Smart Picture

This DVD player provides four predened sets of

picture color settings.

In ' Video ', press  /  to select {Smart Picture },

then press .

{ Standard } Select this for a preset standard picture setting.

{ Vivid }



Select this to make the picture brighter.

{ Cool }



Select this to make the picture softer.

{ Personal }



Select this to personalize your picture color by

adjusting the brightness, contrast, tint and color (saturation).

Use  /  to select a setting and press OK to

conrm.

If you select { Personal }, then proceed to steps

D~G

The setup menu appears.

 

Helpful hint: Press  to go back to previous menu item. Press SETUP to exit the menu item.

Press  /  to highlight one of the following options.

Brightness

Increase the value to brighten the picture or vice

versa. Choose zero (0) for average setting.

Contrast

Increase the value to sharpen the picture or vice

versa. Choose zero (0) to balance the contrast.

Tint

Increase the value to darken the picture or vice versa.

Choose zero (0) for average setting.

Color

Increase the value to enhance the colour in your

picture or vice versa. Choose zero (0) to balance the

colour.

Press  /  to adjust the setting that best suits your

personal preference.

Repeat steps D~ E to adjust your picture preference.

Press  /  to select ＇Close＇ and press OK to

conrm.

JPEG Interval

You can continuously playback all JPEG les

automatically. Set “JPEG Interval” to “5 Seconds”, “10 Seconds” or “15 Seconds”.

In ' Video ', press  /  to select { JPEG Interval },

then press .

{ Off }



Plays back one le at a time.

{ 5 Seconds }



Plays back images in the form of a slide show at 5

seconds intervals.

{ 10 Seconds }



Plays back images in the form of a slide show at 10

seconds intervals

{ 15 Seconds }



Plays back images in the form of a slide show at 15

seconds intervals

Use  /  to select a setting and press OK to

conrm.

Using the Audio setup menu

Press SETUP on the remote control.

The system setup menu appears.

 



Press  /  to select { Audio }, then press .

Press  / to select an item, then press  to

access.

Example: { Night Mode }

The options for the selected item appears.

 

If the selection in the menu is greyed out, that

 

means the feature is not available or not possible to

change at the current state.

Use  /  to select a setting and press OK to

conrm. Example: { On }

DVD Menu Options

Parental control : 8.Adult

Set Password

Language

Video

Audio

Misc

Rating

The setting is selected and setup is completed.

 

To exit, press SETUP.

Digital Output

Select this if you connect to a multichannel decoder/

receiver.

In 'Audio', press  /  to select { Digital Output },

then press .

{ Off }

To deactivate the digital audio output. For example, if

you use the AUDIO OUT jacks to connect to a TV or

stereo system.

{ PCM }

Select this if the connected device is not capable of

decoding multichannel audio. The DVD player will convert the Dolby Digital signal to PCM (Pulse Code Modulation).

{ All }

Select this if the connected device has a built-in

multichannel decoder that supports one of the

multichannel audio format (Dolby Digital, DTS).

Use  /  to select a setting and press OK to

conrm.

Tip:

-When playing MPEG, MP3 and set Digital Output to {All}, the player will output PCM signals.

Night Mode

This mode optimizes playback of sound at low

volume. High volume outputs will be softened and low volume outputs are brought upward to an audible level.

In ＇ Audio＇, press  /  to select { Night Mode },

then press .

{ Off }

Turns off night mode feature. Select this to enjoy the

surround sound with its full dynamic range.

{ On }

Select this to set low volume output. This feature

is only available for movie discs with Dolby Digital

mode.

Use  /  to select a setting and press OK to

conrm.

Down Sampling

You can enable and disable the digital signal for

better sound output quality.

In ＇Audio＇, press  /  to select { Down

Sampling }, then press . { Off }

If your amplier / decoder is compatible with 96 KHz

PCM, select “ Off “ . Sound is sampled at 96 KHz.

{ On }

If your amplier / decoder is not compatible with 96

KHz PCM, select “ On “ . Sound recorded at 96 KHz is down sampled to 48 KHz.

Use  /  to select a setting and press OK to

conrm.

Tip:

- When playing back disc with copyright protection,

the sound will be down sampled to 48 KHz even

when you select Down Sampling off.

3D Effects

To obtain expansive virtual surround sound effects

Helpful hint: Press  to go back to previous menu item. Press SETUP to exit the menu item.

from two speakers, set 3D Effects to on. This

enhancement sounds only output from the Analogue

AUDIO OUT (L / R) jacks of the DVD player.

In 'Audio', press  /  to select { 3D Effects }, then

press .You can set to { Off } or { On }.

Use  /  to select a setting and press OK to

conrm.

Tip:

- Only effective in playback of a DVD Video disc with

Dolby Digital 5.1 bitstream.

Using the Rating setup menu

Press SETUP on the remote control.

The system setup menu appears.

Press  /  to select {Rating }, then press .

Press  /  to select an item, then press  to

access. Example: { Parental control }

The options for the selected item appears.

 

If the selection in the menu is greyed out, that

 

means the feature is not available or not possible to

change at the current state.

Use  /  to select a setting and press OK to

conrm. Example: { 8. Adult }

The setting is selected and setup is completed.

 

To exit, press SETUP.

Rating Level settings

Depending on the DVD, you may be asked to change

the parental level while playing the disc. The rating levels are from 1 to 8 and are country

dependent. You can prohibit the playing of certain

discs that are not suitable for your children, or have certain discs played with alternative scenes.

In ' Rating ', press  /  to select {Parental control },

then press .

Use the number buttons to enter the four-digit

password, then press OK.(See ‘Changing the Password’ on pages 21.)

Press OK again to list the parental level.

{ 1.Kid Safe }



Suitable for children. { 2. G }

General Audience; recommended as acceptable for

viewers of all ages.

{ 3. PG } Parental Guidance suggested.

{ 4. PG-13 }



Unsuitable for children under 13. { 5. PG-R } Parental Guidance Recommended.

{ 6. R }



Restricted; under 17 requires accompanying parent

or adult guardian.

English

DVD Menu Options

Ent er P ass word

Ent er N ew Pas swo rd

Use Default Settings

Language

Video

Audio

Misc

Rating

DivX Registration

DivX Deregistration

Use Default Settings

NoYes

{ 7. NC-17 } No one under 17 admitted.

English

{ 8. Adult }

DVD softwares of any grades (adult/general/children)

can be played back. Should be viewed only by adults due to graphic sexual material, violence or language.

Use  /  to select a rating level and press OK to

conrm.

Select { 8.Adult } to disable parental level and

 

allow all discs to play.

DVDs that are rated higher than the level you

 

selected will not play unless you enter your four-digit password.

Tips:

-This feature will not limit viewing if the disc

manufacturer did not code the disc.

-VCD, SVCD, CD have no level indication, so parental control has no effect on these type of discs. This also applies to most illegal DVDs.

-Some DVDs are not coded with a rating though the movie rating may be printed on the disc cover. The rating level feature does not prohibit play of such discs.

Changing the Password

You need to enter your four-digit password to play a

prohibited disc or if prompted for a password.

In 'Rating', press  /  to select {Set Password },

then press OK.

You will be prompted to enter your four-digit

 

password.

Use the number buttons ( 0-9 ) to enter the four-digit

password, then press OK.

When doing this for the rst time, enter the default

password ＇0000 ＇.

If you forget your old four-digit password, enter the

 

default password ＇ 0000＇.

Press OK again to enter the new four-digit password.

The new four-digit password will now take effect.

 

Press OK to conrm.

Helpful hint: Press  to go back to previous menu item. Press SETUP to exit the menu item.

Using the Misc (Miscellaneous) setup

Press SETUP on the remote control.

The system setup menu appears.

 

Press  /  to select { Misc }, then press .

Press  /  to select an item, then press OK to

access. Example: { Use Default Settings }

The options for the selected item appears.

 

If the selection in the menu is greyed out, that

 

means the feature is not available or not possible to

change at the current state.

Use  /  to select a setting and press OK to

conrm.

Example: { No }

The setting is selected and setup is completed.

 

To exit, press SETUP.

Restoring to original settings

Setting the { Use Default Settings } function will reset

all options and your personal settings to the factory

defaults, except your password and rating level.

In 'Misc', press  /  to select { Use Default

Settings }, then press OK.

The menu will appear.

 

{ Yes } Select this to reset to factory default settings. { No } Select this to close the menu.

Use  /  to select a setting and press OK to

conrm.

To exit, press SETUP.

DivX® Registration

DivX

registration code allows you to rent and

purchase movies using the DivX

the internet.

For more information, visit website: www.divx.com/vod.

In ‘Misc’, press / to select { DivX Registration },

then press OK.

The registration code will appear.



Use the registration code to rent or purchase the

movies from DivX® VOD. Registration service at www.divx.com/vod.

Follow the instructions and download the movie



from your computer onto a CD-R/RW or DVD+R/RW

for playback on this DVD player.

VOD service from

DVD Menu Options

Tips:

- All the downloaded movies from DivX can only be played back on this DVD player.

- Time search feature is available during DivX® movie playback.

DivX® Deregistration

DivX

For more information, visit website:

www.divx.com/vod. About how to obtain DivX

deregistration code is cancelled using the

DivX

VOD service from the internet.

DivX

registration code, pls see below:

The “DivX Registration” should be selectable and

the “DivX Deregistrati on” is grayed out before the

Registration

deregistration code and

DVD player is registered. You can sele ct “DivX Registration” and press OK on remote control to get the 10-character DivX VOD Registration Code and register the DVD player at http://www.divx.com/vod;

The “DivX Registration” is grayed out and the “DivX

Deregistration” is selectable when the DVD player is registered for the rst time. You can select “DivX

Deregistration” to get the 8-character deregistration code, then deregister the DVD player at

http://www.divx.com/vod;

Both “DivX Registration” and “DivX Deregistration”

are selectable when the DVD player is deregistered (not the rst time registered or not registered). You can select “DivX Registration” to get the 10-character Di vX VOD Reg ist ra tion Code or sele ct “ Di vX

Deregistration” to get the 8-character deregistration code, th en use the code to register/deregister the DVD player at http://www.divx.com/vod.

Tray Lock

Press SETUP button, then press the number button

"2006" in sequence to lock the tray.

 All functionality of the player and playback remain

the same except for the OPEN/CLOSE button.

 After the tray is locked, "Tray Lock Is On" will

appear on the screen when OPEN/CLOSE is

pressed.

 To unlock the tray, just follow the same procedure

as above.

English

Specications

English

DVD Player/Outputs/Supplied Accessories

DVD Player

Power supply 110 V - 240 V AC, 50/60 Hz

Power Consumption 12W ( standby :<1W )

Net weight 1.26 kg

External dismensions 330 X 43 X 209 mm (W/H/D)

Signal System PAL, NTSC

Laser Semiconductor laser, wavelength 657/790 nm

Frequency range DVD linear sound : 48 kHz sampling 4 Hz to 22 kHz

Signal-to-noise ratio More than 90 dB

Audio dynamic range More than 80 dB

Harmonic distortion Less than -65 dB

Wow and utter

Operating conditions Temperature : 5OC to 35OC Operation status :Horizontal

Outputs

Video output 1.0 V ( p-p ) , 75 Ω, pin jack x 1

Video output (SCART)

Audio output (SCART) 2.0 V (rms), 10K Ω, SCART socket x 1

Audio output (COAXIAL DIGITAL) 0.5 V (p-p), 75 Ω, pin jack x 1

Audio output (ANALOG) 2.0 V (rms), 10K Ω, pin jacks (L/R) x 1

Supplied Accessories

Remote control(SE-R0301)

96 kHz sampling 4 Hz to 44 kHz

Below measurable level [less than ＋ 0.001 % ( W.PEAK )]

1.0 V ( p-p ) , 75 Ω, SCART socket x 1

Batteries(AAA)

The model complies with the above specications. Designs and specications are subject to change without notice. This model may not be compatible with features and /or specications that may be added in the future.

Troubleshooting

WARNING

Under no circumstances should you try to repair the DVD player yourself, as this will invalidate the

warranty. Do not open the DVD player as there is a risk of electric shock.

If a fault occurs, rst check the points listed below before taking the DVD player for repair. If you are unable

to remedy a problem by following these guides, consult your dealer or TOSHIBA for help.

Problem Solution

No power

No picture

Distorted picture

Picture clipped

Completely distorted picture or black /white picture with DVD.

No sound / distorted sound

No audio at digital output

No sound and picture

Disc cannot be played

Picture freezes momentarily during playback

No return to start-up screen when disc is removed

The player does not respond to the Remote Control

Buttons do not work

-Check if the AC power cord is properly connected.

-Press the I/2ON/STANDBY on the front of the DVD player to turn on the power.

-Refer to your TV' s manual for correct Video In channel

selection. Change the TV channel until you see the DVD screen.

-Check if the TV is switched on.

-Sometimes a small amount of picture distortion may

appear depending on the disc being played back. This is not malfunction.

-May be caused by View Mode Setting (see page 19). Set to Original for normal viewing.

-Connect DVD Player directly to the TV.

-Make sure the disc is compatible with the DVD player.

-Ensure that the DVD Player's setting is set to match that of

the disc and your TV.

-Adjust the volume.

-Check that the speakers are connected correctly.

-Check the digital connections.

-Check if your receiver can decode MPEG-2 or DTS and if not,

please make sure the digital output is set to PCM.

-Check if the audio format of the selected audio language matches your receiver capabilities.

-Check that the cable is connected to the correct device (See Connecting to television).

-The DVD+R/RW must be nalized and in Video mode

format.

-Ensure the disc label is facing up.

-Check if the disc is defective by trying another disc.

-Wrong region code.

-Check the disc for ngerprint/scratches and clean with a soft cloth wiping from centre to edge.

-Reset the unit by switching the player off, then on again.

-Aim the Remote Control directly at the sensor on the front of

the player.

-Reduce the distance to the player.

-Replace the batteries in Remote Control.

-Re-insert the batteries with their polarities(+/- signs)as

indicated.

-To completely reset the player, unplug the AC cord from AC outlet for 5-10 seconds.

English

Troubleshooting

Problem Solution

English

Player does not respond to some operating commands during playback.

DVD Player cannot read CDs /DVDs

Menu items cannot be selected

-Operations may not be permitted by the disc. Refer to the instructions of the disc jacket.

-Use a commonly available cleaning CD/DVD to clean

the lens before sending the DVD Player for repair.

-Press STOP twice before selecting system setup

menu.

-Depending on the disc availability,some menu items

cannot be selected.

Glossary

Analogue audio:

An electrical signal that directly represents sound. In contrast, digital audio can also be an electrical signal, but is an indirect representation of sound. See also Digital audio.

Aspect ratio:

The width of a TV screen relative to it is height. Conventional TVs are 4:3 (i.e., the screen is almost square). Widescreen models are 16:9 (the screen is almost twice as wide as its height)

AUDIO OUT jacks:

Jacks on the back of the DVD System

that send audio to another system (TV, Stereo, etc.)

Bit rate:

The amount of data used to hold a

given length of music; measured in

kilobits per seconds, or kbps. Or, the

speed at which you record.Generally,

the higher the bit rate, or the higher the recording speed, the better the sound

quality. However, higher bit rates use

more space on a disc.

Chapter:

Just as a book is split up into

several chapters, a title on a DVD disc is usually divided into chapters.

Toshiba SD1010 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
