Toshiba Excite Pure, AT15 User's Guide

GMAD00356011 07/13

If you need assistance:

❖ To sh i ba ’s S up p or t W eb si te

tabletsupport.toshiba.com

For more information, see “If Something Goes Wrong” on

page 106 in this guide.

User’s Guide

5.375 x 8.375 ver 2.3

Handling the cord on this product will expose you to lead, a chemical known to the State of California to cause birth defects or other reproductive harm.

Wash hands after

handling.

For the state of California only.

Model: AT10 - A Series

Regulatory Information

Protection of Stored Data

For your important data, please make periodic back-up copies of all the data stored on the hard disk or other storage devices as a precaution against possible failures, alteration, or loss of the data.

IF YOUR DATA IS ALTERED OR LOST DUE TO ANY TROUBLE, FAIL URE OR MALFUNCTION OF THE HARD DISK D RIVE OR OTHER STORAGE DEVICES AND THE DATA CANNOT BE RECOVERED, TOSHIBA SHALL NOT BE LIABLE FOR ANY DAMAGE OR LOSS OF DATA, OR ANY OTHER DAMAGE RESULTING THEREFROM. WHEN COPYING OR TRANSFERRING YOUR DATA, PLEASE BE SURE TO CONFIRM WHETHER THE DATA HAS BEEN SUCCESSFULLY COPIED OR TRANSFERRED. TOSHIBA DISCLAIMS ANY LIABILITY FOR THE FAILURE TO COPY OR TRANSFER THE DATA CORRECTLY.

Critical Applications

The device you have purchased is not designed for any “critical applications.” “Critical applications” means life support systems, medical applications, connections to implanted medical devices, commercial transportation, nuclear facilities or systems or any other applications where product failure could lead to injury to persons or loss of life or catastrophic property damage.

ACCORDINGLY, TOSHIBA, ITS AFFILIATES AND SUPPLIERS DISCLAIM ANY AND ALL LIABILITY ARISING OUT OF THE USE OF THE DEVICE PRODUCTS IN ANY CRITICAL APPLICATIONS. IF YOU USE THE DEVICE PRODUCTS IN A CRITICAL APPLICATION, YOU, AND NOT TOSHIBA, ASSUME FULL RESPONSIBILITY FOR SUCH USE.

5.375 x 8.375 ver 2.3

Radio Frequency (RF) Energy Exposure

When the transmitter and receiver on your device is powered ON, RF energy is received and transmitted. The power level your device transmits at is controlled by your network access while in communication.

Yo u r d e v ic e i s a p p ro v e d t o t he r a di o standard by the country/region listed in the approved countries table for the module installed in your device.

FCC Notice “Declaration of Conformity Information”

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, it may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

❖ Reorient or relocate the receiving antenna. ❖ Increase the separation between the equipment and receiver. ❖ Connect the equipment to an outlet on a circuit different from

that to which the receiver is connected.

❖ Consult the dealer or an experienced radio/TV technician for

help.

Only Peripherals complying with the FCC Class B limits may be attached to this equipment. Operation with noncompliant peripherals or peripherals not recommended by Toshiba is likely to result in interference to radio and TV reception. Shielded cables must be used between the external devices and the device's ports. Changes or modifications made to this equipment not expressly approved by Toshiba or parties authorized by Toshiba could void the user's authority to operate the equipment.

NOTE

5.375 x 8.375 ver 2.3

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

❖ This device may not cause harmful interference. ❖ This device must accept any interference received, including

interference that may cause undesired operation.

Contact Toshiba’s Support Web site at tabletsupport.toshiba.com.

Wireless Interoperability

The Toshiba Wireless LAN Card products are designed to be interoperable with any wireless LAN product that is based on Direct Sequence Spread Spectrum (DSSS) radio technology, and is compliant to:

❖ The IEEE 802.11 Standard on Wireless LANs (Revision A/B/G),

as defined and approved by the Institute of Electrical and Electronics Engineers.

❖ The Wireless Fidelity (Wi-Fi

) certification as defined by the Wi-Fi Alliance. The “Wi-Fi CERTIFIED” logo is a certification mark of the Wi-Fi Alliance.

Bluetooth

and Wireless LAN devices operate within the same

radio frequency range and may interfere with one another. If you use

Bluetooth®

and Wireless LAN devices simultaneously, you may occasionally experience a less than optimal network performance or even lose your network connection.

If you should experience any such problem, immediately turn off your

Bluetooth

or Wireless LAN device.

Please contact Toshiba product support on Web site http://www.toshiba-europe.com/computers/tnt/bluetooth.htm in Europe or tabletsupport.toshiba.com in the United States for more information.

5.375 x 8.375 ver 2.3

Wireless LAN and Your Health

Wireless LAN products, like other radio devices, emit radio frequency electromagnetic energy. The level of energy emitted by Wireless LAN devices however is far much less than the electromagnetic energy emitted by wireless devices like for example mobile phones.

Because Wireless LAN products operate within the guidelines found in radio frequency safety standards and recommendations, Toshiba believes Wireless LAN is safe for use by consumers. These standards and recommendations reflect the consensus of the scientific community and result from deliberations of panels and committees of scientists who continually review and interpret the extensive research literature.

In some situations or environments, the use of Wireless LAN may be restricted by the proprietor of the building or responsible representatives of the organization. These situations may for example include:

❖ Using the Wireless LAN equipment on board airplanes, or ❖ In any other environment where the risk of interference to other

devices or services is perceived or identified as harmful.

If you are uncertain of the policy that applies on the use of wireless devices in a specific organization or environment (e.g. airports), you are encouraged to ask for authorization to use the Wireless LAN device prior to turning on the equipment.

Exposure to Radio Frequency Radiation The radiated output power of the Toshiba Wireless LAN Card is

far below the FCC radio frequency exposure limits. Nevertheless, the Toshiba Wireless LAN Card shall be used in such a manner that the potential for human contact during normal operation is minimized. The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

5.375 x 8.375 ver 2.3

Specific Absorption Rate (IEEE)

Yo u r d e vi c e i s d e s i g ne d t o be i n compliance with Radio Waves exposure regulations and does not exceed the limits for exposure to radio waves (radio frequency electromagnetic fields) in accordance with the Federal Communications Commission (FCC) and Industry Canada (IC). A substantial safety margin is set to assure the safety of all persons, regardless of health.

A unit of measurement known as the Specific Absorption rate, or SAR is utilized for the radio wave exposure guidelines. The SAR measurement for devices does not exceed 1.6W/kg.

The actual SAR values for your device, while in use, are normally well below the stated values. The operating power of your device is automatically decreased when full power is not needed for the wireless connection to increase system efficiency and to minimize interference on the network. The lower the power output of the device the lower its SAR value.

As stated by the World Health Organization, present scientific information indicates no special precautions are needed for the use of this device. To further reduce any exposure, limit your usage.

Tur n W i-F i®, Bluetooth®, and Wireless WAN Functionalities off for Cardiac Pacemakers

❖ Turn W i- Fi

Bluetooth

, and Wireless WAN functionality off when you are near a person who may have a cardiac pacemaker implant or other medical electric device. Radio waves may affect pacemaker or medical device operation, possibly resulting in serious injury. Follow the instructions of your medical device when using any Wi-Fi® or

Bluetooth

or Wireless WAN

functionally.

Regulatory Information

This device complies with the following radio frequency and safety standards.

5.375 x 8.375 ver 2.3

Canada—Industry Canada (IC)

This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conformé à la norme NMB-

003 du Canada. This device complies with RSS 210 of Industry Canada.

The installer of this radio equipment must ensure that the antenna is located or pointed such that it does not emit RF field in excess of Health Canada limits for the general population; consult Safety Code 6, obtainable from Health Canada’s Web site www.hc-sc.gc.ca/rpb. The RF device shall not be colocated with any other transmitter that has not been tested with this device.

Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of this device.

L’ ut ilis atio n de c e di sp osit if e st s ou mis aux deux conditions suivantes: (1) il ne doit pas produire de brouillage et (2) l’utilisateur du dispositif doit être prêt à accepter tout brouillage radioélectrique reçu, même s’il est susceptible de compromettre son fonctionnement.

The term “IC” before the equipment certification number only signifies that the Industry Canada technical specifications were met.

To pr e v en t r ad i o in t e r fe r e n ce t o t h e li c e n se d s er v i c e, t h is d e v ic e i s intended to be operated indoors and away from windows to provide maximum shielding. Equipment (or its transmit antenna) that is installed outdoors is subject to licensing.

Pour empecher que cet appareil cause du brouillage au service faisant l’objet d’une licence, il doit etre utilize a l’interieur et devrait etre place loin des fenetres afin de Fournier un ecram de blindage maximal. Si le matriel (ou son antenne d’emission) est installe a l’exterieur, il doit faire l’objet d’une licence.

Les dispositifs fonctionnant dans la bande 5150-5250 MHz sont réservés uniquement pour une utilisation à l’intérieur afin de réduire les risques de brouillage préjudiciable aux systèmes de satellites mobiles utilisant les mêmes canaux.

Veuillez noter que les utilisateurs d e radars de haute puissa nce sont désignés utilisateurs principaux (c.-à-d., qu’ils ont la priorité) pour les bandes 5250-5350 MHz et 5650-5850 MHz et que ces radars pourraient causer du brouillage et/ou des dommages aux dispositifs LAN-EL.

5.375 x 8.375 ver 2.3

Europe—Restrictions for use of 2.4 GHz Frequencies in European Community Countries

België/ Belgique:

For private usage outside buildings across public grounds over less than 300m no special registration with IBPT/BIPT is required. Registration to IBPT/BIPT is required for private usage outside buildings across public grounds over more than 300m. For registration and license please contact IBPT/BIPT.

Voor priv é-gebruik bui ten gebouw over publieke groud ove r afstand kleiner dan 300m geen registratie bij BIPT/IBPT nodig; voor gebruik over afstand groter dan 300m is wel registratie bij BIPT/IBPT nodig. Voor registratie of licentie kunt u contact opnemen met BIPT.

Dans le cas d’une utilisation privée, à l’extérieur d’un bâtiment, au-dessus d’un espace public, aucun enregistrement n’est nécessaire pour une distance de moins de 300m. Pour une distance supérieure à 300m un enregistrement auprès de l’IBPT est requise. Pour les enregistrements et licences, veuillez contacter l’IBPT.

Deutschland: License required for outdoor installations. Check with reseller for

procedure to follow. Anmeldung im Outdoor-Bereich notwendig, aber nicht

genehmigungspflichtig. Bitte mit Händler die Vorgehensweise abstimmen.

France: Restricted frequency band: only channels 1 to 7 (2400 MHz and

2454 MHz respectively) may be used outdoors in France. Please contact A.R.T. (http://www.art-telecom.fr) for applicable procedures to follow.

Bande de fréquence restreinte: seuls les canaux 1- 7 (2400 et 2454 MHz respectivement) doivent être utilisés endroits extérieur en France. Vous pouvez contacter l’Autorité de Régulation des Té l éc o m m un i c a ti o n s ( h t t p: / / www.art-telecom.fr) pour la procédure à suivre.

Italia: License required for indoor use. Use with outdoor installations

not allowed. È necessaria la concessione ministeriale anche per l’uso interno.

Verificare con i rivenditori la procedur a da seguire.

Nederland: License required for outdoor installations. Check with reseller for

procedure to follow. Licentie verplicht voor gebruik met buitenantennes. Neem

contact op met verkoper voor juiste procedure.

5.375 x 8.375 ver 2.3

Bluetooth® Wireless Technology

Interoperability

Bluetooth

modules are designed to be interoperable with any product

with

Bluetooth

wireless technology that is based on Frequency Hopping Spread Spectrum (FHSS) radio technology, and is compliant to:

❖

Bluetooth

Specification as defined and approved by The

Bluetooth

Special Interest Group.

❖ Logo certification with

Bluetooth

wireless technology as

defined by The

Bluetooth

Special Interest Group.

Bluetooth

modules enable wireless networks over two or more (up to a total of seven) Toshiba portable devices. Please contact To s h i b a p r o d u c t s u p p o r t o n W e b site http://www.toshibaeurope.com/computers/tnt/bluetooth.htm in Europe or tabletsupport.toshiba.com in the United States for more information.

When you use a

Bluetooth

module close to 2.4 GHz Wireless LAN

devices,

Bluetooth

transmissions might slow down or cause errors.

If you detect certain interference while you use a

Bluetooth

device, always change the frequency, move your device to the area outside of the interference range of 2.4 GHz Wireless LAN devices (40 meters/43.74 yards or more) or stop transmitting from your device. Please contact Toshiba product support on Web site http:// www.toshiba-europe.com/computers/tnt/bluetooth.htm in Europe or tabletsupport.toshiba.com in the United States for more information.

Bluetooth

and Wireless LAN devices operate within the same radio frequency range and may interfere with one another. If you use

Bluetooth

and Wireless LAN devices simultaneously, you may occasionally experience a less than optimal network performance or even lose your network connection. If you should experience any such problem, immediately turn off either one of your

Bluetooth

or Wireless LAN. Please contact Toshiba product support on Web site http://www.toshiba-europe.com/ computers/tnt/bluetooth.htm in Europe or tabletsupport.toshiba.com in the United States for more information.

5.375 x 8.375 ver 2.3

Bluetooth® Wireless Technology and Your Health

The products with

Bluetooth

wireless technology, like other radio devices, emit radio frequency electromagnetic energy. The level of energy emitted by devices with

Bluetooth

wireless technology however is much less than the electromagnetic energy emitted by wireless devices such as mobile phones.

Because products with

Bluetooth

wireless technology operate within the guidelines found in radio frequency safety standards and recommendations, Toshiba believes

Bluetooth

wireless technology is safe for use by consumers. These standards and recommendations reflect the consensus of the scientific community and result from deliberations of panels and committees of scientists who continually review and interpret the extensive research literature.

In some situations or environments, the use of

Bluetooth

wireless technology may be restricted by the proprietor of the building or responsible representatives of the organization. These situations may for example include:

❖ Using the equipment with

Bluetooth

wireless technology on

board airplanes, or

❖ In any other environment where the risk of interference to other

devices or services is perceived or identified as harmful.

Bluetooth

wireless technology prior to turning on the equipment.

Exposure to Radio Frequency Radiation The radiated output power of the

Bluetooth

module is far below the FCC radio frequency exposure limits. Nevertheless, the

Bluetooth

module shall be used in such a manner that the potential for human contact during normal operation is minimized.

5.375 x 8.375 ver 2.3

This guide is copyrighted by Toshiba America Information Systems, Inc. with all rights reserved. Under the copyright laws, this guide cannot be reproduced in any form without the prior written permission of Toshiba. No patent liability is assumed, however, with respect to the use of the information contained herein.

Export Administration Regulation

This product and/or document contains technical data that may be controlled under the U.S. Export Administration Regulations, and may be subject to the approval of the U.S. Department of Commerce prior to export. Any export, directly or indirectly, in contravention of the U.S. Export Administration Regulations is prohibited.

Notice

While Toshiba has made every effort at the time of publication to ensure the accuracy of the information provided herein, product specifications, configurations, prices, system/component/options availability are all subject to change without notice. For the most up-to-date product information about your device, or to stay current with the various product software or hardware options, visit Toshiba’s Web site at tabletsupport.toshiba.com. Toshiba assumes no liability for any damages incurred directly or indirectly from any errors or omissions contained herein. In no event shall Toshiba be liable for any incidental, consequential, special, or exemplary damages, whether based on tort, contract or otherwise, arising out of or in connection with this information or any other information contained herein or the use thereof.

5.375 x 8.375 ver 2.3

Trademarks

App Place and Excite are either trademarks or registered trademarks of To s hi b a Am e r ic a I nf o r m at i o n S y s t em s , Inc. and/or Toshiba Corporation.

Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Toshiba is under license. Other trademarks and trade names are those of their respective owners.

U.S. patents apply to this product. See http://patents.dts.com. Manufactured under license from DTS Licensing Limited. DTS, the Symbol, & DTS and the Symbol together are registered trademarks and DTS Premium Voice Pro is a trademark of DTS, Inc. ©DTS, Inc. All Rights Reserved.

Google, the Google logo, Android, Android Market, Google Maps, Google eBooks, Gmail, and YouTube are trademarks of Google, Inc.

Microsoft is a registered trademark of Microsoft Corporation in the United States and/or other countries.

Secure Digital, SD, and microSD are trademarks or registered trademarks of SD-3C, LLC in the United States, other countries or both.

Wi-Fi is a registered trademark of the Wi-Fi Alliance. All other brand and product names are trademarks or registered

trademarks of their respective companies.

Device Recycling Information

As part of a commitment to people and the future, Toshiba promotes the efficient use of resources by working to achieve our zero-waste-tolandfill goal at all our production sites. In addition to our existing waste reduction and recycling policies, Toshiba is strongly committed to reducing electronic waste. In order to ensure efficient use of resources and appropriate treatment of hazardous substances, in accordance with recycling regulations in each state, country, and territory, Toshiba wants to make it easy for customers to recycle products at the end of the life cycle. To learn more about Toshiba's sustainability commitment, visit

us.toshiba.com/green.

Licenses

This Product is licensed under the AVC, the VC-1 and the MPEG-4 Part 2 Visual patent portfolio licenses for the personal and non-commercial use of a consumer to (i) encode video in compliance with the above standards (“Video Standards”) and/or (ii) decode AVC, VC-1 and MPEG4 Part 2 Visual that was encoded by a consumer engaged in personal and non-commercial activity or was obtained from a video provider licensed to provide such video. None of the licenses extend to any other product regardless of whether such product is included with this product in a single article. No license is granted or shall be implied for any other use. Additional information may be obtained from MPEG LA, LLC. See www.mpegla.com.

5.375 x 8.375 ver 2.3

Contents

Introduction.......................................................18

This guide ............................................................ 19

Safety icons ......................................................... 19

Other icons used............................................ 20

Your device’s features and specifications ..... 20

Other documentation........................................... 20

Service options .................................................... 21

Precautions .................................................... 21

File management tips........................................... 22

Toshiba’s online resources .................................. 22

Chapter 1: Getting Started......................................23

Features and components................................... 23

Front............................................................... 24

Back............................................................... 24

Left side ......................................................... 25

Right side ....................................................... 25

Top................................................................. 26

Bottom ........................................................... 26

Connecting to a power source ............................ 26

Battery Notice ...................................................... 28

Charging the battery ............................................ 28

Contents

5.375 x 8.375 ver 2.3

Taking care of your battery.................................. 29

Safety precautions ......................................... 29

Optimizing battery life .................................... 30

Maintaining your battery ................................ 30

Disposing of your device ..................................... 31

Using the device for the first time........................ 31

Turning on the power .................................... 31

Setting up your device ................................... 32

Setting up your Wi-Fi

connection................. 33

Got Google™?............................................... 33

Make it Google™ ........................................... 34

Google™ & Location...................................... 35

Setting the date and time............................... 38

Waking the tablet ........................................... 40

Setting up Wi-Fi

and Bluetooth®

connections ............................................. 41

Registering your Toshiba device ......................... 42

Backing up your data........................................... 42

Backing up data using TOSHIBA File

Manager ................................................... 42

Backing up data using your Google™

Account.................................................... 42

Restoring your data using your Google™

Account.................................................... 43

Navigation and features....................................... 44

Home screen.................................................. 45

Touch screen navigation................................ 46

Navigating the Home screen.......................... 47

System bar..................................................... 47

Securing your tablet....................................... 50

Customizing your Home screens......................... 53

Adding an item to a Home screen ................. 53

Moving an item from the Home screen.......... 53

Removing an item from a Home screen ........ 53

Creating, naming, and removing folders........ 54

Changing the wallpaper ................................. 55

Contents

5.375 x 8.375 ver 2.3

Turning off the device .......................................... 56

Options for turning off the device .................. 56

Using Shut down mode ................................. 57

Using Sleep mode.......................................... 58

Managing your accounts ..................................... 58

Add an account.............................................. 59

Remove an account ....................................... 59

Navigation, Maps, and Local ............................... 61

Managing downloads........................................... 61

Factory data reset................................................ 62

Caring for your device.......................................... 63

Cleaning the device ....................................... 63

Chapter 2: Settings.................................................64

Customizing your device’s settings..................... 64

Apps and Settings menus.............................. 64

Wireless and networks settings ..................... 69

Sound settings............................................... 70

Display settings.............................................. 71

Location access settings ............................... 72

Security settings ............................................ 73

Apps settings ................................................. 74

Users.............................................................. 75

Accounts settings .......................................... 77

Backup & reset settings................................. 78

Storage settings............................................. 79

Language & input settings ............................. 80

Accessibility settings...................................... 81

Date & time settings....................................... 82

About tablet .................................................. 83

Chapter 3: Working with Apps ................................86

Downloading Toshiba Apps................................. 86

TOSHIBA Media Player.................................. 86

Apps..................................................................... 87

Downloading from Google Play™ Store........ 87

Preinstalled Apps on your tablet.................... 88

Uninstalling Apps on your tablet.................... 88

Contents

5.375 x 8.375 ver 2.3

Chapter 4: Exploring the Features on your Device .... 89

Using the onscreen keyboard.............................. 89

Type to enter text........................................... 90

Speak to enter text ........................................ 92

Using the built-in speakers .................................. 92

Using external speakers or headphones ............. 93

Recording sounds.......................................... 93

Using the camera................................................. 93

Using a microSD™ Card ..................................... 94

Inserting memory media ................................ 94

Removing memory media.............................. 94

Adding optional external devices......................... 95

Using an external keyboard ........................... 96

Using an external mouse ............................... 96

Using external devices................................... 96

Chapter 5: Utilities.................................................. 97

TOSHIBA Service Station .................................... 98

Check for application updates..................... 100

Downloading updates.................................. 100

Installing updates......................................... 100

Downloading and installing System

updates .................................................. 101

TOSHIBA File Manager Utility............................ 101

File browsing screen.................................... 103

Operation of files/folders.............................. 103

TOSHIBA Adaptive display................................ 105

Chapter 6: If Something Goes Wrong .................. 106

Problems when you turn on the device ............. 106

The operating system is not working................. 107

Internet problems............................................... 107

Power and the batteries..................................... 108

Display problems ............................................... 109

Sound system problems.................................... 109

Wireless networking problems........................... 110

Contents

5.375 x 8.375 ver 2.3

If you need further assistance............................ 111

Before you contact Toshiba......................... 111

Contacting Toshiba...................................... 111

Other Toshiba Internet Web sites ...................... 112

Toshiba’s worldwide offices .............................. 112

Appendix A: Power Cord/Cable Connectors........114

Glossary..........................................................115

Index ...............................................................126

Introduction

Welcome to the world of powerful, portable, multimedia. With your Toshiba tablet device, you can watch movies, listen to your favorite music, read books, play games and do much more.

The product specifications and configuration information are designed for a product Series. Your particular model may not have all the features and specifications listed or illustrated. For more detailed information about the features and specifications on your particular model, please visit Toshiba’s Web site at

tabletsupport.toshiba.com.

NOTE

Introduction

This guide

5.375 x 8.375 ver 2.3

This guide

This guide introduces the features on your device as well as some basic procedures needed to perform tasks on your tablet, which are powered by the Android™ 4.2, Jelly Bean. This product brings new features and performance enhancements to your device.

Yo u c an:

❖ Read the entire guide from beginning to end. ❖ Skim through and stop when a topic interests you. ❖ Use the table of contents and the index to find specific

information.

Safety icons

All of the Safety instructions contained in this manual must be read carefully and be fully understood before you attempt to use this device, in order to avoid potential hazards that could cause bodily injury, property damage, or damage to the device.

❖ The Safety Instructions contained in this Manual have

been categorized according to the seriousness of the potential hazards, through the use of the following signal words.

Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.

Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.

Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.

Indicates a potentially hazardous situation which, if not avoided, may result in property damage.

Provides important information.

NOTE

Introduction

Other documentation

Your device comes with the following documentation:

❖ A Legal/Safety/Regulatory document ❖ A Quick Start document ❖ A Standard Limited Warranty ❖ It may also contain guides for other programs that may

come with your system.

For accessory information, visit Toshiba’s Web site at

accessories.toshiba.com.

Introduction

Service options

5.375 x 8.375 ver 2.3

Service options

Toshiba’s standard limited warranty, extended warranty, and service upgrade terms and conditions are available at

warranty.toshiba.com.

To stay current on the most recent applications, application updates, and hardware options for your device, as well as other product information, be sure to regularly check the To sh i ba We b s it e a t tabletsupport.toshiba.com.

If you have a problem or need to contact Toshiba, see “If

Something Goes Wrong” on page 106.

Precautions

Your device is designed to provide optimum safety and ease of use, and to withstand the rigors of travel. You should observe certain precautions to further reduce the risk of personal injury or damage to the device.

Keep this device away from small children. This device is not a toy and may be hazardous to small children, for example, small detachable parts may be a choking hazard. Improper use of device could result in loud volume emitting from the device possibly causing hearing damage, and improper use and handling of batteries could result in possible injury.

Never place a heavy object on the device and be careful not to drop a heavy object onto the device. It could damage the device or cause system failure.

❖ Turn in g off the de vi ce w hi le i t is reading from or writing

to flash media may damage the flash media.

❖ Keep the device and disks away from objects that

generate strong magnetic fields, such as large stereo speakers.

❖ Scan all new files for viruses.

This precaution is especially important for files you receive via email or download from the Internet. Occasionally, even new programs you buy from a supplier may contain a virus. You need a special program to check for viruses.

Introduction

File management tips

5.375 x 8.375 ver 2.3

File management tips

❖ Back up your files to external media on a regular basis.

Label the backup copies clearly and store them in a safe place.

As you work with data it exists in the device’s memory. This memory is called “volatile memory” because it is only active while the device is turned on. When you turn off the device, all the data remaining in volatile memory is lost. To help avoid data loss, save your work to Internal Storage or network storage. Your work (data) will remain in internal storage to be called up when you need it. As long as the internal storage remains healthy, your data is relatively safe. However on occasion, hardware failures do happen. If you experience a hardware failure, your data could be lost. As an extra step to help avoid data loss, back up your data. See “Backing up your

data” on page 42 for more information.

❖ Scan all new files for viruses.

This precaution is especially important for files you receive via external media, email, or download from the Internet.

Toshiba’s on line re s ources

To sh i ba m ai n ta i ns a nu mb e r o f online sites to which you can connect. These sites provide information about Toshiba products, give help with technical questions and keep you up to date with future upgrades. For more information, see

“Contacting Toshiba” on page 111.

Chapter 1

Getting Started

This chapter provides tips for using your device effectively, summarizes how to connect components, and explains what to do the first time you use your device.

Please read and adhere to all safety information carefully and make sure you fully understand the instructions before you attempt to use your device in order to avoid potential hazards that could cause bodily injury, property damage, or damage the device.

Features and components

For further details on each of the items listed in the following section, be sure to follow the provided references to sections later in this document.

Getting Started

Features and components

Front

(Sample Illustration) Front view

❖ Camera—Allows you to take still photos (includes flash

settings) or record videos. For more information, see

“Using the camera” on page 93.

Back

(Sample Illustration) Back view

Display

Camera

Getting Started

Features and components

Left side

(Sample Illustration) Left side view

❖ Headphone/Microphone Line-In jack—Allows you

to listen to or record sounds onto your device. For more information, see “Using external speakers or

headphones” on page 93.

❖

Volume control button—Allows you to

increase/decrease the volume.

❖

Micro HDMI® port—Allows connection to an

HDMI

-compatible television or external display device.

❖

microSD™ slot—Supports the use of Micro Secure

Digital™ (SD™) media. For more information, see “Using

a microSD™ Card” on page 94.

❖

Micro USB port—Allows the transfer of data.

❖

Speaker—Allows you to listen to sounds on your

device. For more information, see “Using the built-in

speakers” on page 92.

Right side

(Sample Illustration) Right side view

❖ Speaker—Allows you to listen to sounds on your

device. For more information, see “Using the built-in

speakers” on page 92.

Headphone/Microphone

Micro HDMI® port

Volum e contr ol butt on microS D™ slot

Speaker

Micro USB port

Speaker

Getting Started

Connecting to a power source

Top

(Sample Illustration) Top view

❖ Internal microphones—Allows you to record sounds

using the computer’s internal microphone or an optional external microphone. You can listen to audio files using the built-in speakers, headphones, or external speakers.

❖

Power button—Turns the device on and off. Press and

hold the button for several seconds to turn the device ON/OFF. Press the button quickly to wake the device from Sleep mode or to place it into Sleep mode. For more information, see “Options for turning off the

device” on page 56.

Bottom

(Sample Illustration) Bottom view

Connecting to a power source

Your device requires power to operate. Use the USB Power cable and USB/AC adaptor to connect the device to a live electrical outlet, or to charge the device’s battery.

Always confirm that the power plug (and extension cable plug if used) has been fully inserted into the socket, to ensure a secure electrical connection. Failure to do so may result in a fire or electric shock, possibly resulting in serious injury.

Be careful if you use a multiple connector. An overload on one socket could cause a fire or electric shock, possibly resulting in serious injury.

Internal microphone

Power Button

Internal microphone

Getting Started

Connecting to a power source

Always use the Toshiba USB/AC adaptor that was provided with your device, or use USB/AC adaptors specified by Toshiba to avoid any risk of fire or other damage to the device. Use of an incompatible USB/AC adaptor could cause fire or damage to the device possibly resulting in serious injury. Toshiba assumes no liability for any damage caused by use of an incompatible adaptor.

To c o nn e ct AC po we r t o t he de v ic e :

1 Connect the USB Power cable to the USB/AC adaptor.

(Sample Illustration) Connecting the USB Power cable to the USB/AC adaptor.

Handling the cord on this product will expose you to lead, a chemical known to the State of California to cause birth defects or other reproductive harm.

Wash hands after handling.

2 Plug the USB Power cable into the Micro USB port on

the device.

Do not force the plug into device.

3 Connect the USB/AC adaptor to a live electrical outlet.

Never attempt to connect or disconnect a power plug with wet hands. Failure to follow this instruction could result in an electric shock, possibly resulting in serious injury.

NOTE

Getting Started

Battery Notice

Actual battery life may vary depending on settings, application usage, features or tasks selected, network configuration, operating temperature and many other factors.

The battery life cited in the product specifications is only achieved on the select models and configurations tested by To sh i ba un d er th e s p ec i fi c te s t s et t in g s a t t he ti m e o f publication and is not an estimate of a system’s battery life under any conditions other than the specific test settings.

Recharge time varies depending on usage. The battery may not charge while the device is consuming full power. After a period of time, the battery will lose its ability to perform at maximum capacity and will need to be replaced. This is normal for all batteries.

Charging the battery

If the device is leaking or its case is cracked, put on protective gloves to handle it.

Yo ur dev ic e co nta in s a re c ha rg ea b le bat te r y t hat m a y n ee d to be charged prior to use.

To u s e e xt e rna l p ow e r o r t o c ha rge t h e b at t er y y o u m us t attach the USB/AC adaptor. See “Connecting to a power

source” on page 26.

To c h ar ge t h e de vi c e p lu g i t i n to a p ow e r so ur c e.

Battery life and charge time may vary depending on the external conditions, or the applications and features used.

Please handle your device carefully to avoid scratching or damaging the surface.

Wall Outlet—The fastest way to charge your tablet is with

the included AC adaptor plugged into a wall outlet.

NOTE

Getting Started

Taking care of your battery

USB Charge—In “Suspend mode,” you can also charge

your tablet, although more slowly, by connecting the USB cable to the USB port on your PC. Please make sure your PC is turned ON while charging via USB. If your PC is turned OFF, depending on PC specifications, the tablet battery may discharge. We recommend that you do not use your tablet while charging via USB as auto shut down may occur if the battery charge is too low.

Taking c a re of y our batt ery

The following sections offer tips on how to take care of your battery and prolong its life.

Safety precautions

Device warning indicators

❖ Always immediately turn the power off and

disconnect the power cable/ cord plug from the plug socket and stop using the battery pack if you observe any of the following conditions:

❖ Offensive or unusual odor ❖ Excessive heat ❖ Discoloration ❖ Deformation, cracks, or leaks ❖ Smoke ❖ Other unusual event during use, such as

abnormal sound

Do not turn on the device's power again until an authorized Toshiba service provider has checked it for safety. Continued use could cause a fire or rupture possibly resulting in serious injury or device failure including but not limited to the loss of data.

Getting Started

Taking care of your battery

Optimizing battery life

Yo u c an ext en d yo ur ba t te r y’s l if e b e tw e en c h ar ge s b y turning off features you don’t need. You can also change and monitor the way apps and system resources consume battery power.

Below are some of the things you can do:

❖ To t u rn of f Wi - Fi

Bluetooth

when you are not using

them, touch the

Settings ( ) icon under Wireless &

networks. Turn Wi-Fi

and/or

Bluetooth

ON/OFF. For more information, see “Wireless and networks settings”

on page 69 and “Location access settings” on page 72.

❖ Turn do wn t he s cree n brightness and set a shorter

screen time-out. For more information, see “Display

settings” on page 71.

❖ If you do not need them, turn off automatic syncing for

Gmail™, Calendar, Contact, etc. For more information, see “Accounts settings” on page 77.

❖ If you know you will not be near a Wi-Fi

network for some time, switch to Airplane mode. For more information, see “Wireless and networks settings” on

page 69.

To c h ec k t h e b at t er y c h ar ge l ev el :

1 To uc h t he

Settings ( ) icon.

The Settings menu appears.

2 To uc h t he

About tablet ( ) icon.

The About tablet menu appears.

3 To uc h

Status.

The battery status (charging or not charging) and level (as a percentage of fully charged) are displayed.

For more details on your battery use, touch Battery.

Maintaining your battery

Fully discharging your battery periodically will allow better accuracy of the battery meter.

To fully discharge your battery, periodically disconnect the device from a power source and operate it on battery power until the battery fully discharges.

NOTE

+ 102 hidden pages
