Toshiba A210 User Manual

Download

User’s Manual

A210

computers.toshiba-europe.com

A210

Disclaimer

© 2007 by TOSHIBA Corporation. All rights reserved. Under copyright law, this manual cannot be reproduced in any form without the prior written permission of TOSHIBA. No patent liability is assumed, with respect to the use of the information contained herein.

TOSHIBA A210 Portable Personal Computer User’s Manual

First edition June 2007 Ownership and copyright of music, video computer programs, databases,

etc. are protected by the copyright laws. These copyrighted materials may be copied for private use at home only. If, beyond the limitation above, you copy (including to transform data formats) or modify these materials, transfer them or distribute them via the Internet without approval of copyright owners, you may be subject to claims for compensation for damage and/or criminal penalties due to infringements of copyrights or personal rights. Please remember to observe the copyright laws when you use this product to copy the copyrighted works or perform other actions. Please note that you may infringe the owner’s rights protected by the copyright laws if you use the screen mode switching functions (e.g. Wide mode, Wide Zoom mode, etc.) of this product to display enlarged images/ video at coffee shops or hotels for the purposes of profits or providing these to the public.

This manual has been validated and reviewed for accuracy. The instructions and descriptions it contains are accurate for the A210 Portable Personal Computers at the time of this manual’s production. However, succeeding computers and manuals are subject to change without notice. TOSHIBA assumes no liability for damages incurred directly or indirectly from errors, omissions or discrepancies between the computer and the manual.

Trademarks

IBM is a registered trademark and IBM PC, OS/2, and PS/2 are trademarks of International Business Machines Corporation.

Celeron, Intel, Intel SpeedStep, Pentium, Intel Core and Centrino are trademarks or registered trademarks of Intel Corporation.

MS-DOS, Microsoft, Windows and DirectX are registered trademarks and Windows Vista is a Trademark of Microsoft Corporation.

Centronics is a registered trademark of Centronics Data Computer Corporation.

Photo CD is a trademark of Eastman Kodak. Bluetooth is a registered trademark owned by its proprietor and used by

TOSHIBA under license. iLINK is a trademark of Sony Corporation.

ii User’s Manual

Other trademarks and registered trademarks not listed above may be used in this manual.

Macrovision License of Notice

This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights. Use of this copyright protection technology must be authorized by Macrovision, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited.

When Using Your Computer

Do not operate your portable computer for an extended period of time with the base resting directly on your body. With extended operation, heat can potentially build up in the base. Allowing sustained contact with the skin could cause discomfort or, eventually, a burn.

■ Do not attempt to service the computer yourself. Always follow

installation instructions closely.

■ Do not carry a battery in your pocket, purse, or other container where

metal objects (such as car keys) could short-circuit the battery terminals. The resulting excessive current follow can cause extremely high temperatures and may result in damage from burns.

■ Be sure that nothing rests on your AC adapter’s power cable and that

the cable is not located where it can be tripped over or stepped on.

■ Place the AC adapter in a ventilated area, such as a desk top or on the

floor, when you use it to run the computer or to charge the battery. Do not cover the AC adapter with papers or other items that will reduce cooling; also, do not use the AC adapter while it is inside a carrying case.

■ Use only the AC adapter and batteries that are approved for use with

this computer. Use of another type of battery or AC adapter may risk fire or explosion.

■ If you use an extension cable with your AC adapter, ensure that the total

ampere rating of the products that are plugged into it do not exceed the ampere rating of the extension cable itself.

■ To help avoid the potential hazard of electric shock, do not connect or

disconnect any cables or perform maintenance or reconfiguration of this product during an electrical storm.

■ When setting up the computer for work, place it on a level surface.

■ Do not dispose of batteries in a fire. They may explode. Check with

local authorities for disposal instructions.

■ When travelling, do not check the computer as baggage. You can put

your computer through an X-ray security machine, but never put your computer through a metal detector. If you have the computer checked by hand, be sure to have a charged battery available in case you are asked to turn on the computer.

A210

User’s Manual iii

A210

■ When travelling with the hard drive removed from the computer, wrap

the drive in a non-conducting material, such as cloth or paper. If you have the drive checked by hand, be ready to install the drive in the computer. Your can put the hard drive through an X-ray security machine, but never put it through a metal detector.

■ When travelling, do not place the computer in overhead storage

compartments where it could slide around. Do not drop your computer or subject it to other mechanical shocks.

■ Protect your computer, battery, and hard drive from environmental

hazards such as dirt, dust, food, liquids, temperature extremes, and overexposure to sunlight.

■ When you move your computer between environments with very

different temperature and/or humidity ranges, condensation may form on or within the computer. To avoid damaging the computer, allow sufficient time for the moisture to evaporate before using the computer.

■ When you disconnect a cable, pull on its connector or on its strain relief

loop, not on the cable itself. As you pull out the connector, keep it evenly aligned to avoid bending any connector pins. Also, before you connect a cable make sure both connectors are correctly oriented and aligned.

■ Before you clean your computer, turn if off, unplug it from its power

source, and remove the battery.

■ Handle components with care. Hold a component such as a memory

module by its edges, not its pins.

When using telephone equipment in conjunction with your computer, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following:

■ Do not use this product near water, for example, near a bathtub,

washing bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

■ Avoid using a telephone (other than a cordless type) during an electrical

storm. There may be a remote risk of electric shock from lightning.

■ Do not use the telephone to report a gas leak in the vicinity of the leak.

■ Use only the power cord indicated in this manual.

■ Replace only with the same or equivalent type battery recommended by

the manufacturer.

■ Dispose of used batteries according to the manufacturer’s instructions.

■ To reduce the risk of fire, use only No. 26 AWG or larger

telecommunication line cord.

Use only the battery pack that came with the computer or an optional battery pack. Use of the wrong battery could damage your computer.

TOSHIBA assumes no liability for any damage in such case.

iv User’s Manual

EU Declaration of Conformity

This product is labelled with the CE Mark in accordance with the related European Directives, notably Electromagnetic Compatibility Directive 89/ 336/EEC for the notebook and the electronic accessories including the supplied power adapter, the Radio Equipment and Telecommunications Terminal Equipment Directive 99/5/EEC in case of implemented telecommunication accessories and the Low Voltage Directive 73/23/EEC for the supplied power adapter.

CE Marking is the responsibility of TOSHIBA EUROPE GmbH, Hammfelddamm 8, 41460 Neuss, Germany.

For a copy of the related CE Declaration of Conformity please refer to the following website: http://epps.toshiba-teg.com.

GOST

A210

Following information is only for EU-member states:

The symbol indicates that this product may not be treated as household waste. Please ensure this product is properly disposed as inappropriate waste handling of this product may cause potential hazards to the environment and human health. For more detailed information about recycling of this product, please contact your local city office, your household waste disposal service or the shop where you purchased the product.

This symbol may not stick depending on the country and region where you purchased.

User’s Manual v

A210

Optical Disc Drive Safety Instruction

Your A210 computer is equipped with one of the following drives: DVD Super Multi (+-R DL) drive, HD DVD ROM drive or HD DVD-R drive.

■ The optical disc drive employs a laser system. To ensure proper use of

this product, please read this instruction manual carefully and retain for future reference. Should the unit ever require maintenance, contact an authorized service location.

■ Use of controls, adjustments or the performance of procedures other

than those specified may result in hazardous radiation exposure.

■ To prevent direct exposure to the laser beam, do not try to open the

enclosure.

The optical drive that is used in this computer is equipped with a laser device. A classification label with the following sentence is affixed to the surface of the drive.

CLASS 1 LASER PRODUCT LASER KLASSE 1 LUOKAN 1 LASERLAITE APPAREIL A LASER DE CLASSE 1 KLASS 1 LASER APPARAT

vi User’s Manual

A210

The drive with the above label is certified by the manufacturer that the drive complies with the requirement for laser product on the date of manufacturing pursuant to article 21 of Code of Federal Regulations by the United States of America, Department of Health & Human Services, Food and Drug Administration.

In other countries, the drive is certified to comply with the requirement pursant to IEC 825 and EN60825 on class 1 laser product.

This computer is equipped with one of the optical drives in the following list:

Manufacturer Type

Pioneer DVD Super Multi (±R Double Layer)

DVR-K17

Toshiba Samsung DVD Super Multi (±R Double Layer)

TS-L632

Hitachi DVD Super Multi (±R Double Layer)

GSA-T20N

Panasonic DVD Super Multi (±R Double Layer)

UJ-850U

Teac DVD Super Multi (±R Double Layer)

DV-W28EC

Toshiba HD DVD ROM

TS-L802A

Toshiba HD DVD-R

TS-L902A

User’s Manual vii

A210

Modem warning notice

Conformity Statement

The equipment has been approved to [Commission Decision “CTR21”] for pan- European single terminal connection to the Public Switched Telephone Network (PSTN).

However, due to differences between the individual PSTNs provided in different countries/regions the approval does not, of itself, give an unconditional assurance of successful operation on every PSTN network termination point.

In the event of problems, you should contact your equipment supplier in the first instance.

Network Compatibility Statement

This product is designed to work with, and is compatible with the following networks. It has been tested to and found to confirm with the additional requirements conditional in EG 201 121.

Germany ATAAB AN005, AN006, AN007, AN009, AN010

Greece ATAAB AN005, AN006 and GR01, 02, 03, 04

and DE03, 04, 05, 08, 09, 12, 14, 17

Portugal ATAAB AN001, 005, 006, 007, 011 and P03, 04,

Spain ATAAB AN005, 007, 012, and ES01

Switzerland ATAAB AN002

Norway ATAAB AN002, 005, 007 and

All other countries/ regions

Specific switch settings or software setup are required for each network, please refer to the relevant sections of the user guide for more details.

The hookflash (timed break register recall) function is subject to separate national type approvals. It has not been tested for conformity to national type regulations, and no guarantee of successful operation of that specific function on specific national networks can be given.

viii User’s Manual

08, 10

NO 01, 02

ATAAB AN003, 004

General Precautions

TOSHIBA computers are designed to optimize safety, minimize strain and withstand the rigors of portability. However, certain precautions should be observed to further reduce the risk of personal injury or damage to the computer.

Be certain to read the general precautions below and to note the cautions included in the text of the manual.

Creating a computer-friendly environment

Place the computer on a flat surface that is large enough for the computer and any other items you are using, such as a printer.

Leave enough space around the computer and other equipment to provide adequate ventilation. Otherwise, they may overheat.

To keep your computer in prime operating condition, protect your work area from:

■ Dust, moisture, and direct sunlight.

■ Equipment that generates a strong electromagnetic field, such as

stereo speakers (other than speakers that are connected to the computer) or speakerphones.

■ Rapid changes in temperature or humidity and sources of temperature

change such as air conditioner vents or heaters.

■ Extreme heat, cold, or humidity.

■ Liquids and corrosive chemicals.

A210

Stress injury

Carefully read the Instruction Manual for Safety and Comfort. It contains information on the prevention of stress injuries to your hands and wrists that can be caused by extensive keyboard use. Chapter 3, Getting Started, also includes information on work space design, posture and lighting that can help reduce physical stress.

User’s Manual ix

A210

Heat injury

■ Avoid prolonged physical contact with the computer. If the computer is

used for long periods, its surface can become very warm. While the temperature will not feel hot to the touch, if you maintain physical contact with the computer for a long time, for example if you rest the computer on your lap or if you keep your hands on the palm rest, your skin might suffer a low-heat injury.

■ If the computer has been used for a long time, avoid direct contact with

the metal plate supporting the various interface ports as this can become hot.

■ The surface of the AC adaptor can become hot when in use but this

condition does not indicate a malfunction. If you need to transport the AC adaptor, you should disconnect it and let it cool before moving it.

■ Do not lay the AC adaptor on a material that is sensitive to heat as the

material could become damaged.

Pressure or impact damage

Do not apply heavy pressure to the computer or subject it to any form of strong impact as this can damage the computer’s components or otherwise cause it to malfunction.

Mobile phones

Please be aware that the use of mobile phones can interfere with the audio system. The operation of the computer will not be impaired in any way, but it is recommended that a minimum distance of 30cm is maintained between the computer and a mobile phone that is in use.

Instruction Manual for Safety and Comfort

All important information on the safe and proper use of this computer is described in the enclosed Instruction Manual for Safety and Comfort. Be sure to read it before using the computer.

x User’s Manual

Preface

Manual contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xvi

Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xvi

Equipment checklist. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xviii

Chapter 1 Features, Utilities and Options

Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

Special features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-10

TOSHIBA Value Added Package . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11

Utilities and Applications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-12

Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-14

Chapter 2 The Grand Tour

Front with the display closed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1

Right side . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3

Left side. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4

Back side. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6

Underside . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7

Front with the display open. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8

Keyboard Indicators. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10

Optical Disc drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-11

Chapter 3 Getting Started

Connecting the AC adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2

Opening the display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3

Turning on the power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3

Starting up for the first time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4

Turning off the power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4

Restarting the computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-8

System Recovery Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-8

Restoring the pre-installed software . . . . . . . . . . . . . . . . . . . . . . . . . 3-9

A210

User’s Manual xi

A210

Chapter 4

Operating Basics

Using the TouchPad/Dual Mode Pad . . . . . . . . . . . . . . . . . . . . . . . . . 4-1

Dual Mode Pad Button function

(Dual Mode Pad is provided with some models) . . . . . . . . . . . . . . 4-2

Using the Web Camera (depending on the model purchased) . . . . 4-3

Using the internal modem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5

LAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8

Wireless LAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-10

Using optical disc drives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-12

Writing CDs/DVDs on a DVD Super Multi drive or

HD DVD-ROM drive supporting double layer disc recording . . . . 4-17

Writing CDs/DVDs/HD DVDs on a HD DVD-R drive . . . . . . . . . . . . . 4-21

Using Ulead DVD MovieFactory® for TOSHIBA. . . . . . . . . . . . . . . . 4-24

TOSHIBA Disc Creator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-27

Media Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-28

TV-Out & HDMI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-29

Setting up more than one display. . . . . . . . . . . . . . . . . . . . . . . . . . . 4-29

Cleaning the computer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-30

Moving the computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-30

Chapter 5 The Keyboard

Typewriter keys. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1

F1 ... F12 function keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2

Soft keys: Fn key combinations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2

Hotkeys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3

Windows special keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4

Keypad overlay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4

Generating ASCII characters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6

Chapter 6 Power and Power-Up Modes

Power conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1

Power indicators. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2

Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3

Care and use of the battery pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5

Replacing the battery pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-10

TOSHIBA Password Utility. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-13

Power-up modes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-14

Panel power off/on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-14

System automatic Sleep/Hibernation . . . . . . . . . . . . . . . . . . . . . . . . 6-14

Chapter 7 HW Setup

Accessing HW Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1

HW Setup Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1

xii User’s Manual

A210

Chapter 8

Optional Devices

Express Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2

SD/SDHC/MMC/MS/MS Pro/xD Memory cards . . . . . . . . . . . . . . . . . . 8-3

Memory expansion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-5

Additional battery pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-8

Additional AC adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-8

External monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-9

Television . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-9

HDMI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-11

i.LINK (IEEE1394a) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-14

Security lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-15

Chapter 9 Troubleshooting

Problem solving process. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-1

Hardware and system checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-3

TOSHIBA support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-16

Chapter 10 Disclaimers

Appendix A Specifications

Appendix B Display Modes

Appendix C AC Power Cord and Connectors

Appendix D If your computer is stolen

Glossary

User’s Manual xiii

A210

xiv User’s Manual

Preface

Congratulations on your purchase of the A210 computer. This powerful notebook computer provides excellent expansion capability, including multimedia devices, and it is designed to provide years of reliable, high-performance computing.

This manual tells how to set up and begin using your computer. It also provides detailed information on configuring your computer, basic operations and care, using optional devices and troubleshooting.

If you are a new user of computers or if you’re new to portable computing, first read over the Features, Utilities and Options and The Grand Tour chapters to familiarize yourself with the computer’s features, components and accessory devices. Then read Getting Started for step-by-step instructions on setting up your computer.

If you are an experienced computer user, please continue reading the preface to learn how this manual is organized, then become acquainted with this manual by browsing through its pages. Be sure to look over the Special features section of the Features, Utilities and Options, to learn about features that are unique to your computer.

A210

User’s Manual xv

A210

Manual contents

This manual has ten chapters, four appendixes and a glossary. Chapter 1, Features, Utilities and Options, is an overview of the computer’s

special features, utilities, and options. Chapter 2, The Grand Tour, identifies the components of the computer and

briefly explains how they function. Chapter 3, Getting Started, provides a quick overview of how to begin

operating your computer and gives tips on safety and designing your work area. Be sure to read the sections on setting up the operating system and on restoring the pre-installed software.

Chapter 4, Operating Basics, includes instructions on using the following devices: TouchPad/Dual Mode Pad, the optical disc drives, the internal modem, LAN and Wireless LAN. It also provides tips on care of the computer and discs.

Chapter 5, The Keyboard, describes special keyboard functions including the keypad overlay and hotkeys.

Chapter 6, Power and Power-Up Modes, gives details on the computer’s power resources.

Chapter 7, HW Setup, introduces you to the TOSHIBA Hardware Setup program.

Chapter 8, Optional Devices, describes the optional hardware available. Chapter 9, Troubleshooting, provides helpful information on how to perform

some diagnostic tests, and suggests courses of action if the computer doesn’t seem to be working properly.

Chapter 10, Disclaimers, provides disclaimer information related to your computer.

The Appendix A provide technical information about your computer. The Glossary defines general computer terminology and includes a list of

acronyms used in the text.

Conventions

This manual uses the following formats to describe, identify, and highlight terms and operating procedures.

Abbreviations

On first appearance, and whenever necessary for clarity, abbreviations are enclosed in parentheses following their definition. For example: Read Only Memory (ROM). Acronyms are also defined in the Glossary.

Icons

Icons identify ports, dials, and other parts of your computer. The indicator panel also uses icons to identify the components it is providing information on.

xvi User’s Manual

Keys

The keyboard keys are used in the text to describe many computer operations. A distinctive typeface identifies the key top symbols as they appear on the keyboard. For example, Enter identifies the Enter key.

Key operation

Some operations require you to simultaneously use two or more keys. We identify such operations by the key top symbols separated by a plus sign (+). For example, Ctrl + C means you must hold down Ctrl and at the same time press C. If three keys are used, hold down the first two and at the same time press the third.

DISKCOPY A: B: When procedures require an action such as

clicking an icon or entering text, the icon’s name or the text you are to type in is represented in the type face you see to the left.

Display

Names of windows or icons or text generated by the computer that appears on its display screen is presented in the type face you see to the left.

S ABC

A210

Messages

Messages are used in this manual to bring important information to your attention. Each type of message is identified as shown below.

Pay attention! A caution informs you that improper use of equipment or failure to follow instructions may cause data loss or damage your equipment.

Please read. A note is a hint or advice that helps you make best use of your equipment.

Terminology

This term is defined in this document as follows:

Start

User’s Manual xvii

The word “Start” refers to the button in Microsoft

Windows Vista™.

A210

Equipment checklist

Carefully unpack your computer. Save the box and packing materials for future use. Check to make sure you have all the following items:

Hardware

■ A210 Portable Personal Computer

■ Universal AC Adapter and Power Cord

■ Modular cable for modem (provided with some models)

Software

■ The following software is pre-installed on your hard disk:

■ Microsoft

■ DVD Video Player

■ TOSHIBA Disc Creator

■ TOSHIBA Direct Disc Writer

■ TOSHIBA ConfigFree

■ TOSHIBA Assist

■ TOSHIBA SD Memory Card Format Utility

■ TOSHIBA Acoustic Silencer

■ TOSHIBA HW Setup

■ TOSHIBA Value Added Package Utility

■ TOSHIBA Supervisor Password Utility

■ Ulead DVD MovieFactory

■ Online Manual

■ Product Recovery disc (provided with some models)

Windows Vista™

The system may not function properly if you use drivers that are not pre-installed or distributed by TOSHIBA.

SD Memory Card Format Utility and other SD functions are packaged into TOSHIBA SD Memory Utilities. When uninstalling the SD utilities, click Start -> Control Panel -> Uninstall a program, and select TOSHIBA SD Memory Utilities.

xviii User’s Manual

Documentation

■ Your computer’s documentation:

■ A210 Personal Computer User’s Manual

■ A210 Quickstart

■ Microsoft

Windows Vista™ Quick Start Guide

(provided with some models)

■ Instruction Manual for Safety & Comfort

■ Warranty Information

Backup media

■ Product Recovery DVD-ROM

If any of the items are missing or damaged, contact your dealer immediately.

A210

User’s Manual xix

A210

xx User’s Manual

Chapter 1

Features, Utilities and Options

This chapter identifies the computer’s special features, options and

accessories.

Some of the features described in this manual may not function properly if you use an operating system that was not pre-installed by TOSHIBA.

Features

Processor

AMD

Turion™ 64 X2 Mobile Technology

A210

Other processors may be introduced.

Disclaimer (CPU)

For more information on the Disclaimer regarding CPU, please refer toChapter 10, Disclaimers.

Chipset

Mobile AMD Realtek High Definition Audio Codec ALC268 TEXAS INSTRUMENTS CardReader & 1394a

Controller PCI8402 10M/100M LAN Controller RTL8101E

User’s Manual 1-1

RX690/RS690MC Chipset

A210

Memory

The graphics system in your computer may use part of the main system memory for graphics performance and therefore reduce the amount of system memory available for other computing activities. The amount of system memory allocated to support graphics may vary depending on the graphics system, applications utilized, system memory size and other factors.

Slot Two DDRII SO-DIMM memory modules can be

installed in the 2 memory slots for a maximum of 4GB of system memory.

The system memory size is depending on the model you purchased.

Video RAM Depending on the model you purchased:

Integrated Video Memory in Gfx by ATI Radeon™ X1200, up to 831MB shared with main memory.

(for more than 1GB main memory) ATI Mobility Radeon™

HD2400, 128MB VRAM

ATI Mobility Radeon™ HD2600, 256MB VRAM

BIOS

1MB Flash ROM for system BIOS Suspend to memory or hard disk drive Various Hotkey functions for system control Complete ACPI 1.0b functionality

1-2 User’s Manual

Power

A210

Battery Pack 3-cell Lithium Ion smart battery pack with

10.8V*2000mAh* 6-cell Lithium Ion smart battery pack with

10.8V*4000mAh 9-cell Lithium Ion smart battery pack with

10.8V*6000mAh Approximately 12 hours or longer charging time to

100% battery capacity with system switched on. Approximately 4 hours charge time to 100%

battery capacity with system switched off. Approximately 1.5 days discharging time in Sleep

Mode for the 9-cell battery, 1 day for the 6-cell battery and 0.5 days for 3-cell battery.

Discharge time in shutdown mode is approximately 1 month.

* The availability of this battery is dependent on

the model you purchased.

Disclaimer (Battery Life)

For more information on the Disclaimer regarding Battery Life, please refer to Chapter 10, Disclaimers.

RTC Battery The computer has an internal battery to back up

its Real Time Clock (RTC), calender and setup information. This battery will last for an average of one month with no external power source.

AC adapter The universal AC adapter provides power to the

system and recharges the batteries when they are low. It comes with a detachable power cord.

TouchPad/Dual Mode Pad

A TouchPad/Dual Mode Pad and control buttons in the palm rest enable control of the on-screen pointer.

The Dual Mode Pad is a TouchPad that provides normal touchpad features in its default mode and switches to a DualMode interface when the upper right corner of the TouchPad is tapped. Tapping the same corner again will revert to normal pointing mode.

The volume control on the right side of the TouchPad and print button may not function with some applications.

User’s Manual 1-3

A210

Display

15.4" TFT screen with a resolution of 1280 horizontal x 800 vertical pixels

Disclaimer (LCD)

For more information on the Disclaimer regarding LCD, please refer to Chapter 10, Disclaimers.

Graphics controller Mobile AMD

ATI Mobility Radeon™ HD2400, ATI Mobility Radeon™ HD2600 Graphics Controller (depending on the model purchased)

The graphics controller maximizes display performance. Refer to Display Modes section in Appendix B for more information.

ATI Radeon™ X1200,

Disclaimer (Graphics Processor Unit (“GPU”)

For more information on the Disclaimer regarding Graphic Processor Unit (“GPU”), please refer to Chapter 10, Disclaimers.

Drives

Fixed hard disk drive Depending on the model you purchased:

9.5mm 2.5" hard disk drive (60/80/100/120/160/200 GB)

12.5mm 2.5" hard disk drive (160/200/250/300 GB)

Serial ATA 2.5

1-4 User’s Manual

Disclaimer (HDD Drive Capacity)

For more information on the Disclaimer regarding HDD Drive Capacity, please refer to Chapter 10, Disclaimers.

A210

DVD Super Multi drive supporting ±R Double Layer

Some models are equipped with a full-size DVD Super Multi drive supporting ±R Double Layer module with dual layer support that lets you record data to rewritable CD/DVDs as well as run either 12cm (4.72") or 8cm (3.15") CD/DVDs without using an adapter. It reads DVD-ROMs at maximum 8x speed and CD-ROMs at maximum 24x speed. It writes CD-Rs at up to 24x speed, CD-RWs at up to 16x speed, DVD-Rs at maximum 8x speed, DVD-RWs at maximum 6x speed, DVD+RWs at maximum 8x speed, DVD+Rs at maximum 8x speed, DVD+R (double layer) at maximum 4x speed, DVD-R (dual layer) at maximum 4x speed and DVD-RAM at maximum 5x speed. This drive supports the same formats as the CD-RW/DVD-ROM drive plus the following:

■ DVD-ROM ■ DVD-Video

■ DVD-R ■ DVD-RW

■ DVD+R ■ DVD+RW

■ DVD-RAM ■ DVD+R (double layer)

■ CD-R ■ CD-RW

■ CD-DA ■ CD-Text

■ DVD-R (dual layer)

■ Photo CD (single/multi-session)

■ CD-ROM Mode1, Mode2

■ CD-ROMXA Mode2 (Form1, Form2)

■ Enhanced CD (CD-EXTRA)

User’s Manual 1-5

A210

HD DVD-ROM drive Some models are equipped with a full-size HD

DVD-ROM drive that reads HD DVD-ROMs at maximum 1x speed DVD-ROMs at maximum 8x speed and CD-ROMs at maximum 24x speed. It writes CD-Rs at up to 16x speed, CD-RWs at up to 10x speed, DVD-Rs at maximum 4x speed, DVD-RWs at maximum 6x speed, DVD+RWs at maximum 4x speed, DVD+Rs at maximum 4x speed, DVD+R (double layer) at maximum

2.4x speed, DVD-R (dual layer) at maximum 2x speed and DVD-RAM at maximum 3x speed. This drive supports the following:

■ HD DVD-ROM■ DVD-ROM

■ DVD-R ■ DVD-RW

■ DVD+R ■ DVD+RW

■ DVD-RAM ■ DVD-Video

■ CD-R ■ CD-RW

■ CD-DA ■ CD-Text

■ DVD-R (dual layer)

■ DVD+R (double layer)

■ Photo CD (single/multi-session)

■ CD-ROM Mode1, Mode2

■ CD-ROMXA Mode2 (Form1, Form2)

■ Enhanced CD (CD-EXTRA)

1-6 User’s Manual

A210

HD DVD-R drive Some models are equipped with a full-size HD

DVD-R drive that reads HD DVD-ROMs at maximum 1x speed HD DVD-Rs at maximum 1x speed DVD-ROMs at maximum 8x speed and CD-ROMs at maximum 24x speed. It writes CD-Rs at up to 16x speed, CD-RWs at up to 10x speed, DVD-Rs at maximum 4x speed, DVD-RWs at maximum 6x speed, DVD+RWs at maximum 4x speed, DVD+Rs at maximum 4x speed, DVD+R (double layer) at maximum 2.4x speed, DVD-R (dual layer) at maximum 2x speed, DVD-RAM at maximum 3x speed and HD DVD-R at maximum 1x speed. This drive supports the following:

■ HD DVD-ROM■ DVD-ROM

■ HD DVD-R ■ DVD-RW

■ DVD-R ■ DVD+RW

■ DVD+R ■ DVD-Video

■ DVD-RAM ■ CD-RW

■ CD-R ■ CD-Text

■ CD-DA

■ DVD-R (dual layer)

■ DVD+R (double layer)

■ Photo CD (single/multi-session)

■ CD-ROM Mode1, Mode2

■ CD-ROMXA Mode2 (Form1, Form2)

■ Enhanced CD (CD-EXTRA)

Slots (depending on configuration)

Multiple Digital Media Card (SD/SDHC/MMC/MS/ MS Pro/xD)

Express Card The Express Card expansion slot that can

User’s Manual 1-7

This slot lets you easily transfer data from devices, such as digital cameras and Personal Digital Assistants, that use flash-memory.

You can use a memory module in this slot.

accommodate two standard module formats; an Express Card/34 module and an Express Card/ 54 module. An Express Card module is a small add-in card technology based on the PCI Express and Universal Serial Bus (USB) interfaces.

A210

Ports (depending on configuration)

External monitor 15-pin analog VGA port supports VESA DDC2B

compatible functions.

Universal Serial Bus The computer has four Universal Serial Bus

(USB) ports that comply with the USB 2.0 standard, which enables data transfer speeds more than 40 times faster than USB 1.1 (which this computer also supports).

i.LINK (IEEE1394a) This port enables high-speed data transfer

directly from external devices such as digital video cameras.

HDMI High Definition Multimedia Interface allows the

connection of other High Definition Devices such as Televisions and DVD Players.

CIR Infrared port for devices such as a remote

control.

TV Out The 4-pin S-Video port is compatible with PAL or

NTSC TV standard, supporting Macrovision 7.02 copy protection.

Multimedia

Web Camera (depending on configuration)

Sound system The integrated Windows

Headphone jack A standard 3.5mm stereo jack is provided for the

Microphone jack A standard 3.5 mm mini microphone jack enables

Record/Send still or video images with this integrated Web Camera.

compatible sound system provides support for internal speakers as well as jacks for an external microphone and headphones.

connection of external headphones or speakers.

connection of monaural microphone input.

1-8 User’s Manual

Communications (depending on configuration)

A210

Modem An internal modem provides capability for data

LAN The computer has built-in support for Ethernet

Wireless LAN The computer has a built-in wireless LAN

Bluetooth Bluetooth is a short-range wireless technology

and fax communication. It supports the V.90 or V.92 standards depending on the region and provides a modem jack for connection to a telephone line. The speed of data and fax transfer depends on the analog telephone line conditions.

LAN (10 Mbps, 10BASE-T), Fast Ethernet LAN (100 Mbps 100BASE-TX), or Gigabit Ethernet LAN (1000 Mbps, 1000BASE-T).

mini-card that is compatible with other LAN systems that support the following: 802.11a/b/g/n wireless LAN module/ 802.11a/b/g wireless LAN module/802.11b/g wireless LAN module. It has a Frequency Channel Selection (2.4 or 5 GHz) and allows roaming over multiple channels.

used to create PANs (Personal Area Networks) among your devices, and with other nearby devices like mobile computers, mobile phones, and digital cameras.

Security

Power-on password protection Two level password architecture

Security Lock Slot

Receives an optional security lock in order to anchor the computer to a desk or other large, heavy object.

User’s Manual 1-9

A210

Special features

The following features are either unique to TOSHIBA computers or are advanced features, which make the computer more convenient to use.

TOSHIBA Value Added Package

Display Automatic Power off

Hard Disk Drive Automatic Power Off

System Automatic Sleep/Hibernation

Keypad Overlay A ten-key pad is integrated into the keyboard.

Power-on Password Two levels of password security are available,

Battery Save Mode This feature lets you save battery power. You can

Key combinations that let you quickly modify the system configuration directly from the keyboard without running a system configuration program.

This feature automatically cuts off power to the internal display when there is no input from the keyboard or pointing device for a specified time period. Power is restored when any key is pressed or when there is input from a pointing device. You can specify the time period in the Power Options.

This feature automatically cuts off power to the hard disk drive when it is not accessed for a specified time period. Power is restored when the hard disk is accessed. You can specify the time period in the Power Options.

This feature automatically places the system into either Sleep Mode or Hibernation Mode when there is no input or hardware access for a specified time period. You can specify the time period and select either System Sleep or System Hibernate in the Power Options.

Refer to the Keypad overlay section in Chapter 5,

The Keyboard, for instructions on using the

keypad overlay.

Supervisor and User, which can prevent unauthorized access to your computer.

specify the level of system power management in the Power Options.

Instant Security A specific hot key function locks the system

Panel Power Off/On This feature turns power to the computer off

1-10 User’s Manual

providing data security.

when the display panel is closed and turns it back on when the panel is opened. You can specify the setting in the Power Options.

A210

Low Battery Automatic Hibernation

Hibernation This feature lets you turn off the power without

Sleep In Sleep Mode, power to the system remains on,

■ Before entering Sleep mode, be sure to save your data.

■ Do not install or remove a memory module while the computer is in

Sleep mode. The computer or the module could be damaged.

■ Do not remove the battery pack while the computer is in Sleep mode.

Data in memory will be lost.

When battery power is exhausted to the point that computer operation cannot be continued, the system automatically enters Hibernation Mode and shuts itself down. You can specify the setting in the Power Options.

exiting from your software. The contents of main memory are saved to the hard disk. When you turn on the power again, you can continue working right where you left off. Refer to the

Turning on the power section in Chapter 3, Getting Started, for details.

but the processor and all other devices are effectively in “sleep mode”. When the computer is in Sleep Mode, the Power LED flashes amber. The computer enters Sleep Mode regardless of the Hibernate Mode setting. Refer to the Turnin g

on the power section in Chapter 3, Getting Started, for details.

TOSHIBA Value Added Package

This section describes the TOSHIBA Component features pre-installed on the computer.

TOSHIBA Power Saver

TOSHIBA Button Support

TOSHIBA PC Diagnostic Tool

User’s Manual 1-11

TOSHIBA Power Saver provides you with the features of more various power supply managements.

This utility controls the buttom operation of the computer. The starting application from the buttom can be changed.

The TOSHIBA PC Diagnostic Tool will display basic system configuration information and allow the functionality of some of the computer’s built-in hardware devices to be tested.

A210

TOSHIBA Flash Cards

When you start or resume your computer, the TOSHIBA Flash Cards may take a moment to become available and may display several times before completely activating. The hot key functions will be available once the TOSHIBA Cards are completely active.

If your system is busy and you see a “Not Responding” message, allow TOSHIBA Cards to completely activate before you continue to use the utility and hot keys.

TOSHIBA Components Common Driver

TOSHIBA Accessibility

TOSHIBA Zooming Utility

The TOSHIBA Flash Cards provide a quick way to modify selected system functions and to launch applications.

■ Hot key function

■ TOSHIBA utility launcher function

TOSHIBA Components Common Driver contains the module required for the utility which TOSHIBA offers.

The TOSHIBA Accessibility utility provides support to movement impaireed users when they need to use the TOSHIBA Hot-key functions. In use, the utility allows you to make the Fn key ‘sticky’, that is you can press it once, release it, and they press one of the “F” keys in order to access its specific function. When set, the Fn key will remain active until another key is pressed.

This utility allows you to enlarge or reduce the icon size on Windows Desktop or the zoom factor associated with specific supported applications.

Utilities and Applications

This section describes preinstalled utilities and tells how to start them. For details on operations, refer to each utility’s online manual, help files or readme.txt files.

TOSHIBA Assist TOSHIBA Assist is a graphical user interface that

DVD Video Player The DVD player is used to play DVD Video

Frame dropping, audio skipping or out of synch audio and video may occur during playback of some DVD Video titles. Make sure to connect the computer’s AC adaptor when playing a DVD Video. Power-saving features may interfere with smooth playback.

1-12 User’s Manual

provides easy access to help and services.

media through an on-screen interface and functions.

TOSHIBA ConfigFree ConfigFree is a suite of utilities to allow easy

control of communication devices and network connections. ConfigFree also allows you to find communication problems and create profiles for easy switching between location and communication networks.

To start ConfigFree, click the Start Button, point to All Programs, point to TOSHIBA, point to Networking and click ConfigFree.

TOSHIBA Disc Creator

You can create discs in several formats including audio CDs that can be played on a standard stereo CD player and data discs to store the files and folders on your hard disk drive. This software can be used on a model with a CD-RW/ DVD-ROM drive, DVD Super Multi drive, or HD DVD drive.

TOSHIBA DVD-RAM Utility

TOSHIBA DVD-RAM Utility has the function of Physical Format and Write-Protect to DVD-RAM. This utility is contained the setup module of TOSHIBA Disc Creator. You can boot TOSHIBA DVD-RAM Utility from the menu bar as follows. Start -> All Programs -> TOSHIBA -> CD&DVD Applications -> DVD-RAM Utility.

A210

TOSHIBA Hardware Setup

This program lets you customize your hardware settings according to the way you work with your computer and the peripherals you use. To access this utility, click Start, point to All Programs, point to TOSHIBA, point to Utilities and click HWSetup.

CD/DVD Drive Acoustic Silencer

This utility allows you to configure the read speed of CD drive. You can either configure Normal Mode, which operates the drive at its maximum speed for quick data access, or Quiet Mode, whcih runs at single speed for CD audio and which can lessen operational noise. It is ineffective in DVD.

Ulead DVD MovieFactory

for

You can edit digital video and make a DVD-Video and support Labelflash™ function.

TOSHIBA

The availability of Labelflash™ function depends on the model you purchased.

User’s Manual 1-13

A210

Options

Windows Mobility Center

You can add a number of options to make your computer even more powerful and convenient to use. The following options are available:

Memory Modules Two memory modules can be installed in this

Use only PC5300 compatible DDRII memory modules. See your TOSHIBA dealer for details.

Battery Pack An additional battery pack can be purchased

High capacity battery pack

AC adapter If you use your computer at more than one site

USB Floppy Disk Drive

Mobility Center is a utility for accessing several mobile PC settings quickly in one window. A default maximum of eight tiles are provided by the operating system, and the additional two titles are added to your Mobility Center.

■ Lock Computer:

This can be used to lock your computer without turning it off. This has the same function as the Lock button at the bottom of the right pane in the start menu.

■ TOSHIBA Assist:

This can be used to open TOSHIBA Assist if it is already installed in your computer.

computer.

from your TOSHIBA dealer. Use it as a spare to increase your computer operating time.

An additional battery pack can be purchased from your TOSHIBA dealer. Use it as a spare to increase your computer operating time.

frequently, it may be convenient to purchase an additional AC adapter for each site so you will not have to carry the adapter with you.

Lets you attach a floppy disk drive to your computer by means of a USB cable.

1-14 User’s Manual

The Grand Tour

This chapter identifies the various components of your computer. Become familiar with each component before you operate the computer.

Your selected model may not have all the features and specifications corresponding to all of the features shown below.

Front with the display closed

The following figure shows the computer front with its display panel in the closed position.

A210

Chapter 2

1. Front Edge Logo*

2. DC IN LED

3. Power LED

4. Battery LED

5. Hard Disk Drive LED

6. Multiple Digital Media Card Slot Access LED*

* The availability of this feature is dependent on the model you purchased.

3 425

7 10

Front of the computer with display closed

11 12 13

7. Wireless Communication Switch*

8. Wireless Communication LED*

9. Infrared Reception Window*

10. Multiple Digital Media Card Slot*

11. Microphone Jack

12. Headphone Jack

13. Volume Control

Front Edge Logo* Front Edge Logo indicates the computer series

you bought. (The availability of this function depends on the

model you purchased.)

User’s Manual 2-1

A210

DC IN LED The DC IN LED indicates the computer is

connected to the AC adapter and it is plugged into an AC power source.

Power LED In normal operating mode, the Power LED is blue

(depending on the model you purchased). If the system is in Sleep Mode the LED will flash amber, while the LED will be off when the computer is turned off or is in Hibernation Mode.

Battery LED The Battery LED indicates the battery’s current

charge/discharge status. It lights blue (depending on the model you purchased) when the battery is fully charged. It lights amber while the battery is being charged from the AC adapter. It flashes amber when the battery capacity is low.

Hard Disk Drive LED The Hard Disk Drive LED indicates that the hard

disk drive is being accessed. Every time your computer runs a program, opens a file, or performs some other function in which it must access the hard disk drive, this light will go on.

Multiple Digital Media Card Slot Access LED*

The Multiple Digital Media Card Slot Access LED lights up when the Multiple Digital Media Card is accessed.

(The availability of this function depends on the model you purchased.)

Wireless Communication Switch*

The wireless communication switch turns on the wireless networking transceiver. The Wireless Communication LED beside it indicates that wireless networking is turned on.

(The availability of this function depends on the model you purchased.)

Wireless Communication LED*

Indicates whether the Wireless devices is active or not.

(The availability of this function depends on the model you purchased.)

Infrared Reception Window*

Receives infrared signals from various peripherals.

(The availability of this function depends on the model you purchased.)

Multiple Digital Media Card Slot*

The Multiple Digital Media Card Slot allows you to use media cards from digital still cameras and various forms of portable information equipment.

(The availability of this function depends on the model you purchased.)

2-2 User’s Manual

Microphone Jack The standard 3.5 mm mini microphone jack

enables connection of a three conductive type mini-jack for a monaural microphone.

A210

Right side

Headphone Jack The headphone jack lets you connect stereo

headphones or other audio-output devices such as external speakers. Connecting headphones or other devices to this jack automatically disables the internal speakers.

Volume Contr o l Use this dial to adjust the volume of the stereo

speakers or headphones.

The following figure shows the computer’s right side.

2 3 41 5 6 7 8

1. Universal Serial Bus (USB) Ports

2. Modem Jack*

3. Optical Disc Drive

4. Optical Disc Drive LED

* The availability of this feature is dependent on the model you purchased.

5. Eject Button

6. Emergency Eject Hole

7. DC IN Jack

8. Security Lock

The right side of the computer

Univesal Serial Bus (USB) Ports

The Universal Serial Bus (USB 2.0 and 1.1 compatible) port enables USB-equipped devices such as keyboards, mice, hard drives, scanners, and printers to be connected to the computer.

Modem Jack This jack lets you use a modular cable to connect

the modem directly to a telephone line.

User’s Manual 2-3

A210

Optical Disc Drive The computer is configured with a full-size optical

disc drive module that lets you run either 12 cm (4.72") or 8 cm (3.15") discs without using an adapter. See the Drives section in this chapter for technical specifications on each drive and Chapter 4, Operating Basics, for information on using the drive and caring for discs.

Left side

Optical Disc Drive LED

This indicator lets you know when the Optical Disc Drive is being accessed.

Eject Button Opens the Optical Disc Drive.

Emergency Eject

A back-up for the Eject Button.

Hole

DC IN Jack The DC IN jack is where you plug in the AC

adapter.

Security Lock An optional security cable attaches to this port in

order to anchor your computer to a desk or other large object to deter theft.

The following figure shows the computer’s left side.

1 3 4 52 8

1. RGB Monitor Port

2. Fan Vents

3. TV Out Port*

4. LAN Jack

5. Universal Serial Bus (USB) Ports

6. Express Card Slot for Cardbus Card Slot*

7. HDMI V1.2 PORT*

8. i.LINK (IEEE1394a) Port*

* The availability of this feature is dependent on the model you purchased.

The left side of the computer

RGB Monitor Port This 15-pin port lets you connect an external

video display to the computer.

Fan Vents The fan vents help prevent the CPU from

overheating.

2-4 User’s Manual

A210

To prevent possible over heating of the CPU, never block the fan vent.

TV Out Port* Connect a 4-pin S- video cable into this

connector in order to output either an NTSC or PAL television signal.

(The availability of this function depends on the model you purchased.)

LAN Jack This jack lets you connect to a LAN. The adapter

has built-in support for Ethernet LAN (10 Mbps, 10BASE-T), Fast Ethernet LAN (100 Mbps, 100BASE-TX) and Gigabit Ethernet LAN (1000 Mbps, 1000BASE-T). Two indicators built into the jack let you see the LAN status.

Universal Serial Bus (USB) Ports

The Universal Serial Bus (USB 2.0 and 1.1 compatible) port enables USB-equipped devices such as keyboards, mice, hard drives, scanners, and printers to be connected to the computer.

Express Card Slot for Cardbus Card Slot*

This slot allows you to insert an Express Card. An Express Card module is a small, modular add-in card technology based on PCI Express and Universal Serial Bus (USB) interface. The max. transmission rate at 2.5Gbps. Both 34mn type and 54mm type are supported.

(The availability of this function depends on the model you purchased.)

HDMI V1.2 Port* Allows transfer High Definition Audio/Video

format to a compatible device. (The availability of this function depends on the

model you purchased.)

i.LINK (IEEE1394a) Port*

This port allows you to connect an external device, such as a digital video camera, for high-speed data transfer.

(The availability of this function depends on the model you purchased.)

User’s Manual 2-5

A210

Back side

The following figure shows the computer’s back side.

1. Fan Vents

The back side of the computer

Fan Vents The fan vents help prevent the CPU from

overheating.

To prevent possible overheating of the CPU, never block the fan vents.

2-6 User’s Manual

Underside

The following figure shows the underside of the computer. Make sure the display is closed before turning over your computer.

1. HDD

2. Expansion Memory Socket

3. Fan Vent

A210

4. Battery Pack Latch

5. Battery Pack

6. Battery Pack Lock

The bottom of the computer

HDD Hard Disk Drives store data, files and programs.

Expansion Memory Socket

Use this socket to install a memory module to increase your computer’s memory. Refer to the

Memory expansion section in Chapter 8, Optional Devices.

Fan Vent The fan vent helps prevent the CPU from

overheating.

To prevent possible overheating of the CPU, never block the fan vents.

Battery Pack Latch With the Battery Pack Lock in its unlocked

position, you can slide this latch in order to remove the battery pack.

Battery Pack The battery pack powers the computer when the

AC adapter is not connected. For detailed information on the battery pack, refer to Chapter 6, Power and Power-Up Modes.

User’s Manual 2-7

A210

Battery Pack Lock When you slide this into its locked position, the

Front with the display open

The following figure shows the front of the computer with the display open. To open the display, push the latch on the front of the display and lift it up. Position the display at a comfortable viewing angle.

battery pack cannot be released even if you attempt to slide the battery pack latch into its open position.

1. Display Screen

2. Left and Right Speakers

3. TouchPad/Dual Mode Pad

4. TouchPad Control Buttons

5. Power Button

6. Internet Button*

7. CD/ DVD button*

* The availability of this feature is dependent on the model you purchased.

The front with the display open

8. Play/Pause Button*

9. Stop/Eject Button*

10. Previous Button*

11. Next Button*

12. Web Camera Power LED*

13. Web Camera*

14. Microphone*

Display Screen The LCD displays high-contrast text and graphics

at a resolution up to 1280X800 pixels. Refer to

Appendix B - Display Modes for further

information. When the computer operates from the AC adapter, the display screen’s image will be somewhat brighter than when it operates on battery power - this is normal and is designed to conserve battery power.

2-8 User’s Manual

A210

To prolong the life of your display screen, use a screen saver when you’re not using the computer and it is idle.

Left and Right Speakers

TouchPad/Dual Mode Pad

The computer provides two speakers for stereo sound reproduction.

The TouchPad/Dual Mode Pad pointing device is located in the centre of the palm rest and is used to control the on-screen pointer. Refer to the

Using the TouchPad/Dual Mode Pad section in

Chapter 4, Operating Basics.

TouchPad Control Buttons

Control buttons below the TouchPad/Dual Mode Pad let you select menu items or manipulate text and graphics designated by the on-screen pointer.

Power Button Press the power button to turn the computer’s

power on and off. There is an LED inside the power button which shines either blue (depending on the model you purchased) when the system is on.

Internet Button* Press this button to launch an Internet browser.If

the computer’s power is off, you can press this button to turn on the computer’s power and launch the browser automatically in one step.

(The availability of this function depends on the model you purchased.)

CD/ DVD button* Pressing this button will launch an application

program that allows for watching CD/DVD. An application that is launched differs by a model: Windows Media Player/DVD Video Player. (The availability of this function depends on the

model you purchased.)

Play/Pause Button* Press this button to begin playing an audio CD, a

DVD movie or digital audio files. This button also acts as a Pause button.

(The availability of this function depends on the model you purchased.)

Stop* Stops playing the CD, DVD or digital audio.

(The availability of this function depends on the model you purchased.)

User’s Manual 2-9

A210

Previous Button* Skips backwards to the previous track, chapter or

digital file. Refer to Chapter 4, Operating Basics, for details.

(The availability of this function depends on the model you purchased.)

Next Button* Skips forward to the next track, chapter or digital

file. Refer to Chapter 4, Operating Basics, for details.

(The availability of this function depends on the model you purchased.)

Web Camera Power LED*

Web Camera Power LED indicates Web Camera is working or not.

(The availability of this function depends on the model you purchased.)

Web Camera* Take your picture or send your image to web

Microphone* The Microphone is used with the Web Camera to

If Random or Shuffle is selected in Windows® Media Player, selecting Next or Previous advances to a random selection.

Keyboard Indicators

Arrow Mode When the Arrow mode icon lights green, you can

contacts. (The availability of this function depends on the

model you purchased.)

talk to other Web Camera users and to record messages on windows media.

(The availability of this function depends on the model you purchased.)

CAPS LOCK

Arrow Mode Numeric Mode Caps Lock

use the keypad overlay (light gray labelled keys) as cursor keys. Refer to the Keypad overlay section in Chapter 5, The Keyboard.

2-10 User’s Manual

Numeric Mode You can use the keypad overlay (light gray

CAPS LOCK

Caps Lock The Caps Lock LED lights when you press the

Optical Disc drive

Your computer is equipped with a DVD Super Multi drive, HD DVD-ROM drive or HD DVD-R drive depending on configuration. An ATAPI interface controller is used for the operation of these optical drives. When the computer is accessing a disc, an indicator on the drive glows.

Region codes for DVD drives and media

The disc drive and its media are manufactured according to the specifications of six marketing regions. When you purchase DVD-Video, make sure it matches your drive, otherwise it will not play properly.

Code Region

1 Canada, United States

2 Japan, Europe, South Africa, Middle East

3 Southeast Asia, East Asia

A210

labelled keys) for numeric input when the Numeric mode icon lights green. Refer to the

Keypad overlay section in Chapter 5, The Keyboard.

Caps Lock key. When this light is on, pressing a letter key on the keyboard produces an uppercase (capital) letter.

4 Australia, New Zealand, Pacific Islands, Central America,

South America, Caribbean

5 Russia, Indian Subcontinent, Africa, North Korea,

Mongolia

6 China

Writable discs

This section describes the types of writable discs. Check the specifications for your drive to for the type of discs it can write. Use TOSHIBA Disc Creator to write compact discs. Refer to Chapter 4, Operating Basics.

CDs

■ CD-R discs can be written only once. The recorded data cannot be

erased or changed.

■ CD-RW discs can be recorded more than once. Use either 1x, 2x, or

4x multi-speed CD-RW discs or high-speed 4x to 10x discs. The write speed of ultra-speed CD-RW discs is a maximum of 24x speed.

User’s Manual 2-11

A210

DVDs

■ DVD-R and DVD+R discs can be written only once. The recorded data

cannot be erased or changed.

■ DVD-RW, DVD+RW and DVD-RAM discs can be recorded more than

once.

DVD Super Multi drive supporting ±R Double Layer

The full-size DVD Super Multi drive supporting ±R Double Layer module lets you record data to rewritable discs as well as run either 12cm (4.72") or 8cm (3.15") discs without using an adapter.

The read speed is slower at the centre of a disc and faster at the other edge.

DVD read 8 speed (maximum) DVD-R write 8 speed (maximum) DVD-RW write 6 speed (maximum) DVD+R write 8 speed (maximum) DVD+RW write 8 speed (maximum) DVD-RAM write 5 speed (maximum) CD read 24 speed (maximum) CD-R write 24 speed (maximum) CD-RW write 16 speed (maximum, ultra-speed media) DVD+R (DL) write 4 speed (maximum) DVD-R(DL) write 4 speed (maximum)

This drive cannot use discs that allow writing faster than 8x speed or faster (DVD-R and DVD+R with Single Layer), 6x speed or faster (DVD-RW), 8x speed or faster (DVD+RW), 5x speed (DVD-RAM) or ultra-speed or faster (CD-RW).

2-12 User’s Manual

HD DVD-ROM drive

The HD DVD-ROM supporting ±R Double Layer module lets you record data to rewritable discs as well as run either 12cm (4.72") or 8cm (3.15") discs without using an adapter.

The read speed is slower at the centre of a disc and faster at the other edge.

HD DVD read 1 speed (maximum) DVD read 8 speed (maximum) DVD-R write 4 speed (maximum) DVD-RW write 4 speed (maximum) DVD+R write 4 speed (maximum) DVD+RW write 4 speed (maximum) DVD-RAM write 3 speed (maximum) CD read 24 speed (maximum) CD-R write 16 speed (maximum) CD-RW write 10 speed (maximum, ultra-speed media) DVD+R (DL) write 2.4 speed (maximum) DVD-R(DL) write 2 speed (maximum)

This drive cannot use discs that allow writing faster than 4x speed or faster (DVD-R and DVD+R with Single Layer), 4x speed or faster (DVD-RW and DVD+RW), 3x speed (DVD-RAM) or ultra-speed or faster (CD-RW)

A210

HD DVD-R drive

The HD DVD-R supporting HD DVD-R Double Layer module lets you record data to rewritable discs as well as run either 12cm (4.72") or 8cm (3.15") discs without using an adapter.

The read speed is slower at the centre of a disc and faster at the other edge.

HD DVD read 1 speed (maximum) HD DVD-R write 1 speed (maximum) HD DVD-R (DL) write 1 speed (maximum) DVD read 8 speed (maximum) DVD-R write 4 speed (maximum) DVD-RW write 4 speed (maximum) DVD+R write 4 speed (maximum) DVD+RW write 4 speed (maximum) DVD-RAM write 3 speed (maximum) CD read 24 speed (maximum) CD-R write 16 speed (maximum) CD-RW write 10 speed (maximum, ultra-speed media) DVD+R (DL) write 2.4 speed (maximum) DVD-R(DL) write 2 speed (maximum)

User’s Manual 2-13

A210

AC adapter

The AC adapter converts AC power to DC power and reduces the voltage supplied to the computer. It can automatically adjust to any voltage from 100 to 240 volts and to a frequency of either 50 or 60 hertz, enabling you to use the computer in almost any country/region.

To recharge the battery, simply connect the AC adapter to a power source and the computer. See Chapter 6, Power and Power-Up Modes, for details.

The AC adapter (2-pin plug)

The AC adapter (3-pin plug)

Use of the wrong adapter could damage your computer. TOSHIBA assumes no liability for any damage in such case. The output rating for the computer is 19 volts DC.

Please use only the AC Adapter supplied with the computer or an AC adapter certified by TOSHIBA.

2-14 User’s Manual

Getting Started

This chapter provides basic information to get you started using your computer. It covers the following topics:

Be sure also to read Instruction Manual for Safety & Comfort. This guide, which is included with the computer, explains product liability.

■ Connecting the AC adapter

■ Opening the display

■ Turning on the power

■ Starting up for the first time

■ Turning off the power

■ Restarting the computer

■ Restoring the pre-installed software

A210

Chapter 3

All users should be sure to carefully read the section Starting up for the first time, which describes the actions to take when you turn on the power for the first time.

User’s Manual 3-1

A210

Connecting the AC adapter

Attach the AC adapter when you need to charge the battery or you want to operate from AC power. It is also the fastest way to get started, because the battery pack will need to be charged before you can operate from battery power. The AC adapter can be connected to any power source supplying from 100 to 240 volts and 50 or 60 hertz. For details on using the AC adapter to charge the battery pack, refer to Chapter 6, Power and

Power-Up Modes.

Use of the wrong adapter could damage your computer. TOSHIBA assumes no liability for any damage in such case. The output rating for the computer is 19 volts DC.

1. Connect the power cord to the AC adapter.

Connecting the power cord to the AC adapter

2. Connect the DC output plug on the AC adapter to the DC IN input port

on the back of the computer.

Connecting the adapter to the computer

3. Plug the power cord into a live wall outlet. The Battery and DC IN

indicators on the front of the computer should glow.

To disconnect AC adaptor, you can follow the reversed procedure of Connecting AC adaptor. Please hold the DC output plug portion by your fingers and then plug it out when you disconnect the DC output plug.

3-2 User’s Manual

Opening the display

The display panel can be rotated in a wide range of angles for optimal viewing.

1. Slide the display latch on the front of the computer.

2. Lift the panel up and adjust it to the best viewing angle for you.

Use reasonable care when opening and closing the display panel. Opening it vigorously or slamming it shut could damage the computer.

Turning on the power

This section describes how to turn on the power.

After you turn on the power for the first time, do not turn it off until you have set up the operating system. Refer to the section Starting up for the first

time in this chapter.

A210

Opening the display

1. If a USB floppy disk drive is connected, make sure the drive is empty - if a disk is in the drive, press the eject button to remove it.

2. Open the display panel.

3. Press the computer’s power button and then release it.

Turning on the power

User’s Manual 3-3

A210

Starting up for the first time

When you first turn on the power, the computer’s initial screen is the Windows Vista™ Startup Screen Logo. Follow the on-screen directions for each screen. During setup, you can click the Back button to return to the previous screen.

Be sure to read the Windows Operating System End User License

Agreement carefully.

Turning off the power

The power can be turned off in one of three modes, either Shutdown (Boot) Mode, Hibernation Mode or Sleep Mode.

Shut Down mode (Boot mode)

When you turn off the power in Shut Down mode no data will be saved and the computer will boot to the operating system’s main screen the next time it is turned on.

1. If you have entered data, either save it to the hard disk, drive or to other storege media.

2. Make sure all disk/disks activity has stopped before removing the CD/DVD or floppy diskette.

■ Make sure the Hard Disk Drive indicators is off. If you turn off the

power while a disk (disks) is being accessed, you can lose data or damage the disk.

■ Never turn off the power while an application is running. Doing so could

cause loss data.

■ Never turn off the power, disconnect an external storage device or

remove storage media during data read/write. Doing so can cause data loss.

3. Click Start then click the arrow button ( ) located in the power management buttons ( ) and select Shut Down from

the menu.

4. Turn off any peripheral devices connected to your computer.

Do not turn the computer or peripheral devices back on immediately - wait a short period to avoid and peripheral damage.

3-4 User’s Manual

Sleep Mode

If you do have to interrupt your work, you are able to turn off the power without exiting from your software by placing the computer into Sleep Mode. In this mode data is maintained in the computer’s main memory so that, when you turn on the power again, you can continue working right where you left off.

■ When the AC adaptor is connected, the computer will go into Sleep

Mode according to the settings in the Power Options.

■ To restore the operation from the computer from Sleep Mode, press the

power button or press any key. Please be aware that this latter action only works on the internal keyboard if the. Wake-up on Keyboard option is enabled within the HW Setup utility.

■ If the computer enters Sleep Mode while a network application is

active, the application might not be restored when the computer is next turned on and the system returns from Sleep Mode.

■ To prevent the computer from automatically entering Sleep Mode,

disable Sleep Mode within the Power Options. However, please be aware that this configuration will nullify the computer’s Energy Star compliance.

■ Before entering Sleep Mode, be sure to save your data.

■ Do not install or remove a memory module while the computer is in

Sleep Mode. The Computer or the module could be damaged.

■ Do not remove the battery pack while the computer is in Sleep Mode

(unless the computer is connected to an AC power source). Data in memory will be lost.

A210

Benefits of Sleep Mode

The Sleep Mode feature provides the following benefits:

■ Restore the previous working enviroment more rapidly than does the

Hibernation Mode feature.

■ Saves power by shutting down the system when the computer receives

no input or hardware access for the time period set by the System Sleep Mode feature.

■ Allows the use of the panel power off feature.

User’s Manual 3-5

A210

Executing Sleep Mode

You can enter also Sleep Mode by pressing Fn + F3 - please refer to Chapter 5, The Keyboard, for further details.

Youu can enter Sleep Mode in one of three ways:

1. Click Start then click the sleep button ( ) located in the power management buttons ( ), or click the arrow button ( )

and select Sleep from the menu.

2. Close the computer’s LCD display panel. Please note that this feature must be enabled - please refer to the Power Options (to access it, click

Start followed by Control Panel followed by System and Maintenance and then click the Power Options).

3. Press the power button. Please note that this feature must be enabled - please refer to the Power Options (to access it, click Start followed by Control Panel followed by System and Maintenance and then click the Power Options then select Choose what closing the lid does).

When you turn the power back on, you can continue where you left when you shutdown the computer.

■ When the computer is in Sleep Mode, the power indicator will blink

orange.

■ If you are operating the computer on battery power, you can lengthen

the overall operating time by turning it off into Hibernation Mode - Sleep Mode will consume more power while the computer is off.

Sleep Mode limitations

Sleep Mode will not function under the following conditions:

■ Power is turned back on immediately after shutting down.

■ Memory circuits are exposed to static electricity or electrical noise.

Hibernation mode

The Hibernation Mode feature saves the contents of memory to the hard disk drive when the computer is turned off so that, the next time it is turned on, the previous state is restored. Please note that the Hibernation Mode feature does not save the status of any peripheral devices connected to the computer.

■ Save your data. While entering Hibernation Mode, the computer saves

the contents of memory to the hard disk drive. However, for safety sake, it is best to save your data manually.

■ Data will be lost if you remove the battery or disconnect the AC adaptor

before the save is completed. Wait for the Hard Disk Drive indicator to go out.

■ Do not install or remove a memory module while the computer is in

Hibernation Mode. Data will be lost.

3-6 User’s Manual

A210

Benefits of Hibernation Mode

The Hibernation Mode feature provides the following benefits:

■ Saves Data to the hard disk drive when the computer automatically

shutsdown because of a low battery condition.

■ You can return to your previous working environment immediately when

you turn on the computer.

■ Saves power by shutting down the system when the computer receives

no input or hardware access for the time period set by the System Hibernate feature.

■ Allows the use of the panel power off feature.

Starting Hibernation Mode

You can also enable Hibernation Mode by pressing Fn + F4 - please refer to Chapter 5, The Keyboard, for further details.

To enter Hibernation Mode, follow the steps below.

1. Click Start.

2. Click the arrow button ( ) in the power management buttons

( ).

3. Select Hibernate from the menu.

Automatic Hibernation Mode

The computer can be configured to enter Hibernate Mode automatically when you press the power button or close the lid. In order to define these settings, you can follow the steps as described below:

1. Click Start and click the Control Panel.

2. Click System and Maintenance and click Power Options.

3. Click Choose what the Power Button do or Choose what closing

the lid does.

4. Enable the desired Hibernation Mode settings for When I press the

power button or When I close the lid.

5. Click the Save Changes button.

Data save in Hibernation Mode

When you turn off the power in Hibernation Mode, the computer takes a moment to save the current data in memory to the hard disk drive. During this time, the Hard Disk Drive indicator will glow.

After you turn off the computer, and the content of memory has been saved to the hard disk drive, turn off the power to any peripheral devices.

Do not turn the computer or devices back on immediately. Wait a moment to let all capacitors fully discharge.

User’s Manual 3-7

A210

Restarting the computer

Certain conditions require that you reset the computer, for example if:

■ You change certain computer settings.

■ An error occurs and the computer does not respond to your keyboard

commands.

If you need to restart the computer, there are three ways this can be achieved:

1. Click Start then click the arrow button ( ) in the power management buttons ( ) and select Restart from the menu.

2. Press Ctrl+Alt+Del to display the menu window, then select Restart from the Shutdown options.

3. Press the power button and hold it down for five seconds. Once the computer has turned itself off, wait between ten and fifteen seconds before turning the power on again by pressing the power button.

System Recovery Options

About 1.5GB hidden partition is allocated on the hard disk drive for the System Recovery Options.This partition stores files which can be used to repair the system in the event of a problem.

The System Recovery Options feature will be unusable if this partition is deleted.

System Recovery Options

The System Recovery Options feature is installed on the hard disk when shipped from the factory. In the event that an error occurs between the time power is turned ON and login, and the error is repairable, the Windows Recovery Enviroment will automatically repair the error.

The Window Recovery Environment can also be run manually to repair errors.

The procedure is as follows. Follow the instructions shown on the on-screen menu.

1. Turn off the computer.

2. While holding the F8 key, turn the computer again.

3. The Advanced Boot Options menu will be displayed. Use the arrow keys to select Repair Your Computer and press Enter.

4. Follow the on-screen instructions.

The Windows Vista™ Complete PC Backup feature can be used on Windows Vista™ Business Edition and Ultimate Edition.

3-8 User’s Manual

Restoring the pre-installed software

If preinstalled files are damaged, use the Product Recovery DVD-ROM to restore them. To restore the operating system and all preinstalled software, follow the steps below.

When you reinstall the Windows operating system, the hard disk will be reformatted and all data will be lost.

1. Load the Product Recovery disc in the drive and turn off the computer’s

power.

2. Switch on the computer and, when the In Touch with Tomorrow

TOSHIBA prompt appears, press the F12 key to display the Boot Menu.

3. Use the up or down cursor key to select the CD-ROM/DVD drive in the

display menu.

4. Follow the on-screen instructions.

5. If your computer came with additional software installed, this software

can not be recovered from the Product Recovery DVD-ROM. Re-install these applications (e.g. Works Suite, Games, etc.) separately from other media.

A210

User’s Manual 3-9

A210

3-10 User’s Manual

Operating Basics

This chapter gives information on basic operations including using the TouchPad/Dual Mode Pad, optical disc drives, the internal modem, LAN and wireless LAN. It also provides tips on caring for your computer and on heat dispersal.

Using the TouchPad/Dual Mode Pad

To use the TouchPad/Dual Mode Pad, simply move your finger tip across it in the direction you want the on-screen pointer to go.

A210

Chapter 4

1. TouchPad control buttons 2. TouchPad/Dual Mode Pad

TouchPad/Dual Mode Pad and control buttons

The two buttons below the TouchPad/Dual Mode Pad are used like the buttons on a standard mouse.

Press the left button to select a menu item or to manipulate text or graphics designated by the pointer. Press the right button to display a menu or other function depending on the software you are using.

User’s Manual 4-1

A210

Do not press on the TouchPad/Dual Mode Pad too hard or press a sharp object such as a ball point pen against it. The TouchPad/Dual Mode Pad could be damaged.

The TouchPad/Dual Mode Pad has similar functions to a two-button mouse with a scroll wheel. For some functions, you can tap it instead of pressing a button.

You can customize pointing device actions in Mouse Properties. Open the Control Panel, select the Mouse icon and press Enter to open the Mouse Properties window.

Click Click the left control button or tap the TouchPad/Dual

Mode Pad once.

Double-click Click the left control button twice or tap the TouchPad/Dual

Mode Pad twice.

Scroll Vertical: Move your finger up or down the right edge of the

TouchPad/Dual Mode Pad. Horizontal: Move your finger left or right along the bottom

edge of the TouchPad/Dual Mode Pad.

Dual Mode Pad Button function (Dual Mode Pad is provided with some models)

Mail Button ConfigFree Windows Photo Gallery

Switch Button

Volum e

Application Buttons

Dual Mode Pad Button

Switch button To switch between Cursor Mode and Button

Mode. When you switch to Button Mode, the pad blinks blue.

Volu me Increases or decreases the volume of speaker

and headphone.

Mail button Starts your mail box for you to receive and send

mails.

4-2 User’s Manual

A210

ConfigFree ConfigFree is a suite of utilities to allow easy

control of communication devices and network connections. It also allows you to find communication problems and create profiles for easy switching between locations and communication networks.

Windows Photo Gallery

Windows Photo Gallery gives you many tools for your digital photos and videos. You can organize, find, and view your photos and videos, as well as edit, print, and share them from within Windows Photo Gallery. It also makes it easy to transfer your photos from your camera to your computer, using a simple import process.

1 2 3

Application buttons Three application buttons have default setting.

You can assign other functions and programs to button 1 to 3.

Please refer to “Properties for synaptics Dual Mode Pad” for details.

Using the Web Camera (depending on the model purchased)

This section describes the optional Web Camera feature, which can snapshot images and record videos.

1. Wen Camera Led 2. Web Camera Lens

User’s Manual 4-3

A210

Using the software

The Web Camera software is pre-configured to start when you turn on Windows Vista; if you need to restart it go to Start -> All Programs ->

Camera Assistant Software -> Camera Assistant Software.

21 3

8 7

1. Snapshot

2. Video Recording

3. Audio Recording

4. Functions

5. Display Window

6. Camera Resolution

7. Mute

8. Effects

Snapshot Click to see a preview of the snapshot image;

you can also e-mail the image.

Video Recording Click to prepare for recording. Click again to start

recording. One more to stop recording and see preview of the video.

Audio Recording Click to start recording, click again to stop and

listen to a preview of the audio.

Functions Access additional functions: About, Player,

Effects, Properties, Settings and Help.

About Displays software manufacturer details.

Player Play video files.

Effects Choose images to be displayed on the capture

screen.

Properties Choose from the Options tab to flip, zoom, flicker

rate, night mode and backlight compensation; in the Image tab change the colour settings; in the profile tab change the lighting conditions.

4-4 User’s Manual

Settings Choose from the: Options tab to change the tool

Help Displays the help files for the software.

Using the internal modem

This section describes how to setup the modem and use it to connect to other computer systems. Refer to the computer’s online help files and the online help files for your modem software, for more information.

The internal modem does not support the voice functions described in the help files. All data and fax functions are supported.

■ In case of a lightning storm, unplug the modem cable from the

telephone jack.

■ Do not connect the modem to a digital telephone line. A digital line will

damage the modem.

A210

position; the Picture tab to select picture output options such as size, export file and saving location; the Video tab to choose output settings such as Frame Rate, Size, Compression and the file save path; the Audio tab to chnage the Audio Device, Compression, Volume and file save path.

IMPORTANT SAFETY INSTRUCTIONS

When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following:

1. Do not use this product near water, for example, near a bathtub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

2. Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a remote risk of electric shock from lightning.

3. Do not use the telephone to report a gas leak in the vicinity of the leak.

4. Use only the power cord indicated in this manual.

User’s Manual 4-5

A210

Region selection

Telecommunication regulations vary from one country/region to another, so you will need to make sure the internal modem’s settings are correct for the country/region in which it will be used.

1. Open the Modem Region Select application. It is located on the Programs menu at TOSHIBA > Networking.

Do not use the Country/Region Select function in the Modem setup utility in the Control Panel if the function is available. If you change the Country/ Region in the Control Panel, the change may not take effect.

2. The Region Selection icon appears on the Windows Task Bar.

The Region Selection icon

3. Click the icon with the primary mouse button to display a list of regions that the modem supports. A sub menu for telephony location information will also be displayed. A check will appear next to the currently selected region and telephony location.

4. Select a region from the region menu or a telephony location from the submenu.

■ When you click a region it becomes the modem’s region selection,

and the New Location for telephony will be set automatically.

■ When you select a telephony location, the corresponding region is

automatically selected and it becomes the modem’s current region setting.

Properties menu

Click the icon with the secondary mouse button to display the following menu.

The properties menu

4-6 User’s Manual

Settings

You can enable or disable the following settings:

AutoRun Mode

Region Select Utility starts automatically when you start up the operating system.

Open the Dialing Properties dialog box after selecting region.

The dialing properties dialog box will be displayed automatically after you select the region.

Location list for region selection.

A submenu appears displaying location information for telephony.

Open dialog box, if the modem and Telephony Current Location region code do not match.

A warning dialog box is displayed if current settings for region code and telephony location are incorrect.

Modem Selection

If the computer cannot recognize the internal modem, a dialog box is displayed. Select the COM port for your modem to use.

A210

Dialing Properties

Select this item to display the dialing properties.

If you are using the computer in Japan, technical regulations described in the Telecommunications Business Law require that you select Japan region mode. It is illegal to use the modem in Japan with any other selection.

User’s Manual 4-7

A210

Connecting

To connect the internal modem cable, follow the steps below.

■ In case of a lightning storm, unplug the modem cable from the

telephone jack.

■ Do not connect the modem to a digital telephone line. A digital line will

damage the modem.

1. Plug one end of the modular cable into the modem jack.

2. Plug the other end of the modular cable into a telephone jack.

Connecting the internal modem

Do not pull on the cable or move the computer while the cable is connected.

If you find that the modem speed is low or communication is interrupted when you are using the modem, please set the CPU speed to Maximum within the Power Options.

Disconnecting

To disconnect the internal modem cable, follow the steps below.

1. Pinch the lever on the connector in the telephone jack and pull out the connector.

2. Disconnect the cable from the computer in the same manner.

LAN

The computer is equipped with networking hardware that supports Ethernet LAN (10 Mbps, 10 BASE-T) and Fast Ethernet LAN (100 Mbps, 100 BASE - TX).

Do not install or remove an optional memory module while the Wake-up on LAN feature is enabled.

The Wake-up on LAN feature does not work on battery power. In Hibernate/Power off mode you should always leave the computer connected to the AC adapter if you are using this feature.

4-8 User’s Manual

Connecting the LAN cable

The computer must be configured properly before connecting to a LAN. Logging onto a LAN using the computer’s default settings could cause a malfunction in LAN operation. Check with your LAN administrator regarding set-up procedures.

If you are using Ethernet LAN (10 Mbps, 10BASE-T), you can connect using either a CAT5 or a CAT3 cable.

If you are using 100BASE-TX Fast Ethernet, you must connect using a CAT5 cable.

To connect the LAN cable, follow the steps below.

1. Turn off the power to the computer and to all external devices

connected to the computer.

2. Plug one end of the cable into the LAN jack. Press gently until you hear

the latch click into place.

Connecting the LAN cable

3. Plug the other end of the cable into a LAN hub connec tor. Check with

your LAN administrator before connecting to a hub.

A210

Disconnecting the LAN cable

To disconnect the LAN cable, follow the steps below.

1. Pinch the lever on the connector in the computer’s LAN jack and pull

out the connector.

2. Disconnect the cable from the LAN hub in the same manner.

Check with your LAN administrator before disconnecting from the hub.

User’s Manual 4-9

A210

Wireless LAN

The wireless LAN is compatible with other LAN systems that comply with the IEEE802.11a, 11b, 11g and Draft 11n wireless LAN standards.

It supports the following:

■ Automatic Transmit Rate Select mechanism in the transmit range of 54,

48, 36, 24, 18, 9, 6 Mbps for 802.11a/b/g and 802.11b/g wireless LAN module.

■ Advanced Encryption Standard (AES) data encryption, based on 256bit

encryption algorithm.

■ Frequency Channel Selection (2.4 GHz or 5 GHz)

■ Roaming over multiple channels

■ Card Power Management

■ Wired Equivalent Privacy (WEP) data encryption

11a, 11b, 11g and 11n wireless are based on IEEE 802.11a, 802.11b,

802.11g and 802.11n respectively. The IEEE 802.11n specification has not been finalized and is currently in draft release. The TOSHIBA 11a/b/g/n Wireless LAN Adapters are based on the Draft Release, Version 1.0, of the IEEE 802.11n specification. An Adapter with 11a/b, 11a/b/g or 11a/b/g/n can communicate on any of its supported formats; the actual connection will be based on the access point to which it connects.

Connection compatibility with the wireless equipment in Draft 11n mode is not guaranteed.

The Draft 11n function cannot be used with WEP/TKIP. Draft 11n mode can be used only with WPA-PSK (AES) mode or no security mode.

Network

It may not be possible to make a network connection to a specified network name using the ad hoc network function. If this occurs, the new network(*) will have to be configured for all computers connected to the same network in order to re-enable network connections.

* Please be sure to use new network name.

Security

1. TOSHIBA strongly recommends that you enable encryption function otherwise your computer could be left open to illicit access via the wireless LAN connection which may result in an intrusion that can lead to the theft or loss of stored data among other things. In addition, the owner of an Internet connection is responsible for all browsing, downloading, and uploading activities on that connection. Therefore, an unsecured wireless network connected directly to the Internet is an open invitation for outsiders to abuse your ISP account and privileges.

2. TOSHIBA is not liable for the eavesdropping on your data due to the use of the wireless LAN connection and any damage that may occur thereof.

4-10 User’s Manual

Bluetooth wireless technology

Bluetooth® wireless technology eliminates the need for cables between electronic devices such as desktop computers, printers and mobile phones.

Bluetooth wireless technology has the following features:

Worldwide operation

The Bluetooth radio transmitter and receiver operate in the 2.4 GHz band, which is license-free and compatible with radio systems in most countries in the world.

Radio links

You can easily establish links between two or more devices. The link is maintained even if the devices are not within line of sight.

Security

Two advanced security mechanisms ensure a high level of security:

■ Authentication prevents access to critical data and makes it impossible

to falsify the origin of a message.

■ Encryption prevents eavesdropping and maintains link privacy.

Bluetooth® Stack for Windows® by TOSHIBA

Detailed information regarding the use with these operating systems is listed below. Please refer also to the electronic information which is included with each software.

A210

This Bluetooth® Stack is based on Bluetooth® Version 1.1/1.2/2.0+EDR specification. TOSHIBA cannot confirm compatibility between any PC products and/or other electronic devices that use Bluetooth™ other than TOSHIBA mobile PCs.

Release Notes related to the Bluetooth® Stack for Windows by TOSHIBA

1. Fax application software:

Regarding FAX application software, there are some software that you cannot use on this Bluetooth® Stack.

2. Multi User:

On Windows Vista™, the use of Bluetooth is not supported in a multi-user environment. This means that, when you use Bluetooth, other users logged onto the same computer will not be able to use its Bluetooth functionality.

Product Support:

The latest information regarding Operating System support, Language Support or available upgrades can be found on our web site http://www.toshiba-europe.com/computers/tnt/bluetooth.htm in Europe or www.pcsupport.toshiba.com in the United States.

User’s Manual 4-11

A210

Wireless communications

* Please be sure to use new network name.

Wireless communication switch

You can enable or disable the wireless LAN function with the on/off switch. No transmissions are sent or received when the switch is off. Slide the switch forward to turn it on and backward to turn it off.

Turn the switch off in airplanes and hospitals. Check the LED, it stops glowing when the wireless communication function is off.

Wireless communication LED

The LED indicates the status of the wireless communication functions.

LED status Indication

LED off Wireless communication switch is set to off.

LED glows Wireless communication switch is on.

Using optical disc drives

The illustrations in this section might differ slightly from your drive, but operation is the same for all optical disc drives. The full-size drive provides high-performance execution of disc-based programs. You can run either 12 cm (4.72") or 8 cm (3.15") discs without an adapter. An ATAPI interface controller is used for disc drive operation. When the computer is accessing a disc, an indicator on the drive illuminates.

Use the DVD Video Player application to view DVD-Video discs.

If you have a DVD Super Multi drive or HD DVD drive, refer also to the Writing CD/DVDs on DVD Super Multi drive section or HD DVD drive section for precautions on writing to CDs.

4-12 User’s Manual

Loading optical disc media

To load a disc, follow the steps below.

1. Turn on the power.

2. a. Press the eject button to open the drawer slightly.

Eject button

Pressing the eject button

b. Pressing the eject button will not open the drawer when the

computer’s power is off. If the power is off, you can open the drawer by inserting a slender object (about 15 mm) such as a straightened paper clip into the eject hole just to the right of the eject button.

A210

Manual release with the eject hole

3. Grasp the drawer gently and pull until it is fully open.

Pulling the drawer open

User’s Manual 4-13

A210

4. Lay the disc, label side up, in the drawer.

Inserting a disc

Be careful not to touch the lens or the area around it. Doing so could cause the drive to malfunction.

5. Press gently at the center of the disc until you feel it click into place. The disc should lie below the top of the spindle, flush with its base.

6. Push the center of the drawer to close it. Press gently until it locks in place.

If the disc is not seated properly when the drawer is closed, it might be damaged. Also, the drawer might not open fully when you press the eject button.

Closing the drive drawer

4-14 User’s Manual

Removing compact discs

To remove the disc, follow the steps below.

Do not press the eject button while the computer is accessing the disc drive. Wait for the optical disc indicator to go out before you open the drawer. Also, if the disc is spinning when you open it, wait for it to stop before you remove it.

1. To pop the drawer partially open, press the eject button. Gently pull the

drawer out until it is fully opened.

■ When the drawer pops open slightly, wait a moment to make sure the

disc has stopped spinning before pulling the drawer fully open.

■ Turn off the power before you use the eject hole. If the disc is spinning

when you open the drawer, it could fly off the spindle and cause injury.

2. The disc extends slightly over the sides of the drawer so you can grasp

it. Hold it gently and lift it out.

A210

Removing a disc

3. Push the center of the drawer to close it. Press gently until it

locks into place.

User’s Manual 4-15

A210

Buttons

The Internet button and the CD/DVD button can be assigned other functions by Button Support Utility.

1. Move mouse cursor and reach the top of desktop screen. The back cards and white cards appear. Click “Button support” white card.

2. “Button Support” white card fully appears. After double click this card, the dialog for changing button function is displayed.

3. Change function of Buttons.

CD/DVD play control buttons

In addition to the power button, the following four buttons control functions relating to the playback of optical media and digital audio data:

Play/Pause Starts or pauses play

Stop Stops play

Next Advances to the next track, chapter or data

TOSHIBA Button Support

Previous Returns to the previous track, chapter or data

If Random or Shuffle is selected in Windows Media Player, selecting Next or Previous advances to a random selection.

4-16 User’s Manual

Writing CDs/DVDs on a DVD Super Multi drive or HD DVD-ROM drive supporting double layer disc recording

You can use the DVD Super Multi drive or HD DVD drive to write data to either CD-R/RW or DVD-R/-RW/+R/+RW/-RAM discs. The following applications for writing are preinstalled: TOSHIBA Disc Creator/ Direct Disc Writer. Ulead DVD MovieFactory TOSHIBA, which is a product of Ulead Systems, Inc.

Important message

Before you write or rewrite to CD-R/RW or DVD-R/-RW/+R/+RW/-RAM media, read and follow all set-up and operating instructions in this section. If you fail to do so, the DVD Super Multi drive or HD DVD drive may not function properly, and you may fail to write or rewrite, lose data or incur other damage.

Disclaimer

TOSHIBA does not bear responsibility for the following:

■ Damage to any CD-R/RW or DVD-R/-RW/+R/+RW/-RAM disc that may

be caused by writing or rewriting with this product.

■ Any change or loss of the recorded contents of CD-R/RW or

DVD-R/- RW/ +R/+RW /-RAM media that may be caused by writing or rewriting with this product, or for any business profit loss or business interruption that may be caused by the change or loss of the recorded contents.

■ Damage that may be caused by using third party equipment or

software.

Given the technological limitations of current optical disc writing drives, you may experience unexpected writing or rewriting errors due to disc quality or problems with hardware devices. Also, it is a good idea to make two or more copies of important data, in case of undesired change or loss of the recorded contents.

A210

for

Before writing or rewriting

Please observe the following points when you write or rewrite data.

■ Based on TOSHIBA’s limited compatibility testing, we suggest the

following manufacturers of CD-R/RW and DVD-R/+R/-RW/+RW/-RAM media. However, in no event does TOSHIBA guarantee the operation, quality or performance of any disc. Disc quality can affect write or rewrite success rates.

CD-R: TAIYOYUDEN CO., LTD.

MITSUBISHI KAGAKU MEDIA CO., LTD RICOH Co., Ltd. Hitachi Maxell Ltd.

User’s Manual 4-17

A210

CD-RW: MITSUBISHI KAGAKU MEDIA CO., LTD

RICOH Co., Ltd.

DVD-R: DVD Specifications for Recordable Disc for

General Version 2.0

TAIYOYUDEN CO., LTD. Matsushita Electric Industrial Co., Ltd.

DVD-RW: DVD Specifications for Re-recordable Disc for

Version 1.1 or Version 1.2

VICTOR COMPANY OF JAPAN, LIMITED MITSUBISHI KAGAKU MEDIA CO., LTD

DVD+R: MITSUBISHI KAGAKU MEDIA CO., LTD

RICOH Co., Ltd.

DVD+RW: MITSUBISHI KAGAKU MEDIA CO., LTD

RICOH Co., Ltd.

*DVD-RAM DVD Specifications for DVD-RAM Disc for

Version 2.0, Version 2.1 or Version 2.2

Matsushita Electric Industrial Co., Ltd. Hitachi Maxell Ltd. *DVD Multi drive, DVD Super Multi, and HD DVD

drive can use DVD-RAM.

DVD+R

MITSUBISHI KAGAKU MEDIA CO., LTD

(Double Layer)

DVD-R

MITSUBISHI KAGAKU MEDIA CO., LTD

(Dual Layer)

DVD-R

FUJIFILM Corporation

Labelflash™

DVD+R

FUJIFILM Corporation

Labelflash™

■ If the disc is poor in quality, dirty or damaged, writing or rewriting errors

may occur. Be careful to check the disc for dirt or damage before you use it.

■ The actual number of rewrites to CD-RW or DVD-RW/+RW/-RAM is

affected by the quality of the disc and the way it is used.

■ There are two types of DVD-R: authoring and general use discs. Do not

use authoring discs. Only general use discs can be written to by a computer drive.

■ We can support only Format 1 of DVD-R DL. Therefore you can not do

the additional writing. If your data is under DVD-R (SL) capacity, we suggest to use DVD-R (SL) media.

4-18 User’s Manual

A210

■ You can use DVD-RAM discs that can be removed from a cartridge and

DVD-RAM discs designed without a cartridge. You cannot use a disc with a 2.6 GB single-sided capacity or 5.2 GB double-sided capacity.

■ Other DVD-ROM drives for computers or other DVD players may not be

able to read DVD-R/+R/-RW/+RW/-RAM discs.

■ Data written to a CD-R/DVD-R/+R disc cannot be deleted either in

whole or in part.

■ Data deleted (erased) from a CD-RW and DVD-RW/+RW/-RAM disc

cannot be recovered. Check the content of the disc carefully before you delete it. If multiple drives that can write data to discs are connected, be careful not to delete data from the wrong drive.

■ In writing to a DVD-R/+R/-RW/+RW disc, some disc space is required

for file management, so you may not be able to write the full capacity of the disc.

■ Since the disc is based on the DVD-R/-RW standard, it will be filled with

dummy data if the written data is less than about 1 GB. Even if you write only a small amount of data, it might take time to fill in the dummy data.

■ Two types of DVD-R/+R/-RW/+RW/-RAM discs are on the market: data

and video. Use a video disc to store video data. You can use video discs on a DVD recorder as well as on your computer’s DVD-ROM drive. You cannot use data discs on a DVD recorder.

■ DVD-RAM formatted by FAT32 cannot be read in Windows 2000

without DVD-RAM Driver Software.

■ When multiple drives that can write data to discs are connected, be

careful not to write to the wrong drive.

■ Be sure to connect the universal AC adapter before you write or rewrite.

■ Before you enter Sleep/Hibernation Mode, be sure to finish DVD-RAM

writing. Writing is finished if you can eject DVD-RAM media.

■ Be sure to close all other software programs except the writing

software.

■ Do not run software such as a screen saver, which can put a heavy load

on the CPU.

■ Operate the computer at full power. Do not use power-saving features.

■ Do not write while virus check software is running. Wait for it to finish,

then disable virus detection programs including any software that checks files automatically in the background.

■ Do not use hard disk utilities, including those intended to enhance hard

disk access speed, as they may cause unstable operation and damage data.

■ Write from the computer’s hard disk drive to the CD. Do not try to write

from shared devices such as a LAN server or any other network device.

■ Writing with software other than TOSHIBA Disc Creator or Ulead DVD

MovieFactory® for TOSHIBA has not been confirmed. Therefore, operation with other software cannot be guaranteed.

User’s Manual 4-19

A210

When writing or rewriting

Please observe/consider the following when you write or rewrite to a CD-R/RW, DVD-R/-RW/-RAM or DVD+R/+RW disc.

■ Do not perform any of the following actions when writing or rewriting:

■ Change users in the Windows Vista™ operating system.

■ Operate the computer for any other function, including using a mouse

or TouchPad/Dual Mode Pad or closing/opening the LCD panel.

■ Start a communication application such as a modem.

■ Apply impact or vibration to the computer.

■ Install, remove or connect external devices such as USB devices,

an external display, i.Link devices or optical digital devices.

■ Use the audio/video control button to reproduce music or voice.

■ Open the drive.

■ Do not use shut down/log off and Sleep/Hibernation while writing or

rewriting.

■ Make sure writing or rewriting is completed before going into

Sleep/hibernation. Writing is completed if you can open the drive tray.

■ Set the computer on a level surface and avoid places subject to

vibration such as airplanes, trains or cars. Do not use an unstable surface such as a stand.

■ Keep mobile phones and other wireless communication devices away

from the computer.

■ Always copy data from the hard disk drive to the CD. Do not use

cut-and-paste as the original data will be lost if there is a write error.

How to make a Labelflash™ DVD

Simplified steps for making a Labelflash™ DVD:

1. Insert a Labelflash™ disc in DVD drive.

Set printable surface for underside.

2. Click Start -> All Programs -> DVD MovieFactory for TOSHIBA -> Ulead DVD MovieFactory for TOSHIBA Launcher to launch DVD

MovieFactory.

3. Click Print Disc Label -> Label Printing. Ulead Label@Onece is started.

4. Click the General tab.

5. Choose DVD Drive for Printer. e.g. <E:> PIONEER DVD....

6. Add and customize the look of your images and text.

7. Click Labelflash™ setting and choose Draw Quality.

8. Click Print.

The availability of Labelflash™ function depends on the model you purchased.

4-20 User’s Manual

Writing CDs/DVDs/HD DVDs on a HD DVD-R drive

You can use the HD DVD-R drive to write data to either CD-R/RW or DVD-R/-RW/+R/+RW/-RAM or HD DVD-R discs. The following applications for writing are preinstalled: TOSHIBA Disc Creator/ Direct Disc Writer. Ulead DVD MovieFactory® for TOSHIBA, which is a product of Ulead Systems, Inc.

Important message

Before you write or rewrite to CD-R/RW or DVD-R/-RW/+R/+RW/-RAM or HD DVD-R media, read and follow all set-up and operating instructions in this section. If you fail to do so, the HD DVD-R drive may not function properly, and you may fail to write or rewrite, lose data or incur other damage.

Disclaimer

TOSHIBA does not bear responsibility for the following:

■ Damage to any CD-R/RW or DVD-R/-RW/+R/+RW/-RAM or HD DVD-R

disc that may be caused by writing or rewriting with this product.

■ Any change or loss of the recorded contents of CD-R/RW or
