SERVICE MODE ...................................................................................................................................................... 6
SETTING & ADJUSTING DATA .............................................................................................................................. 18
LOCATION OF CONTROLS ................................................................................................................................... 19
CHASSIS AND CABINET REPLACEMENT PARTS LIST ......................................................................................21
PC BOARDS BOTTOM VIEW................................................................................................................................. 35
TERMINAL VIEW OF TRANSISTORS ................................................................................................................... 44
SPECIFICATIONS .............................................................................................................................................. END
TABLE OF CONTENTS
SPECIFIC INFORMATIONS
APPENDIX:
CIRCUIT DIAGRAM
– 2 –
CHAPTER 1 GENERAL ADJUSTMENTS
SAFETY INSTRUCTIONS
WARNING: BEFORE SERVICING THIS CHASSIS, READ THE “X-RAY RADIATION PRECAUTION”, “SAFETY PRECAU-
TION” AND “PRODUCT SAFETY NOTICE” INSTRUCTIONS BELOW.
X-RAY RADIATION PRECAUTION
1. Excessive high voltage can produce potentially hazardous X-RAY RADIATION. To avoid such hazards, the high
voltage must not be above the specified limit. The nominal
value of the high voltage of this receiver is (A) kV at zero
beam current (minimum brightness) under a (C) V AC power
source. The high voltage must not, under any circumstances,
exceed (B) kV.
Refer to table-1 for high voltage (A), (B) & AC voltage (C).
(See SETTING & ADJUSTING DATA on page 18)
Each time a receiver requires servicing, the high voltage
should be checked following the HIGH VOLTAGE CHECK
procedure in this manual. It is recommended that the reading of the high voltage be recorded as a part of the service
record. It is important to use an accurate and reliable high
voltage meter.
2. The only source of X-RAY RADIATION in this TV receiver
is the picture tube. For continued X-RAY RADIATION protection, the replacement tube must be exactly the same
type tube as specified in the parts list.
3. Some part in this receiver have special safety-related characteristics for X-RAY RADIATION protection. For continued safety, parts replacement should be undertaken only
after referring to the PRODUCT SAFETY NOTICE below.
GENERAL ADJUSTMENTS
SAFETY PRECAUTION
WARNING : Service should not be attempted by anyone unfamiliar with the necessary precautions on this receiver. The following
are the necessary precautions to be observed before servicing this chassis.
1. An isolation transformer should be connected in the power line between the receiver and the AC line before any service is
performed on the receiver.
2. Always discharge the picture tube anode to the CRT conductive coating before handling the picture tube. The picture tube
is highly evacuated and if broken, glass fragments will be violently expelled. Use shatter proof goggles and keep picture tube
away from the unprotected body while handling.
3. When replacing a chassis in the cabinet, always be certain that all the protective devices are put back in place, such as; nonmetallic control knobs, insulating covers, shields, isolation resistor-capacitor network etc.
PRODUCT SAFETY NOTICE
SPECIFIC INFORMATIONS
Many electrical and mechanical parts in this chassis have special safety-related characteristics. These characteristics are
often passed unnoticed by a visual inspection and the protection afforded by them cannot necessarily be obtained by using
replacement components rated for higher voltage, wattage, etc. Replacement parts which have these special safety characteristics are identified in this manual and its supplements; electrical components having such features are identified by
the international hazard symbols on the schematic diagram and the parts list.
Before replacing any of these components, read the parts list in this manual carefully. The use of substitute replacement
parts which do not have the same safety characteristics as specified in the parts list may create shock, fire, X-ray
radiation or other hazards.
– 3 –
WARNING: BEFORE SERVICING THIS CHASSIS, READ THE “X-RAY RADIATION PRECAUTION”, “SAFETY PRECAU-
TION” AND “PRODUCT SAFETY NOTICE” ON PAGE 3 OF SERVICE MANUAL.
SET-UP ADJUSTMENT
■ The following adjustments should be made when a complete realignment is required or a new picture tube is installed.
Perform the adjustments in order as follows :
1. Color Purity
2. Convergence
3. White Balance
Note: The PURITY/CONVERGENCE MAGNET assembly and rubber wedges need mechanical positioning.
Refer to figure 1.
COLOR PURITY ADUSTMENT
GENERAL ADJUSTMENTS
(1)Let the screen face in the installing direction or toward the east (when it is to be moved), bring up the service mode
screen after demagnetizing (front, left, right, and top) with the degaussing coil, receive white signals by pressing the
[TV/VIDEO] button, and then the receiver should be operated for more than 40 minutes.
(2)Perform rough adjustment of the central convergence with the P/C magnet according to the adjustment item.
(3)Receive built-in green signals, loosen set screws on the deflection yoke, remove rubber wedges, and shift the deflection
yoke to toward front.
(4)Move alternately the two 2-pole magnets of the P/C magnets so that the green raster can come to the center of the
screen.
Figure 1.
2-pole purity magnet
(27": Magnet is fixed with deflection yoke.)
SPECIFIC INFORMATIONS
Green Belt
Sub-4-pole convergence magnet (32" : 34")
Sub-4-pole convergence magnet (to be installed on deflection yoke for 30", 32”)
(5)Receive built-in red and blue signals, check that there is no inclination of the single color raster toward one side, and if
each color tilts to a great extent, make adjustment with the 2-pole magnet so that the 3 colors will come to the center
evenly.
(6)Receive the green raster, shift the deflection yoke from a
foremost position (hitting against the picture tube) to a
Shift deflection yoke
(7) Perform marking of each point
(6)
(8)
on the tape of picture tube
backward position horizontally, stop the deflection yoke
at a position where it begins to become a green raster,
and perform accurate marking on the picture tube.
(7)Shift the deflection yoke further backward, and perform
Picture tube
CRT-D board
accurate marking at a position where the green raster
begins to being luck.
(8)Fix the deflection yoke at a position 60% forward within
the range marked in items (6) and (7) above.
CONVERGENCE ADJUSTMENTS
100 60 0%
Fix the deflection yoke at a position 60% forward from a
point between (6) and (7)
P/C Mag
* Adjust the convergence magnet to get vest convergence in the the order to (1) ~ (5).
■ CENTER CONVERGENCE:
(1)Receive the white crosshatch or dot pattern from the service signal generator.
(2)Use the 2 pieces of main 4-pole magnets of P/C magnets, change the open angle, and align the red and blue vertical
lines on the screen center.
(3)Freeze the open angle of the main 4-pole magnets, turn them simultaneously, and align the horizontal lines.
(4)Take the same steps for items (2) and (3) above and align red/blue with green on the screen center using two 6-pole
magnets.
– 4 –
(5)Adjust the sub-4-pole magnets only in case there is any deviation of Xv bow-shaped convergence. (To be usually set at
the initial position)
Align both sides with the sub-4-pole magnets and minimize the deviation of blue and red with the main 4-pole magnets.
blue
blue
red
red
Main 4-pole magnet
red/blue
red/blue
green
6-pole magnet
■ CIRCUMFERENCE CONVERGENCE:
Perform correction in the following manner.
*
blue
green
red
A
B
C
(Parts code:23 948 274) TC-S
blue
green
red
S
N
Blue color or blue mark
D
E
F
*Insert the correction piece between the
picture tube and the deflection yoke.
Bonded surface
(Insertion position of correction
piece)
D
E
F
A
B
C
Adjust VR 1 and minimize the deviation of YH. *Only 27", 30" and 32".
Red
green
blue
blue
green
Red
Xv bow-shaped deviation of convergence
blue
green
red
Sub-4-pole magnet
• Adjust coils and minimize deviation
(The 27” unit has coils underneath it)
A
B
C
■ 30", 27", 32"
blue
green
red
(Parts code:23 948 464)
N
S
D
E
F
Bonded surface
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
Red
green
blue
blue
green
Red
Adjust VR 2 (YHC) and minimize the deviation of YH.
Red
blue
green
green
blue
Red
blue
Red
green
green
Red
blue
Adjust VR 3 (YV) and minimize the deviation of YV.
correction piece into the clearance of terminal board coils of
the deflection yoke.
Note:
Perform insertion by turning the
metal side to the terminal board
side of the deflection yoke.
– 5 –
1. ENTERING TO SERVICE MODE
1) Press o button once on
Remote Control.
SERVICE MODE
2) Press o button again to
keep pressing.
3) While pressing the o button,
press MENU button on TV set.
Mute or
GENERAL ADJUSTMENTS
2. DISPLAYING THE ADJUSTMENT MENU
1)Press MENU button on TV.
Adjustment mode
ITEM
DATA
3. KEY FUNCTION IN THE SERVICE MODE
The following key entry during display of adjustment menu provides special functions.
SPECIFIC INFORMATIONS
A single horizontal line ON/OFF:INFO button (on Remote) or a button (on TV)
Test signal selection :a button (on Remote)
Selection of the adjustment items :Channel s/t (on TV or Remote)
Change of the data value :Volume ; +/– (on TV or Remote)
Adjustment menu mode ON/OFF :MENU button (on TV)
Initialization of the memory (QA02) :CALL + Channel button on TV (s)
Reset the count of operating protect
Color thickness correction
note: Displayed differently as shown below, de-
pending on the setting of the receiving color
system.
COLP (PAL)
COLC (NTSC)
COLS (SECAM)
CAUTION : Never try to perform initialization unless you have changed the memory IC.
– 6 –
4. SELECTING THE ADJUSTING ITEMS
1) Every pressing of CHANNEL s button in the service mode changes the adjustment items in the order of table-2.
(t button for reverse order)
Refer to table-2 for preset data of adjustment mode.
(See SETTING & ADJUSTING DATA on page 18)
5. ADJUSTING THE DATA
1) Pressing of VOLUME ; +/– button will change the value of data in the range from 00H to FFH. The variable
range depends on the adjusting item.
6. EXIT FROM SERVICE MODE
1) Pressing POWER button to turn off the TV once.
■ INITIALIZATION OF MEMORY DATA OF QA02
After replacing QA02, the following initialization is required.
1. Enter the service mode, then select any register item.
2. Press and hold the CALL button on the Remote, then press the CHANNEL s button on the TV. The initialization of QA02 has
been complated.
3. Check the picture carefully. If necessary, adjust any adjustment item above.
Perform “Auto search Memory” on the owner’s manual.
CAUTION: Never attempt to initialize the data unless QA02 has been replaced.
7. TEST SIGNAL SELECTION
1) Every pressing of a button on the Remote Control changes the built-in test patterns on screen as described below
in SERVICE MODE.
GENERAL ADJUSTMENTS
Signal off
The signals marked with are not usable to display in the Test signal for some model.
*
NTSC signals (5 patterns)
PAL signals (5 patterns)
• Red raster
• Green raster
• Blue raster
• Black cross-hatch
• All White
SignalsPicture
SPECIFIC INFORMATIONS
– 7 –
8. SELF DIAGNOSTIC FUNCTION
1) Press “9” button on Remote Control during display of adjustment menu in the service mode.
The diagnosis will begin to check if interface among IC’s are executed properly.
2) During diagnosis, the following displays are shown.
Indicated color of mode now selected : Green and Red
<SELF CHECK>
23******
TIME
POWER : 00
BUS CONT : OK
BLOCK :
UV V1 V2 V3 V4
V5
Indicated color of other modes: White
Green : Normal
Red : The microcomputer operates to provide judgement
of no video signal. The red color is still indicated
though the signal is input, failure may exist in input
signal line including QV01.
QV01 : In case of indication green ---Normal
In case of indication red with input signal----
GENERAL ADJUSTMENTS
Failure may exist in output line including QV01.
Part number of microcomputer (QA01)
Operation number of protecting circuit ----“00” is nor-
mal.
When indication is other than “00”, overcurrent apts to
flow, and circuit parts may possibly be damaged.
BUS CONT ----“OK” is normal.
When indication shows “Q uuu NG”, the device with
the number may possibly be damaged.
BLOCK
UV : TV reception mode
V1 : VIDEO 1 input mode (a1)
SPECIFIC INFORMATIONS
V2 : VIDEO 2 input mode (a2)
V3 : VIDEO 3 input mode (a3)
NOTE: Component which controls character display on
screen is ICF01 (TELETEXT IC.). If this display
function fails to operate due to damage in ICF01,
self diagnosis procedure is as follows.
(1) In case that power indicator is blinking with
interval of 0.5 seconds; it means protecting
circuit (Current limiter) is operating, and circuit components may possibly be damaged.
Check related components.
(2) In case that power indicator is blinking with
interval of 1 second; Protecting circuit does
not operate, but a part of Bus line does not
operate normally. Check Bus line.
V4 : VIDEO 4 input mode (a4)
V5 : VIDEO 5 input mode (a5)
The items marked with are not usable to display in the SELF DIAGNOSTIC FUCTION for some model.
*
– 8 –
1. ENTERING TO DESIGN MODE
1) Select the Service mode.
DESIGN MODE
2) While pressing o or CALL button on
Remote and press MENU button on TV.
3) Press MENU button on TV.
SD
(Design mode)(Adjustment mode)
When QA02 is initialized, items “OPT0” and “OPT1” of DESIGN MODE are set to the data of the representative model of this
chassis family.
Therefore, because ON-SCREEN specification remains in the state of the representative of model. This model is required to
reset the data of items “OPT0” and “OPT1”.
2. SELECTING THE ADJUSTING ITEMS
Every pressing of CHANNEL t button in the design mode changes the adjustment items in the order of table-3.
(s button for reverse order)
Refer to table-3 for data of design mode.
(See SETTING & ADJUSTING DATA on page 18)
3. ADJUSTING THE DATA
Pressing of VOLUME s or t button will change the value of data.
Press
Press
ITEM
DATA
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
– 9 –
ELECTRICAL ADJUSTMENTS
ITEMADJUSTMENT PROCEDURE
FOCUS VR ADJ
SUB-BRIGHTNESS
(BRTC)
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
Note: Constrict the picture height
until the vertical retrace line
appears adjusting the item
HIT (HEIGHT).
HORIZONTAL POSITION
ADJUSTMENT (HPOS)
VERTICAL POSITION
ADJUSTMENT (VPOS)
1. Enter the service mode, then select any register item.
2. Press the TV/VIDEO button on the Remote until the black cross-bar pattern appears on the screen.
3. Adjust the FOCUS control (on T461) for well defined scanning lines on the picture
screen.
1. Set CONTRAST to minimum, and
BRIGHTNESS to center by adjusting user
controls.
2. Set the TV in service mode to get Black
cross-bar of inside pattern.
3. Select BRTC (brightness correction), and
adjust the ; – /+ button to reduce the
value so that white portion of inside pattern slightly light.
4. Adjust ; – /+ button to increase the data
value of BRTC, and set it just before the
difference between the belt of vertical retrace and the border of black portion of
inside pattern is visible.
After that, return vertical height and contrast.
1. Set the TV in service mode, and get
black cross-bar signal with VIDEO
button on remote hand unit.
2. Select either HPOS (Horizontal picture phase) or VPOS (Vertical picture
phase) with CHANNEL s, t buttons,
and adjust horizontal or vertical picture position in the center of screen
with VOLUME ; – /+ buttons.
Belt of vertical retrace
VERTICAL AMPLITUDE
ADJUSTMENT (HIT)
1. Set the TV in service mode, and get
black cross-hatch signal with VIDEO
button on remote hand unit.
2. Select HIT (Vertical amplitude) with
CHANNEL s, t buttons, and adjust
vertical amplitude with VOLUME
; – /+ buttons so that vertical amplitude lacks a little.
3. Adjust vertical amplitude with VOLUME ; – /+ buttons so that the first
bar on cross-hatch signal touches
edge of screen.
The first
– 10 –
ITEMADJUSTMENT PROCEDURE
WIDTH
(WID)
E-W PARABOLA
(PARA)
WHITE BALANCE
ADJUSTMENT
CUTOFF ADJUSTMENT
•
(RCUT)
(GCUT)
(BCUT)
DRIVE ADJUSTMENT
•
(GDRV)
(BDRV)
1. Call up the adjustment mode display, then select the item WID.
2. Press the ; – /+ button to get the picture so the left and rightedges of raster
begins to lack.
3. Press the ; – /+ button to advance the data by 7 steps.
Note : Check the horizontal picture position is correct.
1. Call up the adjustment mode display, then select the item PARA.
2. Press the a button on Remote until the cross-hatch pattern appears on the screen.
3. Press the ; – /+ button to make vertical lines straight as shown below.
1. Set Contrast to 40, and brightness to +20 by picture control.
2. Receive the Black and White pattern.
3. Select RCUT, GCUT and BCUT with CHANNEL s, t buttons, to set individual
values to Initial reference data, and to set GDRV and BDRV to Initial reference
data with VOLUME ; – /+ buttons (See page 18).
4. Press -/- - button on the remote control and rotate Screen VR to get one slight
horizontal line on screen.
Note: Every pressing of -/- - button provides Horizontal line picture and Normal
picture alternately.
5. Press -/- - button to release horizontal line picture, and select the two other colors
which did not light in the above step with CHANNEL s, t buttons. Then tap VOLUME ; – /+ buttons so that three colors slightly light in the same level.
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
X To correct white balance in light area,
select GDRV and BDRV with CHANNEL
s, t buttons to adjust.
HPOS
HIT
VLIN
VPS2
WID
PARA
CNR
TRAP
CPAR
HSC
VPS1
CSAW
Adjustment
R CUTOFF
G CUTOFF
B CUTOFF
R DRIVE
B DRIVE
SUB BRIGHT CEN
SUB COLOR CEN PAL
SUB COLOR CEN SECAM
YOOUT LEVLE FOR FOR ATV
SECAM R-Y
SECAM B-Y
Adjustment
H-POSITION
PICTURE HEIGHT
V-LINEARITY
V-SHIFT
WIDTH
E-W PARABOLA
E-W CORNER
TRAPEZIUM
CENT PARA
EW S CORRECTION
V-POSITION
CENT SAW
Reference data
40H
40H
40H
35H
35H
80H
19H
19H
1EH
07H
01H
Reference data
WIDESuperLive CINEMA
32H
2BH
11H
40H
2AH
11H
13H
45H
07H
11H
70H
08H
←
33H
0EH
←
39H
16H
18H
46H
←
0FH
6FH
←
←
4AH
0FH
←
2BH
21H
1AH
45H
06H
11H
72H
←
DESIGN MODE
ADJUSTING ITEMS AND DATAS IN THE DESIGN MODE:
ItemName of adjustmentPreset DataRemarks
OPT3OPTION 301H
Table-2
Table-3
– 18 –
LOCATION OF CONTROLS (Representaive: 36ZP38B)
Front
GENERAL ADJUSTMENTS
VIDEO-5 (S-VIDEO/VIDEO)
HEAD PHONE
Rear
(5)
L/MONO R
AUDIOVIDEOS-VIDEO
MENU
P
MAIN SWITCH
POSITION UP
POSITION DOWN
VOLUME UP
VOLUME DOWN
SPECIFIC INFORMATIONS
EXIT
SCART-1
SCART-2
SCART-3
SURROUND OUT
(3)/ 3S
(1)
(2)
PB/C
PR/C
Y
B
R
SURROUND OUT
LR
L
AUDIOAUDIO
R
(4)
FIXED
L
R
AERIAL TERMINAL
AUDIO OUT (FIXED)
VIDEO-4 (COMPONENT VIDEO)
– 19 –
Remote Control
GENERAL ADJUSTMENTS
TEXT/TV
CALL
Index, initial
CALL
Power on/Standby
(For Toshiba TV/VCR/DVD only)
213
Number buttons (0-9)
546
879
1 or 2 digit channel selection
Selectable picture
SPECIFIC INFORMATIONS
• Channelposition st
• Menu [12]
• DVD menu
Dolby Surround
Device switch
TV: To control TV
VCR: To control VCR
DVD: To control DVD
When in VCR or DVD mode:
(For Toshiba VCR/DVD only)
cto EJECT
to REWIND
Sto PLAY
to FAST FORWARD
Jto PAUSE
to SKIP-REWIND
Rto STOP
to SKIP-FORWARD
MENU
DVD MENU
OK
DVD ENTER
0
MENUEXIT
DVD
MENU
P
OK
P
TV
VCR
DVD
Input source selection
(A 1 – A 4)
Selectable sound
EXIT
• Volume – +
• Menu <>
• DVD menu <>
Teletext buttons
• Colored buttons
• F + v, ?, ^, r/X
Bass boost on/off
Sound mute
When in TV mode:
mI/IIStereo/Bilingual
selection
Picture still
– 20 –
CHASSIS AND CABINET REPLACEMENT PARTS LIST
WARNING: BEFORE SERVICING THIS CHASSIS, READ THE “X-RAY RADIATION PRECAUTION”, “SAFETY
PRECAUTION” AND “PRODUCT SAFETY NOTICE” ON PAGE 3 OF THIS MANUAL.
CAUTION: The international hazard symbols “” in the schematic diagram and the parts list designate com-
ponents which have special characteristics important for safety and should be replaced only with types identical to
those in the original circuit or specified in the parts list. The mounting position of replacements is to be identical with
originals. Before replacing any of these components, read carefully the PRODUCT SAFETY NOTICE. Do not
degrade the safety of the receiver through improper servicing.
NOTICE:
•
The part number must be used when ordering parts, in order to assist in processing, be sure to include the Model
number and Description.
•
The PC board assembly with * mark is no longer available after the end of the production.
Resistors ............... CF: Carbon FilmCC : Carbon CompositionMF : Metal Film
OMF : Oxide Metal FilmVR : Variable ResistorFR: Fusible Resistor
(All CD and PF capacitors are ±5%, 50V and all resistors, ±5%, 1/6W unless otherwise noted.)
Location
Parts No.Description
No.
CAPACITORS
C10224762221ELECTROLYTIC, 10V 220UF M
C10524109102CERAMIC CHIP, 50V B 1000PF K
C10624797100ELECTROLYTIC, 50V 10UF M
C10824762221ELECTROLYTIC, 10V 220UF M
C10924109103CERAMIC CHIP, 50V B 0.01UF K
C11524109103CERAMIC CHIP, 50V B 0.01UF K
C16024503045PLASTIC FILM, 63V 0.22UF J
C20524797229ELECTROLYTIC, 50V 2.2UF M
C20624794100ELECTROLYTIC, 16V 10UF M
C30224214471CERAMIC DISC, 500V B 470PF K
C30324214471CERAMIC DISC, 500V B 470PF K
C30524795222ELECTROLYTIC, 25V 2200UF M
C30824766221ELECTROLYTIC, 50V 220UF M
C30924590102PLASTIC FILM, 50V 1000PF J
C31024795222ELECTROLYTIC, 25V 2200UF M
C31324082280PLASTIC FILM, 100V 0.22UF J
C31624795471ELECTROLYTIC, 25V 470UF M
C31724214102CERAMIC DISC, 500V B 1000PF K
C31824794471ELECTROLYTIC, 16V 470UF M
C32024795471ELECTROLYTIC, 25V 470UF M
C32124503051PLASTIC FILM, 63V 0.68UF J
C32224617915ELECTROLYTIC, 50V 1UF K 3A LI
C32324503049PLASTIC FILM, 63V 0.47UF J
C32524590223PLASTIC FILM, 50V 0.022UF J
C32624797010ELECTROLYTIC, 50V 1UF M
C32724794471ELECTROLYTIC, 16V 470UF M
C33124503038PLASTIC FILM, 63V 0.056UF J
C33224212102CERAMIC DISC, 50V B 1000PF K
C36124503045PLASTIC FILM, 63V 0.22UF J
C36624082275PLASTIC FILM CQ922 M 100V 82000PF J
C37024794100ELECTROLYTIC, 16V 10UF M
C37224797470ELECTROLYTIC, 50V 47UF M
C37324797470ELECTROLYTIC, 50V 47UF M
C41024092341CERAMIC DISC, 2KV R 470PF K
C41324214392CERAMIC DISC, 500V B 3900PF K
C41624676330ELECTROLYTIC, 100V 33UF M 3A
C41724214391CERAMIC DISC, 500V B 390PF K
C41924212102CERAMIC DISC, 50V B 1000PF K
C42024794101ELECTROLYTIC, 16V 100UF M
C42124232103CERAMIC DISC, 50V F 0.01UF Z
C42124503041PLASTIC FILM , 63V 0.1UF J
Location
Parts No.Description
No.
C42324503124PLASTIC FILM CQ92 T 400V 68000PF J
C43024820103PLASTIC FILM, 630V 0.01UF J
C43124232103CERAMIC DISC, 50V F 0.01UF Z
C43224590103PLASTIC FILM, 50V 0.01UF J
C44124503291PLASTIC FILM CF92 T 400V R62UF J
C44224082637PLASTIC FILM, 400V 0.1UF J
C44324082637PLASTIC FILM, 400V 0.1UF J
C44424503195PLASTIC FILM, 1800VH 5100PF H (36ZP38B)
C44424503196PLASTIC FILM CF92 T, 1800VH 5600PF H
C44524828473PLASTIC FILM, 200V 0.047UF J
C44624679330ELECTROLYTIC, 250V 33UF M 3A
C44724829273PLASTIC FILM, 400V 27000PF J
C44824640908ELECTROLYTIC, 160V 33UF M 3A LI
C45124503047PLASTIC FILM, 63V 0.33UF J
C46024679220ELECTROLYTIC, 250V 22UF M 3A
C46124503196PLASTIC FILM CF92 T 1800VH 5600PF H
C46224666101ELECTROLYTIC, 16V 100UF M 3A
C46424503149PLASTIC FILM, 250V 3.3UF
C46524590183PLASTIC FILM, 50V 0.018UF J
C46624503261PLASTIC FILM CF92 T 1250VH 6800PF H
C46724503253PLASTIC FILM, 1250VH 0.01UF H (36ZP38B)
C46824503253PLASTIC FILM, 1250VH 0.01UF H
C47024794470ELECTORLYTIC, 16V 47UF M
C47124503046PLASTIC FILM, 63V 0.27UF J
C47224503049PLASTIC FILM, 63V 0.47UF J
C47324669010ELECTROLYTIC, 50V 1UF M 3A
C47524820822PLASTIC FILM, 630V 8200PF J
C47624794220ELECTROLYTIC, 16V 22UF M
C47824503038PLASTIC FILM, 63V 0.056UF J
C48124590103PLASTIC FILM, 50V 0.01UF J
C48224212152CERAMIC DISC, 50V B 1500PF K
C48224085988ELECTROLYTIC, NONPOLAR,
C48924590393PLASTIC FILM, 50V 0.039UF J
C49524092343CERAMIC DISC, 2KV 680PF K
C49624092343CERAMIC DISC, 2KV 680PF K
C49824590821PLASTIC FILM CQ922M 50V 820PF J
C50124092730CERAMIC CHIP, 16V B 0.1UF K
C50224092730CERAMIC CHIP, 16V B 0.1UF K
C50324794470ELECTORLYTIC, 16V 47UF M
C50424109103CERAMIC CHIP, 50V B 0.01UF K
(32ZP38B)
50V 1.0UF M 7L
SPECIFIC INFORMATIONS
– 21 –
Location
INFORMATIONS
SPECIFIC
SPECIFIC INFORMATIONS
Parts No.Description
No.
C50524794470ELECTORLYTIC, 16V 47UF M
C50624109103CERAMIC CHIP, 50V B 0.01UF K
C50724100104CERAMIC CHIP, 25V F 0.1UF Z
C50824100104CERAMIC CHIP, 25V F 0.1UF Z
C50924100104CERAMIC CHIP, 25V F 0.1UF Z
C51124100104CERAMIC CHIP, 25V F 0.1UF Z
C51224100104CERAMIC CHIP, 25V F 0.1UF Z
C51324109103CERAMIC CHIP, 50V B 0.01UF K
C51424763221ELECTROLYTIC, 16V 220UF M
C51624105110CERAMIC CHIP, 50V CH 11PF J
C51724206478ELECTROLYTIC, 50V 0.47UF M 7L 3A
C51924797479ELECTROLYTIC, 50V 4.7UF M
C52024503047PLASTIC FILM, 63V 0.33UF J
C52124092733CERAMIC CHIP, 50V B 0.022UF K
C52224109103CERAMIC CHIP, 50V B 0.01UF K
C52324100104CERAMIC CHIP, 25V F 0.1UF Z
C52424109103CERAMIC CHIP, 50V B 0.01UF K
C52524503041PLASTIC FILM , 63V 0.1UF J
C52624109103CERAMIC CHIP, 50V B 0.01UF K
C52724797229ELECTROLYTIC, 50V 2.2UF M
C53024206010ELECTROLYTIC, 50V 1.0UF M 7L 3A
C53124100104CERAMIC CHIP, 25V F 0.1UF Z
C53224100104CERAMIC CHIP, 25V F 0.1UF Z
C53324100104CERAMIC CHIP, 25V F 0.1UF Z
C53424100104CERAMIC CHIP, 25V F 0.1UF Z
C53624100104CERAMIC CHIP, 25V F 0.1UF Z
C53724100104CERAMIC CHIP, 25V F 0.1UF Z
C54024100104CERAMIC CHIP, 25V F 0.1UF Z
C54124100104CERAMIC CHIP, 25V F 0.1UF Z
C54224100104CERAMIC CHIP, 25V F 0.1UF Z
C54324100104CERAMIC CHIP, 25V F 0.1UF Z
C54424100104CERAMIC CHIP, 25V F 0.1UF Z
C54524100104CERAMIC CHIP, 25V F 0.1UF Z
C54724109103CERAMIC CHIP, 50V B 0.01UF K
C54824763101ELECTROLYTIC, 16V 100UF M
C56324206010ELECTROLYTIC, 50V 1.0UF M 7L 3A
C56424797479ELECTROLYTIC, 50V 4.7UF M
C56524797478ELECTROLYTIC, 50V 0.47UF M
C57524092730CERAMIC CHIP, 16V B 0.1UF K
C58024100104CERAMIC CHIP, 25V F 0.1UF Z
C61324666471ELECTROLYTIC, 16V 470UF M 3A
C61524085945ELECTROLYTIC, NONPOLAR, 50V 2.2UF
C61624590183PLASTIC FILM, 50V 0.018UF J
C61724590152PLASTIC FILM, 50V 1500PF J
C61824590563PLASTIC FILM, 50V 0.056UF J
C61924794221ELECTROIYTIC, 16V 220UF M
C62024794101ELECTROLYTIC, 16V 100UF M
C62124590102PLASTIC FILM, 50V 1000PF J
C62624797478ELECTROLYTIC, 50V 0.47UF M
C62824797470ELECTROLYTIC, 50V 47UF M
C62924109221CERAMIC CHIP, 50V B 220PF K
C63024109221CERAMIC CHIP, 50V B 220PF K
C63124669010ELECTROLYTIC, 50V 1UF M 3A
C63224669479ELECTROLYTIC, 50V 4.7UF M 3A
C63324503042PLASTIC FILM, 63V 0.12UF J
C63424668471ELECTROLYTIC, 35V 470UF M 3A
C63924793222ELECTROLYTIC, 10V 2200UF M
C64124669010ELECTROLYTIC, 50V 1UF M 3A
C64424669010ELECTROLYTIC, 50V 1UF M 3A
C64524667470ELECTROLYTIC, 25V 47UF M 3A
C64724591102PLASTIC FILM, 50V 1000PF J
C64824591102PLASTIC FILM, 50V 1000PF J
C64924797229ELECTROLYTIC, 50V 2.2UF M
C65024668102ELECTROLYTIC, 35V 1000UF M 3A
C65124668471ELECTROLYTIC, 35V 470UF M 3A
C65224668471ELECTROLYTIC, 35V 470UF M 3A
C65424503042PLASTIC FILM, 63V 0.12UF J
Location
* C80124503056PLASTIC FILM, AC275V 0.1UF M
* C80224503056PLASTIC FILM, AC275V 0.1UF M
* C81324092555CERAMIC DISC, AC250V E 1000PF M
* C81424092555CERAMIC DISC, AC250V E 1000PF M
Parts No.Description
No.
C65524503042PLASTIC FILM, 63V 0.12UF J
C65624232103CERAMIC DISC, 50V F 0.01UF Z
C65724797229ELECTROLYTIC, 50V 2.2UF M
C66024797229ELECTROLYTIC, 50V 2.2UF M
C66124797478ELECTROLYTIC, 50V 0.47UF M
C66224797229ELECTROLYTIC, 50V 2.2UF M
C66324669229ELECTROLYTIC, 50V 2.2UF M 3A
C66424794100ELECTROLYTIC, 16V 10UF M
C66524073083ELECTROLYTIC CE04P 50V 3.3UF M 3A
C66624073083ELECTROLYTIC CE04P 50V 3.3UF M 3A
C66724669229ELECTROLYTIC, 50V 2.2UF M 3A
C66824590102PLASTIC FILM, 50V 1000PF J
C66924797330ELECTROLYTIC, 50V 33UF M
C67024797330ELECTROLYTIC, 50V 33UF M
C67024590222PLASTIC FILM, 50V 2200PF J
C67124669010ELECTROLYTIC, 50V 1UF M 3A
C67224590222PLASTIC FILM, 50V 2200PF J
C67324669010ELECTROLYTIC, 50V 1UF M 3A
C67424669010ELECTROLYTIC, 50V 1UF M 3A
C67524667470ELECTROLYTIC, 25V 47UF M 3A
C67624669479ELECTROLYTIC, 50V 4.7UF M 3A
C67724590471PLASTIC FILM, 50V 470PF J
C67824590471PLASTIC FILM, 50V 470PF J
C67924591473PLASTIC FILM, 50V 0.047UF J
C68024668102ELECTROLYTIC, 35V 1000UF M 3A
C68124668102ELECTROLYTIC, 35V 1000UF M 3A
C68224668102ELECTROLYTIC, 35V 1000UF M 3A
C68324668102ELECTROLYTIC, 35V 1000UF M 3A
C68424666470ELECTORLYTIC, 16V 47UF M 3A
C68524503042PLASTIC FILM, 63V 0.12UF J
C68624503042PLASTIC FILM, 63V 0.12UF J
C68724232103CERAMIC DISC, 50V F 0.01UF Z
C68824666220ELECTROLYTIC, 16V 22UF M 3A
C68924503042PLASTIC FILM, 63V 0.12UF J
C69124797010ELECTROLYTIC, 50V 1UF M
C69224797010ELECTROLYTIC, 50V 1UF M
C69524668101ELECTROLYTIC, 35V 100UF M 3A
C69624667470ELECTROLYTIC, 25V 47UF M 3A
C70424590822PLASTIC FILM, 50V 8200PF J
C70524797229ELECTROLYTIC, 50V 2.2UF M
C70724794470ELECTORLYTIC, 16V 47UF M
C71224794470ELECTORLYTIC, 16V 47UF M
C71324790100ELECTROLYTIC, 160V 10UF M
C71524214472CERAMIC DISC, 500V B 4700PF K
C71724214472CERAMIC DISC, 500V B 4700PF K
C71824794470ELECTORLYTIC, 16V 47UF M
C71924435151CERAMIC DISC, 500V SL 150PF
C72024790100ELECTROLYTIC, 160V 10UF M
C72124794470ELECTORLYTIC, 16V 47UF M
C80524092281CERAMIC DISC, AC250V E 4700PF
C80624092281CERAMIC DISC, AC250V E 4700PF
C80824668101ELECTROLYTIC, 35V 100UF M 3A
C80924503049PLASTIC FILM, 63V 0.47UF J
C81024086873ELECTROLYTIC, 400V 330UF
C81624073063ELECTROLYTIC CE04P 35V 4.7UF M 3A
C81724092339CERAMIC DISC, 2KV 330PF K
C81824095931PLASTIC FILM, 1250VH 2200PF J
C82124214471CERAMIC DISC, 500V B 470PF K
C82224503049PLASTIC FILM, 63V 0.47UF J
C82324214471CERAMIC DISC, 500V B 470PF K
C82924591272PLASTIC FILM, 50V 2700PF J
C83124794470ELECTORLYTIC, 16V 47UF M
C83224794470ELECTORLYTIC, 16V 47UF M
– 22 –
Location
Parts No.Description
No.
C83424794470ELECTORLYTIC, 16V 47UF M
C83524795100ELECTROLYTIC, 25V 10UF M
C83624794470ELECTORLYTIC, 16V 47UF M
C83824794470ELECTORLYTIC, 16V 47UF M
C84024667102ELECTROLYTIC, 25V 1000UF M 3A
C84224669100ELECTROLYTIC, 50V 10UF M 3A
C87224669221ELECTROLYTIC, 50V 220UF M 3A
C88424086953ELECTROLYTIC, 160V 220UF M 3A
C88524214471CERAMIC DISC, 500V B 470PF K
C88924669222ELECTROLYTIC, 50V 2200UF M 3A
C89124667472ELECTROLYTIC, 25V 4700UF M 3A
C89224667472ELECTROLYTIC, 25V 4700UF M 3A
C89324092337CERAMIC DISC, 2KV 220PF K
C89624214471CERAMIC DISC, 500V B 470PF K
C89824503045PLASTIC FILM, 63V 0.22UF J
C89924214471CERAMIC DISC, 500V B 470PF K
C90224092353CERAMIC DISC, 2KV 4700PF K
C90424436471CERAMIC DISC, 50V SL 470PF J
C90524436471CERAMIC DISC, 50V SL 470PF J
C90724436391CERAMIC DISC, 50V SL 390PF J
C90924679330ELECTROLYTIC, 250V 33UF M 3A
C91024797478ELECTROLYTIC, 50V 0.47UF M
C91124203100ELECTORLYTIC, 16V 10UF M 7L 3A
C91224763222ELECTROLYTIC, 16V 2200UF M (36ZP38B)
C91224763102ELECTROLYTIC, 16V 1000UF M (32ZP38B)
C91324794101ELECTROLYTIC, 16V 100UF M
C91424212103CERAMIC DISC, 50V B 10000PF K
C91524092398CERAMIC DISC, 25V 0.1UF Z,
C93024214101CERAMIC DISC, 500V B 100PF K
C93124214101CERAMIC DISC, 500V B 100PF K
C2102 24105560CERAMIC CHIP, 50V CH 56PF J
C2103 24105560CERAMIC CHIP, 50V CH 56PF J
C2104 24105560CERAMIC CHIP, 50V CH 56PF J
C2110 24100104CERAMIC CHIP, 25V F 0.1UF Z
C4000 24590102PLASTIC FILM, 50V 1000PF J
C4222 24092538CERAMIC CHIP, 10V F 1UF Z
C4401 24763221ELECTROLYTIC, 16V 220UF M
C4402 24109103CERAMIC CHIP, 50V B 0.01UF K
C4403 24797010ELECTROLYTIC, 50V 1UF M
C4404 24109103CERAMIC CHIP, 50V B 0.01UF K
C4405 24100104CERAMIC CHIP, 25V F 0.1UF Z
C4406 24109103CERAMIC CHIP, 50V B 0.01UF K
C4407 24109103CERAMIC CHIP, 50V B 0.01UF K
C4408 24092538CERAMIC CHIP, 10V F 1UF Z
C4409 24794331ELECTROLYTIC, 16V 330UF M
C4410 24109103CERAMIC CHIP, 50V B 0.01UF K
C4411 24100104CERAMIC CHIP, 25V F 0.1UF Z
C4412 24100104CERAMIC CHIP, 25V F 0.1UF Z
C4490 24503190PLASTIC FILM, 400V 0.12UF J
C4491 24503190PLASTIC FILM, 400V 0.12UF J
C4601 24503040PLASTIC FILM, 63V 0.082UF J
C4690 24503041PLASTIC FILM , 63V 0.1UF J
C4699 24073058ELECTROLYTIC, 25V 2200UF M 3A
C5020 24109103CERAMIC CHIP, 50V B 0.01UF K
C5030 24763101ELECTROLYTIC, 16V 100UF M
C5080 24206010ELECTROLYTIC, 50V 1.0UF M 7L 3A
C5090 24763101ELECTROLYTIC, 16V 100UF M
CA0324105180CERAMIC CHIP, 50V CH 18PF J
CA0424105180CERAMIC CHIP, 50V CH 18PF J
CA0924105101CERAMIC CHIP, 50V CH 100PF J
CA1024105101CERAMIC CHIP, 50V CH 100PF J
CA1224105101CERAMIC CHIP, 50V CH 100PF J
CA1424212103CERAMIC DISC, 50V B 10000PF K (36ZP38B)
CA1524105101CERAMIC CHIP, 50V CH 100PF J
CA1624105101CERAMIC CHIP, 50V CH 100PF J
CA1724105101CERAMIC CHIP, 50V CH 100PF J
24092398A NI TOOITSU
Location
Parts No.Description
No.
CA3324793470ELECTROLYTIC CE04G 10V 47UF M
CA4224794101ELECTROLYTIC, 16V 100UF M
CA4324109103CERAMIC CHIP, 50V B 0.01UF K
CA4424109103CERAMIC CHIP, 50V B 0.01UF K
CA4524109103CERAMIC CHIP, 50V B 0.01UF K
CA6724100103CERAMIC CHIP, 50V F 0.01UF Z
CA6824794100ELECTROLYTIC, 16V 10UF M
CA6924100103CERAMIC CHIP, 50V F 0.01UF Z
CA7024794100ELECTROLYTIC, 16V 10UF M
CA9524794100ELECTROLYTIC, 16V 10UF M (36ZP38B)
CB0424092538CERAMIC CHIP, 10V F 1UF Z
CB0524109222CERAMIC CHIP, 50V B 2200PF K
CB0624105561CERAMIC CHIP, 50V CH 560PF J
CB0724109332CERAMIC CHIP, 50V B 3300PF K
CB2124503041PLASTIC FILM , 63V 0.1UF J
CB2224203470ELECTROLYTIC, 16V 47UF M 7L 3A
CB4024092538CERAMIC CHIP, 10V F 1UF Z
CB4124109222CERAMIC CHIP, 50V B 2200PF K
CB4224105561CERAMIC CHIP, 50V CH 560PF J
CB4324109332CERAMIC CHIP, 50V B 3300PF K
CB9024100103CERAMIC CHIP, 50V F 0.01UF Z
CC0124100103CERAMIC CHIP, 50V F 0.01UF Z
CC0224100103CERAMIC CHIP, 50V F 0.01UF Z
CC0324100103CERAMIC CHIP, 50V F 0.01UF Z
CC0324212332CERAMIC DISC, 50V B 3300PF K
CC0424105220CERAMIC CHIP, 50V CH 22PF J
CC0424100103CERAMIC CHIP, 50V F 0.01UF Z
CC0524109102CERAMIC CHIP, 50V B 1000PF K
CC0524212332CERAMIC DISC, 50V B 3300PF K
CC0624109102CERAMIC CHIP, 50V B 1000PF K
CC1224109102CERAMIC CHIP, 50V B 1000PF K
CC1324109102CERAMIC CHIP, 50V B 1000PF K
CC1424212102CERAMIC DISC, 50V B 1000PF K
CC1524212102CERAMIC DISC, 50V B 1000PF K
CC1524232103CERAMIC DISC, 50V F 0.01UF Z
CC1624590103PLASTIC FILM, 50V 0.01UF J
CC2124109102CERAMIC CHIP, 50V B 1000PF K
CC2224109102CERAMIC CHIP, 50V B 1000PF K
CC2424109103CERAMIC CHIP, 50V B 0.01UF K
CC2524109103CERAMIC CHIP, 50V B 0.01UF K
CC3024100103CERAMIC CHIP, 50V F 0.01UF Z
CC3124109102CERAMIC CHIP, 50V B 1000PF K
CC3224100103CERAMIC CHIP, 50V F 0.01UF Z
CC6024109223CERAMIC CHIP, 25V B 0.022UF K
CC6124109223CERAMIC CHIP, 25V B 0.022UF K
CC6224109102CERAMIC CHIP, 50V B 1000PF K
CC6324109102CERAMIC CHIP, 50V B 1000PF K
CC6424109102CERAMIC CHIP, 50V B 1000PF K
CC6524109102CERAMIC CHIP, 50V B 1000PF K
CC6624109102CERAMIC CHIP, 50V B 1000PF K
CC6724109102CERAMIC CHIP, 50V B 1000PF K
CC6824109223CERAMIC CHIP, 25V B 0.022UF K
CC6924109102CERAMIC CHIP, 50V B 1000PF K
CC7024109102CERAMIC CHIP, 50V B 1000PF K
CC7124109223CERAMIC CHIP, 25V B 0.022UF K
CC7224109102CERAMIC CHIP, 50V B 1000PF K
CC7324109102CERAMIC CHIP, 50V B 1000PF K
CC7424109102CERAMIC CHIP, 50V B 1000PF K
CC7524109102CERAMIC CHIP, 50V B 1000PF K
CC7724109102CERAMIC CHIP, 50V B 1000PF K
CC7824109102CERAMIC CHIP, 50V B 1000PF K
CC8024436470CERAMIC DISC, 50V SL 47PF J
CC182 24105151CERAMIC CHIP, 50V CH 150PF J
CD181 24100104CERAMIC CHIP, 25V F 0.1UF Z
CD182 24794100ELECTROLYTIC, 16V 10UF M
CD183 24092733CERAMIC CHIP, 50V B 0.022UF K
CD184 24092733CERAMIC CHIP, 50V B 0.022UF K
SPECIFIC INFORMATIONS
– 23 –
Location
SPECIFIC INFORMATIONS
Parts No.Description
No.
CD185 24100104CERAMIC CHIP, 25V F 0.1UF Z
CD186 24092733CERAMIC CHIP, 50V B 0.022UF K
CD187 24762221ELECTROLYTIC, 10V 220UF M
CD188 24109222CERAMIC CHIP, 50V B 2200PF K
CD189 24794100ELECTROLYTIC, 16V 10UF M
CR0124206010ELECTROLYTIC, 50V 1.0UF M 7L 3A
CR0224100103CERAMIC CHIP, 50V F 0.01UF Z
CR0724100104CERAMIC CHIP, 25V F 0.1UF Z
CR0824100104CERAMIC CHIP, 25V F 0.1UF Z
CR0924100104CERAMIC CHIP, 25V F 0.1UF Z
CR1024100104CERAMIC CHIP, 25V F 0.1UF Z
CR1124105470CERAMIC CHIP, 50V CH 47PF J
CR1224100104CERAMIC CHIP, 25V F 0.1UF Z
CR1324100104CERAMIC CHIP, 25V F 0.1UF Z
CR1424100104CERAMIC CHIP, 25V F 0.1UF Z
CR1524794470ELECTORLYTIC, 16V 47UF M
CR1624100104CERAMIC CHIP, 25V F 0.1UF Z
CS0124797229ELECTROLYTIC, 50V 2.2UF M
CS0224797229ELECTROLYTIC, 50V 2.2UF M
CS0324797229ELECTROLYTIC, 50V 2.2UF M
CS0424797229ELECTROLYTIC, 50V 2.2UF M
CS0524797229ELECTROLYTIC, 50V 2.2UF M
CS0624797229ELECTROLYTIC, 50V 2.2UF M
CS0724797229ELECTROLYTIC, 50V 2.2UF M
CS0824797229ELECTROLYTIC, 50V 2.2UF M
CS0924797229ELECTROLYTIC, 50V 2.2UF M
CS1024797229ELECTROLYTIC, 50V 2.2UF M
CS1124794100ELECTROLYTIC, 16V 10UF M
CS1224794100ELECTROLYTIC, 16V 10UF M
CS1324794100ELECTROLYTIC, 16V 10UF M
CS1424794100ELECTROLYTIC, 16V 10UF M
CS1824794100ELECTROLYTIC, 16V 10UF M
CS1924794100ELECTROLYTIC, 16V 10UF M
CS2024797478ELECTROLYTIC, 50V 0.47UF M
CS2324797478ELECTROLYTIC, 50V 0.47UF M
CS2424797229ELECTROLYTIC, 50V 2.2UF M
CS2524797229ELECTROLYTIC, 50V 2.2UF M
CS2624794100ELECTROLYTIC, 16V 10UF M
CS2724794100ELECTROLYTIC, 16V 10UF M
CT0124792221ELECTROLYTIC CE04G 6.3V 220UF M
CT0224109103CERAMIC CHIP, 50V B 0.01UF K
CT0324109103CERAMIC CHIP, 50V B 0.01UF K
CT0424793101ELECTROLYTIC, 10V 100UF M
CT0524100104CERAMIC CHIP, 25V F 0.1UF Z
CT0624793470ELECTROLYTIC CE04G 10V 47UF M
CT0724092538CERAMIC CHIP, 10V F 1UF Z
CT0824105560CERAMIC CHIP, 50V CH 56PF J
CT0924105560CERAMIC CHIP, 50V CH 56PF J
CT1024793470ELECTROLYTIC CE04G 10V 47UF M
CT1124100104CERAMIC CHIP, 25V F 0.1UF Z
CT1224793470ELECTROLYTIC CE04G 10V 47UF M
CT1324100104CERAMIC CHIP, 25V F 0.1UF Z
CT1424100104CERAMIC CHIP, 25V F 0.1UF Z
CT1724100104CERAMIC CHIP, 25V F 0.1UF Z
CT1924794100ELECTROLYTIC, 16V 10UF M
CT2024109103CERAMIC CHIP, 50V B 0.01UF K
CT2324100104CERAMIC CHIP, 25V F 0.1UF Z
CT9924763102ELECTROLYTIC, 16V 1000UF M
CV0224092538CERAMIC CHIP, 10V F 1UF Z
CV0324092538CERAMIC CHIP, 10V F 1UF Z
CV0424092538CERAMIC CHIP, 10V F 1UF Z
CV0624092538CERAMIC CHIP, 10V F 1UF Z
CV0724100104CERAMIC CHIP, 25V F 0.1UF Z
CV0824203101ELECTROLYTIC, 16V 100UF M 7L 3A
CV0924092538CERAMIC CHIP, 10V F 1UF Z
CV1024794100ELECTROLYTIC, 16V 10UF M
CV1224100104CERAMIC CHIP, 25V F 0.1UF Z
Location
Parts No.Description
No.
CV1324794100ELECTROLYTIC, 16V 10UF M
CV1424100104CERAMIC CHIP, 25V F 0.1UF Z
CV1524092743CERAMIC CHIP, 10V F 0.47UF Z
CV2324203101ELECTROLYTIC, 16V 100UF M 7L 3A
CV2424100104CERAMIC CHIP, 25V F 0.1UF Z
CV2524794470ELECTORLYTIC, 16V 47UF M
CV3524100104CERAMIC CHIP, 25V F 0.1UF Z
CV3624100104CERAMIC CHIP, 25V F 0.1UF Z
CV3924794101ELECTROLYTIC, 16V 100UF M
CV4024100104CERAMIC CHIP, 25V F 0.1UF Z
CV4124100104CERAMIC CHIP, 25V F 0.1UF Z
CV4224092538CERAMIC CHIP, 10V F 1UF Z
CV4424092743CERAMIC CHIP, 10V F 0.47UF Z
CV4524100104CERAMIC CHIP, 25V F 0.1UF Z
CV4624794101ELECTROLYTIC, 16V 100UF M
CV4824503041PLASTIC FILM , 63V 0.1UF J
CV6524203101ELECTROLYTIC, 16V 100UF M 7L 3A
CV6624203101ELECTROLYTIC, 16V 100UF M 7L 3A
CV7024794100ELECTROLYTIC, 16V 10UF M
CV7124100104CERAMIC CHIP, 25V F 0.1UF Z
CV7224092538CERAMIC CHIP, 10V F 1UF Z
CV7324092538CERAMIC CHIP, 10V F 1UF Z
CV7424092538CERAMIC CHIP, 10V F 1UF Z
CV7524092538CERAMIC CHIP, 10V F 1UF Z
CV7624092538CERAMIC CHIP, 10V F 1UF Z
CV7724092538CERAMIC CHIP, 10V F 1UF Z
CZ0124100104CERAMIC CHIP, 25V F 0.1UF Z
CZ0224109103CERAMIC CHIP, 50V B 0.01UF K
CZ0324100104CERAMIC CHIP, 25V F 0.1UF Z
CZ0424100104CERAMIC CHIP, 25V F 0.1UF Z
CZ0724100104CERAMIC CHIP, 25V F 0.1UF Z
CZ4624109103CERAMIC CHIP, 50V B 0.01UF K
CZ4724794101ELECTROLYTIC, 16V 100UF M
