EPA ENERGY STAR ® (MFD)
The United States Environmental Protection Agency (EPA) has introduced a voluntary programme, the ENERGY
STAR programme, to encourage the widespread and voluntary use of energy-efficient technologies that enhance
the workplace, improve product performance and prevent pollution. As an
TEC CORPORATION has determined that this copier model meets the
efficiency.
ENERGY STAR guidelines for this class of copier require ENERGY STAR copiers to have a ‘Sleep Mode’
feature that automatically makes the copier enter the sleep mode after a period of inactivity. The copier must also
automatically change to a ‘Low Power Mode’ (Automatic Energy Save) after a period of time since the last usage.
Specifically, this copier complies with the following requirements.
e-STUDIO230/280 Copier model (Base model)
‘Automatic Energy Save’-
The copier consumes less than 93.55 watts (e-STUDIO230)/112.8 watts (e-STUDIO280) during Energy
Save.
‘Automatic Energy Save’ Default Time-
The default time for the ‘Automatic Energy Save’ is 15 minutes.
‘Sleep Mode’
The copier consumes less than 15 watts in the ‘Sleep Mode’.
‘Sleep Mode’ Default Time-
The default time for the ‘Sleep Mode’ is 40 minutes.
e-STUDIO230/280 Copier/Printer + Fax model (Multifunction model)
‘Automatic Energy Save’-
The copier consumes less than 138.55 watts (e-STUDIO230)/157.80 watts (e-STUDIO280) during Energy
Save.
‘Automatic Energy Save’ Default Time-
The default time for the ‘Automatic Energy Save’ is 15 minutes.
‘Sleep Mode’
The copier consumes less than 80 watts in the ‘Sleep Mode’.
‘Sleep Mode’ Default Time-
The default time for the ‘Sleep Mode’ is 40 minutes.
ENERGY STAR Partner, the TOSHIBA
ENERGY STAR guidelines for energy
Note1- The default setting for the ‘Sleep Mode’ and ‘Automatic Energy Save’ can be changed.
Note2- For Multifunction model, if the Fax or printer data is received in the sleep mode, the copier starts
warming itself up and prints out the data when it becomes ready. Also, when the start button or the
energy saver button on the control panel is pressed, the copier starts warming itself up.
Note3- If ‘Automatic Energy Save’ and ‘Sleep Mode’ have the same setting time, ‘Sleep Mode’ takes priority.
In accordance with EPA
paper.
Great White MultiUse 20 paper
Great White MultiUse 24 paper
If you have any questions regarding the use of recycled paper or some recommended types of recycled paper,
please contact your authorized Toshiba dealer.
ENERGY STAR programme guidelines, Toshiba recommends the following recycled
ENERGY STAR is a U.S. registered mark.
