Toshiba 27A41 User Manual
Toshiba
Welcome to
Important
Safeguards
your TV
TM
Connecting
Using the
Remote Control
your TV
Setting up
Features
Using the TV’s
27A41
3K10601B COVER 21/08/2001, 14:301
Appendix
Welcome to Toshiba
Toshiba
Welcome to
Congratulations! You have purchased one of the finest color TVs on the
market. The goal of this manual is to guide you through setting up and
operating your Toshiba TV as quickly as possible. Please make sure
you’ve received the following items: TV, remote control, batteries,
manual, registration card, and extended service plan literature. If you
did not receive all of the items, or any of the items are damaged or
broken, please contact your Toshiba dealer. In addition, you may need
to purchase other audio or video cables to connect your equipment.
See “Connecting your TV” on page 4 for more information.
Please read all the safety and operating instructions carefully before
you begin.
Exploring your new TV
You can operate your TV by using the buttons on the front panel or the
remote control. All the terminals on the front and the back panel
provide all the connections you will need to connect other equipment to
your TV .
Power indicator
Remote Sensor
Audio (L/R)/Video In
VIDEO3 IN
AUDIO
L/MONO
VIDEO
IN OUT
Y
VIDEO
B
P
P
L/MONO
AUDIO
R
R
R
Power
POWER
ANT (75Ω)
Channel
Volume
VOLUME CHANNEL
VIDEO
L/MONO
S-VIDEO
AUDIO
R
VIDEO 1 VIDEO 2
Selecting a location for the TV
• Place the TV on the floor or on a sturdy platform in a location where
light does not directly hit the screen.
• Place the TV far enough from the walls to allow proper ventilation.
Inadequate ventilation may cause overheating, which may damage
the TV.
The model number and serial number are on the back of your TV.
Record these numbers in the spaces below. Refer to these numbers
whenever you communicate with your Toshiba dealer about this TV.
Model number: _____________________
Serial number:______________________
POWER
TV VCR CABLE
CH
MENU/
ENTER
CH
PLAY
STOP
+
–
CH RTN
PAUSE/STILL
VCR CH
ENT
100
FAVEXIT RECALL TV/VIDEO
FAV
0
VOL
+–
123
456
789
VOL
RESET CAP/TEXT 1/2
CODE MTS SLEEP MUTE
REW FF
TV/VCR
REC
Caution:
The plug has one prong wider than the other
and will fit only one way into a standard
electrical outlet (120 volt AC, 60 Hz). If the
plug does not fit into the outlet, try turning it
around. If the plug still does not fit, the outlet
is probably non-standard and must be
replaced by a qualified electrician.
Do not tamper with the plug or try to force
it into a non-standard outlet.
wide prong
3K10601B P01-03 21/08/2001, 14:292
Important Safeguards ......................................................................................................... 2
Connecting your TV ............................................................................................................ 4
Connecting a VCR .......................................................................................................................................4
Connecting a cable converter box...............................................................................................................5
Connecting a DVD/satellite receiver and a VCR.........................................................................................6
Connecting a DVD with ColorStreamTM and a VCR ....................................................................................6
Connecting two VCRs .................................................................................................................................7
Connecting a camcorder .............................................................................................................................7
Connecting an audio amplifier .....................................................................................................................7
Using the remote control.................................................................................................... 8
Preparing the remote control for use...........................................................................................................8
Installing the remote control batteries .........................................................................................................8
Using the remote control with a VCR or a cable TV converter ...................................................................8
Programming the remote control for use with a VCR or a cable TV converter...........................................9
Learning about the remote control ............................................................................................................10
Setting up your TV .............................................................................................................11
Changing the on-screen display language................................................................................................ 11
Adding channels to the TV’s memory........................................................................................................12
Programming channels automatically ................................................................................................12
Adding and erasing channels manually .............................................................................................12
Changing channels ....................................................................................................................................12
Using the TV’s features .................................................................................................... 13
Adjusting the channel settings...................................................................................................................13
Switching between two channels .......................................................................................................13
Programming your favorite channels .................................................................................................13
Using theV-Chip.........................................................................................................................................14
Selecting a PIN code ..........................................................................................................................14
Blocking programs by ratings .............................................................................................................15
Blocking unrated movies or programs................................................................................................18
Blocking channels...............................................................................................................................18
Labeling channels......................................................................................................................................19
Adjusting the picture ..................................................................................................................................20
Adjusting the picture quality ...............................................................................................................20
Watching video input .................................................................................................................................21
Selecting the ColorStream mode ..............................................................................................................21
Displaying on-screen information ..............................................................................................................21
Setting the sleep timer...............................................................................................................................21
Using the closed caption feature ...............................................................................................................21
Adjusting the sound ...................................................................................................................................22
Muting the sound ................................................................................................................................22
Selecting stereo/SAP broadcasts.......................................................................................................22
Adjusting the sound quality ................................................................................................................23
Using the STABLE SOUND feature ...................................................................................................23
Auto power off............................................................................................................................................24
Understanding the Power Return feature..................................................................................................24
Appendix............................................................................................................................ 24
Cleaning and care .....................................................................................................................................24
Troubleshooting .........................................................................................................................................25
Specifications.............................................................................................................................................26
Limited United States warranty .................................................................................................................27
Toshiba
Toshiba
Welcome to
Welcome to
Important
Safeguards
your TV
Connecting
Using the
Remote Control
your TV
Setting up
Features
Using the TV’s
3K10601B P01-03 21/08/2001, 14:293
1
Appendix
Important
Safeguards
The lightning flash with arrowhead symbol, within an
equilateral triangle is intended to alert the user to the
presence of uninsulated dangerous voltage within the
product's enclosure that may be of sufficient magnitude
to constitute a risk of electric shock.
CAUTION: TO REDUCE THE RISK OF ELECTRIC
CAUTION: Changes or modifications not expressly approved by the party responsible for compliance with the FCC Rules
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
SHOCK, DO NOT REMOVE COVER
(OR BACK). NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.
could void the user's authority to operate this equipment.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
IMPORTANT SAFEGUARDS
1. READ INSTRUCTIONS
All the safety and operating instructions should be read before the unit is operated.
2. RETAIN INSTRUCTIONS
The safety and operating instructions should be retained for future reference.
3. HEED WARNINGS
All warnings on the unit and in the operating instructions should be adhered to.
4. FOLLOW INSTRUCTIONS
All operating and use instructions should be followed.
5. CLEANING
Unplug this unit from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth
for cleaning.
6. ATTACHMENTS
The manufacturer of this unit does not make any recommendations for attachments, as they may cause hazards.
7. WATER AND MOISTURE
Do not use this unit near water. For example, near a bathtub, washbowl, kitchen sink, or laundry tub, in a wet basement,
or near a swimming pool.
8. ACCESSORIES
Do not place this unit on an unstable cart, stand, tripod, bracket, or table.
The unit may fall, causing serious injury, and serious damage to the unit.
8A. An appliance and cart combination should be moved with care.
Quick stops, excessive force, and uneven surfaces may cause the appliance
and cart combination to overturn.
9. VENTILATION
Slots and openings in the cabinet back or bottom are provided for ventilation, to ensure reliable operation of the unit
and to protect it from overheating. These openings must not be blocked or covered. The openings should never be
blocked by placing the unit on a bed, sofa, rug, or other similar surface. This unit should never be placed near or over
a radiator or heat source. This unit should not be placed in a built-in installation, such as a bookcase, or rack unless
proper ventilation is provided or the manufacturer's instructions have been adhered to.
10. POWER SOURCE
This unit should be operated only from the type of power source indicated on the rating plate. If you are not sure of the
type of power supply to your home, consult your appliance dealer or local power company. For units intended to
operate from battery power, or other sources, refer to the operating instructions.
11. GROUNDING OR POLARIZATION
This unit is equipped with a polarized alternating current line plug (a plug having one blade wider than the other).
This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into
the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet.
Do not defeat the safety purpose of the polarized plug. If your unit is equipped with a 3-wire grounding-type plug,
a plug having a third (grounding) pin, this plug will only fit into a grounding-type power outlet. This too, is a safety
feature. If you are unable to insert the plug into the outlet, contacts your electrician to replace your obsolete outlet.
Do not defeat the safety purpose of the grounding-type plug.
12. POWERCORD PROTECTION
Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or
against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit
from the appliance.
2
PORTABLE CART WARNING
(symbol provided by RETAC)
S3126A
3K10601B P01-03 21/08/2001, 14:294
13. LIGHTNING
To protect your unit during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it
from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the unit due to lightning
and power line surges.
14. POWER LINES
An outside antenna system should not be located in the vicinity of overhead power lines, or other electric light or
power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system,
extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.
15. OVERLOADING
Do not overload wall outlets and extension cords as this can result in a risk of fire or electric shock.
16. OBJECT AND LIQUID ENTRY
Do not push objects through any openings in this unit as they may touch dangerous voltage points or short out parts
that could result in fire or electric shock. Never spill or spray any type of liquid into the unit.
17. OUTDOOR ANTENNA GROUNDING
If an outside antenna or cable system is connected to the unit, be sure the antenna or cable system is grounded to
provide some protection against voltage surges and built-up static charges. Section 810 of the National Electrical
Code, ANSI/NFPA 70, provides information with respect to proper grounding of the mast and supporting structure,
grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.
18. SERVICING
Do not attempt to service this unit yourself as opening or removing covers may expose you to dangerous voltage or
other hazards. Refer all servicing to qualified service personnel.
19. DAMAGE REQUIRING SERVICE
Unplug this unit from the wall outlet and refer servicing to qualified service personnel under the following conditions:
a. When the power-supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into the unit.
c. If the unit has been exposed to rain or water.
d. If the unit does not operate normally by following the operating instructions. Adjust only those controls that are
covered by the operating instructions, as an improper adjustment of other controls may result in damage and
will often require extensive work by a qualified technician to restore the unit to its normal operation.
e. If the unit has been dropped or the cabinet has been damaged.
f. When the unit exhibits a distinct change in performance, this indicates a need for service.
20. REPLACEMENT PARTS
When replacement parts are required, be sure the service technician uses replacement parts specified by the manufacturer or those that have the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric shock or other hazards.
21. SAFETY CHECK
Upon completion of any service or repairs to this unit, ask the service technician to perform safety checks to determine
that the unit is in proper operating condition.
22. HEAT
The product should be situated away from heat sources such as radiators, heat registers, stoves, or other products
(including amplifiers) that produce heat.
23. NOTE TO CATV SYSTEM INSTALLER
This reminder is provided to call the CATV system installer's attention to Article 820-40 of the NEC that provides
guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding
system of the building, as close to the point of cable entry as practical.
Toshiba
Welcome to
Important
Important
Safeguards
Safeguards
your TV
Connecting
Using the
Remote Control
your TV
Setting up
EXAMPLE OF ANTENNA GROUNDING AS PER NATIONAL ELECTRICAL CODE
NEC-NATIONAL ELECTRICAL CODE
S2898A
3K10601B P01-03 21/08/2001, 14:295
GROUND CLAMP
ELECTRIC
SERVICE
EQUIPMENT
ANTENNA LEAD IN WIRE
ANTENNA DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING ELECTRODE SYSTEM
(NEC ART 250, PART H)
3
Features
Using the TV’s
Appendix
Connecting your TV
If you haven’t connected electronic equipment before, or you have
been frustrated in the past, you may wish to read this section. (Cables
are not supplied.)
• A coaxial cable is the standard cable that comes in from your
antenna or cable converter box. Coaxial cables use “F” connectors.
• Audio and video cables are usually color coded according to use:
yellow for video and red and white for audio. The red audio cable is
for the stereo right channel, and the white audio cable is for the
stereo (or mono) left channel. If you look at the rear panel of the TV,
you will see that the terminals are color coded in the same manner
as the cables.
• S-video cables provide better picture performance. S-video cables
can only be used with S-video compatible components.
• ColorStream
picture performance. ColorStream cables can only be used with
ColorStream compatible components.
TM
cables come in sets of three and provide the best
Caution:
Do not plug the TV in until you have finished
connecting all of your equipment.
your TV
Connecting
Connecting a VCR
This connection allows you to watch local channels and video programs,
play or record on the VCR while watching TV, and to record from one
channel while watching another channel.
ANTENNA
Coaxial Cable
AUDIO
Cable
VIDEO
Cable
ANT (75Ω)
VIDEO
L/MONO
AUDIO
S-VIDEO
R
VIDEO 1 VIDEO 2
S-Video
Cable
ColorStream
Cable
IN OUT
Y
VIDEO
B
P
L/MONO
AUDIO
P
R
R
TV
You will need:
• one coaxial cable
• one pair of audio cables (only one cable for
a mono VCR)
• one video cable
Caution:
If using a mono VCR, connect L/Mono to
VCR Audio OUT using only one audio cable.
If you have a S-VHS VCR, use the S-video
connections and remove the video cable.
Cable Lead-in
from cable box or
antenna
IN from ANT
CH 3
CH 4
3K10601B P04-11 21/08/2001, 14:284
OUT to TV
IN
OUT
VIDEO
Stereo VCR
LR
AUDIO
Note:
When the video cable and the S-video cable
to Video1 simultaneously, the S-video will
automatically take precedence.
4
Connecting a cable converter box
This television has an extended tuning range and can tune most cable
channels without using a cable company supplied converter box. Some
cable companies offer "premium pay channels" in which the signal is
scrambled. Descrambling these signals for normal viewing requires the
use of a descrambler device which is generally provided by the cable
company.
For Subscribers to Basic Cable TV Service
For basic cable service not requiring a Converter/Descrambler box,
connect the CA TV 75 ohm Coaxial Cable directly to the Antenna Jack
on the back of the television.
For Subscribers to Scrambled Cable TV Service
If you subscribe to a cable service which requires the use of a Converter/Descrambler box, connect the incoming cable to the Converter/
Descrambler box and connect the output of the box to the Antenna
Jack on the back of the television. Follow the connections shown left.
Set the television to the output of the Converter/Descrambler box
(usually channel 3 or 4) and use the Converter/Descrambler box to
select channels.
For Subscribers to Unscrambled Basic Cable with Scrambled Premium Channels
If you subscribe to a cable service in which basic cable channels are
unscrambled and premium channels require the use of a Converter/
Descrambler box, you may wish to use a two-set signal splitter (sometimes called a "two-set coupler") and an A/B Switch box from the cable
installer or an electronics supply store. Follow the connections shown
left. With the switch in the "B" position, you can directly tune any
nonscrambled channels on your TV. With the switch in the "A" position,
tune your TV to the output of the Converter/Descrambler box (usually
channel 3 or 4) and use the box to tune scrambled channels.
Note:
When you use a converter box with your TV,
there may be features that you cannot
program using the remote control, such as
labeling channels, blocking channels, and
programming your favorite channels.
Toshiba
Welcome to
Important
Safeguards
your TV
your TV
Connecting
Connecting
Using the
Remote Control
Converter/ Descrambler
Converter/ Descrambler
/
B SwitchSplitter
A
IN OUT
ANT (75Ω)
A
B
VIDEO
L/MONO
AUDIO
S-VIDEO
R
VIDEO 1 VIDEO 2
Y
VIDEO
B
P
L/MONO
AUDIO
P
R
R
your TV
Setting up
Features
Using the TV’s
5
Appendix
3K10601B P04-11 21/08/2001, 14:285
Connecting a DVD/satellite receiver and a VCR
This connection allows you to watch DVD/satellite, video and TV
programs. You can record from the DVD/satellite receiver and TV, as
well as record one TV channel while watching another channel.
To satellite
To antenna
your TV
Connecting
DVD / Satellite Receiver
OUT
Satellite IN
S-VIDEO
L
R
AUDIO
TV
ANT (75Ω)
VIDEO
L/MONO
S-VIDEO
AUDIO
R
VIDEO 1 VIDEO 2
Stereo VCR
IN from ANT
CH 3
CH 4
OUT to TV
IN OUT
OUT
Y
VIDEO
B
P
L/MONO
AUDIO
PR
R
IN
LR
VIDEO
AUDIO
You will need:
• one coaxial cable
• two pairs of audio cables (only one cable
for a mono VCR)
• one video cable
• one S-video cable
Caution:
You can use a video cable instead of the
S-video cable, but the picture quality will
decrease. If you use a S-video cable between
the TV and DVD/satellite receiver, make the
audio connections only and remove the video
connection.
Connecting a DVD with ColorStream™ and a VCR
This connection allows you to watch DVD, video or TV programs and to
record DVD or TV programs. You can record from one source and
watch a program from another source. Your TV is capable of using
ColorStream (component video). Connecting your TV to a ColorStream
compatible DVD, such as a Toshiba DVD, can greatly enhance picture
quality and performance.
DVD Player with ColorStream™
OUT
L
TM
COLORSTREAM
YCbCr
Y
VIDEO
P
B
L/MONO
AUDIO
P
R
R
To antenna
S-VIDEO
TV
ANT (75Ω)
Stereo VCR
VIDEO
L/MONO
S-VIDEO
R
VIDEO
AUDIO
OUT
IN OUT
AUDIO
R
VIDEO 1 VIDEO 2
You will need:
• one coaxial cable
• three pairs of audio cables (only one cable
for a mono VCR)
• two video cables
• one set of ColorStream video cables
Caution:
To play from the DVD, the DVD and TV must
use ColorStream connections. To record from
the DVD, the DVD and TV must select Video.
The ColorStream selection in the OPTION
menu should be DVD mode. See “Selecting
the ColorStream mode” on page 21.
3K10601B P04-11 21/08/2001, 14:286
IN from ANT
CH 3
CH 4
OUT to TV
IN
OUT
VIDEO
LR
AUDIO
6
Connecting two VCRs
This connection allows you to record from one VCR to another VCR
while watching a video program. You will also be able to record from
one TV channel while watching another channel.
To antenna
Stereo VCR / Playback
IN from ANT
OUT to TV
CH 3
CH 4
TV
ANT (75Ω)
VIDEO
L/MONO
S-VIDEO
AUDIO
R
VIDEO 1 VIDEO 2
Stereo VCR/ Recording
OUT to TV
IN from ANT
CH 3
CH 4
IN
OUT
LR
VIDEO
AUDIO
IN OUT
IN
OUT
VIDEO
Y
B
P
P
R
LR
AUDIO
VIDEO
L/MONO
AUDIO
R
Connecting a camcorder
You will need:
• one coaxial cable
• two pairs of audio cables (only two cables
for mono VCRs)
• two video cables
Caution:
Do not connect one VCR to the output and
input jacks on the TV at the same time. If you
are using a S-VHS VCR, use the S-video
connections and remove the video cable.
Toshiba
Welcome to
Important
Safeguards
your TV
your TV
Connecting
Connecting
This connection allows you to watch video materials recorded on a
camcorder.
Camcorder
AUDIO
VIDEO
L
R
OUT
AUDIO
VIDEO 3 L/MONO
R PHONES
Front Panel of TV
Connecting an audio amplifier
This connection allows you to use an audio amplifier to enjoy a highquality sound. This also allows you to use external speakers.
To control the audio, turn on the TV and the stereo amplifier. You will
need one pair of audio cables.
Audio Amplifier
AUDIO
LR
IN
OUT
You will need:
• one pair of audio cables
• one video cable
Caution:
If you are using a S-VHS camcorder with a
S-video output, use the Video1 jacks on the
back of the TV.
Using the
Remote Control
your TV
Setting up
Features
Using the TV’s
T o cable,
cable box or
antenna
3K10601B P04-11 21/08/2001, 14:297
TV
ANT (75Ω)
VIDEO
L/MONO
S-VIDEO
IN OUT
AUDIO
R
VIDEO 1 VIDEO 2
Y
VIDEO
B
P
L/MONO
AUDIO
P
R
R
7
Appendix
Using the remote control
Preparing the remote control for use
With the remote control, you can operate your TV, most VCR models,
and cable TV converters together , even if they are different brands. If
you will be using your TV with a Toshiba VCR, your remote control is
already programmed and ready to use. If you own different brands of
VCRs and/or converters, you first have to program your remote control.
(See “Programming the remote control for use with a VCR or a cable
TV converter” on page 9.)
Installing the remote control batteries
To install the batteries:
1. Open the battery cover of the back of the remote control.
2. Install two “AAA” size batteries. Match the + and – signs on the
batteries to the signs on the battery compartment.
Note:
This remote control’s functions may or may
not operate your VCR or cable TV converter.
Refer to the owner’s manuals supplied with
the equipment to see which features are
available. In addition, the original controllers
may have features not available on this
remote control. If you would like to continue to
use these features, you may want to use the
original remote control.
Caution:
• Dispose of your batteries in a designated
disposal area. Do not throw your batteries
into a fire.
• Do not mix battery types or combine used
batteries with new ones.
• Remove dead batteries immediately to
prevent battery acid from leaking into the
battery compartment.
• If you do not intend to use the remote control
for a long time, remove the batteries.
Using the
Remote Control
3. Close the battery cover on to the remote control until the lock snaps.
Using the remote control with a VCR or a cable TV converter
To control a Toshiba
VCR:
Press the VCR button
first. The buttons
shown to the right will
then control the VCR.
The rest of the buttons
will operate the TV as
usual.
VCR
Power
Enter
Channel
Numbers
Fast Forward
Play
Rewind
TV/VCR
Record
Stop
VCR CH ▲/▼
Pause/Still
POWER
TV VCR CABLE
123
456
789
+
CH
VOL
MENU/
ENTER
–
CH
RESET CAP/TEXT 1/2
CODE MTS SLEEP MUTE
PLAY
REW FF
STOP
TV/VCR
REC
CH RTN
PAUSE/STILL
VCR CH
ENT
100
FAVEXIT RECALL TV/VIDEO
FAV
To control a cable TV
converter:
Program the remote
control to recognize the
brand of your converter
0
(see “Programming the
remote control for use
VOL
+–
with a VCR or cable TV
converter”, on page 9).
The buttons shown on
the right will control the
cable TV converter. Press
the CABLE button first.
Cable
Power
Enter
Channel
Numbers
Channel +/–
POWER
TV VCR CABLE
123
456
789
+
CH
VOL
MENU/
ENTER
–
CH
RESET CAP/TEXT 1/2
CODE MTS SLEEP MUTE
PLAY
REW FF
STOP
TV/VCR
REC
CH RTN
PAUSE/STILL
VCR CH
ENT
100
FAVEXIT RECALL TV/VIDEO
FAV
0
VOL
+–
3K10601B P04-11 21/08/2001, 14:298
8
Loading...
