Safeguards
Important
Welcome to
Toshiba
Connecting
your TV
Remote Control
Using the
Setting up
your TV
Using the TV’s
Features
27A35C
3U50101A(E)_COVER 3/31/05, 6:18 PM1
Appendix
Dear Customer,
Thank you for purchasing this Toshiba TV. This manual will
Important
help you use the many exciting features of your new TV.
Safeguards
Before operating the TV, please read this manual
completely, and keep it nearby for future reference.
Child Safety
It Makes A Difference
Where Your TV Stands
Safety Precautions
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE.
WARNING: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning symbol in the triangle tells you that the
voltage inside this product may be strong enough to
cause an electric shock. DO NOT TRY TO SERVICE
THIS PRODUCT YOURSELF.
The exclamation mark in the triangle tells you that
important operating and maintenance instructions
follow this symbol.
CAUTION: To reduce the risk of electric shock, do not
use the polarized plug with an extension cord,
receptacle, or other outlet unless the blades can be
inserted completely to prevent blade exposure.
Congratulations on your purchase! As you enjoy
your new TV, keep these safety tips in mind:
The Issue
If you are like most consumers, you have a TV in your home.
Many homes, in fact, have more than one TV.
The home theater entertainment experience is a growing
trend, and larger TVs are popular purchases; however, they
are not always supported on the proper TV stands.
Sometimes TVs are improperly secured or inappropriately
situated on dressers, bookcases, shelves, desks, audio
speakers, chests, or carts. As a result, TVs may fall over,
causing unnecessary injury.
Toshiba Cares!
The consumer electronics industry
is committed to making home
entertainment enjoyable and safe.
The Consumer Electronics
Association formed the Home
Entertainment Support Safety
Committee, comprised of TV and
consumer electronics furniture
manufacturers, to advocate
children’s safety and educate
consumers and their families about
television safety.
NOTE TO CATV INSTALLERS
This is a reminder to call the CATV system installer’s
attention to Article 820-40 of the NEC, which provides
guidelines for proper grounding and, in particular, specifies
that the cable ground shall be connected to the grounding
system of the building, as close to the point of cable entry
as practical. For additional antenna grounding information,
see items 25 and 26 on page 4.
NOTICE OF POSSIBLE ADVERSE
EFFECTS ON TV PICTURE DISPLAY
If a fixed (non-moving) pattern or image remains on the
TV screen for extended periods of time, the image can
become permanently ingrained in the cathode ray
tube(s) of the TV and cause subtle but permanent ghost
images. This type of damage is NOT COVERED BY
YOUR WARRANTY. See page 4 for details.
2
Tune Into Safety
One size does NOT fit all! Use appropriate
furniture large enough to support the weight of your
TV (and other electronic components).
Use appropriate angle braces, straps, and anchors to secure
your furniture to the wall (but never screw anything directly
into the TV).
Carefully read and understand the other enclosed
instructions for proper use of this product.
Do not allow children to climb on or play with furniture
and TVs.
Avoid placing any item on top of your TV (such as a VCR,
remote control, or toy) that a curious child may reach for.
Remember that children can become excited while watching
a program and can potentially push or pull a TV over.
Share our safety message about this hidden hazard of
home with your family and friends. Thank you!
2500 Wilson Blvd.
Arlington, VA 22201 U.S.A.
Tel. 703-907-7600 Fax 703-907-7690
www.CE.org
CEA is the Sponsor, Producer and
Manager of the International CES
0303
2
the
®
3U50101A(E)_P02-06 3/31/05, 6:18 PM2
Important Safety Instructions
QUALIFIED
SERVICE
TECHNICIAN
Installation, Care, and Service
Safeguards
Safeguards
Important
Important
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near
water.
6) Clean only with a dry cloth.
7) Do not block any ventilation
openings. Install in accordance with
the manufacturer’s instructions.
8) Do not install near any heat
sources such as radiators,
heat registers, stoves, or other
apparatus (including amplifiers)
that produce heat.
9) Do not defeat the safety purpose of the polarized or
grounding type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has
two blades and a third grounding
prong. The wide blade or the third
prong are provided for your safety.
If the provided plug does not fit into
your outlet, consult an electrician
for replacement of the obsolete outlet.
Wide plug
Installation
Follow these recommendations and precautions and heed all
warnings when installing your TV:
16) Never modify this equipment. Changes or modifications
may void: a) the warranty, and b) the user’s authority to
operate this equipment under the rules of the Federal
Communications Commission.
17) DANGER: RISK OF SERIOUS PERSONAL
INJURY, DEATH, OR EQUIPMENT
DAMAGE! Never place the TV on
an unstable cart, stand, or table. The TV
may fall, causing serious personal injury,
death, or serious damage to the TV.
18) Never place or store the TV in direct
sunlight; hot, humid areas; areas
subject to excessive dust or vibration;
or locations with temperatures at or
below 41°F (5°C).
19) Always place the TV on the floor
or a sturdy, level, stable surface that
can support the weight of the unit.
Welcome to
Toshiba
Connecting
your TV
Remote Control
Using the
10) Protect the power cord from being
walked on or pinched, particularly at
plugs, convenience receptacles, and
the point where it exits the apparatus.
11) Only use attachments/accessories specified by the
manufacturer.
12) Use only with the cart, stand, tripod,
bracket, or table specified by the
manufacturer, or sold with the
apparatus. When a cart is used, use
caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13) Unplug this apparatus during
lightning storms or when
unused for long periods
of time.
14) Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power supply
cord or plug is damaged, liquid has
been spilled or objects have fallen into
the apparatus, the apparatus has been
exposed to rain or moisture, does not
operate normally, or has been dropped.
15) CAUTION: To reduce the risk of electric shock, do
not use the polarized plug with an extension cord,
receptacle, or other outlet unless the blades can
be inserted completely to prevent blade exposure.
20) Never place items such as vases,
aquariums, or candles on top of the TV.
21) Never block or cover the slots or
openings in the TV cabinet back,
bottom, and sides. Never place
the TV:
• on a bed, sofa, rug, or similar
surface;
• too close to drapes, curtains,
or walls; or
• in a confined space such as a
bookcase, built-in cabinet, or any
other place with poor ventilation.
The slots and openings are provided
to protect the TV from overheating
and to help maintain reliable
operation of the TV.
22) Never allow anything to rest on or roll over the power
cord, and never place the TV where the power cord is
subject to wear or abuse.
23) Never overload wall outlets and
extension cords.
0303
3
3
Setting up
your TV
Using the TV’s
Features
Appendix
3U50101A(E)_P02-06 3/31/05, 6:18 PM3
24) Always operate this equipment from
Ground clamp
Antenna discharge unit
(NEC Section 810-20)
Grounding conductors
(NEC Section 810-21)
Power service grounding
electrode system (NEC Art 250 Part H)
Ground clamps
Antenna lead-in wire
Electric service equipment
QUALIFIED
SERVICE
TECHNICIAN
Important
Safeguards
a 120V AC, 60 Hz power source only.
30) [This item applies to projection TVs only.] If the air
temperature rises suddenly (for example, when the TV is
first delivered), condensation may form on the lenses. This
can make the picture appear distorted or the color appear
faded. If this happens, turn off the TV for 6 to 7 hours to
allow the condensation to evaporate.
25) Always make sure the antenna system is properly
grounded to provide adequate protection against voltage
surges and built-up static charges (see Section 810 of the
National Electric Code).
26) DANG ER: RISK OF SERIOUS PERSONAL
INJURY OR DEATH!
• Use extreme care to make sure you are never in
a position where your body (or any item you are in contact
with, such as a ladder or screwdriver) can accidentally
touch overhead power lines. Never locate the antenna
near overhead power lines or other electrical circuits.
• Never attempt to install any of the following during
lightning activity:
a) an antenna system; or b) cables, wires, or any home
theater component connected to an antenna or phone
system.
Care
31)For added protection of your TV from lightning and power
surges, always unplug the power cord and disconnect the
antenna from the TV if you leave the TV unattended or
unused for long periods of time.
32) During normal use, the TV may make
occasional snapping or popping
sounds. This is normal, especially
when the unit is being turned on or
off. If these sounds become frequent
or continuous, unplug the power cord
and contact a Toshiba Authorized Service Center.
33) Possible Adverse Effects on TV Picture Display: If a
fixed (non-moving) pattern or image remains on the TV
screen for extended periods of time, the image can become
permanently ingrained in the cathode ray tube(s) of the TV
and cause subtle but permanent ghost images. This type
of damage is NOT COVERED BY YOUR WARRANTY.
Never leave the TV on for extended periods of time while it
is displaying the following images or formats:
• Fixed Images, including but not limited to PIP/POP
windows, closed captions, video game patterns, TV
station logos, stock tickers, and websites.
• Special Formats that do not use the entire screen,
including but not limited to widescreen or letterbox format
media viewed on a 4:3 aspect ratio display (with gray or
black bars at the top and bottom of the screen); or 4:3
aspect ratio format media viewed on a widescreen/16:9
aspect ratio display (with gray or black bars on the left
and right sides of the screen).
For better performance and safer operation of your TOSHIBA
TV, follow these recommendations and precautions:
27) Always sit approximately 10–25 feet away from the TV and
as directly in front of it as possible. The picture can appear
dull if you sit too far to the left or right of the TV, or if
sunlight or room lights reflect on the screen. Turn the TV
off to check for reflections on the screen, and then remove
the source of reflections while viewing the TV.
28) Always unplug the TV before
cleaning. Never use liquid or
aerosol cleaners.
29) WARNING: RISK OF ELECTRIC SHOCK!
Never spill liquids or push objects of any kind
into the TV cabinet slots.
Service
34) WARNING: RISK OF ELECTRIC
SHOCK! Never attempt to service the
TV yourself. Opening and
removing the covers may expose
you to dangerous voltage or other
hazards. Refer all servicing to a
Toshiba Authorized Service Center.
35) If you have the TV serviced:
• Ask the service technician to use only replacement parts
specified by the manufacturer.
• Upon completion of service, ask
the service technician to perform
routine safety checks to determine
that the TV is in safe operating
condition.
36)When the TV reaches the end of its useful life, ask a
qualified service technician to properly dispose of the TV.
Improper disposal may result in a picture tube implosion
0303
and possible personal injury.
4
4
3U50101A(E)_P02-06 3/31/05, 6:18 PM4
Important Safety Information .......................................................................................... 2-4
Welcome to Toshiba ............................................................................................................ 6
Exploring your new TV ................................................................................................................................ 6
Selecting a location for the TV ....................................................................................................................6
Connecting your TV ............................................................................................................ 7
Connecting a VCR .......................................................................................................................................7
Connecting a cable converter box ...............................................................................................................8
Connecting a DVD player/satellite receiver and a VCR .............................................................................. 9
Connecting a DVD player with ColorStream® (component video) and a VCR ............................................ 9
Connecting a camcorder ........................................................................................................................... 10
Using the remote control.................................................................................................. 11
Installing the remote control batteries ....................................................................................................... 11
Learning about the remote control ............................................................................................................ 11
Setting up your TV ............................................................................................................. 12
Changing the on-screen display language ................................................................................................ 12
Adding channels to the TV’s memory ........................................................................................................13
Programming channels automatically ................................................................................................ 13
Adding and erasing channels manually ............................................................................................. 13
Changing channels .................................................................................................................................... 13
Using the TV’s features ..................................................................................................... 14
Adjusting the channel settings ................................................................................................................... 14
Switching between two channels ....................................................................................................... 14
Programming your favorite channels ..................................................................................................14
Using the LOCK menu ............................................................................................................................... 15
Selecting a PIN code .......................................................................................................................... 15
Locking channels ................................................................................................................................16
Locking video input .............................................................................................................................17
Setting the GameTimerTM..........................................................................................................................17
Labeling channels ...................................................................................................................................... 18
Setting the clock ........................................................................................................................................ 19
Setting the ON/OFF timer ..........................................................................................................................19
Setting the ON timer ........................................................................................................................... 19
Setting the OFF timer .........................................................................................................................20
Adjusting the picture quality ......................................................................................................................21
Watching video input ................................................................................................................................. 21
Specifying the ColorStream® setting .........................................................................................................21
Displaying TV status information on-screen ..............................................................................................21
Setting the sleep timer ...............................................................................................................................22
Using the closed caption feature ...............................................................................................................22
Adjusting the sound ...................................................................................................................................23
Muting the sound ................................................................................................................................23
Selecting stereo/SAP broadcasts ....................................................................................................... 23
Adjusting the sound quality ................................................................................................................ 23
Using the surround sound feature ...................................................................................................... 24
Using the StableSound® feature ......................................................................................................... 24
Auto power off............................................................................................................................................ 24
Understanding the Power Return feature ..................................................................................................24
Appendix ............................................................................................................................ 25
Troubleshooting ......................................................................................................................................... 25
Specifications............................................................................................................................................. 26
Limited Canada Warranty ..........................................................................................................................27
Safeguards
Safeguards
Important
Important
Welcome to
Toshiba
Connecting
your TV
Remote Control
Using the
Setting up
your TV
Using the TV’s
Features
3U50101A(E)_P02-06 3/31/05, 6:18 PM5
Appendix
5
Welcome to Toshiba
Congratulations! You have purchased one of the finest color TVs on
the market. The goal of this manual is to guide you through setting up
and operating your Toshiba TV as quickly as possible.
You may need to purchase other audio or video cables to connect your
equipment. See “Connecting your TV” on page 7 for more information.
Please read all the safety and operating instructions carefully before
you begin.
Exploring your new TV
You can operate your TV by using the buttons on the front panel or the
Toshiba
Welcome to
remote control. The front and back panels provide all the inputs you will
need to connect other equipment to your TV.
POWER
Remote sensor
TV front panel
TV back panel
Power indicator
ANT (75Ω)
Channel
VIDEO
S-VIDEO
L/
MONO
AUDIO
R
Audio(L/R)Video in
Volume
IN
Y
P
P
VIDEO 1
B
R
Selecting a location for the TV
• Place the TV on the floor or on a sturdy platform in a location where
light does not directly hit the screen.
• Place the TV far enough from the walls to allow proper ventilation.
Inadequate ventilation may cause overheating, which may damage
the TV.
3U50101A(E)_P02-06 3/31/05, 6:18 PM6
6
Connecting your TV
• A coaxial cable is the standard cable that comes in from your
antenna or cable converter box. Coaxial cables use “F” connectors.
• Standard A/V (audio/video) cables are usually color coded accord-
ing to use: yellow for video and red and white for audio. The red
audio cable is for the stereo right channel, and the white audio
cable is for the stereo left (or mono) channel. If you look at the rear
panel of the TV, you will see that the terminals are color coded in
the same manner as the cables.
• An S-video cable provides better picture performance than a
standard video cable. S-video cables can only be used with S-video
compatible components.
• Component video cables come in sets of three and provide the best
picture performance. Component video cables can only be used
with component video compatible components.
ANTENNA
Coaxial Cable
S-Video
Cable
NOTICE: RISK OF
EQUIPMENT DAMAGE!
Do not plug in any power cords
until you have finished connecting
all equipment.
Safeguards
Important
Welcome to
Toshiba
Connecting
Connecting
your TV
your TV
AUDIO
Cables
VIDEO
Cable
Component video
Cables
Connecting a VCR
This connection allows you to watch local channels and video programs,
play or record on the VCR while watching TV, and record from one
channel while watching another channel.
TV
IN
AUDIO
R
Y
P
P
VIDEO 1
OUT
B
R
Stereo VCR
IN
LR
VIDEO
AUDIO
Cable Lead-in
from cable box
or antenna
ANT (75Ω)
IN from ANT
CH 3
CH 4
S-VIDEO
OUT to TV
VIDEO
L/
MONO
You will need:
• two coaxial cables
• one set of standard A/V cables
Note:
If using a mono VCR, connect L/Mono to
VCR Audio OUT using only one audio cable.
For better picture quality, if your VCR has
S-video, you can use an S-video cable
instead of the standard video cable. Do not
connect a standard video cable and an
S-video cable to VIDEO1 simultaneously.
The unauthorized recording, use,
distribution or revision of television
programs, videotapes, DVDs, and other
materials is prohibited under the
Copyright Laws of the United States and
other countries, and may subject you to
civil and criminal liability.
Remote Control
Using the
Setting up
your TV
Using the TV’s
Features
Appendix
3U50101A(E)_P07-13 3/31/05, 6:18 PM7
7
Connecting a cable converter box
This television has an extended tuning range and can tune most cable
channels without using a cable company supplied converter box. Some
cable companies offer “premium pay channels” in which the signal is
scrambled. Descrambling these signals for normal viewing requires the
use of a descrambler device, which is generally provided by the cable
company.
For Subscribers to Basic Cable TV Service
For basic cable service not requiring a Converter/Descrambler box,
connect the CATV 75 ohm Coaxial Cable directly to the Antenna Jack
on the back of the television.
For Subscribers to Scrambled Cable TV Service
If you subscribe to a cable service that requires the use of a Converter/
Descrambler box, connect the incoming cable to the Converter/
Descrambler box and connect the output of the box to the Antenna
Jack on the back of the television. Follow the connections shown
below. Set the television to the output of the Converter/Descrambler
box (usually channel 3 or 4) and use the Converter/Descrambler box to
select channels.
your TV
Connecting
For Subscribers to Unscrambled Basic Cable with
Scrambled Premium Channels
If you subscribe to a cable service in which basic cable channels are
unscrambled and premium channels require the use of a Converter/
Descrambler box, you may wish to use a two-set signal splitter (sometimes called a “two-set coupler”) and an A/B Switch box from the cable
installer or an electronics supply store. Follow the connections shown
below. With the switch in the “B” position, you can directly tune any
nonscrambled channels on your TV. With the switch in the “A” position,
tune your TV to the output of the Converter/Descrambler box (usually
channel 3 or 4) and use the box to tune scrambled channels.
Note:
When you use a converter box with your TV,
there may be features that you cannot
program using the remote control, such as
labeling channels, blocking channels, and
programming your favorite channels.
Incoming CATV
Converter/Descrambler
Converter/Descrambler
A
/
B SwitchSplitter
IN
AUDIO
R
Y
P
P
VIDEO 1
B
R
S-VIDEO
VIDEO
L/
MONO
ANT (75Ω)
A
B
3U50101A(E)_P07-13 3/31/05, 6:18 PM8
8
Connecting a DVD player/satellite receiver
and a VCR
This connection allows you to watch DVD/satellite, VCR, or TV
programs. You can record from the satellite receiver and TV, as well as
record one TV channel while watching another channel.
To satellite
DVD player/ Satellite Receiver
VIDEO AUDIO
Satellite IN
S-VIDEO
OUT to TV
OUT
Stereo VCR
LR
You will need:
• three coaxial cables
• one set of standard A/V cables
• one S-video cable
• one pair of standard audio cables
Note:
You can use a standard video cable instead of
the S-video cable, but the picture quality will
decrease. If you use an S-video cable
between the TV and DVD player/satellite
receiver, make the audio connections only
and remove the standard video cable.
Safeguards
Important
Welcome to
Toshiba
ANT (75Ω)
IN
OUT
VIDEO AUDIO
VIDEO
L/
MONO
S-VIDEO
LR
IN
Y
P
AUDIO
P
R
VIDEO 1
B
R
®
IN from ANT
OUT to TV
CH 3
CH 4
TV
Connecting a DVD player with ColorStream
(component video) and a VCR
This connection allows you to watch DVD, VCR, or TV programs and
record TV programs. You can record one TV channel while watching
another channel or a DVD. Your TV is capable of using ColorStream
(component video). Connecting your TV to a component video compatible
DVD player, such as a Toshiba DVD player with ColorStream®, can
greatly enhance picture quality and performance.
L
OUT
AUDIO
IN
VIDEO 1
Y
P
B
P
R
IN
OUT
®
VIDEO
VIDEO
OUT
COLORSTREAM
YCbCr
LR
AUDIO
TM
To antenna
DVD player with ColorStream
R
S-VIDEO
TV
S-VIDEO
VIDEO
L/
MONO
AUDIO
R
ANT (75Ω)
Stereo VCR
IN from ANT
CH 3
CH 4
OUT to TV
You will need:
• two coaxial cables
• one set of component video cables
• one pair of standard audio cables
Note:
The ColorStream inputs on this TV are for use
with devices that output 480i interlaced
signals ONLY. This TV will not accept or
display 480p or 720p progressive scan
signals or 1080i interlaced high-definition
signals. If you connect a high-definition settop receiver, 480p progressive scan DVD
player, or other similar device to the TV’s
ColorStream inputs, YOU MUST SWITCH
THE DEVICE’S OUTPUT TO 480i INTERLACED MODE FIRST. Failure to do this will
cause a poor picture or no picture to display.
The unauthorized recording, use,
distribution or revision of television
programs, videotapes, DVDs, and other
materials is prohibited under the
Copyright Laws of the United States and
other countries, and may subject you to
civil and criminal liability.
Connecting
Connecting
your TV
your TV
Remote Control
Using the
Setting up
your TV
Using the TV’s
Features
Appendix
3U50101A(E)_P07-13 3/31/05, 6:18 PM9
9
Connecting a camcorder
This connection allows you to watch video materials recorded on a
camcorder.
You will need:
• one set of standard A/V cables
your TV
Connecting
Front Panel of TV
VIDEO
OUT
AUDIO
L
R
Camcorder
Note:
For better picture quality, if your camcorder
has S-video, you can connect an S-video
(and standard audio cables) to VIDEO1 on
the back of the TV. Do not connect a standard
video cable and an S-video cable to VIDEO1
simultaneously.
3U50101A(E)_P07-13 3/31/05, 6:18 PM10
10
Using the remote control
Installing the remote control batteries
Safeguards
Important
To install the batteries:
1. Open the battery cover on the back of the remote control.
2. Install two “AAA” size batteries. Match the + and – signs on the
batteries to the signs on the battery compartment.
3. Close the battery cover on the remote control until the lock snaps.
Caution:
Never throw batteries into a fire.
Notes:
• Be sure to use AAA size batteries.
• Dispose of batteries in a designated
disposal area.
• Batteries should always be disposed of with
the environment in mind. Always dispose of
batteries in accordance with applicable laws
and regulations.
• If the remote control does not operate
correctly, or if the operating range becomes
reduced, replace batteries with new ones.
• When necessary to replace batteries in the
remote control, always replace both
batteries with new ones. Never mix battery
types or use new and used batteries in
combination.
• Always remove batteries from remote
control if they are dead or if the remote
control is not to be used for an extended
period of time. This will prevent battery acid
from leaking into the battery compartment.
Welcome to
Toshiba
Connecting
your TV
Remote Control
Remote Control
Using the
Using the
Learning about the remote control
POWER turns the TV on and off
CHANNEL NUMBERS allow direct access to channels (page 13)
RECALL displays status information on-screen (page 21)
SLEEP programs the TV to turn off at a set time (page 22)
MUTE turns off the sound (page 23)
CH + / – cycles through programmed channels (page 13)
VOLUME + / – adjusts the volume level
MENU/ENTER allows access to programming menus, and sets
programmed menu information (page 12)
EXIT exits programming menus (page 12)
CAP/TEXT turns closed captions or text on and off (page 22)
1/2 selects closed caption/text channel 1 or 2 (page 22)
RESET returns settings to preset factory formats (pages 21 and 23)
CH RTN (Channel Return) returns to the last viewed channel (page
14)
MTS switches among STEREO, SAP, and MONO sound (page 23)
TV/VIDEO selects the video input source (page 21)
FAV
▲/ ▼
(Favorite Channels) cycle through favorite channels
(page 14)
'
$%
(
)
&
$%
#
!"
Setting up
your TV
Using the TV’s
Features
Appendix
3U50101A(E)_P07-13 3/31/05, 6:18 PM11
11
Setting up your TV
After you have installed the batteries and programmed the remote
control, you need to set some preferences on the TV using the menu
system. You can access the menu system with the buttons on the
remote control.
• When you make a menu selection, your changes occur immediately.
You do not have to press MENU or EXIT to see your changes.
• After 15 seconds, the menu screen will automatically close if you do
not make a selection. Your changes will still be saved.
• When you are finished programming the menus, press EXIT.
Changing the on-screen display language
You can choose from three different languages (English, French, and
Spanish) for the on-screen display of adjustment menus and
messages.
To select a language:
1. Press MENU, then press
PICTURE AUDIO SETUPCHOPTION
LANGUAGE
CH LABEL START
FAVORITE CH
LOCK
ON/OFF TIMER
COLORSTREAM
SELECT ADJUST
ENGLISH
START
START
OFF
DVD
or until the OPTION menu appears.
Exit
Menu
your TV
Setting up
2. Press
PICTURE AUDIO SETUPCHOPTION
LANGUAGE
CH LABEL START
FAVORITE CH
LOCK
ON/OFF TIMER
COLORSTREAM
SELECT ADJUST
3. Press
or to highlight your desired language.
or to highlight LANGUAGE.
ENGLISH FRANCAIS
ESPANOL
START
START
OFF
DVD
3U50101A(E)_P07-13 3/31/05, 6:18 PM12
12
Adding channels to the TV’s memory
When you press CH +/- on the remote control or CHANNEL ▼/▲ on
the TV front panel, your TV will stop only on the channels stored in the
TV’s channel memory. Follow the steps below to program channels into
the memory.
Safeguards
Important
Programming channels automatically
Your TV can automatically detect all active channels and store them in
its memory. After the TV has stored the channels in its memory automatically, you can add or erase specific channels manually.
To add channels automatically:
1. Press MENU, then press or to display the SETUP menu.
2. Press
CABLE selection is highlighted.
3. Press or to highlight either TV
or CABLE, depending on which
you use.
If you use an antenna, choose TV.
If you use cable, choose CABLE.
4. Press
5. Press or to start channel programming. The TV will automatically cycle through all the TV or Cable channels (depending on
which you selected), and store all active channels in the channel
memory.
While the TV is cycling through the channels, the message
“PROGRAMMING NOW-PLEASE WAIT” appears.
6. When channel programming is complete, the message “COMPLETED”
appears.
7. Press CH + or – to view the programmed channels.
or until the TV/
to select CH PROGRAM.
PICTURE AUDIO SETUP OPTION
TV / CABLE TV CABLE
CH PROGRAM
ADD / ERASE
SELECT ADJUST
CH
START
ADD
Welcome to
Toshiba
Channel
Numbers
Connecting
your TV
Channel +/–
Menu
Remote Control
Using the
Adding and erasing channels manually
After you have programmed the channels automatically, you can add
or erase specific channels manually.
To add or erase channels manually:
1. Select the channel you want to add or erase.
If you are adding a channel, you must select the channel using the
Channel Number buttons.
2. Press MENU, then press
to display the SETUP menu.
3. Press
or to highlight ADD/
ERASE.
4. Press or to select ADD or
or
PICTURE AUDIO SETUP OPTION
CH
TV / CABLE CABLE
CH PROGRAM START
ADD / ERASE ADD ERASE
ERASE, whichever function you
want to perform.
5. Repeat steps 1–4 for other
SELECT ADJUST
channels you want to add or erase.
Changing channels
To change to the next programmed channel:
▲/ ▼
Press CHANNEL
remote control.
To change to a specific channel (programmed or unprogrammed):
Press the Channel Number buttons (0–9 and 100) on the remote
control.
For example, to select channel 125, press 100, 2, 5.
on the TV front panel or CH +/– on the
Setting up
Setting up
your TV
your TV
Using the TV’s
Features
Appendix
3U50101A(E)_P07-13 3/31/05, 6:18 PM13
13
Using the TV’s features
Adjusting the channel settings
Switching between two channels
You can switch between two channels without entering an actual
channel number each time.
To switch between two channels:
1. Select the first channel you want to view.
2. Select a second channel using the Channel Number buttons (0–9,
100).
3. Press CH RTN. The previous channel will be displayed.
Each time you press CH RTN, the TV will switch back and forth
between the two channels.
Programming your favorite channels
You can preset up to 12 of your favorite channels using the Favorite
Channel Programming feature. Because this feature scans through
only your favorite channels, it allows you to skip other channels you
do not normally watch.
You can still use Channel + / – to scan through all the channels you
programmed in the TV’s memory.
To program your favorite channels:
1. Select a channel you want to program as a favorite channel.
2. Press MENU, then press
3. Press or to highlight FAVORITE CH.
or to display the OPTION menu.
Channel
Numbers
CH RTN
Features
Using the TV’s
PICTURE AUDIO SETUPCHOPTION
CH LABEL START
FAVORITE CH
LOCK
ON/OFF TIMER
COLORSTREAM
SELECT START
4. Press
ENGLISHLANGUAGE
START
START
OFF
DVD
or to display the FAVORITE CH menu. SET/CLEAR will
be highlighted.
PICTURE AUDIO SETUPCHOPTION
FAVORITE CH : CH 012
SET/CLEAR SET CLEAR
SET UP CH
TV CABLE
SELECT
END EXIT
5. Press
or to highlight SET and press ENTER.
0000
0000
0000
SET ENTER
6. Press EXIT to close the screen.
7. Repeat steps 1–6 for up to 12 channels.
To select your favorite channels:
Press the FAV ▲ ▼ buttons on the remote control to select your
favorite channels.
The FAV ▲ ▼ buttons will not work until you have programmed
your favorite channels.
Channel
Numbers
Exit
Menu/
Enter
FAV
FAV
3U50101A(E)_P14-23 3/31/05, 6:19 PM14
14
To clear your favorite channels:
1. Select a channel you want to clear.
2. Press MENU, then press or to display the OPTION menu.
3. Press
or to highlight FAVORITE CH.
4. Press or to display the FAVORITE CH menu. SET/CLEAR will
be highlighted.
PICTURE AUDIO SETUPCHOPTION
FAVORITE CH : CH 012
SET/CLEAR SET CLEAR
SET UP CH
TV CABLE
SELECT
END EXIT
5. Press
or to highlight CLEAR.
PICTURE AUDIO SETUPCHOPTION
FAVORITE CH : CH 012
SET/CLEAR SET CLEAR
SET UP CH
TV CABLE
SELECT
END EXIT
736 4 1
12 125 63 40
13 28 97 112
SET ENTER
736 4 1
12 125 63 40
13 28 97 112
CLEAR ENTER
Channel
Numbers
Exit
Menu/
Enter
Safeguards
Important
Welcome to
Toshiba
Connecting
your TV
6. Press ENTER until “0” replaces the channel number you want to
erase.
7. Press EXIT to clear the screen.
8. Repeat steps 1–6 for the other channels.
Using the LOCK menu
The LOCK menu includes the CH LOCK, VIDEO LOCK, GAMETIMER,
and NEW PIN CODE functions.
Selecting a PIN code
You can use these functions after entering the correct PIN code.
To select your PIN code and access the LOCK menus:
1. Press MENU, then press
2. Press or to highlight LOCK.
PICTURE AUDIO SETUPCHOPTION
CH LABEL START
FAVORITE CH
LOCK
ON/OFF TIMER
COLORSTREAM
SELECT START
ENGLISHLANGUAGE
START
START
OFF
DVD
3.Press or to display the BLOCKING menu.
or to highlight the OPTION menu.
Menu
Remote Control
Using the
Setting up
your TV
Using the TV’s
Using the TV’s
Features
Features
PICTURE AUDIO SETUPCHOPTION
LOCK
BLOCKING RESET
PIN CODE
SELECT
END EXIT
3U50101A(E)_P14-23 3/31/05, 6:19 PM15
SET ENTER
[0-9]
Appendix
15
4. Use the Channel Number buttons (0–9) to enter your PIN code.
If you are accessing the LOCK menus for the first time, select a
four-digit number to be your PIN code. Press ENTER. The
BLOCKING menu appears.
PICTURE AUDIO SETUPCHOPTION
LOCK
CH LOCK START
VIDEO LOCK
GAME TIMER
NEW PIN CODE
SELECT ADJUST
OFF
OFF
START
Note:
If you forget your PIN code, press RECALL
four times within five seconds from the
BLOCKING menu. This resets your PIN code
and allows you to proceed to the BLOCKING
menu.
Features
Using the TV’s
5. You may now enable blocking. See “Locking channels” (below), “To
change your PIN code” (below), or “Locking video input” (page
17), or “Setting the GameTimer™” (page 17).
To c hange your PIN code:
1. Press MENU, then press
or to display the OPTION menu.
2. Press or to highlight LOCK.
3. Press
or to display the BLOCKING menu.
4. Use the Channel Number buttons (0–9) to enter your PIN code.
Press ENTER. The BLOCKING menu appears.
5. Press
or to highlight NEW PIN CODE and press or to
display the NEW PIN CODE menu.
6. Use the Channel Number buttons (0–9) to enter a new code.
Press ENTER.
7. Press EXIT to return to normal viewing.
Locking channels
With the CH LOCK feature, you can lock specific channels. You will not
be able to tune locked channels unless you clear the setting. You can
choose to lock up to nine TV channels and nine cable channels.
To lock channels:
1. Use the Channel Number buttons (0–9, 100) to display the
television channel you wish to lock.
2. Press MENU, then press
3. Press or to highlight LOCK.
4. Press or to display the LOCK menu.
5. Use the Channel Number buttons (0–9) to enter your PIN code,
then press ENTER. The LOCK menu appears.
6. Press
or to highlight CH LOCK and press or to display
the CH LOCK menu.
7. Press
or to select the following:
• SET– to set the channel as one to be
locked. Then press ENTER.
• CLEAR– to clear all channels from
the list of locked channels.
Then press ENTER.
8. Repeat steps 1 through 7 to lock other
channels. When you are finished
locking channels, press EXIT to return
to normal viewing.
If you try to tune a locked channel, the
TV will not display it, but will display the
nearest unlocked channel.
or to display the OPTION menu.
PICTURE AUDIO SETUPCHOPTION
LOCK
CH LOCK START
VIDEO LOCK
GAME TIMER
NEW PIN CODE
SELECT ADJUST
PICTURE AUDIO SETUPCHOPTION
CH LOCK : CH 12
SET/CLEAR SET CLEAR
LOCKED CH
TV CABLE
SELECT
END EXIT
OFF
OFF
START
000
000
000
SET ENTER
Channel
Numbers
Recall
Exit
Menu/
Enter
Channel
Numbers
Exit
Menu/
Enter
Note:
After programming CH LOCK, change
channels before turning off the television.
3U50101A(E)_P14-23 3/31/05, 6:19 PM16
16
To unlock channels:
1. Press MENU, then press or to display the OPTION menu.
2. Press or to highlight LOCK and then press or to
display the LOCK menu.
3. Use the Channel Number buttons (0–9) to enter your PIN code,
then press ENTER. The LOCK menu appears.
4. Press
or to highlight CH LOCK and press or to display
the CH LOCK menu.
5. Press or to highlight CLEAR, and then press ENTER. This
clears all channels from the list of locked channels.
6. Press EXIT to return to normal viewing.
Locking video input
With the VIDEO LOCK feature, you can lock out the input sources
(VIDEO1, VIDEO2, COLORSTREAM) and channels 3 and 4.
You will not be able to select the input sources with the TV/VIDEO
button or Channel Numbers unless you clear the setting.
To set up the video lock:
1. Press MENU, then press
2. Press
or to highlight LOCK.
3. Press or to display the LOCK menu.
4. Use the Channel Number buttons (0–9) to enter your PIN code,
then press ENTER. The LOCK menu appears.
5. Press
or to highlight VIDEO LOCK.
6. Press or to select:
• OFF: Unlocks all video input
sources.
VIDEO: Locks VIDEO1, VIDEO2 and
•
COLORSTREAM.
• VIDEO +: Locks VIDEO1, VIDEO2,
COLORSTREAM, channel 3 and
channel 4. This option should be used if
you use the antenna terminal to play a
video tape.
7. Press EXIT to return to normal viewing.
Setting the GameTimer
With the GameTimerTM feature, you can automatically activate the
VIDEO LOCK feature (VIDEO setting)
TV game (30, 60, 90 or 120 minutes).
To set up the GameTimer:
1. Press MENU, then press
2. Press or to highlight LOCK.
3. Press or to display the LOCK menu.
4. Use the Channel Number buttons (0–9) to enter your PIN code,
then press ENTER. The LOCK menu appears.
5. Press
6. Press
minutes, 120 minutes or OFF).
7. Press EXIT to return to normal
viewing. After the GameTimer is
programmed, the display will appear
briefly every ten minutes to remind you
that the GameTimer is operating.
When the programmed time is
reached, the TV will change channels
automatically.
or to highlight GameTimer.
or to select a time limit (30 minutes, 60 minutes, 90
or to display the OPTION menu.
PICTURE AUDIO SETUPCHOPTION
LOCK
TM
CH LOCK START
VIDEO LOCK
GAME TIMER
NEW PIN CODE
SELECT ADJUST
OFF
VIDEO VIDEO+
OFF
START
to set a time limit for playing a
or to display the OPTION menu.
PICTURE AUDIO SETUPCHOPTION
LOCK
CH LOCK START
VIDEO LOCK
GAME TIMER
NEW PIN CODE
SELECT ADJUST
OFF
OFF 30 60 90 120
START
Channel
Numbers
Exit
Menu/
Enter
Note:
After programming VIDEO LOCK, change
channels or press the TV/VIDEO button
before turning off the television.
Channel
Numbers
Exit
Menu/
Enter
Safeguards
Important
Welcome to
Toshiba
Connecting
your TV
Remote Control
Using the
Setting up
your TV
Using the TV’s
Using the TV’s
Features
Features
Appendix
3U50101A(E)_P14-23 3/31/05, 6:19 PM17
17
SPACE
–0 9
+
• • •
–
• • •
A
Z
Labeling channels
Channel labels appear over the channel number display each time you
turn on the TV, select a channel, or press the Recall button. You can
choose any four characters to identify a channel.
To create channel labels:
1. Select a channel you want to label.
2. Press MENU, then press
3. Press or to highlight CH LABEL.
or until the OPTION menu appears.
Channel
Numbers
PICTURE AUDIO SETUPCHOPTION
CH LABEL START
FAVORITE CH
LOCK
ON/OFF TIMER
COLORSTREAM
SELECT START
4. Press
ENGLISHLANGUAGE
START
START
OFF
DVD
or to display the CH LABEL menu. SET/CLEAR will be
highlighted.
PICTURE AUDIO SETUPCHOPTION
CH LABEL : CH 12
SET/CLEAR SET CLEAR
LABEL
SELECT
END EXIT
SET ENTER
5. Press or to highlight SET.
6. Press
or to highlight LABEL.
PICTURE AUDIO SETUPCHOPTION
CH LABEL : CH 12
SET/CLEAR SET
LABEL
Exit
Menu/
Enter
Features
Using the TV’s
SELECT
END EXIT
SET ENTER
7. Press or to enter a character in the
first space. Press the button repeatedly
until the character you want appears
on the screen. Press ENTER.
8. Repeat step 7 to enter the rest of the
characters.
If you would like a blank space in the
label name, you must choose a blank
PICTURE AUDIO SETUPCHOPTION
CH LABEL : CH 12
SET/CLEAR SET
LABEL
SELECT
END EXIT
A
SET ENTER
space from the list of characters; otherwise, a dash will appear in
that space.
9. Repeat steps 1–8 for other channels. You can assign a label to
each channel.
10. Press EXIT to clear the screen.
To erase channel labels:
1. Select a channel with a label.
2. Press MENU, then press
3. Press
or to highlight CH LABEL.
or until the OPTION menu appears.
4. Press or to display the CH LABEL menu.
SET/CLEAR will be highlighted.
5. Press
or to highlight CLEAR.
6. Press ENTER.
7. Repeat steps 1–6 to erase other channel labels.
18
Note:
The character will change as below.
3U50101A(E)_P14-23 3/31/05, 6:19 PM18
Setting the clock
You must set the clock before you can program the ON/OFF timer.
To set the clock: (Example: 8:30 AM)
1. Press MENU, then press or to display the OPTION menu.
2. Press
or to highlight ON/OFF TIMER.
Safeguards
Important
PICTURE AUDIO SETUPCHOPTION
CH LABEL START
FAVORITE CH
LOCK
ON/OFF TIMER
COLORSTREAM
SELECT ADJUST
SET ENTER
3. Press
ENGLISHLANGUAGE
START
START
ON OFF SET
DVD
or to highlight SET, then press ENTER. The ON/OFF
TIMER menu appears.
4. Press
or to highlight CLOCK, then press or to
highlight the hour position.
PICTURE AUDIO SETUPCHOPTION
ON/OFF TIMER
CLOCK 12:00 AM
ON TIMER
12:00 AM CH 001
OFF TIMER
12:00 AM
SELECT
END EXIT
CLEAR
CLEAR
ADJUST
5. Press or to set the hour, then press to highlight the
minute position.
PICTURE AUDIO SETUPCHOPTION
ON/OFF TIMER
CLOCK 8:30 AM
ON TIMER
12:00 AM CH 001
OFF TIMER
12:00 AM
SELECT
END EXIT
CLEAR
CLEAR
ADJUST
Exit
Menu/
Enter
Note:
If the power source for the TV is interrupted
(for example, the power cord is unplugged or
a power failure occurs), you will need to reset
the clock.
Welcome to
Toshiba
Connecting
your TV
Remote Control
Using the
6. Press
or to set the minutes, then press EXIT to return to
normal viewing.
Setting the ON/OFF timer
Setting the ON timer
This feature allows you to program the TV to turn on automatically at a
set time. If you program the ON timer to “DAILY,” the TV will turn on every
day at the same time to the same channel until you clear the ON timer.
Note : You must set the clock before you can program the ON timer
(see above).
To set the ON timer: (Example: Turning on the TV to channel 12 at
7:00 AM, DAILY)
1. Press MENU, then press
2. Press
3. Press
or to highlight ON/OFF TIMER.
or to highlight SET, then press ENTER. The ON/OFF
TIMER menu appears.
4. Press or to highlight ON TIMER and press or to
highlight the hour position.
PICTURE AUDIO SETUPCHOPTION
ON/OFF TIMER
CLOCK 12:00 AM
ON TIMER
12:00 AM CH 001
OFF TIMER
12:00 AM
SELECT
END EXIT
CLEAR
CLEAR
ADJUST
or to display the OPTION menu.
19
Menu/
Enter
Note:
After a power failure or disconnection of the
power, the timer settings will be lost.
Setting up
your TV
Using the TV’s
Using the TV’s
Features
Features
Appendix
3U50101A(E)_P14-23 4/1/05, 9:51 AM19
5. Press or to set the desired hour, then press .
PICTURE AUDIO SETUPCHOPTION
ON/OFF TIMER
CLOCK 12:00 AM
ON TIMER
7:00 AM CH 001
OFF TIMER
12:00 AM
SELECT
END EXIT
CLEAR
CLEAR
ADJUST
6. Set the desired minutes and channel, as in step 5.
7. Press
or to select ONCE or DAILY timer date.
PICTURE AUDIOCHOPTIONSETUP
ON/OFF TIMER
CLOCK 12:00 AM
ON TIMER
7:00 AM CH 012
OFF TIMER
12:00 AM
SELECT
END EXIT
CLEARONCE DAILY
CLEAR
SET ENTER
8. Press EXIT to return to normal viewing.
To cancel the ON timer:
Select CLEAR in step 7 above.
Press EXIT to return to normal viewing.
Setting the OFF timer
This feature allows you to program the TV to turn off automatically at a set
time. If you program the OFF timer to “DAILY,” the TV will automatically
turn off every day at the same time.
Note : You must set the clock before you can program the OFF timer
(see page19).
To set the OFF timer: (Example: Turning off the TV at 11:30 PM)
1. Press MENU, then press
2. Press
3. Press
or to highlight ON/OFF TIMER.
or to highlight SET, then press ENTER.
The ON/OFF TIMER menu appears.
4. Press
or to highlight OFF TIMER, then press or to
highlight the hour position.
or to display the OPTION menu.
Exit
Note:
The ON TIMER has a one-hour automatic
shut off. One hour after the ON TIMER has
turned on the TV, the TV will turn off
automatically unless you press any button.
Features
Using the TV’s
PICTURE AUDIO SETUPCHOPTION
ON/OFF TIMER
CLOCK 12:00 AM
ON TIMER
7:00 AM CH 012
OFF TIMER
12:00 AM
SELECT
END EXIT
DAILY
CLEAR
ADJUST
5. Press or to set the desired hour, then press .
PICTURE AUDIO SETUPCHOPTION
ON/OFF TIMER
CLOCK 12:00 AM
ON TIMER
7:00 AM CH 012
OFF TIMER
11:00 PM
SELECT
END EXIT
DAILY
CLEAR
ADJUST
6. Set the desired minutes, as in step 5.
7. Press or to select ONCE or DAILY.
PICTURE AUDIO SETUPCHOPTION
ON/OFF TIMER
CLOCK 12:00 AM
ON TIMER
7:00 AM CH 012
OFF TIMER
11:30 PM
SELECT
END EXIT
DAILY
ONCE DAILY
CLEAR
SET ENTER
8. Press EXIT to return to normal viewing.
To cancel the OFF timer:
Select CLEAR in step 7 above.
Press EXIT to return to normal viewing.
Exit
Menu/
Enter
20
3U50101A(E)_P14-23 4/1/05, 9:51 AM20
Adjusting the picture quality
You can adjust the picture quality to your personal preferences,
including the contrast, brightness, color, tint, and sharpness. The
qualities you choose will be stored automatically in your TV’s memory.
To adjust the picture quality:
1. Press MENU, then press or to display the PICTURE menu.
PICTURE AUDIO SETUPCHOPTION
CONTRAST
BRIGHTNESS
COLOR 32
TINT
SHARPNESS
SELECT ADJUST
2. Press or until the item you want to adjust is highlighted.
3. Press
or to adjust the level.
Selection Pressing
contrast lower higher
brightness darker lighter
color paler deeper
tint reddish greenish
sharpness softer sharper
4. Press EXIT to return to normal viewing.
Watching video input
You can use the TV/VIDEO button on the remote control to view a signal
coming from other devices, such as a VCR or video disc player that may
be connected to your TV. (See “Connecting your TV” on page 7.)
Specifying the ColorStream® setting
You can use the ColorStream (component video) input for connecting
either a DVD player or a DTV receiver.
Note: This TV is not HD ready.
1. Press TV/VIDEO to put the TV in
ColorStream mode.
2. Press MENU, then press
the OPTION menu appears.
3. Press
or to highlight
COLORSTREAM.
4. Press
or to highlight DVD or
DTV, depending on which device is
connected.
5. Press EXIT to return to normal viewing.
Note:
The factory setting is DVD.
Displaying TV status information on-screen
Press RECALL to display the following
information on-screen:
• Clock
• Channel number or VIDEO mode
selected
• Channel label (if preset)
• Stereo or SAP (second audio program)
audio status
64
32
0
32
or until
PICTURE AUDIO SETUPCHOPTION
CH LABEL START
FAVORITE CH
LOCK
ON/OFF TIMER
COLORSTREAM
SELECT ADJUST
12:00 AM
STEREO
SAP
ENGLISHLANGUAGE
START
START
OFF
DVD DTV
CABLE 007
(TV)
ABCD
Exit
Menu
Reset
Note:
To reset the picture adjustments to the factory
settings, press RESET.
To select the input mode:
Press the TV/VIDEO button repeatedly to
select the desired mode. The signal source
you are connected to is displayed in light blue.
TV VIDEO 1
COLOR
STREAM
VIDEO 2
Recall
Menu
TV/VIDEO
Safeguards
Important
Welcome to
Toshiba
Connecting
your TV
Remote Control
Using the
Setting up
your TV
Using the TV’s
Using the TV’s
Features
Features
Appendix
3U50101A(E)_P14-23 3/31/05, 6:19 PM21
21
Setting the sleep timer
You can set the TV so it turns off automatically.
To set the sleep timer:
Repeatedly press SLEEP on the remote control to set the length of
time until the TV turns off. The clock will count down 10 minutes for
each press of the SLEEP button (120, 110, ...10, 0). After the sleep
time is programmed, the display will appear briefly every ten minutes
to remind you that the sleep timer is operating.
To confirm the sleep timer setting:
Press SLEEP one time. The remaining time will be momentarily
displayed.
To cancel the sleep timer:
Repeatedly press SLEEP until the display turns to 0.
Sleep
Features
Using the TV’s
Using the closed caption feature
The closed caption feature has two options: captions or text. A caption
is a printed version of the dialogue, narration and/or sound effects of a
program. Text is information not related to the program that appears on
half of the TV screen when available.
To view captions or text:
1. Select the desired program. Closed captioned programs are
usually marked in your local TV listing as “CC.”
2. Press CAP/TEXT repeatedly to select caption or text mode.
CAPTION CH1 TEXT CH1
3. Press 1/2 to select the caption or text channel.
CAPTION CH2
4. To turn off the closed caption feature, press CAP/TEXT
repeatedly until captions or text no longer display on-screen.
TEXT CH2
1/2
CAP/TEXT
Note:
A closed caption signal may not be decoded
in the following situations:
• When a video tape has been dubbed.
• When the signal reception is weak.
• When the signal reception is non-standard.
When you select the text mode, the text
screen always appears as a black box. When
there is no signal, however, the text screen
will not display text characters. Repeatedly
press CAP/TEXT until the box disappears.
NOTICE OF POSSIBLE ADVERSE
EFFECTS ON TV PICTURE DISPLAY
Avoid displaying stationary images on your
TV screen for extended periods of time.
Fixed (non-moving) patterns or images
(including but not limited to PIP/POP
windows, closed captions, video game
patterns, TV station logos, stock tickers,
websites, and special formats that do not
use the entire screen) can become
permanently ingrained in the cathode ray
tube(s) of the TV and cause subtle but
permanent ghost images. This type of
damage is NOT COVERED BY YOUR
WARRANTY. See page 4 for details.
3U50101A(E)_P14-23 3/31/05, 6:19 PM22
22
Adjusting the sound
Muting the sound
Press MUTE to temporarily turn off the sound. While the sound is off,
the screen will display the word “MUTE” in the lower right-hand corner.
To restore the sound, press MUTE again.
Safeguards
Important
Selecting stereo/SAP broadcasts
You can listen to high-fidelity stereo sound with the Multi-channel TV
Sound (MTS) feature. MTS can also transmit a second audio program
(SAP) containing a second language or other audio information.
When the TV receives a stereo or SAP broadcast, the word STEREO
or SAP appears on-screen every time the TV is turned on, the channel
is changed, or the RECALL button is pressed.
The MTS feature is not available in the VIDEO mode.
You can leave your TV in STEREO mode because it will automatically
output stereo or monaural sound, depending on the broadcast type. If
the stereo sound is noisy, select MONO to reduce the noise. The word
STEREO or SAP is displayed in light blue when the TV receives the
signal.
To select the desired MTS setting:
Repeatedly press the MTS button to select either STEREO, SAP,
MONO+SAP, or MONO. If the current program is not available in
stereo or SAP, the setting will not be available when you press the
MTS button.
Adjusting the sound quality
You can change the sound quality of your TV by adjusting the bass,
treble, and balance.
To adjust the sound quality:
1. Press MENU, then press
or until the AUDIO menu appears.
Recall
Mute
MTS
STEREO
MONO
SAP
MONO + SAP
If the current program is not broadcasting
either stereo or SAP, those settings will not be
available when you press the MTS button.
Welcome to
Toshiba
Connecting
your TV
Remote Control
Using the
PICTURE AUDIO SETUPCHOPTION
BASS
TREBLE
BALANCE
SURROUND
STABLE SOUND
SELECT ADJUST
OFF
OFF
32
32
0
2. Press or to highlight the item you want to adjust.
3. Press
or to adjust the level.
PICTURE AUDIO SETUPCHOPTION
BASS
TREBLE
BALANCE
SURROUND
STABLE SOUND
SELECT ADJUST
OFF
OFF
32
32
0
• makes the sound quality weaker or decreases the balance in
the right channel, depending on the item selected.
makes the sound quality stronger or decreases the balance in
•
the left channel, depending on the item selected.
23
Menu
Reset
Note:
To reset your audio adjustments to the factory
settings, press RESET.
Setting up
your TV
Using the TV’s
Using the TV’s
Features
Features
Appendix
3U50101A(E)_P14-23 3/31/05, 6:19 PM23
Using the surround sound feature
The surround sound feature expands the audio listening field wider and
deeper to create exceptional sound quality from the TV’s speakers.
The feature uses stereo signals from a TV broadcast or video input.
To turn on the surround sound feature:
1. Select the STEREO mode, if available (see “Selecting stereo/SAP
broadcasts” on page 23.)
2. Press MENU, and then press
appears.
3. Press
4. Press
BASS
TREBLE
BALANCE
SURROUND
STABLE SOUND
SELECT ADJUST
or to highlight SURROUND.
or to highlight ON.
PICTURE AUDIO SETUPCHOPTION
OFF
ON
OFF
To turn off the surround sound feature:
Highlight OFF in step 4 above.
In general, you can leave your TV in surround mode because it will
automatically output the type of sound being broadcast (surround
stereo or monaural).
or until the AUDIO menu
32
32
0
Menu
Features
Using the TV’s
Using the StableSound® feature
The StableSound feature limits the highest volume level to prevent
extreme changes in volume when the signal source is changed.
®
To turn on the StableSound
feature:
1. Press MENU, then press or until the AUDIO menu appears.
2. Press or to highlight STABLE SOUND.
3. Press
To turn off the StableSound
or to highlight ON.
PICTURE AUDIO SETUPCHOPTION
BASS
TREBLE
BALANCE
SURROUND
STABLE SOUND
SELECT ADJUST
OFF
ON OFF
32
32
0
®
feature:
Highlight OFF in step 3 above.
Auto power off
The TV will automatically turn off after approximately 15 minutes if it is tuned to a vacant channel or a station that completes
broadcast for the day and stops broadcasting on that channel. This feature does not work in VIDEO mode.
its
Understanding the Power Return feature
If the power is cut off while you are viewing the TV and the power is resupplied, the Power Return feature will turn the TV
on automatically.
If the power is going to be off for a long time or you are going to be away from the TV for a long time, unplug the power cord
from the wall outlet to prevent the TV from turning on in your absence.
3U50101A(E)_P24-BACK 3/31/05, 6:19 PM24
24
Appendix
Troubleshooting
Before calling a service technician, please check the following table for a possible cause of the problem and some solutions.
Problem Solution
TV will not turn on • Make sure the power cord is plugged in, then press POWER.
• The remote control batteries may be dead. Replace the batteries.
No picture, no sound • Check the antenna/cable connections.
• This TV will not accept or display 480p or 720p progressive scan
signals or 1080i interlaced high-definition signals through its
ColorStream inputs. Switch the other device’s output to 480i interlaced
mode first (see page 9).
No sound, picture OK • The sound may be muted. Press VOLUME.
• The station may have broadcast difficulties. Try another
• The MTS feature may be in SAP mode. Press the MTS button on the
remote control until STEREO (or MONO) mode is active.
Poor sound, picture OK • The station may have broadcast difficulties. Try another channel.
• The MTS feature may be in SAP mode. Press the MTS button on the
remote control until STEREO (or MONO) mode is active.
Poor picture, sound OK • Check the antenna connections.
• The station may have broadcast difficulties. Try another channel.
• Adjust the PICTURE menu.
• This TV will not accept or display 480p or 720p progressive scan
signals or 1080i interlaced high-definition signals through its
ColorStream inputs. Switch the other device’s output to 480i interlaced
mode first (see page 9).
Poor reception of broadcast channels • The station may have broadcast difficulties. Try another channel.
• Check the antenna connections.
• If you are using a VCR, make sure the TV/VCR button is set correctly.
Cannot receive above channel 13 • Make sure the TV/CABLE feature in the SETUP menu is set to “CABLE.”
Unable to select a certain channel • The channel may be blocked by the CH LOCK feature, or erased with
the add/erase feature.
Cannot access signal input sources (Video1, • Check the VIDEO LOCK feature.
Video2 and ColorStream) and/or Channels 3 and 4
Multiple images • The station may have broadcast difficulties. Try another channel.
• Use a highly directional outdoor antenna.
Poor color or no color • The station may have broadcast difficulties. Try another channel.
• Adjust the TINT and/or COLOR in the PICTURE menu.
• If you change the direction of the TV while it is turned on, the picture
could suffer from color shading. If so, turn off the TV and allow it to cool
for several hours before turning it on again.
Black box on screen • Repeatedly press CAP/TEXT to turn off the Closed Caption Text mode.
No stereo or SAP sound from a • Make sure the MTS feature is set properly.
known MTS broadcast
The PIN code does not work • Change or reset your PIN code (pages 15 and 16).
The remote control does not operate • Remove all obstructions between the remote control and the TV.
• The remote control batteries may be dead. Replace the batteries.
channel.
Safeguards
Important
Welcome to
Toshiba
Connecting
your TV
Remote Control
Using the
Setting up
your TV
Using the TV’s
Features
Appendix
Appendix
3U50101A(E)_P24-BACK 3/31/05, 6:20 PM25
25
Specifications
• This model complies with the specifications below.
• Design and specifications are subject to change without notice.
• This model may not be compatible with features and/or specifications that may be added in the future.
Picture Tube 676 mm (27 in.) diagonal (Screen size is approximate.)
Television system NTSC standard
Channel coverage VHF: 2–13
UHF: 14–69
Cable TV: 4A, A-5–A-1, A-I,
J–W, W+1–W+84
Power source 120V AC, 60 Hz
Power consumption 125 W
Audio power 2.5 W + 2.5 W
Speaker type 50.8 mm x 88.9 mm (2 in. x 3-1/2 in.) x 2 pcs.
Video/Audio terminals S-VIDEO INPUT
Y-INPUT: 1V (p-p), 75 ohm, negative sync.
C-INPUT: 0.286V (p-p) (burst signal), 75 ohm
VIDEO/AUDIO INPUT
VIDEO: 1V (p-p), 75 ohm, negative sync.
AUDIO: 150 mV (rms) (30% modulation equivalent, 47k ohm)
ColorStream
Y : 1V (p-p), 75 ohm
PR : 0.7V (p-p), 75 ohm
PB : 0.7V (p-p), 75 ohm
Dimensions Width : 650 mm (25-9/16 in.)
Height : 571.5 mm (22-1/2 in.)
Depth : 500.5 mm (19-11/16 in.)
Weight 80.5 Ibs. (36.5 kg)
Supplied accessories Remote control with two size “AAA” batteries
®
(component video) INPUT
Appendix
3U50101A(E)_P24-BACK 3/31/05, 6:20 PM26
26
Limited Canada Warranty
for 27'' and All Smaller Television Models
Safeguards
Important
Toshiba of Canada Limited (“TCL”) makes the following limited
warranties to original consumers in Canada. THESE LIMITED
WAR RANTIES EXTEND TO THE ORIGINAL CONSUMER
PURCHASER OR ANY PERSON RECEIVING THIS TELEVISION AS A
GIFT FROM THE ORIGINAL CONSUMER PURCHASER AND TO NO
OTHER PUR CH ASER OR TRANSFEREE.
PRODUCTS PURCHASED IN CANADA AND USED ANYWHERE
OUTSIDE OF CANADA, INCLUDING, WITHOUT LIMITATION, THE
U.S.A. AND MEXICO, ARE NOT COVERED BY THESE WARRANTIES.
PRODUCTS PURCHASED ANYWHERE OUTSIDE OF CANADA,
INCLUDING, WITHOUT LIMITATION, THE U.S.A. AND MEXICO,
AND USED IN CANADA, ARE NOT COVERED BY THESE WARRANTIES.
Limited One (1) Year Warranty on Parts and Labor*
TCL warrants this television and its parts against defects in materials
or workmanship for a period of one (1) year after the date of original
retail purchase.
OPTION, REPAIR OR REPLACE A DEFECTIVE PART WITH A NEW
OR REFURBISHED PART WITHOUT CHARGE TO YOU FOR PARTS
OR LABOR. YOU MUST DELIVER THE ENTIRE TELEVISION TO
AN AUTHORIZED TCL SERVICE DEPOT. YOU MUST PAY FOR ALL
TRANSPORTATION AND INSURANCE CHARGES FOR THE
TELEVISION TO AND FROM THE SERVICE DEPOT.
Limited Two (2) Year Warranty on Picture Tube*
TCL further warrants the picture tube in this television against defects
in materials or workmanship for a period of two (2) years after the
date of original retail purchase.
AT TC L’S OPTION, REPAIR OR R EPLACE A DEFECTIVE PICTURE
TUBE WITH A NEW OR REFURBISHED PICTURE TUBE WITHOUT
CHARGE TO YOU, EXCEPT THAT, IF A DEFECTIVE PICTURE TUBE
IS REPAIRED OR REPLACED AFTER ONE (1) YEAR FROM THE
DATE OF THE ORIGINAL RETAIL PURCHASE, YOU MUST PAY
ALL LABOR CHARGES INVOLVED IN THE REPAIR OR
REPLACEMENT. YOU MU ST DE LIVER THE ENTIRE TELEVISION
TO AN AUTHORIZED TCL SERVICE DEPOT. YOU MUST PAY FOR
ALL TRAN SPORTATION AND INSURANCE CHARGES FOR THE
TELEVISION TO AND FROM THE SERVICE DEPOT.
Rental Units
The warranty for rental units begins with the first rental or thirty (30)
days from the date of shipment to the rental firm, whichever comes first.
*Limited Warranty for Commercial Units
TCL warrants televisions sold and used for commercial purposes as
follows: all parts are warranted against defects in materials or
workmanship for a period of ninety (90) days after the date of original
purchase.
REPAIR OR REPLACE A DEFECTIVE PART WITH A NEW OR
REFURBISHED PART WITHOUT CHARGE TO YOU FOR PARTS
OR LABOR. YOU MUST DELIVER THE ENTIRE TELEVISION TO
AN AUTHORIZED TCL SERVICE DEPOT. YOU MUST PAY FOR
ALL TRANSPORTATION AND INSURANCE CHARGES FOR THE
TELEVISION TO AND FROM THE SERVICE DEPOT.
Owner s Manual and Product Registration
Read this owner’s manual thoroughly before operating this television.
Register your product online at www.toshiba.ca as soon as possible.
By registering your product, you will enable TCL to bring you new
products specifically designed to meet your needs and help us to
contact you in the unlikely event a safety notification is required.
Failure to register your product does not diminish your warranty
rights.
DURING THIS PERIOD, TCL WILL, AT TCL’S
DURING THIS PERIOD, TCL WILL,
DURING THIS PERIOD, TCL WILL, AT TCL’S OPTION,
Your Responsibility
THE ABOVE WARRANTIES ARE SUBJECT TO THE FOLLOWING
CONDITIONS:
(1) You must provide your bill of sale or other proof of purchase.
(2) All warranty servicing of this television must be performed by an
Authorized TCL Service Depot.
(3) These warranties from TCL are effective only if the television is
purchased in Canada from an authorized TCL dealer and
operated in Canada.
(4) Labor charges for installation, setup, adjustment of customer
controls, and installation or repair of antenna systems are not
covered by these warranties. Reception problems caused by
inadequate antenna systems are your responsibility.
(5) Warranties extend only to defects in materials or workmanship
as limited above and do not extend to any television or parts that
have been lost or discarded by you or to damage to any television
or parts caused by fires, misuse, accident, Acts of God (such as
lightning or fluctuations in electric power), improper installation,
improper maintenance, or use in violation of instructions
furnished by TCL; or to units that have been modified or had the
serial number removed, altered, defaced, or rendered illegible.
How to Obtain Warranty Services
If, after following all of the operating instructions in this manual and
checking the “Troubleshooting” section, you find that service is needed:
(1) To find the nearest TCL Authorized Service Depot, visit TCL’s web site
at www.toshiba.ca.
(2) Present your bill of sale or other proof of purchase to the Authorized
Service Depot. You must deliver the entire television to an Authorized
TCL Service Depot. You must pay for all transportation and insurance
charges for the television to and from the Service Depot.
For additional information,
visit TCL s web site: www.toshiba.ca
ALL WARRANTIES IMPLIED BY THE LAW OF ANY PROVINCE OF
CANADA, INCLUDING TH E IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE,
ARE EXPRESSLY LIMITED TO THE DURATION OF THE LIMITED
WARRANTIES SET FORTH ABOVE. WITH TH E EXCE PTION OF ANY
WAR RANTIES IMPLIED BY THE LAW OF ANY PROVINCE OF
CANADA AS H EREBY LIMITED, THE FOREGOING WARRANTY IS
EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES,
GUARANTEES, AGREEMENTS, AND SIMILAR OBLIGATIONS OF
TCL WITH RESPECT TO THE REPAIR OR REPLACEMENT OF ANY
PARTS. IN NO EVENT SHALL TCL BE LIABLE FOR
CONSEQUENTIAL OR INCIDENTAL DAMAGES (INCLUDING, BUT
NOT LIMITED TO, LOST PROFITS, BUSINESS INTERRUPTION, OR
MODIFICATION OR ERASURE OF RECORDED DATA CAUSED BY
USE, MISUSE, OR INABILITY TO USE TH IS PRODUCT).
No person, agent, distributor, dealer, or company is authorized to
change, modify, or extend the terms of these warranties in any manner
whatsoever. The time within which action must be commenced to
enforce any obligation of TCL arising under this warranty or under any
law of Canada or of any province thereof is hereby limited to 90 days
from the date you discover, or should have discovered, the defect. This
limitation does not apply to implied warranties arising under the law of
any province of Canada.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND
YOU MAY ALSO HAVE OTHER RIGHTS, WHICH MAY VARY
FROM PROVINCE TO PROVINCE IN CANADA. SOME
PROVINCES OF CANADA DO NOT ALLOW LIMITATIONS ON
HOW LONG AN IMPLIED WARRANTY LASTS, WHEN AN
ACTION MAY BE BROUGHT, OR THE EXCLUSION OR
LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES,
SO THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT
APPLY TO YOU UNDER SUCH CIRCUMSTANCES.
Welcome to
Toshiba
Connecting
your TV
Remote Control
Using the
Setting up
your TV
Using the TV’s
Features
Appendix
Appendix
3U50101A(E)_P24-BACK 3/31/05, 6:20 PM27
27
TEL.: (905) 470-5400
Service Centers:
TORONTO: 191 McNABB STREET,
MARKHAM, ONTARIO, L3R 8H2, CANADA
TEL.: (905) 470-5400
MONTREAL: 18050 TRANS CANADA, KIRKLAND,
QUEBEC, H9J-4A1, CANADA
TEL.: (514) 390-7766
VANCOUVER: 22171 FRASERWOOD WAY,
ColorStream® and StableSound® are registered trademarks of Toshiba America Consumer Products, L.L.C.
GameTimer is a trademark of Toshiba America Consumer Products, L.L.C.
RICHMOND, B.C., V62 1J5, CANADA
TEL.: (604) 303-2500
PRINTED IN THAILAND
3U50101A(E)_P24-BACK 3/31/05, 6:20 PM28
28
Loading...
